Owner’s Manual
42”/50”/55”/60”/65” Class 1080p
Plasma HDTV
(41.9/49.9/55.1/60.1/64.7 inches measured
diagonally)
Manual de usuario
Televisión de alta definición de 1080p
y clase 42”/50”/55”/60”/65” de Plasma
(41,9/49,9/55,1/60,1/64,7 pulgadas medidas
diagonalmente)
For assistance (U.S.A./Puerto Rico), please call:
1-877-95-VIERA (958-4372)
www.panasonic.com/help
For assistance (Canada), please call:
1-866-330-0014
concierge.panasonic.ca
Para solicitar ayuda (EE.UU./Puerto Rico), llame al:
1-877-95-VIERA (958-4372)
www.panasonic.com/help
Model No.
Número de modelo
TC-P42S60
TC-P50S60
TC-P55S60
TC-P60S60
TC-P65S60
English
Español
Register online at
www.panasonic.com/register
(U.S. customers only)
manual electrónico
Thank you for purchasing this Panasonic product.
Please read these instructions before operating your set and
retain them for future reference. The images shown in this
manual are for illustrative purposes only.
Gracias por su decisión de comprar este producto marca Panasonic.
Lea estas instrucciones antes de utilizar su televisor y guárdelas
para consultarlas en el futuro. Las imágenes mostradas en este
manual tienen solamente fines ilustrativos.
TQB2AA0704-1
This product incorporates the following software:
(1) the software developed independently by or for Panasonic Corporation,
(2) the software owned by third party and licensed to Panasonic Corporation,
(3) the software licensed under the GNU LESSER GENERAL PUBLIC LICENSE Version 2.1 (LGPL V2.1) and/
or,
(4) open sourced software other than the software licensed under the LGPL V2.1.
The software categorized as (3) and (4) are distributed in the hope that it will be useful, but WITHOUT ANY
WARRANTY, without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR
PURPOSE. Please refer to the detailed terms and conditions thereof shown in the "License" menu on this
product.
At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at
the contact information provided below, for a charge no more than our cost of physically performing source
code distribution, a complete machine-readable copy of the corresponding source code covered under LGPL
V2.1 or the other licenses with the obligation to do so, as well as the respective copyright notice thereof.
Contact Information : cdrequest@unipf.jp
The source code and the copyright notice are also available for free in our website below.
http://www.unipf.jp/dl/DTV13U/
“PlayReady” is a trademark registered by Microsoft. Please be aware of the following.
(a) This product contains technology subject to certain intellectual property rights of Microsoft. Use or
distribution of this technology outside of this product is prohibited without the appropriate license(s) from
Microsoft.
(b) Content owners use Microsoft PlayReady™ content access technology to protect their intellectual property,
including copyrighted content. This device uses PlayReady technology to access PlayReady-protected
content and/or WMDRM-protected content. If the device fails to properly enforce restrictions on content usage,
content owners may require Microsoft to revoke the device’s ability to consume PlayReady-protected content.
Revocation should not affect unprotected content or content protected by other content access technologies.
Content owners may require you to upgrade PlayReady to access their content.
If you decline an upgrade, you will not be able to access content that requires the upgrade.
■Do not display a still picture for a long time
This causes the image to remain on the plasma screen (“Image retention”).
This is not considered a malfunction and is not covered by the warranty.
4 : 3
Typical still images
Channel number and other logos
●
Image displayed in 4:3 mode
●
Video game
●
12
To prevent the “Image retention”, the screen
saver is automatically activated after a
few minutes if no signals are sent or no
operations are performed.
■Set up
Do not place the unit where it’s exposed to sunlight or other bright light (including reflections).
●
Use of some types of fluorescent lighting may reduce the remote control’s transmission range.
●
2
VIERA Link™ is a
trademark of Panasonic
Corporation.
HDMI, the HDMI logo and
High-Definition Multimedia
Interface are trademarks
or registered trademarks
of HDMI Licensing LLC in
the United States and other
countries.
DLNA®, the DLNA Logo and
DLNA CERTIFIED™ are
trademarks, service marks,
or certification marks of
the Digital Living Network
Alliance.
Manufactured under license
under U.S. Patent Nos:
5,956,674; 5,974,380;
6,487,535 & other U.S.
and worldwide patents
issued & pending. DTS,
the Symbol, & DTS and
the Symbol together are
registered trademarks &
DTS 2.0+Digital Out is a
trademark of DTS, Inc.
