Operating Instructions
Functional Manual
LCD Projector
Model No.
PT-AR100EH
Thank you for purchasing this Panasonic product.
■ Before operating this product, please read the instructions (Basic Guide / Functional Manual) carefully and
save this manual for future use.
■ Please ensure you read the “Read this rst!” (
pages 6 to 12) carefully prior to use.
ENGLISH
TQBJ0407
2 - ENGLISH
WARNING:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION: To assure continued compliance, use only shielded interface cables when connecting
to computers or peripheral devices. Any unauthorized changes or modications to this
equipment will void the users authority to operate.
ENGLISH - 3
Features of the ProjectorFeatures of the Projector
Harmonization with
Quick StepsQuick Steps
projection environment
See the relevant page for details.
This projector is equipped with
technology to automatically adjust
the image according to the lighting
of the projection environment
(brightness, color).
Improved brightness
A newly developed high luminance
lamp and an optical system have
been introduced to facilitate the joy
of viewing in a bright living room.
Wide range of picture modes
This projector is equipped with an
exclusive mode for enjoying games
and sports content at high image
quality levels.
1. Set up your projector
(
2. Connect the projector to
(
3. Connect the power cord
(
4. Switch on the projector
(
page 20)
other devices
page 25)
page 27)
page 28)
5. Select the input signal
(
6. Adjust the image
(
page 30)
page 30)
4 -
ENGLISH
Important
Information
Introduction Getting Started Basic Operation Settings Maintenance Appendix
Contents
Be sure to read “Read this rst!”. (
pages 6 to 12)
Important Information
Read this rst! .....................................................6
Precautions for use ......................................... 13
Introduction
About your projector ....................................... 17
Cautions when transporting..........................................13
Cautions when installing ...............................................13
Cautions on use ............................................................15
About disposal ...............................................................15
Accessories ...................................................................16
Optional accessories ....................................................16
Remote control .............................................................. 17
Projector body ...............................................................18
Illuminating button lights ............................................... 31
Selecting the picture mode ........................................... 31
Adjusting the picture .....................................................31
Loading a saved setting ................................................ 32
Displaying the [VIERA LINK MENU] menu ................. 32
Displaying the waveform monitor .................................32
Resetting to the default settings ................................... 32
Submenu ....................................................................... 33
Switching the input signal .............................................33
Using the <FUNCTION> button .........................................33
Displaying the [ECO MANAGEMENT] menu..............33
Settings
Menu navigation ............................................... 34
Navigating through the menu .......................................34
Menu list ........................................................................ 35
Getting Started
Setting up .......................................................... 20
Projection method .........................................................20
Parts for ceiling mount (optional) .................................. 20
Projection related ..........................................................21
Front adjustable feet and throwing angle ....................22
Lens shift and positioning .............................................23
Connections ...................................................... 25
Before connecting to the projector ...............................25
Connecting example: COMPONENT IN/
S-VIDEO IN/VIDEO IN ................................................. 25
Connecting example: HDMI IN/COMPUTER IN .........26
Basic Operation
Switching the projector on/off ....................... 27
Power cord ....................................................................27
Power indicator .............................................................27
Switching on the projector ............................................ 28
Switching off the power .................................................29
Projecting an image ......................................... 30
Selecting the input signal ..............................................30
Adjusting the image ...................................................... 30
Remote control operation ............................... 31
[PICTURE] menu .............................................. 37
[PICTURE MODE] ........................................................ 37
[CONTRAST] ................................................................ 37
[BRIGHTNESS] ............................................................37
[COLOUR] .....................................................................37
[TINT] .............................................................................37
[COLOUR TEMPERATURE] .......................................38
[SHARPNESS] .............................................................. 38
[DYNAMIC IRIS] ........................................................... 38
[LIGHT HARMONIZER] ...............................................38
[WAVEFORM MONITOR] ............................................ 39
[SPLIT ADJUST] ...........................................................41
[ADVANCED MENU] .................................................... 42
[PICTURE MEMORY] .................................................. 53
SIGNAL MODE .............................................................54
[POSITION] menu ............................................. 55
[H-POSITION] ...............................................................55
[V-POSITION] ............................................................... 55
[DOT CLOCK] ............................................................... 55
[CLOCK PHASE] ..........................................................55
[ASPECT] ...................................................................... 56
[WSS] ............................................................................58
[OVER SCAN] ...............................................................58
[KEYSTONE] ................................................................58
ENGLISH
- 5
Important
Information
IntroductionGetting StartedBasic OperationSettingsMaintenanceAppendix
Contents
[AUTO SETUP] .............................................................58
[SCREEN AREA MEMORY] ........................................ 59
[OPTION] menu ................................................ 63
[ON-SCREEN DISPLAY] ..............................................63
[BACK COLOUR] .........................................................63
[STARTUP LOGO] ........................................................64
[AUTO SEARCH] .......................................................... 64
[HDMI SIGNAL LEVEL] ................................................ 64
[FRAME RESPONSE] .................................................. 64
[PROJECTION METHOD] ...........................................64
[TRIGGER 1/2 SETTING] ............................................65
[HIGH ALTITUDE MODE] ............................................66
[LAMP POWER] ...........................................................66
[ECO MANAGEMENT] ................................................67
[FUNCTION BUTTON] .................................................68
[VIERA LINK SETTINGS] .............................................68
[OTHER FUNCTIONS] ................................................. 70
Appendix
Using VIERA Link ............................................. 82
Summary of VIERA Link features ................................82
VIERA Link “HDAVI Control” ........................................83
Technical information ...................................... 86
List of compatible signals .............................................86
Serial terminal ...............................................................87
Specications ................................................... 90
Dimensions ...................................................................92
Index ................................................................... 93
[TEST PATTERN] .........................................................70
[LAMP RUNTIME] ........................................................70
Maintenance
TEMP and LAMP Indicators ............................ 71
Managing the indicated problems ................................ 71
Care and replacement ..................................... 73
Before cleaning the projector /
replacing components ..................................................73
Cleaning the projector ................................................... 73
Component replacement .............................................. 75
Troubleshooting ............................................... 80
Ceiling mount bracket safeguards ................ 81
Read this rst!
6 -
ENGLISH
Important
Information
Read this rst!
WARNING: THIS APPARATUS MUST BE EARTHED.
WARNING: To prevent damage which may result in re or shock hazard, do not expose this appliance to rain
Machine Noise Information Ordinance 3. GSGV, January 18, 1991: The sound pressure level at the operator
position is equal or less than 70 dB (A) according to ISO 7779.
WARNING:
1. Remove the plug from the mains socket when this unit is not in use for a prolonged period of time.
2. To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to
3. Do not remove the earthing pin on the mains plug. This apparatus is equipped with a three prong
CAUTION: To assure continued compliance, follow the attached installation instructions, which includes using
or moisture.
qualied service personnel.
earthingtype mains plug. This plug will only t an earthing-type mains socket. This is a safety feature. If you
are unable to insert the plug into the mains socket, contact an electrician. Do not defeat the purpose of the
earthing plug.
the provided power cord and shielded interface cables when connecting to computer or peripheral
device. If you use serial port to connect PC for external control of projector, you must use optional
RS-232C serial interface cable with ferrite core. Any unauthorized changes or modications to
this equipment will void the user’s authority to operate.
Read this rst!
ENGLISH
- 7
Important
Information
13A250V
BS1363/A
HE-8
N
ASA
L
IMPORTANT: THE MOULDED PLUG
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 13 amp fuse
is tted in this plug. Should the fuse need to be replaced, please ensure that the replacement fuse has a rating
of 13 amps and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark
or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is retted when the fuse is replaced. If you
lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover
can be purchased from an Authorised Service Center.
If the tted moulded plug is unsuitable for the mains socket in your home, then the fuse should be
removed and the plug cut off and disposed of safely. There is a danger of severe electrical shock if the
cut off plug is inserted into any 13 amp socket.
If a new plug is to be tted, please observe the wiring code as shown below.
If in any doubt, please consult a qualied electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
Green - and - Yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wire in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows.
The wire which is coloured GREEN - AND - YELLOW must be connected to the terminal in the
plug which is marked with the letter E or by the Earth symbol or coloured GREEN or GREEN AND - YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug which is
marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in the plug which is
marked with the letter L or coloured RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.
Read this rst!
8 -
ENGLISH
Important
Information
WARNING:
The wall outlet or the circuit breaker shall be installed near the equipment and shall be easily
accessible when problems occur. If the following problems occur, cut off the power supply
immediately.
Continued use of the projector in these conditions will result in re or electric shock.
During a thunderstorm, do not touch the projector or the cable.
Electric shocks can result.
Do not do anything that might damage the power cord or the power plug.
If the power cord is used while damaged, electric shocks, short-circuits or re will result.
Completely insert the power plug into the wall outlet and the power connector into the projector
terminal.
If the plug is not inserted correctly, electric shocks or overheating may occur and re will result.
Do not use anything other than the provided power cord.
Failure to observe this will result in electric shocks or re.
Clean the power plug regularly to prevent it from becoming covered in dust.
Failure to observe this will cause a re.
Pull the power plug out from the wall outlet and wipe it with a dry cloth regularly.
Do not handle the power plug and power connector with wet hands.
Failure to observe this will result in electric shocks.
Do not overload the wall outlet.
If the power supply is overloaded (ex., by using too many adapters), overheating may occur and re will result.
POWER
If foreign objects or water get inside the projector, cut off the power supply.
z
If the projector is dropped or the cabinet is broken, cut off the power supply.
z
If you notice smoke, strange smells or noise coming from the projector, cut off the power supply.
z
Please contact an Authorized Service Center for repairs, and do not attempt to repair the projector yourself.
Do not damage the power cord, make any modications to it, place it near any hot objects, bend it
z
excessively, twist it, pull it, place heavy objects on top of it or wrap it into a bundle.
Ask an Authorized Service Center to carry out any repairs to the power cord that might be necessary.
Do not use plugs which are damaged or wall outlets which are coming loose from the wall.
z
If dust builds up on the power plug, the resulting humidity can damage the insulation.
z
If not using the projector for an extended period of time, pull the power plug out from the wall outlet.
z
Read this rst!
ENGLISH
- 9
Important
Information
WARNING:
ON USE/INSTALLATION
Do not place the projector on soft materials such as carpets or sponge mats.
Doing so will cause the projector to overheat, which can cause burns, re or damage to the projector.
Do not set up the projector in humid or dusty places or in places where the projector may come into
contact with oily smoke or steam, ex. a bathroom.
Using the projector under such conditions will result in re, electric shocks or deterioration of components.
Deterioration of components (such as ceiling mount brackets) may cause the projector which is mounted on
the ceiling to fall down.
Do not install this projector in a place which is not strong enough to take the full weight of the
projector or on top of a surface which is sloped or unstable.
Failure to observe this will cause projector to fall down or tip over the projector, and severe injury or damage
could result.
Do not cover the air inlet port or the air outlet port.
Doing so will cause the projector to overheat, which can cause re or damage to the projector.
Do not place the projector in narrow, badly ventilated places such as closets or bookshelves.
z
Do not place the projector on cloth or papers, as these materials could be drawn into the air inlet port.
z
Do not place your hands or other objects close to the air outlet port.
Doing so will cause burns or damage your hands or other objects.
Heated air comes out of the air outlet port. Do not place your hands or face, or objects which cannot
z
withstand heat close to this port.
Do not cover the air intake/exhaust ports or place anything within 100 mm (4") of them.
Doing so will cause the projector to overheat, which can cause re or damage to the projector.
Do not look and place your skin into the lights emitted from the lens while the projector is being used.
Doing so can cause burns or loss of sight.
Strong light is emitted from the projector’s lens. Do not look or place your hands directly into this light.
z
Be especially careful not to let young children look into the lens. In addition, turn off the main power when
z
you are away from the projector.
Never attempt to remodel or disassemble the projector.
High voltages can cause re or electric shocks.
For any inspection, adjustment and repair work, please contact an Authorized Service Center.
z
Do not project an image with the lens cover attached.
Doing so can cause re.
Do not allow metal objects, ammable objects, or liquids to enter inside of the projector. Do not allow
the projector to get wet.
Doing so may cause short circuits or overheating, and result in re, electric shock, or malfunction of the
projector.
Do not place containers of liquid or metal objects near the projector.
z
If liquid enters inside of the projector, consult your dealer.
z
Particular attention must be paid to children.
z
Use the ceiling mount bracket specied by Panasonic.
Defects in the ceiling mount bracket will result in falling accidents.
Attach the supplied safety cable to the ceiling mount bracket to prevent the projector from falling down.
z
Installation work (such as ceiling mount bracket) should only be carried out by a qualied technician.
If installation is not carried out and secured correctly it can cause injury or accidents, such as electric shocks.
Do not use anything other than an authorized ceiling mount bracket.
z
Be sure to use the provided accessory wire with an eye bolt as an extra safety measure to prevent the
z
projector from falling down. (Install in a different location to the ceiling mount bracket)
Read this rst!
10 -
ENGLISH
Important
Information
WARNING:
Do not use or handle the batteries improperly, and refer to the following.
Failure to observe this will cause burns, batteries to leak, overheat, explode or catch re.
If the battery uid leaks, do not touch it with bare hands, and take the following measures if necessary.
Do not disassemble the lamp unit.
If the lamp breaks, it could cause injury.
Lamp replacement
The lamp has high internal pressure. If improperly handled, an explosion and severe injury or accidents will
result.
Do not allow infants or pets to touch the remote control.
Do not use the supplied power cord with devices other than this projector.
Remove the depleted batteries from the remote control promptly.
ACCESSORIES
Do not use unspecied batteries.
z
Do not disassemble dry cell batteries.
z
Do not heat the batteries or place them into water or re.
z
Do not allow the + and - terminals of the batteries to come into contact with metallic objects such as
z
necklaces or hairpins.
Do not store batteries together with metallic objects.
z
Store the batteries in a plastic bag and keep them away from metallic objects.
z
Make sure the polarities (+ and -) are correct when inserting the batteries.
z
Do not use a new battery together with an old battery or mix different types of batteries.
z
Do not use batteries with the outer cover peeling away or removed.
z
Battery uid on your skin or clothing could result in skin inammation or injury.
z
Rinse with clean water and seek medical advice immediately.
Battery uid coming in contact with your eyes could result in loss of sight.
z
In this case, do not rub your eyes. Rinse with clean water and seek medical advice immediately.
The lamp can easily explode if struck against hard objects or dropped.
z
Before replacing the lamp, be sure to disconnect the power plug from the wall outlet.
z
Electric shocks or explosions can result if this is not done.
When replacing the lamp, turn the power off and allow the lamp to cool for at least one hour before
z
handling it otherwise it can cause burns.
Keep the remote control out of the reach of infants and pets after using it.
z
Using the supplied power cord with devices other than this projector may cause short circuits or
z
overheating, and result in electric shock or re.
Leaving them in the unit may result in uid leakage, overheating, or explosion of the batteries.
z
Read this rst!
ENGLISH
- 11
Important
Information
CAUTION:
POWER
When disconnecting the power cord, be sure to hold the power plug and power connector.
If the power cord itself is pulled, the lead will become damaged, and re, short-circuits or serious electric
shocks will result.
When not using the projector for an extended period of time, disconnect the power plug from the wall
outlet and remove the batteries from the remote control.
Failure to do so may result in re or electric shock.
Disconnect the power plug from the wall outlet before carrying out any cleaning and replacing the unit.
Failure to do so may result in electric shock.
ON USE/INSTALLATION
Do not place heavy objects on top of the projector.
Failure to observe this will cause the projector to become unbalanced and fall, which could result in damage or
injury. The projector will be damaged or deformed.
Do not put your weight on this projector.
You could fall or the projector could break, and injury will result.
Be especially careful not to let young children stand or sit on the projector.
z
Do not place the projector in extremely hot locations.
Doing so will cause the outer casing or internal components to deteriorate, or result in re.
Take particular care in locations exposed to direct sunlight or near stoves.
z
Always disconnect all cables before moving the projector.
Moving the projector with cables still attached can damage the cables, which will cause re or electric shocks
to occur.
ACCESSORIES
Do not use the old lamp unit.
If used it could cause lamp explosion.
If the lamp has broken, ventilate the room immediately. Do not touch or bring your face close to the
broken pieces.
Failure to observe this will cause the user to absorb the gas which was released when the lamp broke and
which contains nearly the same amount of mercury as uorescent lamps, and the broken pieces will cause
injury.
