Pelco DX4808HD-4000 Specsheet

PRODUCT SPECIFICATION

video management solutions

DX4700HD/DX4800HD Series Hybrid Video Recorders

16- AND 24-CHANNEL HVR WITH HD DISPLAY AND REAL-TIME RECORDING

Product Features

• Supports the DX Mobile Application for Access on Devices Running

®

iOS 5.x or Later and Android™ 3.x or Later

Apple

• Supports Integration with Third-Party VMS Through the Pelco API

• Motion Recording for IP Cameras

• 8 or 16 Analog Cameras Plus 8 IP Cameras or Encoders

• Supports 8 Megapixel (MPx) IP Cameras at up to 12 Mbps Total

• Supports Pelco IP and Axis

3 MPx Resolution

• Up to 30/25 Images Per Second (ips) at 4CIF Resolution for

DX4800HD

• Up to 30/25 Images Per Second at CIF Resolution for DX4700HD

• Supports Continuous, Motion, and Alarm Recording

• 1080p Video Display over VGA

• Operates in Both IPv6 and IPv4 Network Environments

• Searchable by Date/Time, Event, Bookmark, ATM/POS, Export

Review, and Pixel

®

VAPIX® version 3 IP Cameras up to

• Up to 8 TB Internal Storage Capacity

• eSATA Storage Expansion Port

• 1 Bidirectional Audio Output

• DX Series Client Simultaneously Connects to DX Series DVRs/HVRs

• DS ControlPoint Client Simultaneously Connects to both DX and

DS Series DVRs/HVRs

®

• Support for Coaxitron

Control of Analog Cameras

and Pelco’s KBD300A Keyboard for PTZ

The DX4700HD/DX4800HD Series of hybrid video recorders
provides a cost-effective solution to customers who have continued
requirements for 8 or 16 analog cameras and want to expand their
systems with megapixel IP recording. The ability to support eight

®

Pelco megapixel IP cameras, or Axis

cameras, gives customers new
power and flexibility in their IP migration path. Customers can now
benefit from megapixel image detail where they need it most. For
example, customers can monitor registers, cash counting operations,
high-value merchandise areas, or lobbies and entrances while still
receiving maximum value from existing analog cameras and cabling.

DX4700HD/DX4800HD Series HVRs give customers the ability to
record at the speed and resolution they need. The new CPU resource
meter monitors system resources in real time and is a useful gauge for
the addition of IP cameras to the system. Both models record up to
30 ips on all channels. In addition, the DX4800HD adds the ability to
record full frame rate video at 4CIF resolution for all cameras. With
this kind of recording power, previous analog investments gain
extended life.

Customers can take advantage of high resolution video by displaying
output from the DX4700HD/DX4800HD Series on 1080p monitors
over VGA. The DX4700HD/DX4800HD Series is compatible with all
Pelco VGA 1080p monitors.

With up to 8 TB of internal storage, the DX4700HD/DX4800HD
Series overcomes the high storage demands of megapixel and high
speed recording without sacrificing speed for resolution. Customers
can readily expand storage with either JBOD or RAID 5 optional
eSATA devices. DX4700HD/DX4800HD Series HVRs also match
security requirements to storage needs with the unique HDD
partitioning feature, which can allocate individual disk partitions for
normal and alarm recording if desired.

DX4700HD/DX4800HD Series HVRs provide the unique ability to
leverage installed systems: the new DX Series remote client
provides operational functionality for DX4000 and DX8000 Series
DVRs/HVRs, and the optional DS ControlPoint software integrates

®

with DX Series products as well as Digital Sentry

systems.

DX4700HD/DX4800HD Series users will benefit from the robust
capabilities including the use of bidirectional audio for enhanced
security, access instant playback for quick investigative work, and
the ability to capture and overlay ATM/POS text with video recording.
For all its features, the DX4700HD/DX4800HD Series reduces
installation overhead with out of the box recording. An intuitive
interface makes custom installation easy and reduces learning time
for end customers.

With a wide new range of capabilities, DX4700HD/DX4800HD
Series HVRs well suit the needs of existing analog markets and are
an integral part of an efficient megapixel IP migration strategy.

International Standards

Organization Registered Firm;

ISO 9001 Quality System

C5615 / REVISED 8-5-13

APPLICATIONS

The DX4700HD/DX4800HD Series is perfect for customers who want higher resolution images than analog cameras can provide for specific critical areas of their
business, including cash-counting, cashiers, entry/exit, or high-value merchandise areas.

Client-to-server connectivity allows operation from a remote location and can connect to as many as 100 DX Series systems simultaneously. Up to 100 systems
can be added to the DX Series client site tree. Multiple DX Series clients, running on dispersed computers, can host a variety of servers in their respective site
trees. The DX Series client can operate multiple DX Series systems including DX4700HD/DX4800HD, DX4700/DX4800, DX4100, DX4500/DX4600, DX8000,
and DX8100 systems. Each server supports five simultaneous remote connections. The optional DS ControlPoint client can be used to simultaneously operate
any of the current DX Series systems as well as any Integral or Digital Sentry DVR/HVR.

