ONE FOR ALL URC-3425 User Manual
Universal remote
Universal Fernbedienung
Télécommande universelle
Mando a Distancia Universal
Telecomando Universal
Telecomando Universale
Universele Afstandsbediening
∆ЛПВ¯ВИЪИЫЩ‹ЪИФ
English
Deutsch
Français
Español
Português
Italiano
Nederlands
EППЛУИО¿
URC-3425
Instruction manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 2
2 WWW.ONEFORALL.COM
PICTURE OF THE ONE FOR ALL 2 REMOTE
3
INSTALLING THE BATTERIES
4
THE KEYPAD
4
SET UP
SETTING UP THE ONE FOR ALL 2
6
Direct code set up 6
Search Method 7
SET-UP CODES
EXTRA FEATURES
Mode re-assignment (Changing a device mode)
8
Volume Punch Through
9
QUICK CODE REFERENCE
10
PROBLEM & SOLUTION
10
CUSTOMER SERVICE
11
Table of Contents
Your ONE FOR ALL 2 Package contains:
• Your ONE FOR ALL 2 Remote
• Your ONE FOR ALL 2 Manual
Your manual is divided into two parts: set-up instructions and device codes.
You may need this guide again in the future, so please be sure to
keep it.
Your ONE FOR ALL 2 needs 2 new “AA/LR6” alkaline batteries.
Your ONE FOR ALL 2 can operate two devices: a Television and a Video
Recorder.
About Your ONE FOR ALL 2
English
Televisions 11
Video Recorders 19
WWW.ONEFORALL.COM 3
1
9
7
4
5
6
10/11
8
3
2
Installing the Batteries
Your ONE FOR ALL 2 needs 2 new “AA/LR6” alkaline batteries.
1 Remove the battery cover from the back of your ONE FOR ALL 2 by
pressing down on the tab.
2 Match the batteries to the + and - marks inside the battery case,
then insert the batteries.
3 Press the battery cover back into place.
See picture of ONE FOR ALL 2 remote on page 3
1 LED
The LED (Light Emitting Diode) flashes red to show the remote is
working.
2 MAGIC Key
The MAGIC key is used to set up your ONE FOR ALL 2.
3 MENU Key
The MENU key controls the same function as it did on your original
remote.
4 POWER Key
The Power key controls the same function as it did on your original
remote.
5 Device Keys
The TV and VCR keys select the device to be controlled. For example pressing the TV key allows the remote to control the functions of your Television and after pressing VCR you can operate
your Video Recorder.
6 Number Keys
The Number keys (0-9, 10, 20 (AV)) provide functions just like your
original remote, such as direct access programme selection. If your
original remote uses one/two digit input switching (-/-- symbol), this
function can be obtained by pressing the -/-- key, which is the same
as the 10 key. If your original remote has an 20 key, this function can
also be found under the AV key.
7 Programme (Channel) +/- Keys
These keys operate in the same way as the keys on your original
remote. If available on your original remote, these keys will allow
you to navigate through the menu.
The Keypad
Important notes:
- In order to avoid having to reprogram your ONE FOR ALL 2 after
you remove the batteries, you will need to insert new batteries
within 5 minutes. Also it is best that you do not use rechargable
batteries.
- On the inside of the battery compartment door you will find a
label on which to write your Set-Up codes after your ONE FOR
ALL 2 is set up for your device. Please write down your codes for
easy, future reference.
WWW.ONEFORALL.COM 4
WWW.ONEFORALL.COM 5
8 MUTE Key
The Mute key operates the same function it did on your orginal
remote control. Also, if your original remote control required that
you press an “OK” or “ENTER” key during Menu operation, the
Mute key can be used for this function.
9 Volume +/- Keys
These keys operate in the same way as the keys on your original
remote. If available on your original remote, these keys will allow
you to navigate through the menu.
10 Video Recorder Keys
After pressing the VCR key, the Video Recorder keys operate the
functions of your Video Recorder. To prevent accidental recording,
the Record key must be pressed twice to start recording.
11 Teletext and Fastext Keys
After pressing the TV key, the top row of the VCR keys is used to
operate the main Teletext functions. The symbols below the keys are
for Teletext. The text keys are used to access the Teletext functions
of your television. Of course, your television must have Teletext
capability.
TEXT ON: Puts the television in the Teletext mode.
TEXT OFF: Switches the television back to regular viewing mode. On
some televisions, this may be done by pressing the TEXT ON key
several times.
HOLD/STOP: Stops changing pages.
EXPAND: Shows the top half of the Teletext page in larger letters.
By pressing again, you can see the bottom half of the Teletext page
enlarged. To return to regular Teletext viewing, press the EXPAND
key again, or press the TEXT ON key, depending on your television.
After pressing the TV key and accessing the text mode, the bottom row of
the Video Recorder keys marked
red, green, yellow and blue, allow you
to access the Fastext functions of your television. If on your original
remote control these keys are used for Menu navigation, the ONE
FOR ALL Fastext keys may operate in the same way.
