Olympus SH-1 Instruction Manual

Page 1

DIGITAL CAMERA

SH -1

Instruction Manual

Thank you for purchasing an O lympus digital camera. Before you star t to

use your new c amera, please read these instr uctio ns carefully to enjoy optimum p erfo rmanc e and a longer ser vice life. Keep this manual in a safe place for future reference.

We recommend that you take test shots to get accustomed to your cam era

before taking important photographs.

The screen and camera illustrat ions shown in this manual were produced

during the development stages and may differ from the actual product .

Page 2

Unpack the box contents

The following items are included with the camera. If anything is missing or damaged, contact the dealer from whom you purchased the camera.

Digital camera Strap

Stylus pen USB-AC adapter (F-2AC) USB cable (CB-USB8)

Other accessories not shown: Warranty card Contents may vary depending on purchase location.

• The touch panel can be used for operations marked with  in this manual.

Lithium Ion Battery

(LI-92B)

OLYMPUS Setup

CD-ROM

Attaching the camera strap

• Attach the strap to the other eyelet in the same manner.

• Pull the strap tight so that it does not come loose.

Page 3

Names of parts

1 Connector cover 2 Strap eyelet 3 Self-timer lamp/AF illuminator 4 Lens 5 Built-in flash 6 Flash switch 7 Stereo microphone 8 Indicator lamp 9 n button 0 Zoom lever a Shutter button b Mode dial c Monitor (Touch screen) d R (Movie) button e q (Playback) button f A button

• FGHI instruct to press the up/down/left/right arrow pad.

g INFO (Information display) button h /Wi-Fi button i Multi-connector j HDMI micro connector k Speaker l Battery/card compartment lock m Battery/card compartment cover n Tripod socket o Arrow pad p F (Up) / F (Exposure

compensation) button

q I (Right) /# (Flash) button r H (Left) button s G (Down) / jY (Sequential

shooting/Self-timer) /  (Erase) button

Page 4

Preparations for shooting

Inserting and removing the battery and card

Follow Steps 1 and 2

to open the battery/card compartment cover.

• Turn off the camera before opening the battery/card compartment cover.

Insert the battery while sliding

the battery lock knob in the direction of the arrow.

• Insert the battery as illustrated with the C mark toward the battery lock knob.

• Slide the battery lock knob in the direction of the arrow to unlock, and then remove the battery.

Insert the card straight until it clicks

into place.

• Always use the specified cards with this camera. Do not insert other types of memory cards. g “Using the card” (P. 94)

• Do not touch the metallic parts of the card directly.

Battery/card compartment lock

Battery/card compartment cover

Battery lock knob

Write-protect switch

Page 5

To remove the card

Press the card in until it clicks and comes out slightly, then remove the card.

Follow Steps 1 and 2 to

close battery/card compartment cover.

• When using the camera, be sure to close the battery/card compartment cover.

Page 6

Charging the battery

Connect the USB cable and USB-AC adapter to the camera

and charge the battery.

• The battery is not fully charged at shipment. Before use, be sure to charge the battery until the indicator lamp turns off (up to 4.5 hours).

Connecting the camera

Indicator lamp On: Charging Off: Charged

Multi-connector

Connector cover

For charging the battery abroad, see “Using your charger and USB-AC adapter abroad” (P. 93).

Never use any cable other than supplied or Olympus-designated USB cable.

This may cause smoking or burning.

The included F-2AC USB-AC adapter (hereafter referred to as USB-AC

adapter) differs depending on the region where you purchased the camera. If you received a plug-in type USB-AC adapter, plug it directly into AC outlet.

Be sure to unplug the power plug of the USB-AC adapter from the wall outlet

when the charging is complete or the playback ends.

For details on the battery, see “Battery Handling Precautions” (P. 102). For

details on the USB-AC adapter, see “USB-AC adapter” (P. 103).

AC outlet

USB cable (supplied)

Page 7

• If the indicator lamp does not light, check the USB cable and USB-AC adapter connections.

• If “No Connection” is displayed on the back monitor, disconnect the USB cable and set [Storage] in [USB Connection] (P. 63) before connecting the cable again.

When to charge the batteries

Error message

Charge the battery when the error message shown on the right appears.

Battery Empty

Flashes in red

Page 8

Turning on the camera and making the initial settings

When you turn on the camera for the first time, a screen appears enabling to set the language for the menus and messages displayed in the monitor, and the date and time. To change the selected date and time, see “Setting the date and time d [X]” (P. 65).

Press the n button to turn on the camera, press

FGHI

the A button.

Press

pad to select the year for [Y].

of the arrow pad to select your language and press

of the arrow

YMDTime

2014

-- --

Back

:..

Y/M/D

Press I of the arrow pad

to save the setting for [Y].

As in Steps 2 and 3, press

FGHI

Y M D Time

2014

of the arrow pad to

set [M] (month), [D] (day), [Time] (hours and minutes), and [Y/M/D] (date order), and then press the A button.

• For precise time setting, press the A button as the time signal strikes

00 seconds.

-- --

Back

:..

Y/M/D

Page 9

Use HI to select the

time zone and then press the A button.

• Use FG to turn daylight saving time ([Summer]) on or off.

’14.02.26 12:30

Summer

Page 10

Using basic functions

Taking photographs



Press the n button to turn on the camera.

When the camera is turned on, the monitor will turn on.

Set the mode dial to P.

In mode P, the camera automatically adjusts shutter speed and aperture in response to subject brightness.

Frame the shot.

• When holding the camera, take care not to cover the flash, microphone or other important parts with your fingers, etc.

Press the shutter button

halfway down to focus.

The camera was unable to focus if the AF target mark flashes red. Try focusing again.

• The shutter speed and aperture value are displayed in red if the camera is unable to achieve optimal exposure.

To take the picture, gently

Press halfway

press the shutter button all the way down while being careful not to shake the camera.

• You can also take photographs using the touch screen.

g “Shooting using touch panel” (P. 39)

Press

halfway

AF target

Shutter speed

Aperture value

Press the rest of

the way down

F6.9F6.91/4001/400

Page 11



Viewing photographs (Playing back images)

Turn on the camera. Press the q button.

• Your most recent photograph is displayed.

• Press HI to select an image.

q button

Displays the

previous frame

Displays the next frame

Arrow pad

You can view later frames and earlier frames using the touch screen.

• Drag the screen to left to advance one frame, and drag the screen to right to rewind one frame.

Index display

• In single-frame playback, turn the zoom lever to W for Index playback.

• Use FGHI to move the cursor.

• Turn the zoom lever to T for single-frame playback.

Tap  to display Index playback.

• Tap . - on the right to view the next or previous page.

• Tap an image to view it full frame.

Still image

’13/02/26’13/02/26 12:3012:30

’

14/02/26 12:30

12:30’14/02/26

4/30

Page 12

Close-up playback

• In single-frame playback, turn the zoom lever to T to

zoom in up to 10×; turn to W to zoom out. Press the A button to return to single-frame playback.

• Press FGHI to scroll an image to the direction of

the button you pressed.

Tap  for playback zoom.

• Use your finger to scroll the display when the picture is zoomed in.

• Tap Z to return to single-frame playback.

’14/02/26’14/02/26

12:3012:30

4/30

Page 13

Recording movies

Press the R (movie) button

to start recording.

• The movie is shot in the set shooting mode. Note that the shooting mode effects may not be obtained for some shooting modes.

• Sound is also recorded.

• When using a camera with a CMOS image sensor, moving objects may appear distorted due to the rolling shutter phenomenon. This is a physical phenomenon whereby distortion occurs in the filmed image when shooting a fast-moving subject or due to camera shaking. In particular, this phenomenon becomes more noticeable when using a long focal length.

Press the R (movie) button again to stop recording.

Lights up red when

recording

RECREC

Recording time

0:00

0:00 0:340:34

RECREC

0:000:00

Recording length

0:340:34

(P. 96)

Page 14

 Movie playback

Select a movie, and press the A button.

• Turn the zoom lever to the T side to display the movie index. Use FGHI to select the frame to start playback.

’14/02/26’14/02/26 12:3012:30

4/30

00:12/00:3400:12/00:34

During playbackMovie

Pausing and restarting

playback

Fast forward

Rewind

Adjusting the volume

Press the A button to pause playback. During pause, fast forward or reverse, press the A button to restart playback.

Press I to fast forward. Press I again to increase the fast forward speed.

Press H to rewind. Press H again to increase the rewind speed.

Use FG to adjust the volume.

Operations while playback is paused

Elapsed time/Total shooting time

00:12/00:3400:12/00:34

During pause

Jump

Advancing and

rewinding one frame at

a time

Resuming playback

Press FG to jump to the previous/next index.

Press I or H to advance or rewind one frame at a time. Hold I or H pressed for continuous advance or rewind.

Press the A button to resume playback.

• During a pause, turn the zoom lever to the W side for the split index display.

Page 15

To stop movie playback

Press the  button.

• To play back movies on the computer, the supplied PC software is recommended. For the first use of the PC software, connect the camera to the computer, then launch the software.

Playing back movies using touch panel

Tap the following icon.

Play back movies. Tap again to pause playback.



Tap ( or * to fast forward or rewind.

(

Tap & or ) to advance or rewind one frame.

)

Go back to the beginning of the movie.

Display movie index.

Erasing images during playback

Display the image you want to erase and press G ().

• To erase a movie, select the movie to erase and press G ().

Press

• Grouped images are erased as a group (P. 16).

• Multiple images or all images can be erased at a time (P. 61).

to select [Erase], and press the A button.

Erase

Cancel

Back

100-0004100-0004

4/304/30

Page 16

 Playing back panorama and grouped

images

Playing back panorama images

Panorama images that were combined together using [Auto] or [Manual] can be scrolled for viewing.

Select a panorama image during

playback. Press the A button.

12:30’14/02/26

To control panorama image playback

Stop playback: Press the  button. Pause: Press the A button. Control while paused

FGHI

Press direction of the pressed button. Turn the zoom lever to enlarge/shrink the image. Press the A button to restart scrolling.

Tapping  also scrolls panorama images for viewing.

to scroll the image in the

Viewing area

4/304/30

Page 17

Playing back grouped images

With sequential shooting, interval shooting and Photo in Movie, the taken images are displayed as a group during playback.

Expands.

• Expand to view the frames of a group in index view.

T side

• Tapping K also expands the frames.

• If you want to delete images from the grouped images, you can expand the group and delete the images individually.

• Select the image and press the A button to display the images respectively.

• Use HI to view the previous/next frame.

A button

Plays back the grouped images in sequence automatically or pauses playback.

Tapping  also plays back grouped images.

Sequential images frame

• The sequentially shot images are played back automatically.

• Expand to view the images in index view.

ExpandExpand

PlayPlay

’14/02/26’14/02/26

Sequential images frame

Photo in Movie frame

• The movie and the still images are played back.

• Expand to view the images in index view.

• Pause the playback and turn the zoom lever to the W side to display the still images as a chapter index of the movie. Select the still image and press the A button to play back the movie from that point.

12:30

4/30

Page 18

Monitor display

Shooting screen displays

26 25 24 23

1 2

SCNSCN

Date

ORM

1820212219 131617 15

F6.9F6.91/1001/100

2930

0:00:340:00:34

0.00.0

AUTOWBAUTO

ISO

AUTO

4:3

5 6 7 8 9 10 11 12

When the shutter button is pressed halfway down

Reading a histogram

If the peak fills too much of the frame, the image will appear mostly black.

The green section shows luminance distribution within the screen’s center.

If the peak fills too much of the frame, the image will appear mostly white.

