The DP70 is a 12.5-megapixel, 12-bit cooled digital color camera offering high
sensitivity and high-speed data transfer. This camera is equipped to capture
images with outstanding color fidelity from demanding application s including
fluorescence.

The 3.3-megapixel DP12 offers users maximum flexibility. Use it as a stand-alone
digital camera, operated conveniently from the compact handset control unit, or
interface it to a PC via USB technology.

View Hamamatsu's line of high resolution video and digital cameras specially
developed for microscopy and other scientific applications.

The MicroFire is a 2-megapixel, 12-bit FireWire™ digital camera. Comes complete
with easy-to-use PictureFrame software, allowing images to be acquired
effortlessly. Imaging has never been this easy! Choose from either a color or
monochrome model.

The Q-Color digital camera series is available in 5.0 and 3.2- megapixel versions.
Both deliver high-resolution images with outstanding detail an d great color f or
documentation and publication. Available with or without cooling.

This high performance, megapixel digital camera is designed to provide high­resolution, full-color images viewable on a PC via its FireWire™ (IEEE 1394) high­speed interface.

For digital imaging systems offering high performance and megapixel resolution,
choose from a color or monochrome 12-bit cooled FireWire™ digital camera
featuring high dynamic range, low noise, and high sensitivity for outstanding
results.

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

Olympus’ wide array of high-quality color video cameras give you all the image
quality and flexibility you need for an efficient viewing experience.

We offer a full line of film cameras, ranging from completely manual to fully
automatic, for varying levels of creativity and ease of use.

DP70 Camera Specifications

DP70 Camera Type Single Chip Color CCD Camera, Piezo shifted
Imaging Sensor

Image Resolutions 4080x3072, 2040x1536, 1360x1024, 680x512
Sensitivity ISO equivalents of 200/400/800/1600
Bit Depth 12-bit per R,G,B (48-bit image file)
Metering Modes 30%, 1%, & 0.1% spot (moveable)
Exposure Range 1/44,000 sec. to 60 sec.
Exposure Controls Exposure Modes Auto, manual, SFL auto

Image Integration Mode Integral or average
Number 64 frames
Binning Options Off (1x), 2X, 4X For preview image only
White Balance Mode Auto, manual, and one-push
Black Balance Mode Auto, manual, and one-push
Image Format BMP, TIFF, JPEG, PICT, and AVI
Computer Interface PCI bus interface
Image Transfer Rate Approximately 3 sec. (at max. resolution 4080x3072)
Frame Rate 15 frames/sec. max. @ 680x512
OS Windows XP, 2000, NT 4.0

Cooling Peltier device, Ta-10º C
Size 2/3 inch
Effective Pixels 1.45 million pixels (1.5 million total)
Scanning Progressive scan
Color Filter RGB Bayer primary color filter

AE Lock Available
Exposure

Adjustment

Range: +/-2.0eV in 1/3eV stop

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

DP70 PC Specifications:

CPU Pentium III 450 MHz or more Pentium 4, 1.3GHz or more
Chip Set Intel 440BX AGP, Intel 815E Intel 845, Intel 845D, Intel 850
RAM SDRAM 512 MB or more

HDD Empty capacity of 200 MB or more Empty capacity of 200 MB or more
Graphic Card 16 MB or more 16 MB or more
PCI Bus PCI Rev. 2.1 PCI Rev. 2.1
OS Win 2000/XP/NT4.0 Win 2000/XP/NT4.0
PC Case Size Large enough to house a

Power Supply 250W or more 250W or more

IBM PC-AT compatible, Pentium IIIIBM PC-AT compatible, Pentium 4

PC100, PC133

352x126x29mm PCI board

Minimum Recommended

SDRAM 512 MB or more
PC100, PC266, PC600, PC800

Large enough to house a 352x126x29mm PCI board

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

DP12 Digital Camera Specifications

Imaging Sensor: 1/1.8 inch (~0.55") interlace scan CCD w/3.34 Mpixels (actual 3.24 Megap ixel)
Image Recording: Sensitivity: 25/50/100 ISO equivalent

Metering System: 1% spot, 30% average
Exposure Control: Automatic, Manual, AE lock
Exposure Time: Automatic 1/4000 sec.-1/2 sec., Manual 1/4000sec.- 8 sec.
Exposure Adjustment: +/-2EV (1/3 increments)
3 White Balance Modes: Full auto, one touch, manual
Recording Media: 3.3V SmartMedia Card* (SSFDC) *Not Included

Resolution:
SHQ (TIFF) 2048x1536 (Approx. 9.4MB)
SHQ (JPEG) 2048x1536 (Approx. 2.3MB)
HQ (JPEG) 1600x1200 (Approx 790KB)
SQ1 (JPEG) 1024x668 (Approx 580KB)
SQ2 (JPEG) 640x480 (Approx 230KB)

