OWNER’S MANUAL

Network 3D Blu-ray Disc™ / DVD Player

Please read this manual carefully before operating your set and retain it for future reference.

BP325 / BP325N

P/NO : MFL67475851_1.0

Getting Started2

Safety Information

Getting Started

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK) NO

USER-SERVICEABLE PARTS INSIDE REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

enclosure that may be of sucient magnitude to constitute a risk of electric shock to persons.

instructions in the literature accompanying the product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

CAUTION: The apparatus shall not be exposed to water (dripping or splashing) and no objects lled with liquids, such as vases, shall be placed on the apparatus.

WARNING: Do not install this equipment in a conned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings shall be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing)

Use of controls, adjustments or the performance of procedures other than those specied herein may result in hazardous radiation exposure.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a dedicated circuit;

That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specication page of this owner’s manual to be certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or re. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service centre. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible.

NOTICE: For safety marking information including product identication and supply ratings, please refer to the main label on the bottom or rear of the apparatus.

CAUTION: Only use the AC adapter supplied with this device. Do not use a power supply from another device or another manufacturer. Using any other power cable or power supply may cause damage to the device and void your warranty.

Getting Started 3

This device is equipped with a portable battery or accumulator.

Safety way to remove the battery or the battery from the equipment: Remove the

old battery or battery pack, follow the steps in reverse order than the assembly. To prevent contamination of the environment and bring on possible threat to human and animal health, the old battery or the battery put it in the appropriate container at designated collection points. Do not dispose of batteries or battery together with other waste. It is recommended that you use local, free reimbursement systems batteries and accumulators. The battery shall not be exposed to excessive heat such as sunshine, re or the like.

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.

2. All electrical and electronic products shall be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.

4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.

Disposal of waste batteries/accumulators

1. When this crossed-out wheeled bin symbol is attached to batteries/ accumulators of Your product it means they are covered by European Directive 2006/66/EC.

2. This symbol may be combined with chemical symbols for mercury(Hg), cadmium(Cd) or lead(Pb) if the battery Contains more that 0.0005% of mercury, 0.002% of cadmium or

0.004% of lead.

3. All batteries/accumulators should be disposed separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

4. The correct disposal of Your old batteries/ accumulators will help to prevent potential negative consequences for the environment, animal and human health.

5. For more detailed information about disposal of Your old batteries/ accumulators, please contact Your city offi ce, waste disposal service or the shop where You purchased the product.

Getting Started

Getting Started4

LG Electronics hereby declares that this/these product(s) is/are

requirements and other relevant provisions of Directive 2004/108/EC, 2006/95/EC and 2009/125/

EC.

Getting Started

European Standards Centre:

Krijgsman 1, 1186 DM Amstelveen, The Netherlands

yPlease note that this is NOT a Customer Service

contact point. For Customer Service Information, see Warranty Card or contact the dealer that you purchased this product.

in compliance with the essential

Notes on Copyrights

yBecause AACS (Advanced Access Content

System) is approved as content protection system for Blu-ray Disc format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analog signal output, etc., of AACS protected contents. The operation of this product and restrictions on this product may vary depending on your time of purchase as those restrictions may be adopted and/or changed by AACS after the production of this product.

yFurthermore, BD-ROM Mark and BD+ are

additionally used as content protection systems for Blu-ray Disc format, which imposes certain restrictions including playback restrictions for BD-ROM Mark and/or BD+ protected contents. To obtain additional information on AACS, BDROM Mark, BD+, or this product, please contact an authorized Customer Service Centre.

yMany BD-ROM/DVD discs are encoded with

copy protection. Because of this, you should only connect your player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected discs.

yThis product incorporates copyright protection

technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi. Reverse engineering or disassembly is prohibited.

yUnder the U.S. Copyright laws and Copyright

laws of other countries, unauthorized recording, use, display, distribution, or revision of television programs, videotapes, BD-ROM discs, DVDs, CDs and other materials may subject you to civil and/ or criminal liability.

Important Notice for TV colour system

The colour system of this player diers according to currently playing discs.

For example, when the player plays the disc recorded in the NTSC colour system, the image is output as an NTSC signal.

Only the multi system colour TV can receive all signals output from the player.

yIf you have a PAL colour system TV, you will see

just distorted images when using discs or video contents recorded in NTSC.

yThe multi system colour TV changes the colour

system automatically according to input signals. In case that the colour system is not changed automatically, turn it o and then on to see normal images on screen.

yEven if the disc recorded in NTSC colour system

are well displayed on your TV, these may not be recorded correctly on your recorder.

Caution

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a movie

in 3D mode for inrm, child and pregnant woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing content in 3D, it is strongly recommended to stop the playback and rest until you feel normal.

Getting Started 5

Getting Started

Table of Contents6

Table of Contents

1 Getting Started

2 Safety Information 8 Introduction 8 – Playable discs and symbols used in

this manual

9 – About the “7” symbol display 9 – Compatibility notes 10 – File requirement 11 – AVCHD (Advanced Video Codec High

Definition) 12 – Certain system requirements 12 – Regional code 12 – System select 13 Remote control 14 Front panel 14 Rear panel

2 Connecting

15 Connecting the AC adapter 15 Connecting to your TV 16 – What is SIMPLINK? 17 – Resolution setting 18 Connecting to an amplifier 18 – Connecting to an amplifier via HDMI

output 19 – Connecting to an amplifier via digital

audio output 20 Connecting to your home network 20 – Wired network connection 20 – Wired network setup 23 USB device connection 23 – Playback content in the USB device

3 System Setting

24 Settings 24 – Initial Setup 25 – Adjust the setup settings 25 – [DISPLAY] Menu 27 – [LANGUAGE] Menu 27 – [AUDIO] Menu 29 – [LOCK] Menu 30 – [NETWORK] Menu 30 – [OTHERS] Menu

4 Operating

32 General Playback 32 – Using [HOME] menu 32 – Playing a disc 32 – Playing a file on disc/USB device 33 – Playing Blu-ray 3D disc 33 – Enjoying BD-Live™ 34 – Basic operations for video and audio

content 34 – Basic operations for photo content 34 – Using the disc menu 35 – Resume playback 35 – Last scene memory 35 Advanced Playback 35 – Repeat playback 36 – Repeating a specific portion 36 – Viewing content information 36 – Changing content list view 37 – Selecting a subtitle file 37 – Options while viewing a photo 38 – Listening to music while slide show 38 On-screen display 38 – Displaying content information on-

screen 39 – Playing from selected time 39 – Selecting a subtitle language 40 – Hearing a different audio 40 – Watching from a different angle 40 – Changing the TV Aspect Ratio 41 – Changing subtitle Code Page 41 – Changing the Picture Mode 42 Using the Premium

5 Troubleshooting

43 Troubleshooting 43 – General 44 – Network 45 – Picture 45 – Customer support 45 – Open source software notice

Table of Contents 7

6 Appendix

46 Controlling a TV with the supplied remote

control

46 – Setting up the remote to control your

TV 47 Network software update 47 – Network update notification 47 – Software update 49 Area code list 50 Language code list 51 Trademarks and licenses 53 Audio output specifications 55 Specifications 56 Maintenance 56 – Handling the unit 56 – Notes on discs 57 Important information relating to network

services

Getting Started8

Introduction

Playable discs and symbols used in this manual

Getting Started

Media/Term Logo Symbol Description

yDiscs such as movies that can be purchased or

rented.

y“Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs.

yBD-R/RE discs that are recorded in BDAV format.

yBD-R/RE discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

yDiscs such as movies that can be purchased or

rented.

yMovie mode and nalized only

ySupports the dual layer disc also

Finalized AVCHD format

yDVD±R/RW discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

Blu-ray

DVD-ROM

DVD-R

DVD-RW

DVD+R

DVD+RW

(8 cm, 12 cm)

y u i

DVD-RW (VR)

(8 cm, 12 cm)

Audio CD

(8 cm, 12 cm)

CD-R/RW

(8 cm, 12 cm)

Note –

Caution –

y u i

VR mode and nalized only

Audio CD

yCD-R/RW discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

Indicates special notes and operating features.

Indicates cautions for preventing possible damages from abuse.

Note

yDepending on the conditions of the

recording equipment or the CD-R/RW (or DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW) discs cannot be played on the unit.

yDepending on the recording software & the

nalization, some recorded discs (CD-R/RW, DVD±R/RW, BD-R/RE) may not be playable.

yBD-R/RE, DVD±R/RW and CD-R/RW discs

recorded using a personal computer or a DVD or CD Recorder may not play if the disc is damaged or dirty, or if there is dirt or condensation on the player’s lens.

yIf you record a disc using a personal

computer, even if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

yThis player requires discs and recordings to

meet certain technical standards in order to achieve optimal playback quality.

yPre-recorded DVDs are automatically set to

these standards. There are many dierent types of recordable disc formats (including CD-R containing MP3 or WMA les) and these require certain pre-existing conditions to ensure compatible playback.

yCustomers should note that permission

is required in order to download MP3 / WMA les and music from the Internet. Our company has no right to grant such permission. Permission should always be sought from the copyright owner.

yYou have to set the disc format option

to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live System, you cannot use it on LG player. (Mastered/Live File System : Disc format system for windows Vista)

Getting Started 9

About the “7” symbol display

“7” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specic media.