Switching the displays

The displays change in the order of Normal → Detailed → No info. → Level Gauge each time the INFO button is pressed. g P. 67

Page 19

No. Name Normal Detailed No info.

Shooting mode

Connection to Smartphone

Sub mode

Picture Mode

Flash

Exposure compensation

White balance

ISO sensitivity

Image size (still images)

Aspect

Image size (movies)

Recording with sound/ wind noise reduction

Movie recording length

Movie recording icon

World time

Image stabilization

Metering

Date stamp

Compression

Number of storable still pictures

Current memory

Battery check

Histogram

AF target mark

ouch Shutter

Grid Guide

Aperture value

Shutter speed

Camera shake warning

RR RRRR RR RR RR

RR RR RR RRR RR RR RR

RR RR

– – –

–

RRRR

–

RRRR

R R R

––

–– –– –– –– –– ––

–– –– ––

––

–– –– –– –– –– –– ––

––

–– –– ––

––

Level

Gauge

–

Page 20

Playback mode display

100-0004100-0004

2.0

2.01/10001/1000

4608

34564608 3456

AUTOWB125

ISO

ORM

AUTOWB125

ISO

ORM

’14/02/26 12:30

F6.9F6.9

• Normal

3245

1010

12:30’14/02/26’14/02/26 12:30

21 20 22

Still image

4/304/30

• Detailed

1 23 54

1010

F6.9F6.9

ISO

AUTOWB125

ORM

34564608 3456

4608 100-0004100-0004

’14/02/26 12:30

1110 129

• No information

Switching the displays

The displays change in the order of Normal → Detailed → No info. each time the INFO button is pressed.

4/30

2.02.01/10001/1000

14 15

16 17 18 19

2021

Page 21

No. Name Normal Detailed No info.

Battery check

Eye-Fi transfer data/Wi-Fi

Protect

Adding sound

Share order

Print reservation/number of prints

Current memory

Frame number/ total number of images

Compression/ Image size (movies)

Shutter speed

Shooting mode

ISO sensitivity

Aperture value

Histogram

Exposure compensation

Picture mode/sub mode

White balance

Image size (still images)

File name

Recording date and time

Grouped images

Touch screen button

–

RR RR RR RR RR RR

–

– – – – – – – – – –

RR RRR RRR

R R R R R R R R R R

– – – – – – –

–

– – – – – – – – – – –

Page 22

Shooting using basic functions

Using the shooting modes

Selecting shooting mode

Turn the mode dial to set the shooting mode to the indicator.

• After selecting mode.

ART

, O, p, P, or r, select the sub

Page 23

List of shooting mode

• The default settings of the function are highlighted in .

Shooting mode Sub mode

P (Program mode)

(Manual mode)

ART

(Art Filter)

O (Scene Mode)

i (Hand-Held Starlight

mode) p (Panorama)

P (PHOTO STORY) r (Advanced Movie

mode) A (iAUTO mode)

• “List of settings available in each shooting mode” (P. 97), “List of O

settings” (P. 98), “List of ART settings” (P. 99)

• In certain shooting modes, the camera may take a few moments for image processing after taking a picture.

Pop Art/Soft Focus/Pale&Light Color/ Grainy Film/Pin Hole/Diorama/Dramatic Tone

Portrait/e e-Portrait/F Landscape/

Interval Shooting/G Night Scene/

Night+Portrait/C Sport/2 Indoor/

Self Portrait/` Sunset/X Fireworks/

Cuisine/^ Documents/g Beach & Snow/

Super Macro/E Backlight HDR

Auto/Manual

Standard/Speed/Zoom In/Out/Fun Frames s

Photo in Movie/} 60p Movie/

;

High-Speed Movie// Time Lapse Movie

–

P. 10

P. 24

P. 25

P. 26

P. 28

P. 30

P. 32

P. 33

Page 24

M (manual mode)

In mode M, you can set the aperture value, shutter speed, and ISO manually.

• The exposure difference from suitable exposure is displayed.

ISO

Shutter speed

Rotate the mode dial to M.

Press F, and use HI to select aperture value (F-numbers),

FNo.

Over/Under exposure

shutter speed, and ISO and use FG to select each value. Press the A button to set.

F6.9F6.9 +2.0+2.01/4001/400ISO6400ISO6400

Page 25

ART

(art filters)

You can shoot with color and effect like posters and paintings.

Sub mode Application

Pop Art

Soft Focus

Pale&Light Color

Enhances the color and atmosphere of an image more brightly and vividly.

Expresses an ethereal atmosphere with a soft tone and makes an image dreamy.

Expresses a comfortable floating feeling by making an image more pale and light.

Grainy Film Expresses the strength and roughness of black and white.

Expresses the tunnel effect like that obtained from an

Pin Hole

old fashioned camera or a toy camera by reducing the peripheral brightness.

Expresses an image shooting a surreal miniature world with

Diorama

enhancing the saturation and contrast and blurring an outof-focus area of an image.

Enhances the local contrast of an image and provide an

Dramatic Tone

image that a difference of brightness and darkness is emphasized.

Rotate the mode dial to

Use HI to select a sub mode and press

ART

the A button at the end.

• Press the A button once again to display the

sub mode selection screen.

Pop Art

0.00.0

AUTOWBAUTO

4:3

MENUMENU

Page 26

O (scene mode)

Only by selecting a sub mode according to the subject or the scene, you can shoot with an proper setting.

Sub mode Application

Portrait Suitable for portrait shooting.

e-Portrait

Landscape Suitable for landscape shooting.

Interval Shooting

Night Scene Suitable for tripod shooting of night scenes.

Night+Portrait

Sport Suitable for fast action shooting.

Indoor Suitable for shooting portraits indoors like party scene.

Self Portrait Suitable for shooting yourself with holding the camera.

Sunset Suitable for shooting the sunset.

Fireworks Suitable for shooting fireworks at night.

Cuisine Suitable for shooting cuisine.

Documents Suitable for shooting paper documents or time tables.

Beach & Snow

Super Macro Suitable for shooting extremely close-up images.

Backlight HDR

Smoothes out skin tones and texture. This mode is suitable when viewing images on a high-definition TV.

Automatically shoot successive images according to set [Start Waiting Time], [Frame], and [Interval Time].

Suitable for portrait shooting against a background of night view.

Suitable for shooting at snow-capped mountains, seascapes in the sun, and other whitish scenes.

Suitable for contrasting scenes. This mode captures multiple images and merges them into one, properly exposed image.

Rotate the mode dial to O.

Use HI to select a sub mode and press

Portrait

the A button at the end.

• Press the A button once again to display the

sub mode selection screen.

• In [e-Portrait] mode, two images are recorded: an unmodified image and a second image to which [e-Portrait] effects have been applied.

4:3

MENUMENU

Page 27

1 Interval Shooting

Adjusts interval settings in the setting menu before selecting Interval Shooting in O (Scene Mode) to shoot.

Customizing the setting

Press the  button to display the

menus. Use H to move to the page tab, and

Ta b

Interval Settings

Level Gauge Settings

BackSettings Menu 3

use FG to select Setting menu 3 and then press A.

Use FG to select [Interval Shooting] and press A. Then

press FG to select an item and press A.

Interval Settings

Level Gauge Settings

Use FG to highlight an option and press A to select.

Frame

Start Waiting Time

Sets the number of frames to be shot between 1 and 99 frames.

Sets the time from pressing the shutter button until the picture is taken between 0 and 60 minutes.

BackSettings Menu 3

Frame

Start Waiting Time

Interval Time

Sets the shooting interval for the second and

Interval Time

subsequent frames per 10 seconds or between 1 and 60 minutes.

• Press the  button repeatedly to exit the menu.

• The interval may be longer than the set interval such as when the camera takes a few moments for image processing.

• Taken pictures are displayed as a group.

• For the free space on a card, you cannot shoot the set number of frames.

• The camera may go into sleep mode during interval shooting, but the shooting is performed according to the setting.

To cancel the interval shooting

Press the  button.

BackInterval Settings

min sec

Page 28

: (Hand-Held Starlight)

Reduces blur when shooting low light/ illuminated scenes. The flash can be used.

• By pressing the shutter button once, the camera shots multiple images automatically and continuously, and merges them into a high quality image with less noise.

p (Panorama mode)

You can shoot and combine multiple images to create an image with a wide angle of view (panoramic image).

Rotate the mode dial to p.

Press the A button to go to the function menu. Use HI to

select a sub mode and press the A button at the end.

Submenu Application

Auto

Manual

• Move the camera as if rotating it around a vertical axis through the center of the lens to take better panorama images.

Taking pictures with [Auto]

1 Select [Auto] in the sub mode first. Press G and use HI to select the angle

of view (STD:180°, FULL:360°), and then press the A button.

2 Point the camera to the start

position.

3 Press the shutter button to begin

shooting.

4 Start panning. When the arrow

reaches the end of the guide, recording ends automatically.

• The camera automatically processes the images and the combined panorama image is displayed.

• To stop shooting in the middle, press the shutter button or A button. If the camera pauses for a while, shooting automatically finishes.

• If the message [Image was not created.] is displayed, shoot again.

• To cancel the panorama function, press the  button.

Panorama images are automatically combined just by swinging the camera in the shooting direction.

Three frames are taken and combined by the camera. The user composes the shots using the guide frame and manually releases the shutter.

Cancel

Guide

Save

AUTO

FULL

Page 29

Taking pictures with [Manual]

1 Use FGHI to specify at which

edge the next picture is to be connected, and then press the A

Direction for combining frames

MANUALMANUAL

button.

2 Press the shutter button to take the

first frame.

3 Compose the next shot so that the edge of the first frame displayed faintly on

the screen overlaps the subject of the second frame, and press the shutter button.

• To combine only two frames, press the A button.

4 Repeat step 3 to take a third frame. The camera automatically combines the

frames into a single panorama image.

Page 30

P (PHOTO STORY)

When shooting, an image is incorporated into a layout frame set to create a desired collage. This enables wide range of photo expression with themes or stories.

Rotate the mode dial to P.

Select a theme using FG and press

Types of theme

Standard

Speed

Zoom In/Out

Fun Frames

Select desired items in the theme using

FGHI, then press A.

• Press the shutter button halfway to return to the shooting screen.

Theme

Standard

Back

Set

Page 31

Tap a frame in standby mode to shoot.

0.00.0

WB AUTOWBAUTO

ISO

ISO AUTO

AUTO

0.00.0

WB AUTOWBAUTO

ISO

ISO AUTO

AUTO

0.00.0

AUTOWBAUTO

ISO

AUTO

ORM

• Tap the frame when the subject is not displayed in a frame.

Shoot each frame in the same way.

• Shot images are displayed in the frames.

• Touch any framed image and then U while U is displayed, so that the

image is canceled, and you can retake the shot.

• Press the  button and select [Exit], and then press the A button to

cancel the shot picture and restart shooting again.

After shooting all frames, press N and save the picture.

• When changing a shooting mode in the middle of shooting, the shooting state will be automatically saved.

• AF Mode is fixed to [Spot].

• The image size is fixed at a size equivalent to [4].

• The following operations are not available in the Photo Story mode. Movie recording, sequential, and self-timer.

Page 32

s (Advanced Movie mode)

You can shoot the movie by using the evolving movie function.

Submenu Description

s (Photo in Movie)

} (60p Movie)

; (HighSpeed Movie)

/ (Time Lapse Movie)

• Except in Photo in Movie, you cannot take still images by pressing the shutter

button. The Photo in Movie function is also enabled when shooting in P mode or M mode.

• The flash is not available when capturing still images using Photo in Movie.

• Images captured during Photo in Movie are displayed as a group.