Image Display: 3.5 inch 200,000 pixel TFT color LCD Monitor

Live image display:
max. 30 frames/sec
Image magnifications 1X, 2X (electronic zoom)

Stored image display:
30 frames/sec
Image magnifications: 1/16X, 1/9X, 1/4X, 1X, 2X, and 4X

I/O: DC Input

Data Output: USB
Video Output: Composite (NTSC/PAL)
SSFDC slot (SmartMedia)

DP12 Features & Benefits:

• 3.34 Megapixel (2048 x 1536)
1/1.8" (~0.55") interlace scan
CCD.

• High-resolution, large, 3.5" tilting
200,000 pixel color LCD monitor
(now integrated into the separate
compact control unit) for easy,
accurate focusing and framing.
Allows display of 16 images at
once!

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

• Easy use of operation; the DP12 is operated entirely from the separate handset
control unit. Users can choose between 3 ISO ratings and automatic or manual
exposure modes ensuring acquisition of images with optimum quality.

• Easy image adjustment with 3 white balance selections, 1% spot metering, 30%
average metering, and ±1/3 stop exposure adjustment.

• New focusing indicator and 2X electronic zoom function for easy low magnification
focusing.

• Calibrated scale bar that can be superimposed horizontally or vertically on the
displayed image.

TM

• Single storage SmartMedia

slot for SmartMediaTM memory cards (up to 128MB).

• USB interface located on the separate handset control unit for optional connection to

a PC.

• Images can be acquired in color or
grayscale.

• Standard C-mount thread.

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

Hamamatsu Video & Digital Camera Specifications

Imaging device Interline Interline Interline Full frame Full frame
CCD ICX - 285 ER -150 ER -150 S7170 CCD47-10
Number of Pixels 1344 x1024 1344 x 1024 1344 x 1024 512 x 512 1024 x 1024

Pixel size
Noise 8 e- RMS 6 e- RMS 3 e- & 6 e- RMS 6 e- RMS 4 e- RMS
Full well capacity 18,000 e- 18,000 e-
Dynamic range 2,250:1 3,000:1 3,100:1 to 13,500:2 38,300:1 20,000:1

Digitizer(s) 12 bit 12 bit 12 & 14 bit 12 & 14/16 bit 12 & 14/16 bit
Peak QE 60% 70% 70% 90% 80%
Clock 14.75 MHz 14.75 MHz 10 M & 1.25 MHz 2.5 M & 156 KHz 5 M & 312.5 KHz

Frame rate 8.8 Hz 8.8 Hz 0.85 Hz & 1.25 MHz
Cooling temp. 5 degrees C -30 degrees C -60 degrees C -60 degrees C -60 degrees C

Dark current 0.8 e/p/s 0.03 e/p/s 0.0065 e/p/s 0.3 e/p/s 0.01 e/p/s
Hi/Low Light

mode
Mechanical

shutter
Shortest

exposure
Longest exposure 10 sec 4200 sec 2 hours or longer 2 hours or longer 2 hours or longer
Anti-blooming Yes Yes Yes No No
Digital output IEEE1394 IEEE1394 RS-422/IEEE1394 RS-422 RS-422

ORCA 285 ORCA-ER ORCAII-ER ORCAII-BT-512 ORCAII-BT-1024

6.45 x 6.45
um

No Yes Yes No No

No No No Required Required

10 us 10 us 30 us 20 ms 20 ms

6.45 x 6.45
um

6.45 x 6.45 um 24 x 24 um 13 x 13 um

18,500 e- & 40,500

e-

230,000 e- 80,000 e-

0.45 Hz & 156
KHz

0.21 Hz & 312
KHz

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

MicroFire™Camera Specifications

CCD Array 1600 x 1200 Pixels, 7.4 x 7.4 microns
Format: 14.8mm diagonal (2/3" format)
Hardware Interface: IEEE 1394 (FireWire™), 6 pin
Software Interface: MicroFire™ Proprietary, SDK Available
Binning Modes: 1X1 (1600 X 1200)

2X2 (800 X 600) Monochrome only
3X3 (512 X 400) Color only
4X4 (400 X 300) Monochrome only

Subframing modes: User-defined # of lines, in multiples of 2

Range: 100 lines - 1200 lines

Frame Rates (max): 10 FPS @ 1600 x 1200

18 FPS @ 800 x 600 (2x2 binning)
24 FPS @ 512 x 400 (3x3 binning)
30 FPS @ 400 x 300 (4x4 binning)
48 FPS @ 1600 X 100 (subframed mode)

