Pioneer AVHP-6500-DVD, AVHP-6550-DVD Service manual

PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2003
K-ZZU. APR. 2003 Printed in Japan
ORDER NO.
CRT3038
AVH-P6500DVDUC
- This service manual should be used together with the following manual(s):
Model No. Order No. Mech. Module Remarks CX-3016 CRT3056 MS3 DVD Mech. Module:Circuit Description, Mech.Description, Disassembly
AVH-P6500DVD/UC
NOTE:
- Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works. © 1992-1997 Dolby Laboratories. All rights reserved.
- Inverter for LCD back light becomes a high voltage.
For details, refer to "Important symbols for good services".
AVH-P6500DVDEW AVH-P6550DVDRC,RD
2
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

SAFETY INFORMATION

- DVD Player Service Precautions
1. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on mode may damage the ICs inside the unit.
2. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-sol­der) by referring to “ the DISASSEMBLY” on page 167.
3. Please adjusting the skew after changing the pickup unit(see page 133).
4. During disassembly, be sure to turn the power off since an internal IC might be destroyed when a connector is plugged or unplugged.
UC
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause cancer, birth defects or other reproductive harm. Health & Safety Code Section 25249.6 - Proposition 65
EW
1. Safety Precautions for those who Service this Unit.
Follow the adjustment steps (see pages 129 through 166)in the service manual when servicing this unit. When check-
ing or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable results.
Caution:
1. During repair or tests, minimum distance of 13cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
2. The triangular label is attached to the mechanism unit frame.
3
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
On the top of the player.
CAUTION : VORSICHT : ADVARSEL : VARNING : VARO! :
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1860
CLASS 1 LASER PRODUCT
WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1 but the laser component is capable of emitting radiation exceeding the limit for CLASS 1. A specially instructed person should do servicing operation of the apparatus.
Laser diode characteristics
Wave length:
DVD:640~660nm CD:770~810nm
Maximum output:2.44mw(Emitting period :9sec.)
DVD:743mw(Emitting period : unlimited)
Additionla Laser Caution
Transistors Q1101 and Q1102 in PCB drive the laser diodes for DVD and CD respectively. When Q1101 or Q1102 is shorted between their terminals, the laser diodes for DVD or CD will radiate beam. If the top cover is removed with no disc loaded while such short-circuit is continued, the naked eyes may be exposed to the laser beam.
4
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely. When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable. In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning, proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual.
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC
CAUTION
Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type recommended by the manufacture. Discord used batteries according to the manufacture's instructions.
ES
CAUTION
Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type.
Battery
Slide the tray out on the back of the remote controller and insert the battery with the (+) and (–) poles pointing in the proper direction.
Note :
Use a CR2025 (3V) lithium battery only. Never use other types of battery with this unit.
5
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC

CONTENTS

SAFETY INFORMATION ............................................2
1. SPECIFICATIONS........................................................6
2. EXPLODED VIEWS AND PARTS LIST.......................8
2.1 PACKING...............................................................8
2.2 EXTERIOR(1).......................................................10
2.3 EXTERIOR(2).......................................................14
2.4 EXTERIOR(3).......................................................16
2.5 DVD MECHANISM MODULE.............................18
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...20
3.1 BLOCK DIAGRAM ..............................................20
3.2 OVERALL CONNECTION DIAGRAM.................26
3.3 MOTHER PCB(GUIDE PAGE).............................28
3.4 RELAY PCB .........................................................34
3.5 EXTENSION PCB................................................35
3.6 DVD CORE UNIT(MS3)(SODC)(GUIDE PAGE) .36
3.7 DVD CORE UNIT(MS3)(CPU)(GUIDE PAGE) ....42
3.8 COMPOUND(A) AND COMPOUND UNIT(B)........50
3.9 PU UNIT(REFERENCE).......................................51
3.10 TUNER UNIT.....................................................52
3.11 INVERTER PCB .................................................54
3.12 MONITOR PCB,UPPER PCB AND SENSE PCB(GUIDE PAGE)56
3.13 GRILLE PCB ......................................................62
3.14 PANEL PCB .......................................................64
3.15 MAIN UNIT,SW UNIT AND VOLUME UNIT ...66
4. PCB CONNECTION DIAGRAM ...................................68
4.1 MOTHER PCB .....................................................68
4.2 RELAY PCB AND EXTENSION PCB ..................72
4.3 DVD CORE UNIT(MS3) ......................................74
4.4 COMPOUND UNIT(A) AND COMPOUND UNIT(B) ...78
4.5 TUNER UNIT.......................................................80
4.6 INVERTER PCB ...................................................82
4.7 MONITOR PCB ...................................................84
4.8 UPPER PCB .........................................................88
4.9 SENSE PCB.........................................................89
4.10 GRILLE PCB ......................................................90
4.11 PANEL PCB .......................................................91
4.12 MAIN UNIT .......................................................92
4.13 SW UNIT AND VOLUME UNIT........................94
5. ELECTRICAL PARTS LIST ...........................................95
6. ADJUSTMENT ..........................................................129
6.1 JIG CONNECTION DIAGRAM .........................129
6.2 DVD ADJUSTMENT .........................................130
6.3 MAIN VIDEO LEVEL ADJUSTMENT ...............150
6.4 MONITOR PCB ADJUSTMENT .......................152
6.5 INVERTER PCB ADJUSTMENT .......................156
6.6 MOTHER PCB ADJUSTMENT .........................157
6.7 MONITOR TEST MODE ...................................158
6.8 DOT CLOCK ADJUSTMENT ............................162
6.9 TOUCH PANEL CALIBRATION ........................163
7. GENERAL INFORMATION........................................167
7.1 DIAGNOSIS ......................................................167
7.1.1 DISASSEMBLY ........................................167
7.1.2 PCB LOCATIONS .....................................173
7.1.3 CONNECTOR FUNCTION DESCRIPTION
.174
7.2 PARTS ...............................................................176
7.2.1 IC ..............................................................176
7.2.2 DISPLAY...................................................202
7.3 OPERATIONAL FLOW CHART.........................203
7.4 CLEANING ........................................................204
8.OPERATIONS .............................................................205
6
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

1. SPECIFICATIONS

7
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
8
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

2. EXPLODED VIEWS AND PARTS LIST

NOTE:
- Parts marked by * are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to
mark on the product are used for disassembly.
- For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions, apply as you think it appropriate.)

