HF3670, HF3671,
HF3672
Philips SleepMapper app
2
3
1
13
12
1
11
7
5
4 38
9
10
6
English 6
Dansk 28
Deutsch 50
Español 73
Français 95
Italiano 117
Nederlands 140
Norsk 163
Português 185
Suomi 207
Svenska 229
6
English
Contents
Introduction _____________________________________________________________________________ 7
General description________________________________________________________________________ 7
Intended use _____________________________________________________________________________ 7
The effects of the Sleep & Wake-Up Light_____________________________________________________ 8
Important safety information _______________________________________________________________ 8
Safety and compliance _____________________________________________________________________ 10
Electromagnetic fields (EMF)________________________________________________________________ 10
Interactive menu icons _____________________________________________________________________ 10
Connecting your appliance to Wi-Fi__________________________________________________________ 11
Navigating the menu ______________________________________________________________________ 12
Setting wake-up profiles ___________________________________________________________________ 13
Time + alarm back-up ______________________________________________________________________ 14
Snoozing_________________________________________________________________________________ 14
Dismissing the alarm_______________________________________________________________________ 14
Using the appliance as a bedside lamp _______________________________________________________ 15
Midnight Light ____________________________________________________________________________ 15
Settings __________________________________________________________________________________ 15
Listening to music _________________________________________________________________________ 17
Wind-down programs _____________________________________________________________________ 18
Sunset simulation _________________________________________________________________________ 18
RelaxBreathe _____________________________________________________________________________ 19
Bedtime function__________________________________________________________________________ 20
Charging your mobile phone _______________________________________________________________ 20
Cleaning and storage ______________________________________________________________________ 20
Recycling_________________________________________________________________________________ 21
Warranty and support _____________________________________________________________________ 21
Troubleshooting __________________________________________________________________________ 21
Specifications _____________________________________________________________________________ 25
Open-source and third-party software _______________________________________________________ 27
Introduction
Congratulations on your purchase and welcome to Philips! To fully benefit from
the support that Philips offers, register your product at
www.philips.com/welcome.
The Philips SmartSleep connected Sleep & Wake-Up Light helps you wake up
more pleasantly. The light gently prepares your body for waking up at the set
time and can be accompanied by natural wake-up sounds or FM radio.
The light-guided breathing function, personalized sun settings, bedroom
environment tracking and several other features make this connected Sleep &
Wake-Up Light the perfect companion for your bedroom.
Tip: Using the Philips SleepMapper app will enable extra features. These
features are explained in the app.
If the appliance is updated through connecting it to Wi-Fi with the app, the
information in this document may not be up to date. Find the latest user
manual on www.philips.com/support by searching for the type number of
your appliance.
General description
The numbered items in this list refer to the numbered items in the overview
illustration.
1 Lamp housing
2 Display
3 Sound pressure sensor
4 USB charging port
5 Reset button
6 Radio antenna
7 AmbiTrack sensor: Humidity and temperature sensor
8 Auxiliary (AUX) socket
9 Adapter DC socket
10 Speaker
11 Snooze/Midnight Light
12 Adapter
13 Small plug
English
7
Intended use
The Philips SmartSleep connected Sleep & Wake-Up Light is intended to give
you a more natural and refreshed wake-up and a relaxed feeling before falling
asleep.
This is not a general illumination product.
8
English
The effects of the Sleep & Wake-Up Light
The Philips SmartSleep connected Sleep & Wake-Up Light gently prepares your
body for waking up during the last 30 minutes of sleep. In the early morning
hours our eyes are more sensitive to light than when we are awake. During that
period the relatively low light levels of a simulated natural sunrise prepare our
body for waking up and getting alert.
People who use the appliance wake up more easily, have a better overall mood
in the morning and feel more energetic. Because the sensitivity to light differs
per person, you can set the light intensity of your appliance to a level that
matches your light sensitivity for an optimal start of the day.
To fully experience the effects of the connected Sleep & Wake-Up Light, place
the appliance at approximately 16 in. – 20 in. / 40 cm – 50 cm from your head,
on a flat stable surface of your bedside table.
For more information about the connected Sleep & Wake-Up Light, see
www.philips.com.
Important safety information
Read this important information carefully before you use the appliance and
save it for future reference.
Danger
-
Water and electricity are a dangerous combination. Do not use this
appliance in wet surroundings (e.g. in the bathroom or near a shower or
swimming pool).
-
Keep the adapter dry.
-
This appliance is for indoor use only.
-
Do not let water run into the appliance or spill water onto the appliance.
-
Do not immerse the appliance in water or rinse under the tap.
-
Do not place anything close to the appliance that could cause water or any
other liquid to drip or splash onto the appliance.
-
The adapter contains a transformer, which converts an unsafe
100–240VAC mains voltage to a safe 24VDC low voltage. Do not cut off
the adapter to replace it with another plug, as this causes a hazardous
situation.
Warning
-
Never use the appliance if the lamp housing is damaged, broken or missing.
-
If the adapter, cord or appliance has been damaged in any way, liquid has
spilled or objects have fallen into and/or onto the appliance, the appliance
has been exposed to rain or moisture, does not operate normally or has
been dropped or damaged, it should not be operated.
-
If you feel uncomfortable at any point while using RelaxBreathe in the
breathing exercise, just go back to breathing normally.
-
Only use the appliance in combination with the adapter supplied.
