OKI Metcal User Manual

Precision Systems for the Electronics Bench

SOLDERING, DESOLDERING AND REWORK SYSTEMS

SP440

SP440 Desoldering System

Since 1982, Metcal has been the industry’s single source of high-performance,

precision systems for the electronics bench. Always ahead of the competition,

Metcal’s soldering/desoldering stations, BGA/CSP/QFP rework equipment and

fume extraction systems continue to set the standard for reliability, flexibility

and cost-effective performance.

Recently, Frost & Sullivan awarded Metcal the prestigious "Market Engineering

Leadership Award," recognizing Metcal as the leader in the world SMT rework

and repair equipment market, in part through dominant market share, but also

because of our continuing "technology innovation."

By listening to customers, focusing on their specific needs and working as

their technology partner, we continue the quest for excellence, economy and

innovation – aimed at helping each customer meet increasingly complex

electronics manufacturing challenges.

Welcome to Metcal.

page

01

Contents

02

SmartHeat®Technology

04

MX-500 Soldering, Desoldering & Rework System

07

Soldering Tip Cartridges

20

SP440 Self-Contained Desoldering System

22

QX2 Convection Rework System

27

SMT-1160 Hot Air Pencil

18

SP200 Soldering System

10

Desoldering Tip Cartridges

11

Rework Tip Cartridges

14

Speciality Tip Cartridges

15

Microfine Rework Tip Cartridges

16

Accessories & Spare Parts

page

02

SmartHeat

®

SmartHeat

®

SmartHeat

®

Technology

What Is SmartHeat®?

Unlike conventional soldering irons, SmartHeat®administers heat directly from the heater to the

joint. Metcal tip cartridges detect the thermal load and instantly adjust the power in order to

deliver the right amount of heat precisely where it is needed. If the tip cools while transferring heat

to a joint, SmartHeat

®

immediately responds by safely increasing the power to maintain a constant

tip temperature. As a result, operators are relieved of the responsibility of regulating the tip

temperature, thus eliminating the risk of thermal damage to the component or to the PCB.

SmartHeat

®

soldering systems comprise three basic elements: a high frequency power supply, a tip

cartridge and a hand-piece. The cartridge contains the solder tip, a heater and the wire coil.

The Metcal Difference

In production environments where a single component can cost hundreds of dollars and rework and

repair can sometimes be more costly than the components involved, process control is vital. Metcal

improves product quality, increases productivity and reduces manufacturing costs with its patented

SmartHeat

®

technology. As SmartHeat®maintains a constant tip temperature, automatically

delivering the exact amount of power required for the task, consistent results are guaranteed and

component/PCB damage is virtually eliminated. Metcal’s SmartHeat

®

systems offer task-specific

versatility with no limits, no barriers and absolutely no compromise.

When the temperature of the heater (a copper bar coated with a magnetized iron/nickel alloy)

reaches a certain level (its Curie Point), it stops absorbing energy and the temperature becomes

SmartHeat

®

VARIABLE POWER HEATER

FIXED TEMPERATURE SOLDERING TIP

CONNECTOR

constant. Energy from the power supply feeds a steady current to the coil. This creates an electrical

field from which the heater absorbs energy, turns it into heat and transfers it to the iron/nickel

alloy. When soldering has drawn heat from the heater to the extent that the tip begins to cool, the

®

alloy reacts by taking on more energy in order to reheat the tip. In this way, SmartHeat

self-

regulates the tip temperature to within ±1.1ºC of a set point regardless of thermal load and

without any need for adjustment.

Trouble-Free Tip Replacement

The heat-resistant pad supplied with the unit

allows you to easily insert and remove the tip

cartridge. The simplicity of this process ensures

there is no loss of productivity, no need for

additional tools and no reason for two soldering

systems to be heating at the same time.