2.1 PACKING

23
24
29
30
31
25
27
19
28
22
18
17
16
20
15
34
14
21
13
36
1
12
35
33
11
32
2
4
6
10
7
9
8
5
7
6
3
9
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
- PACKING SECTION PARTS LIST
Part No. MarkNo. Description P6500DVD/UC P6500DVD/EW P6550DVD/RC P6550DVD/RD * 1-1 Polyethylene Bag CEG1116 CEG1116 CEG1116 CEG1116
1-2 Owner’s Manual CRB1836 CRB1830 CRB1838 CRB1838 1-3 Owner’s Manual CRB1837 CRB1831 CRB1839 CRB1840 1-4 Installation Manual CRD3782 CRD3781 CRD3783 CRD3784
* 1-5 Card ARY1048 Not used Not used Not used
2 Carton CHG5077 CHG5076 CHG5078 CHG5079 3 Contain Box CHL5077 CHL5076 CHL5078 CHL5079 4 Air Cushioned Bag CEG1089 CEG1089 CEG1089 CEG1089 5 Polyethylene Bag CEG1173 CEG-162 CEG-162 CEG-162 6 Protector CHP2707 CHP2707 CHP2707 CHP2707
7 Protector CHP2706 CHP2706 CHP2706 CHP2706 8 Protector CHP2387 CHP2387 CHP2387 CHP2387 9 Protector CHP2708 CHP2708 CHP2708 CHP2708
10 Remote Control Unit CXC1224 CXC1226 CXC1226 CXC1226
* 11 Polyethylene Bag E36-615 E36-615 E36-615 E36-615
12 Screw CBA1650 CBA1650 CBA1650 CBA1650 13 Bush CNV1917 CNV1917 CNV1917 CNV1917 14 Cord Assy CDE7168 CDE7168 CDE7168 CDE7168 15 Cord Assy CDE7193 Not used CDE7193 CDE7193 16 Cord Assy CDE7194 CDE7194 CDE7194 CDE7194
17 Cord Assy CDE7321 CDE7321 CDE7321 CDE7321 18 Cord Assy CDE7187 CDE7187 CDE7187 CDE7187 19 Antenna Cable CDH1281 CDH1281 CDH1281 CDH1281 20 Sheet CNM7244 CNM7244 CNM7244 CNM7244 21 Sub Craton CHG5080 CHG5080 CHG5080 CHG5080
* 22 Polyethylene Bag CEG-158 CEG-158 CEG-158 CEG-158
23 Screw Assy CEA3686 CEA3686 CEA3686 CEA3686 24 Screw CBA1468 CBA1468 CBA1468 CBA1468 25 Screw CMZ50P060FTC CMZ50P060FTC CMZ50P060FTC CMZ50P060FTC 27 Screw BMZ50P060FTC BMZ50P060FTC BMZ50P060FTC BMZ50P060FTC
* 28 Polyethylene Sheet CNM4338 CNM4338 CNM4338 CNM4338 * 29 Lock Tie Not used CNV-754 CNV-754 CNV-754 * 30 Fastener CNM6544 CNM6544 CNM6544 CNM6544 * 31 Fastener CNM6545 CNM6545 CNM6545 CNM6545
32 Accessory Assy CEA3685 CEA3685 CEA3743 CEA3743
33 Fixing Screw JGZ20P070FMC JGZ20P070FMC Not used Not used 34 Cord Assy Not used CDE7192 Not used Not used
* 35-1 Polyethylene Bag Not used CEG1116 Not used Not used
35-2 Owner’s Manual Not used CRB1832 Not used Not used 35-3 Owner’s Manual Not used CRB1833 Not used Not used
35-4 Owner’s Manual Not used CRB1834 Not used Not used
35-5 Owner’s Manual Not used CRB1835 Not used Not used * 35-6 Passport Not used CRY1013 Not used Not used * 35-7 Warranty Card Not used CRY1157 Not used Not used * 35-8 Caution Card CRP1298 CRP1298 Not used Not used
36 Cleaning Cloth Assy CEA3952 CEA3952 CEA3952 CEA3952
- Owner's Manual, Installation Manual
Part No. Language CRB1836 English CRB1837 French CRD3782 English,French CRB1830 English CRB1831 Spanish CRB1832 German CRB1833 French CRB1834 Italian
Part No. Language CRB1835 Dutch CRD3781 English,Spanish,German,
French,Italian,Dutch CRB1838 English CRB1839 Traditional chinese CRB1840 Spanish CRD3783 English,Traditional chinese CRD3784 English,Spanish
10
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