If you believe that you have absorbed the gas or that the gas has got into your eyes or mouth, seek
z
medical advice immediately.
Ask your dealer about replacing the lamp unit and check the inside of the projector.
z
Read this rst!
12 -
ENGLISH
Important
Information
end of Read this rst
To remove the battery
Remote Control Battery
1. Press the guide and lift the cover.
2. Remove the batteries.
Trademarks
VGA and XGA are trademarks of International Business Machines Corporation.•
SVGA is a registered trademark of the Video Electronics Standards Association.•
HDMI, the HDMI logo and High-Denition Multimedia Interface is a trademark or registered trademark of HDMI Licensing •
LLC.
The font used in the on-screen displays is a Ricoh bitmap font, which is manufactured and sold by Ricoh Company, Ltd.•
Other names, company names or product names used in these operating instructions are the trademarks or registered •
trademarks of their respective holders.
Please note that the operating instructions do not include the ® and TM symbols.
Illustrations in these operating instructions
Note that illustrations of the projector may differ from the ones you actually see. •
Page references
Term
In these instructions, references to pages are indicated as: (•
In these instructions, the “Wireless remote control unit” accessory is referred to as the “Remote control”.•
page 00).
Precautions for use
ENGLISH
- 13
Important
Information
Precautions for use
Be sure to use the projector after removing the packaging material, such as
■
the fastening tapes and protective sheet.
Take proper care when disposing of the removed packaging material.
Cautions when transporting
Ensure that the supplied lens cover is attached when transporting.
z
Hold the bottom of the projector when transporting.
z
Do not transport with the front adjustable feet extended. Doing so may result in damage to the front adjustable feet.
z
Cautions when installing
Do not set up the projector outdoors.
■
The projector is designed for indoor use only.
Do not use under the following conditions.
■
Places where vibration and impacts occur such as in a car or vehicle: Doing so may damage the internal parts
z
and result in malfunctions.
Near the exhaust of an air conditioner: Depending on the conditions of use, the screen may uctuate due to the hot
z
air from the air exhaust port or the heated or cooled air from the air conditioner. Take care so that the exhaust from the
projector or other equipment, or the air from the air conditioner does not blow toward the front of the projector.
Near lights (studio lamps, etc.) where temperature changes greatly (See “Operating environment”
z
Doing so may shorten the life of the lamp or result in deformation of the outer case and malfunctions.
Near high-voltage power lines or near motors: Doing so may interfere with the operation of the projector.
z
About lens focus
■
The focus of high brightness projection lenses may not be stable immediately after turning power on due to the
effects of heat from light coming from light sources. Adjust lens focus 30 minutes after starting to project a video.
page 90):
Make sure to set [HIGH ALTITUDE MODE] to [ON] when using the projector
■
at elevations of 1 400 m (4 593 ft) or higher and lower than 2 700 m (8 858 ft)
above sea level.
Failure to do so may shorten the life of the internal parts and result in malfunctions.
Make sure to set [HIGH ALTITUDE MODE] to [OFF] when using the projector
■
at elevations lower than 1 400 m (4 593 ft) above sea level.
Failure to do so may shorten the life of the internal parts and result in malfunctions.
Do not install the projector at elevations of 2 700 m (8 858 ft) or higher above
■
sea level.
Failure to do so may shorten the life of the internal parts and result in malfunctions.
Do not tilt the projector or place it on its side.
■
Do not tilt the projector body more than approximately ±30 ° vertically or ±10 °
horizontally. Overtilting may result in shortening the component’s lifespan.
Do not cover the air intake/exhaust ports or place anything within 100 mm (4
■
+30°
-30°
of them.
")
Be sure to consult a specialized technician or your dealer when installing the
■
product on a ceiling.
An optional ceiling mount bracket is required.
Model No.: ET-PKA110H (for high ceilings), ET-PKA110S (for low ceilings)
Precautions for use
14 -
ENGLISH
Important
Information
Adjustable feet
z
z
z
z
■Installation precautions
Do not stack projectors.
Do not cover the projector’s air intake port or air exhaust port.
Install the projector so that cold air or hot air from air conditioners does not come in to direct contact with the air intake port
or air exhaust port.
100 mm (4") or more
Air exhaust port
zDo not install the projector in an enclosed space.
If the projector needs to be installed in an enclosure, provide a separate air conditioning unit or ventilating equipment.
Emitted heat accumulates if ventilation is insufcient. This may cause the protection circuit of the projector to operate.
Use the front adjustable feet for oor installation only and for angle adjustment in such cases.
If you use the adjustable feet for any other purpose, the set may be damaged.
100 mm (4") or more 100 mm (4") or more
Air intake port
Air intake port
Precautions for use
ENGLISH
- 15
Important
Information
Cautions on use
In order to view clear video images
■
Clear, high contrast video can be viewed when curtains are closed and lights near the screen are extinguished in
z
order to stop light from reaching the screen.
In some rare cases, depending on the usage environment a “ickering” may appear on the screen due to the
z
effects of air from the exhaust port or hot/cold air from air conditioners. Do not set up this projector in a situation
where air from the exhaust of this device or other devices, or air from air conditioners is circulated to the front of
this device.
The focus of high brightness projection lenses may not be stable immediately after turning power on due to the
z
effects of heat from light coming from light sources. Focus stabilizes 30 minutes after video projection starts.
Do not touch the surface of the projection lens with bare hands.
■
If ngerprints or dirt are left on the projection lens, they will be enlarged and projected and will prevent the
viewing of clear video images. Also, always replace the lens cover when not using the projector.
About LCD panels
■
LCD panels are manufactured using high precision technologies, but in some cases they may have dead
pixels, or permanently lit pixels. Please understand that this is not a fault.
Also, projecting a still image for extended periods of time may lead to afterimages on LCD panels. Please be
aware that in some cases these afterimages may not disappear completely.
About optical components
■
If using in an environment with a high temperature, or where dust or tobacco smoke is present, the
replacement cycle of optical components such as LCD panels and polarizing plates may shorten even after
less than one year of use. For more details, please contact your dealer.
About the lamp
■
This product uses an internal high pressure mercury lamp for the light source.
High pressure mercury lamps have the following characteristics.
Brightness decreases with usage time.
z
In some cases, the lamp may make a large sound, crack, and reach the end of its lifespan as a result of shocks,
z
damage, and deterioration related to usage period.
Large disparities occur in lifespan due to individual properties and usage conditions. Lifespan is especially
z
affected if you use the lamp continuously for more than 6 hours or switch it ON/OFF rapidly.
Very occasionally the lamp may crack after starting projection.
z
The possibility of cracking increases as the lamp nears the end of its lifespan.
z
If the lamp cracks, gas may be leaked from inside and smoke may be seen.
z
Please prepare a spare lamp in advance.
z
About disposal
To dispose of the product, inquire your local authorities or dealer for correct methods of disposal.
The lamp contains mercury. When disposing of used lamp units, contact your local authorities or dealer for correct
methods of disposal.
Precautions for use
ロリヨラヵ
ヸモヷユョヰンヮ
ヮヰワリヵヰン
ヷリユンモ
ロㄊㄏㄌ
ヴヶャ
ヮユワヶ
ユワヵユン
ョヶワヤヵリヰワ
リワヱヶヵヴユロユヤヵ
モュルヶヴヵヮユワヵ
ヱリヤヵヶンユ
ヮ
ヰュユ
ヱリヤヵヶンユ
ヮユヮヰンヺ
ロヰモ
ユヤヰ
ュ
ヮ
ユ
ワ
ヶ
ュ
ユ
ョ
モ
ヶ
ロ
ヵ
ヱンヰルユヤヵヰン
ャモヤレバ
ンユヵヶンワヰヱヵリヰワ
ヱンヰルユヤヵヰン
ャモヤレバ
ンユヵヶンワヰヱヵリヰワ
Information
Important
Accessories
Please conrm that the items displayed below are included.
Wireless remote control unit: 1
(N2QAYB000681)
Lens cover: 1
(TEEC5524)
(Attached to the projector by
default.)
AA/R6 battery: 2
(For remote control unit)
Power cord: 1
(TXFSX01RXRZ)
CD-ROM: 1
(TXFQB02RWEZ)
Attention
Dispose of the packaging appropriately after removing from the product.
z
Contact an Authorized Service Center if you lose any of the included items.
z
The model number of accessories and optional accessories may be changed without prior notication.
z
Store small parts out of reach of infants.
z
Store the lens cover properly.
z
The lens cover protects the projection lens from dust and dirt.
Attach the lens cover when not using the device.
Optional accessories
Optional accessories
(product names)
Ceiling mount bracket ET-PKA110H (for high ceilings), ET-PKA110S (for low ceilings)
Replacement lamp unit ET-LAA110
Model No.
16 -
ENGLISH
About your projector
Remote control
Top
■
Remote control signal transmitter
Send remote control signal.
Point at the remote control receiver part on the
projector when using.
Front
■
With the <MAIN POWER> switch of the
projector turned <ON>, switch between
the standby mode and projection mode.
Cycle through the
[PICTURE MODE].
About your projector
Switch the remote control
button lights off or on.
Display the [PICTURE] menu or
[ADVANCED MENU] menu.
Display the [MEMORY
LOAD] menu.
Introduction
Display the [VIERA LINK
MENU] menu.
Display the menu screen.
Display menus of external
devices when using
VIERA Link.
Alter the points during a
gamma adjustment.
Switch the input signals.
Attention
Do not drop the remote control.
z
Avoid contact with liquids or moisture.
z
Do not attempt to disassemble or modify the remote control.
z
Display the input waveform.
Display the [ECO MANAGEMENT]
Reset adjusted menu values
to the default settings.
Use for menu screen
Allocate frequently used operations
and use as a shortcut button.
Inserting and removing the remote control batteries
Open the cover.
Insert the batteries and
replace the cover (insert
from
side).
● Follow the reverse
procedure to remove the
batteries.
menu.
operation.
Note
Pressing buttons on the remote control when button lights is set to on illuminates the button lights.
z
Button lights dim if no actions are carried out after approximately 5 seconds, and then extinguish if no actions are carried
out after a further 5 seconds.
When pointed directly at the receiver on the front of the projector, the remote control can be used up to a distance of
z
approximately 7 meters. It may also be used at a vertical/horizontal angle of up to ±30 degrees.
The remote control may not operate correctly if there is an obstacle between it and the receiver on the projector.
z
Signals from the remote control can be reected off a screen when using the projector, but limitations to the range of
operability may occur due to reected light loss resulting from the properties of the screen.
The remote control may not be usable if the receiver is exposed to uorescent or other strong lights. As far as is possible,
z
keep the remote control away from light sources.
ENGLISH
- 17
About your projector
18 -
ENGLISH
Introduction
Projector body
Top and front view
■
Temperature indicator
Lamp indicator
Power indicator
Air exhaust port
Color sensor window
Remote control signal receiver
Projection lens
Attention
Do not place your hands or objects close to the exhaust port.
z
- Do not place hands or face near.
- Do not place near objects that are intolerant to heat.
- Inserting ngers may result in injury.
Hot air is expelled from the exhaust port and can cause burns,
injuries, and deformation
Focus ring
Adjusts the focus.
Zoom ring
Adjusts the zoom.
Air intake port /
Air lter cover
Control panel
Lens shift lever
Lens shift cover
When the lens shift
.
cover is closed
Attention
Ensure that there are no build ups of dirt on the air intake and exhaust ports.
z
Control panel
■
Power button
With the <MAIN POWER>
switch of the projector turned
<ON>, switch between the
standby mode and projection
mode.
Opening the lens shift
cover
Press the cover and
slide.
Switch input
Use for menu screen
operation
About your projector
ENGLISH
- 19
Introduction
ヤヰヮヱヶヵユンチチリワ
ヴユンリモロ
ヴノヷリュユヰチリワ
ヵンリヨヨユン
リワチヒ リワチビ
ヒ
ビ
ヤヰヮヱヰワユワヵ
リワ
ヷリュユヰチリワ
■
Back and bottom view
Security slot
The security slot is compatible with the
Kensington MicroSaver Security System.
Air intake port
Connecting
terminals
AC IN
Connect the
power cord
included.
Connecting terminals
■
HDMI IN
Connect HDMI
signal cables.
COMPUTER IN
Terminal for RGB signal or YCBCR/
signal input from a computer.
YP
BPR
Main power
Switch the projector on/off.
Front adjustable
feet
Screw up/down to
adjust the projection
angle.
S-VIDEO IN/VIDEO IN
Terminal for inputting
S-VIDEO/VIDEO signal.
TRIGGER
Trigger terminal for connecting
and controlling the projector and
external devices.
SERIAL
Terminal for controlling the
projector using a computer.
COMPONENT IN
Connect a color component
signal cable. (YC
BCR
/YPBPR)
Setting up
20 -
ENGLISH
Getting Started
Setting up
Projection method
You can use any of the following 4 projection methods. Select a projection method suitable for the position of the
projector.
For projection method settings, see [PROJECTION METHOD] in the [OPTION] menu. (
page 64)
Setting on a desk/oor and projecting
■
from front
[PROJECTION
METHOD]
Mounting on the ceiling and projecting
■
from front
Menu Method
[FRONT/DESK]
Setting on a desk/oor and
■
projecting from rear
(using a translucent screen)
Menu Method
[PROJECTION
METHOD]
Mounting on the ceiling and
■
[REAR/DESK]
projecting from rear
(with a translucent screen)
Menu Method
[PROJECTION
METHOD]
[FRONT/CEILING]
Menu Method
[PROJECTION
METHOD]
[REAR/CEILING]
Parts for ceiling mount (optional)
You can install the projector on the ceiling using the optional ceiling mount bracket (model no.: ET-PKA110H (for
high ceilings) and ET-PKA110S (for low ceilings)).
Use only the ceiling mount brackets specied for this projector.
z
Refer to the installation manual for the ceiling mount bracket when you install the bracket and the projector.
z
Attention
To ensure projector performance and security, installation of the ceiling mount bracket must be carried by your
dealer or a qualied technician.
Setting up
ENGLISH
- 21
Getting Started
Projection related
Install the projector with reference to the gure below and the projection distance. You can adjust the display size
and display position according to the screen size and screen position.
Projection screen
L (LW - LT)
Screen
1
*
Projection distance (m)
Screen
SH Screen height (m)
SW Screen width (m)
H Distance from the center of the lens to the image lower end (m)
SD Screen diagonal size (m)
LW: Minimum projection distance *1
LT: Maximum projection distance
(All measurements below are approximate and may differ slightly from the actual measurements.)
Projection screen size 16:9 size
Screen Diagonal (SD)
1.02 m (40") 1.11 m (3' 8") 2.29 m (7' 6") -0.08 to 0.58 m
1.27 m (50") 1.41 m (4' 8") 2.87 m (9' 5") -0.09 to 0.71 m
1.52 m (60") 1.70 m (5' 7") 3.46 m (11' 4") -0.11 to 0.86 m
1.78 m (70") 1.99 m (6' 6") 4.04 m (13' 3") -0.13 to 1.00 m
2.03 m (80") 2.28 m (7' 6") 4.62 m (15' 2") -0.15 to 1.15 m
2.29 m (90") 2.57 m (8' 5") 5.21 m (17' 1") -0.17 to 1.29 m
2.54 m (100") 2.87 m (9' 5") 5.79 m (19' 0") -0.19 to 1.44 m
3.05 m (120") 3.45 m (11' 4") 6.96 m (22' 10") -0.22 to 1.71 m
3.81 m (150") 4.33 m (14' 2") 8.70 m (28' 7") -0.28 to 2.15 m
5.08 m (200") 5.79 m (19' 0") 11.62 m (38' 1") -0.37 to 2.86 m
6.35 m (250") 7.25 m (23' 9") 14.53 m (47' 8") -0.47 to 3.58 m
7.62 m (300") 8.71 m (28' 7") 17.45 m (57' 3") -0.56 to 4.30 m
Minimum distance
(LW)
Maximum distance
(LT)
Height position
(H)
Projection screen size 2.35:1 size
Screen Diagonal (SD)
1.02 m (40") 1.18 m (3' 10") 2.43 m (8' 0") -0.13 to 0.53 m
1.27 m (50") 1.49 m (4' 11") 3.04 m (10' 0") -0.15 to 0.65 m
1.52 m (60") 1.80 m (5' 11") 3.66 m (12' 0") -0.19 to 0.79 m
1.78 m (70") 2.11 m (6' 11") 4.27 m (14' 0") -0.22 to 0.92 m
2.03 m (80") 2.42 m (7' 11") 4.89 m (16' 1") -0.25 to 1.05 m
2.29 m (90") 2.73 m (8' 11") 5.51 m (18' 1") -0.28 to 1.18 m
2.54 m (100") 3.04 m (10' 0") 6.12 m (20' 1") -0.32 to 1.31 m
3.05 m (120") 3.66 m (12' 0") 7.35 m (24' 1") -0.37 to 1.56 m
3.81 m (150") 4.58 m (15' 0") 9.20 m (30' 2") -0.47 to 1.96 m
5.08 m (200") 6.13 m (20' 1") 12.28 m (40' 3") -0.62 to 2.61 m
6.35 m (250") 7.67 m (25' 2") 15.36 m (50' 5") -0.78 to 3.27 m
7.62 m (300") 9.22 m (30' 3") 18.44 m (60' 6") -0.94 to 3.92 m
Minimum distance
(LW)
Maximum distance
(LT)
Height position
(H)
Setting up
22 -
ENGLISH
Getting Started
You can calculate projection dimensions other than those in the above table from the projection screen size SD (m)
using the formula below.