-
If the adapter is damaged, always have it replaced with one of the original
type in order to avoid a hazard.
Caution
English
-
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
-
Consult your doctor before you start using the appliance if you have suffered
from or are suffering from depression.
-
Do not use this appliance as a means to reduce your hours of sleep. The
purpose of this appliance is to help you wake up more easily. It does not
diminish your need for sleep.
-
Check if the voltage indicated on the appliance corresponds to the local
voltage before you connect the appliance.
-
Protect the power cord from being walked on or pinched, particularly at
plugs, wall sockets and points where it exits from the lamp.
-
Do not use the adapter in or near wall sockets that contain an electric air
freshener to prevent irreparable damage to the adapter.
-
Do not drop the appliance on the floor, hit it hard or expose it to other heavy
shocks.
-
Place the appliance on a stable, level and non-slippery surface.
-
Do not impair the cooling of the appliance by covering the appliance with
items such as blankets, curtains, clothes, papers, etc.
-
Do not use the appliance at room temperatures lower than 5°C or higher
than 35°C.
-
The appliance has no on/off switch. To disconnect the appliance, remove the
adapter from the socket-outlet. The adapter and socket-outlet shall remain
easily accessible at all times.
-
This appliance is only intended for household use, including similar use for
instance in hotels.
-
No naked flame sources, such as lighted candles, should be placed on the
appliance.
-
The LEDs inside this Wake-Up Light are not replaceable, when they reach
their end of life the whole Wake-Up Light shall be replaced.
9
General
-
If you often wake up too early or with a headache, reduce the set light
intensity level and/or the set sunrise simulation time.
-
If you often wake up by the alarm sound, increase the set light intensity level
or the set sunrise simulation time.
-
If you share a bedroom with someone else, this person may unintentionally
wake up from the light of the appliance, even though this person is further
removed from the appliance. This phenomenon is the result of differences in
light sensitivity between people.
-
The power consumption of the appliance is lowest if no device is connected
to the USB port and the lamp, radio, display and Wi-Fi are turned off.
10
English
Safety and compliance
This appliance meets the safety requirements in the EU for:
-
IEC 60598: Luminaires.
-
IEC 62471: Photobiological safety of lamps and lamp systems.
-
IEC 62368: Audio/video, information and communication technology
equipment.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and regulations
regarding exposure to electromagnetic fields.
Interactive menu icons
Wake-up profile/Alarm Light intensity and light
on/off
Return to higher level in
the menu
Settings Sounds Confirm and save
Wind-down program AUX socket Radio
Enable Wi-Fi Disable Wi-Fi Change alarm settings
Display settings and display
brightness
Enable display timeout Disable display timeout Deactivate alarm
Enable audio feedback Disable audio feedback Light or sound
Sunset simulation Duration of the wake-up
Days of the week RelaxBreathe RelaxBreathe pace
Select day of the week Deselect day of the week Duration of a program
Start bedtime Start program Stop program
Select natural sound Dismiss alarm
profile
setting
guidance
Delete wake-up profile
Connecting your appliance to Wi-Fi
If the appliance is updated through connecting it to Wi-Fi with the app, the
information in this document may not be up to date. Find the latest user
manual on www.philips.com/support. Philips reserves the right to update the
firmware of the appliance.
Easy Wi-Fi setup
Download the Philips SleepMapper app from Google Play or the App Store on
your mobile phone. See the information in Google Play or the App Store to
check if your mobile phone is compatible with the app. You can easily set up
the Wi-Fi connection to your connected Sleep & Wake-Up Light.
The setup to install your Sleep & Wake-Up Light and connect to your home WiFi network only needs to be done once. This setup will take approximately 5-10
minutes.
Setup wizard of the connected Sleep & Wake-Up Light
1 When you use your connected Sleep & Wake-Up Light for the first time, a
setup wizard starts on the appliance.
2 After selecting your language on the display of the appliance, continue in
the app. Make sure that you have the app open on your mobile phone.
3 Follow the instructions in the app to connect your appliance to the Wi-Fi
network. If you have trouble connecting your appliance, check the support
section in the app or the items mentioned in the troubleshooting section in
this user manual (see 'Troubleshooting').
-
If you previously chose to set up your appliance without the app, but now
want to connect your appliance to the app, press the Wi-Fi icon in the
settings menu of your appliance. The access point mode icon will be
shown on the display. Open the app on your mobile phone to connect.
-
If you have changed your Wi-Fi home network or changed your password,
press and hold the Wi-Fi icon in the settings menu of your appliance for 8
seconds. The access point mode icon will be shown on the display. Open
the app on your mobile phone to connect.
The Wi-Fi connection issue icon might appear on the display if a connection
cannot be established. Check the troubleshooting section to solve the problem.
English
11
Note: The app on your mobile phone and your connected Sleep & Wake-Up
Light can ONLY communicate with each other when both appliances are
connected to the same home Wi-Fi network. If this is not the case, you cannot
remotely control the appliance through the app (e.g. set an alarm).
AmbiTrack sensors
The connected Sleep & Wake-Up Light collects input from its surroundings
through the AmbiTrack sensors. AmbiTrack sensors measure light, humidity,
temperature and sound pressure. These factors can influence your sleep. Only in
the app you can see information on the recommended values for ideal sleep
conditions. The measurements of the sensors can be influenced by the
surroundings of the appliance. For example, if you place the appliance next to a
window or near a heating source such as a radiator, the temperature and
12
Hello
English
humidity sensors might not represent the temperature / humidity of the entire
room.