2.2 EXTERIOR(1)

11
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
1 Screw CMZ50P060FTC 2 Case
See Contrast table(2)
3 Panel CNB2828 4 Holder CNC9510 5 Screw IMS26P050FTC
6 Holder CND1435 7 Bracket CND1438 8 Bracket CND1439 9 Holder CND1440
10 Holder CND1441
11 Bracket CND1482 12 Bracket CND1603 13 Insulator CNM8110 14 Insulator CNM8495 15 Cord Assy
See Contrast table(2)
16 Transistor(Q851) 2SD2375 17 Panel
See Contrast table(2)
18 IC(IC308) PAL007A 19 Mother Unit
See Contrast table(2)
20 Screw BMZ26P160FTC
21 Screw BSZ26P080FTC 22 Clamper CEF1009 23 Terminal(CN155)
See Contrast table(2)
24 Connector(CN701) CKM1332 25 Connector(CN301) CKM1389
26 Connector(CN972) CKS1940 27 Connector(CN1702) CKS1944 28 Connector(CN971) CKS2191 29 Connector(CN801) CKS3124 30 Connector(CN156) CKS3131
31 Connector(CN154) CKS3132 32 Connector(CN803) CKS3751 33 Connector(CN202) CKS3902 34 Connector
(CN101,CN5901)
CKS3986
35 Connector(CN805) CKS4068
36 Connector(CN203) CKS4132 37 Connector(CN152) CKS4249 38 Connector(CN151)
See Contrast table(2)
39 Connector(CN1502) CKS4467 40 Connector(CN1701) CKS4496
41 Connector(CN1500) CKS4680 42 Connector(CN153) CKS4681 43 Connector(CN201) CKS4691 44 Holder CNC5399 45 Holder CND1433
46 Holder CND1434 47 Holder CND1436 48 Holder CND1437 49 Heat Sink CNR1684 50 Heat Sink CNR1703
51 Clamper CNV1251 52 Fan Motor CXM1262 53 Screw BMZ20P025FTC 54 Screw BMZ20P030FZK 55 Screw BMZ26P030FZK
56 Screw BMZ26P040FTC 57 Sheet CNM8526 58 Screw(M2x2) CBA1551 59 Label
See Contrast table(2)
60 Cord CDE6574
61 Cord Assy CDE7167 62 Cord Assy CDE7175 63 Cord Assy CDE7176 64 Cable CDE7178 65 Cable CDE7282
66
DVD Mechanism Module(MS3)
CXK6310 67 Screw PMZ20P160FTC 68 Button CAC7953 69 Screw CBA1111 70 Spring CBH2681
71 Spring CBH2682 72 Spring CBH2683 73 Cable CDE7179 74 Holder CND1841 75 Insulator CNM8510
76 Arm CNV7567 77 Arm CNV7568 78 Arm CNV7569 79 Panel Unit
See Contrast table(2)
80 Screw(M2 x 4) CBA1734
81 Screw BPZ20P080FZK 82 Button(Detach)
See Contrast table(2)
83 Button(Eject) See Contrast table(2) 84 Button(SRC) CAC7946 85 Button(EQ) CAC7947
86 Button
See Contrast table(2)
87 Button(Reset) See Contrast table(2) 88 Button CAC8149
* 89 Badge
See Contrast table(2)
90 Spring CBH2680
91 Cover CNS7441 92 Keyboard Unit
See Contrast table(2)
93 Sheet CNM8514 94 Connector(CN5501) CKS4657 95 Connector(CN5902) CKS4658
96 Grille Unit
See Contrast table(2)
97 Knob Unit CXC2034 98 Clamper
See Contrast table(2)
99 Sheet CNM8515
100 Cusion CNM8516
101 Holder CND1840 102 Insulator CNM8521 103 Screw(M2.6 x 2.5) CBA1482 104 Screw(M2.6 x 4) CBA1738 105 Spacer CNM8552
106 Spacer CNM8575
(1) EXTERIOR(1) SECTION PARTS LIST
Mark No. Description Part No.
Mark No. Description Part No.
12
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC
(2) CONTRAST TABLE
AVX-P6500DVD/UC , AVX-P6500DVD/EW , AVX-P6550DVD/RC and AVX-P6550DVD/RD are constructed
the same except for the following:
Part No.
Mark No. Description P6500DVD/UC P6500DVD/EW P6550DVD/RC P6550DVD/RD
2 Case CNB2910 CNB2910 CNB2911 CNB2911 15 Cord Assy CDE7177 CDE7177 Not used Not used 17 Panel CNS7480 CNS7480 CNS7481 CNS7481
19 Mother Unit CWM8760 CWM8759 CWM8761 CWM8762 23 Terminal(CN155) CKF-047 CKF-047 Not used Not used
38 Connector(CN151) CKS4454 CKS4454 Not used Not used 59 Label Not used VRW1860 Not used Not used 79 Panel Unit CXC1895 CXC1895 CXC1896 CXC1896
82 Button(Detach) CAC7944 CAC7944 CXC7951 CXC7951 83 Button(Eject) CAC7945 CAC7945 CXC7950 CXC7950
86 Button CAC7948 CAC7948 CXC7949 CXC7949 87 Button(Reset) CAC8053 CAC8053 CXC8054 CXC8054
* 89 Badge CAH1754 CAH1754 CAH1792 CAH1792
92 Keyboard Unit CWM8766 CWM8765 CWM8766 CWM8766 96 Grille Unit CXC2181 CXC2180 CXC2182 CXC2182
98 Clamper CEF1009 CEF1009 Not used Not used
13
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
14
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