Product includes software.
© DTS, Inc. All Rights
Reserved.
Manufactured under
license from Dolby
Laboratories. Dolby and
the double-D symbol
are trademarks of Dolby
Laboratories.
HDAVI Control™ is a trademark of Panasonic
Corporation.
Contents
Please read before using the unit
Safety Precautions ····································· 4
•
Accessories/Optional Accessories ·············9
•
Connections ·············································13
•
Identifying Controls ··································17
•
First Time Setup ······································· 19
•
Using eHELP (Built-in Manual) ················20
•
Frequently Asked Questions (FAQ) ·········21
•
Care and Cleaning ··································22
•
Specifications ···········································23
•
Limited Warranty
•
(for U.S.A. and Puerto Rico only) ·············25
Customer Services Directory
•
(for U.S.A. and Puerto Rico) ····················26
Limited Warranty (for Canada) ·················27
•
This product is licensed under the AVC patent
portfolio license for the personal and non-commercial
use of a consumer to (i) encode video in compliance
with the AVC Standard (“AVC Video”) and/or (ii)
decode AVC Video that was encoded by a consumer
engaged in a personal and non-commercial activity
and/or was obtained from a video provider licensed
to provide AVC Video. No license is granted or shall
be implied for any other use. Additional information
may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.
3
Safety Precautions
CAUTION
RISK OF ELECTRIC SHOCK
WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.
DO NOT OPEN
The lightning flash with arrowhead
within a triangle is intended to tell the
user that parts inside the product are a
risk of electric shock to persons.
The exclamation point within a
triangle is intended to tell the
user that important operating and
servicing instructions are in the
papers with the appliance.
WARNING:
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
Do not place liquid containers (flower vase, cups, cosmetics, etc.) above the set
(including on shelves above, etc.).
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding type plug has two blades and a
third grounding prong. The wide blade or the
third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete
outlet.
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11) Only use attachments / accessories specified by
the manufacturer.
12) Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart / apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as powersupply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has been
dropped.
15) To prevent electric shock, ensure the grounding
pin on the AC cord power plug is securely
connected.
4
WARNING/CAUTION (TV set)
WARNING
Small parts can present choking hazard if
accidentally swallowed.
Keep small parts away from young children.
Discard unneeded small parts and other objects,
including packaging materials and plastic bags/
sheets to prevent them from being played with
by young children, creating the potential risk of
suffocation.
■Set up
This Plasma TV may fall and can cause personal
injury or even death if not installed correctly. To
prevent personal injury or death, follow these
warnings:
Install the Plasma TV in accordance with
●
the manufacturer’s recommended pedestal
or stand, corresponding hardware and
installation instructions.
This Plasma TV is for use only with the following
optional accessories. Use with any other type
of optional accessories may cause instability.
The following accessories are manufactured by
Panasonic Corporation.
• Wall-hanging bracket (Angled)
TY-WK4P1RW (TC-P42S60, TC-P50S60)
TY-WK5P1RW (TC-P55S60, TC-P60S60)
TY-WK6P1RW (TC-P65S60)
Be sure to ask a qualified technician to carry
●
out the installation and set-up.
Two or more people are required to install or
remove the television.
Some wall mounts (wall-hanging brackets) are
●
not designed to be mounted to walls with steel
studs or old cinder block constructions.
Ask your dealer or licensed contractor to properly
secure the wall-hanging bracket.
Do not route the TV’s power cord inside the
●
wall.
The power cord was not designed for in-wall
mounting.
Doing so can lead to fire hazard.
Do not place the Plasma TV or its stand on a
●
sloped or unstable surface.
The Plasma TV may fall or tip over.
Do not support the Plasma TV on a non-
●
specified pedestal.
Do not place the Plasma TV on furniture that
●
can easily be used as steps, such as a chest of
drawers.
Do not climb or allow children to climb on the
●
Plasma TV
Place or install the Plasma TV where it cannot
●
be pushed, pulled over or knocked down.
Route all cords and cables such that they
●
cannot be tripped over or pulled by curious
children.
Do not place any objects on top of the Plasma
●
TV.
If water spills onto the Plasma TV or foreign
objects get inside it, a short-circuit may occur,
which could result in fire or electric shock. If any
foreign objects get inside the Plasma TV, please
consult an Authorized Service Center.