• Only when High-Speed Movie, you can select [c], [d], and [Off] of the self-timer.

• While you shoot Time Lapse Movie, you cannot change the focus position.

• The camera may go into sleep mode during Time Lapse Movie, but the shooting is performed according to the setting.

• When the battery gets low during Time Lapse Movie, the camera stops shooting and starts saving the images you have taken on the card. For the battery remaining, the camera may fail to generate a movie. Use a fullcharged battery.

• In Time Lapse Movie, pressing the R (movie) button while shooting stops the shooting. The length of the movie is depending on the number of frames.

Captures still images as you shoot a movie. During a single movie, you can capture a maximum of 12 still images.

Shoots a smooth movie at 60 frames/second. Image size is fixed at full HD (1920×1080).

Shoots a fast-moving subject and play back in slow motion. HS120fps (1280×720), HS240fps (432×324)

Generate a movie for 20 seconds by shooting successive and interval images at set shooting time. You can set “shooting time” in the function menu. The camera automatically ends shooting for a set shooting time and record a time lapse movie.

Page 33

A (iAUTO mode)

A full auto mode in which the camera automatically optimizes settings for the current scene. The camera does all the work, which is convenient for beginners.

Rotate the mode dial to A.

Press the shutter button halfway down to focus.

The camera was unable to focus if the AF target mark flashes red. Try focusing again.

To take the picture, gently press the shutter button all the way

down while being careful not to shake the camera.

Using the live guide

The live guide can be used to change settings in M mode.

1 Press A to display the live guide. 2 Use FG to highlight an item and press A.

Guide items

• Change Color Saturation

• Change Color Image

• Change Brightness

3 Use FG to choose a level and check the

effect or description.

• Press the shutter button halfway to select.

4 Press the shutter button to take a picture.

• To clear the live guide from the display,

press the  button.

• Touching the screen also changes the live

guide setting levels. g P. 39

• Pictures may appear grainy at some live guide setting levels.

• Changes to the live guide setting levels may not be visible on the screen.

• The flash can not be used with the live guide.

• Changes to the live guide options cancel previous changes.

• Choosing the live guide settings that exceed the limits of the camera exposure meters may result in pictures that are over- or under-exposed.

Guide item

Change Color Saturation

Level bar

Clear & Vivid

Flat & Muted

Page 34

Using the zoom

Turning the zoom lever adjusts the shooting range. Turn the zoom lever as far as it will go to speed up the zoom operation, and turn it partway for a slow zoom operation (not applicable when shooting a movie).

W side T side

Image size Zoom bar

Zoom bar

5050

0.00.0

AUTOWBAUTO

ISO

AUTO

16M

4:3

0:00:340:00:34

ORM

16M

Optical zoom

Super-resolution zoom*1

Other

*1 For the super resolution zoom and the details, refer to (P. 54). *2 Due to increased processing of the pixel counts, the image quality will not

degrade. The magnifi cation ratio changes depending on the image size setting.

Page 35

Using shooting options (Set by direct button)

Some items are not available in some shooting modes. g “List of settings available in each shooting mode” (P. 97)

Flash

You can use a flash when shooting.

Slide the flash switch to

raise the flash.

Press the # button (I) to display options.

Use HI to choose a flash mode and press A.

#AUTO

• In [!](Red-eye reduction flash), after the pre-flashes, it takes about

• [!](Red-eye reduction flash) may not work effectively under some

To turn off the flash

Press the flash down back into the camera.

Auto flash

Red-eye reduction flash

Fill-in flash

Flash off The flash does not fire.

1 second before the shutter is released. Do not move the camera until shooting is complete.

shooting conditions.

Flash switch

The flash fires automatically in low light or backlight conditions.

This function allows you to reduce the red-eye phenomenon.

The flash fires regardless of the light conditions.

Page 36

Exposure compensation

Compensates the brightness (appropriate exposure) adjusted by the camera.

Press the +/- button (F), and then press HI for the exposure

compensation.

• Choose positive (“+”) values to make pictures brighter, negative (“–”) values to make pictures darker.

Negative (–) No compensation (0) Positive (+)

Page 37

Single/Sequential

Press the jY button (G) to display the direct menu.

Select an option using HI and press A.

Single-frame shooting



Sequential 1 *



Sequential 2 *

High-Speed1 *

High-Speed2 *

*1 Taken pictures are displayed as a group. *2 The number of recording pixels are limited.

• During sequential shooting, focus, exposure, and white balance are locked at the first frame.

• During sequential shooting, if the battery check blinks due to low battery, the camera stops shooting and starts saving the pictures you have taken on the card. The camera may not save all of the pictures depending on how much battery power remains.

1, 2

Shoots 1 frame at a time when the shutter button is pressed (normal shooting mode).

The images are taken sequentially for 200 frames at up to about 2.5 frames per second (fps) while pressing down the shutter button all the way down.

The images are taken sequentially for up to 16 frames at about 11.5 frames per second (fps) while pressing down the shutter button all the way down.

The images are taken sequentially for up to 60 frames at about 20 frames per second (fps) while pressing down the shutter button all the way down.

The images are taken sequentially for up to 60 frames at up to 60 frames per second (fps) while pressing down the shutter button all the way down.

Page 38

Self timer

Sets the time after the shutter button is pressed until the picture is taken.

Press the jY button (G) to display the direct menu.

Select [c], [d] or [YC] using HI and press the A button.

Press the shutter button halfway to focus, the rest of

Self-timer

12 SEC

Self-timer

2 SEC

Custom

Self-timer

• To cancel the activated self-timer, press the  button.

• Self timer is not canceled automatically after shooting.

the way down to start the timer. First, the self-timer lamp lights up for approximately 10 seconds, then it blinks for approximately 2 seconds and the picture is taken.

Press the shutter button halfway to focus, the rest of the way down to start the timer. The self-timer lamp blinks for approximately 2 seconds, and then the picture is taken.

After selecting this mode, press the  button to set “the number of frames, the time from pressing the shutter button until the picture is taken, and the interval time”. Pictures are taken by these setting.

AFL (Focus lock)

You can lock the focus position.

Press the shutter button halfway to focus.

While keeping the position of the camera, press the A button.

• The camera focuses and locks the position.

• Press the A button again to release the focus lock.

• Zooming operation, pressing the  button, and the other operations

also release the focus lock.

• After shooting, the focus lock is released.

• Touching the screen also locks and releases the focus lock. g P. 39

Page 39

Shooting using touch panel

By touching the screen, the subject to be focused on can be set or the picture can be taken.

• When using a monitor protector or gloves, touching operation may not work well.

• When touching operation is difficult with your finger, use the Stylus pen (supplied).

Every time  is touched, the operation is changed.



: The subject that is touched is focused on and the picture is taken

automatically.



: The subject that is touched is AF locked. Press the shutter button to

take the picture. Touch  to release the AF lock. Focus lock ends when the shutter is released.

GUIDE

Clear & Vivid

1080

0:340:34

ORM

Using for the live guide (P. 33)

In M mode, the live guide can be set.

Touch M.

• Touch an item to set the level.

Drag the level bar slider vertically to set the level, and touch

• Touch O to end the live guide.

• Touch % to cancel the setting.

LIVE

Flat & Muted

Page 40

Using shooting options (Set by function menu)

Some items are not available in some shooting modes. g “List of settings available in each shooting mode” (P. 97)

Function menu

1 Picture Mode..........................P. 41

2 Flash ......................................P. 41

3 Exposure compensation ........P. 42

4 White balance ........................ P. 42

5 ISO sensitivity ........................ P. 42

Press A to display the function menu.

• To hide the function menu, press A again.

Use FG on the arrow pad to select settings, use HI to

change the selected setting, and press A.

Displays the selected function name

Selection

1 2

0.00.0

AUTOWBAUTO

ISO

AUTO

5 6

4:3

8 9

MENUMENU

6 o/

Setup menu (P. 47)

Y .....................................

7 Image Size (still images)........P. 43

8 Aspect .................................... P. 43

9 Image size (movies)...............P. 44

Arrow pad

(HI)

Flash Auto

0.00.0

AUTOWBAUTO

Arrow pad

ISO

AUTO

(FG)

4:3

MENUMENU

Function

P. 43

Page 41

• The default settings of the function are highlighted in .

Picture Mode Sets the processing options.

Vivid Produces vivid colors.

Natural Produces natural colors.

Muted Produces flat tones.

Fish Eye

Sparkle

Reflection Makes an image with the effect of reflecting in a mirror.

Fragmented

Pop Art

Soft Focus

Pale&Light

Color

Grainy Film Expresses the strength and roughness of black and white.

Pin Hole

Diorama

Dramatic

Tone

Flash Sets the flash firing method.

Flash Auto

Redeye

Fill In The flash fires regardless of the available light.

Flash Off The flash does not fire.

Produces distortion with the effect of shooting with a fisheye lens.

Produces twinkling lights with the effect of shooting with a cross filter.

Makes an image into a collage of tiles. This mode produces the effect of mosaic art.

Enhances the color and atmosphere of an image more brightly and vividly.

Expresses an ethereal atmosphere with a soft tone and makes an image dreamy.

Expresses a comfortable floating feeling by making an image more pale and light.

Expresses the tunnel effect like that obtained from an old fashioned camera or a toy camera by reducing the peripheral brightness.

Expresses an image shooting a surreal miniature world with enhancing the saturation and contrast and blurring an out-of-focus area of an image.

Enhances the local contrast of an image and provide an image that a difference of brightness and darkness is emphasized.

The flash fires automatically in low-light or backlight conditions.

Pre-flashes are emitted to reduce the occurrence of red eye in your photos.

Page 42

Exposure compensation

–2.0 to +2.0 Value

White balance

WB Auto The camera automatically adjusts the white balance.

Sunny Suitable for shooting outdoors under a clear sky.

Cloudy Suitable for shooting outdoors under a cloudy sky.

Incandescent Suitable for shooting under tungsten lighting.

Fluorescent Suitable for shooting under white fluorescent lighting.





One Touch 1



One Touch 2

ISO sensitivity Sets the ISO sensitivity.

ISO Auto

High ISO

Auto

S to # Value

Compensates the brightness (appropriate exposure) adjusted by the camera.

Set a larger negative (–) value to adjust darker, or a larger positive (+) value to adjust brighter.

Sets an appropriate color scheme for the light of the shooting scene.

For manually adjusting the white balance according to the light when shooting. Set a piece of white paper or other white object so that it fills the entire screen, and press the  button to set the white balance. For how to register one touch white balance, see “Registering one touch white balance” (P. 44).

The camera automatically sets the sensitivity with priority on image quality.

The camera automatically sets the sensitivity with priority on minimizing blur caused by a moving subject or by camera shake.

Set a smaller value to reduce noise in the picture, or a larger value to reduce blur.

Page 43

Single One frame is shot each time the shutter button is pressed.



Sequential 1



Sequential 2

High-Speed1

High-Speed2

12 sec

2 sec

Custom Self-

timer

Image size (still images)



4608×3456 Suitable for printing pictures over A3 (11×17 in.).

3200×2400 Suitable for printing pictures up to A3 (11×17 in.).

1920×1440 Suitable for printing pictures up to A4 size (8.5×11 in.).

640×480 Suitable for using pictures on emails.

Aspect Sets the horizontal-to-vertical ratio of images.



4:3

16:9

3:2



1:1

Sets the sequential shooting function and the time from pressing the shutter button until the picture is taken.

The images are taken sequentially for 200 frames at up to about 2.5 frames per second (fps) while pressing down the shutter button all the way down.

The images are taken sequentially for up to 16 frames at about 11.5 frames per second (fps) while pressing down the shutter button all the way down.