2.3 EXTERIOR(2)

15
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
101 Screw(M2x3) CBA1082 102 Screw(M2x2) CBA1250 103 Screw(M2x4) CBA1277 104 Screw(M2x1.5) CBA1615 105 Washer CBF1038
106 Spring CBH2645 107 Spring CBH2646 108 Spring CBH2647 109 Spring CBL1585 110 Spring CBL1586
111 Spring CBL1587 112 Cord Assy CDE7047 113 Cord Assy CDE7213 114 Shaft CLA4270 115 Shaft CLA4305
116 Shaft CLA4306 117 Shaft CLA4309 118 Bracket CND1221 119 Heat Sink CND1228 120 Case CND1229
121 Holder CND1318 122 Holder CND1449 123 Sheet CNM7939 124 Sheet CNM8037 125 Insulator CNM8048
126 Insulator CNM8158 127 Sheet CNM8159 128 Tape CNM8160 129 Insulator CNM8294 130 Gear CNR1664
* 131 Gear CNR1665
132 Gear CNR1677 133 Gear CNR1678 134 Gear CNR1679 135 Gear CNR1680
136 Gear CNR1688 137 Gear CNR1708 138 Gear CNR1709 139 Gear CNV7383 140 Holder CNV7384
141 Holder CNV7385 142 Rack CNV7386 143 Rack CNV7387
* 144 Slider CNV7388
145 Slider CNV7389
* 146 Holder CNV7390
147 Arm CNV7391 148 Gear CNV7522 149 Gear CNV7523 150 Gear CNV7524
151 Gear CNV7529 152 Chassis Unit CXB9509 153 Frame Unit CXB9511 154 Holder Unit CXB9512 155 Shaft Unit CXB9513
156 Holder Unit CXB9514 157 Motor Unit(M3001)(Position) CXB9515 158 Motor Unit(M3002)(Angle) CXB9516 159 Screw CZB3082 160 Screw CZB3083
161 Washer CZB3084 162 Main Unit CZW3087 163 SW Unit CZW3088 164 Volume Unit CZW3089 165 Screw IMS20P020FTC
166 Screw IMS20P030FZK 167 Washer YE15FUC 168 Screw BMZ26P050FTC 169 Connector(CN3801) CKS4068 170 Connector(CN3802,CN3803) CKS3124
171 Connector(CN3807,3809) CKS3125 172 Connector(CN3808) CKF1064 173 IC(IC3801) BA00AST 174 Volume(VR3841) CCW1025 175 Flexible PCB CNP7118
176 Holder CNV7446 177 Screw CBA1484 178 Holder CND1314 179 Screw JFZ20P022FNI 180 Cover CNS7438
181 Screw BPZ20P060FZK
- EXTERIOR(2) SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
16
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

2.4 EXTERIOR(3)

17
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
201 Cord Assy CDE7194 202 Cap CNV6727 203 Cord Assy
See Contrast table(2)
204 Fuse(10A)
See Contrast table(2)
205 Cap See Contrast table(2)
206 Resistor See Contrast table(2) 207 Cord Assy CDE7321 208 Cap CNS1472 209 Resistor RS1/2PMF102J 210 Remote Control Unit
See Contrast table(2)
211 Cover CZN5357 212 Cord Assy
See Contrast table(2)
213 Fuse(10A)
See Contrast table(2)
214 Cap
See Contrast table(2)
215 Resistor
See Contrast table(2)
216 Screw BSZ26P060FTC 217 Screw BSZ30P060FZK 218 Cord Assy CDE7280 219 Chassis CNA2615 220 Case
See Contrast table(2)
221 Insulator CNM8124 222 Tuner Unit
See Contrast table(2)
223 Screw BMZ30P050FTC 224 FM/AM Tuner Unit
See Contrast table(2)
225 Holder CND1432
226 Terminal(CN1412) CKF-047 227 Pin Jack(CN1403) CKS1825 228 Connector(CN101,CN102) CKS4653 229 Pin Jack(CN1401,CN1402) CKS2918 230 Connector(CN1404) CKS4467
231 Connector(CN1405) CKS4663 232 Antenna Jack(CN1406) CKX1056 233 Holder CNC6746 234 Holder CNC7205 235 Holder CNC9888
236 Holder CND1451
237 Transistor(Q1404) 2SD2375 238 Grille Unit
See Contrast table(2)
239 Touch Panel CSX1057 240 Button(ENT,WIDE,MENU)
See Contrast table(2)
241 Button CAC7936 242 Screw JFZ20P022FNI 243 FFC CDE7195 244 LCD CAW1805 245 Holder CND1468
246 Lighting Conductor CNV7564 247 Sheet CNM8488 248 Holder CND1469 249 Insulator CNM8131 250 FFC CDE7196
251 LCD Panel CWX2671 252 Insulator CNM8132 253 Sheet CNM7783 254 Sheet CNM7784 255 Holder CND1467
256 Screw BPZ20P060FTC 257 Monitor Unit
See Contrast table(2)
258 Connector(CN4461) CKS3968 259 Connector(CN4801) CKS3991 260 Connector(CN4201) CKS4054
261 Connector(CN4301) CKS4054 262 Connector(CN4311) CKS4374 263 Connector(CN5002) CKS4428 264 Connector(CN4701) CKS4495 265 Connector(CN4312) CKS4496
266 Connector(CN4451) CKS4595 267 Connector(CN5001) CKS4595 268 Connector(CN4421) CKS4675 269 Holder CND1677 270 Insulator CNM7351
271 Cushion CNM8440
(1) EXTERIOR(3) SECTION PARTS LIST
Mark No. Description Part No.
Mark No. Description Part No.
(2) CONTRAST TABLE AVX-P6500DVD/UC , AVX-P6500DVD/EW , AVX-P6550DVD/RC and AVX-P6550DVD/RD are constructed the same except for the following:
Part No.
Mark No. Description P6500DVD/UC P6500DVD/EW P6550DVD/RC P6550DVD/RD
203 Cord Assy Not used CDE7192 Not used Not used 204 Fuse(10A) Not used CEK1136 Not used Not used 205 Cap Not used CNS1472 Not used Not used 206 Resistor Not used RS1/2PMF102J Not used Not used 210 Remote Control Unit CXC1224 CXC1226 CXC1226 CXC1226
212 Cord Assy CDE7193 Not used CDE7193 CDE7193 213 Fuse(10A) CEK1136 Not used CEK1136 CEK1136 214 Cap CNS1472 Not used CNS1472 CNS1472 215 Resistor RS1/2PMF102J Not used RS1/2PMF102J RS1/2PMF102J 220 Case CNB2834 CNB2834 CNB2878 CNB2878
222 Tuner Unit CWM8774 CWM8773 CWM8774 CWM8774 224 FM/AM Tuner Unit CWE1651 CWE1650 CWE1651 CWE1651 238 Grille Unit CXC1095 CXC1094 CXC1101 CXC1101 240 Button
(ENT,WIDE,MENU)
CAC7935 CAC7935 CAC7952 CAC7952
257 Monitor Unit CWM8764 CWM8763 CWM8764 CWM8764
18
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