All units are meters. (Values obtained using the formula below contain a slight error.)
If the projection screen size is assumed to be SD,
Projection screen height (SH) = SD (m) × 0.490 = SD (m) × 0.392
Projection screen width (SW) = SD (m) × 0.872 = SD (m) × 0.920
Minimum distance (LW) = SD (m) × 1.1503 − 0.056 = SD (m) × 1.2169 − 0.054
Maximum distance (LT) = SD (m) × 2.2951 − 0.041 = SD (m) × 2.4248 − 0.037
Front adjustable feet and throwing angle
Install the projector on a at surface with its front side become parallel to the screen surface so that the screen
becomes rectangle.
If the screen is tilted towards the bottom, extend the adjustable feet to make a rectangle screen. If the projector is
tilted horizontally, use the adjustable feet to level the projector.
As shown in the diagram, the feet can be extended by turning the front adjustable feet, and can be retracted by
turning in the opposite direction.
16:9 size 2.35:1 size
Attention
Hot air is expelled from the air exhaust port. Do not touch the air exhaust port (
z
front leg adjustable feet.
Note
Tighten the front adjustable feet until you hear them click into place.
z
page 18) directly when you adjust the
Setting up
ENGLISH
- 23
Getting Started
Lens shift and positioning
If the projector is not positioned right in front of the center of the screen, you can adjust the projected image
position by moving the lens shift dials within the shift range of the lens.
Adjusting the lens shift
■
Remove the lens shift cover.1)
See “About your projector” (
z
open the lens shift cover.
2) Rotate the lens shift lever in the direction shown
in the gure (counterclockwise) to release the lock.
Adjust projection using the lens shift lever.3)
Horizontal shift
●
Adjust the projection by moving the lens shift lever horizontally according to the installation position of the
screen and projector.
Up to approximately
26% of the
projection screen
Up to approximately
projection screen
page 18) regarding how to
26% of the
Screen
Move the lens shift
●
lever in direction A
Vertical shift
Move the lens shift
lever in direction B
Adjust by moving the lens shift lever vertically according to the installation position of the screen and
projector.
Move the lens shift
lever in direction D
Up to
approximately
65% of the
projection
screen
Screen
Up to
approximately
65% of the
projection
screen
Attention
Do not force the lens shift lever. If excessive force is placed on the lever, it may break.
z
Rotate the lens shift lever clockwise to x.4)
Attach the lens shift cover.5)
Move the lens shift
lever in direction C
Setting up
24 -
ENGLISH
Getting Started
Projector location range
■
The setting position can be adjusted within the following range.
See “Projection related” regarding adjustment of the projection screen height (SH) and width (SW). (
●
page 21)
Projector setting range when the screen position is xed
Projector
Projector setting range
(center of lens)
Vertical center of screen
Screen
Shift range of the projection screen when the projector position is xed
●
Projection position with no lens shift
Projector
Shift direction Maximum range of adjustment
Center of lens
Shift range for
projection screen
Horizontal (H) Approximately 26% of the projection screen width (SW)
Vertical (V) Approximately 65% of the projection screen height (SH)
Note
Position the projector directly in front of the screen and move the lens shift lever to the center to obtain the optimum
z
projection image quality.
When the lens shift lever is at the horizontal limit of the shift range, you cannot move the lever to the vertical limit. Likewise,
z
when the lens shift lever is at the vertical limit of the shift range, you cannot move the lever to the horizontal limit.
Shift the lens position within the adjustment range. If you shift the lens position outside the adjustment range, a restriction is
z
imposed on the lens movement to protect the optical components and the focus changes.
If the projected image cannot be t into the screen using the lens shift function alone, adjust the projection angle using the
z
adjustable feet (
(
page 58)
page 22), and then correct the keystone distortion using the [KEYSTONE] in the [POSITION] menu.
Connections
ENGLISH
- 25
Getting Started
Connections
ヤヰヮヱヶヵユンチチリワ
ヴユンリモロ
ヴノヷリュユヰチリワ
ヵンリヨヨユン
リワチヒ リワチビ
ヒ
ビ
ヤヰヮヱヰワユワヵ
リワ
ヷリュユヰチリワ
ヤヰヮヱヶヵユンチチリ
ワ
ヴユンリモ
ロ
リワチヒ
リワチビ
ヵンリヨヨユン
ヒ
ビ
Before connecting to the projector
Read and follow the operating and connecting instructions of each peripheral device.
z
The peripheral devices must be turned off.
z
If not provided or sold separately with each peripheral device, obtain the connection cables required for system connection
z
in accordance with the device to be connected.
If the video signal from the video source contains a lot of jitter, the image may appear to be wobble. In such cases, a time
z
base corrector (TBC) must be connected.
The signals that can be connected to the projector include VIDEO, S-VIDEO, analog-RGB (with TTL sync. level) and digital
z
signal.
Some computer models are not compatible with the projector.
z
See “List of compatible signals” for the types of video signals that can be used with this projector. (
z
Audio cables must be connected from each external device directly to the audio reproduction system.
z
page 86)
Caution
When connecting to a computer or other equipment, use the power cord included with each device and a
sealed, commercially available cable.
Connecting example: COMPONENT IN/S-VIDEO IN/VIDEO IN
To COMPONENT
video output
To VIDEO
output
To S-VIDEO
output
DVD player Video player DVD player
Connections
ヤヰヮヱヶヵユンチチリワ
ヴユンリモロ
ヴノヷリュユヰチリワ
ヵンリヨヨユン
リワチヒ リワチビ
ヒ
ビ
ヤヰヮヱヰワユワヵ
リワ
ヷリュユヰチリワ
ヴ
ユンリモ
ロ
ヴ
ヷ
リュユヰチリワ
ヵンリヨヨユン
ヒ
ビ
ヤヰヮヱヰワユワヵ
リワ
ヷリュユヰチリ
ワ
Connecting example: HDMI IN/COMPUTER IN
Getting Started
Note
Use an HDMI High Speed cable that conforms to HDMI standards. If a cable that does not meet HDMI standards is used,
z
video may be interrupted or may not be displayed.
It is possible to connect with DVI devices via an HDMI/DVI conversion adapter, but some devices may not project the
z
image properly or other such problems could be encountered.
When connecting to a serial terminal, see “Serial terminal”. (
z
If you use a computer that has a resume function (last memory), you may have to reset the function so that it operates.
z
HDMI cable
(commercially available)
(commercially available)
To RGB output
To HDMI output
Computer cable
Blu-ray player
page 87)
Computer
26 -
ENGLISH
Switching the projector on/off
Switching the projector on/off
Power cord
Use the power cord included to prevent removal of the power cord and make sure it is fully inserted into
the projector.
Make sure the <MAIN POWER> switch is on the <OFF> side before connecting the power cord.
Use the power cord included and ensure that it is fully inserted.
For power cord handling details, see “Read this rst!”. (
pages 6 to 12)
Connecting
■
Fully insert until the tabs on the left
and right make a click sound.
Disconnecting
■
Pull out while pushing on the tabs on
the sides.
Power indicator
The power indicator indicates the power status.
Check the status of the power indicator <ON (G) / STANDBY (R)>
before operating the projector.
Indicator status Status
No illumination or ashing Main power is switched off.
Power is switched off. (Standby mode.)
Lit
Red
Flashing
Press the power < / | > button to start projection.
* Does not operate when the lamp indicator or temperature indicator is ashing.
Power is switched off (standby mode) and the [POWER ON LINK] is set to
[ON] in the VIERA Link settings.
For details about [POWER ON LINK], see [POWER ON LINK] (
Power indicator
page 69).
Basic Operation
Green
Orange
Flashing
Lit Projecting.
Lit
Flashing
The projector is preparing to project.
Projection starts after a brief pause.
Preparing to switch off the power.
The power is switched off after a while. (Changes to the standby mode.)
The
mode. Preparing to project. Projection starts after a brief pause.
power < / | >
button is switched on again in the power off preparation
ENGLISH
- 27
Switching the projector on/off
28 -
ENGLISH
Basic Operation
Attention
The internal fan operates and cools the projector while it is preparing to power off (when the power indicator is illuminated
z
orange). Do not switch the main power off or remove the power cord.
Note
When the power <
z
to enter projection mode.
The projector consumes approx. 0.08 W of electrical power even when the power is off (when the power indicator is
z
illuminated red).
Power consumption when the power indicator ashes red is almost the same as when the lamp is illuminated red.
z
/ | > button is pressed while the projector is in the power off preparation mode, it may take some time
Switching on the projector
Check external device connections before switching the projector on.
Power indicator
Connect the power cord to the projector.1)
Connect the power plug to an outlet.2)
Press the <ON> side of the <MAIN 3)
POWER> switch to turn on the power.
The power indicator illuminates or ashes red.
z
Remove the lens cover.4)
Be sure to remove the lens cover before starting
z
projection.
Press the power 5) < /
The power indicator illuminates green after ashing
z
for a while and projection starts.
4)
|
> button.
3)
5)
Attention
Using the projector while the lens cover is attached
z
causes the device to heat up and can result in a re.
Note
When starting up the projector, a small rattling sound
z
may be heard or when the luminous lamp is lit a tinkling
sound may be heard, but this is not a malfunction.
During video projection, the cooling fan operates and
z
makes a sound. This fan sound may change with
ambient temperature and becomes louder when the lamp
is turned on.
Setting the [LAMP POWER] in the [OPTION] menu to
z
[ECO] reduces operation sounds. (
When the lamp is turned off and immediately turned back
z
on again, the video may temporarily icker slightly at the
start of projection due to lamp characteristics. This is not
a malfunction.
page 66)
Switching the projector on/off
ENGLISH
- 29
Basic Operation
Switching off the power
Carefully check the status of the power indicator before operating.
Power indicator
Press the power <1) / | > button.
The conrmation message is displayed.
z
Select [OK] with the 2)
buttons.
▲
▼
Press the <ENTER> button (or press the 3)
power <
The lamp extinguishes and video projection halts.
z
The cooling fan continues to operate and the power
z
indicator illuminates orange. Wait for the power
indicator to turn red or start ashing red.
/ | > button again).
4)
1) - 3)
Press the <OFF> side of the <MAIN 4)
POWER> switch to turn off the power.
Never switch off the main power or remove the
z
power cord when the cooling fan is operating.
Note
Select [CANCEL] or press the <MENU> or <RETURN>
z
button to close the power off conrmation message.
The power can also be switched off when the power <
z
button is held down for 0.5 seconds or more.
/ | >
Projecting an image
30 -
ENGLISH
Basic Operation
Projecting an image
Check the connections of the external devices
(
page 25) and the connection of the power cord
(
page 27), and switch on the power (
to start projecting. Select the video for projection, and
adjust appearance of the projected image.
Selecting the input signal
Switch on the external devices.1)
Press the play button on an external device, such
z
as a Blu-ray player. When [AUTO SEARCH] in the
[OPTION] menu is [ON], the projector automatically
searches for an input signal and starts projection.
(
Switch the video input.2)
The video selected with the <INPUT SELECT>
z
button is projected. (
Attention
The video may not be displayed properly depending on
z
the external device or the DVD being played back. In
such cases, set [TV-SYSTEM], [RGB/YC
YP
BPR
Check the projection screen and video aspect ratio, and
z
select the most appropriate aspect ratio with [ASPECT]
in the [POSITION] menu. (
page 28),
page 64)
page 33)
] or [RGB/
BCR
] of the [ADVANCED MENU]. ( page 52)
page 56)
Rotate the lens shift lever in a 3)
counterclockwise direction to disengage
the shift lever lock.
Adjust the lens shift.4)
Adjust the projection position with the shift lever.
z
Adjusting the image
Adjust the angle of the projector.1)
Place the projector parallel to the screen, and
z
then install it on a at surface so that the screen
becomes rectangle.
If the screen is tilted lower than the screen, extend
z
the adjustable feet to make a rectangle screen.
For details, see “Front adjustable feet and throwing
z
angle”. (
Remove the lens shift cover.2)
For details, see “Opening the lens shift cover”.
z
(
page 18)
page 22)
See “Lens shift and positioning”. (
z
page 23)
Rotate the shift lever clockwise to x.5)
Attach the lens shift cover.6)
Adjusting the zoom and focus.7)
Turn zoom ring and focus ring to adjust.
z
Focus ring
Zoom ring
Note
Panasonic recommends that focus adjustment be made
z
after 30 minutes or more have elapsed since picture
display.
As the projection size changes if the focus ring is turned,
z
turn the zoom ring to ne tune the projection size again.
Remote control operation
ENGLISH
- 31
Basic Operation
Remote control operation
You can operate the projector with the remote control
within a range of 7 m (23').
Operating by pointing at the projector
z
Ensure the remote control transmitter is facing the remote
control signal receiver on the front of the projector during
use.
Facing to the screen
z
Ensure the remote control transmitter is facing the screen
and press the required buttons to operate the projector.
The signal will be reected off the screen. The operating
range may differ due to the screen material. This function
may not be effective with a translucent screen.
Note
Do not let strong light shine onto the signal receiver. The
z
remote control may malfunction under strong light such
as uorescent light.
If there are any obstacles between the remote control
z
and the remote control signal receiver, the remote control
may not operate correctly.
Illuminating button lights
You can illuminate the button lights on the remote
control.
Press
Press the <LIGHT> button again to extinguish the
button lights.
Note
Button lights dim if no actions are carried out for
z
approximately 5 seconds, and then extinguish if no
actions are carried out for a further 5 seconds.
After the button lights have automatically extinguished,
z
they automatically illuminate again if any button is
pressed.
(If the <LIGHT> button is pressed within 10 seconds
of illuminating, the button lights extinguish and do
not automatically illuminate even if another button is
pressed.)
Selecting the picture mode
You can switch to your desired picture mode settings.
Press
The settings change as follows each time the button
is pressed.
[NORMAL] [
[VIVID CINEMA] [CINEMA1]
Note
You can also switch the picture mode settings using the
z
on-screen menu.
For details see [PICTURE MODE] in the [PICTURE]
menu. (
DYNAMIC
page 37)
] [GAME] [SPORTS]
[REC709]
Adjusting the picture
Switchable setting items from the [PICTURE] menu of
the on-screen menu can be displayed in a list.
Press
Press the button to switch between [PICTURE] menu
and [ADVANCED MENU] menu. Press ▲ ▼ to select
the required menu item and ◄ ► to adjust.
[PICTURE] menu items
z
[PICTURE MODE], [CONTRAST], [BRIGHTNESS],
[COLOUR], [TINT], [COLOUR TEMPERATURE],
[SHARPNESS ] and [DYNAMIC IRIS]
[ADVANCED MENU] menu items
z
[GAMMA HIGH], [GAMMA MID], [GAMMA LOW],
[CONTRAST], [BRIGHTNESS], [NR], [MPEG NR],
[MOTION EFFECT], [x.v.Colour], [DETAIL CLARITY],
[CINEMA REALITY], [TV-SYSTEM], [RGB/YC
[RGB/YP
BPR
]
Note
For details regarding the adjustment method, see the
z
[PICTURE] menu (
MENU] menu (
Press the <RETURN> or <MENU> button or wait for 7
z
seconds without performing any operation to clear the
adjustment screen.