The images are taken sequentially for up to 60 frames at about 20 frames per second (fps) while pressing down the shutter button all the way down.

The images are taken sequentially for up to 60 frames at up to 60 frames per second (fps) while pressing down the shutter button all the way down.

The self-timer lamp turns on for approx. 10 seconds, then blinks for approx. 2 seconds, and then the picture is taken.

The self-timer lamp blinks for approx. 2 seconds, then the picture is taken.

Photographs are taken at “the number of frames, the time from pressing the shutter button until the picture is taken, and the interval time” which you set.

Sets the number of recording pixels.

Change the horizontal-to-vertical ratio when taking pictures.

Page 44

Image size (movies)

1080 60p



1080p Shoots full HD movies.



720p Shoots HD movies.

VGA Shoots 640×480 movies.

HS 120

HS 240

You can set only when [Vivid], [Natural], and [Muted] is set on the picture

mode in P and M mode and [I Super Macro].

HS movie: Film quickly moving subjects for slow-motion playback.

Sets the number of recording pixels.

Shoots smooth full HD movies at 60 frames per second

(fps).

*1, 2

Shoots 1280×720 HS movies.

*1, 2

Shoots 432×324 HS movies.

• In certain shooting modes, some functions cannot be set. g “List of settings

available in each shooting mode” (P. 97).

• Examples of image size when the aspect ratio is 4:3.

Registering one touch white balance

Select [ One Touch 1] or [ One Touch 2], face the camera toward a piece of white paper or other white object, and press the  button.

• The camera releases the shutter and the white balance is registered. When the white balance was previously registered, the registered data is updated.

• The registered white balance data will not be cleared by turning off the power.

• Perform this procedure under the light where the pictures will be actually taken.

• When the camera settings are changed, the white balance must be registered again.

• When the white balance cannot be registered, check that the white paper fills the screen, and then perform the procedure again.

Page 45

Page 46

Using the setup menu functions

Setup menu

4 Playback Menu

Normal

Auto

Face/iESP

ESPESP/

Slideshow Edit Erase Print Order (P. 78)

R (Protect) Share Order (P. 70)

Camera Menu 1 Back

1 2 3 4 5 6 7

Wi-Fi StartWi-Fi Start

ResetReset

Compression

Shadow Adjust

Touch Shutter Off AF Mode

P. 56

1 Camera Menu 1

Wi-Fi Start/End Wi-Fi (P. 68) Reset Compression Shadow Adjust

Touch Shutter AF Mode ESP/n

2 Camera Menu 2

Digital Zoom Image Stabilizer (Still images) AF Illuminat. Rec View

Pic Orientation Date Stamp Super-Res Zoom

3 Movie Menu

IS Movie Mode R (Movie sound recording) Wind Noise Setting

P. 48

P. 51

P. 55

5 Settings Menu 1

Memory Format/Format Backup Eye-Fi USB Connection

q Power On Sound Settings Pixel Mapping

6 Settings Menu 2

s (Monitor) TV Out l (Language)

(Date/time)

World Time Touch Calibration Wi-Fi Settings

7 Settings Menu 3

Interval Settings Level Gauge Settings

P. 62

P. 64

P. 67

Page 47

Using the setup menu

Press the  button during shooting or playback to display the setup menu. The setup menu provides access to a variety of camera settings, such as shooting and playback functions, time and date settings, and display options.

Press the  button.

• The setup menu is displayed.

Press H to select the page tabs. Use FG to select the

Camera Menu 1 Back

Wi-Fi StartWi-Fi Start

ResetReset

Compression

Shadow Adjust

Touch Shutter Off AF Mode

Face/iESP

desired page tab and press I.

Page tab

Normal

Face/iESP

Auto

ESPESP/

Camera Menu 1 Back

Wi-Fi StartWi-Fi Start

ResetReset

Compression

Shadow Adjust

Touch Shutter Off AF Mode

Use FG to select the desired submenu 1 and then press the

Submenu 1

Camera Menu 1 Back

Wi-Fi StartWi-Fi Start

ResetReset

Compression

Shadow Adjust

Touch Shutter Off AF Mode

Face/iESP

A button.

Submenu 2

Normal

Face/iESP

Camera Menu 1 Back

Wi-Fi StartWi-Fi Start

ResetReset

Auto

Off

ESPESP/

Compression

Shadow Adjust

Touch Shutter

AF Mode

ESP/

Camera Menu 1 Back

Wi-Fi StartWi-Fi Start

ResetReset

Compression

Shadow Adjust

Touch Shutter

AF Mode

Face/iESP

Camera Menu 1 Back

Wi-Fi StartWi-Fi Start

ResetReset

Compression

Shadow Adjust

Touch Shutter

AF Mode

Use

to select the desired submenu 2

and then press the A button.

• Once a setting is selected, the display returns to the Submenu 1.

• There may be additional operations.

Press the  button to complete the setting.

Normal

Auto

ESPESP/

Normal

Auto

ESPESP/

Off

Normal

Auto

ESPESP/

Page 48

For the operation method, refer to (P. 47).

• The default settings of the function are highlighted in .

z

Camera Menu 1

Restoring the shooting functions to the default settings

[Reset]

Submenu 2 Application

Restores the following menu functions to the default settings.

• Sub mode of

• Set value of M mode

• Picture Mode

• Flash

Yes

No The settings will not be changed.

• Exposure compensation

• White balance

• ISO sensitivity

• o/Y

• Image Size (still images)

• Aspect

• Image Size (movies)

• Camera Menu 1, Camera Menu 2 and Movie Menu Functions

ART

, O, p,

P, and r

Selecting the image quality for still images z [Compression]

Submenu 2 Application

Fine Shooting at high quality.

Normal Shooting at normal quality.

• “Number of storable pictures (still images)/Recording length (movies) in the internal memory and cards” (P. 96)

48EN48

Page 49

For the operation method, refer to (P. 47).

Brightening the subject against backlight z [Shadow Adjust]

Submenu 2 Application

Auto Automatically On when a compatible shooting mode is selected.

Off The effect is not applied.

• When [ESP/n] is set to [n], [Shadow Adjust] is automatically fixed to [Off].

Shoot with automatic adjustment to brighten an area that has become darker.

Setting the Touch Shutter function z [Touch Shutter]

Submenu 2 Application

Off

• This setting can also be changed by touching the panel. g P. 39

The subject that is touched is AF locked. (Press the shutter button manually.)

The subject that is touched is focused on and the picture is taken automatically.

49EN49

Page 50

For the operation method, refer to (P. 47).

Selecting the focusing area z [AF Mode]

Submenu 2 Application

The camera focuses automatically. (If a face is detected, it is shown by a white frame

Face/iESP

halfway and the camera focuses, the frame turns to green face is detected, the camera chooses a subject in the frame and focuses automatically.)

Spot

AF Tracking

For some subjects, the frame may not appear or may take some time to

appear.

If the frame blinks in red, the camera cannot focus. Try refocusing on the

The camera focuses on the subject located within the AF target mark.

The camera tracks the subject movement automatically to focus on it continuously.

subject.

To focus on a moving subject continuously (AF Tracking)

1 Hold the camera to align the AF target mark on the subject and press the A

button.

2 When the camera recognizes the subject, the AF target mark automatically

tracks the subject movement to focus on it continuously.

3 To cancel the tracking, press the A button.

• Depending on the subjects or the shooting conditions, the camera may be unable to lock the focus or fail to track the subject movement.

• When the camera fails to track the subject movement, the AF target mark changes to red.

; when the shutter button is pressed

. If no

50EN50

Page 51

For the operation method, refer to (P. 47).

Selecting the method for measuring the brightness

[ESP/n]

Submenu 2 Application

ESP

5 (spot)

• When set to [ESP], the center may appear dark when shooting against strong backlighting.

z

Camera Menu 2

Shoots to obtain a balanced brightness over the entire screen (Meters the brightness at the center and surrounding areas of the screen separately).

Shoots the subject at the center during backlighting (Meters the brightness at the center of the screen).

Shooting at higher magnifications than optical zoom

[Digital Zoom]

Submenu 2 Application

Off Disable digital zoom.

On Enable digital zoom.

• The option selected for [Digital Zoom] affects the appearance of the zoom bar (P. 54).

51EN51

Page 52

For the operation method, refer to (P. 47).

Reducing the blur caused by the camera shake when shooting

[Image Stabilizer]

Submenu 2 Application

Off

On The image stabilizer is activated.

While Exposing

• There may be a noise coming from inside the camera when reducing camera shake.

• Images may not be stabilized if camera shake is too severe.

• When the shutter speed is extremely slow, such as when taking pictures at night, [Image Stabilizer] may not be as effective.

The image stabilizer is deactivated. This is recommended for shooting when the camera is fixed in place on a tripod or other stable surface.

Image stabilization is activated when the shutter button is pressed all the way down.

Using the assist lamp for shooting a dark subject

[AF Illuminat.]

Submenu 2 Application

Off The AF illuminator is not used.

When the shutter button is pressed halfway down, the AF illuminator turns on to aid focusing.

AF illuminator

52EN52

Page 53

For the operation method, refer to (P. 47).

Viewing the image immediately after shooting z [Rec View]

Submenu 2 Application

Off

1/2/3 (sec)

The image being recorded is not displayed. This allows the user to prepare for the next shot while following the subject in the monitor after shooting.

The image being recorded is displayed for selected second(s). This allows the user to make a brief check of the image that was just taken.

Automatically rotating images shot with the camera in a vertical position during playback z [Pic Orientation]

• During shooting, the [y] (P. 59) setting on the playback menu is set

automatically.

• This function may not work properly if the camera is facing up or down during shooting.

Submenu 2 Application

Information about the vertical/horizontal orientation of the

Off

camera during shooting is not recorded with images. Images shot with the camera in a vertical position are not rotated during playback.

Information about the vertical/horizontal orientation of the camera during shooting is recorded with images. Images are automatically rotated during playback.

Imprinting the date of recording z [Date Stamp]

Submenu 2 Application

Off Do not imprint the date.

On Stamp new photographs with the date of recording.

• When the date and time are not set, [Date Stamp] cannot be set. g [X] (P. 65)

• The date stamp can not be deleted.

• You cannot set [Date Stamp] when drive settings are [], [], [c], and [d], and the picture mode is except [Vivid], [Natural], and [Muted].

53EN53

Page 54

For the operation method, refer to (P. 47).

Shooting larger pictures than when using optical zoom with low degrading of image quality z [Super-Res Zoom]

Submenu 2 Application

Off Disable super-resolution zoom.

On Enable super-resolution zoom.

• [Super-Res Zoom] is available only when [Image Size] is set to [].

Super-resolution

zoom

On Off 16M

Off On

On On 16M

*1 Due to increased processing of the pixel counts, the image quality will not

degrade. The magnification ratio changes depending on the image size setting.

• Photographs taken with the zoom bar displayed in red may appear “grainy”.

54EN54

Digital zoom Image size Zoom bar

Super-resolution zoom

16M

Digital zoom

Other

Super-resolution zoom

Digital zoom

Page 55

For the operation method, refer to (P. 47).

Movie Menu

Reducing the blur caused by the camera shake when shooting A [IS Movie Mode]

Submenu 2 Application

Off

On The image stabilizer is activated.

On Hybrid

• Images may not be stabilized if camera shake is too severe.

• In HS movie mode, [On Hybrid] cannot be used.

The image stabilizer is deactivated. This is recommended for shooting when the camera is fixed in place on a tripod or other stable surface.

The image stabilizer is activated. This function compensates for large-amplitude shake, such as the slow kind which occurs if you shoot while walking.