2.5 DVD MECHANISM MODULE

19
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
1 DVD Core Unit(MS3) CWX2709 2 Connector(CN1501) CKS4282 3 Cover CNC9943 4 Connector(CN1202) CKS4624 5 Connector(CN1611) CKS4052
6 Connector(CN1603) CKS4374 7 Connector(CN1101) CKS4625 8 Connector(CN1201) CKS4067 9 Screw BMZ20P020FTC
10 Screw(M2 x 3.5) CBA1571
11 Screw(M2 x 2.5) CBA1623 12 Washer CBF1038 13 Washer CBF1064 14 Spring CBH2586 15 Spring CBH2587
16 Spring CBH2588 17 Spring CBH2589 18 Spring CBH2590 19 Spring CBH2591 20 Spring CBH2592
21 Spring CBH2593 22 Spring CBH2594 23 Spring CBH2595 24 Spring CBH2596 25 Spring CBH2597
26 Spring CBH2598 27 Spring CBH2599 28 Spring CBH2600 29 Spring CBH2601 30 Spring CBH2602
31 Spring CBH2603 32 Spring CBH2604 33 Spring CBH2605 34 Spring CBH2711 35 Spring CBL1564
36 Pickup Unit(Service)(DP5) CXX1639 37 Shaft CLA3881 38 Shaft CLA4206 39 Shaft CLA4207 40 Lever CNC9933
41 Holder CNC9939 42 Holder CNC9940 43 Holder CNC9941 44 Frame CNC9944 45 Sheet CNM6883
46 Sheet CNM8283 47 Sheet CNM8287 48 Lever CNV7154 49 Lever CNV7155 50 Cam CNV7156
51 Rack CNV7157 52 Clamper CNV7158 53 Arm CNV7159 54 Arm CNV7160 55 Arm CNV7161
56 Arm CNV7162 57 Arm CNV7163 58 Arm CNV7164 59 Roller CNV7165 60 Arm CNV7166
61 Guide CNV7167 62 Gear CNV7169 63 Gear CNV7170 64 Gear CNV7171 65 Gear(Brack) CNV7172
66 Gear CNV7173 67 Gear CNV7174 68 Rack CNV7175 69 Gear CNV7176 70 Arm CNV7177
71 Lever CNV7178 72 Lever CNV7179 73 Screw IMS20P030FTC 74 Gear CNV7181 75 Holder CNV7183
76 Holder CNV7184 77 Guide CNV7745 78 Roller CNV7344 79 Damper CNV7470 80 Damper CNV7471
81 Coller CNV7645 82 Compound Unit (A) CWX2752 83 Gathering PCB CNX3835 84 Compound Unit (B) CWX2753 85 Washer YE20FTC
86 Chassis Unit CXB8680 87 Arm Unit CXB8681 88 Frame Unit CXB8683 89 Arm Unit CXB8684 90 Bracket Unit CXB8685
91 Motor Unit(LOADING)(M1) CXB8687 92 Motor Unit(CARRIAGE)
(M2)
CXB8688 93 Screw Unit CXB8689 94 Roller Unit CXB8690 95 Motor(SPINDLE)(M3) CXM1211
96 Screw JFZ20P018FTC 97 Photo-transistor(Q1299) CPT231SCTD 98 Switch
(S1201,S1202,S1203)
CSN1051 99 Spring Switch
(S1204,S1205)
CSN1052
100 Resistor(R1298,R1299) RS1/16S0R0J
101 Screw JFZ20P018FTC 102 ••••• 103 Arm CNV7742 104 Arm CNV7743 105 Spring CBH2710
Mark No. Description Part No.
Mark No. Description Part No.
- DVD MECHANISM MODULE SECTION PARTS LIST
20
DTR,RXPC, TXPC
CCR CCG CCB CCSYNC
YS CCREM
ANR ANG ANB
CSYNC
1 2 3 4
8
18
18 19 17 20
15
7
1
1
2
2
9
10 4
4,52
1
1 5
3
4
(1/2)MOTHER PCB
A
NAVI 26PIN RGB CABLE
108 107
105 106
137 21 15 13 17 16 20 19 18
SYSTEM
CONTROLLER
IC601 PE5347A(EW) PE5348A
(UC,RC,RD)
(2/2)
CN805
RXMON TXMON
DREM REMUTE
VBU
VDD5
CN151(2/2)
CN803
(1/2)
CN201
ANGLEIN
LIFTPUL
MTRS
MTRPW
MTR2 MTR1
deg)sw pushsw
SNSPW
ANGLEIN
LIFTPUL
MTRS
MTRPW
MTR2 MTR1
angl)sw
pushsw
SNSPW
VDD
VBU
Q106
Q105
Q104
18
25
1 2 3
19 20
5
21
30 31 32 27
20 19 18 17 16 15 13 12 11
10
1 2 3
M
KEY
MATRIX
ILLUMINATION
GRILLE PCB
PANEL PCB
ILMG,ILMA(EW model)
IC5501 RS-140
CN5902
CN5501
CN5901
KEY0-2
KEY0-2
REMCOM
RESET
CN101
RESET
(UC,EW model)
SWAC5R6
AVCC5V
B.U.
B.U.
L
X601
18.874368MHz
BUZZER
73
74
68
132
VDD5
5 4
VDD5
SRVDD
SRVDD
VC33
VCC5
IC 602
S-80841CNUA-B82
IC 801
BA00BC0WFP
IC 803
BP5451
IC 806
BA00BC0WFP
IC 804
S-818A33AUC-BGM
Q802
CN1702
C
D
EXTENSION PCB
CN202
CN1701
CN1603
A
CN8
(2/2
Q107
Q112
(UC,EW model)
ACC5
Q843
Q801
Q819
Q844
Q818
Q601
FU808
35p
VDD
Q126
dsens
7
10
7
10
16
9
2
9
612
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM

3.1 BLOCK DIAGRAM

21
CN3802
MO1 MOB
1 2
CN3809
CN3843 CN3842 CN3841
CN3833 CN3831 CN3832
ANGLV
ANGLIN0
1
2
ANGLG
3
IC 3802
BA6247FP
Q3804
VR3841
CN3801
5
MTR2
4
MTRPW
3
MTRS
11
VDD
18 19 20
VBU
10
SNSPW
2
LIFTPUL
1
ANGLEIN
9
pushsw
8
angl)sw
6
MTR1
Regulator for driver
Motor driver
41
1
18
22
16
14
6
5
IC 3801
BA00AST
Q3801
CN3803
MO2 MOB
2 1
M
M
POSITION
MOTOR
ANGLE
MOTOR
13
IC 3803
TA78L05F
Q3802
Q3803
13
IC 3805
GP2L24B
24
IC 3804
TC7S14FU
CN3807
LIFT
ANGLE0
1
3
GNDSNS
2
VOLUME UNIT
SW UNIT
S3832
LIFTSW
S3831
ANGLE0SW
MAIN UNIT
Q4156
8.0V
CN4801
Q4153
734
Q4152
1
VR
Q4155
VG
Q4154
VB
VCOM
36 4
Q4151
1438
17
101
Q4182
Q4183
8.0V
IC 4151
NJM2138V
RGB AMP
CN4421
TOUCH SCREEN
28
27
26
CN4461
ANR1 ANG1 ANB1 CSYNC CVBS
YS
DPDT
22
MONI5V
REMCON
17
X4001 42MHz
IC4001
TC90A64AF-P
SYSTEM
CONTROLLER
IC 4601
PD5842A
LCD MICROCOMPUTER
82
83
ROUT
PNLYV2,PNLXV2,PNLADX2,PNLADY2
RIN
52
GIN
53
HDIN
18
CVI1
65
GOUT
BOUT
OSDCLK
MFLPW
62
HSYNC
SCKE
X0
X1
IC4181
NJM082BV
VCOM AMP
6
17
28
POLC
1
2
1
4
102
100
NDSH
NDSV
VSYNC
IC4093
TC7SH08FU
1,2
4
IC4092
TC7SH08FU
KEY
MATRIX
KEY
MATRIX
IC 4691
S-93C46BR0I
Q4131
Q4133
Q4132
Q4121
Q4123
Q4122
BIN
54
Q4111
Q4113
Q4112
FNAVI
93
Q4101
Q4103
Q4102
IC 4142
TK15404MI
2
IC4141
TC7SH08FU
1,2
4
IC4065
TC7SZ08FU
24
RESET
12
IC 4602
S-80827CNNB-B8M
RESET
12
82
MVIPW
26
INVPUL
2
LSEN
VSW5
LSEN
LCD
LCD
BACK LIGHT
LCD MODULE
DIMDTY
DIMDTY
PWRFL
VACC5V
MONITOR PCB
I
X4601
13
15
XOUT
XIN
10MHz
CN5002
FL1
FL2
IC 5003
OZ961IS
20
11
10
T5001
Q5005
Q5004
UPPER PCB
INVERTER PCB
H
N
P
O
Q5003
PWRFL
CN5001
CN4451
3 1 5,14,15
7
IC5001
TA78L05F
1
4
18
IC 5002
TC7SET08FU
CN4201
CN4701
SUB DISPLAY
CN4301
CN4311
CN4312
ANGLEIN
LIFTPUL
MTRS
MTRPW
MTR2 MTR1
angl)sw
pushsw
SNSPW
VDD
VBU
1 2 3
9
14 15 16
8
9103
2
IC 4311
NJM062V
3
16
7
1
15
KYDT
16
MFLPW
17
25 26 27 23 29
21
14
1 2 3
4
2
19 20 1 20
J
SENSE PCB
K
OUT OF LIGHT SENSOR
INVERTER FOR
BACK LIGHT
TWO PICTURES
CONTROL IC
IC 4851
LT1376CS8
IC 4701
PD6340A
2
IC 4841
R1130H251B
2
2.5V
VCC
IC 4861
MAX1748EUE
4
18V
3.3V
Q4832
Q4831
3.3V
3.3V
14.4V 3
1
7
8V
-12V
15
8
8.0V
Q4835
5V
KST1,2,KDT1,2,3,4
KST1,2,KDT2
SEG
KST1,2,KDT3,4
FILTER
SYMC AMP
5->3 CHANGE
5->3V CHANGE
BLNK
92
IC4064
TC7SZ08FU
24
IC4063
TC7SZ32FU
24
IC4061
TC7SZ02FU
24
IC4605
TC7SH08FU
24
IC4604
TC7SET08FU
42
POWER SUPPLY
EEP-ROM
VBILL,VILLA(EW model),VILLGB
VBILL,VILLA,VILLGB
VBILL,VILLA,VILLGB
24
DIMDTY
IC 4451
TC7SET08FU
2
4
7
10
A
CN803
(2/2)
64
81
DPDT
36
KYDT
35
PWRFL
35pin
(EW model)
(EW model)
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
22
MAIN ANT
CN1405
SL
DO
DI
CK
CE1
RDSHSLK
RDSLOCK RDSDATA
RDSCK
ROMVDD
TUNL
CN1404
CN1502
CN1
19
BGSENS
BCAM
AUXV
AUXL
REARV
REARL
CE2
LDET
CN1412
REVERSE GEAR SENSE
29
I
CN
NAVI 2 RGB CA
AV BUS
Q1404
RER VIEW CAMERA IN
L VIDEO IN
CN1402
V VIDEO IN
L REAR VIDEO OUT
CN1401
V REAR VIDEO OUT
19
22
12 12
55
99
22 22
26 26
FMRF
ANT adj
RF adj
FM ANT
T51
CF52
CF51
VCC
VDD_3.3
3.3V
2.5V
IC 4
3.3V 2.5V
IC 2
2.5V
CE2
ROM_VDD
SL
DI
CK
CE1
LDET
DO
RDS_CK
RDS_DATA
RDS_LOCK
RDS_HSLK
6 13 5 10 9 8 11 14 18 19 20 21
1
3
IC 1
3.3V
AM ANT
FMRF
ATT
LPF
OSC
IC 3 EEPROM
5.0V
IC 5
5V 3.3V
ATT
MIXER, IF AMP
DET, FM MPX,
RDS DECODER
23
Lch
FM/AM TUNER UNIT
TUNER UNIT
G
RELAY P
B
CN1
D
CN
I
CN1
D
CN1406
(EW model)
4
4 1,2
17
IC 1402
BA00ASFP
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC
23
SYSTEM
CONTROLLER
IC 601
PE5348A
(UC,RC,RD)
PE5347A
(EW)
(1/2)
CN1405
SL
DO
DI
CK
CE1
RDSHSLK
RDSLOCK RDSDATA
RDSCK
ROMVDD
12 17 5 3 2 6 1
20 15 14 9 8
21