Exposure Time Range: 500 microseconds - 60 seconds
Gain Range: 1x - 16x
Bit Depth: 36 Bit Color
Optical Interface: C-mount (1-32 thread), 17.5mm backfocus
Computer Recommendations: 1GHz or better PC,

Windows™ 98 SE/ME/2000/XP
1600 x 1200, 32-bit color video
512 MB RAM

Q-Color 3™ Specifications

Sensor Sony ICX252AQ – 8.933mm diagonal – 1” x 1.8” (1/2”) optical format

Resolution 2080 x 1542 active pixel resolution, 3.2 M active pixels
CCD Type Interlaced* , interline, Bayer color (R,G,B primary color mosaic filters

on chip)

Pixel Size 3.45 µ x 3.45 µ
Well capacity 8600 e¯
Readout noise 9.8 e¯
S/N ratio 58 dB
Dark current

(cooled)
Dark current

(uncooled)

Readout Speed**

8-Bit (default
setting)
2x2 binning
3x3 binning
4x4 binning

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

2.3 e¯/pixel/second
9 e¯/pixel/second

20 MHz in 8-bit, 10 MHz in 10-bit
Full resolution – 5.4 fps
Full frame readout time 210 ms (8bit) 420 ms (10-bit)

9.2 fps (8-bit) 4.1 fps (10-bit) in full color
12 fps (8-bit) 6 fps (10-bit) in full color
14 fps (8-bit) 7 fps (10-bit) in full color

ROI Region of Interest (up to 100 fps)

Exposure Times 1.6 ms to 17.9 minutes with 1 µ resolution
Cooling (optional) Approx. 10º C below ambient

Reduces dark current during long exposure times

Power Cooled – 560mA@12V=6.72W

Uncooled – 310mA@12V=3.72W
The Q-Color 3™ can only draw power through a FireWire™ port. An
auxiliary power supply cannot be hooked up directly to the Q-Color 3™.
A PCMCIA FireWire™ card with an auxiliary power supply is required to
run the Q-Color 3™ on a laptop.

Mounts Standard C-mount for microscopes or lens

Standard camera tripod mount 1 / 4” – 20

Q-Color 5™ Specifications

Sensor Sony ICX282AQ - 2/3" optical format

Resolution 2580 x 1944 active pixel resolution, 5.0 Megapixels
CCD Type Interlaced*, interline, Bayer color (R,G,B primary color mosaic filters

on chip)

Pixel Size 3.4 µ x 3.4 µ
Well capacity 8600 e¯
Readout noise 9.8 e¯
S/N ratio 58 dB
Dark current

(cooled)
Dark current

(uncooled)

Readout Speed**

8-Bit (default
setting)
2x2 binning
3x3 binning
4x4 binning
ROI

Exposure Times 1.6 ms to 17.9 minutes with 1 µ resolution
Cooling (optional) Approx. 10° C below ambient

Power Cooled – 560mA@12V=6.72W

Mounts Standard C-mount for microscopes or lens

2.3 e¯/pixel/second
9 e¯/pixel/second

20 MHz in 8-bit, 10 MHz in 10-bit
Full resolution – 3.5 fps
Full frame readout time 286 ms (8bit) 555 ms (10-bit)

5.9 fps (8-bit) 3.0 fps (10-bit) in full color

7.4 fps (8-bit) 3.75 fps (10-bit) in full color

8.9 fps (8-bit) 4.5 fps (10-bit) in full color
Region of Interest (up to 30 fps)

Reduces dark current during long exposure times

Uncooled – 310mA@12V=3.72W
The Q-Color 5™ can only draw power through a FireWire™ port. An
auxiliary power supply cannot be hooked up directly to the Q-Color 5™.
A PCMCIA FireWire™ card with an auxiliary power supply is required to
run the Q-Color 5™ on a laptop.

Standard camera tripod mount 1 / 4" - 20

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

MagnaFire™ SP Camera Specifications

Description: Megapixel color imaging camera system designed for scientific

microscope imaging applications

Physical Dimensions: 47mm high, 166mm wide, 166mm deep; weight: 1.5kg.
Operating Environment: Operating Temperature: +5°C to +35°C

Storage Temperature: -10°C to +60°C
Humidity: 0 - 80% relative non-condensing
Shock and Vibration: as per ISTA guidelines

Camera Power Supply: Power Supply Dimensions: 213mm long, 155mm wide, 64mm

tall; weight 1.7kg
Line Voltage: 100-240V~, 50/60Hz, 33VA; 250mA maximum
current
Fuse Type: 5 X 20mm, 400mA, SB, IEC 127

Regulatory Compliance: UL/CSA, CE laboratory rated.
Image Sensor: SONY ICX085 AK Color Interline Transfer CCD, 2/3 in., 1300 x

1030 x 6.7µ square pixels.

