Oreck BB1005 User's Guide

SIMPLY AMAZING
TM
USER’S GUIDE
Compact
Canister
Vacuum
BB1005
SAVE THIS BOOKLET!
Includes:
• Safety Warnings
• Parts List
• Operating Instructions
• Maintenance
• Warranty
• Trouble Diagnosis
• Accessories List
73063-01 REV A
6
1
BEFORE OPERATING CLEANER, READ ALL
INSTRUCTIONS IN THIS
MANUAL CAREFULLY.
IIMMPPOORRTTAANNTT SSAAFFEETTYY
IINNSSTTRRUUCCTTIIOONNSS
Table of Contents
Safeguards
Safeguards, Important Electrical Information,
Important Safety Instructions...................................page 2
Warranty, Parts List, Accessories............................page 3
Assembly, Polarized Plug Notice, To Operate,
Maintenance ..........................................................page 4
Maintenance & Customer Service,
Troubleshooting Guide............................................page 5
IMPORTANT: Make sure filter bag is in place. Do not operate cleaner without filter bag. Damage to motor may occur.
• Be sure bag gasket is in place. If the white bag gasket is damaged or lost, replace at once.
• For best results, change disposable filter bag regularly even if it is not completely full. An extremely dirty bag or a bag close to full will affect the suction of the cleaner and can create excessive motor heat that could damage the motor. A good practice is to change the filter bag every 30 days even if it is not full.
• Do not pick up moist materials or liquids.
• Clean your vacuum cleaner with a damp (not wet) cloth in the disposable bag cavity and the outside of canister unit.
MOTOR PROTECTION SYSTEM: If fine materials such as soot, cement, plaster dust, copy machine powder, etc. are picked up, the bag surface may seal and cause the motor to shut off to avoid over-heating. If this happens, turn the switch off and unplug the cleaner. Replace filter bag. Check and clear any clogs in hose or accessories. After approximately 30 min. the motor will have cooled and the cleaner will be ready to use.
Note: The cleaner must remain unplugged for 30 minutes for motor to cool and system to reset.
The wires in this main lead are coloured in accordance with the following code:
Blue-Neutral Brown-Live
If the colours of the wires in the main lead of this appliance do not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black. The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or coloured Red. Do not make any connection to
the terminal marked E or coloured green and yellow.
This appliance is double insulated and no earth connection is necessary.
If you remove the plug from power supply cord, dispose of it. Ashock hazard could result if incorrect plug is inserted into a 13 AMP socket outlet.
When changing the fuse, use 5 AMP or same size replacement fuse.
Never use the plug without the fuse cover fitted in place. The fuse carrier is red and hinged to the plug. Do not use the plug if it is different. If necessary, you may contact customer services for replacement fuse covers.
• Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and before servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this manual.
• Do not use with damaged cord or plug.lf appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, retum it to a service center. Call free on 0845 603 0153 for the service center nearest you.
• Do not pull or carry by cord, use cord as a handle, close door on cord, or pull cord around sharp edges or corners. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and anything that may reduce air flow.
• Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
• Do not use to pick up anything that is buming or smoking, such as cigarettes, matches, or hot ashes.
• Do not use without filter bag assembly in place.
• Tum off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids, such as gasoline or lighter fluid, or use in areas where they may be present.
• Do not use appliance in an enclosed space where flammable, explosive or toxic vapors are given off by oil base paint, paint thinner, some moth proofing substances, or in an area where flammable dust is present.
• Do not pick up toxic material such as chlorine bleach, drain cleaner, gasoline, etc. with this appliance.
SSAAVVEE TTHHEESSEE IINNSSTTRRUUCCTTIIOONNSS
Household Use Only
2
When using an electrical appliance, basic
precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE
USING THIS VACUUM CLEANER
WWAARRNNIINNGG
To reduce the risk of fire,
electric shock, or injury:
Important Electrical Information
WARNING:Unplug cord from electrical
outlet before servicing.
5
Oreck UK P.O. Box 107 Exeter EX2 8ZQ
Warranty
Parts List
ORECK MANUFACTURING COMPANY: (Oreck 21180 Johnson Road; Long Beach, MS, USA 39560 gives you the following warranty for this product only if it was originally purchased for residential use, not resale from Oreck or an Oreck Authorized Retail Dealer.)
Oreck will repair or replace, free of charge, to the original purchaser, any part that is found to be defective in material or workmanship within three (3) years of the date of purchase; ten (10) years on housing. This warranty applies to normal domestic use. Any commercial use of this product will void this warranty.
This warranty does not cover the replacement of expendable or consumable parts such as belts, brushes, bulbs, disposable bags and other parts subject to normal wear unless they are defective in material or workmanship.
This warranty does not apply to any part subjected to accident, abuse, alteration, misuse, damage caused by act of God, the use of voltages other than indicated on the serial number displayed on this product or service of this product by other than Oreck or a participating Factory Authorized Service Center.
Oreck does not authorize any person or representative to assume or grant any other warranty obligation with the sale of this product.
Oreck's warranty is valid only if you retain proof of purchase from Oreck or an Oreck Authorized Retail Dealer for this product. If you purchase this product from any other source, your purchase is "AS IS;" which means Oreck grants you no warranty, and thatyou, not Oreck, assume the entire risk of the quality and performance of this product, including the entire cost of any necessary servicing or repairs of any defects.
This warranty is in addition to your statutory and other legal rights. Ex-demonstration units carry a one year warranty.
Accessories (Sold Seperately)
ITEM PART #
Replacement Hypo-Allergenic Filter Bags 12 Pk. with 1 Micro Filter PKBB12DW
Replacement Micro Filter 72005-01 Replacement HEPA Filter HF1000 Replacement White Bag Gasket 72017-02 Wire Tool Rack BBRACK Vinyl Tool Rack CADDYBB Fresh Air® Scent Cartridges
Notes of Vanilla® 8pk FA1PK Spring Mulberries® 8pk FA2PK Blooming Jasmine® 8pk FA3PK
3