Set the [ADJUSTMENT MODE] to [SIMPLE] for adjusting
z
[GAMMA HIGH], [GAMMA MID], and [GAMMA LOW]
(
page 42).
The items for [SHARPNESS] that can be adjusted differ
z
depending on the [ADJUSTMENT MODE].
[SIMPLE]: [SHARPNESS]
[ADVANCED]: [H-SHARPNESS]
[V-SHARPNESS]
page 37) and the [ADVANCED
page 42).
BCR
] and
Remote control operation
32 -
ENGLISH
Basic Operation
Loading a saved setting
Displays the [MEMORY LOAD] menu.
Press
Attention
Setting can also be performed using the on-screen menu.
z
For details, see [MEMORY LOAD] in the [PICTURE]
menu. (
Displaying the [VIERA LINK MENU] menu
You can control some functions of the external device
with this projector remote control.
Press
Note
See “Using VIERA Link” for details. (
z
Displaying the waveform monitor
By displaying the input signal from a connected
external device with a waveform, you can check if the
video signal (luminance) level is set to a value within
this projector’s recommended range, and can adjust it
accordingly.
page 54)
page 82)
Checks that the waveform for each of the
[FULL
SCAN]
[SINGLE
LINE
SCAN]
Note
Signals lower than 0 % in the waveform monitor will be
z
displayed as same as 0 % on the projected image.
[SINGLE LINE SCAN] can display horizontal lines in Y-
z
(brightness), R- (red), G- (green), and B- (blue) from the
top of the screen to the bottom more nely than [FULL
SCAN], and each item can be adjusted in the same way
as [FULL SCAN].
When selecting [FULL SCAN], the display position of the
z
waveform can be set using the ▲▼
So that the display of individual adjustment screen in
z
[PICTURE] does not interfere with the waveform monitor,
the positioning of this screen differs depending on the
circumstances at the time.
The [AUTO ADJUST] is executed by pressing the
z
<DEFAULT> button while the waveform is displayed.
(
While the waveform monitor is displayed, you cannot
z
adjust the [COLOUR MANAGEMENT] settings.
Y- (brightness), R- (red), G- (green), and
B- (blue) values for the whole image is
within the recommended range.
Checks that the waveform for each of the
Y- (brightness), R- (red), G- (green), and
B- (blue) values for an arbitrary number
of lines from the top of the screen to the
bottom is within the recommended range.
Enables more detailed conrmation than
z
[FULL SCAN].
Line position can be changed with the ▲▼
z
buttons.
The display position of the [WAVEFORM
z
MONITOR] changes depending on the line
position.
buttons.
▲
▼
page 39)
Press
The settings change as follows each time the
<ENTER> button is pressed.
[FULL SCAN (Y)] [FULL SCAN (R)]
[SINGLE LINE SCAN (B)] [FULL SCAN (G)]
[SINGLE LINE SCAN (G)] [FULL SCAN (B)]
[SINGLE LINE SCAN (R)] [SINGLE LINE SCAN (Y)]
The waveform monitor disappears when the
<WAVEFORM MONITOR> button is pressed again.
Note
Setting can also be performed using the on-screen menu.
z
For details, see [WAVEFORM MONITOR] in [PICTURE]
menu. (
page 39)
Resetting to the default settings
You can reset most of the settings or adjustment
values for submenus to factory default settings.
Press
For details, see “Navigating through the menu Returning adjusted values to default settings” of “Menu
navigation”. (
page 34)
Remote control operation
ENGLISH
- 33
Basic Operation
Submenu
When the VIERA Link control is enabled, the function
menus of external devices can be displayed.
page
(
Furthermore, points for a gamma adjustment can be
altered. (
82)
page
42)
Press
Switching the input signal
The input for projection can be switched.
Press
The settings change as follows each time the button
is pressed.
[COMPONENT IN]
[COMPUTER IN] [S-VIDEO IN]
Attention
Input a signal noted in the “List of compatible signals”.
z
(
page 86)
Note
See “Connecting terminals” regarding input ports.
z
(
page 19)
If no operations are performed for approximately 3
z
seconds, the input guidance display automatically
disappears.
If a port that has no input is selected, the whole input port
z
graphic ashes. This graphic is displayed until an input is
present.
Using the <FUNCTION> button
Functions used often can be allocated to the
<FUNCTION> button on the remote control and this
can be used as a short cut button.
Press
Allocating operations to the
■
<FUNCTION> button
[HDMI 2 IN] [VIDEO IN]
[HDMI 1 IN]
[COMPONENT
IN]
[S-VIDEO IN]
[VIDEO IN]
[HDMI 1/2 IN]
[COMPUTER IN]
When [INPUT GUIDE] on the [OPTION] menu is
set to [DETAILED] (
will be displayed on the upper right of the projected
image, and the currently selected input terminal
can be checked. (The selected input method will be
highlighted in yellow.)
Press the button several times or press ▲ ▼ ◄ ► to
cycle through the input methods.
It may take time for the video to change after
switching input.
COMPONENT signals (YCBCR/
YPBPR) from the device connected
to COMPONENT IN.
S-VIDEO signal from the device
connected to S-VIDEO IN.
VIDEO signal from the device
connected to VIDEO IN.
HDMI signal from the device
connected to
HDMI IN 1/HDMI IN 2.
RGB signal and
COMPONENT signals (YCBCR/
YPBPR) from the device connected
to COMPUTER IN.
page 63), graphical guidance
Press the <MENU> button in the controls 1)
of the projector or on the remote control
to display the menu items for allocation
(main menu, submenu, or detailed menu).
For how to use the on-screen menu, see “Navigating
z
through the menu”. (
page 34)
Hold the <FUNCTION> button on the 2)
remote control down for at least 3
seconds.
After setup is complete the allocated menu items
z
are displayed under the on-screen menu.
Note
While the menu is displayed, the projector does not
z
operate even when the button is pressed.
Displaying the [ECO MANAGEMENT] menu
The settings screen for ECO MANAGEMENT can be
displayed. (
Press
page
67)
Menu navigation
34 -
ENGLISH
Settings
Menu navigation
PICTURE MODE
CONTRAST
BRIGHTNESS
COLOUR
TINT
COLOUR TEMPERAT URE
SHARPNESS
DYNAMIC IRIS
LIGHT HARMONIZER
WAVEFORM MONITOR
SPLIT ADJAST
ADVANCED MENU
PICTURE MEMORY
NORMAL
SIMPLE
ON
0
0
0
0
0
POSITION
LANGUAGE
OPTION
H-POSITION
V-POSITION
ASPECT
WSS
OVER SCAN
KEYSTONE
SCREEN AREA MEMORY
16:9
ON
0
0
0
0
POSITION
LANGUAGE
OPTION
H-POSITION 0
H-POSITION 0
0
Navigating through the menu
Operating procedure
■
Press
Press the <1) MENU> button on the remote
control or in the controls of the projector.
The main menu is displayed.
z
Press the ▲▼ buttons to select main 2)
menu items.
Select the item to be adjusted from the 4 items
z
[PICTURE], [POSITION], [LANGUAGE] and
[OPTION]. The selected item is indicated with a
yellow cursor, and the submenu is displayed on the
right hand side.
Press the ▲▼ buttons to select the 4)
submenu item you wish to alter, then
press the
For items where the setting is switched or that have
z
a bar scale, the menu screen disappears and only
the selected item (individual adjustment screen) is
displayed, as shown in the diagram below.
For items that are only names, pressing the
z
<ENTER> button displays the next screen and
advanced settings can be performed.
Note
Pressing the <RETURN> or <MENU> button when the
z
menu screen is displayed returns to the previous screen.
Depending on the signal input, some items may not be
z
adjustable and some functions may not be usable.
Some items can be adjusted even if a signal is not input.
z
See page
z
35 for the submenu items.
to switch settings/adjust.
▲
▼
■Returning adjusted values to default
settings
Press the <DEFAULT> button on the remote control
to return the settings/adjustment values to default
settings.
Press
This function differs depending on the screen
displayed.
Press the <ENTER> button.3)
The submenu is displayed, and submenu items
z
become selectable.
When the submenu screen is displayed:
●
The submenu items displayed are returned to
their default settings.
When individual adjustment screen is displayed:
●
Only the item currently being adjusted is returned
to its default settings.
Note
All settings cannot be simultaneously returned to default
z
settings.
Some items do not return to default settings even you
z
press the <DEFAULT> button. Please set those items
individually.
The vertical bar above the bar scale on the individual
z
adjustment screen indicates the default setting.
The position of the vertical bar varies depending on the
input signal.
Default setting
Current setting
Menu navigation
ENGLISH
- 35
Settings
Menu list
The on-screen menu is used for settings and
adjustments on this projector.
See “Navigating through the menu” for details of onscreen menu operation. (
The submenu of the main menu is displayed, and
setting/adjustment for each item can be performed.
[ ■PICTURE]
S-VIDEO IN/VIDEO IN/COMPONENT (YC
●
YPBPR) signal input/HDMI
Submenu items
[PICTURE MODE] [NORMAL] 37
[CONTRAST] [0] 37
[BRIGHTNESS] [0] 37
[COLOUR] [0] 37
[TINT] [0] 37
[COLOUR
TEMPERATURE]
[SHARPNESS] [SIMPLE] 38
[DYNAMIC IRIS] [ON] 38
[LIGHT HARMONIZER]
[WAVEFORM MONITOR] — 39
[SPLIT ADJUST] — 41
[ADVANCED MENU] — 42
[PICTURE MEMORY] — 53
SIGNAL MODE
*1: COMPONENT IN/HDMI IN only
COMPUTER (RGB) signal input
●
Submenu items
[PICTURE MODE] [NORMAL] 37
[CONTRAST] [0] 37
[BRIGHTNESS] [0] 37
[COLOUR
TEMPERATURE]
[SHARPNESS] [SIMPLE] 38
[DYNAMIC IRIS] [ON] 38
[LIGHT HARMONIZER]
[WAVEFORM MONITOR] — 39
[SPLIT ADJUST] — 41
[ADVANCED MENU] — 42
[PICTURE MEMORY] — 53
SIGNAL MODE 54
*1
page 34)
Default
setting
[0] 38
Default
setting
[0] 38
BCR
Page
38
54
Page
38
/
[ ■POSITION]
S-VIDEO IN/VIDEO IN
●
Submenu items
[H-POSITION] [0] 55
[V-POSITION] [0] 55
[ASPECT] [AUTO] 56
[WSS]
*1
[OVER SCAN] [+7] 58
[KEYSTONE] [0] 58
[SCREEN AREA MEMORY]
*1: PAL signal input only
COMPONENT IN/COMPUTER IN
●
Submenu items
[H-POSITION] [0] 55
[V-POSITION] [0] 55
[DOT CLOCK]
[CLOCK PHASE]
*1
*2
[ASPECT] [16:9] 56
[WSS]
[OVER SCAN]
*3
*4
[KEYSTONE] [0] 58
[AUTO SETUP]
*5
[SCREEN AREA MEMORY]
*1: COMPUTER IN only (exc. 480i, 576i, 480p, 576p)
*2: Exc. 480i/576i
*3: COMPONENT IN (576i, 576p) only
*4: COMPONENT IN and COMPUTER signal (movie
based signals) input only
*5: COMPUTER IN (RGB) signals only (exc. movie
based signals)
HDMI IN
●
Submenu items
[H-POSITION] [0] 55
[V-POSITION] [0] 55
[ASPECT] [16:9] 56
[OVER SCAN] [0] 58
[KEYSTONE] [0] 58
[SCREEN AREA MEMORY]
Note
The default settings may be different depending on the
z
picture menu.
Default
setting
[ON] 58
Default
setting
[0] 55
[0] 55
[ON] 58
[0] 58
— 58
Default
setting
Page
59
Page
59
Page
59
Menu navigation
36 -
ENGLISH
Settings
[ ■LANGUAGE]
[DEUTSCH]
[FRANÇAIS]
[ESPAÑOL]
[ITALIANO]
[PORTUGUÊS]
[SVENSKA]
[NORSK]
[DANSK]
[POLSKI]
[
[MAGYAR]
[РУССКИЙ]
[
[ ]
[ENGLISH]
[
中文
[
日本語
]
]
]
]
Language
[ ■OPTION]
Submenu items
[ON-SCREEN DISPLAY] — 63
[BACK COLOUR] [BLUE] 63
[STARTUP LOGO] [ON] 64
[AUTO SEARCH] [ON] 64
[HDMI SIGNAL LEVEL]
[FRAME RESPONSE] [NORMAL] 64
[PROJECTION METHOD]
[TRIGGER 1 SETTING] [OFF] 65
[TRIGGER 2 SETTING] [OFF] 65
[HIGH ALTITUDE MODE] [OFF] 66
[LAMP POWER] [NORMAL] 66
[ECO MANAGEMENT]
[FUNCTION BUTTON] — 68
[VIERA LINK SETTINGS] — 68
[OTHER FUNCTIONS] — 70
[TEST PATTERN] — 70
[LAMP RUNTIME] — 70
*1
Default
setting
[NORMAL] 64
[FRONT/
DESK]
Page
64
67
*1: HDMI IN only
Note
Display of submenu items and default settings differs
z
depending on the selected input port.
[PICTURE] menu
ENGLISH
- 37
Settings
Remote control
Projector controls
[PICTURE] menu
Select [PICTURE] from the main menu of
“Navigating through the menu” (
and choose an item from the submenu.
After selecting an item, adjust the image with the
z
buttons.
page
34
),
▲
[PICTURE MODE]
You can use these preset parameter settings to
optimize image projection according to image source
or projection environment.
Switch settings Switch settings
▼
[CONTRAST]
You can adjust the contrast of the colors.
Setting range: -64 to +64
z
Attention
Adjust the [BRIGHTNESS] in advance if necessary.
z
Lower
Higher
[BRIGHTNESS]
You can adjust the dark (black) part of the projected
image.
Darker
Setting range: −32 to +32
z
Brighter
[COLOUR]
The settings change as follows each time the button
is pressed.
[NORMAL]
[VIVID CINEMA] [CINEMA1]
[NORMAL] For a general image.
[DYNAMIC]
[GAME] For use with games.
[SPORTS] For sports program.
[REC709]
[CINEMA1]
[VIVID
CINEMA]
Note
It may take a few seconds for the picture to stabilize after
z
a picture mode change.
[DYNAMIC]
For viewing at high brightness and
sharpness.
For HDTV standard (ITU-R BT.
709) color temperature 6 500 K at
the default setting of the [PICTURE]
menu items.
Tuned by top Hollywood colorists
for watching a movie with smooth
image quality.
For use with a high luminance,
clear picture mode.
[GAME] [SPORTS]
[REC709]
You can adjust the color saturation of the projected
image.
Lighter
Setting range: −32 to +32
z
Note
When COMPUTER signal is input, only movie based
z
signals can be adjusted.
Movie based signals are 480i, 576i, 480p, 576p, 720/60p,
z
720/50p, 1 080/60i, 1 080/50i, 1 080/60p, 1 080/50p and
1 080/24p.
Darker
[TINT]
You can adjust the skin tone in the projected image.
Less greenish
Setting range: −32 to +32
z
Note
When COMPUTER signal is input, only movie based
z
signals can be adjusted.
Movie based signals are 480i, 576i, 480p, 576p, 720/60p,
z
720/50p, 1 080/60i, 1 080/50i, 1 080/60p, 1 080/50p and
1 080/24p.
Less reddish
[PICTURE] menu
38 -
ENGLISH
Settings
SHARPNESS
ADJUSTMENT MODE
SHARPNESS
H-SHARPNESS
V-SHARPNESS
SIMPLE
0
POSITION
LANGUAGE
SHARPNESS
ADJUSTMENT MODE
SHARPNESS
H-SHARPNESS
V-SHARPNESS
ADVANCED
0
0
POSITION
LANGUAGE
H-SHARPNESS
V-SHARPNESS
0
0
LIGHT HARMONIZER
MODE
MANUAL ADJUST
MANUAL
POSITION
0
[COLOUR TEMPERATURE]
You can adjust the color temperature if the white
areas of the projected image are bluish or reddish.
Setting range: -6 to +6
z
Less bluish
Less reddish
[SHARPNESS]
With regards to the input signal, adjust video
sharpness using one of [SIMPLE] which adjusts
horizontal direction and vertical direction
simultaneously or [ADVANCED] which adjusts each
individually.