Compatibility notes

yBecause BD-ROM is a new format, certain disc,

digital connection and other compatibility issues are possible. If you experience compatibility problems, please contact an authorized Customer Service Center.

yThis unit allows you to enjoy functions such

as picture-in-picture, secondary audio and Virtual packages, etc., with BD-ROM supporting BONUSVIEW (BD-ROM version 2 Prole 1 version

1.1). Secondary video and audio can be played from a disc compatible with the picture-inpicture function. For the playback method, refer to the instructions in the disc.

yViewing high-denition content and up-

converting standard DVD content may require a HDMI-capable input or HDCP-capable DVI input on your display device.

ySome BD-ROM and DVD discs may restrict the

use of some operation commands or features.

yDolby TrueHD, Dolby Digital Plus and DTS-HD are

supported with maximum 7.1 channels if you use HDMI connection for the audio output of the unit.

yYou can use a USB device to store some disc

related information, including downloaded online content. The disc you are using will control how long this information is retained.

Getting Started

Getting Started10

File requirement

Movie files

Getting Started

File

Location

Disc,

USB

Music files

File

Extension

“.avi”, “.divx”, “.mpg”, “.mpeg”, “.mkv ”, “.mp4”, “.asf ”, “.wmv”, “.m4v” (DRM free), “.vob”, “.3gp” , “.v”

Codec Format Audio Format Subtitle

DIVX3.xx, DIVX4.xx, DIVX5.xx, DIVX6.xx (standard playback only), XVID, MPEG1 SS, H.264/MPEG-4 AVC, MPEG2 PS, MPEG2 TS, VC-1 SM (WMV3)

Dolby Digital, DTS, MP3, WMA, AAC, AC3

SubRip (.srt / .txt), SAMI (.smi), SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), VobSub (.sub), SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/.txt), TMPlayer (.txt), DVD Subtitle System (.txt)

File

Location

Disc,

USB

Photo files

File

Location

Disc,

USB

File

Extension

“.mp3”, “.wma”, “.wav”, “.m4a” (DRM free), “.ac”

File

Extension

“.jpg”, “.jpeg”, “.png”, “.gif ”

Sampling Frequency Bitrate Note

within 32 - 48 kHz (WMA), within 16 - 48 kHz (MP3)

Recommended

Size

Less than 4,000 x 3,000 x 24 bit/pixel Less than 3,000 x 3,000 x 32 bit/pixel

within 32 - 192 kbps (WMA), within 32 - 320 kbps (MP3)

Progressive and lossless compression photo image les are not supported.

Some wav les are not supported on this player.

Note

Getting Started 11

Note

yThe le name is limited to 180 characters.

yMaximum les/Folder: Less than 2000 (total

number of les and folders)

yDepending on the size and number of the

les, it may take several minutes to read the contents on the media.

yThe le requirements on page 10 are not

always compatible. There may have some restrictions by le features.

yThis unit cannot support the ID3 Tag

embedded MP3 le.

yThe total playback time of audio le

indicated on the screen may not correct for VBR les.

yHD movie les contained on the CD/DVD or

USB 1.0/1.1 may not played properly. Blu-ray Disc or USB 2.0 are recommended to play back HD movie les.

yThis player supports H.264/MPEG-4 AVC

prole Main, High at Level 4.1. For a le with higher level, the warning message will appear on the screen.

yThis player does not support les that are

recorded with GMC

*1 GMC – Global Motion Compensation

*2 Qpel – Quarter pixel

or Qpel

Note

yA “avi” le which is encoded “WMV 9 codec”

is not supported.

yThis player supports UTF-8 les even it

contains Unicode subtitle contents. This player can not support the pure Unicode subtitle les.

yDepending on the types of le or ways of

recording, it may not play back.

yA disc which was recorded by multi-session

on normal PC is not supported on this player.

yTo be playback a movie le, movie le name

and Subtitle le name must be the same.

yIf video codec is MPEG2 TS or MPEG2 PS,

subtitle does not play back.

yThe total playback time of music le

indicated on the screen may not correct for VBR les.

AVCHD (Advanced Video Codec High Definition)

yThis player can playback AVCHD format discs.

These discs are normally recorded and used in camcorders.

yThe AVCHD format is a high denition digital

video camera format.

yThe MPEG-4 AVC/H.264 format is capable of

compressing images at higher eciency than that of the conventional image compressing format.

yThis player can playback AVCHD discs using

“x.v.Colour” format.

ySome AVCHD format discs may not play

depending on the recording condition.

yAVCHD format discs need to be nalized.

y“x.v.Colour” oers a wider colour range than

normal DVD camcorder discs.

Getting Started

Getting Started12

Certain system requirements

For high denition video playback:

yHigh denition display that has HDMI input jack.

yBD-ROM disc with high denition content.

Getting Started

yHDMI or HDCP capable DVI input on your display

device is required for some content (as specied by disc authors).

For Dolby® Digital Plus, Dolby TrueHD and DTS-HD multi-channel audio playback:

yAn amplier/receiver with a built-in (Dolby

Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD) decoder.

yMain, center, surround speakers and subwoofer

as necessary for chosen format.

Regional code

This unit has a regional code printed on the rear of the unit. This unit can play only BD-ROM or DVD discs labelled same as the rear of the unit or “ALL”.

System select

Open the disc tray using the B (OPEN/CLOSE) button and then, press and hold M (PAUSE) for more than ve seconds to change the color system (PAL /NTSC /AUTO).

Remote control

Getting Started 13

Battery installation

Remove the battery cover on the rear of the Remote Control, and insert the R03 (size AAA) battery with 4 and 5 matched correctly.

• • • • • • a • • • • • •

(POWER): Switches the player

ON or OFF.

(OPEN/CLOSE): Opens and

closes the disc tray.

0-9 numerical buttons: Selects numbered options in a menu.

CLEAR: Removes a number when setting the password.

TV Control Buttons: See page

46.

• • • • • • b • • • • •

c/v

backward or forward.

C/V

next or previous chapter / track / le.

M z Z

• • • • • • c • • • • •

HOME (n): Displays or exits the [Home Menu].

INFO/MENU (m): Displays or exits On-Screen Display.

Direction buttons: Selects an option in the menu.

ENTER (b): Acknowledges menu selection.

BACK (1): Exits the menu or returns to the previous screen.

DISC MENU: Accesses menu on a disc.

(SCAN): Searches

(SKIP): Goes to the

(PAUSE): Pauses playback.

(PLAY): Starts playback.

(STOP): Stops playback.

• • • • • • d • • • • •

REPEAT (h): Repeats a desired section or sequence.

AUDIO ([): Selects an audio language.

SUBTITLE (]): Selects a subtitle language.

TITLE/POP-UP: Displays the DVD title menu or BD-ROM’s pop-up menu, if available.

Colored (R, G, Y, B) buttons: Use to navigate BD-ROM menus. They are also used for [MOVIE], [PHOTO], [MUSIC] and [Premium] menu.

Getting Started

Getting Started14

Front panel

Getting Started

Disc Tray

Display Window

Remote Sensor

Rear panel

DC IN 12V (AC adapter input)

LAN port

(OPEN / CLOSE)

d B

(POWER)

e 1

USB Port

HDMI OUT

DIGITAL AUDIO OUT (COAXIAL)

Connecting 15

Connecting the AC adapter

Connect the unit to the power supply with the supplied AC adapter.

Rear of the unit

Plug into a

power source.

yContact an electrical parts distributor for

assistance in selecting a suitable AC plug adapteror AC cord set.

yThis AC adapter is manufactured by APD Group

Yang Ming Industrial.

Caution

Only use the AC adapter supplied with this device. Do not use a power supply from another device or manufacturer. Using any other power cable or power supply may cause damage to the device and void your warranty.

Connecting to your TV

If you have a HDMI TV or monitor, you can connect it to this player using a HDMI cable (Type A, High Speed HDMI™ Cable). Connect the HDMI jack on the player to the HDMI jack on a HDMI compatible TV or monitor.

Rear of the unit

HDMI

cable

Set the TV’s source to HDMI (refer to TV’s Owner’s manual).

Note

Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections.

Connecting

Connecting16

Additional information for HDMI

yWhen you connect a HDMI or DVI compatible

device make sure of the following:

-Try switching o the HDMI/DVI device and this player. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this player.