Setting up your appliance without the app
You can set up the Sleep & Wake-Up Light without the app. Before you can use
the appliance, a setup wizard on the appliance needs to be completed first. You
can connect the appliance to the app later.
We strongly recommend you to set up your appliance with the SleepMapper
app in order to enjoy all functionalities the app offers.
1 Start the setup wizard by tapping on the start icon on the display of the
appliance.
2 You will be guided through the setup wizard on the appliance, where you
set the desired settings, a wake-up profile and a winddown program.
Note: The wake-up profile and the wind-down program can be set later. Skip
these settings by tapping the arrow repeatedly. However, we advise you to set
your wake-up profile and your wind-down program during this setup. This can
help you explore the different functions of the appliance.
Navigating the menu
If you have set up your appliance with the help of the SleepMapper app or
through the setup wizard (see 'Setting up your appliance without the app') on
the appliance, you will see the menu as described in the following sections.
On the display of the appliance you can select and set the wake-up profile,
bedside lamp, settings, sound (source) or the wind-down program.
Note: If the display is blank, move your hand towards the lower part of
appliance to show the display menu. You will see the menu icons.
Confirming and saving settings
All your personalized settings and profiles will be permanently stored in the
memory. You can change them at any time. Press the check mark icon to
confirm and save the desired profile or setting change in any menu.
Note: Your personalized settings and profiles will not be lost, if you remove the
adapter from the electrical outlet.
Setting wake-up profiles
In your wake-up profile on the appliance you can set the alarm time, the
maximum light intensity and type of wake-up sound you prefer. In total you can
set two different wake-up profiles in the menu of the appliance. With the
SleepMapper app, you can set more wake-up profiles.
Note: The main display of the appliance shows the set alarm time if an alarm is
active.
Note: Press and hold the alarm icon in the main menu to deactivate all set
alarms at once.
1 You can toggle between different wake-up profiles on the appliance by
using the arrow icons .
2 To deactivate the alarm, press the deactivate alarm icon .
3 Press the alarm settings icon to enter the alarm profile set-up menu.
Alarm time and day
In this menu you can change the time by pressing + or -. The alarm will be
automatically repeated every day.
English
13
You can select on which day of the week the alarm should go off.
1 Press the calendar icon .
2 The days of the week are indicated by the first letter of the day. When an
alarm is active, the letter is shown brightly. You can toggle between the days
of the week by using the arrow icons.
3 To deactivate the alarm for a certain day, press this icon .When a specific
day is inactive, the letter of that day is only dimly visible.
Light intensity of the wake-up profile
The lamp of the appliance simulates a sunrise. Like a sunrise, the brightness of
the lamp increases gradually. During this wake-up curve, the color of the light
changes from soft red to warm orange to bright yellow.
Press icon on the display to choose one of the 25 light intensity levels.
Duration of the wake-up profile
The default duration of the wake-up curve (brightness increase to the set
maximum light intensity) is 30 minutes. The duration can be changed to your
preference by pressing the icon on the appliance.
14
English
Type of sound
Press this icon to open the sounds menu to set the sound of the wake-up
profile.
1 Press the toggle icon to choose one of the three sounds options: natural
sounds, radio or no sound.
2 Press the natural sounds icon to select one of the natural sounds or press
the radio icon to select one of the radio presets.
3 You can set the volume with the loudspeaker icon .
Remove a wake-up profile
Press this icon to change the alarm. To remove a wake-up profile, press .
Time + alarm back-up
In the event of a power failure, all functions of the appliance, including the
display, do not work. However, the internal clock and a back-up alarm remain
active for at least 8 more hours.
If during the power failure the set alarm time is due, a back-up alarm goes off
generating a beeping sound for approximately 1 minute.
Snoozing
When the wake-up curve has ended (when the set maximum light intensity has
been reached) and the alarm sound is playing, you can tap the top of the
appliance to snooze.
The lamp stays on, but the sound is muted. The snooze duration can be
adjusted in the app. The default snooze duration is 9 minutes. After 9 minutes,
the alarm sound starts playing again.
Note: The light and sound automatically turn off 60 minutes after the alarm has
gone off or 60 minutes after the last snooze action.
Dismissing the alarm
When the wake-up curve is active or the alarm goes off, you can dismiss it by
pressing this icon on the appliance. If you dismiss it, this alarm profile is
deactivated for that day.
Using the appliance as a bedside lamp
You can use the connected Sleep & Wake-Up Light as a bedside lamp.
Press the bedside lamp icon on the display to switch on the bedside lamp.
Note: You can increase and decrease the brightness intensity. You can select a
brightness between 1 (low) and 25 (high). The default brightness setting is 20.
To switch off the light, press the cross icon in the menu.
Tip: When the light is on, you can also turn off the light with a single tap on the
top of the appliance. All active programs will stop. Set alarms remain active.
Midnight Light
If you wake up during the night, you can tap the top of the appliance to
activate a dim light. This dim, subtle orange light provides you with just enough
light to find your way in the dark. Switch off the Midnight Light by tapping the
top of the appliance again.
English
15
Settings
Note: The Midnight Light cannot be activated directly when the main light is
already on. In that case, first tap the top of the appliance to deactivate the main
light. Then tap again to activate the Midnight Light.