Important note: For a more detailed explanation of Teletext and Fastext,
please refer to the manual of your television. Remember, different televisions
control Teletext and Fastext features in different ways. Not all of the Teletext
functions may be available for your particular model.
6 WWW.ONEFORALL.COM
3 Press and hold down MAGIC until the red light blinks
twice. (The red light will blink once and then twice.)
4 Enter your (four-digit device code) using the number
keys. The red light will blink twice.
5 Now, aim the ONE FOR ALL 2 at your device and
press POWER If your device switches off, the ONE
FOR ALL 2 is ready to operate your device.
6
Turn your device back on and try all the remote’s functions to ensure
they are working properly. If the functions do not work properly,
repeat steps 1-5 using another code listed under your brand.
7 If your device does not respond, follow steps 1 to 5 with
each code listed for your brand. If none of the codes listed
for your brand operate your device, or if your brand is not
listed at all, try the search method described on page 7.
8 Write your code in the four boxes provided in the battery
compartment and on page 10 for easy future reference.
Setting up the ONE FOR ALL 2
Before you start, please read these instructions carefully
Important notes:
- Most TV’s do not switch on pressing the POWER key. Please try pressing a
“number” key or the “TV-text off” key to switch your TV back on.
- Some codes are quite similar. If your device does not respond or is not
functioning properly with one of the codes, try another code listed under
your brand.
- If your device’s original remote control does not have a POWER key, press
PLAY instead of POWER when setting up your device.
- Remember to press the correct device key before operating your device.
Only one device can be assigned to a device key. If your original remote
operates more than one device, you need to set up each device separately.
MAGIC
____
6 WWW.ONEFORALL.COM
Devices can be found under the following keys:
Video Recorder
Television
VCRTV
Direct code set up
Example: To set up the ONE FOR ALL 2 for your television:
1
ONE FOR A
Acura
Admiral
Adyson
Agazi
AGB
Agef
Aiko
2 Press the TV key
Find the code for your device in the Code list (page 11 - 22).
1
4
, 0
3
6
9
3
0
0
, 0
0
3
9
0
, 0
7
8
0
0
6
1
2
, 0
Codes are listed by device type and brand name.
7
1
2
0
4
6
2
0
6
1
5
0
, 0
7
3
7
0
8
0
, 0
0
9
0
0
, 0
6
1
2
The most popular code is listed first.
0
4
7
2
1
, 0
7
7
3
3
0
, 0
0
8
0
2
, 0
1
6
3
0
device is switched on (not on standby).
TV
on the ONE FOR ALL 2.
Make sure your
The Search Method
If your device does not respond to the ONE FOR ALL 2 after you have tried
all the codes listed for your brand, try searching for your code. The Search
Method allows you to find the code for your device by scanning through all
the codes contained in the memory of the ONE FOR ALL 2. The Search
Method may also work if your brand is not listed at all.
Example: To search for your TV code:
1 Switch your television on (not on standby).
2 Press the TV key on your ONE FOR ALL 2.
3 Press and hold down MAGIC until the ONE FOR ALL 2’s
red light blinks twice (The red light will blink once and
then twice).
4 Press 9 9 1. The red light will blink twice.
5 Next, press POWER.
6 Aim the ONE FOR ALL 2 at your Television. Now press CH+
over and over, until your Television turns off (everytime
you press the CH+ key the ONE FOR ALL 2 will send out a
POWER signal from the next code contained in the memory). You may have to press this key many times (up to 150
times) so please be patient. If you skip past a code, you
can go to the previous code(s) by pressing the CH- key.
Remember to keep pointing the ONE FOR ALL 2 at your
Television while pressing this key.
7 As soon as your television turns off, press MAGIC to store
the code.
Once you have Set-Up your ONE FOR ALL 2, you can blink back your
SET-UP CODE for future reference.
Example: To blink out your Television code:
1
Press TV once.
2 Press and hold MAGIC until the ONE FOR ALL 2’s red
light blinks twice (The red light will blink once and then
twice).
3 Press 9 9 0. The red light will blink twice.
4 For the first digit of your four-digit code, press 1 and
count all the red blinks. If there are no blinks, the digit is
"0".
5 For the second digit, press 2 and count all the red blinks.
If there are no blinks, the digit is "0".
6 For the third digit, press 3 and count all the red blinks.
If there are no blinks, the digit is "0".
7 For the fourth digit, press 4 and count
all the red blinks. If there are no blinks, the digit is "0".
Now you have your four-digit code.
Important notes:
- Most TV’s do not switch on pressing the POWER key. Please try pressing a
“number” key or the “TV-text off” key to switch your TV back on.
- To search for the code for your Video Recorder follow the instructions
above only press the VCR device key instead of TV during step 2.
- If your Video’s original remote control does not have a POWER key, press
PLAY instead of POWER during step 5.
WWW.ONEFORALL.COM 7
MAGIC
MAGIC
MAGIC
9
919
9
0
1
2
3
4
TV