The SmartHeat®Route To Lead-Free Hand Soldering

Switching to lead-free hand soldering does not necessarily mean that you will have to invest in new

equipment or adjust your existing process. As SmartHeat’s variable power and fixed temperature

guarantee a repeatable tip temperature under a wide variety of thermal loads, the system can easily

adapt to meet the higher temperatures demanded by lead-free applications without any need for

modification.

No Calibration Required For Easy ISO 9000 Compliance

To define the parameters for soldering with a SmartHeat®system, simply record the tip cartridge

part number. As the heater’s alloy dictates the temperature, calibration is not required. Indeed,

there are no dials, buttons or calibration tools, typical of other systems, with which you can adjust

SmartHeat’s temperature. This avoids all risk of unauthorized operator intervention. Throughout the

page

03

cartridge’s lifetime, temperature drift is less than a few degrees. A letter to confirm SmartHeat’s

self-calibration capacity is available on request.

page

04

MX-500

MX-500

Soldering, Desoldering & Rework System

Industry Standard, Soldering, Desoldering And Rework System

Metcal’s MX-500 Soldering, Desoldering & Rework System is the benchmark against which other

soldering, desoldering and rework systems are measured. Flexible, fast and powerful, the MX-500

Soldering, Desoldering & Rework System raises bench-top conduction soldering to a new level of

process control, productivity and throughput.

Higher Throughput At Lower Temperatures

Unlike conventional soldering/rework systems that rely on stored energy, Metcal systems use SmartHeat

®

for direct power on demand. Despite its capacity to work at lower, safer temperatures, SmartHeat®still

delivers the fastest temperature recovery, joint-to-joint, in the industry.

Versatility Without Compromise

Metcal’s MX-500 Soldering, Desoldering & Rework System handles both SMT and through-hole

soldering/rework with one power supply at the bench. With two switchable outputs, the system can be

adapted to your exact needs, using two of the three tools available (soldering iron, Talon®tweezers,

desolder gun) to configure the most powerful bench-top soldering/rework system on the market. In

addition, the MX-500 Soldering, Desoldering & Rework System’s power supply has an automatic shut-

off, which helps maximize tip cartridge life, and a standard four year warranty.

page

05

MX-500

Unrivalled Comfort And Simplicity

The short tip-to-grip distance, characteristic of the Metcal hand-piece, improves process precision,

especially for fine-pitch applications. The easy-squeeze design of Metcal’s Talon®tweezers has been

ergonomically designed for superior performance, unmatched comfort and optimum control.

Part No. Description

MX-500S-11 Two Port 100/120 VAC, Solder System

MX-500S-21 Two Port 220/240 VAC, Solder System

INCLUDES

MX-500P Two Port Switchable Power Supply with Power Cord*

MX-RM3E Rework Hand-Piece with Cord

MX-WS4 Workstand

AC-YS3 Sponge

AC-CP2 Cartridge Removal Pad

MX-500TS-11 Two Port 100/120 VAC, Solder/Talon®System

MX-500TS-21 Two Port 220/240 VAC, Solder/Talon®System

INCLUDES

MX-500P Two Port Switchable Power Supply with Power Cord*

MX-TALON Talon®Hand-Piece with Cord

MX-WS5 Workstand

MX-RM3E Rework Hand-Piece with Cord

MX-WS4 Workstand

AC-YS3 Sponge (2)

AC-CP2 Cartridge Removal Pad (2)

MX-500S SMT SOLDERING/REWORK SYSTEM

MX-500TS SMT REWORK/TALON®SYSTEM

Tip cartridges sold separately from all systems. *220/240 VAC systems do not include power cords.