Press the settings icon to open the settings menu.
Note: Press and hold the settings icon for 8 seconds to open a new menu, in
which you can select VERSION (firmware version of the appliance) or DEMO
mode (accelerated wake-up curve).
In the settings menu, you can adjust the clock time (when Wi-Fi is disabled), the
audio feedback, the display brightness of the appliance and enable/disable WiFi.
16
English
Time
Wi-Fi
Press this icon to open the time menu.
In this menu you can change the time by pressing + or -.
Press the time notation icon to toggle between the 12-hour clock and 24-hour
clock.
Note: This option is not available when the appliance is connected to Wi-Fi.
Turn Wi-Fi on or off by pressing on the Wi-Fi icon. When Wi-Fi is disabled ,
any update made in the app will not be implemented until the Wi-Fi connection
is restored.
Note: Press and hold the Wi-Fi icon for approximately 8 seconds to return to
access point mode. Open access point mode when you want to connect your
appliance to a different Wi-Fi network or if you have changed your Wi‑Fi
password.
If you accidentally activated access point mode, press the Wi-Fi icon in the Wi-Fi
menu twice to activate Wi-Fi again. Your connected Sleep & Wake-Up Light
remembers the network you were connected to.
Audio feedback
Display settings
If you do not want to hear clicks when you press an icon, press the audio
feedback icon to turn off the audio feedback. You hear one click as a
confirmation. To reactivate the audio feedback, press this icon .
Press the display settings icon in the settings menu to set the display settings.
In this menu you can adjust the display brightness level and select the display
timeout option.
Display brightness
You can adjust the display brightness from level 1 to level 6 with the plus and
minus icons. Choose a level that is optimal for you to see the display at night.
The appliance automatically adjusts the display brightness when the ambient
light in your bedroom changes.
Display timeout
If you do not want the appliance to produce any light, not even from the time
indication, press the display timeout icon to turn off the display completely. The
display turns off gradually a few seconds after your last interaction with the
icons.
Normally, if you do not touch the display for some time in any menu, the display
reverts to time and status indication only. When the display timeout is
activated, no time indication is shown.
Press the disable display timeout icon to turn on the display again.
Tip: If you want to check the time or select a function while the display timeout
is activated, just place your hand near the display to turn it on for a few seconds.
Listening to music
Press the sounds icon to select the preferred sound source.
Tip: Press and hold the sounds icon to activate/deactivate the sound via the
menu.
In the sounds menu, you can select radio or play your own music by connecting
a music playing device to the AUX socket.
Tip: When the radio or music is on, you can turn off the sound with a single tap
on top of the appliance. All active programs will stop. Set alarms remain active.
English
17
Listening to radio
You can listen to the FM radio with the Sleep & Wake-Up Light. If you selected
the radio function in the sounds menu, it shows the selected radio station. You
can manually change the radio station by selecting the FM frequency of
another radio station.
Tip: Make sure to unwind the antenna fully and move it around until you
receive the best reception.
You can preset 5 radio stations. Use the FM frequency setting icon to select a
radio station. Press and hold the double arrow button to automatically search
for the next radio station.
After setting a radio station, you can easily add another preset radio station by
selecting the toggle icon . With this process, you can preset 5 radio stations.
Set the preferred volume with the loudspeaker icon .
18
English
Music via Auxiliary (AUX) socket
You can use the connected Sleep & Wake-Up Light as a speaker for music by
connecting a music playing device (for instance your mobile phone) to the AUX
socket.
If the sound is not loud enough when you have set the volume on the appliance
to maximum, increase the volume on your music playing device.
If the sound is too loud or distorted when you have set the volume on the
appliance to low, decrease the volume on your music playing device.
Note: You need an AUX cable to connect the connected Sleep & Wake-Up Light
to a music playing device.
Note: You cannot wake up to music from a device connected to the AUX socket.
Wind-down programs
Press the wind-down program icon to choose the desired wind-down program.
The appliance features two wind-down programs to help you relax before you
fall asleep: sunset simulation and RelaxBreathe.
You can deactivate the active wind-down program by tapping the top of the
appliance.
You can also activate or deactivate the bedtime function in this menu.
Sunset simulation
During the sunset simulation, the brightness of the light decreases gradually
with colors changing from bright yellow to warm orange to soft red.
Press the sunset simulation icon to enter the sunset simulation set-up menu.
Press play to start the sunset simulation. Press stop or tap on the top of the
appliance to stop the program.
Use this icon to set the duration of the sunset simulation. You can select a
duration of 5, 10, 15, 20, 30 or 45 minutes.
You can change the light intensity of the sunset simulation with the light icon.
RelaxBreathe
English
Press the sounds icon to set a sound that fades away during the sunset
simulation.
Press the toggle icon to choose one of the three sound options: natural
sounds, radio or no sound. You can also play your own music by connecting a
music playing device to the AUX socket.
Press the natural sounds icon to select one of the natural sounds.
You can set the initial volume with the loudspeaker icon .
RelaxBreathe uses the belly breathing technique as a basis for the breathing
program. You can choose one of the breathing programs, guided by light or
sound. The combination of the belly breathing exercise and the guidance of the
connected Sleep & Wake-Up Light helps you slow down and feel relaxed.
Press the RelaxBreathe icon to enter the RelaxBreathe set-up menu.
