PRODUCT DATASHEET

Osprey ® 820e

Video Capture Card

Two solutions in a
single capture card.

The Osprey 820e continues the strong tradition of high-quality streaming performance. The latest video capture card
now lets you add audio and video to a traditional graphics interface making it an ideal solution for lecture capture.
This dual input card can ingest SD or HD analog video as well as VGA, HDMI and DVI.

Optimized for live streaming.

Take advantage of advanced video pre-processing
features such as logo/bitmap overlay with transparency
and positioning controls, de-interlacing, color space
conversion and closed-caption extraction and render­ing. Wide screen signaling is also standard.

Ideal Solutions

> Education

> Enterprise

> Global OEM systems integrators

Applications

> Presentation capture

- Lectures

- Corporate meetings

> Webcasting
> Live streaming
> Podcasting
> Mobile TV
> Video on Demand

Multiple streams.

The Osprey 820e also comes standard with
SimulStream®. This driver enhancement provides
the ability to feed multiple encoding applications
at the same time.

Key Attributes

> HDMI/DVI/VGA input

> Accepts analog SD and HD video inputs

> Automatically senses signal types

> PCIe host interface

> SimulStream option enables:

- Completely independent settings for sizing,

scaling and bit rate speeds, plus logo overlays
with dynamic positioning

- A multitude of simultaneous video format outputs

> Professional features, such as loss of video

detection, color space conversion, automatic
telecine detection and processing, and automatic
optimization for changing motion content

> Drivers available for Microsoft® Windows®

and Linux operating systems

Continue the Legacy. Capture the Future.

OSPREY

®

820e

Video Capture Card

Specifications

Osprey 820e card

DVI Dongle to component x 2

Supported Digital Modes

1920 x 1080/60/p 1280 x 1024/85

1920 x 1080/59.94/p 1280 x 1024/60

1920 x 1080/50/p 1280 x 960/85

1920 x 1080/60/i 1280 x 960/60

1920 x 1080/59.94/i 1280 x 800/60

1920 x 1080/50/i 1280 x 768/85

1920 x 1080/30/p 1280 x 768/60

1920 x 1080/29.97/p 1280 x 720/60

1920 x 1080/25/p 1280 x 720/59.94

1920 x 1080/24/p 1280 x 720/50

1920 x 1080/23.98/p 1024 x 768/85

1600 x 1200/60 1024 x 765/60

1440 x 900/85 800 x 600/85

1440 x 900/60 800 x 600/60

1400 x 1050/85 640 x 480/85

1400 x 1050/60 640 x 480/75

1360 x 768/60 640 x 480/60

HDCP not supported.

DVI to VGA or HDMI
adapters x 2

Y/C to S-Video Adapter

Driver Support:

• Microso® DirectShow® API

• Linux available from open source community

Inputs:

Video:

Two channels of acve video are available. Each channel can
be any of the following:

• 2x DVI-I

• 2x HDMI

up to 1920 x 1080 at 60 fps
(DVI - HDMI adapters included)

• 2x VGA/XVGA resoluons

up to 1600 x 1200 at 60 Hz
(DVI - VGA adapters included)

Three composite inputs are available but only one can be
used on each MFI.

• 2x Component

• 6x Composite

• 2x S-Video

(component breakout, BNC - RCA adapters
included, and BNC - mini included)

Audio:

• HDMI (2 x 8 channels LPCM)

• Unbalanced (1 x stereo)

Connectivity:

PCI Express (x 4):

•

Slots: x 4, x 8, or x 16

Pre-Processing:

• Closed-capon extracon / rendering

• Logo / bitmap overlay

• Scaling, cropping, de-interlacing and

inverse telecine

• Loss of video automac test paern

generaon with text overlay opon

Dimensions:

• Half-length board

• 6.60” L x 4.38” H (16.76 cm L x 11.13 cm H)

Supported Analog Modes

1920 x 1080/60 1280 x 960/85

1920 x 1080/59.94 1280 x 960/60

1920 x 1080/50 1280 x 800/60

1920 x 1080/25 1280 x 768/85

1920 x 1080/24 1280 x 768/75

1920 x 1080/23.98 1280 x 720/60

1600 x 1200/60 1280 x 720/50

1440 x 900/75 1024 x 768/85

1400 x 1050/75 1024 x 768/60

1400 x 1050/60 800 x 600/85

1360 x 768/60 640 x 480/85

1280 x 1024/85 640 x 480/60

1280 x 1024/60

Continue the Legacy. Capture the Future.

North America 800 251 7900 | Europe

Hardware Warranty:

• 1 year limited hardware warranty

System Requirements:

• Mul-core processors (4 or more) are recommended

to run video applicaons.

The Osprey 820e video capture card requires intense band­widths across the system bus, CPU, and memory. The host
computer system capabilies (CPU, RAM, and motherboard)
must be capable of processing this amount of data.

/