Recording sound when shooting movies A [R]

Submenu 2 Application

Off No sound is recorded.

On Sound is recorded.

• Sound is not recorded when an HS movie mode is selected.

Reduce wind noise in the recorded sound when recording movie A [Wind Noise Setting]

Submenu 2 Application

Off Disable Wind Noise Reduction.

On Uses Wind Noise Reduction.

55EN55

Page 56

For the operation method, refer to (P. 47).

Playback Menu

Playing back pictures automatically q [Slideshow]

Submenu 2 Submenu 3 Application

Off/ Cosmic/

BGM

Start ― Starts the slideshow.

• During a slideshow, press I to advance one frame, H to go back one frame.

• Press the  button or the A button to stop the slideshow.

Breeze/ Mellow/ Dreamy/ Urban

Selects the background music options.

Editing still images q [Edit]

Submenu 1 Submenu 2

P. 57

P. 58

P. 59

P. 60

Edit (still images)

Edit (movies)

Q P

Shadow Adj

Redeye Fix

e-Portrait

In-Movie Image Capture

Movie Triming

56EN56

Page 57

For the operation method, refer to (P. 47).

Changing the image size q [Q]

This saves a high-resolution image as a separate image with a smaller size for use in e-mail attachments and other applications.

Submenu 1 Submenu 2 Submenu 3

Edit

1 Use HI to select an image. 2 Use FG to select an image size and press the A button.

• The resized image is saved as a separate image.

3 7

Cropping image q [P]

Submenu 1 Submenu 2

Edit

1 Use HI to select an image, and press the A

button.

2 Use the zoom lever to select the size of the

cropping frame, and use frame.

3 Press the A button after you have selected the

area to trim.

• The edited image is saved as a separate image.

FGHI

to move the

Back

Cropping frame

57EN57

Page 58

For the operation method, refer to (P. 47).

Adding sound to still images q [R]

Submenu 1 Submenu 2

Edit

1 Use HI to select an image. 2 Aim the microphone toward the sound source. 3 Press the A button.

• Recording starts.

• The camera adds (records) sound for approx. 4 seconds while playing back the image.

Microphone

To play sound recordings

To play sound recorded with an image, select the image and press the A button.

• Press FG to adjust volume.

Brightening areas that are dark due to backlight or other reasons q [Shadow Adj]

Submenu 1 Submenu 2

Edit Shadow Adj

1 Use HI to select an image, and press the A button.

• The edited image is saved as a separate image.

• Depending on the picture, the editing may not be effective.

• The retouching process may lower the image resolution.

Retouching red eyes in flash shooting q [Redeye Fix]

Submenu 1 Submenu 2

Edit Redeye Fix

1 Use HI to select an image, and press the A button.

• The edited image is saved as a separate image.

• Depending on the picture, the editing may not be effective.

• The retouching process may lower the image resolution.

58EN58

Page 59

For the operation method, refer to (P. 47).

Rotating images q [y]

Submenu 1 Submenu 2

Edit

1 Use HI to select an image. 2 Press the A button to rotate the image. 3 If necessary, repeat Steps 1 and 2 to make settings for other images, and

press the  button.

• The new picture orientations will be saved even after the power is turned off.

Smoothing skin tone q [e-Portrait]

Submenu 1 Submenu 2

Edit e-Portrait

1 Use HI to select an image, and press the A button.

• Some images cannot be adjusted such as when faces are undetectable.

• The edited image is saved as a separate image.

Capturing still images from movies q [In-Movie Image Capture]

Submenu 1 Submenu 2

Edit In-Movie Image Capture

1 Use HI to select the movie and press the A button.

2 Use FGHI to display the frame to be

captured and press the A button.

• The selected frame is recorded as a still image.

• Some frames cannot be captured.

00:14/00:3400:14/00:34

Frame position

59EN59

Page 60

For the operation method, refer to (P. 47).

Trimming long movies q [Movie Triming]

Submenu 1 Submenu 2

Edit Movie Triming

1 Use HI to select the movie and press the A button. 2 Use FG to select saving method and press the A button.

Submenu 3 Application

New File Records the trimmed movie as new movie file.

Overwrite Overwrites the original movie with the trimmed movie.

3 Use FGHI to display the frame to start erasing, and then press the A

button.

4 Use FGHI to display the frame to end erasing, and then press the A

button.

5 Use FG to select [Erase] and press the A button.

• To cancel trimming, select [Cancel].

• Movie trimming is processed by seconds. The movie length is automatically adjusted so that the selected start and end frames are included.

When editing movies in a group

1 Expand the desired group. g “Playing back grouped images” (P. 17) 2 Use HI to select the movie and press the A button.

• When you expand the group to edit respective movie, the edited movie can be saved respectively as [New File].

60EN60

Page 61

For the operation method, refer to (P. 47).

Erasing images q [Erase]

Submenu 2 Application

All Erase All images in the internal memory or card will be erased.

Sel. Image Images are individually selected and erased.

Erase Deletes the image displayed.

Erase Group

• When erasing pictures in the internal memory, do not insert the card into the camera.

• Protected images cannot be erased.

To individually select and erase images q [Sel. Image]

1 Use FG to select [Sel. Image], and

press the A button.

2 Use

be erased, and press the A button to add a R mark to the image.

• Turn the zoom lever to the T end to

3 Repeat Step 2 to select the images to be erased, and then press the 

button to erase the selected images.

4 Use FG to select [Yes], and press the A button.

• The images with a R mark are erased.

To erase all images [All Erase]

1 Use FG to select [All Erase], and press the A button. 2 Use FG to select [Yes], and press the A button.

All images in the group are erased. To erase each image in the group, refer to “Playing back panorama and grouped images” (P. 16).

FGHI

to select the image to

mark

return to the single frame display.

Sel. Image (1)

Erase/Cancel

4/304/30

61EN61

Page 62

For the operation method, refer to (P. 47).

Protecting images q [R]

• Protected images cannot be erased by [Erase] (P. 15, 61), [Sel. Image], [Erase Group], or [All Erase] (P. 61), but all images are erased by [Memory Format]/ [Format] (P. 62).

1 Use HI to select an image. 2 Press the A button.

• Press the A button again to cancel the settings.

3 If necessary, repeat Steps 1 and 2 to protect other images, and press the

 button.

• If you protect the grouped images, all images in the group will be protected at once. To protect each image in the group, expand images. g “Playing back panorama and grouped images” (P. 16)

d Settings Menu 1

Erasing data completely d [Memory Format]/ d [Format]

• Before formatting, check that no important data is left in the internal memory or card.

• Cards must be formatted with this camera before first use or after being used with other cameras or computers.

• Be sure to remove the card before formatting the internal memory.

Submenu 2 Application

Yes

No Cancels formatting.

Completely erases the image data in the internal memory or card (including protected images).

Copying images in the internal memory to the card d [Backup]

Submenu 2 Application

Yes Backs up image data in the internal memory to the card.

No Cancels the backup.

62EN62

Page 63

For the operation method, refer to (P. 47).

Using an Eye-Fi card d [Eye-Fi]

Submenu 2 Application

All Transfers all images.

Sel. Image Transfers only selected image.

Off Disable Eye-Fi communication.

• When using an Eye-Fi card, read the Eye-Fi card instruction manual carefully, and comply with the instructions.

• Use the Eye-Fi card in compliance with the laws and regulations of the country where the camera is used.

• In locations such as on an airplane, where the Eye-Fi communication is prohibited, remove the Eye-Fi card from the camera, or set [Eye-Fi] to [Off].

• This camera does not support the Eye-Fi card’s Endless mode.

Selecting a method for connecting the camera to other devices d [USB Connection]

Submenu 2 Application

Auto

Storage Connect camera as a card reader.

MTP

Print Select when connecting to a PictBridge-compatible printer.

• When using the supplied software, select [Storage].

• Refer to “Connecting the camera to a computer” (P. 80) for the connection method with a computer.

Set to select the connection method each time the camera is connected to another device.

For Windows Vista/Windows 7/Windows 8/Windows 8.1, connect camera as a portable device.

63EN63

Page 64

For the operation method, refer to (P. 47).

Turning on the camera with the q button d [q Power On]

Submenu 2 Application

Yes

The camera is not turned on. To turn on the camera, press the

button.

Press and hold the q button to turn the camera on in the playback mode.

Selecting the camera sound and its volume d [Sound Settings]

Submenu 2 Submenu 3 Application

Sound Type

Volume

1/2/3

0/1/2/3/4/5 Selects the operation volume of camera buttons.

0/1/2/3/4/5 Selects the image playback volume.

Selects the camera sounds (operation sounds, shutter sound, and warning sound).

Adjusting the image processing function d [Pixel Mapping]

• This function has already been adjusted at factory shipping, and no adjustment is needed right after purchase. Approximately once a year is recommended.

• For best results, wait at least one minute after taking or viewing pictures before performing pixel mapping. If the camera is turned off during pixel mapping, be sure to perform it again.

To adjust the image processing function

Press the A button when [Start] (Submenu 2) is displayed.

• The check and adjustment of the image processing function starts.

d Settings Menu 2

Adjusting the brightness of the monitor d [s]

1 Use FG to adjust the brightness while viewing

the monitor, and then press the A button.

64EN64

Back

Page 65

For the operation method, refer to (P. 47).

Playing back images on a TV d [TV Out]

The TV video signal system varies depending on the countries and regions.

Before viewing camera images on your TV, select the video output according to your TV’s video signal type.

Submenu 2 Submenu 3 Application

NTSC/PAL

HDMI Out

HDMI Control

• For the connection method, refer to “Viewing camera images on TV” (P. 72).

NTSC

PAL

480p/576p 720p 1080i 1080p

Off Operate with the camera.

On Operate with the TV remote control.

Connecting the camera to a TV in North America, Taiwan, Korea, Japan, and so on.

Connecting the camera to a TV in European countries, China, and so on.

Set the signal format to be given priority. If the TV setting does not match, it is changed automatically.

Changing the display language d [l]

Submenu 2 Application

Languages

The language for the menus and error messages displayed on the monitor is selected.

Setting the date and time d [X]

1 Press FG of the arrow pad to select the year for [Y]. 2 Press I of the arrow pad to save the setting for [Y]. 3 As in Steps 1 and 2, press FGHI of the arrow pad to set [M] (month),

[D] (day), [Time] (hours and minutes), and [Y/M/D] (date order), and then press the A button.

• For precise time setting, press the A button as the time signal strikes 00

seconds.

To check the date and time

Press and hold the INFO button while the camera is turned off. The current time is displayed for approx. 3 seconds.

65EN65

Page 66

For the operation method, refer to (P. 47).

Choosing home and alternate time zones d [World Time]

• You will not be able to select a time zone using [World Time] if the camera clock has not first been set using [X].

Submenu 2 Submenu 3 Application

Home/ Alternate

*1, 2

In areas where daylight saving time is in effect, use FG to turn daylight

saving time ([Summer]) on.

When you select a time zone, the camera automatically calculates the time

— Select the home time zone (x).

—

The time in the home time zone (the time zone selected for x in submenu 2).

The time in the travel destination time zone (the time zone selected for z in submenu 2).

Select the travel destination time zone (z).

difference between the selected zone and the home time zone (x) to display the time in the travel destination time zone (z).

Calibrating the touch panel d [Touch Calibration]

Touch the panel following the instructions on the screen with the Stylus pen.

Setting Wi-Fi d [Wi-Fi Settings]

Submenu 2 Application

Connection Settings

Private Regenerate a password. Reseth

Reset Wi-Fi Settings Reset Wi-Fi settings to the default settings.