Image Size: 1280x1024 pixels.
Dynamic Range: 60dB
Signal to Noise Ratio: 60dB
Color Image Formation: Single pass exposure matrix color
File Bit Depth: 10bit, 16bit, user defined
Live Image Display Rate: 10 images/second, full field, full resolution
Computer Interface: IEEE 1394 FirewireTM, 400 megabits/sec.
Bright Field Image Capture

Time:
Dark Current: 4 electrons/pixel/sec. @ 0°C nominal.
Read Noise: 16 electrons/pixel.
Well Depth: 16,000 electrons.
Exposure Control: Full automatic, manual override.

Camera Shutter: Electronic, software controlled.
Optical Interface: Industry standard "C" mount (17.5mm backfocus). No relay

Camera Control and Display
Software:

Full field, full resolution color: < 2.0 sec.

0.00017 sec to 10+ minutes/color in normal mode.

0.00017 sec to 1 minute/color in Turbo mode.
Manual settings at 1/16 stop intervals.

lens optics required.
WindowsTM 98 (Second Edition), WindowsTM 2000

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

CC12 & FVII CAMERA SPECIFICATIONS

CC12:

• 1376 x 1032 x 6.45µm square pixel 2/3" CCD color imaging sensor

• PC interface: FireWire™ (IEEE 1394)

• High 36 (3 x 12) bit dynamic range

• Rapid image transfer rate

• Variable binning allows focusing of even the weakest signals

• High frame rate, up to 22 fps in binning mode

• Low noise; Peltier cooled to 10°C ambient

• Exposure times from 100µs to 160 seconds

• Real-time functions that make use of the entire dynamic range: automatic gain,

white balance, and live histogram display

• Ability to create multiple configurations that include all camera settings relevant to
image acquisition, binning, clipping, calibration, and pre- and post-processing macro
commands

FVII:

• 1376 x 1032 x 6.45µm square pixel 2/3" CCD monochrome imaging sensor

• PC interface: FireWire™(IEEE 1394)

• High 12 bit dynamic range

• Ideal for fluorescence

• Rapid image transfer rate

• Variable binning allows focusing of even the weakest signals

• High frame rate, up to 22 fps in binning mode

• Low noise; Peltier cooled to 10°C ambient

• Exposure times from 100µs to 160 seconds

• Real-time functions that make use of the entire dynamic range: automatic gain,

white balance, shading correction, and live histogram display

• Ability to create multiple configurations that include all camera settings relevant to
image acquisition, binning, clipping, calibration, and pre- and post-processing macro
commands

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]

applications that require merging multiple exposures

Color Video Camera Specifications

CCD Size 3-CCD

Lens Mount Sony

S/N

Ratio

Resolution

(TV lines)

Output RGB, Y/C,

RS-232

Control

Application Brightfield Brightfield Brightfield Brightfield,

DXC-990 DXC-390 DXC-190 OLY-750 ODEI75D

3-CCD

1/2"

Bayonet

63dB 62dB 50dB 62dB 60dB 50dB 56dB

1/3"

C-Mount C-Mount C-Mount C-Mount C-Mount C-Mount

1/2" 3-CCD

1/3"

850 800 470 750 750 480 570

RGB, Y/C,

Composite

Yes Yes No Yes Yes No No

Composite

Y/C,

Composite

RGB,

Composite,

S-Video

Fluorescence

Digital/Video

3-CCD

1/2"

RGB,

Composite,

S-Video

Brightfield,

Fluorescence

OLY-200 OLY-150IR

Infrared

1/3" 1/2"

Composite Composite

Brightfield Infrared

700nm-

950nm

Film Camera Specifications

Camera Type Manual Automatic Automatic Automatic

Film Types 35mm/Polaroid 35mm/Polaroid 35mm/Polaroid 35mm/Polaroid

Spot

Metering

Light Meter External Silicon

Reciprocity

Correction
Bracketing - - 3, 5, 7 frames 3, 5, 7

Exposure

Adjustment

Data

Imprinting

Fluorescence

Mode

PM10M PM10SP PM20 PM30

- 1% 1% 0.1% & 1%

Silicon

photodiode

- 3 settings 8 settings 8 settings

photodiode

N/A 0.25-4.00

N/A Optional Optional Built-in

(±2EV)

0.25-4.00
(±2EV)

- - Yes Yes: 2 types

CCD

frames

0.25-4.00
(±2EV)

DSP Technologies, Inc. Box 61737 Santa Barbara, CA 93160

Phone [phone] Fax [phone] email: [e-mail]