MX-TALON-01 Talon®Upgrade Kit

INCLUDES

MX-TALON Talon®Hand-Piece with Cord

MX-WS5 Workstand

AC-YS3 Sponge

AC-CP2 Cartridge Removal Pad

TALON®UPGRADE KITS

SM-TALON-02 Talon®Upgrade with Switchbox for Older STSS Systems

INCLUDES

MX-TALON Talon®Hand-Piece with Cord

MX-WS5 Workstand

AC-YS3 Sponge

AC-CP2 Cartridge Removal Pad

STSS-SW1E Switchbox with Storage Tray

page

06

MX-500

Pistol Grip SMT Desoldering/Rework System

The MX-500DS Desoldering/Rework System converts shop air into a powerful Venturi vacuum to clean

through-holes quickly and efficiently. Paper solder collection liners within the hand-piece barrel are easy

to maintain and are an improvement upon traditional glass tubes.

Please note: The MX-500DS Desoldering/Rework System requires shop air for desoldering. If shop air is not

available, Metcal recommends the SP440 Self-Contained Desoldering System.

Tip cartridges sold separately from all systems. *220/240 VAC systems do not include power cords.

.10"

.39"

9.9mm

2.5mm

.39"

.07"

9.9mm

1.78mm

.06"

.39"

1.5mm

9.9mm

.36"

.04"

1.0mm

9.1mm

.33"

.016"

8.4mm

0.4mm

.54"

0.4mm

.016"

13.7mm
.63"

.016"

16.0mm

0.4mm

.58"

.016"

14.7mm

0.4mm

MX-D001 Desolder Upgrade Kit

INCLUDES

MX-DS1 Desoldering Hand-Piece

MX-RM8E Desoldering Cord

MX-DAH4 ESD Air Hose with Fitting

MX-WS5 Workstand

MX-YS3 Sponge

MX-CP2 Cartridge Removal Pad

AC-CB1 Cleaning Brush

AC-CB2 Tube Cleaning Brush

MX-DCF1 Chamber Liner and Filter Pack

AC-TC Desoldering Tip Cleaner

DESOLDER UPGRADE KIT

Part No. Description

MX-500DS-11 Tw o Port 100/120 VAC, Desolder/Solder System

MX-500DS-21 Tw o Port 220/240 VAC, Desolder/Solder System

INCLUDES

MX-500P Two Port Switchable Power Supply with Power Cord*

MX-DS1 Desoldering Hand-Piece

MX-RM3E Rework Hand-Piece with Cord

MX-RM8E Desoldering Cord

MX-DAH4 ESD Air Hose with Fitting

MX-WS5 Workstand

AC-YS3 (x2) Sponge (2)

AC-CP2 (x2) Cartridge Removal Pad (2)

AC-CB1 Cleaning Brush

AC-CB2 Tube Cleaning Brush

MX-DCF1 Chamber Liner and Filter Pack

AC-TC Desoldering Tip Cleaner

MX-500DS SMT DESOLDERING/REWORK SYSTEM

MX-500

Soldering, Desoldering & Rework System

page

07

MX Tips

STTC

Soldering Tip Cartridges

FREQUENTLY USED TIP CARTRIDGES

.10"

.39"

9.9mm

2.5mm

STTC-X36* Chisel 30° .10” (2.5mm)

For medium to heavy load joints requiring extra reach.

STTC soldering tip cartridges are for use with the MX and the STSS soldering/rework hand-pieces only.

They cannot be used with the SP systems, the Talon

®

or desoldering hand-pieces.

.39"

.07"

9.9mm

1.78mm

STTC-X37* Chisel 30° .07”(1.78mm)

For a wide variety of tasks. If you are choosing the first tip for your
Metcal system, the STTC-037 is ideal.

.06"

.39"

1.5mm

9.9mm

STTC-X38* Chisel 30° .06” (1.5mm)

A finer version of the STTC-037. Ideal for medium to light through­hole and general surface mount touch-up.

.36"

.04"

1.0mm

9.1mm

STTC-X25 Chisel 30° .04” (1.0mm)

Good for a variety of light soldering tasks. Looking for a surface
mount touch-up tip? The STTC-025 should be your first choice.