Set the connection mode.

“Using Wi-Fi function” (P. 68)

Cancel all images selected for sharing.

• For the operation method, refer to “Setting up a wireless LAN connection (WiFi Settings)” (P. 69).

66EN66

Page 67

For the operation method, refer to (P. 47).

d Settings Menu 3

Adjusting interval settings d [Interval Settings]

Submenu 2

Frame

Start Waiting Time

Interval Time

1 to 99 (frames)

00 to 60 (minutes)

10/20/30/40/50 (sec.)/01 to 60 (minutes)

Submenu 3

Designing type of level gauge display d [Level Gauge Settings]

Submenu 2 Submenu 3 Application

Level Gauge Display

Level Adjust

Level gauge display

• Indicate the orientation of the camera. The “tilt” direction is indicated on the vertical bar and the “horizon” direction on the horizontal bar.

• Use the indicators on the level gauge as a guide.

• If the level gauge does not indicate the orientation correctly, calibrate the angle of the level gauge.

Off Hide level gauge.

On Display level gauge.

Reset Restore the factory default angle.

Adjust

Set the virtual horizon to the camera’s current angle.

250250 F6.9

0.00.0

67EN67

Page 68

Using Wi-Fi function

Using the wireless LAN functions on the camera, you can connect to a smartphone with Wi-Fi connectivity to view or transfer images on your smartphone, and to operate the camera by remote control. The position information will be added to images on the memory card. To use this function, you must have the relevant app installed on the smartphone. http://oishare.olympus-imaging.com/

• G is displayed on images to which position information has been added. Log

position information is only available when using a smartphone with a GPS function.

• Set the time and area of the camera precisely before using.

Before using the wireless LAN function, read “Precautions when using the

wireless LAN function” (P. 103).

If using the wireless LAN function in a country outside the region where the

camera was purchased, there is a risk that the camera will not conform to the wireless communication regulations of that country. Olympus will not be held responsible for any failure to meet such regulations.

Depending on the country or region, Wi-Fi and/or GPS is subject to the laws.

Therefore, you may not receive a repair service. Contact Olympus authorized service station in advance.

As with any wireless communication, there is always a risk of interception by

a third party.

The wireless LAN function on the camera cannot be used to connect to a

home or public access point.

While charging with F-2AC and connecting to USB device, Wi-Fi connection

is unavailable.

Page 69

Setting up a wireless LAN connection (Wi-Fi Settings)

To use the wireless LAN functions on the camera (P. 70), you need to make setting such as the password to be used when connecting.

Setting password selection method

1 Select [Wi-Fi Settings] in the d Settings Menu 2 and press A. 2 Select [Wi-Fi Connect Settings] and press I. 3 Select the wireless LAN connection method and press A.

Submenu 2 Submenu 3 Application

Private

Connection Settings

Changing private connection password

One-Time

Select Select which method to use each time.

Off Wi-Fi function is turned off.

Change the password used for [Private].

1 Select [Wi-Fi Settings] in the d Settings Menu 2 and press A. 2 Select [Private] and press I.

• Pressing F generates and displays a different password. A present

password is overwritten.

Cancelling image sharing

Deselects images selected for sharing (P. 70) when connected to a wireless LAN network.

1 Select [Wi-Fi Settings] in the d Settings Menu 2 and press A. 2 Select [Reseth] and press I. 3 Select [Yes] and press A.

Connects to one smartphone (Connect using a preset password.). All images in the camera are available for viewing.

Connects to two or more smartphones (Connect using a different password each time.). Only the images selected for sharing are available for viewing.

Page 70

Initializing wireless LAN settings

Initializes content of [Wi-Fi Settings].

1 Select [Wi-Fi Settings] in the d Settings Menu 2 and press A. 2 Select [Reset Wi-Fi Settings] and press I. 3 Select [Yes] and press A.

• A password is randomly changed.

The wireless LAN antenna is contained in the camera grip. Where possible,

avoid covering the antenna with your hands.

During wireless LAN connection, the battery will run down faster. If the battery

is running low, the connection may be lost during a transfer.

Connection may be difﬁ cult or slow in proximity to devices that generate

magnetic ﬁ elds, static electricity or radio waves, such as near microwaves, cordless telephone.

Sharing images over Wi-Fi connection

Share Order

With [One-Time], you can select the images to share in advance.

1 Display the setup menu.

• “Using the setup menu” (P. 47)

2 From the playback menu, select [Share Order] and then press the A button. 3 Use HI to select an image for sharing and press A to display h. 4 Repeat 3 to select all images for sharing, and then press the  button to

end [Share Order].

• h is displayed on the images selected for sharing.

You can set a share order on a maximum around 200 frames.

Page 71

Start Wi-Fi connection for sharing images (Wi-Fi Start)

You can view images directly on a smartphone that has Wi-Fi connectivity or transfer images between the camera and a smartphone that has Wi-Fi connectivity. To use this function, you must install and start the relevant app for the smartphone ”OI.Share (OLYMPUS IMAGE SHARE)”.

1 Select [Wi-Fi Start] in the d Camera Menu 1 and press A.

• Pressing and holding the  button also starts Wi-Fi connection.

• When [Connection Settings] is set to [Off], [Wi-Fi Start] is not available.

2 Select the connection method and press A.

• Depending on the setting of [Connection Settings], the connection method is varied as follows.

Private connection

• Sets SSID and a password with your smartphone. Reading a QR code with OI.Share sets SSID and a password automatically. From the second time, the same setting is automatically applied for the connection.

One-time connection

• Sets SSID and a password with your smartphone every time. Reading a QR code with OI.Share sets SSID and a password automatically.

Select

• Select which method to use each time.

3 To end the connection, press and hold  on the camera.

• While selecting Remote Shutter Mode in OI.Share, press A after a QR code is displayed.

Page 72

Connecting the camera to another device

Viewing camera images on TV

Use the AV cable (sold separately) to playback recorded images on your TV. You can play back high-definition images on a high-definition TV by connecting it to the camera using the HDMI cable.

Multi-connector

AV cable (sold separately: CB-AVC3) (Connect to the TV video input jack (yellow) and audio input jack (white).)

HDMI cable (Connect to the HDMI connector on the TV.)

HDMI Micro connector

Use the cable to connect the camera to the TV.

• Choose the camera video mode before connecting the camera via an AV

cable. g [TV Out] (P. 65)

Choose the TV input channel.

• The camera monitor turns off when the cable is connected.

• Press the q button when connecting via an AV cable.

• For details on changing the input source of the TV, refer to the TV’s instruction manual.

• Depending on the TV’s settings, the displayed images and information may become cropped.

(type D)

Page 73

• If the camera is connected using both an A/V and HDMI cable, it will assign priority to HDMI.

• Do not connect the USB cable and HDMI cable at the same time.

• If the camera is connected via an HDMI cable, you will be able to choose the digital video signal type. Choose a format that matches the input format selected with the TV.

1080p Priority is given to 1080p HDMI output.

1080i Priority is given to 1080i HDMI output.

720p Priority is given to 720p HDMI output.

480p/576p

480p/576p HDMI output. 576p is used when [PAL] is selected for

[TV Out] (P. 65)

Using the TV remote control

The camera can be operated by a TV remote control when connected to a TV that supports HDMI control.

Select [TV Out] in Settings Menu 2.

Select [HDMI Control] and choose [On].

Operate the camera by using the TV remote control.

• You can operate the camera by following the operation guide displayed on the TV.

• Some televisions may not support all features.

• You cannot shoot pictures or movies when the HDMI cable is connected.

• Do not connect the camera to other HDMI output devices. Doing so may damage the camera.

• HDMI output is not performed while connected via USB to a computer or printer.

Page 74

Printing Pictures

Direct printing (PictBridge)

By connecting the camera to a PictBridge-compatible printer with the USB cable, you can print out recorded pictures directly. Before connecting, select [Print] for [USB Connection] (P. 63) in the setting menu.

Connecting the camera

Multi-connector

Smaller terminal

• Use a fully charged battery for printing.

• Movies cannot be printed.

 Easy printing

Use HI to display the pictures you want to print on the

USB cable

camera.

Connect the camera to the printer

using the supplied USB cable.

• If the easy print start screen is not displayed, select [Print] for [USB Connection] (P. 63) in the setting menu before connecting the printer again.

Easy Print Start Custom Print

USB port

Page 75

Press I.

• The picture selection screen appears when printing is completed. To print

another picture, use HI to select the image and press A.

• To exit, unplug the USB cable from the camera while the picture selection screen is displayed.

 Custom printing

Connect the camera to the printer using the supplied USB

cable and turn the camera on.

• When the camera is turned on, a dialog should be displayed in the monitor prompting you to choose a host. If it is not, select [Print] for [USB Connection] (P. 63) in the setting menu.

Follow the operation guide to set a print

All Print

Multi Print

All Index

Print Order

option.

Selecting the print mode

Select the type of printing (print mode). The available print modes are as shown below.

Print Prints selected pictures.

All Print

Multi Print

All Index Prints an index of all the pictures stored in the card.

Print Order

Prints all the pictures stored in the card and makes one print for each picture.

Prints multiple copies of one image in separate frames on a single sheet.

Prints according to the print reservation you made (P. 78). If there is no picture with print reservation, this is not available.

BackPrint Mode Select

Page 76

Setting the print paper items

This setting varies with the type of printer. If only the printer’s STANDARD setting is available, you cannot change the setting.

Size Sets the paper size that the printer supports.

Borderless

Pics/sheet

Selects whether the picture is printed on the entire page or inside a blank frame.

Selects the number of pictures per sheet. Displayed when you have selected [Multi Print].

Selecting pictures you want to print

Select pictures you want to print. The selected pictures can be printed later (single-frame reservation) or the picture you are displaying can be printed right away.

Prints the currently displayed picture. If there is a

Print (f)

picture that [Single Print] reservation has already been applied to, only that reserved picture will be printed.

Applies print reservation to the currently displayed

Single Print (t)

picture. If you want to apply reservation to other pictures after applying [Single Print], use HI to select them.

Sets the number of prints and other items for the

More (u)

currently displayed picture, and whether or not to print it. For operation, refer to “Setting printing data” in the next section.

Single Print

4/30

34564608 34564608

100-0004

’14/02/26’14/02/26 12:3012:30

Select

ORMNORM

Page 77

Setting printing data

Select whether to print printing data such as the date and time or file name on the picture when printing.

<×

Date Prints the date and time recorded on the picture.

File Name Prints the file name recorded on the picture.

Once you have set the pictures for printing and printing data,

Sets the number of prints.

Trims the picture for printing. Set the trimming size with the zoom lever (T/W), and set the trimming position with FGHI.

select [Print], then press A.

• To stop and cancel printing, press A. To resume printing, select [Continue].

 Cancelling printing

To cancel printing, highlight [Cancel] and press A. Note that any changes to the print order will be lost; to cancel printing and return to the previous step, where you can make changes to the current print order, press .

Page 78

Print reservation (DPOF)

In print reservations, the number of prints and date imprint option are saved in the image on the card. This enables easy printing at a printer or print shop supporting DPOF by using only the print reservations on the card without a computer or a camera.

• Print reservations can be set only for the images stored on the card.

• DPOF reservations set by another DPOF device cannot be changed by this camera. Make changes using the original device. Making new DPOF reservations with this camera will erase the reservations made by the other device.

• DPOF print reservations can be made for up to 999 images per card.

 Single-frame print reservations [<]

Display the setup menu.

• “Using the setup menu” (P. 47)

From the playback menu q, select [Print Order] and then

press the A button.