Press play to start the RelaxBreathe session. Press stop or tap on the top of
the appliance to stop RelaxBreathe.
Press this icon to set the duration of the relaxation program. You can select a
duration of 5, 10 or 15 minutes.
19
You can select one of seven relaxation programs with preset breathing pace.
Each relaxation program has a different breathing pace. The program '4
breaths' is preset to 4 breaths per minute. Program '5 breaths' is preset to 5
breaths per minute. Each next program has one additional breath per minute.
The last program (10 breaths) is preset to 10 breaths per minute.
You can select light or sound to guide you during the selected relaxation
program. Follow the light or sound when you inhale and exhale.
-
For guidance with light, inhale when the light intensity increases. In
between the two subtle light flashes, hold your breath. Exhale slowly when
the light intensity decreases.
-
For guidance with sound, inhale when the intensity of the sound of the
waves increases. When the intensity of the sound pauses, hold your breath.
Slowly exhale when the intensity of the sound of the waves decreases.
Follow your preferred pace with the help of light or sound for a more relaxed
feeling. You can even do this with your eyes closed.
Note: You can find an instruction video of RelaxBreathe in the app and on the
Philips website.
20
English
Belly breathing for relaxation
Belly breathing is the most recognized breathing exercise technique to help
people relax. When you breathe from your belly, your diaphragm pulls down
automatically. This pulls down your lungs and allows you to inhale fully and
deeply.
Caution: If you feel uncomfortable at any point during this breathing
exercise, just go back to breathing normally.
How to do belly breathing
1 Lie down comfortably on your back.
2 Inhale through your nose, exhale through your nose or mouth.
3 Place one hand on your stomach and your other hand on your chest.
You should see your hand on your stomach move up with each inhale and
move down with each exhale. The hand on your chest should only move
slightly.
4 Your breath should only come from your belly. Try to make your exhale
longer than your inhale as this will quickly make you feel more relaxed.
Note: The RelaxBreathe function of the appliance can guide you during belly
breathing.
Bedtime function
You can track your time in bed by long-pressing the top of the appliance for
approximately 2 seconds before going to sleep to activate the bedtime
function. Or activate bedtime in the wind-down menu. You can also start the
bedtime function by pressing 'start tracking' in the SleepMapper app.
A moon icon will appear on the display of the appliance to let you know
bedtime tracking has started. You can find more information about the
bedtime function in the app.
Charging your mobile phone
You can use the USB port (see 'General description') to charge your mobile
phone.
Cleaning and storage
-
Clean the appliance with a soft, dry cloth.
-
Do not use abrasive cleaning agents, pads or cleaning solvents like alcohol,
acetone, etc., as this may damage the surface of the appliance.
-
If you are not going to use the appliance for an extended period of time,
remove the adapter from the wall outlet and store the appliance in a safe,
dry location where it will not be crushed, banged, or subject to damage.
-
Do not wrap the cord around the appliance when storing it.
Recycling
-
This symbol means that this product shall not be disposed of with normal
household waste (2012/19/EU).
-
Follow your country's rules for the separate collection of electrical and
electronic products. Correct disposal helps prevent negative consequences
for the environment and human health.
Warranty and support
If you need information or support, please visit www.philips.com/support or
go to your Philips dealer. You can also contact the philips Consumer Care
Center in your country (see the international warranty leaflet for contact
details).
Troubleshooting
This chapter summarizes the most common problems you could encounter with
the appliance. If you are unable to solve the problem with the information
below, visit www.philips.com/support for a list of frequently asked questions
or contact the Consumer Care Center in your country.
If the appliance is updated through connecting it to Wi-Fi with the app, the
information in this document may not be up to date. Find the latest user
manual on www.philips.com/support. Philips reserves the right to update the
firmware of the appliance.
English
21
Connectivity troubleshooting
Problem Solution
I cannot download the
app on my mobile phone.
The app is available for Android and iOS mobile phones. The app is not
available for Windows phones.
22
English
Problem Solution
I cannot connect my
Wake-Up Light to my
home-Wi-Fi network,
what should I do?
If you cannot connect your Wake-Up Light to your home Wi-Fi network and still
see the flashing icon for access point mode , it could be one of following
issues:
1. Wrong password. Make sure that you entered the correct Wi-Fi network
password and try again.
2. Is your router suitable for connection with your Wake-Up Light? Your router
must have a 2,4 GHz band to communicate with the appliance. For the first
time setup make sure your mobile phone and the appliance are both
connected to the same 2,4 GHz Wi-Fi network, otherwise you will not be able
to connect the appliance and your mobile phone. The appliance cannot
connect to a 5 GHz network. Temporarily switch off the 5 GHz network to
connect the appliance to 2,4 GHz network. Afterwards you can switch on the 5
GHz network again.
3. Check the signal strength of the Wi-Fi. If the signal is weak, the appliance
cannot connect properly. Move the appliance closer to the router to make sure
that a good Wi-Fi signal is available.
If the previous steps do not solve the issue, consider the following:
1. Go back to default settings by pressing the end of a paperclip into the reset
button on the back of the appliance (see 'General description'). This reset will
remove all personal settings.
2. If the previous steps are not the issue, contact the Philips Consumer Care
Center in your country.
Connecting my
connected Sleep & WakeUp Light to a Wi-Fi guest
network does not work.