.33"

.016"

8.4mm

0.4mm

STTC-X07 Conical Sharp .04” (1.0mm)

General-purpose SMT and through-hole tip when access is limited.

.54"

0.4mm

.016"

13.7mm

STTC-X22 Conical Sharp .016” (0.4mm)

Sharp tip cartridges for soldering SMT components or fine wire
applications (not for general through-hole tasks).

.63"

.016"

16.0mm

0.4mm

STTC-X06 Conical Sharp .016” (0.4mm)

For limited access SMT rework.

.58"

.016"

14.7mm

0.4mm

STTC-X40 Sharp Bent 30° .016” (0.4mm)

Tip for soldering SMT components. The bend makes it much
easier to work on small circuits and PLCCs.

STTC-X45 Bevel 60° .016” (0.4mm)

An extended length fine tip for surface mount or fine wire
applications (not for general through-hole tasks).

500 SERIES X =5 600 SERIES X=0 700 SERIES X=1 800 SERIES X=8, WHEN FOLLOWED BY AN *

.04"

1.0mm

.66"

16.7mm

page

08

MX Tips

OTHER STANDARD TIP CARTRIDGES

.45"

.19"

.08"

4.83mm

2.0mm

.03"
.76mm

11.43mm

.07"

.45"

.19"

.09"

2.3mm

4.8mm

1.8mm

11.43mm

.19"

.45"

.08"

2.0mm

4.8mm

11.43mm

.50"

.33"

.25"

.08"

8.4mm

6.4mm

2.0mm

12.7mm

.19"

.12"

3.0mm

4.8mm

.30"

.20"

5.0mm

7.6mm

.10"

.39"

9.9mm

2.5mm

.39"

.07"

9.9mm

1.78mm

.36"

.04"

1.0mm

9.1mm

.06"

.39"

1.5mm

9.9mm

STTC-X17*

Extra Large Chisel
.20” (5.0mm)

STTC-X65

Large Chisel
.20” (5.0mm)

STTC-X20

Long Reach
Chisel 12°
.15” (3.8mm)

STTC-X03*

Chisel 90°
.12” (3.0mm)

STTC-X13

Chisel 90º
.12” (3.0mm)

STTC-X33

Chisel 90°
.10” (2.5mm)

STTC-X04

Chisel 90°
.07” (1.78mm)

STTC-X42

Long Reach Chisel 60°
.07” (1.78mm)

STTC-X98

Chisel Bent 30º
.07” (1.78mm)

STTC-X99

Chisel Bent 30°
.06” (1.5mm)

STTC-X41

Chisel 30°
.05” (1.3mm)

STTC-X83

Conical Grooved
.08” (2.0mm)

STTC-X32

Conical Sharp
.07” (1.78mm)

.30"

.20"

5.0mm

7.6mm

.45"

.20"

5.0mm

11.4mm

.15"

.85"

3.8mm

21.6mm

.34"

.12"

8.6mm

3.0mm

.19"

.12"

3.0mm

4.8mm

.39"

.10"

2.5mm

9.9mm

.43"

.07"

10.9mm

1.78mm

.07"

.63"

1.78mm

16.0mm
.39"

.07"

1.78mm

9.9mm

.47"

.06"

1.5mm

11.9mm

21.8mm

.05"

.86"

1.3mm

.08"

.70"

17.8mm

2.0mm

1.78mm

.39"

.07"

9.9mm

STTC-X02

Conical Sharp
.07” (1.78mm)

STTC-X01

Conical Sharp
.04” (1.0mm)

STTC-X31

Conical Sharp
.04” (1.0mm)

STTC-X43

Conical Sharp
.02” (0.5mm)

STTC-X12

Conical
.08” (2.03mm)

STTC-X11

Conical
.02” (0.5mm)

STTC-X16

Conical
.02” (0.5mm)

STTC-X44

Sharp Bent 30º
.02” (0.5mm)

