Peerless-AV PRMA100 User Manual
FULL-MOTION TILTING TV WALL MOUNT
For 10" - 26" TVs
®
VESA
ADJUST
TILT
Fits 10" to 26" (25-66cm)
TVs with VESA® 75, 100
and 200 x 100mm
mounting patterns
Extends, turns and tilts with
a full range of motion for
the ideal viewing position
Vertical tilt movement
to ensure the ideal
viewing angle
25LB
11kg
VESA
®
LEVEL
ORGANIZE
Ensure alignment
with included level
Cable management
protects, contains &
conceals your cables
PRMA2X1
Model Number(s)
WARRANTY: Limited 5-year
PRMA2X1
The Paramount™ series articulating
wall mounts give the ultimate in
TV positioning, with one-person,
Hook-and-Hang™ easy installation.
The articulating arm allows you to
extend the TV up to 14.89" (378mm)
from the wall, and can retract to
just 2.79" (71mm) from the wall. The
integrated cable management
provides a clean, professional
nish. One-Touch™ tilt of ±15°, ±5°
roll for post-installation leveling
and ±90° of pivoting means the TV
will be perfectly positioned for the
optimum viewing angle.
FULL-MOTION TILTING TV WALL MOUNT FOR 10"-26" TVs
HOOK-AND-HANG™
INSTALLATION
TV is easily installed
by a single person
±15° ONE-TOUCH™ TILT
Easily adjust the angle of the TV
without the use of tools
9.36"
(238mm)
2.80"
(71mm)
2.25"
(57mm)
5.50"
(140mm)
EXTENDS UP TO
14.89" (378mm)
Offers the perfect
viewing angle
MOUNTS TO WOOD STUD,
CONCRETE, CINDER
OR BREEZE BLOCK
Can be mounted anywhere
in the home
VESA® COMPATIBLE
Accomodates a variety
of TV mounting paterns
ES
All dimensions = inch (mm)
4.50"
(114mm)
0.50"
(13mm)
5.38"
(100mm)
(137mm)
7.62"
(194mm)
Product Specifications
PACKAGE SIZE
(L x W x H)
PRMA2X1
8.0" x 9.8" x 2.4"
(204 x 249 x 61mm)
Ordering Specifications
MASTER PACK SIZE
(L x W x H)
TOP VIEW WALL PLATE
7.87"
(200mm)
3.94"
4.44"
(113mm)
FRONT VIEW
PACKAGE
SHIP WEIGHT
2.9lb (1.2kg) 735029294290 1 25lb (11kg) Black
MASTER PACK
SHIP WEIGHT
SIDE VIEW
PACKAGE
UPC
MASTER PACK
2.79"
(71mm)
UPC
UNITS IN
PACKAGE
15.62"
(397mm)
14.89"
(378mm)
13.02"
(331mm)
SIDE VIEW
+/-15° TILT
LoAd CAPACITy AVAILABLE CoLoRS
UNITS IN
MASTER PACK
PRMA2X1
Peerless Industries, Inc. 2300 White Oak Circle Aurora, IL 60502 (800) 865-2112 (630) 375-5100 Fax: (800) 359-6500 peerless-av.com
Visit peerless-av.com to see the complete line of AV solutions from Peerless-AV, including at panel mounts, projector mounts, carts/stands, furniture, cables, screen cleaners and a full assortment of accessories.
© 2013 Peerless Industries, Inc. Peerless-AV® is a registered trademark and ParamountTM is a trademark of Peerless Industries, Inc. All rights reserved.
10.5" x 9.3" x 8.3"
(267 x 235 x 210mm)
12.8lb (5.8kg) 10735029294297 4
LIT-1041
