Peerless-AV PANA-C84103 User Manual

PANA-C84103
500 lb
MAX
(227 kg)
ENG
1
2015-06-30 #:126-9068-1
WARNING
Do not begin to install product until you have read and understood the instructions and warnings contained in this user guide. Always use an assistant or mechanical lifting equipment to safely lift and position equipment. This product must be installed onto fl at, hard, level surface to prevent tipping. The cart or stand is not affi xed or secured to the fl oor, and may therefore tip over and/or fall if screen and/or stand is shaken or hit. Displays must be removed before moving cart. Not recommended for use in areas with heavy traffi c. This product is intended for indoor use only. Use of this product outdoors could lead to product failure or personal injury. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the Maximum Load Capacity. Be careful not to pinch fi ngers when operating the mount. For support please call customer care at 1-800-865-2112.
ENG
Symbols
To properly tighten screws: Tighten until screw head makes contact, then tighten another 1/2 turn. Do not overtighten screws.
1
ENG
WARNING
Screws must get at
ENG
least three full turns and fi t snug.
x3
2
ENG
Heavy
Display center.
ENG
Do not overtighten screws.
ENG
Tools Needed for Assembly.
3
+1/2
4
2
2015-06-30 #:126-9068-1
ENG
This page was intentionally left blank
3
2015-06-30 #:126-9068-1
Parts (Before beginning, make sure you have all parts shown below).
Parts List
A caster, 5" swivel 4 600-0026 B caster support 4 145-T1799 C cover 6 145-T1809 D base leg 2 145-T1767 E horizontal leg support 2 145-T1785 F base support tube 2 145-T1812 G base support 10 560-T1261 H vertical leg support 2 145-T1777
I adaptor bracket left 1 146-T1298 J adaptor bracket right 1 146-T1299 K computer cover 1 145-T1930 L computer shelf 1 145-T1931 M rail weldment 1 146-T1295 N cord bracket 4 146-T1321 O locking tab 4 145-TI936 P M8 x 16mm socket button screw 84 520-9527 Q M8 square nut 64 530-1066 R cover clip 24 590-0317 S M5 x 10mm type-f, socket pin screw 6 520-1164 T M5 x 12mm socket pin screw 4 520-1064 U 1/4" power bit 1 560-0263 V 5mm allen wrench 1 560-9640
W lock tab 2 201-T1204
X vertical support bracket 2 146-T1296 Y 4mm allen wrench 1 560-9646 Z clip hook bracket 2 146-T1320
AA M5 x 30mm socket pin screw 2 520-1112 BB cable tie 8 560-9711
A
(4)
caster
(4)
B
caster support
C
(6)
cover
(2)
D
base leg
Part #Description Qty
(2)
H
vertical leg
support
(10)
G
base support
(2)
F
base support
tube
(2)
E
horizontal leg
support
4
(1)
I
adaptor
bracket left
2015-06-30 #:126-9068-1
(1)
J
adaptor
bracket right
(4)
O
locking tab
AA
M5 x 30mm
(84)
P
M8 x 16mm
M
weldment
(2)
Q
M8 square nut
(1)
rail
(64)
(24)
R
cover clip
(2)
X
vertical support
bracket
(6)
S
M5 x 10mm
(1)
L
computer shelf
K
computer cover
(2)
W
lock tab
(4)
T
M5 x 12mm
(1)
(1)
U
1/4" power
bit
(1)
Y
4mm allen
wrench
(1)
V
5mm allen
wrench
(4)
N
cord
bracket
5
(8)
cable tie
(2)
Z
clip hook
bracket
2015-06-30 #:126-9068-1
1
Repeat for each caster assembly.
B
V
(5mm)
P (4)
A
Do not fully tighten hardware
P (2)
Q (2)
SIDE VIEW
6
2015-06-30 #:126-9068-1
2
Repeat for each base leg assembly.
V
(5mm)
Q (2)
D
F
P (4)
Q (2)
Q (2)
Q (2)
F
P (4)
7
2015-06-30 #:126-9068-1
3
Repeat for each base leg assembly.
TIGHTEN CONNECTING HARDWARE
ENG
FLUSH EDGES
Casters must be fl ush to end of horizontal leg support.
ENG
4
Repeat for each base support (x10).
Q(4)
P(4)
G
SIDE VIEW
Do not fully tighten hardware
8
2015-06-30 #:126-9068-1
5
Repeat for each side (x2).
TIGHTEN CONNECTING HARDWARE
G(4)
6
LOCK WHEELS
H
TIGHTEN CONNECTING HARDWARE
E
9
2015-06-30 #:126-9068-1
7
8
TIGHTEN CONNECTING HARDWARE
G(2)
E
TIGHTEN CONNECTING HARDWARE
E
10
38.0"
96.5cm
2015-06-30 #:126-9068-1
9
Repeat for each vertical support bracket (x4).
P (2)
10
Q (4)
X
X (2)
P (4)
1/8"
(3mm)
1/8"
(3mm)
11
2015-06-30 #:126-9068-1
11
M
TIGHTEN
HARDWARE
(X2)
Cross support must center on vertical leg supports.
12
TIGHTEN
HARDWARE
(X2)
2015-06-30 #:126-9068-1
12
N
O
T
OPTIONAL: Unlock wheels to move cart to desired location; Lock wheels before hanging screens.
LOCK WHEELS
13
TIGHTEN CONNECTING HARDWARE
O
N
T
TOP VIEW
2015-06-30 #:126-9068-1
13
J
14
I
2015-06-30 #:126-9068-1
14
W (2)
14
15
S (2)
Z (2)
AA (2)
2015-06-30 #:126-9068-1
15-1
15-2
Secure screw in "locked" position.
Unlocked Locked
Z (2)
16
2015-06-30 #:126-9068-1
16
17
L
1/8"
(3mm)
S (2)
L
TIGHTEN CONNECTING HARDWARE
17
L
K
2015-06-30 #:126-9068-1
18
Repeat for each cover.
R (4)
C
18
2015-06-30 #:126-9068-1
19
Route cables through cord brackets.
N
19
2015-06-30 #:126-9068-1
Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless® products will be free from defects in material and
LIMITED FIVE-YEAR WARRANTY
workmanship, under normal use, for a period of fi ve years from the date of purchase by the original end-user (but in no case longer than six years after the date of the product's manufacture). At its option, Peerless will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
In no event shall the duration of any implied warranty of merchantability or fi tness for a particular purpose be longer than the period of the applicable express warranty set forth above. Some states do not allow limitations on how long a implied warranty lasts,
so the above limitation may not apply to you. This warranty does not cover damage caused by (a) service or repairs by the customer or a person who is not authorized for such service
or repairs by Peerless, (b) the failure to utilize proper packing when returning the product, (c) incorrect installation or the failure to follow Peerless' instructions or warnings when installing, using or storing the product, or (d) misuse or accident, in transit or otherwise, including in cases of third party actions and force majeure.
In no event shall Peerless be liable for incidental or consequential damages or damages arising from the theft of any product, whether or not secured by a security device which may be included with the Peerless
exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty is in lieu of all other warranties, expressed or implied, and is the sole remedy with respect to product defects. No dealer,
distributor, installer or other person is authorized to modify or extend this Limited Warranty or impose any obligation on Peerless in connection with the sale of any Peerless
This warranty gives specifi c legal rights, and you may also have other rights which vary from state to state.
®
product.
®
product. Some states do not allow the