STTC-X26

Sharp Bent 30°
.016” (0.4mm)

STTC-X14

Bevel 45º
.08” (2.03mm)

STTC-X35

Bevel 30°
.07” (1.78mm)

STTC-X47

Bevel 60°
.07” (1.78mm)

STTC-X05

Bevel 30°
.07” (1.78mm)

.48"

.07"

12.2mm

1.78mm

.04"

.53"

13.5mm

1.0mm

.39"

.04"

1.0mm

9.9mm

.02"

.60"

0.5mm

15.2mm

.08"

.17"

4.3mm

2.03mm

.18"

0.5mm

.02"

4.6mm

.02"

.19"

0.5mm

4.8mm

.57"

.02"

14.5mm

0.5mm

.016"

7.9mm

.31"

0.4mm

.19"

.08"

4.7mm

2.03mm

.07"

9.9mm

30°

.39"

1.78mm

.07"

14.2mm

60°

1.78mm
.56"

.46"

.07"

30°

1.78mm

11.7mm

.17"

.05"

30°

1.3mm

4.3mm

9.1mm

.04"

30°

.36"

1.0mm

.04"

.56"

.02"

60°

1.0mm

.51mm

14.2mm

.14"

.19"

.21"

5.3mm

4.8mm

3.6mm

.02"

.19"

0.5mm

4.8mm

page

09

MX Tips

500 SERIES X =5 600 SERIES X=0 700 SERIES X=1 800 SERIES X=8, WHEN FOLLOWED BY AN *

PTTB-501

Bonding Tip

PTTB-504

Bonding Tip

PTTB-502

Bonding Tip

PTTB-503

Bonding Tip

PTTB BONDING TIP CARTRIDGES

OTHER STANDARD TIP CARTRIDGES

SRTC ROBOTIC TIP CARTRIDGES

For use with robotic applications and MX-RM5E or MX-RM8E handles only. Similar to STTC tip cartridges,

however, STRC Robotic Tip Cartridges have a shaft length of 3.15” (80mm) and, therefore, are not

compatible with the MX-RM3E handle.

For use in low temperature plastic bonding applications, these aluminum tips can be used with all

available MX handles.

.45"

.19"

.08"

4.83mm

2.0mm

.03"
.76mm

11.43mm

.07"

.45"

.19"

.09"

2.3mm

4.8mm

1.8mm

11.43mm

.19"

.45"

.08"

2.0mm

4.8mm

11.43mm

.50"

.33"

.25"

.08"

8.4mm

6.4mm

2.0mm

12.7mm

SRTC-X13

Chisel 90º
.12” (3.0mm)

SRTC-X37

Chisel 30º
.07” (1.78mm)

SRTC-X17*

Extra Large Chisel
.20” (5.0mm)

SRTC-X36

Chisel 30º
.10” (2.5mm)

.19"

.12"

3.0mm

4.8mm

.30"

.20"

5.0mm

7.6mm

.10"

.39"

9.9mm

2.5mm

.39"

.07"

9.9mm

1.78mm

SRTC-X38

Chisel 30º
.06” (1.5mm)

SRTC-X25

Chisel 30º
.04” (1.0mm)

.36"

.04"

1.0mm

9.1mm

.06"

.39"

1.5mm

9.9mm

600 SERIES X =0 700 SERIES X=7 800 SERIES X=8, WHEN FOLLOWED BY AN *

STTC-X15

Bevel 30°
.05” (1.3mm)

STTC-X24

Bevel 30°
.04” (1.0mm)

STTC-X97

Groved Semi-Rigid
Coax

STTC-X46

Long Reach
Bevel 60º

.04” (1.0mm)

STTC-X70

Heat Staking
.19” (4.8mm)

.17"

.05"

30°

1.3mm

4.3mm

9.1mm

.04"

30°

.36"

1.0mm

.04"

.56"

.02"

60°

1.0mm

.51mm

14.2mm

.14"