Softer
Note
Setting range will vary according to the selected input
z
signal.
[SHARPNESS] can be adjusted using either [SIMPLE] or
z
[ADVANCED]. Both settings cannot be used at the same
time.
Adjusting the [SHARPNESS].
z
(When [SIMPLE] is selected for the
[ADJUSTMENT MODE].)
Sharper
Select item with the ▲▼ buttons, and 2)
adjust with the
Pressing the ▲▼ buttons on the screen during
z
adjustment switches to the [H-SHARPNESS] or
[V-SHARPNESS] adjustment screen.
The setting range varies according to the selected
z
picture mode and input signal.
buttons.
▲
▼
[DYNAMIC IRIS]
You can switch automatic adjustment of the lamp and
the lens iris on/off. This augments the video to create
a video expression with sharp contrast between light
and shade.
Switch settings Switch settings
[ON] Automatic adjustment
[OFF] No adjustment
[LIGHT HARMONIZER]
You can optimize the video according to the
brightness and color of the surroundings.
z
Press 1)
buttons to select [SIMPLE].
▲
▼
Select [SHARPNESS] with the ▲▼ 2)
buttons, and adjust with the
buttons.
▲
▼
Adjusting the [SHARPNESS].
(When [ADVANCED] is selected for the
[ADJUSTMENT MODE].)
Press the ◄► buttons to select 1)
[ADVANCED].
Switch settings Switch settings
Light harmonizer on (automatic
augmentation). The color sensor
[AUTO]
detects the brightness of the
surroundings and automatically
augments the video display.
Light harmonizer on (manual
setting). When [MANUAL] is
[MANUAL]
selected, [MANUAL ADJUST] can
be set using the
buttons
▲
▼
(setting range: 0 to +3).
[OFF] Light harmonizer off.
Note
[AUTO] mode may not function correctly if an object is
z
placed on the color sensor (
is placed in a recess.
page 18) or the projector
[PICTURE] menu
ENGLISH
- 39
Settings
WAVEFORM MONITOR
OFF
FULL SCAN(Y)
FULL SCAN(R)
FULL SCAN(G)
FULL SCAN(B)
SINGLE LINE SCAN(Y)
SINGLE LINE SCAN(R)
SINGLE LINE SCAN(G)
SINGLE LINE SCAN(B)
MONITOR POSITION
AUTO ADJUST
UPPER LEFT
●
[WAVEFORM MONITOR]
By using a commercial test disk etc. and setting the
luminance level of the output (brightness) signal from
a connected external device to a value within this
projector’s recommended range, you can perform
adjustment so the display performance of the projector
can be fully leveraged.
Press the <ENTER> button.1)
The [WAVEFORM MONITOR] menu is displayed.
z
Press the ▲▼ buttons to select the 2)
required item.
The waveform monitor is displayed.
z
Select [OFF] to close the waveform monitor.
z
Press the <ENTER> button.3)
Note
For details, see “Displaying the waveform monitor” in
z
“Remote control operation”. (
■[MONITOR POSITION]
You can set the display position of the input waveform
during the FULL SCAN display.
Switch settings Switch settings
page 32)
[ ■AUTO ADJUST]
The luminance level of the output signal from a connected
external device is automatically adjusted by setting the
automatic waveform adjustment items.
Press the <ENTER> button.1)
Press the ▲▼ buttons to select the 2)
required item.
Automatic waveform
adjustment items
[BLACK LEVEL ADJUST] [ON]
[WHITE LEVEL ADJUST] [ON]
[RGB ADJUST (BLACK)] [OFF]
[RGB ADJUST (WHITE)] [OFF]
Default
setting
Press the ◄► buttons to switch 3)
adjustment.
Press the ▲▼ buttons to select [START 4)
AUTO ADJUST] and press the <ENTER>
button.
[PROCESSING] message is displayed. When
z
adjustment is complete, a conrmation message for
applying results is displayed.
Select [OK] with the 5)
buttons.
▲
▼
Press the <ENTER> button.6)
Note
When [BLACK LEVEL ADJUST] is [ON], the display
z
signal Y (brightness) value’s black level is automatically
adjusted to the 0% position.
When [WHITE LEVEL ADJUST] is [ON], the display
z
signal Y (brightness) value’s white level is automatically
adjusted to the 100% position.
When [RGB ADJUST (BLACK)] is [ON], the display signal
z
R (Red), G (Green), and B (Blue) value’s black level are
all automatically adjusted to the 0% position.
When [RGB ADJUST (WHITE)] is [ON], the display signal
z
R (Red), G (Green), and B (Blue) value’s white level are
all automatically adjusted to the 100% position.
[AUTO ADJUST] cannot be executed if the [WAVEFORM
z
MONITOR] is [OFF].
Project the luminance adjustment signal of a commercial
z
test disk etc., and perform automatic adjustment.
However, even with an adjustment disk, correct
adjustment may not be possible if noise is included on
the disk itself or the playback device generates noise.
[AUTO ADJUST] adjusts based on the 0% and 100%
z
standard signal within the screen, so correct adjustment
cannot be performed if standard signals are not displayed
on the screen because of overscan etc., or if a signal that
is less than 0% or greater than 100% is displayed on the
screen.
[PICTURE] menu
40 -
ENGLISH
Settings
RETURN
MOVE DISPLAY
CHANGE WF MODE
Adjust the waveform
■
Project the brightness adjustment signal of a commercial
test disk (0% [0 IRE or 7.5 IRE] - 100% [100 IRE] ) and
perform adjustment.
Adjust to 100%
Signal (luminance) level
Monitor
Adjust to 0 %
With COMPUTER (except 1 080
signal) or HDMI (Expand)
Signal (luminance) level
Adjust to 0 %
position
Adjust to 100%
Monitor
position
With the [WAVEFORM MONITOR] displayed, press the
<MENU> button on the remote control and adjust using
[ADVANCED MENU] and [PICTURE] from the on-screen
menu.
displayable
area
displayable
area
Adjust [FULL SCAN(Y)] / [SINGLE LINE 1)
SCAN(Y)].
Set on [PICTURE] and use the
z
adjust [BRIGHTNESS] and then [CONTRAST].
Adjust the bottom line of the
waveform to 0 %
[BRIGHTNESS]
(0 or 7.5 IRE)
Setting range:
z
−32 to +32
Adjust the top line of the
waveform to 100 %
[CONTRAST]
(100 IRE)
Setting range:
z
−64 to +64
buttons to
▲
▼
Adjust [FULL SCAN(R)] / [SINGLE LINE 2)
SCAN(R)].
Set on [ADVANCED MENU] and use the
z
buttons to adjust [BRIGHTNESS R] and then
[CONTRAST R].
Adjust the bottom line of the
waveform to 0 %
[BRIGHTNESS R]
(0 or 7.5 IRE)
Setting range:
z
−16 to +16
Adjust the top line of the
waveform to 100 %
[CONTRAST R]
(100 IRE)
Setting range:
z
−32 to +32
Adjust [FULL SCAN(G)] / [SINGLE LINE 3)
SCAN(G)].
Set on [ADVANCED MENU] and use the
z
buttons to adjust [BRIGHTNESS G] and then
[CONTRAST G].
Adjust the bottom line of the
waveform to 0 %
[BRIGHTNESS G]
[CONTRAST G]
(0 or 7.5 IRE)
Setting range:
z
−16 to +16
Adjust the top line of the
waveform to 100 %
(100 IRE)
Setting range:
z
−32 to +32
▲
▲
▼
▼
[PICTURE] menu
ENGLISH
- 41
Settings
SPLIT ADJUST
AREA SELECT
SPLIT ADJUST MODE
NORMAL
POSITION
LANGUAGE
MOVE AREA ENTER : GO TO SPLIT ADJUST RETURN : GO TO FREEZE SCREEN
MENU : GO TO PICTURE MENU ENTER : ADJUSTMENT COMPLETE RETURN : GO TO AREA SELECT
MENU : GO TO PICTURE MENU ENTER : ADJUSTMENT COMPLETE RETURN : GO TO AREA SELECT
PICTURE MODE
CONTRAST
BRIGHTNESS
COLOUR
TINT
COLOUR TEMPERATURE
SHARPNESS
DYNAMIC IRIS
LIGHT HARMONIZER
WAVEFORM MONITOR
SPLIT ADJAST
ADVANCED MENU
PICTURE MEMORY
SIMPLE
0
0
0
0
0
POSITION
LANGUAGE
OPTION
F
RETURN
FUNCTION
DISABLE
ENTER
SELECT
Adjust [FULL SCAN(B)] / [SINGLE LINE 4)
SCAN(B)].
Set on [ADVANCED MENU] and use the
z
▲
buttons to adjust [BRIGHTNESS B] and then
[CONTRAST B].
Adjust the bottom line of the
waveform to 0 %
[BRIGHTNESS B]
(0 or 7.5 IRE)
Setting range:
z
−16 to +16
Adjust the top line of the
waveform to 100 %
[CONTRAST B]
(100 IRE)
Setting range:
z
−32 to +32
[SPLIT ADJUST]
You can perform image adjustment for some
[PICTURE] menu items while displaying a certain
area of the frozen image in a split window.
Press the <ENTER> button.1)
The [SPLIT ADJUST] menu is displayed.
z
▼
Press the <ENTER> button.4)
Split screen display begins.
z
[When [SPLIT ADJUST MODE] is [NORMAL]]
[When [SPLIT ADJUST MODE] is [REVERSE]]
Note
By selecting the [SPLIT ADJUST MODE] with the ▲▼
z
buttons and switching [NORMAL] to [REVERSE], the
screen displayed on the left during split screen display
can be reversed and adjusted.
Press the ▲▼ buttons to select [AREA 2)
SELECT] and then press the <ENTER>
button.
The image is frozen and an area for adjustment is
z
displayed. The image being projected is recorded
and displayed as a frozen image.
Use the 3)
buttons to select the area to
▲
▼
be adjusted.
Note
Press the <RETURN> button, and a frozen screen is
z
displayed.
Press the <MENU> button and make 5)
adjustments with the [PICTURE] menu.
The menu screen is displayed. You can adjust the
z
image for optimal display.
Items that can be adjusted
z
Submenu items Page
[CONTRAST] 37
[BRIGHTNESS] 37
[COLOUR] 37
[TINT] 37
[COLOUR TEMPERATURE] 38
[SHARPNESS] 38
[ADVANCED MENU] 42
Press the <RETURN> button until getting 6)
back to the adjustment screen.
[PICTURE] menu
42 -
ENGLISH
Settings
SPLIT ADJUST
SAVE CHANGES?
YES : SAVE AND QUIT
NO : QUIT WITHOUT SAVING
CANCEL : ADJUST AGAIN
CANCELYES NO
RETURN
SELECT
ENTER
GAMMA ADJUSTMENT
ADJUSTMENT MODE
GAMMA HIGH
GAMMA MID
GAMMA LOW
POINT
Y ADJUST
R ADJUST
G ADJUST
B ADJUST
INITIALIZE
ADVANCED
5
POSITION
LANGUAGE
OPTION
Press the <ENTER> button.7)
The conrmation message is displayed.
z
Select [YES] with the ◄► buttons and press the
<ENTER> button to apply the changes and return
to the frozen screen.
Select [NO] with the ◄► buttons and press the
<ENTER> button to return to the frozen screen
without applying changes.
Note
Select [CANCEL] on the conrmation message and press
z
the <ENTER> button to return to the adjustment screen.
Press the <RETURN> button.8)
You can now view the projected video with the
z
adjustments applied.
Note
You cannot adjust menu items that are displayed in grey
z
during split adjustment.
The [KEYSTONE] of [POSITION] becomes inactive
z
during split adjustment.
[ADVANCED MENU]
You can perform more detailed image adjustment
manually.
Press the <ENTER> button.
The [ADVANCED MENU] menu is displayed.
z
■[GAMMA ADJUSTMENT]
You can make detailed adjustments to the light intensity of
each input signal level by using the [ADVANCED] mode,
or adjust at 3 levels (high, mid, low) by using the [SIMPLE]
mode.
Note
You can only carry out the [GAMMA ADJUSTMENT]
z
through either the [ADVANCED] or [SIMPLE] mode. Both
settings cannot be used at the same time.
Adjusting the gamma (when [ADVANCED]
●
is selected for [ADJUSTMENT MODE])
Press the ◄► buttons to select 1)
[ADVANCED].
[PICTURE] menu
ENGLISH
- 43
Settings
Y ADJUST
POINT5
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT50%0
Y ADJUST
POINT
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT50%+105
Y ADJUST
POINT
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT60%06
GAMMA ADJUSTMENT
ADJUSTMENT MODE
GAMMA HIGH
GAMMA MID
GAMMA LOW
POINT
Y ADJUST
R ADJUST
ADVANCED
5
POSITION
LANGUAGE
OPTION
GAMMA ADJUSTMENT
ADJUSTMENT MODE
GAMMA HIGH
GAMMA MID
GAMMA LOW
POINT
Y ADJUST
R ADJUST
ADVANCED
6
POSITION
LANGUAGE
OPTION
Press the ▲▼ buttons to select [Y ADJUST] 2)
and then press the <ENTER> button.
The [Y ADJUST] menu is displayed and a
z
maximum of 9 points are adjustable.
(A)
Displays information about the current selected point
(A).
Default setting:
POINT [5] INPUT [50 %] OUTPUT [0]
Adjust the tone with the ▲▼3)
buttons,
▲
▼
<ENTER> button, <SUB MENU> button, or
<DEFAULT> button.
a. Changing the selected point
Using the remote control
z
The selection point moves one point to the right each
time the <SUB MENU> button is pressed. The default
setting is point 5.
Ex. 5 -> 6 ->...-> 9 -> 1 ->...
[POINT]
[1] to [9]
[INPUT]
[1 %] to
[99 %]
[OUTPUT]
[-252] to
[+252]
Display the present selected point
number.
Numbers 1 to 9 are displayed from
the left of the input signal level.
Your selected point is indicated in
yellow on the graph.
Display the input level of the present
selected point.
Setting range: from 1 to 99 % in
increments of 1 %.
Default settings: 10, 20, 30, 40, 50,
60, 70, 80, 90 %
Display the output level of the present
selected point.
Adjustable range depends on the
input level.
Default setting: 0
Using the device control
z
You can also change the [POINT] from the [GAMMA
ADJUSTMENT] menu directly.
Use ▲ ▼ to select [POINT] and ◄ ► to change the
point.
[PICTURE] menu
44 -
ENGLISH
Settings
Y ADJUST
POINT
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT50%05
Y ADJUST
POINT
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT44%05
Y ADJUST
POINT
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT50%+105
Y ADJUST
POINT
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT50%+305
b. Adjusting the input level
To adjust the input level from the present setting,
z
press
continuously until it reaches your
▲
▼
desired level. (It may be moved left and right.)
Setting range: from 1 to 99 % in increments of
z
1 %. (However, it cannot be set beyond the
adjacent points.)
Only available to adjust the input level in the
z
[Y ADJUST] screen and not other screens.
(Input level cannot be adjusted on the [R/G/B
ADJUST] screen.)
Ex. Press ◄ in the [Y ADJUST] screen and move the
selected point leftward.
c. Adjusting the output level
To adjust the output level from the present setting,
z
press ▲ ▼ continuously until it reaches to your
desired level. (It may be moved up and down.)
Output level can be adjusted for each color on
z
the [R/G/B ADJUST] screen.
Ex. Press ▲ in the [Y ADJUST] screen and move the
selected point upward.
MOVE
UP
MOVE LEFT
Setting range: -252 to +252
Setting range: 1 to 99 %
[PICTURE] menu
ENGLISH
- 45
Settings
GAMMA ADJUSTMENT
ADJUSTMENT MODE
GAMMA HIGH
GAMMA MID
GAMMA LOW
POINT
Y ADJUST
R ADJUST
G ADJUST
B ADJUST
INITIALIZE
ADVANCED
5
POSITION
LANGUAGE
OPTION
R ADJUST
POINT
0% 50% 100%
INPUT
OUTPUT
INPUT OUTPUT50%+105
POSITION
LANGUAGE
OPTION
GAMMA ADJUSTMENT
ADJUSTMENT MODE
GAMMA HIGH
GAMMA MID
GAMMA LOW
POINT
Y ADJUST
R ADJUST
G ADJUST
B ADJUST
INITIALIZE
ADVANCED
5
GAMMA ADJUSTMENT
INITIALIZE GAMMA ADJUSTMENT.