-The connected device’s video input is set

Connecting

correctly for this unit.

-The connected device is compatible with 720x576p, 1280x720p, 1920x1080i or 1920x1080p video input.

yNot all HDCP-compatible HDMI or DVI devices

will work with this player.

-The picture will not be displayed properly with non-HDCP device.

Note

yIf a connected HDMI device does not accept

the audio output of the player, the HDMI device’s audio sound may be distorted or may not output.

yWhen you use HDMI connection, you can

change the resolution for the HDMI output. (Refer to “Resolution Setting” on page 17)

ySelect the type of video output from the

HDMI OUT jack using [HDMI Color Setting] option on the [Setup] menu (see page

26).

yChanging the resolution when the

connection has already been established may result in malfunctions. To solve the problem, turn o the player and then turn it on again.

yWhen the HDMI connection with HDCP

is not veried, TV screen is changed to black screen. In this case, check the HDMI connection, or disconnect the HDMI cable.

yIf there are noises or lines on the screen,

please check the HDMI cable (length is generally limited to 4.5 m).

What is SIMPLINK?

Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection.

Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power O, etc.

Refer to the TV owner’s manual for the details of SIMPLINK function.

LG TV’s with SIMPLINK function has the logo as shown above.

Note

Depending on the disc type or playing status, some SIMPLINK operation may dier from your purpose or not work.

Resolution setting

The player provides several output resolutions for HDMI OUT jack. You can change the resolution using [Setup] menu.

1. Press HOME (n).

2. Use (b). The [Setup] menu appears.

3. Use

4. Use press ENTER (b) to move to the third level.

5. Use press ENTER (b) to confirm your selection.

to select the [Setup] and press ENTER

a/d

to select [DISPLAY] option then press

w/s

to move to the second level.

to select the [Resolution] option then

w/s

to select the desired resolution then

w/s

Connecting 17

Note

yIf your TV does not accept the resolution

you have set on the player, you can set resolution to 576p as follows:

1. Press B to open the disc tray.

2. Press Z (STOP) for more than 5 seconds.

yWhen you set the resolution to 576i with

HDMI connection, actual resolution is outputted to 576p.

yIf you select a resolution manually and then

connect the HDMI jack to TV and your TV does not accept it, the resolution setting is set to [Auto].

yIf you select a resolution that your TV

does not accept, the warning message will appear. After resolution change, if you cannot see the screen, please wait 20 seconds and the resolution will automatically revert back to the previous resolution.

yThe 1080p video output frame rate may

be automatically set to either 24 Hz or 50 Hz depending both on the capability and preference of the connected TV and based on the native video frame rate of the content on the BD-ROM disc.

Connecting

Connecting18

Connecting to an amplifier

Make one of the following connections, depending on the capabilities of your existing equipment.

yHDMI audio connection

yDigital audio connection (page 19)

Since many factors aect the type of audio output,

Connecting

see “Audio output specications” for details (pages

53).

About digital multi-channel sound

A digital multi-channel connection provides the best sound quality. For this, you need a multichannel Audio/Video Receiver that supports one or more of the audio formats supported by your player. Check the logos on the front of the Audio/ Video receiver and the manual. (PCM Stereo, PCM Multi-Ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and/or DTS-HD)

Connecting to an amplifier via HDMI output

Connect the player’s HDMI OUT jack to the corresponding in jack on your amplier using a HDMI cable.

Rear of the unit

HDMI cable

Receiver/Amplier

HDMI cable

Connect the amplier’s HDMI output jack to HDMI input jack on your TV using a HDMI cable if your amplier has HDMI output jack.

You will need to activate the player’s digital output. (See “[AUDIO] Menu” on pages 27)

Connecting to an amplifier via digital audio output

Connect the player’s COAXIAL OUT jack to the corresponding in jack on your amplier using an optional digital audio cable.

Rear of the unit

Coaxial cable

Connecting 19

Connecting

Receiver/Amplier

You will need to activate the player’s digital output. (See “[AUDIO] Menu” on pages 27.)

Connecting20

Connecting to your home network

This player can be connected to a local area network (LAN) via the LAN port on the rear panel. By connecting the unit to a broadband home network, you have access to services such as software updates, BD-Live interactivity and on-line

content services.

Connecting

Wired network connection

Using a wired network provides the best performance, because the attached devices connect directly to the network and are not subject to radio frequency interference.

Please refer to the documentation for your network device for further instructions.

Connect the player’s LAN port to the corresponding port on your Modem or Router using a commercially available LAN or Ethernet cable.

Note

yWhen plugging or unplugging the LAN

cable, hold the plug portion of the cable. When unplugging, do not pull on the LAN cable but unplug while pressing down on the lock.

yDo not connect a modular phone cable to

the LAN port.

ySince there are various connection

congurations, please follow the specications of your telecommunication carrier or internet service provider.

Broadband service

Router

Rear of the unit

Wired network setup

If there is a DHCP server on the local area network (LAN) via wired connection, this player will automatically be allocated an IP address. After making the physical connection, a small number of home networks may require the player’s network setting to be adjusted. Adjust the [NETWORK] setting as follow.

Preparation

Before setting the wired network, you need to connect the broadband internet to your home network.

Connecting 21

1. Select [Connection Setting] option in the [Setup] menu then press ENTER (b).

2. Read the preparations for the network settings and then press ENTER (b) while [Start] is highlighted.

Network will automatically be connected to the unit.

Advanced Setting

If you want to set the network settings manually, use [Network Setting] menu and press ENTER (b).

1. Use

2. Select [Next] and press ENTER (b) to apply

to select [Advanced Setting] on the

w/s

w/s/a/d

between [Dynamic] and [Static].

Normally, select [Dynamic] to allocate an IP address automatically.

Note

If there is no DHCP server on the network and you want to set the IP address manually, select [Static] then set [IP Address], [Subnet Mask], [Gateway] and [DNS Server] using

w/s/a/d

make a mistake while entering a number, press CLEAR to clear the highlighted part.

network settings.

to select the IP mode

and numerical buttons. If you

Connecting

Network connection status is displayed on the screen.

3. Press ENTER (b) while [Close] is highlighted to finish the wired network settings.

Connecting22

Notes on network connection

yMany network connection problems during

set up can often be xed by re-setting the router or modem. After connecting the player to the home network, quickly power o and/ or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again.

yDepending on the internet service provider (ISP),

Connecting

the number of devices that can receive internet service may be limited by the applicable terms of service. For details, contact your ISP.

yOur company is not responsible for any

malfunction of the player and/or the internet connection feature due to communication errors/malfunctions associated with your broadband internet connection, or other connected equipment.

yThe features of BD-ROM discs made available

through the Internet Connection feature are not created or provided by our company, and our company is not responsible for their functionality or continued availability. Some disc related material available by the Internet Connection may not be compatible with this player. If you have questions about such content, please contact the producer of the disc.

ySome internet contents may require a higher

bandwidth connection.

yEven if the player is properly connected and

congured, some internet contents may not operate properly because of internet congestion, the quality or bandwidth of your internet service, or problems at the provider of the content.

ySome internet connection operations may not

be possible due to certain restrictions set by the Internet service provider (ISP) supplying your broadband Internet connection.

yAny fees charged by an ISP including, without

limitation, connection charges are your responsibility.

yA 10 Base-T or 100 Base-TX LAN port is required

for wired connection to this player. If your internet service does not allow for such a connection, you will not be able to connect the player.

yYou must use a Router to use xDSL service.

yA DSL modem is required to use DSL service and

a cable modem is required to use cable modem service. Depending on the access method of and

subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this player or you may be limited to the number of devices you can connect at the same time. (If your ISP limits subscription to one device, this player may not be allowed to connect when a PC is already connected.)

yThe use of a “Router” may not be allowed or its

usage may be limited depending on the policies and restrictions of your ISP. For details, contact your ISP directly.

USB device connection

This player can play movie, music and photo les contained in the USB device.

Playback content in the USB device

1. Insert a USB device to the USB port until it fits into place.

When you connect the USB device on the HOME menu, the player plays a music le contained in the USB storage device automatically. If the USB storage device is containing various types of les, a menu for the le type selection will appear.

File loading may takes few minutes depending on the number of content stored in the USB storage device. Press ENTER (b) while [Cancel] is selected to stop loading.

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using and press ENTER (b).

4. Select the [USB] option using ENTER (b).

w/s

, and press

a/d

Connecting 23

Note

yThis player supports USB ash drive/

external HDD formatted in FAT32 and NTFS when accessing les (music, photo, movie). However, for Blu-ray contents, only FAT32 format is supported. Use the USB ash drive/ external HDD formatted in either FAT32 or NTFS when enjoying Blu-ray contents.

yThe USB device can be used for the local

storage for enjoying BD-Live discs with Internet.

yThis unit can support up to 4 partitions of

the USB device.

yDo not extract the USB device during

operation (play, etc.).

yA USB device which requires additional

program installation when you have connected it to a computer, is not supported.

yUSB device: USB device that supports

USB1.1 and USB2.0.

yMovie, music and photo les can be played.