Use

A button.

to select [<], and press the

Print Order

’14/02/26’14/02/26 12:3012:30

100-0004

4/30

34564608 34564608

ORMNORM

Use HI to select the image for print reservation. Use

select the quantity. Press the A button.

Use

to select the [X] (date print) screen option, and

press the A button.

Submenu 2 Application

No This prints the image only.

Date This prints the image with the shooting date.

Time This prints the image with the shooting time.

Use

to select [Set], and press the A button.

Page 79

 Reserving one print each of all images on the card [U]

Follow Steps 1 and 2 in [<] (P. 78).

Use

Follow Steps 5 and 6 in [<].

 Resetting all print reservation data

Follow Steps 1 and 2 in [<] (P. 78).

Select either [<] or [U], and press the A button.

Use

 Resetting the print reservation data for selected images

Follow Steps 1 and 2 in [<] (P. 78).

Use

Use HI to select the image with the print reservation you

want to cancel. Use If necessary, repeat Step 4, and then press the A button when

finished.

Use

press the A button.

• The settings are applied to the remaining images with the print

Use

to select [U], and press the A button.

to select [Reset], and press the A button.

to select [<], and press the A button.

to select [Keep] and press the A button.

to set the print quantity to “0”.

to select the [X] (date print) screen option, and

reservation data.

to select [Set], and press the A button.

Page 80

Connecting the camera to a computer

Connecting the camera

Multi-connector

USB cable

Smaller terminal

If nothing is displayed on the camera screen even after connecting the

camera to the computer, the battery may be exhausted. Use a full-charged battery.

If the camera cannot connect to PC, disconnect the USB cable and check the

setting of [USB Connection] (P. 63) before connecting to PC again.

• The battery can be charged while the camera is connected to the computer via USB. The charging time varies depending on the performance of the computer. (There may be cases in which it takes approx. 10 hours.)

USB port

Page 81

Copying pictures to a computer

Your camera supports the USB Mass Storage Class. You can transfer images to a computer by connecting the camera to the computer with the provided USB cable. The following operating systems are compatible with the USB connection:

Windows

Macintosh Mac OS X v10.5-v10.9

Turn the camera off and connect it to the computer.

• The location of the USB port varies with the computer. For details, refer to your computer’s manual.

The computer recognizes the camera as a new device.

If your computer is running Windows Vista / Windows 7 / Windows 8 /

Windows 8.1, select [MTP] in [USB Connection] of the setting menu to use Windows Photo Gallery.

Data transfer is not guaranteed in the following environments, even if your

computer is equipped with a USB port.

Computers with a USB port added by means of an extension card, etc. Computers without a factory-installed OS and home-built computers

Camera controls can not be used while the camera is connected to a

computer.

If the dialog is not displayed when the camera is connected, set [USB

Connection] (P. 63) of the setting menu before connecting to PC again.

Windows XP SP3 /Windows Vista SP2 / Windows 7 SP1 / Windows 8 / Windows 8.1

Page 82

Installing Software

 Windows

Insert the supplied CD in a CD-ROM drive.

Windows XP

• A “Setup” dialog will be displayed.

Windows Vista / Windows 7 / Windows 8 / Windows 8.1

• An Autorun dialog will be displayed. Click “OLYMPUS Setup” to display the “Setup” dialog.

If the “Setup” dialog is not displayed, select “My Computer” (Windows XP) or

“Computer” (Windows Vista/Windows 7) from the start menu. Double-click the CD-ROM (OLYMPUS Setup) icon to open the “OLYMPUS Setup” window and then double-click “LAUNCHER.EXE”.

If a “User Account Control” dialog is displayed, click “Yes” or “Continue”.

Follow the on-screen instructions on your computer.

• Click the “Registration” button and follow the on-screen instructions.

Install OLYMPUS Viewer 3.

• Check the system requirements before beginning installation.

• Click the “OLYMPUS Viewer 3” button and follow the on-screen instructions to install the software.

Operating System

Processor

RAM 1 GB or more (2 GB or more recommended)

Free Hard Drive Space 3 GB or more

Monitor Settings

• See online help for information on using the software.

Windows XP SP3 /Windows Vista SP2 / Windows 7 SP1 /Windows 8 / Windows 8.1

Pentium 4 1.3 GHz or better (Core 2 Duo 2.13 GHz or better required for movies)

1024 × 768 pixels or more Minimum 65,536 colors (16,770,000 colors recommended)

Page 83

 Macintosh

Insert the supplied CD in a CD-ROM drive.

• The disk contents should automatically be displayed in the Finder. If they are not, double-click the CD icon on the desktop.

• Double-click the “Setup” icon to display the “Setup” dialog.

Install OLYMPUS Viewer 3.

• Check the system requirements before beginning installation.

• Click the “OLYMPUS Viewer 3” button and follow the on-screen instructions to install the software.

Operating System Mac OS X v10.5–v10.9

Processor

RAM 1 GB or more (2 GB or more recommended)

Free Hard Drive Space 3 GB or more

Monitor Settings

• Other languages can be selected from the language combo box. For information on using the software, see online help.

Intel Core Solo/Duo 1.5 GHz or better (Core 2 Duo 2 GHz or better required for movies)

1024 × 768 pixels or more Minimum 32,000 colors (16,770,000 colors recommended)

Page 84

Usage Tips

If the camera does not work as intended, or if an error message is displayed on the screen, and you are unsure of what to do, refer to the information below to fix the problem(s).

Troubleshooting

 Battery

The camera does not work even when batteries are installed.

• Insert recharged batteries in the correct direction. g “Inserting and

removing the battery and card” (P. 4)

• Battery performance may have been reduced temporarily due to low temperature. Take the batteries out of the camera, and warm them by putting them in your pocket for a while.

 Card

An error message is displayed.

• g “Error message” (P. 86)

 Shutter button

No picture is taken when the shutter button is pressed.

• Cancel sleep mode. To save battery power, the camera automatically goes into sleep mode and the monitor turns off if there is no operation for 3 minutes when the camera is turned on. No picture is taken even if the shutter button is fully pressed in this mode. Operate the zoom lever or other buttons to restore the camera from sleep mode before taking a picture. If the camera is left for another 12 minutes, it automatically turns off. Press the n button to turn the camera on.

• Press the q button to switch to the shooting mode.

• Wait until #(flash charge) stops blinking before taking pictures.

• With prolonged camera use, the internal temperature may increase, resulting in automatic shutdown. If this occurs, wait until the camera has sufficiently cooled. The camera’s external temperature may also increase during use, however this is normal and does not indicate malfunction.

Page 85

 Monitor

Difficult to see.

• Condensation may have occurred. Turn off the power, and wait for the camera body to become acclimated to the surrounding temperature and dry out before taking pictures.

The light is caught in the picture.

• Shooting with flash in dark situations results in an image with many flash reflections on dust in the air.

 Date and time function

Date and time settings return to the default setting.

• If the batteries are removed and left out of the camera for about 3 days*1, the date and time settings return to the default setting, and must be reset. *1 The time until the date and time settings return to the default setting varies

depending on how long the batteries have been loaded. g “Turning on the camera and making the initial settings” (P. 8)

Page 86

Error message

• When one of the messages below is displayed on the monitor, check the corrective action.

Error message Corrective action

Card problem

Card Error

Write Protect

Memory Full

Card Full

Card Setup

Power Off

Format

Memory Setup

Power OffPower Off

Memory Format

No Picture

Picture Error

Before erasing important images, download them to a computer.

All data will be erased.

Insert a new card.

Card problem

The card write-protect switch is set to the “LOCK” side. Release the switch.

Internal memory problem

• Insert a card.

• Erase unwanted images.

Card problem

• Replace the card.

• Erase unwanted images.

Card problem

Use FG to select [Format], and press the A button. Next, use FG to select [Yes], and press the A

button.

Internal memory problem

Use FG to select [Memory Format], and press the

A button. Next, use FG to select [Yes], and press the A button.

Internal memory/Card problem

Take pictures before viewing them.

Problem with selected image

Use photo retouch software, etc. to view the image on a computer. If the image still cannot be viewed, the image file is corrupted.

Page 87

Error message Corrective action

Problem with selected image

The Image

Cannot Be Edited

Use photo retouch software, etc. to edit the image on a computer.

Battery problem

Battery Empty

Charge the battery.

Connection problem

No Connection

Connect the camera and computer or printer correctly.

Printer problem

No Paper

Load paper into the printer.

Printer problem

No Ink

Refill the ink in the printer.

Printer problem

Jammed

Settings

Changed

Remove the jammed paper.

Printer problem

Return to the status where the printer can be used.

Printer problem

Print Error

Turn off the camera and printer, check the printer for any problems, and then turn the power on again.

Problem with selected image

Use a computer to print.

Cannot Print

This is displayed, for instance, when the printer’s paper tray has been

removed. Do not operate the printer while making the print settings on the camera.

This camera may be unable to print images taken by other cameras.

Page 88

Shooting tips

When you are unsure of how to take a picture that you envision, refer to the information below.

 Focusing

Focusing on the subject.

• Taking a picture of a subject not in the center of the monitor. g P. 38

After focusing on an object at the same distance as the subject, compose the shot, and take the picture.

• Set [AF Mode] to [Face/iESP]. g P. 50

• Taking a picture in [AF Tracking] mode. g P. 50

The camera tracks the subject movement automatically to focus on it continuously.

• Taking a picture of a shadowy subject. g P. 52

Using the AF illuminator makes focusing easier.

• Taking a picture of subjects where autofocus is difficult.

In the following cases, after focusing on an object (by pressing the shutter button halfway down) with high contrast at the same distance as the subject, compose the shot, and take the picture.

Subject with low contrast Excessively bright light in

Subjects at different

distances

center of frame

Fast-moving subject Subject not inside AF

Subject containing no vertical lines

area

*1 It is also effective to compose the shot by holding the camera vertically to

focus, and then returning to the horizontal position to take the picture.

Page 89

 Camera shake

Taking pictures without camera shake.

• Taking pictures using [Image Stabilizer]. g P. 52

The camera detects camera movement to reduce the blur even if the ISO sensitivity is not increased. This function is also effective when taking pictures at a high zoom magnification.

• Shooting movies using [IS Movie Mode]. g P. 55

• Select [J Sport] in the scene mode. g P. 26 The [J Sport] mode uses a fast shutter speed and can reduce the blur incurred by a moving subject.

• Taking pictures at a high ISO sensitivity. g P. 42 If a high ISO sensitivity is selected, pictures can be taken at a high shutter speed even at locations where a flash cannot be used.

 Exposure (brightness)

Taking pictures with the right brightness.

• Taking pictures of a subject against a backlight Faces or backgrounds are bright even when shot against backlight. [Shadow Adjust] g P. 58 [E Backlight HDR] g P. 26

• Taking pictures using [Face/iESP]. g P. 50 Appropriate exposure is obtained for a face against backlight, and the face is brightened.

• Taking pictures using [Spot Metering]. g P. 51 Brightness is matched with a subject in the center of the screen and the image is not affected by background light.

• Taking pictures using [Fill In] flash. g P. 35 A subject against backlight is brightened.

• Taking pictures of a white beach or snow scene. g P. 26 Select [g Beach & Snow] in the scene mode.

• Taking pictures using exposure compensation. g P. 36 Adjust the brightness while viewing the screen for taking the picture. Normally, taking pictures of white subjects (such as snow) results in images that are darker than the actual subject. Use the exposure compensation to adjust in the positive (+) direction to express whites as they appear. When taking pictures of black subjects, on the other hand, it is effective to adjust in the negative (-) direction.

Page 90

 Color hue

Taking pictures with colors at the same shade as they appear.