CANCELOK
d. Changing the adjustment by different color
types
The settings change as follows each time the
z
<ENTER> button is pressed.
Y ADJUST R ADJUST
B ADJUST G ADJUST
You can also switch each different color adjustment
menu through the [GAMMA ADJUSTMENT] menu.
Select your required color adjustment ([Y ADJUST],
[R ADJUST], [G ADJUST], [B ADJUST]) with ▲ ▼
in the [GAMMA ADJUSTMENT] menu and press the
<ENTER> button.
●
Initialize the gamma adjustment results
Press the ▲▼ buttons to select 1)
[INITIALIZE] and press the <ENTER>
button.
The conrmation message is displayed for the
z
gamma initialization.
e. Setting the output levels back to the default
setting
To set the output level on the selected point back
z
to the default setting “0”, press the <DEFAULT>
button on the remote control.
Note
Individual input levels cannot be set back to their default
z
settings by pressing the <DEFAULT> button. Press
to move back themselves if needed.
▲
▼
Select [OK] with the 2)
buttons and press
▲
▼
the <ENTER>button.
Your gamma settings in [ADVANCED] mode will
z
return to factory default settings.
Note
Initialization is not available in [SIMPLE] mode.
z
[PICTURE] menu
46 -
ENGLISH
Settings
GAMMA ADJUSTMENT
ADJUSTMENT MODE
GAMMA HIGH
GAMMA MID
GAMMA LOW
POINT
Y ADJUST
R ADJUST
SIMPLE
0
0
0
POSITION
LANGUAGE
OPTION
GAMMA HIGH
GAMMA MID
GAMMA LOW
0
0
0
●Adjusting the gamma (when [SIMPLE] is
selected for [ADJUSTMENT MODE])
Press the ◄► buttons to select [SIMPLE].1)
Select item with the ▲▼ buttons, and 2)
adjust with the
You can adjust linear intensity at 3 levels (high,
z
mid, low). Press ▲ ▼ to select your required
gamma levels.
-1 +1
buttons.
▲
▼
■[BRIGHTNESS]
You can adjust color temperatures centring mainly on black.
R (RED), G (GREEN), B (BLUE)
-1 +1
[ADVANCED MENU] menu items
Default
setting
[BRIGHTNESS R] 0
[BRIGHTNESS G] 0
[BRIGHTNESS B] 0
Setting range: -16 to +16
z
■[NR]
You can eliminate the noise that occurs when the input
signal deteriorates.
Weaken Strengthen
[ADVANCED MENU] menu items
Default
setting
[GAMMA HIGH] 0
[GAMMA MID] 0
[GAMMA LOW] 0
Setting range: -8 to +8
z
■[CONTRAST]
You can adjust color temperatures centring mainly on
white.
R (RED), G (GREEN), B (BLUE)
-1 +1
[ADVANCED MENU] menu items
[CONTRAST R] 0
[CONTRAST G] 0
[CONTRAST B] 0
Default
setting
Setting range: 0 to +3
z
■[MPEG NR]
You can eliminate the noise that occurs upon projection for
videos that use MPEG compression.
Weaken Strengthen
Setting range: 0 to +3
z
Attention
Use a strong setting when projecting an MPEG video.
z
COMPUTER (RGB) signal is not supported.
z
Setting range: -32 to +32
z
[PICTURE] menu
ENGLISH
- 47
Settings
■[MOTION EFFECT]
COLOUR MANAGEMENT
PROFILE
ADJUSTMENT MODE
START ADJUSTMENT
LOG
NORMAL
CURSOR
COLOUR
TINT
BRIGHTNESS
CURSOR
0
0
0
RETURN
DEFAULT
SELECT
ENTER
Videos with a lot of movement can also be viewed sharply.
Switch settings Switch settings
Adjusting the selected color (when
z
[CURSOR] is selected for [ADJUSTMENT
MODE])
Select the desired color with a cursor and adjust.
Press the ◄► buttons to select [CURSOR] 1)
in [ADJUSTMENT MODE].
[OFF]
[ON]
MOTION EFFECT inactive
MOTION EFFECT active
Note
The effect on the video may be difcult to see in some
z
cases.
■[COLOUR MANAGEMENT]
For the selected [PICTURE MODE], you can adjust a
selected color individually with [CURSOR] mode or adjust
the six color components (Red, Green, Blue, Cyan,
Magenta, Yellow) with [RGBCMY] mode.
Adjustment results can be saved as a prole and called
later.
●Create a new prole
Note
[COLOUR MANAGEMENT] will be unable to adjust with
z
the setting of [REC709] in [PICTURE MODE], when
HDMI signal is selected.
When the input signal is switched while adjusting,
z
adjustment details are not saved.
If there is another area, which has the exact same or
z
similar color as the target on the same screen, these
colors will be adjusted as well.
You can adjust all colors except white, gray and black.
z
If you edit a single color to be individual different colors,
z
the desired color may not be achieved.
Press the ▲▼ buttons to select [START 2)
ADJUSTMENT] and press the <ENTER>
button.
The cross cursor
z
projected image is captured.
Screen
(A) is displayed, and the
Move the cursor with the ▲▼◄► buttons 3)
to the required place to select a color.
Align the center of the cross cursor on the point
z
in the projected image to be adjusted.
Press the <ENTER> button.4)
[CURSOR] menu
z
are displayed.
(B) and the color selected (C)
Screen
Note
In some cases you may be unable to adjust when the
z
very edge point of the projection area is selected.
You can create a prole only when [ADJUSTMENT
z
MODE] is set to either [CURSOR] or [RGBCMY]. A prole
cannot be created from both adjustments.
White, gray and black cannot be edited.
z
[PICTURE] menu
48 -
ENGLISH
Settings
COLOUR
TINT
BRIGHTNESS
CURSOR
RETURN
DEFAULT
SELECT
ENTER
0
0
0
COLOUR MANAGEMENT
PROFILE
ADJUSTMENT MODE
START ADJUSTMENT
LOG
NORMAL
RGBCMY
RGBCMY ADJUSTMENT
RED
GREEN
BLUE
CYAN
MAGENTA
YELLOW
ALL DELETE
COLOUR
TINT
BRIGHTNESS
RED
0
0
0
RETURN
DEFAULT
SELECT
ENTER
Press the ▲▼ buttons to select a menu 5)
item and the ◄► buttons to adjust each
item level.
Adjust the vividness of the
[COLOUR]
color.
Setting range:
z
−30 to +30
Adjust the color tone.
[TINT]
Setting range:
z
−30 to +30
Adjust the brightness of the
[BRIGHTNESS]
The default setting for each item is [0].
z
After adjusting, the post-adjustment color (D) is
displayed.
color.
Setting range:
z
−20 to +20
Adjusting the selected color (when
z
[RGBCMY] is selected for [ADJUSTMENT
MODE])
Select the color from 6 different color types ([RED],
[GREEN], [BLUE], [CYAN], [MAGENTA], [YELLOW]) and
adjust [COLOUR], [TINT] and [BRIGHTNESS].
Press the ◄► buttons to select [RGBCMY] 1)
in [ADJUSTMENT MODE].
Press the ▲▼ buttons to select [START 2)
ADJUSTMENT] and press the <ENTER>
button.
Press the ▲▼ buttons to select your 3)
desired color and press the <ENTER>
button.
Screen
Press the <ENTER> button.6)
[PROCESSING] message is displayed for a few
z
seconds and the result is stored in [LOG].
You can store up to 8 logs under [LOG]. Press
the <RETURN> or <MENU> button to adjust
the other colors. Repeat from step 3) to store
more adjustments.
Press the <RETURN> button or <MENU> 7)
button twice.
This returns you to the [COLOUR
z
MANAGEMENT] menu.
Menu
z
Screen
(B) and the base color (C) is displayed.
[PICTURE] menu
ENGLISH
- 49
Settings
COLOUR
TINT
BRIGHTNESS
RED
0
0
0
RETURN
DEFAULT
SELECT
ENTER
LOG
ADJUSTMENT MODE
PICTURE MODE
POINT1
POINT2
POINT3
POINT4
POINT5
POINT6
POINT7
POINT8
ALL DELETE
: CURSOR
: NORMAL
COLOUR TINT BRIGHTNESS
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
Press the ▲▼ buttons to select a menu 4)
item and the ◄► buttons to adjust each
item level.
Adjust the vividness of the
[COLOUR]
color.
Setting range:
z
−30 to +30
Adjust the color tone.
[TINT]
Setting range:
z
−30 to +30
Adjust the brightness of the
[BRIGHTNESS]
The default setting for each item is [0].
z
After adjusting, the post-adjustment color (D) is
displayed.
color.
Setting range:
z
−20 to +20
Screen
Press the <ENTER> button.5)
[PROCESSING] message is displayed for a few
z
seconds and the result is stored in [LOG].
You can store up to 6 different color adjusted
images under [LOG]. Press the <RETURN>
button to adjust the other colors. Repeat from
step 3) to store more adjustments.
Press the <RETURN> button or <MENU> 6)
button twice.
This returns you to the [COLOUR
z
MANAGEMENT] menu.
Note
Base color
z
when [ADJUSTMENT MODE] is set to [RGBCMY]), are
intended to be guide colors only.
(C) and post-adjustment color (D) (displayed
Editing/deleting logs
●
You can edit or delete stored logs.
Press the ▲▼ buttons to select [LOG] and
press the <ENTER> button.
The [LOG] menu is displayed.
z
Managing the stored logs created through the
z
[CURSOR] mode
Adjusted
color
Selected
color
Press ▲ ▼ to select the point you wish
to edit, and press the <ENTER> button
to display the screen to select [CHANGE]
or [DELETE].
[CHANGE]: The [CURSOR] menu is
displayed and you can
[POINT]
[1] - [8]
[DELETE]: Deletes point adjustment
readjust the color.
data.
Press the <ENTER> button
to display a conrmation
message.
Select [OK] with the
buttons and press the
<ENTER> button to delete.
When [ALL DELETE] is selected using
the ▲▼ buttons and <ENTER> is
pressed, a conrmation message is
[ALL
DELETE]
displayed.
Select [OK] with the
buttons and press
▲
▼
the <ENTER> button to delete all logs.
The [PROFILE] setting will be set to
[NORMAL] if all logs are deleted.
▲
▼
[PICTURE] menu
50 -
ENGLISH
Settings
LOG
ADJUSTMENT MODE
PICTURE MODE
RED
GREEN
BLUE
CYAN
MAGENTA
YELLOW
ALL DELETE
: RGBCMY
: NORMAL
COLOUR TINT BRIGHTNESS
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
+10+10 +10
PROFILE SAVE
☆
USER1
★
USER2
☆
USER3
PROFILE SAVE
SAVE THE PROFILE DATA AS USER 1.
CANCELOK
PROFILE NAME INPUT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcde fghijklm
nopqrstuvwxyz
1234567890
!"#$%&'
＊ +-/=?@\^
_`|~()<>[]{},.:;
ALL DELETE
SPACE
OK CANCEL
Managing the stored logs created through the
z
[RGBCMY] mode
Saving a log setting as a prole
●
Save a log setting as a prole.
You can save up to 3 proles.
Press the ▲▼ buttons to select [PROFILE 1)
SAVE] and press the <ENTER> button.
The [PROFILE SAVE] menu is displayed.
z
Press the ▲▼ buttons to select the number 2)
to be saved and press the <ENTER>
button.
Selected
color
[RED]
[GREEN]
[BLUE]
[CYAN]
[MAGENTA]
[YELLOW]
[ALL DELETE]
Adjusted
color
Press ▲ ▼ to select the color you
wish to edit, and press the <ENTER>
button to display the screen to select
[CHANGE] or [DELETE].
[CHANGE]: You can readjust the color.
[DELETE]: Deletes color adjustment
history.
Press the <ENTER> button
to display a conrmation
message.
Select [OK] with the
▲
▼
buttons and press the
<ENTER> button to delete.
When [ALL DELETE] is selected using
the ▲▼ buttons and <ENTER> is
pressed, a conrmation message is
displayed.
Select [OK] with the
buttons and
▲
▼
press the <ENTER> button to delete
all logs.
The [PROFILE] setting will be set to
[NORMAL] if all logs are deleted.
: When a prole is already saved
★
: Not saved
☆
The [PROFILE SAVE] conrmation message is
z
displayed.
Select [OK] with the ◄► buttons.3)
Press the <ENTER> button.4)
The [PROFILE NAME INPUT] screen is
z
displayed.
Note
If [ADJUSTMENT MODE] is set to [RGBCMY],
z
adjusting and registering the [COLOUR], [TINT], and
[BRIGHTNESS] as [0] for adjustment values that have
been previously registered deletes them from the log.
Press the ▲▼◄► buttons to select the 5)
characters and press the <ENTER> button
for input.
You can enter up to 14 characters.
z
Select [ALL DELETE] and press the <ENTER>
z
button to erase all input text. If you press the
<DEFAULT> button on the remote control, you can
erase the character currently selected by the cursor
in the input box.
Select [OK] with the ▲▼◄► buttons.6)
Press the <ENTER> button.7)
Note
Press the <ENTER> button without entering any text
z
to keep the default name ([USER1 - 3]).
[PICTURE] menu
ENGLISH
- 51
Settings
POSITION
LANGUAGE
PROFILE DELETE
USER1
USER2
USER3
ALL DELETE
PROFILE DELETE
DELETE THE USER 1 DATA.
CANCELOK
POSITION
LANGUAGE
PROFILE NAME CHANGE
USER1
USER2
USER3
PROFILE NAME INPUT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcde fghijklm
nopqrstuvwxyz
1234567890
!"#$%&'
＊ +-/=?@\^
_`|~()<>[]{},.:;
ALL DELETE
SPACE
OK CANCEL
SCENE1
●
Deleting a prole
Press the ▲▼ buttons to select [PROFILE 1)
DELETE] and press the <ENTER> button.
The [PROFILE DELETE] menu is displayed.
z
Press the ▲▼ buttons to select the prole 2)
to be deleted and press the <ENTER>
button.
Select [ALL DELETE] to delete all proles.
z
The [PROFILE DELETE] conrmation message
z
is displayed.
Select [OK] with the 3)
buttons.
▲
▼
●
Changing a prole name
Press the ▲▼ buttons to select [PROFILE 1)
NAME CHANGE] and press the <ENTER>
button.
The [PROFILE NAME CHANGE] menu is
z
displayed.
Press the ▲▼ buttons to select the 2)
prole name to be changed and press the
<ENTER> button.
The [PROFILE NAME INPUT] screen is
z
displayed.
Press the <ENTER> button.4)
Note
If all proles are deleted, the system returns to the
z
[COLOUR MANAGEMENT] menu.
Press the ▲▼◄► buttons to specify the 3)
location of the required character and
press the <ENTER> button.
You can enter up to 14 characters.
z
Select [ALL DELETE] and press the <ENTER>
z
button to erase all input text. If you press the
<DEFAULT> button on the remote control, you
can erase the character currently selected by
the cursor in the input box.
Press the ▲▼◄► buttons to select [OK].4)
Press the <ENTER> button.5)
Note
Press the <ENTER> button without entering any text to
z
keep the default name ([USER1-3]).
[PICTURE] menu
52 -
ENGLISH
Settings
Loading saved proles
●
Select a saved prole (color adjustment result). The
adjustment values set in the prole are applied to the
[PICTURE MODE] menu and recorded.
■[CINEMA REALITY]
You can switch the automatic image synchronizer on/off for
24 frames a second images, such as movies.
Press the ▲▼ buttons to select [PROFILE].1)
Use the 2)
[NORMAL] [USER1]
[USER3] [USER2]
[NORMAL]
[USER]
[1] to [3]
buttons to switch the prole.
▲
▼
Default setting.
Displayed when prole is saved.
[ ■x.v.Colour]
You can switch on/off the automatic adjustment system for
signals which comply with HDMI standard (x.v.Ycc).
Switch settings Switch settings
[ON] Active
[OFF] Inactive
Note
This function is only available when a signal supporting
z
HDMI standards (x.v.Ycc) is input via an HDMI input
terminal and [PICTURE MODE] is set to [REC709].
Switch settings Switch settings
[ON] Cinema reality active
[OFF] Cinema reality inactive
Note
[CINEMA REALITY] is effective only with interlace
z
signals.
■[TV-SYSTEM]
[Only during VIDEO or S-VIDEO signal input]
The projector automatically detects the input signal but if
an unstable signal is input, set the system manually. Set
with a system format that matches the input signal.