For details of operations on each le, refer to relevant pages.

yRegular back up is recommended to

prevent data loss.

yIf you use a USB extension cable, USB HUB

or USB Multi-reader, the USB device may not be recognized.

ySome USB device may not work with this

unit.

yDigital camera and mobile phone are not

supported.

yUSB Port of the unit cannot be connected

to PC. The unit cannot be used as a storage device.

Connecting

5. Select a file using or ENTER (b) to play the file.

6. Withdraw the USB device carefully.

w/s/a/d

, and press PLAY

System Setting24

Settings

Initial Setup

When you turn on the unit for the rst time, the initial setup wizard appears on the screen. Set the display language and network settings on the initial setup wizard.

1. Press 1 (POWER).

The initial setup wizard appears on the screen.

2. Use

w/s/a/d

and press ENTER (b).

System Setting

3. Read and prepare the preparations for the network settings and then press ENTER (b) while [Start] is highlighted.

to select a display language

4. Check all the settings that you have set in the previous steps.

Press ENTER (b) while [Finish] is highlighted to finish the initial setup settings. If there is any settings to be changed, use [Previous] and press ENTER (b).

a/d

to select

If wired network is connected, the network connection setting will automatically be finished.

For details on network settings, refer to “Connecting to your Home Network” on page

20.

System Setting 25

Adjust the setup settings

You can change the settings of the player in the [Setup] menu.

1. Press HOME (n).

2. Use (b). The [Setup] menu appears.

3. Use press d to move to the second level.

4. Use press ENTER (b) to move to the third level.

to select the [Setup] and press ENTER

a/d

to select the first setup option, and

w/s

to select a second setup option, and

w/s

[DISPLAY] Menu

TV Aspect Ratio

Select a TV aspect ratio option according to your TV type.

[4:3 Letter Box]

Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture.

[4:3 Pan Scan]

Select when a standard 4:3 TV is connected. Displays pictures cropped to ll your TV screen. Both sides of the picture are cut o.

[16:9 Original]

Select when a 16:9 wide TV is connected. The 4:3 picture is displayed with an original 4:3 aspect ratio, with black bars appearing at the left and right sides.

[16:9 Full]

Select when a 16:9 wide TV is connected. The 4:3 picture is adjusted horizontally (in a linear proportion) to ll the entire screen.

Note

You cannot select [4:3 Letter Box] and [4:3 Pan Scan] option when the resolution is set to higher than 720p.

System Setting

5. Use ENTER (b) to confirm your selection.

to select a desired setting, and press

w/s

System Setting26

Resolution

Sets the output resolution of the HDMI video signal. Refer to page 17 for details about the resolution setting.

[Auto]

If the HDMI OUT jack is connected to TVs providing display information (EDID), automatically selects the resolution best suited to the connected TV.

[1080p]

Outputs 1080 lines of progressive video.

[1080i]

System Setting

Outputs 1080 lines of interlaced video.

[720p]

Outputs 720 lines of progressive video.

[576p]

Outputs 576 lines of progressive video.

[576i]

Outputs 576 lines of interlaced video.

1080p Display Mode

When the resolution is set to 1080p, select [24 Hz] for smooth presentation of lm material (1080p/24 Hz) with a HDMI-equipped display compatible with 1080p/24 Hz input.

Note

yWhen you select [24 Hz], you may

experience some picture disturbance when the video switches video and lm material. In this case, select [50 Hz].

yEven when [1080p Display Mode] is set to

[24 Hz], if your TV is not compatible with 1080p/24 Hz, the actual frame frequency of the video output will be 50 Hz to match the video source format.

HDMI Color Setting

Select the type of output from the HDMI OUT jack. For this setting, please refer to the manuals of your display device.

[YCbCr]

Select when connecting to a HDMI display device.

[RGB]

Select when connecting to a DVI display device.

3D Mode

Select the type of output mode for Blu-ray 3D disc playback.

[O ]

Blu-ray 3D disc playback will output as 2D mode like a normal BD-ROM disc playback.

[On]

Blu-ray 3D disc playback will output as 3D mode.

Home Menu Guide

This function allows you to display or delete the guide bubble on the Home Menu. Set this option to [On] for displaying guide.

System Setting 27

[LANGUAGE] Menu

Display Menu

Select a language for the [Setup] menu and onscreen display.

Disc Menu/Disc Audio/ Disc Subtitle

Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the disc was recorded.

[Other]

Press ENTER (b) to select another language. Use number buttons then press ENTER (b) to enter the corresponding 4-digit number according to the language code list on page 50.

[O] (Disc Subtitle only)

Turn o Subtitle.

Note

Depending on the disc, your language setting may not work.

[AUDIO] Menu

Each disc has a variety of audio output options. Set the player’s Audio options according to the type of audio system you use.

Note

Since many factors aect the type of audio output, see “Audio output specications” on page 53 for details.

Digital Output

[PCM Stereo] (HDMI, COAXIAL)

Select if you connect this unit’s HDMI OUT or COAXIAL OUT jack to a device with twochannel digital stereo decoder.

[PCM Multi-Ch] (HDMI only)

Select if you connect this unit’s HDMI OUT jack to a device with multi-channel digital decoder.

[DTS Re-Encode] (HDMI, COAXIAL)

Select if you connect this unit’s HDMI OUT or COAXIAL OUT jack to a device with DTS decoder.

[BitStream] (HDMI, COAXIAL)

Select if you connect this unit’s DIGITAL AUDIO OUT and HDMI OUT jack to a device with LPCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and DTS-HD decoder.

Note

yWhen [Digital Output] option is set to [PCM

Multi-Ch], the audio may output as PCM Stereo if the PCM Multi-Ch information is not detected from HDMI device with EDID.

yIf the [Digital Output] option is set to [DTS

Re-Encode], the DTS Re-Encode audio is outputted for BD-ROM discs with secondary audio and the original audio is outputted for the other discs (like [BitStream]).

System Setting

System Setting28

Sampling Freq. (Digital Audio Output)

[48 kHz]

Select this if your A/V Receiver or Amplier is not capable of handling 192 kHz and 96 kHz signal. When this choice is made, this unit automatically converts any 192 kHz and 96 kHz signals to 48 kHz so your system can decode them.

[96 kHz]

Select this if your A/V Receiver or Amplier is not capable of handling 192 kHz signals. When this choice is made, this unit automatically

System Setting

converts any 192 kHz signals to 96 kHz so your system can decode them.

[192 kHz]

Select this if your A/V Receiver or Amplier is capable of handling 192 kHz signals.

Check the documentation for your A/V Receiver or Amplier to verify its capabilities.

DRC (Dynamic Range Control)

This function allows you to listen to a movie at a lower volume without losing clarity of sound.

[Auto]

The dynamic range of the Dolby TrueHD audio output is specied by itself. And the dynamic range of the Dolby Digital and Dolby Digital Plus are operated as same as the [On] mode.

[On]

Compress the dynamic range of the Dolby Digital, Dolby Digital Plus or Dolby TrueHD audio output.

[O ]

Turns o this function.

Note

The DRC setting can be changed only when a disc is not inserted or the unit is in complete stop mode.

System Setting 29

[LOCK] Menu

The [LOCK] settings aect only BD-ROM and DVD playback.

To access the any features in [LOCK] settings, you must enter the 4-digit security code you have created. If you have not entered a password yet, you are prompted to do so. Enter a 4-digit password twice, and press ENTER (b) to create a new password.

Password

You can create or change the password.

[None]

Enter a 4-digit password twice, and press ENTER (b) to create a new password.

[Change]

Enter the current password and press ENTER (b). Enter a 4-digit password twice, and press ENTER (b) to create a new password.

If you forget your password

If you forget your password, you can clear it using the following steps:

1. Remove any disc that might be in the player.

2. Select [Password] option in the [Setup] menu.

3. Use Number buttons to enter “210499”. The password is cleared.

Note

If you make a mistake before pressing ENTER (b), press CLEAR. Then input the correct password.

DVD Rating

Blocks playback of rated DVD based on their content. (Not all discs are rated.)

[Unlock]

If you select [Unlock], parental control is not active and the disc plays in full.

[Rating 1-8]

Rating one (1) has the most restrictions and rating eight (8) is the least restrictive.

Blu-ray Disc Rating

Set an age limit of BD-ROM play. Use number buttons to input an age limit for BD-ROM viewing.

[255]

All BD-ROM can be played.