DX Series DVRs and HVRs offer the flexibility to meet the size and performance of industry video recording requirements. For example, small sites can use DX4700
to add one to two IP cameras and record 30/25 ips at CIF resolution. DX4700HD/DX4800HD Series HVRs expand security by adding the value of eight megapixel
cameras to an analog environment of 8 or 16 cameras and the performance of 4CIF/30 ips for the DX4800HD Series. Both the DX4700HD/DX4800HD Series and
DX4700/DX4800 Series also support ATM/POS recording.

The DX4700HD/DX4800HD Series provides valuable audio recording capabilities for those applications where policy and legislation allow. Bidirectional audio is an
excellent tool for training or for an increased security presence. With up to four audio inputs and two audio outputs, full recording, search, export, and playback
capabilities are available at the server. IP streams can be viewed in megapixel resolution at both the server and client.

2 IP

DX4700

8 IP

1 TO 8

ANALOG

KBD300A

000

0
SERIES

DX4708HD

MIC

2 IP

SWITCH

SPEAKERS

000

0
S
E

R
I
ES

DX4800

NETWORK

SWITCH

DS NVs

DX SERIES CLIENT OR
DS CONTROL POINT

ETHERNET

SERIAL

ANALOG

USB

RCA

8 IP

1 TO 16

ANALOG

000

0
S
E

R
I
ES

DX4816HD

MIC

SPEAKERS

ATM/POS

REGCOM

HYDRA

IMPORTANT NOTE. PLEASE READ.

The network implementation is shown as a general representation only and is not intended to show a detailed network topology. Your actual
network will differ, requiring changes or perhaps additional network equipment to accommodate the system as illustrated. Please contact your
local Pelco representative to discuss your specific requirements.

ELECTRICAL/VIDEO

Input Voltage 90 to 264 VAC, 50/60 Hz, autosensing
Power Consumption Maximum 220 W
Signal System NTSC/PAL, switchable
Operating System Embedded Linux
Video Compression H.264 Main profile
Recording Resolutions NTSC PAL

Video Outputs 1 main VGA or analog multiscreen for live

Multiscreen 1 configurable, analog spot monitor
Display Resolution

Server Up to 1920 x 1080
Client Up to 1920 x 1080

Remote Connection LAN/WAN

Network Connection Gigabit Ethernet, RJ-45
Simultaneous Remote

Connections 5
Bandwidth Throttle Server-based, 32 Kbps to 100 Mbps
Network Streaming Configurable per camera

704 x 480 704 x 576
704 x 240 704 x 288
352 x 240 352 x 288

viewing

TCP/IP (IPv6, IPv4)

SUPPORTED PTZ PROTOCOLS

Pelco C, Pelco D, Pelco P
Bosch_Autodome
Ganz_DSCP, Ganz_P360V1
Kalatel_Cyberdome
LG_Multix, LG_SD168
Panasonic_CS850
Samsung_SCC

MAXIMUM IPS RECORDING

NTSC IPS PAL IPS

Model Format

DX4708HD

DX4716HD

DX4808HD

DX4816HD

Tot al

CIF 240 30 200 25

2CIF 120 15 100 12.5

4CIF 60 7.5 50 6.25

CIF 480 30 400 25

2CIF 240 15 200 12.5

4CIF 120 7.5 100 6.25

CIF 240 30 200 25

2CIF 240 30 200 25

4CIF 240 30 200 25

CIF 480 30 400 25

2CIF 480 30 400 25

4CIF 480 30 400 25

Per

Camera Total

Per

Camera

AUDIO

Line In

DX4708HD/DX4716HD 2, mono, RCA line in

DX4808HD/DX4816HD 4, mono, RCA line in
Output 2, mono, 0 dB, RCA
Sampling Rate 128 Kbps (16 KHz)
Two-Way Audio Mic-in, line-out
Supported Codecs G.711, G.721, G.728

MECHANICAL

Connectors

Video Inputs 8 or 16, BNC

Video Outputs 8 or 16, BNC, looping

Alarm Input 1 per BNC input;

Relay Output 2 for 8-channel (N.C. or N.O.);

Relay Contact Ratings*

Rated (resistive) Load 0.5 A at 120 VAC or 1 A at 24 VDC
Video Output 1 SVGA or 1 analog
TCP/IP Port RJ-45, 10/100/1000
Data Input 2, RS-422/RS-485 terminals for connecting

DB9 1, RS-232C connector for interfacing with an

USB 2 high-speed USB 2.0 ports (1 front, 1 back)
eSATA 1 eSATA port for JBOD or RAID 5 external

*Relays are grounded.

Screw terminal;
N.C. or N.O., supervised or nonsupervised

4 for 16-channel (N.C. or N.O.)