.19"

.21"

5.3mm

4.8mm

3.6mm

.02"

.19"

0.5mm

4.8mm

page

10

MX Tips

STDC

Desoldering System Tip Cartridges

STANDARD TIP CARTRIDGES

Par t No. A B

STDC-X 02 .025 (0.64) .055 (1.40)

STDC-X 03 .030 (0.76) .066 (1.68)

STDC-X 04 .040 (1.02) .070 (1.78)

STDC-X 05 .050 (1.27) .080 (2.03)

STDC-X 06 .060 (1.52) .090 (2.29)

STDC-X 07 .095 (2.41) .125 (3.18)

0.400"

Standard

Long Reach

LONG REACH TIP CARTRIDGES

Par t No . A B

STDC-X 03L .030 (0.76) .066 (1.68)

STDC-X 04L .040 (1.02) .070 (1.79)

STDC-X 05L .050 (1.27) .080 (2.03)

TATC

Talon®Tip Cartridges

Part No. Description

TATC -X01 Fine Point Tip .20” (5.08mm)

TATC -X02 Blades Tip .25” (6.35mm)

TATC -X03 Blades Tip .62” (5.75mm)

TATC -X04 Blades Tip .81” (20.57mm)

TATC -X05 TSOP 32 Tip

TATC -X06 Blades Tip 1.1” (27.94mm)

TATC -X08 Angled Viper Tip .05” (1.27mm)

500 SERIES X =5 600 SERIES X=6

Designed for the removal of all discrete and SO symmetrical components. TATC tip cartridges for

Talo n

®

hand-pieces are always sold in pairs. Due to its shape and design, by simply rotating the

Talo n

®

, a single TATC cartridge can remove a 28 pin SOIC, a tantalum or an 0603 chip capacitor

without changing tips. Metcal’s new Viper Tip is shown in the main photograph below.

Depending on available access, choose one of two desoldering tip cartridge configurations:

standard STDC or long reach STDC. Like all Metcal tip cartridges, STDC changeover takes just a few

seconds. When desoldering through-hole components, on thermally demanding PCBs, always use

the correct geometry for the task. This may mean choosing an 800 series (high temperature) tip.

600 SERIES X =0 700 SERIES X=1 800 SERIES X=8

700 SERIES X =7 800 SERIES X=8

DIAMETERS IN INCHES (mm)

B

A

page

11

MX Tips

SLOT TIP CARTRIDGES

DIMENSIONS IN INCHES (mm)

SMT TYPE A B D Part No.

Chip 0805 .090 (2.29) .050 (1.27) .070 (1.79) SMTC-X 01

Chip 1206, 1210 .140 (3.56) .060 (1.52) .070 (1.79) SMTC-X 02

Chip 1808, 1812 .190 (4.83) .080 (2.03) .075 (1.91) SMTC-X 03

Chip, Box A (EIA SOPM-3224) .135 (3.43) .080 (2.03) .120 (3.05) SMTC-X 35

Chip, Box B (EIA SOPM-3528) .150 (3.81) .095 (2.41) .100 (2.54) SMTC-X32

Melf, Box B (EIA SOPM-4532) .190 (4.83) .110 (2.79) .160 (4.06) SMTC-X36

Chip, Box C (EIA SOPM-6032) .250 (6.35) .095 (2.41) .130 (3.30) SMTC-X 33*

Chip, Box D (EIA SOPM-7246) .300 (7.62) .100 (2.54) .140 (3.56) SMTC-X 34*

SOT-23 .068 (1.73) .100 (2.54) .050 (1.27) SMTC-X 05

SOT-89 .110 (2.80) .250 (6.35) .080 (2.03) SMTC-X 08

Chip 0402, 0603, 0805 (angled) .080 (2.03) .050 (1.27) .060 (1.52) SMTC-X88

Chip 0402, 0603 .070 (1.78) .040 (1.02) .040 (1.02) SMTC-X96

500 SERIES X =5 600 SERIES X=0 700 SERIES X=1 *=NOT AVAILABLE FOR 500 SERIES

SMTC

SMT Rework Tip Cartridges

Designed for reworking SMT components, SMTC tip cartridges do it all – assembly, removal and

cleaning. The SMTC range includes slot, tunnel and quad tip cartridges. The SMTC range also

includes hoof tips for drag soldering, blade tips to remove residual solder from pads, and knife tips

for multi-lead soldering of PLCCs in tight places.

