Oreck COMPACTO 6, COMPACTO 9 User Guide

40372-01 Rev B

SIMPLY AMAZING

USER’S GUIDE

PROFESSIONAL

GRADE

COMMERCIAL

COMPACTO 6 COMPACTO 9

•IMPORTANT•

SAVE THIS BOOKLET!

Includes:

• Safety Warnings

• Warranty

• Operating Instructions

• Trouble Diagnosis

USA / Canada: 1-800-336-0433

www.commercial.oreck.com

Table of Contents

Maintenance and Customer Service, Grounding Instructions, Important Safety Instructions . page 2

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3

Assembly General Information, Replacing the Exhaust Filter, . . .

Replacing and Cleaning the Motor Filter, . . . . . . . . . .

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . page 5

, Operating Instructions . . . . . . . . . . . . . . . . . page 4

arranty, Replacement Parts . . . . . . . . . . . . . . . . . . . . page 6

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic

precautions should always be followed,

including the following:

READ ALL INSTRUCTIONS BEFORE

USING THIS VACUUM CLEANER

BEFORE OPERATING CLEANER,

READ ALL INSTRUCTIONS IN

THIS MANUAL CAREFULLY.

Maintenance and Customer Service

Your Oreck vacuum cleaner is a product of precise engineering. The motor bearings are permanently lubricated and should not be oiled. If you require additional information or have problems with your Oreck appliance, you may call ORECK Commercial Customer Service at:

USA / Canada: 1-800-336-0433

Please specify the model number and serial/code number which can be found on the data plate on the back of the vacuum.

Save your sales or purchase slip. Should your Oreck appliance require warranty service in the U.S.A., present this slip to the Authorized Service Center as your proof of purchase date or, in Canada, call customer service.

Grounding Instructions (Compacto 9 model)

This appliance must be grounded. If it should malfunction or break down, grounding provides a safe path of least resistance for electrical current, reducing the risk of electric shock. The cord for this appliance has an equipment-grounding conductor and a grounding plug. It must only be plugged into an electrical outlet that is properly installed and grounded in accordance with all local codes and ordinances. Do not modify plug provided with appliance.

DANGER: Improper connection of the equipment-grounding conductor can result in a risk of electrical shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is grounded. If not, have a proper outlet installed by a qualified electrician.

This appliance is for use on a nominal 120-volt circuit. It has a grounding plug similar to the example shown. Make sure the appliance is connected to an outlet with the same configuration as the plug. No adapter should be used with this appliance.

Grounded Outlet

Grounding Pin

• Do not use outdoors or on wet surfaces.

• Do not allow to be used as a toy. Close attention is necessary

• Use only as described in this manual. Use only manufacturer’s

• Do not leave appliance unattended when plugged in. Unplug from

• Connect to a properly grounded outlet only. See: Grounding

• Do not use with damaged cord or plug.

• If vacuum cleaner is not working as it should, has been dropped,

• Do not pull or carry by cord, use cord as a handle, close door on

• Do not run vacuum over cord.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not

• Do not handle plug or vacuum cleaner with wet hands.

• Do not put any object into openings. Do not use with any opening

• Keep hair, loose clothing, fingers and all parts of body away from

• Do not use to pick up anything that is burning or smoking, such as

• Do not use without filter bag assembly in place.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up flammable or combustible liquids, such as

• Do not use appliance in an enclosed space where flammable,

•

• Use caution when vacuuming over area rug edges and fringe.

• Do not use extension cords or outlets with inadequate current

WARNING

To reduce the risk of fire,

electric shock, or injury:

when used by or near children.

recommended attachments.

outlet when not in use and before servicing.

Instructions (Compacto 9 only).

damaged, left outdoors, or dropped into water, return it to a service center or call customer service at:

USA / Canada: 1-800-336-0433

cord, or pull cord around sharp edges or corners. Keep cord away from heated surfaces.

the cord.

blocked; keep free of dust, lint, hair and anything that may reduce air flow.

openings and moving parts.

cigarettes, matches, or hot ashes.

gasoline or lighter fluid, or use in areas where they may be present.

explosive or toxic vapors are given off by oil base paint, paint thinner, some mothproofing substances, or in an area where flammable dust is present.

Do not pick up toxic material such as chlorine bleach, drain cleaner, gasoline, etc. with this appliance.

carrying capacity

Servicing of Double-Insulated Appliances

(Compacto 6 model)

A double-insulated appliance is marked with one or more of the following: The words “DOUBLE INSULATION” or “DOUBLE INSULATED” or the double-insulation symbol ( ). In a doubleinsulated appliance, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-insulated appliance, nor should a means for grounding be added to the appliance. Servicing a double-insulated appliance requires extreme care and knowledge of the system and should be done only by qualified service personnel. Replacement parts for a double-insulated appliance must be identical to the parts they replace.

SAVE THESE INSTRUCTIONS

For Commercial Use

Parts List

To assist you in identifying components of your vacuum, the parts have been numbered as follows:

Latch

2. Disposable Exhaust Filter

3. Cord Hooks

4. Cord Strain Relief

5. Crevice Tool Holder

6. Normal Use / Quiet Mode (Compacto 9 model)

7. On / Off Switch Handle

8. Power Cord

9. Intake

10.

11. Crevice Tool

12. Dual Purpose Nozzle (Compacto 9 model)

13. Carpet Nozzle

14. Upholstery Tool

15. Dusting Brush

16. Telescopic Wand

17. Suction Control

18. Hose Assembly

19. Bare Floor Nozzle (Compacto 6 model)

20. Carpet Height Adjustment (Compacto 9 model)

21. Motor Inlet Filter (not shown)

22. Paper Filter Dust Bag (not shown)

Compacto 9

Compacto 6

141516