In the unlikely event that you receive a shock
●
from this product, it is possible that your
household outlet may be wired improperly.
Have an electrician verify that the TV’s outlet is
properly wired. If the symptom persists, have the
TV serviced by a qualified authorized technician.
To prevent the spread of fire, keep
●
candles or other open flames away
from this product at all times
■AC Power Supply Cord
To prevent fire or electric shock:
The Plasma TV is designed to operate on a 120
●
V AC, 60 Hz service. Insert the power cord plug
as far as it will go into the wall socket.
If the plug is not fully inserted, heat may generate,
which could cause a fire.
The included power cord is for use with this
●
unit only.
Do not use any power cord other than that
●
provided with this TV.
Do not handle the power cord plug with wet
●
hands.
Do not do anything that might damage the
●
power supply cord.
When disconnecting the power supply cord,
●
hold the plug, not the cord.
Do not use the power supply cord if the plug or
●
cord is damaged.
Replace the cord or contact your Authorized
Service Center.
Do not use a 3-prong to 2-prong AC plug
●
adapters to connect your TV’s plug to the wall
outlet.
Doing so will defeat the TV plug’s safety feature,
which can lead to a shock hazard. If the wall outlet
does not accommodate a 3-prong plug, have a
qualified electrician replace your outlet and check
the associated wiring.
If water or an object gets inside the Plasma TV,
●
if the Plasma TV is dropped, or if the enclosure
becomes damaged, unplug the power supply
cord immediately.
A short-circuit may occur, which could cause a
fire. Contact an Authorized Service Center for an
evaluation.
■Radio waves
Do not place this TV in any medical institutions
●
or locations with medical devices.
Radio waves from this TV may interfere with the
medical devices and cause accidents due to the
malfunction.
Do not use this TV near any automatic control
●
devices such as automatic doors or fire alarms.
Radio waves from this TV may interfere with the
automatic control devices and cause accidents
due to the malfunction.
Keep this TV away at least 9 inches (22 cm)
●
from the location where a cardiac pacemaker
is implanted.
Radio waves from this TV may interfere with the
operation of the pacemaker.
5
■Handling the power supply cord
Insert the power plug fully into the socket outlet.
●
(If the power plug is loose, it could generate heat
and cause fire.)
Ensure that the power plug is easily
●
accessible.
Ensure the earth pin on the power plug is
●
securely connected to prevent electrical shock.
• An apparatus with CLASS I construction shall
be connected to a power socket outlet with a
protective earthing connection.
Do not touch the power plug with a wet hand.
●
(This may cause electrical shock.)
Do not use any power cord other than that
●
provided with this TV. (This may cause fire or
electrical shock.)
Do not damage the power cord. (A damaged
●
cord may cause fire or electrical shock.)
• Do not move the TV with the cord plugged in the
socket outlet.
• Do not place a heavy object on the cord or place
the cord near a high-temperature object.
• Do not twist the cord, bend it excessively, or
stretch it.
• Do not pull on the cord. Hold onto the power
plug body when disconnecting cord.
• Do not use a damaged power plug or socket
outlet.
If a problem occurs (such as no picture or
●
no sound), or if smoke or an abnormal odor
is detected from the Plasma TV, unplug the
power supply cord immediately.
Continued use of the TV under these conditions
might cause a fire or permanent damage to the TV.
Have the TV evaluated by an Authorized Service
Center. Servicing of the TV by unauthorized
personnel is strongly discouraged due to its high
voltage.
CAUTION
Do not cover the ventilation holes.
●
Doing so may cause the Plasma TV to overheat,
which can cause a fire or damage to the Plasma
TV.
Leave a space of 3 15/16” (10 cm) or more at
●
the top, left and right, and 2 3/4” (7 cm) or more
at the rear.
When using the pedestal, keep the space
●
between the bottom of the TV and the pedestal
or stand surface clear from objects that may
obstruct ventilation.
■When Moving the Plasma TV
Be sure to disconnect all cables before moving
●
the Plasma TV.
Moving the TV with its cables attached might
damage the cables which, in turn, can cause fire
or electric shock.
To prevent an electric shock, disconnect the
●
power plug from the wall outlet as a safety
precaution before carrying out any cleaning.
Transport only in upright position.
●
Transporting the unit with its display panel facing
upright or downward may cause damage to the
internal circuitry.
Using a dry cloth, clean any dust from the
●
power supply cord and plug regularly.