Switch settings Switch settings
The settings change as follows each time the button
is pressed.
[AUTO] [NTSC]
[SECAM] [NTSC4.43]
■[DETAIL CLARITY]
You can adjust the detail clarity system levels.
Reduce the
effect
Setting range: 0 to +7
z
Strengthen the
effect
[PAL-N] [PAL]
[PAL-M]
Attention
Set this to [AUTO] under normal conditions.
z
Switch the settings to the respective TV signal formats.
z
Note
Setting [AUTO] will automatically select NTSC,
z
NTSC4.43, PAL, PAL-M, PAL-N, SECAM, or PAL60.
[PICTURE] menu
ENGLISH
- 53
Settings
POSITION
LANGUAGE
PICTURE MEMORY
MEMORY SAVE
MEMORY LOAD
MEMORY DELETE
MEMORY NAME CHANGE
POSITION
LANGUAGE
MEMORY SAVE
ƭ
MEMORY1
Ƭ
MEMORY2
ƭ
MEMORY3
ƭ
MEMORY4
ƭ
MEMORY5
1/2
MEMORY SAVE
SAVE THE ADJUSTED VALUE AS MEMORY 1.
CANCELOK
MEMORY NAME INPUT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcde fghijklm
nopqrstuvwxyz
1234567890
!"#$%&'
＊ +-/=?@\^
_`|~()<>[]{},.:;
ALL DELETE
SPACE
OK CANCEL
■[RGB/YCBCR], [RGB/YPBPR]
Set this to [AUTO] under normal conditions. If images are
not displayed correctly when this is set to [AUTO], set
either [RGB] or [YC
input signal.
Switch settings Switch settings
The settings change as follows each time the button
is pressed.
[AUTO] [RGB]
[YPBPR] [YCBCR]
When using COMPUTER input
●
When using 480i, 480p, 576i, 576p, or VGA60 input:
z
Select from [AUTO], [RGB], [YCBCR].
When using a movie based signal input other than
z
described above:
Select from [AUTO], [RGB], [YPBPR].
When using an HDMI 1/2 input
●
When using a 480p or 576p input:
z
Select from [AUTO], [RGB], [YCBCR].
When using a movie based signal input other than
z
described above:
Select from [AUTO], [RGB], [YPBPR].
], [YPBPR] in accordance with the
BCR
[PICTURE MEMORY]
Press the <ENTER> button.
The [PICTURE MEMORY] menu is displayed.
z
■[MEMORY SAVE]
Values set (adjustment values) for videos can be
saved as favorites.
: Memory with data already stored.
★
: No data stored
☆
Press the ▲▼ buttons to select the 1)
number to be saved and press the
<ENTER> button.
The [MEMORY SAVE] conrmation message is
z
displayed.
Note
See “List of compatible signals” for signal details.
z
(
page 86)
In some cases the projector may not operate correctly
z
with some connected devices.
These cannot be selected using COMPONENT input
z
terminals.
Select [OK] with the 2)
buttons.
▲
▼
Press the <ENTER> button.3)
[MEMORY NAME INPUT] screen is displayed.
z
Press the ▲▼◄► buttons to specify the 4)
location of the required character and
press the <ENTER> button.
You can enter up to 16 characters.
z
Select [ALL DELETE] and press the <ENTER>
z
button to erase all input text. If you press the
<DEFAULT> button on the remote control, you can
erase the character currently selected by the cursor
in the input box.
[PICTURE] menu
54 -
ENGLISH
Settings
POSITION
LANGUAGE
MEMORY LOAD
MEMORY1
MEMORY2
MEMORY3
MEMORY4
MEMORY5
1/2
POSITION
LANGUAGE
MEMORY DELETE
MEMORY1
MEMORY2
MEMORY3
MEMORY4
MEMORY5
1/2
MEMORY DELETE
DELETE THE MEMORY 1 DATA.
CANCELOK
POSITION
LANGUAGE
MEMORY NAME CHANGE
MEMORY1
MEMORY2
MEMORY3
MEMORY4
MEMORY5
1/2
MEMORY NAME INPUT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcde fghijklm
nopqrstuvwxyz
1234567890
!"#$%&'
＊ +-/=?@\^
_`|~()<>[]{},.:;
ALL DELETE
SPACE
OK CANCEL
Press the ▲▼◄► buttons to select [OK].5)
Press the <ENTER> button.6)
Note
Press the <ENTER> button without entering any text to
z
keep the default name ([MEMORY1-16]).
■[MEMORY LOAD]
You can access the details saved through [MEMORY
SAVE].
Press the ▲▼ buttons to select the 1)
memory name to be called.
Press the <ENTER> button.2)
The video adjustments for the recalled memory
z
name are switched to.
Note
If there is no saved setting in the [MEMORY SAVE] or
z
[ALL DELETE] has been performed, the [MEMORY
LOAD] menu will not be selectable.
For details how to access with the remote control, see
z
“Loading a saved setting” in “Remote control operation”.
(
page 32)
■[MEMORY DELETE]
You can delete memory entries.
■[MEMORY NAME CHANGE]
You can edit the memory name settings.
Press the ▲▼ buttons and select the 1)
memory name to be changed.
Press the <ENTER> button.2)
The [MEMORY NAME INPUT] screen is displayed.
z
Press the ▲▼◄► buttons to specify 3)
the location of the required character to
enter and press the <ENTER> button.
You can enter up to 16 characters.
z
Select [ALL DELETE] and press the <ENTER>
z
button to erase all input text. If you press the
<DEFAULT> button on the remote control, you can
erase the character currently selected by the cursor
in the input box.
Press the ▲▼ buttons and select the 1)
memory name to be deleted.
Press the <ENTER> button.2)
Select [ALL DELETE] to delete all memory entries.
z
[MEMORY DELETE] conrmation message is
z
displayed.
Select [OK] with the ◄ ► buttons.3)
Press the <ENTER> button.4)
Press the ▲▼◄► buttons to select [OK].4)
Press the <ENTER> button.5)
Note
Press the <ENTER> button without entering any text to
z
keep the default name ([MEMORY1-16]).
SIGNAL MODE
(Available with signals from COMPUTER IN/
COMPONENT IN/HDMI IN only.)
The name of the signal being projected is displayed.
Note
See “List of compatible signals” for signal details.
z
(
page 86)
[POSITION] menu
ENGLISH
- 55
Settings
[POSITION] menu
Remote control
Projector controls
Select [POSITION] from the main menu in
“Navigating through the menu” (
choose an item from the submenu.
After selecting an item, use the
z
screen position.
page 34) and
to adjust the
▲
▼
[H-POSITION]
If the position of the picture projected on the screen
deviates when the relative position of the projector
and the screen is correctly set, move the picture
position horizontally.
[DOT CLOCK]
This reduces noise that occurs when projecting
striped patterns.
When the kind of striped pattern shown below is
projected, periodic noise sometimes occurs. In such
cases, use the
the least noise.
Note
Clock adjustment is feasible for COMPUTER (RGB)
z
signal input other than 480i, 576i, 480p, and 576p.
Attention
[DOT CLOCK] needs to be adjusted before adjusting the
z
[CLOCK PHASE].
buttons to adjust to the setting with
▲
▼
[CLOCK PHASE]
Moving left
Moving right
[V-POSITION]
If the position of the picture projected on the screen
deviates when the relative position of the projector
and the screen is correctly set, move the picture
position vertically.
Moving
downward
Moving upward
[Available with signals from COMPUTER IN/
COMPONENT IN only]
If ickering of the image or bleeding of contours
occurs, make adjustments to ensure the optimum
image display.
Use the ◄ ► buttons to adjust noise so that it is not
prominent.
Note
If the projecting signal’s dot clock frequency is higher
z
than 154 MHz, adjusting [DOT CLOCK] or [CLOCK
PHASE] may not eliminate noise.
[CLOCK PHASE] cannot be adjusted when a 480i or 576i
z
COMPONENT (YC
[CLOCK PHASE] cannot be adjusted when a 480i or 576i
z
COMPUTER (RGB) signal is input.
When using digital signal input, adjustment is not
z
feasible.
) signal is input.
BCR
[POSITION] menu
56 -
ENGLISH
Settings
[ASPECT]
You can switch the image aspect ratio manually when
needed.
Aspect ratio depends on signals.
Switch settings Switch settings
When a VIDEO/S-VIDEO signal is input
■
[NTSC/NTSC4.43/PAL-M/PAL60 input]
[AUTO] [4:3] [16:9]
[ZOOM] [JUST] [S16:9]
Note
[AUTO] is enabled only when an NTSC signal is input for
z
both VIDEO and S-VIDEO signals.
[PAL/PAL-N/SECAM input]
[16:9]
[4:3] [JUST] [ZOOM2]
[S16:9]
[14:9]
[ZOOM1]
■
COMPONENT signal (YC
/YPBPR) /
BCR
COMPUTER (RGB) signal
[1 080/60i, 1 080/50i, 1 080/60p, 1 080/50p,
1 080/24p, 720/60p, 720/50p input]
[16:9] [S16:9] [H-FIT]
[4:3] [ZOOM] [V-FIT]
[480i/480p input]
[AUTO] [4:3] [16:9]
[ZOOM] [JUST] [S16:9]
[576i/576p input]
[16:9]
[4:3] [JUST] [ZOOM2]
Attention
If a 4:3 aspect video is projected at a 16:9 aspect ratio,
z
the edges may not be visible or the shape of the image
may change. Please project videos intended by the
author for 4:3 projection at that aspect ratio.
[S16:9]
[14:9]
[ZOOM1]
When a COMPUTER (RGB) signal is
■
input
[4:3] [16:9]
Note
If using a 1 280 × 720/60, 1 280 × 768/60, 1 280 x
z
800/60, WXGA+60, 1 920 x 1 080/50, 1 920 x 1 080/60,
or WUXGA60RB signal, the aspect ratio is xed so this
cannot be switched.
HDMI
■
[1 080/60i, 1 080/50i, 1 080/60p, 1 080/50p,
1 080/24p, 720/60p, 720/50p input]
[16:9] [S16:9] [H-FIT]
[4:3] [ZOOM] [V-FIT]
[480p input]
[16:9] [S16:9] [JUST]
[4:3] [ZOOM]
Note
If an aspect ratio that differs from the one used in the
z
input signal is selected, the video will look different from
the original.
If you project a copyrighted image enlarged or distorted
z
by using [ASPECT] function in commercial use in a
public place, such as a restaurant or hotel, you might
infringe on the copyright of the creator which is protected
by copyright law.
When set to [AUTO], the aspect ratio is automatically
z
switched to the optimum aspect ratio when an aspect
ratio identier is included in the input signal.
[AUTO] may not be displayed if the input signal is VIDEO
z
or COMPONENT (YC
A black area may appear at the top and bottom of the
z
screen when videos that are wider than 16:9 (cinema
vision etc.) are projected.
When a signal is input that uses overseas broadcasting
z
formats, the supported aspect ratio modes differ from the
table shown.
BCR
/YPBPR).
[576p input]
[16:9]
[4:3] [JUST] [ZOOM2]
[S16:9]
[14:9]
[ZOOM1]
[POSITION] menu
ENGLISH
- 57
Settings
Aspect Screen
[4:3]
Projects at 4:3.
[16:9]
Projects at 16:9.
(Enlarged horizontally)
Input signal
Projection screen
Input signal
Projection screen
Aspect Screen
[ZOOM]
Enlarges while
preserving original
ratio.
The projected video
may be clipped in
some cases, but
the video can be
accurately reproduced.
Use the ▲ ▼ buttons
to adjust vertically.
(Not available with
HDMI signal.)
[H-FIT]
Adjusts horizontally to
t 16:9.
(Enlarged horizontally)
Input signal
Projection screen
Input signal
Projection screen
[S16:9]
Projects a 16:9 aspect
video onto a 4:3 aspect
screen.
[JUST]
Adjusts horizontally to
t 16:9.
When projecting
a 4:3 aspect ratio
video, distortion in the
center of the screen is
reduced.
(Enlarged horizontally)
Input signal
Projection screen
Input signal
Projection screen
[V-FIT]
Adjusts vertically to t
16:9.
(Enlarged vertically)
Use the ▲ ▼ buttons
to adjust vertically.
(Not available with
HDMI signal.)
Input signal
Projection screen
[POSITION] menu
58 -
ENGLISH
Settings
[WSS]
In the European broadcasting system, if the input
signal contains an identication signal, WSS
automatically switches the aspect ratio to the required
setting. (
Switch settings Switch settings
Note
Aspect ratio switches only in the case of these input
z
signals: PAL/625i (576i)/625p (576p)
page 56)
[ON] Switch automatically
[OFF] Do not switch automatically
[OVER SCAN]
If the 4 edges of an image are partly dropped, you can
use this function to adjust and project it properly.
Note
You can correct the distortion ± 30 degrees from the
z
vertical plane. However, if there is overcorrection, the
image quality may deteriorate and become blurry. For a
better quality image, installing the projector with minimum
distortion is recommended.
The result of the keystone correction will affect the size of
z
the image.
Keystone correction does not function on the menu
z
screen.
When adjustment with [KEYSTONE] carried out, the
z
vertical center of the screen and the lens need to be
realigned.
Some distortion may occur due to lens shift adjustment.
z
The result of the keystone correction may affect the
z
aspect ratio.
[AUTO SETUP]
(COMPUTER IN only)
When you select [AUTO SETUP] and then press the
<ENTER> button, [H-POSITION], [V-POSITION],
[DOT CLOCK], and [CLOCK PHASE] are adjusted
automatically in accordance with the input signal.
Shrink image
Setting range: 0 to +10
z
Note
COMPUTER signal (exc. movie based signals) is not
z
supported.
Enlarge image
[KEYSTONE]
If the projector is aligned non-perpendicularly to the
screen, or if the projection screen has an angled
surface, you can correct the keystone vertically.
Image Operation
Setting range: −32 to +32
z
[POSITION] menu
ENGLISH
- 59
Settings
POSITION
LANGUAGE
OPTION
SCREEN AREA MEMORY
MEMORY LOAD
MEMORY SAVE
MEMORY EDIT
AUTO SWITCHING
H-AREA POSITION
V-AREA POSITION
LEFT MASKING AREA
RIGHT MASKING AREA
UPPER MASKING AREA
LOWER MASKING AREA
ASPECT
0
0
0
0
0
0
16:9
POSITION
LANGUAGE
OPTION
SCREEN AREA MEMORY LOAD
MEMORY1
MEMORY2
MEMORY3
MEMORY4
MEMORY5
MEMORY6
POSITION
LANGUAGE
OPTION
SCREEN AREA MEMORY SAVE
ƭ
MEMORY1
Ƭ
MEMORY2
ƭ
MEMORY3
ƭ
MEMORY4
ƭ
MEMORY5
ƭ
MEMORY6
SCREEN AREA MEMORY SAVE
SAVE THE ADJUSTED VALUE AS MEMORY 1.
CANCELOK
SCREEN AREA MEMORY NAME INPUT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcde fghijklm
nopqrstuvwxyz
1234567890
!"#$%&'
＊ +-/=?@\^
_`|~()<>[]{},.:;
ALL DELETE
SPACE
OK CANCEL
[SCREEN AREA MEMORY]
Press the <ENTER> button to display the [SCREEN
AREA MEMORY] menu.
[ ■MEMORY LOAD]
You can recall horizontal and vertical video
z
positions, mask amount adjustment values, and
aspect settings saved with [MEMORY SAVE]
(
page 59).
[ ■MEMORY SAVE]
This enables saving horizontal video position,
vertical video position, adjustment for amount of
mask, and aspect settings.
: Memory with data already stored.
★
: No data stored
☆
Press the ▲▼ buttons to select the 1)
memory to be saved.
Press the <ENTER> button.2)
The [SCREEN AREA MEMORY SAVE] conrmation
z
message is displayed.
Press the ▲▼1) buttons to select the
memory name to be recalled.
Press the <ENTER> button.2)
The video adjustments for the recalled memory are
z
switched to.
Note
If a setting is not saved using [MEMORY SAVE] or all
z
memories are deleted using [MEMORY DELETE] in the
[SCREEN AREA MEMORY] menu, the [MEMORY LOAD]
menu will not be displayed.
Select [OK] with the ◄ ► buttons.3)
Press the <ENTER> button.4)
[SCREEN AREA MEMORY NAME INPUT] screen
z
is displayed.