• Taking pictures by selecting white balance. g P. 42

Best results in most environments can normally be obtained with the [WB Auto] setting, but for some subjects, you should try experimenting with different settings. (This is especially true for sunshade under a clear sky, mixed natural and artificial light settings, and so on.)

 Image quality

Taking sharper pictures.

• Taking pictures with the optical zoom or super-resolution zoom. Avoid using digital zoom (P. 51) to take pictures.

• Taking pictures at a low ISO sensitivity. g P. 42 If the picture is taken with a high ISO sensitivity, noise (small colored spots and color unevenness that were not in the original image) can occur, and the image can appear grainy.

Playback/Editing tips

 Playback

Playing images in the internal memory and card.

• Remove the card and display the images in internal memory. g P. 4

Viewing images with high picture quality on a highdefinition TV.

• Connect the camera to the TV using an HDMI cable. g P. 72

 Editing

Erasing the sound recorded to a still image.

• Record over the sound with silence when playing back the image.

g P. 58

Page 91

Page 92

Information

Cleaning and storing the camera

Camera care

Exterior:

• Wipe gently with a soft cloth. If the camera is very dirty, soak the cloth in water

and wring well. Wipe the camera with the damp cloth and then dry it with a dry cloth. If you have used the camera at the beach, use a cloth soaked in clean water and well wrung.

Monitor:

• Wipe gently with a soft cloth.

Lens:

• Blow dust off the lens with a commercial blower, then wipe gently with a lens

cleaner.

Do not use strong solvents such as benzene or alcohol, or a chemically

treated cloth.

Mold may form on the lens surface if the lens is left dirty.

Battery/USB-AC adapter:

• Wipe gently with a soft, dry cloth.

Storage

• When storing the camera for extended periods, remove the battery, adapter

and card, and keep in a cool, dry place that is well ventilated.

• Periodically insert the battery and test the camera functions.

Avoid leaving the camera in places where chemical products are handled

since this may result in corrosion.

Page 93

Using a separately sold USB-AC adapter

The USB-AC adapter F-3AC (sold separately) can be used with this camera. Do not use any USB-AC adapter other than the dedicated one. When using F-3AC, be sure to use the USB cable included with this camera. Do not use any other USB-AC adapter with this camera.

Using a separately sold charger

A charger (UC-90: sold separately) can be used to charge the battery.

Using your charger and USB-AC adapter abroad

• The charger and USB-AC adapter can be used in most home electrical sources within the range of 100 V to 240 V AC (50/60Hz) around the world. However, depending on the country or area you are in, the AC wall outlet may be shaped differently and the charger and USB-AC adapter may require a plug adapter to match the wall outlet. For details, ask at your local electrical shop or travel agent.

• Do not use travel voltage converters as they could damage your charger and USB-AC adapter.

Page 94

Using the card

Cards compatible with this camera

SD/SDHC/SDXC/Eye-Fi (with Wireless LAN function) card (commercially available) (for compatibility card details, visit the Olympus website.)

• This camera can be used without a card by storing images in its internal memory.

Eye-Fi card

• The Eye-Fi card may become hot during use.

• When using an Eye-Fi card, the battery may run out faster.

• When using an Eye-Fi card, the camera may function more slowly.

SD/SDHC/SDXC card write-protect switch

The SD/SDHC/SDXC card body has a write-protect switch. If you set the switch to the “LOCK” side, you will not be able to write to the card, delete data or format. Return the switch to enable writing.

LOCK

Format

Cards must be formatted with this camera before first use or after being used with other cameras or computers.

Page 95

Checking the image saving location

The memory indicator shows whether the internal memory or card is being used during shooting and playback.

Current memory indicator

v: Internal memory is being used w: Card is being used

Even if [Memory Format]/[Format], [Erase], [Sel. Image], [All Erase], or [Erase

Group] is performed, the data in the card is not completely erased. When disposing of the card, damage the card to prevent the disclosure of personal data.

Switching between a card and internal memory is not available.

When using the internal memory, remove the card ﬁ rst.

Readout/recording process of the card

During shooting, the current memory indicator lights up in red while the camera is writing data. Never open the battery/card cover or unplug the USB cable. This can not only damage the image data but also render the internal memory or card unusable.

Page 96

Number of storable pictures (still images)/Recording length (movies) in the internal memory and cards

The ﬁ gures for the number of storable still pictures and recording length are

approximate. The actual capacity varies with shooting conditions and the card used.

4608×3456

3200×2400

1920×1440

640×480

Compression

L M L M L M L M

Number of storable pictures

Internal memory SD/SDHC/SDXC card (4GB)

4 460 8 880

9 900 16 1,630 27 2,740 54 5,480

198 20,110 341 30,170

Recording length

Internal memory

With sound

9 sec. 9 sec. 18 min. 18 min.

14 sec. 15 sec. 27 min. 29 min.

27 sec. 30 sec. 51 min. 57 min.

1 min. 6 sec. 1 min. 28 sec. 125 min. 167 min.

―

Without sound

11 sec. 17 sec.

SD/SDHC/SDXC card (4GB) With sound

―

Without sound

21 min. 32 min.

Still pictures

Image Size



Examples of image size when the aspect ratio is 4:3.

Movies

Image Size

c 1920×1080

 1920×1080  1280×720

640×480

y 1280×720 z 432×324

The recording length is up to 29 minutes in the HD quality specified.

The recording length is up to 20 sec. in the HS quality specified.

• The maximum file size of a single movie is 4GB, regardless of the capacity of the card.

Increasing the number of pictures that can be taken

Either erase unwanted images, or connect the camera to a computer or other device to save the images, and then erase the images in the internal memory or card. [Erase] (P. 15, 61), [Sel. Image], [All Erase], [Erase Group] (P. 61), [Memory Format]/ [Format] (P. 62)

Page 97

List of settings available in each shooting mode

For the available settings of O and settings” (P. 98) and “List of

Picture Mode Flash Exposure Comp. White balance ISO

o/Y

Image size (still images)

Aspect Image size (movies) Shutter speed Aperture value Compression Shadow Adjust Touch Shutter AF Mode

ESP/ Digital Zoom Image Stabilizer AF Illuminat. Rec View Pic Orientation Date Stamp Super-Res Zoom IS Movie Mode

Wind Noise Setting

ART

settings” (P. 99).

―――

*1 *1 ― *1 *1 ―

―

*1 ― *1 *1 *1 *1

*1 ― *1

――――

RRRRRR

―――

R RR

――*1

―

―――

R RR

―

R RR RRRRRR RR

―――

R RR RR RR

ART

, refer to “List of O

RR RRR R

――

―

RRR

RRR R

―

――

―

― *1 ――

RR R R R

RRR

―

RRR

R RRR RRR RRR

― *1

――

―

*1 *1

――

― *1

― *1 ― *1 ― *1

――

― *1

R R

―

*1 *1 *1 *1

*1 *1 *1

*1 Some functions cannot be set.

Page 98

List of

settings

BeF1GUC

Picture Mode Flash Exposure Comp. White balance ISO

o/Y

Image size (still images)

Aspect Image size

(movies) Shutter speed Aperture value Compression Shadow Adjust Touch Shutter AF Mode

ESP/ Digital Zoom Image Stabilizer AF Illuminat. Rec View Pic Orientation Date Stamp Super-Res Zoom IS Movie Mode

Wind Noise Setting

*1 Some functions cannot be set.

―――R――――――――――R― *1 *1 ―R― *1 *1 *1 *1 ――*1 ― *1 ――

―――R――――――――――R―

―――R――――――――――R― *1 *1 *1 ― *1 *1R*1 *1 *1 *1 *1 *1 *1R*1

RRRRRRRRRRRRRRRR

*1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1R*1

――――――――――――――――

RRRRRRRRRRRRRRRR RRRR RRRR R―R

――――――――――――――――

RRRRRRR RRR―RRRRRRRRRRRR RRRRRRRRRR RRR―RRRRRRRRRRRR RRRRRRRRRRRRRRRR RRRRRRRRRRRRRRRR

――――――――――――――――

RRRRRRRRRRRRRRRR RRRRRRRRRRRRRRRR

RRRRRRRRRRRRRRRR

23`X_^gIE

――

RRRR―RRR RRRRRRRR

RR―R―RRR

R―R

―

R RR

―

――

R―R

Page 99

List of

Picture Mode Flash Exposure

Comp. White balance ISO

o/Y

Image size (still images)

Aspect Image size

(movies) Shutter speed Aperture value Compression Shadow Adjust Touch Shutter AF Mode ESP/ Digital Zoom Image

Stabilizer AF Illuminat. Rec View Pic Orientation Date Stamp Super-Res

Zoom IS Movie Mode

Wind Noise Setting

*1 Some functions cannot be set.

ART

settings

Pop

Soft

Art

Focus

―― ― ―― ― ―

RR R RR R R

RR R

―― ― ―― ― ―

*1 *1 *1 *1 *1 *1 *1

RR R RR R R

*1 *1 *1 *1 *1 *1 *1

―― ― ―― ― ―

RR R RR R R

―― ― ―― ― ―

RR R RR R R RR R RR R R RR R RR R R

―― ― ―― ― ―

RR R RR R R

RR R RR R R RR R RR R R RR R RR R R

―― ― ―― ― ―

RR R RR RR R RR

RR R RR

Pale&Light

Color

Grainy

Film

―

Diorama

Hole

RR R

―

Dramatic

Tone

R R

Page 100

General Precautions

Handling the Camera

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT

REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL.

DANGER If the product is used without observing the information given

WARNING If the product is used without observing the information given

CAUTION If the product is used without observing the information given

WARNING! TO AVOID THE RISK OF FIRE OR ELECTRICAL SHOCK, NEVER DISASSEMBLE, EXPOSE THIS PRODUCT TO WATER OR OPERATE IN A HIGH HUMIDITY ENVIRONMENT.

General Precautions

Read All Instructions — Before you use the product,

read all operating instructions. Save all manuals and documentation for future reference.

Cleaning — Always unplug this product from the wall

outlet before cleaning. Use only a damp cloth for cleaning. Never use any type of liquid or aerosol cleaner, or any type of organic solvent to clean this product.

Attachments — For your safety, and to avoid

damaging the product, use only accessories recommended by Olympus.

Water and Moisture — For precautions on

products with weatherproof designs, read the weatherprooﬁ ng sections.

Location — To avoid damage to the product, mount

the product securely on a stable tripod, stand, or bracket.

REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

An exclamation mark enclosed in a triangle alerts you to important operating and maintenance instructions in the documentation provided with the product.

under this symbol, serious injury or death may result.

under this symbol, injury or death may result.

under this symbol, minor personal injury, damage to the equipment, or loss of valuable data may result.

Power Source — Connect this product only to the

power source described on the product label.

Lightning — If a lightning storm occurs while using

a USB-AC adapter, remove it from the wall outlet immediately.

Foreign Objects — To avoid personal injury, never

insert a metal object into the product.

Heat — Never use or store this product near any

heat source such as a radiator, heat register, stove, or any type of equipment or appliance that generates heat, including stereo ampliﬁ ers.

Handling the Camera

WARNING

• Do not use the camera near ﬂ ammable or explosive gases.

• Do not use the ﬂ ash and LED (including AF illuminator) on people (infants, small children, etc.) at close range.

• You must be at least 1 m (3 ft.) away from the faces of your subjects. Firing the ﬂ ash too close to the subject’s eyes could cause a momentary loss of vision.

100

Olympus SH-1 Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Preparations for shooting

Using basic functions

Shooting using basic functions

Using the setup menu functions

Connecting the camera to another device

Usage Tips

Information

SAFETY PRECAUTIONS