[0-254]

Prohibits play of BD-ROM with corresponding ratings recorded on them.

Note

The [Blu-ray Disc Rating] will be applied only for the Blu-ray disc that containing the Advanced Rating Control.

Area Code

Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 49.

System Setting

System Setting30

[NETWORK] Menu

The [NETWORK] settings are needed to use the software update, BD-Live and on-line content services.

Connection Setting

If your home network environment is ready to connect the player, the player needs to be set the wired network connection for network communication. (See “Connecting to your Home Network” on pages 20.)

Connection Status

If you want to check tshe network status on this

player, select the [Connection Status] options and

System Setting

press ENTER (b) to check whether a connection to the network and the internet have been established.

BD-LIVE connection

You can restrict Internet access when BD-Live functions are used.

[Permitted]

Internet access is permitted for all BD-Live contents.

[Partially permitted]

Internet access is permitted only for BDLive contents which have content owner certicates. Internet access and AACS Online functions are prohibited for all BD-Live contents without a certicate.

[Prohibited]

Internet access is prohibited for all BD-Live contents.

[OTHERS] Menu

DivX® VOD

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an ocial DivX Certied® device that plays DivX video. Visit divx.com for more information and software tools to convert your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod. divx.com for more information on how to complete your registration.

[Register]

Displays the registration code of your player.

[Deregister]

Deactivate your player and display the deactivation code.

Note

All the downloaded videos from DivX(R) VOD with this player’s registration code can only be played on this unit.

Auto Power Off

The screen saver appears when you leave the player in Stop mode for about ve minutes. If you set this option to [On], the unit automatically turns o within 20 minutes since the Screen Saver is displayed. Set this option to [O] to leave the screen saver until the unit is operated by the user.

Initialize

[Factory Set]

You can reset the player to its original factory settings.

[Blu-ray Storage Clear]

Initializes the BD-Live contents from the connected USB storage.

Note

If you reset the player to its original factory settings using [Factory Set] option, you have to set all the activation for the on-line services and network settings again.

Software

System Setting 31

System Setting

[Information]

Displays the current software version.

[Update]

You can update the software by connecting the unit directly to the software update server (see page 47).

Disclaimer Notice

Press ENTER (b) to view the notice of Network Service Disclaimer.

Operating32

General Playback

Using [HOME] menu

The home menu appears when you press HOME

Operating

(n). Use ENTER (b).

[Movie] - Plays video contents.

[Photo] - Plays photo contents.

[Music] - Plays audio contents.

[Premium] - Displays the Premium Home

screen.

[Setup] - Adjusts the system settings.

to select a category and press

a/d

Playing a disc

erto

1. Press B (OPEN/CLOSE), and place a disc on the disc tray.

2. Press B (OPEN/CLOSE) to close the disc tray.

For the most Audio CD, BD-ROM and DVD-ROM discs, playback starts automatically.

3. Press HOME (n).

4. Select [Movie] or [Music] using ENTER (b).

5. Select [Blu-ray Disc], [DVD], [VR] or [Audio] option using

Note

yPlayback functions described in this manual

are not always available in every les and media. Some functions can be restricted depending on many factors.

yDepending on the BD-ROM titles, a USB

device connection may be needed for the proper playback.

yUnnalized DVD-VR format discs may not

be played in this player.

ySome DVD-VR discs are made with CPRM

data by DVD RECORDER. This unit cannot support these kinds of discs.

, and press ENTER (b).

w/s

a/d

, and press

Playing a file on disc/USB device

yui

This player can play movie, music and photo les contained in the disc or USB device.

1. Insert a data disc on the tray or connect a USB device.

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using and press ENTER (b).

4. Select [Data] or [USB] option using press ENTER (b).

5. Select a file using

(PLAY) or ENTER (b) to play the file.

w/s/a/d

a/d

, and

w/s

, and press

Operating 33

Playing Blu-ray 3D disc

This player can play the Blu-ray 3D discs which contains separate views for the left and right eyes.

Preparation

In order to playback Blu-ray 3D title in stereoscopic 3D mode, you need to:

Check your TV is 3D capable and has HDMI

input(s).

y Wear 3D glasses to enjoy the 3D experience

if it is necessary.

Check whether the BD-ROM title is the Blu-

ray 3D disc or not.

Connect an HDMI cable (Type A, High

Speed HDMI™ Cable) between the player’s HDMI output and TV’s HDMI input.

1. Press HOME (n), and set the [3D Mode] option on the [Setup] menu to [On] (page 26).

2. Press B (OPEN/CLOSE), and place a disc on the disc tray.

3. Press B (OPEN/CLOSE) to close the disc tray.

The playback starts automatically.

4. Refer to the owner’s manual of your 3D-ready TV for the further instruction.

You may need to adjust the display settings and focus on your TV’s setting for the improved 3D eect.

Caution

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a movie

in 3D mode for inrm, child and pregnant woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing contents in 3D, it is strongly recommended to stop the playback and rest until you feel normal.

Enjoying BD-Live™

BD-ROM supporting BD-Live that has a network extension function allows you to enjoy more functions such as downloading new movie trailers by connecting this unit to the internet.

1. Check the network connection and settings (page 20).

2. Insert a USB storage device to the USB port on the front panel.

A USB storage device is needed to download bonus content.

3. Press HOME (n), and set the [BD-LIVE connection] option on the [Setup] menu (page

30).

Depending on a disc, the BD-Live function may not be operated if [BD-LIVE connection] option is set to [Partially Permitted].

4. Insert a BD-ROM with BD-Live.

The operations are dier depending on the disc. Refer to the manual supplied with the disc.

Caution

Do not extract the connected USB device while content is being downloaded or a Bluray disc is still in the disc tray. Doing so may damage the connected USB device and BDLive features may not operate properly with the damaged USB device anymore. If the connected USB device seems damaged from such an action, you can format the connected USB device from the PC and reuse it with this player.

Note

ySome BD-Live contents may be restrictively

accessed in some territories by contents provider’s own decision.

yIt may take up to several minutes to load

and start enjoying BD-Live contents.

Operating

Operating34

Basic operations for video and audio content

To stop playback

Press Z (STOP) while playback.

To pause playback

Press M (PAUSE) while playback. Press z (PLAY) to resume playback.

To play frame-by-frame (Video)

Press M (PAUSE) while movie playback. Press M (PAUSE) repeatedly to play Frame-by-Frame playback.

To scan forward or backward

Press c or v to play fast forward or fast reverse during playback.

You can change the various playback speeds by

pressing c or v repeatedly.

Operating

To slow down the playing speed

While the playback is paused, press v repeatedly to play various speeds of slow motion.

To skip to the next/previous chapter/track/file

During playback, press C or V to go to the next chapter/track/le or to return to the beginning of the current chapter/track/le.

Press C twice briey to step back to the previous chapter/track/le.

Basic operations for photo content

To play a slide show

Press z (PLAY) to start slide show.

To stop a slide show

Press Z (STOP) while slide show.

To pause a slide show

Press M (PAUSE) while slide show. Press z (PLAY) to re-start the slide show.

To skip to the next/previous photo

While viewing a photo in full screen, press a or d to go to the previous or next photo.

Using the disc menu

ero

To display the disc menu

The menu screen may be displayed rst after loading a disc which contains a menu. If you want to display the disc menu while playback, press DISC MENU.

Use

w/s/a/d

menu items.

To display the Pop-up menu

Some BD-ROM discs contain Pop-up menu that appears while playback.

Press TITLE/POP-UP while playback, and use

w/s/a/d

items.

buttons to navigate through

buttons to navigate through menu

Operating 35

Resume playback

eroyt u

The unit records the point where you pressed the

(STOP) depending on the disc.

If “MZ (Resume Stop)” appears on the screen briey, press z (PLAY) to resume playback (from the scene point). If you press Z (STOP) twice or unload the disc, “Z(Complete Stop)” appears on the screen. The unit will clear the stopped point.

Note

yThe resume point may be cleared when a

button is pressed (for example; 1 (POWER),

(OPEN/CLOSE), etc).

yOn BD-ROM discs with BD-J, the resume

playback function does not work.

yIf you press Z (STOP) once during BD-ROM

interactive title playback, the unit will be in Complete Stop mode.

Last scene memory

This unit memorizes the last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch o the unit. If you load a disc that has the scene memorized, the scene is automatically recalled.

Note

yLast Scene Memory function for a previous

disc is erased once a dierent disc is played.

yThis function may not work depending on

the disc.

yOn BD-ROM discs with BD-J, the last scene

memory function does not work.

yThis unit does not memorize settings of

a disc if you switch o the unit before commencing to play it.

Advanced Playback

Repeat playback

erotu y

During playback, press REPEAT (h) repeatedly to select a desired repeat mode.

Blu-ray Disc / DVD / Movie les

A- – Selected portion will be repeated continually.