Press the ▲▼ ◄ ► buttons to specify 5)
the location of the required character and
press the <ENTER> button.
You can enter up to 16 characters.
z
Select [ALL DELETE] and press the <ENTER>
z
button to erase all input text. If you press the
<DEFAULT> button on the remote control, you can
erase the character currently selected by the cursor
in the input box.
Press the ▲▼ ◄ ► buttons to select 6)
[OK].
Press the <ENTER> button.7)
Note
Press the <ENTER> button without entering any text to
z
keep the default name ([MEMORY1-6]).
[POSITION] menu
60 -
ENGLISH
Settings
POSITION
LANGUAGE
OPTION
SCREEN AREA MEMORY EDIT
MEMORY DELETE
MEMORY NAME CHANGE
POSITION
LANGUAGE
OPTION
SCREEN AREA MEMORY DELETE
MEMORY1
MEMORY2
MEMORY3
MEMORY4
MEMORY5
MEMORY6
ALL DELETE
SCREEN AREA MEMORY DELETE
DELETE THE MEMORY 1 DATA.
CANCELOK
POSITION
LANGUAGE
OPTION
SCREEN AREA MEMORY NAME CHANGE
SCREEN 1
MEMORY2
MEMORY3
MEMORY4
MEMORY5
MEMORY6
SCREEN AREA MEMORY NAME INPUT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcde fghijklm
nopqrstuvwxyz
1234567890
!"#$%&'
＊ +-/=?@\^
_`|~()<>[]{},.:;
ALL DELETE
SPACE
OK CANCEL
[ ■MEMORY EDIT]
You can delete memory entries and edit the memory
name settings.
[MEMORY DELETE]
z
Press the ▲ ▼ buttons and select the 1)
memory name to be deleted.
z
[MEMORY NAME CHANGE]
Press the ▲▼ buttons to select the 1)
memory name to be changed.
Press the <ENTER> button.2)
[SCREEN AREA MEMORY NAME INPUT]
z
screen is displayed.
Select [ALL DELETE] to delete all memory
z
entries.
Press the <ENTER> button.2)
The [SCREEN AREA MEMORY DELETE]
z
conrmation message is displayed.
Select [OK] with the ◄ ► buttons.3)
Press the <ENTER> button.4)
Press the ▲▼ 3) ◄ ► buttons to specify
the location of the required character
and press the <ENTER> button.
You can enter up to 16 characters.
z
Select [ALL DELETE] and press the <ENTER>
z
button to erase all input text. If you press the
<DEFAULT> button on the remote control, you
can erase the character currently selected by
the cursor in the input box.
Press the ▲▼ 4) ◄ ► buttons to select
[OK].
Press the <ENTER> button.5)
Note
Press the <ENTER> button without entering any text to
z
keep the default name ([MEMORY1-6]).
[POSITION] menu
ENGLISH
- 61
Settings
SCREEN AREA MEMORY AUTO SWITCHING
2.35:1 IMAGE DETECTION
16:9 IMAGE DETECTION
OFF
OFF
POSITION
LANGUAGE
OPTION
AUTO SWITCHING
■
[
]
This function automatically identies wide signal*1 or
16:9/4:3 and automatically recalls memory settings
that have been set for each screen size.
*1 : Wide signals are 2.35:1,
2.40:1, 2.50:1, 2.55:1 aspect signals.
Use the ▲▼ buttons to select the item 1)
for automatic identication.
Press the ◄ ► buttons to select 2)
the required memory for automatic
identication.
The memory setting which has been selected for
z
[2.35:1 IMAGE DETECTION] is loaded after a
given period of time once the input signal switches
from 16:9/4:3 to 2.35:1.
The memory setting which has been selected for
z
[16:9 IMAGE DETECTION] is loaded after a given
period of time once the input signal switches from
2.35:1 to 16:9/4:3.
If [OFF] is selected, automatic identication will not
z
be performed.
This function is not available when [ZOOM] or
z
[V-FIT] is selected from the [ASPECT] menu.
Note
If the memory is not registered using [MEMORY SAVE] in
z
the [SCREEN AREA MEMORY] menu, you cannot select
[AUTO SWITCHING].
When displaying the menu or test pattern, automatic
z
identication is not performed.
Images may not be correctly recognized if there is noise
z
in the picture or external device generates noise. Image
size may also not be correctly recognized depending on
the video.
Image size may not be correctly recognized if the input
z
signal level from the external device is not set to the
suggested value range. In this case, adjust the input
signal level using the [WAVEFORM MONITOR] menu.
(
page 39)
Image size may not be correctly recognized if the screen
z
position is not correctly adjusted.
In this case, adjust the screen position using the
[POSITION] menu. (
page 55)
H-AREA POSITION
■[
]
You can move the frame area horizontally, such as
aligning the right or left frame edge to the screen
edge.
Moving left
Moving right
For example, when projecting an overscanned 16:9
projection area at a 4:3 aspect ratio on a 4:3 aspect
screen, you can adjust the horizontal discrepancy
between the screen position and the video display
position.
16:9 projection area
4:3 video display position
V-AREA POSITION
[
■
]
4:3 screen
You can move the frame area vertically, such as
aligning the top or bottom frame edge to the screen
edge.
Moving
downward
Moving upward
For example, when projecting an overscanned 16:9
projection area at a 2.35:1 cinema scope screen
movie on a 2.35:1 size cinema scope screen, you can
adjust the vertical discrepancy between the screen
position and the video display position.
2.35:1 cinema scope screen
16:9 projection area
2.35:1 cinema scope screen
size video display position
[POSITION] menu
62 -
ENGLISH
Settings
LEFT MASKING AREA
[
■
You can place a blank (mask) area in the left side
edge on the screen.
Less More
Setting range: 0 to 70
z
RIGHT MASKING AREA
[
■
You can place a blank (mask) area in the right side
edge on the screen.
Less More
Setting range: 0 to 70
z
]
]
UPPER MASKING AREA
[
■
You can place a blank (mask) area in the upper side
edge on the screen.
Less More
Setting range: 0 to 70
z
LOWER MASKING AREA
[
■
You can place a blank (mask) area in the lower side
edge on the screen.
Less More
Setting range: 0 to 70
z
Note
If it is set to [0], each masking function will be invalid.
z
The [MASKING AREA] function will be invalid when
z
adjusting the [COLOUR MANAGEMENT] or [SPLIT
ADJUST] settings, when displaying the [TEST PATTERN]
or [WAVEFORM MONITOR], or when no signal is
detected.
]
]
ASPECT
■
The aspect ratio for the current video is displayed.
Note
See “[ASPECT]” for ASPECT details. (
z
page 56)
[OPTION] menu
ENGLISH
- 63
Settings
[OPTION] menu
Remote control
Projector controls
ON-SCREEN DISPLAY
INPUT GUIDE
OSD DESIGN
OSD POSITION
DETAILED
TYPE1
CENTRE
POSITION
LANGUAGE
OPTION
Select [OPTION] from the main menu of
“Navigating through the menu” (
page 34),
and choose an item from the submenu.
Select item and use the ◄ ► buttons to switch the
z
settings.
[ON-SCREEN DISPLAY]
This enables setup related to on-screen display.
Press the <ENTER> button.
The [ON-SCREEN DISPLAY] menu is displayed.
z
■[OSD DESIGN]
Set the color of the on-screen menu.
Switch settings Switch settings
[TYPE1] Display using normal design
[TYPE2]
Display using black and white
design
■[OSD POSITION]
You can change the displaying position of the on-screen
menu.
Switch settings Switch settings
[CENTRE]
Display in the center of the
projection screen
[ ■INPUT GUIDE]
Set the display method for the currently selected input port
name. This is displayed in the top right of the screen when
the <INPUT SELECT> button is pressed. (
Switch settings Switch settings
[DETAILED]
Display the input terminal
graphically
[OFF] Turn off the guidance
[SIMPLE]
Display the name of input
terminal only
page 33)
[LOWER LEFT]
Display in the bottom left
of the projection screen
Display in the bottom
[LOWER CENTRE]
center of the projection
screen
[LOWER RIGHT]
[UPPER LEFT]
[UPPER CENTRE]
[UPPER RIGHT]
Display in the bottom right
of the projection screen
Display in the upper left of
the projection screen
Display in the upper center
of the projection screen
Display in the upper right
of the projection screen
[BACK COLOUR]
Set the color of the projection screen when no signal
is input.
Switch settings Switch settings
[BLUE]
[BLACK]
Display the whole projection
screen blue
Display the whole projection
screen black
[OPTION] menu
64 -
ENGLISH
Settings
[STARTUP LOGO]
You can switch the Panasonic logo that is displayed
when starting up the projector on/off.
Switch settings Switch settings
[ON] Active
[OFF] Inactive
Note
The logo Panasonic is displayed for 15 seconds.
z
[AUTO SEARCH]
Sets whether to automatically search for terminals
that have an input signal when the projector is turned
on.
Switch settings Switch settings
[FRAME RESPONSE]
Switch this setting when a progressive signal is
input and you wish to reduce the time taken from the
signal being input to the video being displayed on the
screen.
Switch settings Switch settings
[NORMAL] Prioritizes the image quality
[FAST] Prioritizes the frame response
Note
[NORMAL] allows higher quality image viewing.
z
[PROJECTION METHOD]
Set the projection method according to the projector
installation status. Change the projection method if
the screen is displayed upside down or the display is
reversed. (
page 20)
[ON] Active
[OFF] Inactive
Attention
Set this to [ON] under normal circumstances.
z
When no signal is detected, the last used input will be
z
selected.
[HDMI SIGNAL LEVEL]
If video is not displayed correctly when this projector
is connected to an external device via an HDMI
connection, switch the settings.
Switch settings Switch settings
[NORMAL]
[EXPAND]
Signal level used by general
external devices
Expanded signal level used by
some devices
Switch settings Switch settings
[FRONT/DESK]
[FRONT/
CEILING]
[REAR/DESK]
[REAR/
CEILING]
When setting on a desk/oor and
projecting from the front
When using the ceiling mount
bracket (optional accessory) and
projecting from the front
When setting on a desk/oor and
projecting from the rear (using a
translucent screen)
When using the ceiling mount
bracket (optional accessory) and
projecting from the rear (using a
translucent screen)
Note
This may not work correctly with some external devices,
z
and problems such as video not being displayed may
occur.
[OPTION] menu
ENGLISH
- 65
Settings
ON-SCREEN DISPLAY
BACK COLOUR
STARTUP LOGO
AUTO SEARCH
HDMI SIGNAL LEVEL
FRAME RESPONSE
PROJECTION METHOD
TRIGGER 1 SETTING
TRIGGER 2 SETTING
HIGH ALTITUDE MODE
LAMP POWER
ECO MANAGEMENT
FUNCTION BUTTON
VIERA LINK SETTINGS
BLUE
ON
ON
NORMAL
NORMAL
FRONT/DESK
OFF
OFF
OFF
NORMAL
POSITION
LANGUAGE
OPTION
1/2
TRIGGER 1 SETTING
OFF
OUTPUT
POWER ON
SCREEN AREA MEMORY 1
SCREEN AREA MEMORY 2
SCREEN AREA MEMORY 3
SCREEN AREA MEMORY 4
SCREEN AREA MEMORY 5
SCREEN AREA MEMORY 6
BLANK
DELAY TIME
INPUT
POWER ON/OFF
SELECT 4:3 ASPECT
SELECT 16:9 ASPECT
SELECT S16:9 ASPECT
SELECT JUST ASPECT
SELECT ZOOM ASPECT
SELECT H-FIT ASPECT
SELECT V-FIT ASPECT
RS-232C COMMAND LINK
0 SEC.
BLANK
POSITION
LANGUAGE
OPTION
[TRIGGER 1/2 SETTING]
You can set the function for each trigger terminal.
Attention
Make sure the <MAIN POWER> switch of the projector
z
is turned <OFF> before a cable is connected to or
disconnected from a trigger terminal.
[OUTPUT]
■
In conjunction with projector operation set in the [TRIGGER
1 SETTING]/[TRIGGER 2 SETTING] menu, a trigger
output signal is sent to an external device with a trigger
terminal to enable control.
[INPUT]
■
Receipt of a trigger input signal from an external device
enables control of projector operation setup in the
[TRIGGER 1 SETTING]/[TRIGGER 2 SETTING] menu.
Press the ▲▼◄► buttons to select 2)
the input/output function and press the
<ENTER> button.
Function settings
z
Unable to transmit the
trigger output signal. Does
[OFF]
Output
z
[POWER ON]
[SCREEN AREA
MEMORY 1]
[SCREEN AREA
MEMORY 2]
[SCREEN AREA
MEMORY 3]
[SCREEN AREA
MEMORY 4]
[SCREEN AREA
MEMORY 5]
[SCREEN AREA
MEMORY 6]
[BLANK]
not function even if trigger
input signal is received.
(Trigger input signal can
be received.)
[SELECT 4:3
ASPECT]
[SELECT 16:9
ASPECT]
[SELECT S16:9
ASPECT]
[SELECT JUST
ASPECT]
[SELECT ZOOM
ASPECT]
[SELECT H-FIT
ASPECT]
[SELECT V-FIT
ASPECT]
[RS-232C COMMAND
LINK]
Use the ▲▼ buttons to select [TRIGGER 1)
1 SETTING] or [TRIGGER 2 SETTING] and
press the <ENTER> button.
The [TRIGGER SETTING] menu is displayed.
z
When the item which is set in the [TRIGGER
1 SETTING]/[TRIGGER 2 SETTING] menu is
chosen or executed in the projector, 12 V is output
from a trigger terminal.
Note
When [AUTO] is selected in the [ASPECT] menu of
z
[POSITION], video is automatically displayed using either
4:3 or 16:9 aspect ratio depending on the input signal,
so if this aspect ratio matches the settings made in
[TRIGGER 1 SETTINGS] or [TRIGGER 2 SETTINGS] 12
V is output.
[BLANK]•
When [BLANK] is activated, output is 12 V. If the
setting is released, output is 0 V.
[RS-232C COMMAND LINK]•
Receives commands (
page 88) from external
device and outputs 12 V.
[OPTION] menu
66 -
ENGLISH
Settings
Input
z
[POWER ON/OFF] [BLANK]
[POWER ON/OFF]•
If the trigger input signal from the external device is
changed from 0 V to 12 V, the projector power will be
switched on. And if it is changed from 12 V to 0 V, the
power will be switched off.
[BLANK]•
If the trigger input signal from the external device is
changed from 0 V to 12 V, the screen will go blank. And
if it is changed from 12 V to 0 V, the [BLANK] setting
will be released.
Press the ▲▼◄► buttons to move the 3)
cursor to [DELAY TIME]
[HIGH ALTITUDE MODE]
Set to [ON] when using at locations between 1400 m
and 2 700 m above sea level.
Switch settings Switch settings
[OFF]
[ON]
When using at an altitude of less
than 1 400 m above sea level
When using at high altitudes
(between 1 400 m and 2 700 m
above sea level)
Press the ◄► buttons to set the delay 4)
time for the trigger output signal
The delay time can be set to 2, 4, 6, 8, 10, 20, and
z
30 seconds.
It is possible to delay the trigger output signal (12 V)
z
by the amount of time set. (Only available if trigger
output item is selected.)
E.g.) Select [SELECT 4:3 ASPECT] of the trigger output
function and set the delay time to 10 seconds.
Set the [ASPECT] in the [POSITION] menu to [4:3],
and 12V is output from the trigger port after 10
seconds.
Note
You should not use trigger terminal output as the power
z
source for other devices.
The projector will not accept trigger input while preparing
z
to project after the power has been switched on and
while preparing to shutdown after projection. Input trigger
signals after projection starts or after entering standby
mode.
12 V cannot be output from the trigger terminal when the
z
projector is in standby mode.
Note
The fan rotation and operating noise increases if set to
z
[ON].
[LAMP POWER]
Switch the lamp intensity according to the usage
environment of the projector and its intended use.
Switch settings Switch settings
[NORMAL]
[ECO]
Note
The brightness in the [ECO] settings is lowered
z
enabling saving power and reducing operating noise. It
is recommended that you use the [ECO] setting when
viewing in a place where natural light is blocked and
there is no articial light.
When no input signal is detected, the function is disabled.
z
When higher luminance is
required
When lower luminance is
sufcient
[OPTION] menu
ENGLISH
- 67