PTZ cameras

ATM/POS device

storage

GENERAL

Operating Temperature 0° to 50°C (32° to 122°F)
Relative Humidity Maximum 80%, noncondensing
Mounting Standard 19-inch rack mount (2 unit)
Dimensions 49.78 x 48.26 x 8.89 cm

Unit Weight

Without HDD 6.0 kg (13.2 lb)
With HDD 9.0 kg (19.8 lb)

Shipping Weight 18.2 kg (40.0 lb) maximum
Camera Views

Server 1, 4, 6, 8, 9, 16, 25
Client 1 to 36

(19.6" D x 19.0" W x 3.5" H)

CERTIFICATIONS/PATENTS

•CE

• FCC, Class A

• UL/cUL

•C-Tick

•CCC

•KCC

• S Mark for Argentina

CLIENT MINIMUM PC REQUIREMENTS

Processor Intel® Pentium® 4 (or later), 1 GHz
Operating System Microsoft

Memory 256 MB
Video 64 MB
Display Resolution 1024 x 768, 32-bit color

®

Windows XP (SP3), Windows Vista
Windows 7 and DirectX

Windows® 2000,

®

9.1 (or later)

®

, or

PRODUCT MODELS AND FEATURES

Feature DX4708HD DX4716HD DX4808HD DX4816HD

IP Cameras or Encoders 8 8 8 8

Images Per Second at 4CIF 60 240 240 480

Multi-Event Recording Yes Yes Yes Yes

Standard Optical Disk Drive DVD±RW DVD±RW DVD±RW DVD±RW

Maximum Hard Disk Storage (GB) 8000 8000 8000 8000

Audio Inputs/Outputs 2/2 2/2 4/2 4/2

Alarm Inputs/Outputs 8/2 16/2 8/4 16/4

MODEL NUMBERS

Model numbers for the DX4700HD/DX4800HD Series consist of the base
model code (features for which are listed above), the number of analog video
connections, and the size of the internal hard drive. The combination of
features you choose determines your model number. For example, the model
number for a DX4800HD unit with 16 analog channels and 2 TB of storage is
DX4816HD-2000.

Note: Model numbers must possess the HD designation in order to support
the features listed in these specifications.

DXXXXXHD-XXXX

Model
Channels (8 or 16)
Storage (GB)

Base Model Channels (HD) Storage in GB

DX4700
DX4800

8

16

250

500
1000
2000
4000
6000
8000

SUPPLIED ACCESSORIES

Power Cords 1 USA, 1 European, and 1 UK
USB Mouse 1 for configuration and operation
Resource Disc 1, contains server and client software and

documentation
Remote Control 1 for configuration and operation
Accessory Hardware Alarm and relay terminal blocks,

rack mount kit

COMPATIBLE PRODUCTS

Pelco Sarix® IP Cameras (IM, IX, ID, and IE Series)
Pelco NET5400 Series Encoders
Axis IP Cameras (must be compatible with VAPIX version 3)
KBD300A Keyboard
DX Series Client
DS ControlPoint
Pelco API
Mobile Devices Running Apple iOS 5.x or Later and Android 3.x or Later
American Video Equipment Hydra

™

JBOD or RAID 5 External eSATA HDD Enclosures*
1080p Resolution Monitors Over VGA (recommended)
*The DX4700HD/DX4800HD Series has been tested with the Promise

Technology, Inc. SmartStor
enclosure with a maximum capacity of four Seagate 1 TB Barracuda

®

model DS4600 enclosure. Pelco tested this

®

SV35.5 (model ST31000525SV) drives.

OPTIONAL ACCESSORIES

KBD300A KBD300A desktop keyboard with full

KBD300USBKIT Remote keyboard wiring kit (120 VAC) for

KBD300USBKIT-X Remote keyboard wiring kit (230 VAC) for

NET5400 Series Network video encoders for integrating

Note: It is recommended that you use a 1080p resolution monitor with a VGA
input. Pelco offers a variety of monitor options to accommodate this
specification. Contact the factory for more information.

switching and configuration capabilities and

joystick control of PTZ functions; requires a

KDB300USBKIT or a KBD300USBKIT-X

KBD300A

KBD300A

analog cameras into IP video surveillance

systems

Pelco by Schneider Electric

3500 Pelco Way, Clovis, California 93612-5699 United States

USA & Canada Tel [phone] Fax [phone]
International Tel [phone] Fax [phone]
www.pelco.com www.pelco.com/community

Pelco, the Pelco logo, and other trad emarks associated with Pelco products referred

to in this publication are trademarks of Pelco, Inc. or its affiliates. ONVIF and the

ONVIF logo are trademarks of ONVIF Inc. All othe r product names and

Product specifications and availability are subject to change without no tice.

services are the property of their respective comp anies.

©Copyright 2013, Pelco, Inc. All rights reserved.