(page 36)

Chapter – The current chapter will be played

back repeatedly.

Title – The current title will be played back

repeatedly.

All – All the tracks or les will be played back

repeatedly.

To return to normal playback, press REPEAT (h) repeatedly to select [O ].

Audio CDs/Music les

Track – The current track or le will be played

;

back repeatedly.

All – All the tracks or les will be played back

repeatedly.

– The tracks or les will be played back in

random order.

All – All the tracks or les will be played

back repeatedly in random order.

A-B – Selected portion will be repeated

continually. (Audio CD only)

To return to normal playback, press CLEAR.

Note

yIf you press V once during Repeat

Chapter/Track playback, the repeat playback cancels.

yThis function may not work on some disc or

title.

Operating

Operating36

Repeating a specific portion

eroty

This player can repeat a portion you have selected.

1. While playback, press REPEAT (h) to select [A-] at the beginning of the portion you wish to repeat.

2. Press ENTER (b) at the end of the portion. Your selected portion will be repeated continually.

3. To return to normal playback, press REPEAT (h) repeatedly to select [O ].

Note

yYou cannot select a portion less than 3

seconds.

yThis function may not work on some disc or

title.

Viewing content information

Operating

The player can display the content information.

1. Select a le using

2. Press INFO/MENU (m) to display the option menu.

3. Select the [Information] option using press ENTER (b).

The le information appears on the screen.

While movie playback, you can display the le information by pressing TITLE/POP-UP.

Note

The information displayed on the screen may not correct comparing actual content information.

w/s/a/d

Changing content list view

yui

On the [Movie], [Music] or [Photo] menu, you can change the content list view.

Method 1

Press red (R) coloured button repeatedly.

, and

w/s

Method 2

1. On the content list, press INFO/MENU (m) to display the option menu.

2. Use

3. Press ENTER (b) to change the content list view.

to select the [View Change] option.

w/s

Operating 37

Selecting a subtitle ﬁle

If the subtitle le name is dierent from the movie le name, you need to select the subtitle le on the [Movie] menu before playing the movie.

1. Use

w/s/a/d

wish to play in the [Movie] menu.

2. Press ENTER (b).

Press ENTER (b) again to deselect the subtitle le. Selected subtitle le will be displayed when you play the movie le.

Note

If you press Z (STOP) while playback, the subtitle selection is cancelled.

to select the subtitle le you

Options while viewing a photo

You can use various options during viewing a photo in full screen.

1. While viewing a photo in full screen, press INFO/ MENU (m) to display the option menu.

2. Select an option using

a Current photo/Total number of photos

– Use

b Slide Show – Press ENTER (b) to start or

pause slide show.

c Music Select – Select the background

music for the slide show (page 38).

d Music –Press ENTER (b) to start or pause

background music.

e Rotate – Press ENTER (b) to rotate the

photo clockwise.

f Zoom – Press ENTER (b) to display the

[Zoom] menu.

g Eect – Use

effect between photos in a slide show.

h Speed – Use

speed between photos in a slide show.

3. Press BACK (1) to exit the option menu.

to view previous/next photo.

a/d

w/s

to select a transition

to select a delaying

Operating

Operating38

Listening to music while slide show

You can display photo les while listening to music les.

1. While viewing a photo in full screen, press INFO/ MENU (m) to display the option menu.

2. Use press ENTER (b) to display the [Music Select] menu.

3. Use (b).

4. Use play.

Operating

Select g and press ENTER (b) to display the upper directory.

5. Use d to select [OK], and press ENTER (b) to complete music selection.

to select [Music Select] option, and

w/s

to select a device, and press ENTER

w/s

to select a file or a folder you wish to

w/s

On-screen display

You can display and adjust various information and settings about the content.

Displaying content information on-screen

eroy

1. While playback, press INFO/MENU (m) to show various playback information.

a Title – current title number/total number of

titles

b Chapter – current chapter number/total

number of chapters

c Time – elapsed playing time/total playback

time

d Audio – selected audio language or channel e Subtitle – selected subtitle. f Angle – selected angle/total number of

angles

g TV Aspect Ratio – selected TV aspect Ratio h Picture Mode – selected picture mode

Operating 39

2. Select an option using

3. Use

4. Press BACK (1) to exit the on-screen display.

yIf no button is pressed for a few seconds,

yA title number cannot be selected on some

yAvailable items may dier depending on

yIf an interactive Blu-ray Disc is playing back,

to adjust the selected option value.

a/d

Note

the on-screen display disappears.

discs.

discs or titles.

some setting information is displayed on the screen but prohibited to be changed.

w/s

Playing from selected time

eroy

1. Press INFO/MENU (m) during playback. The time search box shows the elapsed playing time.

2. Select the [Time] option and then input the required start time in hours, minutes, and seconds from left to right.

For example, to nd a scene at 2 hours, 10 minutes, and 20 seconds, enter “21020”.

Press forward or backward.

3. Press ENTER (b) to start playback from selected time.

yThis function may not work on some disc or

titles.

yThis function may not work depending on

the le type.

to skip the playback 60 seconds

a/d

Note

Selecting a subtitle language

eroy

1. During playback, press INFO/MENU (m) to display the on-screen display.

2. Use

3. Use

4. Press BACK (1) to exit the on-screen display.

ySome discs allow you to change subtitle

yYou can select the [Subtitle] option on the

to select the [Subtitle] option.

w/s

to select desired subtitle language.

a/d

Note

selections only via the disc menu. If this is the case, press TITLE/POP-UP or DISC MENU button and choose the appropriate subtitle from the selections on the disc menu.

on-screen display directely by pressing SUBTITLE (]) button.

Operating

Operating40

Hearing a different audio

eroy

1. During playback, press INFO/MENU (m) to display the on-screen display.

Operating

2. Use

3. Use audio track or audio channel.

ySome discs allow you to change audio

yImmediately after you have switched sound,

yOn BD-ROM disc, the multi audio format

yYou can select the [Audio] option on the on-

to select the [Audio] option.

w/s

to select desired audio language,

a/d

Note

selections only via the disc menu. In this case, press TITLE/POP-UP or DISC MENU button and choose the appropriate audio from the selections on the disc menu.

there may be a temporary discrepancy between the display and actual sound.

(5.1CH or 7.1CH) is displayed with [MultiCH] in the on-screen display.

screen display directely by pressing AUDIO ([) button.

Watching from a different angle

Changing the TV Aspect Ratio

eoy

You can change the TV aspect ratio setting while playback.

1. During playback, press INFO/MENU (m) to display the On-Screen display.

2. Use option.

3. Use

4. Press BACK (1) to exit the On-Screen display.

Even if you change the value of the [TV Aspect Ratio] option in on-screen display, the [TV Aspect Ratio] option in the [Setup] menu is not changed.

to select the [TV Aspect Ratio]

w/s

to select desired option.

a/d

Note

ero

If the disc contains scenes recorded at dierent camera angles, you can change to a dierent camera angle during playback.

1. During playback, press INFO/MENU (m) to display the On-Screen display.

2. Use

3. Use

4. Press BACK (1) to exit the On-Screen display.

to select the [Angle] option.

w/s

to select desired angle.

a/d

Operating 41

Changing subtitle Code Page

If the subtitle is displayed in broken letter, you can change the subtitle code page to view the subtitle le properly.

1. During playback, press INFO/MENU (m) to display the playback menu.

2. Use

3. Use

4. Press BACK (1) to exit the on-screen display.

to select the [Code Page] option.

w/s

to select desired code option.

a/d

Changing the Picture Mode

eroy

You can change the [Picture mode] option while playback.

1. During playback, press INFO/MENU (m) to display the On-Screen display.

2. Use

3. Use

4. Press BACK (1) to exit the On-Screen display.

Setting the [User setting] option

1. During playback, press INFO/MENU (m) to display the on-screen display.

2. Use

3. Use and press ENTER (b).

4. Use options.

Select [Default] option then press ENTER (b) to reset the all video adjustments.

5. Use and press ENTER (b) to nish setting.

to select the [Picture Mode] option.

w/s

to select desired option.

a/d

to select the [Picture Mode] option.

w/s

to select the [User setting] option,

a/d

w/s/a/d

to adjust the [Picture Mode]

to select the [Close] option,

Operating

Operating42

Using the Premium

You can use various content services via Internet with the Premium feature.

1. Check the network connection and settings (page 20).

2. Press HOME (n).

3. Select the [Premium] using ENTER (b).

a/d

, and press

4. Select an on-line service using and press ENTER (b).

Note

Operating

yDetailed information of each service,

contact to the content provider or visit suppot link of the service.

yThe content of Premium services and

service related information, including user interface, is subject to changes. Please refer to the web site of each service for most upto-date information.

yWhen you are rst time to access [Premium]

feature, current country setting appears. If you want to change the country setting, select [Edit] and press ENTER (b).

w/s/a/d

Troubleshooting 43

Troubleshooting

General

Symptom Cause & Solution

The Power does not turned on. yPlug the power cord into the wall outlet securely.