Build-up of dust on the power cord plug can
increase humidity, which might damage the
insulation and cause a fire.
This Plasma TV radiates infrared rays;
therefore, it may affect other infrared
communication equipment. Install your infrared
sensor in a place away from direct or reflected
light from your Plasma TV.
The TV will still consume some power as long as
the power supply cord is connected to the wall
outlet.
Display panel is made of glass. Do not apply
●
strong force or impact to the display panel.
This may cause damage resulting in injury.
The TV is heavy. TV should be handled by 2 or
●
more people. Support as shown to avoid injury
by the TV tipping or falling.
6
FCC and IC STATEMENT
This equipment has been tested and found to comply with the limits for an Other Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the Panasonic Service Center or an experienced radio/TV technician for help.
FCC Caution:
To assure continued compliance, follow the attached installation instructions and use only shielded
interface cables when connecting to peripheral devices. Some recommended user provided interface
cables may require usage of the attached ferrite core kit(s), refer to interface cable connection
instructions for details. Any changes or modifications not expressly approved by Panasonic Corp. of
North America could void the user's authority to operate this device.
FCC and Industry Canada (IC) RF Exposure Warning:
• This TV is provided with one USB port on rear enclosure for exclusive dedicated use for insertion
of the following optional transmitter: Wireless LAN Adapter with FCC ID:H8N-WLU5150/IC
ID:1353A-WLU5150.
• Other transmitters shall not be used, unless specifically recommended when they become
available. Other third-party wireless transmitters have not been RF exposure evaluated for use
with this TV and may not comply with FCC and IC RF exposure requirements.
• The above described transmitter comply with FCC and IC radiation exposure limits set forth for
an uncontrolled environment for mobile use with minimum 8 inches (20 cm) spacing requirement
between transmitters and all person’s body (excluding extremities of hands, wrist and feet) during
wireless modes of operation.
<Only for wireless LAN if capable of transmission in the 5.15 ~ 5.25 GHz frequency band>
This product is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range.
FCC and IC require this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the
potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated
as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause
interference with and/or damage this product.
Responsible Party: Panasonic Corporation of North America
Contact Source: Panasonic Consumer Marketing Company of North America
email:
This device complies with Part 15 of the FCC Rules and all applicable IC RSS standards.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
One Panasonic Way, Secaucus, NJ 07094
1-877-95-VIERA (958-4372)
consumerproducts@panasonic.com
7
CEA CHILD SAFETY NOTICES
WARNING
Flat panel displays are not always supported on
the proper stands or installed according to the
manufacturer’s recommendations. Flat panel
displays that are inappropriately situated on
dressers, bookcases, shelves, desks, speakers,
chests, or carts may fall over and may cause
personal injury or even death.
The consumer electronics industry (of which
Panasonic is a member) is committed to making
home entertainment enjoyable and safe. To prevent
personal injury or death, be sure to follow the
following safety guidelines:
TUNE INTO SAFETY:
• One size does NOT fit all. Follow the
manufacturer’s recommendations for the safe
installation and use of your flat panel display.
• Carefully read and understand all enclosed
instructions for proper use of this product.
• Don’t allow children to climb on or play with
furniture and television sets.
• Don’t place flat panel displays on furniture that
can easily be used as steps, such as a chest of
drawers.
• Remember that children can become excited while
watching a program, especially on “larger than life”
flat panel displays. Care should be taken to install
the display where it cannot be pushed, pulled over,
or knocked down.
• Care should be taken to route all cords and cables
connected to the flat panel display so that they
cannot be pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL
MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
• Use a mount that has been recommended by
the display manufacturer and/or listed by an
independent laboratory (such as UL, CSA, ETL).
• Follow all instructions supplied by the display and
wall mount manufacturers.
• If you have any doubts about your ability to safely
install your flat panel display, contact your retailer
about professional installation.
• Make sure the wall where you are mounting the
display is appropriate. Some wall mounts are not
designed to be mounted to walls with steel studs
or old cinder block construction. If you are unsure,
contact a professional installer.
• A minimum of two people are required for
installation. Flat panel displays can be heavy.
Panasonic recommends that a qualified installer
perform the wall-mount installation. See page 5.
The American Academy of Pediatrics
discourages media viewing for children
younger than two years. For more details, see
www.aap.org.
■About built-in wireless LAN
To use the built-in wireless LAN, using an access point is recommended.