CN1500
CN153
TUNSL
TUNPDI
TUNPDO
TUNPCK
TUNCE
rds%&k
rdslk
RDT
rck
45 101 135
46
47
48 100
24
25
23
57
CN152
12 16
5 3 2 6 1
19 14 13
9 8
20
TUNL
BGSENS
BCAM
AUXV
AUXL
REARV
REARL
CE2
ldet
TUNPCE2
LDET
VPFL
SYS+B
RC,RD
R357
FU805
BUP
VPVI
FU803
VBU
FU804
ACC
ILL
40
12
11
39
B.REM
PARK ING
IC301
NJM4558V
IC302
NJM4558V
IC307
NJM4558V
IC304
NJM2068V
GUIDE SOUND
INPUT
3
3
1
7
3
3
1,2
1,2
1
2
41 42 43 10
2
129
PBSENS
127
TELIN
112
TXMS3
113
IRQPWR
114
XRESET
126
ILSENS
ONSEI
+
ONSEI
96
29
118
ASENS
88
8
IPPW
1
IC 306
NJM4558V
GUIDE MIX
UC,EW
21
POWER AMP
IC308
PAL007A
RL
+
12
FLIN
4
SYSPW
14
RLIN
23
RL
17
RR
+
19
RR
5
FL
+
3
FL
9
FR
+
7
FR
25
R.REM
GND
+
BACK UP
ACC5
Q701
Q704
Q833
BUP
BUP
BUP
VDD5
VDD5
Q839
Q840
FAN
FU807
CN701
4
2
6
3
11
13
1
7
5
12
8
9
14
15
16
CN801
CN972
2
1
RL
+
RL
RR
+
RR
FL
+
FL
FR
+
TEL MUTE
FR
VDD5
B.up
ACC
CN154
CN803
(2/2)
29pin
CN203
6
35
1
36 21 22 23
24
ONSEI + ONSEI-
HTXD
AVCOMP
OPT
IPL+
MONVBS
MS3L
SLVSTS
38
VIDEO OUT
IP-BUS
CORD
CN151(1/2)
10
13 14
24
NAVI 26PIN
RGB CABLE
AV BUS CABLE
IC 309
(2/2)
PA2028A
IC 305
PML009A
VIDEO/AUDIO
SELECTOR
IC 506
(2/2)
CXA2089Q
7
11
9
IC154
HA12187FP
6
90
2
RX
91
49
1
TX
ACCPW
TUNPW
130
BGSENS
111
RXMS3
1
1
2
8
16
47 35
15
23
40
3
IC502
NJM2137V
IC151
TA2050F
12
8
3
1
IC152
TA2050F
12
8
673
4
14
94
1
Q904
Q903
6 26
18 14
20 12
16 16
10 22
14 18
230
IC153
TA2050F
IC155
TC4S81F
12
8
6
CN156
2
CN971
1
IC503
NJM2137V
3
1
IC505
NJM2137V
3
1
4
5
1.2
IC201
TC74VHCT08AFT
1
8
6
3
3
IC202
SM5304AV
IC203
TC74VHC08FT
1
2,4
6
IC501
NJM2137V
3
1
3
2
2,14
VDD
3V -> 5V CHANGE
VIDEO5V
Q206
Q205
VDD
IC971
TC7WT125FU
2
3
2
4
Q841EF801
IC807
S-812C50AUA-C3E
Q842
Q834
VD8
3
9
10
IC805
AN8011S
Q822
FU802
CN1611
D
CN4461
I
CN1501
D
MOTHER PCB(2/2)
A
(UC,EW model)
IC507
BA7623F
IC303
NJM4558V
IC504
NJM2137V
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
24
26
24
DVD CORE UNIT (MS3)
Q1101
Q1102
Q1104
Q1103
Q1105
65LD
78LD
2
4
VSHF
CN1101
CN1201
CN1202
LPC01
LPC02
IC 1706
TC7SH08FU
IC 1702
M5M5V216ATP-70HI
IC 1705
PD6447A
FEP
IC 1101
AN8703FH
SODC
IC 1301
MNZS26EDCUB
IC 1202
AN8471SAT1
36
XWR
CPU
IC 1701
PE5395A
(1/2)
62 63 90
X1700 5MHz
CLKOUT
94
17
1
2
3
11
86
111
97
79
96
CD/DVD
X2 X1
XWR
DMIXON
FSSW
XUWR
DSCSNS
SRAM
FLASH MEMORY
IC 1201
BA5985FM
23
PICKUP UNIT(SERVICE)(DP5)
A,B1-4,C,RF+,RF-
M
SPINDLE
MOTOR
M
CARRIGE
MOTOR
M
LOADING
MOTOR
FOP,FOM,TOP,TOM
COP,COM
DRIVER
9
LOM
10
LOP
10
A0-17,D0-7
D
FD,TD,M
D
,CRGDRV,FG
FG
S1206
S1902
S1903
S1904
S1901
S1905
CLAMP SW
12cm
8cm
8cm
Disc sens
Disc sens
COMPOUND UNIT(B)
F
COMPOUND UNIT(A)
E
TBAL,FBAL,JLINE,TEY,ASF,FEY,ARF+,ARF-,
OFTR,BOO,RFENV,TESTSG
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC
25
36
34
4
6
3
8
11
21,22
87
88
136
26
5
2
3
3
IC 1502
TC74VCX74FT
IC 1504
TC74VCX74FT
IC 1505
TC7PA04FU
IC 1501
M2V64S40DTP-6L
SDRAM
SICOMN,SOCOMN,SCKCOMN,etc
IC 1507
SM8707FV
XWRH, XWR
SRCK
LRCK
CLK27
HCLK
1
5 12
3
14
7
1
10
3,5
5
8
4
7
6
2
2,3
6,7
1
3
CLOCK GEN.
Rch OUT
IECOUT
Lch OUT
IC 1605
PCM1742KE
IC 1604
NJM2100V
CN1501
CN1611
VCC33
AV CHIP
IC 1503
MN677531KAUB
83
IECOUT
CPU
IC 1701
PE5395A(2/2)
11 12
VCC33
CN203
A
CN971
A
IC 1602
NJM2100M
AMUTE,VCONTB,XRES,IRQPWR,HSTCMD,SLVSTS
1
CN1603
CN1701
C
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
26
model
TUNER UNIT
RELAY PCB
G
B
MAIN UNIT
N
SW UNIT
O
VOLUME UNIT
P
EXTENSION
PCB
C
M
I
INVERTER PCB
H
LCD PANEL
TOUCH
PANEL
MS3 MECHANISM MO
D
MOTHER PCB
A
E F
POWER SUPPLY
DIGITAL
OUTPUT
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