How do I remove my
personal Wi-Fi settings
and alarms from the
connected Sleep & WakeUp Light?
I want to connect my
new smartphone to my
connected Sleep & WakeUp Light. What do I need
to do?
Using your appliance within a guest network is not supported. Please set up
your appliance within a regular Wi-Fi network.
Go back to default settings by pressing the end of a paperclip into the reset
button on the back of the appliance (see 'General description').
If your mobile phone is still connected to the Sleep & Wake-Up Light, first
remove the connection in the app in the 'more' tab by selecting 'Forget device'.
Please install the app again on your new mobile phone. Indicate in the app that
you already installed the connected Sleep & Wake-Up Light and follow the
instructions in the app.
Problem Solution
I cannot use the app to
set alarms or control the
connected Sleep & WakeUp Light.
First, check if your Sleep & Wake-Up Light is connected to a Wi-Fi network. If
you completed the Wi-Fi Setup through the Philips SleepMapper app and
connected your appliance to a specific Wi-Fi network, you should see a steady
Wi-Fi symbol on the main display of the appliance, in the upper right corner .
First check if Wi-Fi on your mobile phone and router are enabled. If you see the
Wi-Fi disabled icon on the display of the appliance, enable Wi-Fi first.
-
Your mobile phone could have reconnected to a different Wi-Fi network.
Make sure that your mobile phone and appliance are connected to the
same home Wi-Fi network.
If you see the Wi-Fi connection issue icon , it could be one of the following
issues.
1. Check the settings for your home Wi-Fi network on the router. It could be
that universal Plug and Play (UPnP) is not enabled on your router. Enable this
setting on the router.
2. Check the signal strength of the Wi-Fi. If the signal is weak, the appliance
cannot connect properly. Move the appliance closer to the router to make sure
that a good Wi-Fi signal is available.
3. You might have changed the home Wi-Fi password or installed a new router.
If the previous steps do not solve the issue, consider the following:
1. Go back to default settings by pressing the end of a paperclip into the reset
button on the back of the appliance (see 'General description'). This reset will
remove all personal settings.
2. If the previous steps are not the issue, contact the Philips Consumer Care
Center in your country.
English
23
I have a new router/Wi-Fi
password/Wi-Fi network
and I want to connect my
connected Sleep & WakeUp light to it. What do I
need to do?
Follow these steps to set up a connection again:
1. In the SleepMapper app, go to the ‘More’ tab and click on ‘View device
details’ and select ‘Forget device’.
2. In the settings menu of your Sleep & Wake-Up Light, press and hold the Wi-Fi
icon for 8 seconds. You will see the access point mode icon on the display.
3. Open the app again, go to the ‘More’ tab to add select 'Add a new device'.
Follow the instructions in the app.
General troubleshooting
Problem Solution
The icon on the display or
the light on the
appliance does not
respond when I try to set
different functions.
1. Disconnect the appliance from the power source by removing the adapter
from the wall socket. Wait 10 seconds and reconnect the appliance. Start it
again.
2. If restarting the appliance does not work, go back to default settings by
pressing the end of a paperclip into the reset button on the back of the
appliance (see 'General description'). Please note that all personal settings (set
alarm etc.) will be removed by going back to default settings.
If the appliance still does not work, contact Philips Consumer Care Center in
your country.
24
English
Problem Solution
The lamp does not go on
when the alarm goes off.
Perhaps you set a light intensity level that is too low. Increase the light intensity
level in your wake-up profile.
Perhaps you turned off the alarm function. The alarm icon is visible on the
display when the alarm is active.
The lamp does not go on
right away when I switch
it on.
I do not hear the alarm
sound when the alarm
goes off.
The FM radio does not
work or makes a
crackling sound.
The alarm went off
yesterday, but it did not
go off today.
It may take between 1 to 5 seconds for the lamp to go on, depending on the
set light intensity level.
Perhaps you set a sound level that is too low. To set a higher sound level,
increase the volume level of the wake-up sound in your wake-up profile.
When you have set an alarm, you will first see the light of the wake-up curve.
The alarm sound only starts playing when the set alarm time has been reached.
You can change the duration of the wake-up light curve.
If you selected the FM radio as the alarm sound, turn on the FM radio after you
turn off the alarm to check if the FM radio works.
Check if your FM radio is correctly tuned to a radio station. If necessary, adjust
the frequency. If the radio still does not work, contact the Philips Consumer
Care Center in your country.
Check if the FM radio is correctly tuned to a radio station. If necessary, adjust
the frequency.
Change the position of the antenna by moving it around. Make sure that you
have unwound the antenna completely.
Perhaps the broadcast signal is weak. Adjust the frequency and/or change the
position of the antenna by moving it around. Make sure you have unwound the
antenna completely.
Perhaps you turned off the alarm function or only set the alarm for a specific
day. The alarm icon is visible on the display when the alarm is due within 24
hours.
In the Philips SleepMapper app you have several options to set alarms; perhaps
the alarm was not set correctly. Check if you have set the alarm in the app
correctly. Make sure your appliance and the app are connected to the same
home Wi-Fi network when you set an alarm.
I wanted to snooze, but
the alarm did not go off
again after 9 minutes.
The light wakes me too
early or too late.
I am unable to turn the
Midnight Light function
on/off.
You might have accidentally pressed this icon on the display to dismiss the
alarm. This deactivates the alarm for that day. Tap the top of the appliance to
snooze.