The unit does not start playback.

The angle cannot be changed. yMulti-angles are not recorded on the DVD Video being played.

Cannot play movie, photo or music les.

The remote control does not work properly.

The unit is plugged in, but the power will not turn on or o.

The unit is not operating normally.

yInsert a playable disc. (Check the disc type, colour system, and

regional code.)

yPlace the disc with the playback side down.

yPlace the disc on the disc tray correctly inside the guide.

yClean the disc.

yCancel the Rating function or change the rating level.

yThe les are not recorded in a format that the unit can play.

yThe unit does not support the codec of the movie le.

yThe remote control is not pointed at the remote sensor of the unit.

yThe remote control is too far from the unit.

yThere is an obstacle in the path of the remote control and the unit.

yThe battery in the remote control is exhausted.

You can reset the unit as follows.

yUnplug the power cord, wait at least ve seconds, and then plug it in

again.

Troubleshooting

Troubleshooting44

Network

Symptom Cause & Solution

BD-Live feature does not work. yThe connected USB storage may not have enough space. Connect

Streaming video services (such as YouTube™, etc.) are often stopped or “buer” during playback.

the USB storage with at least 1GB free space.

yEnsure that the unit is correctly connected to the local area network

and can access the internet (see page 20).

yYour broadband speed may not fast enough to use the BD-Live

features. Contact your Internet Service Provider (ISP) and increase the broadband speed is recommended.

yThe [BD-LIVE connection] option in the [Setup] menu is set to

[Prohibited]. Set the option to [Permitted].

yYour broadband service speed may not be fast enough to stream

video services. Contact your Internet Service Provider (ISP) and increase the broadband speed is recommended.

Troubleshooting 45


Symptom Cause & Solution

There is no picture. ySelect the appropriate video input mode on the TV so the picture

Picture noise appears. yYou are playing a disc recorded in a colour system that is dierent

from the unit appears on the TV screen.

yConnect the video connection securely.

yCheck the [HDMI Color Setting] in the [Setup] menu is set to the

appropriate item that conforms to your video connection.

yYour TV may not support the resolution you have set on the player.

Change the resolution that your TV accepts.

yThe player’s HDMI OUT jack is connected to a DVI device that does

not support copyright protection.

from your TV.

ySet the resolution which your TV accepts.

Blu-ray 3D disc playback does not output 3D views.

yConnect the player to your TV with HDMI cable (Type A, High Speed

HDMI™ Cable).

yYour TV may not support “HDMI 3D mandatory format”.

yThe [3D Mode] option in the [Setup] menu is set to [O ].

Set the option to [On].

Customer support

You can update the Player using the latest software to enhance the products operation and/or add new features. To obtain the latest software for this player (if updates have been made), please visit http://www.lg.com/global/support or contact LG Electronics customer care centre.

Open source software notice

To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are available to download with the source code.

Troubleshooting

Appendix46

Controlling a TV with the supplied remote control

You can control your TV using the buttons below.

By pressing You can

(TV POWER) Turn the TV on or o.

Scan up or down through memorized channels.

Switch the TV’s input source between the TV and other input sources.

Appendix

PR/CH +/–

VOL +/– Adjust the volume of the TV

AV/INPUT

Note

Depending on the unit being connected, you may not be able to control your TV using some of the buttons.

Setting up the remote to control your TV

You can operate your TV with the supplied remote control. If your TV is listed in the table below, set the appropriate manufacturer code.

1. While holding down 1 (TV POWER) button, and press the manufacturer code for your TV with the numerical buttons (see the table below).

Manufacturer Code number

LG 1(Default), 2

Zenith 1, 3, 4

GoldStar 1, 2

Samsung 6, 7

Sony 8, 9

Hitachi 4

2. Release the 1 (TV POWER) button to complete setting.

Depending on your TV, some or all buttons may not function on the TV, even after entering the correct manufacturer code. When you replace the batteries of the remote, the code number you have set may be reset to the default setting. Set the appropriate code number again.

Appendix 47

Network software update

Network update notification

From time to time, performance improvements and/or additional features or services may be made available to units that are connected to a broadband home network. If there is new software available and the unit is connected to a broadband home network, the player will inform you about the update as follows.

Option 1

1. The update menu will appear on the screen when you turn off the player.

2. Use press ENTER (b).

Option 2

If the software update is available from the update server, the “Update” icon appears in the Home menu. Press blue (B) coloured button to start the update procedure.

to select a desired option and then

a/d

[OK] Starts the software update.

[Cancel] Exits the update menu and turns

the power o.

Software update

You can update the player using the latest software to enhance the products operation and/or add new features. You can update the software by connecting the unit directly to the software update server.

Note

yBefore updating the software in your player,

remove any disc and USB Device from the player.

yBefore updating the software in your player,

turn the player o and then turn it back on.

yDuring the software update procedure,

do not turn o the player or disconnect AC power, or do not press any button.

yIf you cancel the update, turn o the power

and turn it on for stable performance.

yThis unit cannot be updated to previous

software version.

1. Check the network connection and settings (page 20).

2. Select [Software] option in the [Setup] menu then press ENTER (b).

3. Select [Update] option, and press ENTER (b).

The player will check for the newest update.

Note

yPressing ENTER (b) while checking for the

update will end the process.

yIf there is no update available, the Message,

“No update is found.” appears. Press ENTER (b) to return to the [Home Menu].

Appendix

Appendix48

4. If newer version exists, the message “Do you want to download it?” appears.

5. Select [OK] to start update. (Selecting [Cancel] will end the update.)

6. The player starts downloading the newest update from the server. (Downloading will takes several minutes depending on your home network condition)

7. When downloading is completed, the message, “Download is complete. Do you want to update?” appears.

8. Select [OK] to start updating. (Selecting [Cancel] will end the update and downloaded file will not be re-usable. To update software the next time, the software update procedure has to be started from the beginning again.)

Caution

Do not turn o the power during the software update.

Note

If the software includes the driver update, disc tray may open during the process.

9. When update is completed, the power will be turned automatically in a few seconds.

10. Turn the power back on. The system now operates with the new version.

Note

Appendix

The Software Update function may not work properly depending on your internet environment. In this case, you can obtain the latest software from the authorized LG Electronics Service Centre then update your player. Refer to “Customer support” on page

45.