3.2 OVERALL CONNECTION DIAGRAM

27
FAN
MONITOR PCB
I
GRILLE PCB
L
PANEL
PCB
M
UPPER PCB
J
SENSE PCB
K
FM/AM ANTENNA
CONNECTOR (NAVI)
AV BUS
IP BUS
RCA
CORD
EXTENSION
CONNECTOR
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
28
A-a A-b
A-a
A-b
A-b
A-a
Large size
SCH diagram
Guide page
Detailed page
Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST".
A-a
ABC
NAVI 26PIN RGB CABLE
D
CN1611
G
CN1405
B
CN1500
IP-BUS
CORD
M
CN5901
I
CN4461
D
CN1501
>
>
>
>
>
>
>
>
>
>
>
SYSTEM CONTROLLER
MS3 VIDEO
RCA INPUT VIDEO
NAVI DVD VIDEO
AV-BUS
VIDEO
VIDEO FILTER
AUDIO
ISOLATOR
IP-BUS DRIVER
AV SELECTOR
VIDEO ISOLATOR
V
OPTICAL OUTPUT BUFFER
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
EW,UC, RC
RC,RD
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC

3.3 MOTHER PCB(GUIDE PAGE)

29
A-b
A
CXM1262
FAN
CN202
CN201
N
CN3801
AV-BUS CABLE
>
>
>
>
>
>
>
>
>
>
>
>
270µH
C
CN1702
FRONT L CH
FRONT R CH
REAR L CH
REAR R CH
SUBWOOFER L CH
SUBWOOFER R CH
CEK??? 10A
>
Decimal points for resistor and capacitor fixed values are expressed as :
2.2 2R2
0.022 R022
The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.
Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors.
NOTE :
Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors.
: The power supply is shown with the marked box.
A
MOTHER PCB
MOTHER UNIT Consists of MOTHER PCB RELAY PCB EXTENSION PCB
POWER AMP
EVOL.
NAVI
GUIDE
MIXING
VCC 3.3V REG.
VCC 5V, VCC 1.8V D/D CONVERTER
VD8V
D/D CONVERTER
SRVDD REG.
HIGH OUT
AUDIO SIGNAL LINE VIDEO SIGNAL LINE
V
V
V
V
V
V
V
V
V
V
5
6
7
8
F
E
D
C
B
A
5
6
7
8
AVH-P6500DVD/UC
30
A-a
A-b A-a
A-a
A-b
1
2
EW,UC,
RC
RC,RD
D
CN1611
G
CN1405
I
CN4461
D
CN1501
>
>
>
>
>
>
>
>
>
MS3 VIDEO
RCA INPUT VIDEO
NAVI DVD VIDEO
AV-BUS
VIDEO
VIDEO FILTER
AUDIO
ISOLATOR
AV SELECTOR
VIDEO ISOLATOR
OPTICAL OUTPUT BUFFER
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
1
234
12
34
F
E
D
C
B
A
AVH-P6500DVD/UC
Loading...
+ 180 hidden pages