Perhaps the light intensity level you have set is not appropriate for you. Try a
lower light intensity level if you wake up too early or a higher intensity level of
you wake up too late. You can also change the duration of the wake-up curve.
If light intensity 1 is not low enough, move the appliance further away from the
bed. If the light intensity is not high enough to wake you, make sure that the
light of the appliance is not blocked by any object and the appliance is nearby.
Make sure you tap on the correct position (top/back) of the appliance.
Problem Solution
I am unable to stream
music via USB.
The USB connection is only for charging your mobile phone. You are not able to
stream music to the connected Sleep & Wake-Up Light.
English
25
The AUX socket doesn't
work properly.
Suddenly the appliance
makes a beeping sound.
Try to set the volume on your mobile phone either higher or lower. If necessary,
adjust the volume level on the appliance as well.
The backup alarm went off. This can happen up to 8 hours after the power was
removed and a set alarm time is due. The alarm sound stops automatically after
approximately 1 minute. You also can stop the alarm sound immediately if you
power up the appliance for a brief moment.
To prevent the back-up alarm from going off when the power is removed (e.g.
storage) disable the alarms prior to powering down.
Specifications
Adapter
Manufacturer PHILIPS
Type number HF20
Rated input voltage 100 – 240V AC
Rated input frequency 50 / 60Hz
Rated output voltage 24.0VDC
Rated output current 0.75A
Rated output power 18.0W
No-load power < 0.1W
Efficiency class VI
Safety classification Class II power supply
Dimensions
(height x width x depth)
Weight Approx. 0.12kg (4.2oz.) for EU version
Cord length Approx. 150cm (4.9ft)
35 x 78 x 66 mm (1.38 x 3.07 x 2.6 in.) for EU version
50 x 78 x 56 mm (1.97 x 3.07 x 2.2 in.) for UK version
Approx. 0.13 kg (4.6 oz.) for UK version
Main unit
Manufacturer PHILIPS
Type number HF3670, HF3671, HF3672
26
English
Rated input voltage 24V DC
Rated input current 0.75A
Rated input power 18W
Standby power appliance
(main unit + adapter)
Conditions: night (12 h / 0 lux), day (12 h / 500 lux), all functions
suspended
Safety classification Class III luminaire
Dimensions
(height x width x depth)
Weight Approx. 0.78kg (27.5oz.)
< 2 W (Wi-Fi on and display at maximum brightness)
< 1 W (Wi-Fi off and display maximum brightness)
< 0.5 W (Wi-Fi off and display off)
Approx. 225 x 220 x 120mm (8.86 x 8.66 x 4.72in.)
Ports
USB charging 5V DC, 1A
AUX sensitivity 280 mV
Light
Light output (level 1 – 25) Approx. 1 lux – 350*lux at 45cm (approx. 1 lux – 350*lux
Light color (level 1 – 25) Approx. 1500 K – 2800K
at 17.7in.)
*depending on model
FM
FM-radio frequency band 87.5MHz – 108.0MHz
Wi-Fi
Operating frequency (channel 1 – 13) 2412 MHz – 2472 MHz
Modulation type IEEE 802.11b, 802.11g, 802.11n
RF output power Max. 20 dBm
AmbiTrack sensors
Light sensor 0 lux to 2500 lux
Temperature sensor 0 °C to 50 °C (32 °F to 122 °F)
Humidity sensor 0% to 100% (relative humidity)
Sound pressure sensor 30 dBA to 70 dBA
Operating conditions
Temperature 5 °C to 35 °C (41 °F to 95 °F)
Relative humidity 20 % to 90 % (no condensation)
Atmospheric pressure 86 kPa to 106 kPa
Storage conditions
Temperature -20 °C to 50 °C (-4 °F to 122 °F)
Relative humidity 20 % to 90 % (no condensation)
Atmospheric pressure 86 kPa to 106 kPa
Open-source and third-party software
A copy of the open-source software and third-party commercial software
license agreement can be found on the website www.philips.com/support
Search for the device number HF3670 / HF3671 / HF3672 / HF3650 / HF3651 /
HF3652 / HF3653 / HF3654 on the technical documentation page of the
product.
English
27
28
Dansk
Indhold
Introduktion _____________________________________________________________________________ 29
Generel beskrivelse ________________________________________________________________________ 29
Beregnet anvendelse ______________________________________________________________________ 29
Virkningerne ved Sleep & Wake-Up Light _____________________________________________________ 30
Vigtige sikkerhedsoplysninger ______________________________________________________________ 30
Sikkerhed og overensstemmelse ____________________________________________________________ 32
Elektromagnetiske felter (EMF)______________________________________________________________ 32
Interaktive menuikoner ____________________________________________________________________ 32
Sådan tilsluttes apparatet til Wi-Fi ___________________________________________________________ 32
Navigering i menuen ______________________________________________________________________ 34
Indstilling af vækkeprofiler _________________________________________________________________ 35
Backup for tid + alarm______________________________________________________________________ 36
Snooze-funktion __________________________________________________________________________ 36
Slå alarmen fra ____________________________________________________________________________ 36
Sådan brugesapparatet som sengelampe ____________________________________________________ 37
Midnight Light ____________________________________________________________________________ 37
Indstillinger_______________________________________________________________________________ 37
Lytte til musik _____________________________________________________________________________ 39
Gear ned-programmer _____________________________________________________________________ 40
Simulation af solnedgang __________________________________________________________________ 40
RelaxBreathe _____________________________________________________________________________ 41
Sengetidsfunktion_________________________________________________________________________ 42
Opladning af mobiltelefon _________________________________________________________________ 42
Rengøring og opbevaring __________________________________________________________________ 42
Genanvendelse ___________________________________________________________________________ 43
Reklamationsret og support ________________________________________________________________ 43
Fejlfinding________________________________________________________________________________ 43
Specifikationer ____________________________________________________________________________ 47
Open source- og tredjepartssoftware ________________________________________________________ 49
Introduktion
Tillykke med dit køb, og velkommen til Philips! For at få fuldt udbytte af den
support, Philips tilbyder, skal du registrere dit produkt på
www.philips.com/welcome.