●
To use the built-in wireless LAN in the access point mode, up to 7 devices are connectable. But the
●
transfer rate will vary according to communication environment or connected equipments.
Do not use the built-in wireless LAN to connect to any wireless network (SSID*1) for which you do
●
not have usage rights. Such networks may be listed as a result of searches. However, using them
may be regarded as illegal access.
Check that the Access point supports WPS*2.
●
(If it does not support WPS, the encryption key of the Access point is required when configuring
settings.)
Follow the instructions on the Access point setup screen and configure the appropriate security settings.
●
For more details on setting of Access point, please refer to operating manual for the Access point.
We recommend using 11n (5 GHz) for the wireless system between the built-in wireless LAN and
●
Access point.
Communication is also possible with 11a, 11b, and 11g, but the communication speed may be
slower.
If the wireless system of the Access point is changed, devices that could connect by wireless LAN
●
may no longer be able to connect.
Data transmitted and received over radio waves may be intercepted and monitored.
●
Keep the TV away from the following devices as much as possible:
●
Wireless LAN, microwaves, and other devices that use 2.4 GHz and 5 GHz signals. Otherwise, the
TV failures such as malfunction may occur due to the radio wave interference.
When noises occur due to the static electricity, etc., the TV might stop operating for the protection
●
of the devices. In this case, turn the TV Off with power On / Off switch, then turn it On again.
*1 SSID is a name for identifying a particular wireless network for transmission.
*2 WPS: Wi-Fi Protected Setup
8
Accessories/Optional Accessories
Accessories
Check that all the following items have been included with your TV
Remote Control
N2QAYB000827
Batteries (2)
AA Battery
Assembly (p. 11)
Power cord Pedestal
Ferrite core
(For TC-P42S60/TC-P50S60 only)
for HDMI cable (2)
for USB Keyboard (1)
Owner’s Manual
Quick start guide
Child safety
Product Registration Card (U.S.A.)
Optional Accessories
Please contact your nearest Panasonic dealer to purchase the recommended optional accessories. For
additional details, please refer to the optional accessories installation manual.
Electronic Touch Pen
TY-TP10U
●
This device provides you to paint or play games on the TV screen.
• Available only for specific applications.
• This TV can be paired with up to 2 Touch Pens simultaneously.
(Pairing condition may differ depending on the registration status for each
Bluetooth device.)
• You need to connect the Bluetooth adapter* to this TV.
(*Included with this optional accessory)
Wall-hanging bracket
TY-WK4P1RW (42"/50")
●
TY-WK5P1RW (55"/60")
●
TY-WK6P1RW (65")
●
(image)
Tilting angle for this TV:
•
(for 42"/50"/55"/65")
0 (vertical) to 10 degrees
(for 60")
0 (vertical) to 15 degrees
Back of the TV
a
Holes for wall-hanging
bracket installation
(42"/50")
a: 15.7” (400 mm)
b: 11.8” (300 mm)
(55"/60")
a: 19.7” (500 mm)
b: 11.8” (300 mm)
(65")
a: 26.9” (684 mm)
b: 11.8” (300 mm)
screws for attaching the TV to the wallhanging bracket (not supplied with the TV)
b
(View from the side)
M8
Depth of screw:
(for 42"/50")
Minimum: 0.67 ” (17.0 mm)
Maximum: 1.38 ” (35.0 mm)
(for 55"/60"/65")
Minimum: 0.67 ” (17.0 mm)
Maximum: 1.46” (37.0 mm)
9
Warning
In order to maintain the TV’s performance and safety, be absolutely sure to ask your dealer or a
●
licensed contractor to secure the wall-hanging brackets.
Carefully read the instructions accompanying optional accessories, and be absolutely sure to take
●
steps to prevent the TV from tipping over.
Do not mount the unit directly below ceiling lights (such as spotlights, floodlights or halogen lights)
●
that typically give off high heat. Doing so may be warped or damage plastic cabinet parts.
Handle the TV carefully during installation since subjecting it to impact or other forces may cause
●
product damage.
Take care when fixing wall brackets to the wall. Always ensure that there are no electrical cables or
●
pipes in the wall before hanging the bracket.
When using the angled-type wall-hanging bracket, please ensure that there is sufficient space for the
●
connecting cables not to press against the wall when the TV is tilted forward.
To prevent fall and injury, remove the TV from its fixed wall position when it is no longer in use.
●
10
Loading...
