Philips EXP2301-00, EXP2300 User Manual
Portable MP3-CD Player
EXP2300
EXP2301
User manual
Manuel d'utilisation
Manual del usuario
Gebruikershandleiding
Printed in China
Meet Philips at the Internet
http://www.philips.com
EXP2300, EXP2301
AL/JW-430-2
EQ
%
1
6
2
@
5
4
3
#
0
7
$
8
9
!
1
OPEN
3
CD
4
CD
5
HOLD ➟ OFF
6
PLAY 2;
7 VOL
!!!
2
QUICK START MISE EN SERVICE RAPIDE
1
2.
1.
English
CONTROLS
Supplied Accessories:
1 x headphones HE035
1 x AC/DC adapter AY3162 (not for all versions)
CONTROLS ( see figure 1)
1 VOL
E
.........adjusts the volume.
2 OPEN 2.............opens the CD lid.
3 9 ........................stops playback/clears programmed tracks/ switches off the
set.
4 MODE................selects playback options (e.g. SHUFFLE, REPEAT).
5
-/+
....................MP3 only: skips forward/backward albums.
6 PROG.................programs tracks and reviews the program.
7 ...........................display
8 2;......................switches the player on, starts playback and pauses playback.
9 EQ ......................selects from 4 different equalization settings
0 ∞ /§................skips and searches tracks backward/forward.
! ESP....................selects between the battery powersave mode and Electronic
Skip Protection (ESP). ESP prevents playback interruptions
caused by shocks.
@ OFF.....................switches HOLD off.
HOLD .................locks all buttons.
# p / LINE OUT....3.5mm headphone jack;
jack to connect the player to another audio input of an
additional appliance.
This set complies with the radio interference requirements of the
European Union.
CONTROLS
$ 4.5V DC ...............jack for external power supply.
% .............................typeplate
POWER SUPPLY
Batteries (not included)
Inserting AA (LR6, UM3) batteries
1 Open the battery compartment.
2 Insert 2 x AA batteries as shown into the battery
compartment.
3 Close the battery compartment.
Helpful Hints:
– Old and new or different types of batteries should not
be combined.
– Remove batteries if they are empty or if the player is not going to be used for a
long time.
Battery indication
The battery level is shown in the display screen as follows:
Battery usable
Battery empty
Average playing time of batteries under normal conditions
Battery type Power Save
Audio CD MP3-CD
Alkaline AA 18 hours 28 hours
Batteries contain chemical substances, so they should be disposed of properly.
POWER SUPPLY
Power adapter (supplied or optionally available)
Only use AY3162 adapter (4.5V/450mA DC, positive
pole to the center pin). Any other product may damage
the player.
1 Make sure local voltage corresponds to the power
adapter's voltage.
2 Connect the power adapter to the 4.5V DC socket of
the player and to the wall socket.
Helpful Hints:
– Always disconnect the adapter when you are not using it.
GENERAL INFORMATION
CD player and CD handling
• Do not touch the lens A of the CD player.
• Do not expose the unit, batteries or CDs to humidity, rain, sand or excessive heat (caused by heating
equipment or direct sunlight).
• You can clean the CD player with soft, slightly
dampened, lint-free cloth. Do not use any cleaning
agent as it may have a corrosive effect.
• To clean the CD, wipe it in a straight line from the center toward the edge
using soft, lint-free cloth. The cleaning agent may damage the disc! Never
write on a CD or attach a sticker to it.
• The lens may cloud over when the unit is moved suddenly from cold to warm
surroundings. In that case, playing a CD is not possible. Leave the CD player in
a warm environment until the moisture has evaporated.
• Active mobile phones in the vicinity of the CD player may cause malfunctions.
• Avoid dropping the unit as this may cause damage.
GENERAL INFORMATION
ENVIRONMENTAL INFORMATION
• All redundant packing material has been omitted. We have done our utmost to
make the packaging easily separable into two mono materials: cardboard (box)
and polyethylene (bags, protective foam sheet).
• Your set consists of materials which can be recycled if disassembled by a specialized company. Please observe the local regulations regarding the disposal
of packing materials, dead batteries and old equipment.
– Apparatus shall not be exposed to dripping or splashing.
– Do not place any sources of danger on the apparatus
(e.g. liquid filled objects, lighted candles)
2.
1.