Please note: SMTC soldering tip cartridges are for use with the MX-RM3E soldering/rework hand-

pieces for STSS/MX systems only. They cannot be used with SP systems, Talon

®

hand-pieces or

desolder hand-pieces.

B

D

A

page

12

MX Tips

TUNNEL TIP CARTRIDGES FOR DUAL IN-LINE PACKAGES

DIMENSIONS IN INCHES (mm)

SMT TYPE A2 A B D Part No.

DPAC .335 (8.51) .335 (8.51) .250 (6.35) .200 (5.08) SMTC-X47

SO-8 .320 (8.13) .380 (9.65) .750 (19.05) .240 (6.10) SMTC-X107

SO-16 .330 (8.38) .330 (8.38) .475 (12.07) .230 (5.84) SMTC-X46*

SO-8 .335 (8.51) .335 (8.51) .665 (16.90) .250 (6.35) SMTC-X68**

SOIC-8 .200 (5.08) .200 (5.08 .170 (4.32) .090 (2.29) SMTC-X04

SOIC-14,-16 .200 (5.08) .200 (5.08) .400 (10.16) .090 (2.29) SMTC-X06

SOIC-14 .204 (5.18) .204 (5.18) .350 (8.89) .100 (2.54) SMTC-X142

SOIC-24 (Mini flat pack) .280 (7.11) .280 (7.11) .620 (15.75) .125 (3.18) SMTC-X77