Philips SmartSleep-tilsluttede Sleep & Wake-Up Light kan give dig en mere
behagelig opvågning. Lyset forbereder roligt din krop på at vågne til den tid, du
har sat vækkeuret til, og kan kombineres med naturlige opvågningslyde eller
FM-radio.
Den lys-guidede åndedrætsfunktion, personligt tilpassede solindstillinger,
registrering af soveværelsesomgivelser og flere andre funktioner gør dette
tilsluttede Sleep & Wake-Up Light til den perfekte ledsager i dit soveværelse.
Tip: Brug af Philips SleepMapper-appen giver ekstra funktioner. Oplysninger om
disse funktioner er forklaret i appen.
Hvis apparatet opdateres via tilslutning til Wi-Fi med appen, er oplysningerne i
dette dokument muligvis ikke aktuelle. Find den nyeste brugervejledning på
www.philips.com/support ved at søge efter dit apparats typenummer.
Generel beskrivelse
De nummererede dele på denne liste refererer til de nummererede dele i
oversigtsillustrationen.
1 Lampekabinet
2 Display
3 Lydniveausensor
4 USB-opladerport
5 Reset-knap (nulstilling)
6 Radioantenne
7 AmbiTrack-sensor: Luftfugtigheds- og temperatursensor
8 Ekstrastik (AUX)
9 Jævnstrømsstik til adapter
10 Højttaler
11 Snooze/Midnight Light
12 Adapter
13 Lille stik
Dansk
29
Beregnet anvendelse
Det Philips SmartSleep-tilsluttede Sleep & Wake-Up Light er beregnet til at give
dig en mere naturlig og frisk opvågning og en mere afslappende fornemmelse,
inden du falder i søvn.
Dette produkt er ikke beregnet til at give generel belysning.
30
Dansk
Virkningerne ved Sleep & Wake-Up Light
Det Philips SmartSleep-tilsluttede Sleep & Wake-Up Light forbereder dig blidt
på at vågne i løbet af de sidste 30 minutter af din søvn. Tidligt om morgenen er
øjnene mere følsomme over for lys, end når vi er vågne. I denne periode
forbereder de relativt lave lysniveauer i en simuleret naturlig solopgang vores
krop på at vågne.
Dem, der bruger apparatet, vågner lettere, føler sig generelt bedre tilpas og
mere oplagt om morgenen. Da lysfølsomheden er forskellig fra person til
person, kan du indstille lysintensiteten på apparatet til et niveau, der passer til
din egen lysfølsomhed, så du fåren optimal start på dagen.
For at få den fulde effekt af det tilsluttede Sleep & Wake-Up Light skal du
placere apparatet cirka 40 cm – 50 cm fra dit hoved på en flad stabil overflade
på dit natbord.
Du finder flere oplysninger om det tilsluttede Sleep & Wake-Up Light på
www.philips.com.
Vigtige sikkerhedsoplysninger
Læs disse vigtige oplysninger omhyggeligt igennem, inden apparatet tages i
brug, og gem dem til eventuel senere brug.
Fare
-
Vand og elektricitet er en farlig kombination. Brug ikke apparatet i våde
omgivelser (f.eks. i badeværelset eller i nærheden af en bruser eller
swimmingpool).
-
Hold adapteren tør.
-
Dette produkt er kun til indendørs brug.
-
Sørg for, at der ikke trænger vand ind i apparatet, og at der ikke spildes vand
på det.
-
Apparatet må aldrig kommes ned i vand eller skylles under vandhanen.
-
Placer ikke noget i nærheden af apparatet, der kan få vand eller anden
væske til at dryppe eller stænke på det.
-
Adapteren indeholder en transformator, der omformer en farlig
100–240Vvekselstrømsspænding til en sikker 24Vjævnstrømsspænding.
Klip ikke adapteren af for at udskifte den med et andet stik, da dette vil føre
til farlige situationer.
Advarsel
-
Brug aldrig apparatet, hvislampekabinettet er beskadiget, gået i stykker
eller mangler.
-
Apparatet må ikke benyttes, hvis adapter, ledning eller apparat på nogen
måde er beskadiget, hvis der er spildt væsker på det, eller hvis apparatet har
været udsat for stødpåvirkninger, hvis apparatet har været udsat for
påvirkninger fra regn eller fugt, hvis det ikke fungerer normalt, eller hvis det
er blevet tabt eller beskadiget.
-
Hvis du begynder at føle ubehag i forbindelse med vejrtrækningsøvelsen
RelaxBreathe, skal du bare trække vejret normalt igen.
Loading...
