Olympus E-450, E-450 14-42mm Kit Specifications

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

E-450 14-42mm Kit

• Art Filters • Built-In flash and wireless
flash control

• 100% D-SLR quality • 10 Megapixel Live MOS
sensor

• TruePic III+ processor for

ideal color reproduction and
low noise

• Exceptional ease of use

• Comfortable Live View

thanks to high speed
contrast AF**

• 6.9cm / 2.7'' HyperCrystal
II LCD

With the Olympus E-450, the superior quality of E-System D-SLRs and ease-of-use of compact cameras are fused in a model that
brings out the artist in anyone. Indeed, the successor to the renowned E-420 is packed with features that encourage novices to explore
their creative potential and create masterpieces. Three in-camera Art Filters, for example, apply stylish effects to any image at the touch
of a button. Meanwhile, image composition is simplified thanks to Live View depictions on the bright LCD. This latest addition to the
Olympus E-System range is not only one of the smallest and lightest models on the market*, it also boasts all the benefits of the Four
Thirds Standard at an affordable price. And, of course, the E-450 has a full range of Olympus’ innovative
E-System technology on board.

Specifications

Type

Lens mount Four Thirds

Body material Glassfibre reinforced plastics

Image Sensor

Effective pixels 10 Megapixels

Filter array Primary colour filter (RGB)

Full resolution 11.8 Megapixels

Type 4/3'' Live MOS sensor

Aspect ratio & area 4:3 / 17.3 x 13.0mm

Engine

Type TruePic III+

Filter

LPF filter Fixed type

IR cut filter Hybrid type

Dust reduction filter Supersonic Wave Filter

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Viewfinder

Viewfinder type Eye-level single-lens

viewfinder

Field of view Approx. 95%

Magnification Approx. 0.92x with a 50mm

lens set to infinity at -1

dioptre

Depth of field preview Yes

Eye point 14mm

Diopter adjustment Yes -3.0 - +1.0 diopter / built-

in type

Focusing screen Fixed type (Neo Lumi-Micron

Mat Screen)

Mirror Quick return mirror

Displayed information AF frame (super impose)

AE lock

AF confirmation mark

Metering mode

Exposure mode

Shutter speed

Aperture value

White balance

Exposure compensation

value indicator

Flash

Battery check

Eye piece shutter Eye-piece cap EPC-1

supplied

Live View

AF type Option between phase

difference detection system

and contrast detection

autofocus

Displayed information Face / Eye detection mode

Focus mode

AF frame display

AF confirmation mark

Shooting information

100% field of view 100%

Magnification levels 7 / 10x

Focusing System

Method TTL phase difference

detection system, contrast

detection system

Modes Manual focus

Single AF

Single AF + MF

Continuous AF

Continuous AF + MF

Focus areas 3 points / Automatic and

manual selection. For

contrast detection AF, 11

points are used.

AF illuminator Yes , Built-in flash (external

flash available / inactivation

possible)

AF lock Yes , Locked by first position

of shutter release button, AE/

AF lock button (customised)

AF tracking Yes , Available in continuous

AF mode

Detection range 0 - 19 EV (ISO 100)

Exposure System

Exposure compensation +/- 5EV / 1/3 steps

Exposure bracketing 3 frames / +/- 1/3, 2/3, 1 EV

steps

Modes Auto

Programme automatic

Aperture priority

Shutter priority

Manual

Scene Modes

Light Metering

Method TTL open aperture light

metering

Zones 49 zones Multi-pattern

Sensing System

Detection range 1 - 20 EV (50mm, 1:2, ISO

100)

Sensitivity

Auto ISO 100 - 1600

Manual ISO 100 - 1600 (adjustable in

1 EV steps)