Appendix 49

Area code list

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF

Argentina AR

Australia AU

Austria AT

Belgium BE

Bhutan BT

Bolivia BO

Brazil BR

Cambodia KH

Canada CA

Chile CL

China CN

Colombia CO

Congo CG

Costa Rica CR

Croatia HR

Czech Republic CZ

Denmark DK

Ecuador EC

Egypt EG

El Salvador SV

Ethiopia ET

Fiji FJ

Finland FI

France FR

Germany DE

Great Britain GB

Greece GR

Greenland GL

Hong Kong HK

Hungary HU

India IN

Indonesia ID

Israel IL

Italy IT

Jamaica JM

Japan JP

Kenya KE

Kuwait KW

Libya LY

Luxembourg LU

Malaysia MY

Maldives MV

Mexico MX

Monaco MC

Mongolia MN

Morocco MA

Nepal NP

Netherlands NL

Antilles AN

New Zealand NZ

Nigeria NG

Norway NO

Oman OM

Pakistan PK

Panama PA

Paraguay PY

Philippines PH

Poland PL

Portugal PT

Romania RO

Russian Federation RU

Saudi Arabia SA

Senegal SN

Singapore SG

Slovak Republic SK

Slovenia SI

South Africa ZA

South Korea KR

Spain ES

Sri Lanka LK

Sweden SE

Switzerland CH

Taiwan T W

Thailand TH

Turkey TR

Uganda UG

Ukraine UA

United States US

Uruguay UY

Uzbekistan UZ

Vietnam VN

Zimbabwe ZW

Appendix

Appendix50

Language code list

Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Sindhi 8368

Singhalese 8373

Slovak 8375

Slovenian 8376

Spanish 6983

Sudanese 8385

Swahili 8387

Swedish 8386

Tagalog 8476

Tajik 8471

Tamil 8465

Telugu 8469

Thai 8472

Tonga 8479

Turkish 8482

Turkmen 8475

Twi 8487

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapük 8679

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 7473

Yoruba 8979

Zulu 9085

Appendix

Afar 6565

Afrikaans 6570

Albanian 8381

Amharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Aymara 6588

Azerbaijani 6590

Bashkir 6665

Basque 6985

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton 6682

Bulgarian 6671

Burmese 7789

Byelorussian 6669

Chinese 9072

Croatian 7282

Czech 6783

Danish 6865

Dutch 7876

English 6978

Esperanto 6979

Estonian 6984

Faroese 7079

Fiji 7074

Finnish 7073

French 7082

Frisian 7089

Galician 7176

Georgian 7565

German 6869

Greek 6976

Greenlandic 7576

Guarani 7178

Gujarati 7185

Hausa 7265

Hebrew 7387

Hindi 7273

Hungarian 7285

Icelandic 7383

Indonesian 7378

Interlingua 7365

Irish 7165

Italian 7384

Japanese 7465

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kirghiz 7589

Korean 7579

Kurdish 7585

Laotian 7679

Latin 7665

Latvian, Lettish 7686

Lingala 7678

Lithuanian 7684

Macedonian 7775

Malagasy 7771

Malay 7783

Malayalam 7776

Maori 7773

Marathi 7782

Moldavian 7779

Mongolian 7778

Nauru 7865

Nepali 7869

Norwegian 7879

Oriya 7982

Panjabi 8065

Pashto, Pushto 8083

Persian 7065

Polish 8076

Portuguese 8084

Quechua 8185

Rhaeto-Romance 8277

Rumanian 8279

Russian 8285

Samoan 8377

Sanskrit 8365

Scots Gaelic 7168

Serbian 8382

Serbo-Croatian 8372

Shona 8378

Trademarks and licenses

Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™, BONUSVIEW™ and the logos are trademarks of the Blu-ray Disc Association.

Appendix 51

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

“DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation.

Java is a trademark of Oracle and/or its aliates.

HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

“x.v.Colour” is a trademark of Sony Corporation.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

DivX®, DivX Certied® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.

Appendix

Appendix52

Cinavia Notice

This product uses Cinavia technology to limit the use of unauthorized copies of some commerciallyproduced lm and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted.

More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA.

This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Appendix

Audio output specifications

Appendix 53

Jack/Setting

Source

Dolby Digital PCM 2ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch DTS Dolby Digital

Dolby TrueHD PCM 2ch DTS Dolby Digital

DTS PCM 2ch DTS DTS

DTS-HD PCM 2ch DTS DTS

Linear PCM 2ch PCM 2ch DTS PCM 2ch

Linear PCM 5.1ch PCM 2ch DTS PCM 2ch

Linear PCM 7.1ch PCM 2ch DTS PCM 2ch

Jack/Setting

Source

Dolby Digital PCM 2ch PCM 2ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch PCM 2ch DTS Dolby Digital Plus

Dolby TrueHD PCM 2ch PCM 2ch DTS Dolby TrueHD

DTS PCM 2ch PCM 2ch DTS DTS

DTS-HD PCM 2ch PCM 2ch DTS DTS-HD

Linear PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch

Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch

Linear PCM 7.1ch PCM 2ch PCM 7.1ch DTS Linear PCM 7.1ch

*1 The secondary and interactive audio may not

be included in the output bitstream if [Digital Output] option is set to [BitStream]. (Except LPCM Codec : the output always include interactive and secondary audio.)

*2 This player automatically selects the HDMI audio

according to the decoding capability of the connected HDMI device even though [Digital Output] option is set to [BitStream].

*3 On the PCM audio output, the sampling

frequency of DIGITAL AUDIO OUT is limited to 96 kHz.

COAXIAL (DIGITAL AUDIO OUT)

PCM Stereo

PCM Stereo PCM

DTS Re-encode

HDMI OUT

Multi-Ch

*4 If the [Digital Output] option is set to [DTS re-

encode], the audio output is limited to 48 kHz and 5.1Ch. If the [Digital Output] option is set to [DTS re-encode], the DTS Re-encode audio is outputted for BD-ROM discs, and the original audio is outputted for the other discs (like [BitStream]).

yIf the HDMI OUT jack is connected to your TV

with High Speed HDMI™ Cable and Dolby Digital Plus/Dolby TrueHD is outputted from HDMI OUT jack, COAXIAL OUT jack is limited to “PCM 2ch” (When the HDMI and DIGITAL AUDIO OUT are connected simultaneously).

DTS Re-encode

BitStream

*1 *

Appendix

Appendix54

yThe audio is outputted as PCM 48 kHz/16 bit for

MP3/WMA le and PCM 44.1kHz/16 bit for Audio CD while playback.

yYou must select a digital audio output and

a maximum sampling frequency that your Amplier (or AV receiver) accepts using [Digital Output] and [Sampling Freq.] options on the [Setup] menu (see page 27).

yWith digital audio connection (DIGITAL AUDIO

OUT or HDMI OUT), Disc Menu button sounds of BD-ROM may not be heard if the [Digital Output] option is set to [BitStream].

yIf the audio format of the digital output does

not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

yMulti-channel Digital Surround Sound via digital

connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder.

Appendix

Specifications

General

Power requirements DC 12 V 0 1 A

AC adapter WA-12M12Fx

Dimensions (W x H x D) Approx. 270 x 39 x 198 mm

Net Weight (Approx.) 0.95 Kg

Operating temperature 5 °C to 35 °C

Operating humidity 5 % to 90 %

Outputs

HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)

DIGITAL AUDIO OUT (COAXIAL) 0.5 V (p-p), 75 Ω, RCA jack x 1

System

Laser Semiconductor laser

wavelength 405 nm / 650 nm

Signal system Standard PAL / NTSC colour TV system

LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX

Bus Power Supply (USB) DC 5 V 0 500 mA

Appendix 55

yDesign and specications are subject to change without notice.

Appendix

Appendix56

Maintenance

Handling the unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Keeping the exterior surfaces clean

yDo not use volatile liquids such as insecticide

spray near the unit.

yWiping with strong pressure may damage the

surface.

yDo not leave rubber or plastic products in

contact with the unit for a long period of time.

Maintaining the unit

The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty

or worn, the picture quality could be diminished.

Appendix

For details, please contact your nearest authorized service centre.

Notes on discs

Handling discs

Do not touch the playback side of the disc. Hold the disc by the edges so that ngerprints do not get on the surface. Never stick paper or tape on the disc.

Storing discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight.

Cleaning discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the centre to out.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.

Important information relating to network services

All information, data, documents, communications, downloads, les, text, images, photographs, graphics, videos, webcasts, publications, tools, resources, software, code, programs, applets, widgets, applications, products and other content (“Content”) and all services and oerings (“Services”) provided or made available by or through any third party (each a “Service Provider”) is the sole responsibility of the Service Provider from whom it originated.

The availability of and access to Content and Services furnished by the Service Provider through the LGE Device are subject to change at any time, without prior notice, including, but not limited to the suspension, removal or cessation of all or any part of the Content or Services.

Should you have any inquiry or problem related to the Content or Services, you may refer to the Service Provider’s website for the most up-todate information. LGE is neither responsible nor liable for customer service related to the Content and Services. Any question or request for service relating to the Content or Services should be made directly to the respective Content and Service Providers.

Please note that LGE is not responsible for any Content or Services provided by the Service Provider or any changes to, removal of, or cessation of such Content or Services and does not warrant or guaranty the availability of or access to such Content or Services.

Appendix 57

Appendix

Panasonic BP325N, BP325 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Information

Getting Started

Introduction

Playable discs and symbols used in this manual

About the “7” symbol display

Compatibility notes

File requirement

AVCHD (Advanced Video Codec High Definition)

Certain system requirements

Regional code

System select

Remote control

Front panel

Rear panel

Connecting the AC adapter

Connecting to your TV

Connecting

What is SIMPLINK?

Resolution setting

Connecting to an amplifier

Connecting to an amplifier via HDMI output

Connecting to an amplifier via digital audio output

Connecting to your home network

Wired network connection

Wired network setup

USB device connection

Playback content in the USB device

Settings

Initial Setup

System Setting

Adjust the setup settings

[DISPLAY] Menu

[LANGUAGE] Menu

[AUDIO] Menu

[LOCK] Menu

[NETWORK] Menu

[OTHERS] Menu

General Playback

Using [HOME] menu

Operating

Playing a disc

Playing a file on disc/USB device

Playing Blu-ray 3D disc

Enjoying BD-Live™

Basic operations for video and audio content

Basic operations for photo content

Using the disc menu

Resume playback

Last scene memory

Advanced Playback

Repeat playback

Repeating a specific portion

Viewing content information

Changing content list view

Options while viewing a photo

Listening to music while slide show

On-screen display

Displaying content information on-screen

Playing from selected time

Selecting a subtitle language

Hearing a different audio

Watching from a different angle

Changing the TV Aspect Ratio

Changing subtitle Code Page

Changing the Picture Mode

Using the Premium

Troubleshooting

General

Troubleshooting

Network


Customer support

Open source software notice

Controlling a TV with the supplied remote control

Appendix

Setting up the remote to control your TV