SOIC-16 (Wide) .320 (8.13) .320 (8.13) .470 (11.94) .270 (6.86) SMTC-X124

SOIC-20 .375 (9.53) .375 (9.53) .520 (13.21) .125 (3.18) SMTC-X10

SOIC-24 .375 (9.53) .375 (9.53) .620 (15.75) .125 (3.18) SMTC-X09

SOIC-28, SOL-34 .375 (9.53) .375 (9.53) .720 (18.29) .125 (3.18) SMTC-X07

SOIC-32 .520 (13.21) .520 (13.21) .805 (20.45) .170 (4.32) SMTC-X 42

SOJ-28, SOM-36 .315 (8.00) .340 (8.64) .740 (18.80) .074 (1.88) SMTC-X26

SOJ-32, 34 .315 (8.00) .340 (8.64) .840 (21.34) .125 (3.18) SMTC-X140

SOJ-40, SOM-32 .410 (10.41) .450 (11.43) 1.020 (25.91) .075 (1.91) SMTC-X 40

SOJ-42 .410 (10.41) .450 (11.43) 1.070 (27.18) .125 (3.18) SMTC-X 148

SOMC-14,-16, DB-20 .270 (6.86) .270 (6.86) .440 (11.18) .090 (2.29) SMTC-X20

SOP-20 .270 (6.86) .270 (6.86) .285 (7.24) .100 (2.54) SMTC-X138

SOP-28 .420 (10.67) .420 (10.67) .720 (18.29) .125 (3.18) SMTC-X 39

SOP-40 .460 (11.68) .510 (12.95) 1.000 (25.4) .125 (3.18) SMTC-X134*

SOP-44 .510 (12.95) .565 (14.35) 1.070 (27.18) .105 (2.67) SMTC-X 83

TSOP-28 .470 (11.94) .505 (12.83) .320 (8.13) .065 (1.65) SMTC-X 95

TSOP-40 .730 (18.54) .760 (19.30) .400 (10.16) .120 (3.05) SMTC-X 154

TSOP-56 .730 (18.54) .760 (19.30) .556 (14.12) .120 (3.05) SMTC-X 162

TSOP-32 .730 (18.54) .760 (19.30) .320 (8.13) .120 (3.05) SMTC-X84**

600 SERIES X =0 700 SERIES X=1 *=NOT AVAILABLE FOR 600 SERIES

**=NOT AVAILABLE FOR 700 SERIES

QUAD TIP CARTRIDGES FOR PLCC

SMT TYPE A2 A B2 B D Part No.

PLCC 18 .300 (7.62) .330 (8.38) .500 (12.70) .530 (13.46) .150 (3.81) SMTC-X 11

PLCC 20 .360 (9.14) .400 (10.16) .360 (9.14) .400 (10.16) .150 (3.81) SMTC-X 12

PLCC 28 .370 (9.40) .410 (10.41) .570 (14.48) .610 (15.49) .150 (3.81) SMTC-X 103

PLCC 32 .450 (11.43) .500 (12.70) .550 (13.97) .600 (15.24) .150 (3.81) SMTC-X16

PLCC 28 .455 (11.56) .500 (12.70) .455 (11.58) .500 (12.70) .150 (3.81) SMTC-X13

PLCC 44 .660 (16.76) .700 (17.78) .660 (16.76) .700 (17.78) .150 (3.81) SMTC-X14

PLCC 68 .960 (24.38) .995 (25.27) .960 (24.38) .995 (25.27) .220 (5.59) SMTC-X 18*

PLCC 68 dual• .960 (24.38) .995 (25.27) .960 (24.38) .995 (25.27) .220 (5.59) SMTC-X 28

PLCC 84 dual• 1.165 (29.59) 1.195 (30.35) 1.165 (29.59) 1.195 (30.35) .220 (5.59) SMTC-X29

PLCC 52 .760 (19.30) .800 (20.32) .760 (19.30) .800 (20.32) .150 (3.81) SMTC-X17*

PLCC 84 1.165 (29.59) 1.195 (30.35) 1.165 (29.59) 1.195 (30.35) .220 (5.59) SMTC-X 19*

Please note: •Dual tip cartridges require two power supply units and two hand-pieces. A Dual Hand-Piece

Support (MX-DHS) is also recommended.

600 SERIES X =0 700 SERIES X=1 FOR ALL QUADS USE 700 SERIES TIP CARTRIDGES

* =NOT AVAILABLE FOR 600 SERIES

B

A2

A

D

B

B2

AA2

D

page

13

QUAD TIP CARTRIDGES FOR QFP

DIMENSIONS IN INCHES (mm)

SMT TYPE A2 A B B2 D Part No.

SQFP 48 (EIAJ) .330 (8.38) .330 (8.38) .330 (8.38) .330 (8.38) .100 (2.54) SMTC-X121

SQFP 64 (EIAJ) .440 (11.18) .440 (11.18) .440 (11.18) .440 (11.18) .100 (2.54) SMTC-X120

TQFP 44 .440 (11.18) .480 (12.19) .480 (12.19) .520 (13.21) .110 (2.79) SMTC-X 159

TQFP 80 .485 (12.32) .525 (13.34) .485 (12.32) .525 (13.34) .110 (2.79) SMTC-X132

QFP 48 .550 (13.97) .550 (13.97) .550 (13.97) .550 (13.97) .130 (3.30) SMTC-X 115

VQFP 100 (EIAJ) .570 (14.48) .610 (15.49) .570 (14.48) .610 (15.49) .110 (2.79) SMTC-X118

QFP 128 (3.2 mm fp) .620 (15.75) .620 (15.75) .860 (21.84) .860 (21.84) .130 (3.30) SMTC-X 133

QFP 44 .635 (16.13) .635 (16.13) .635 (16.13) .635 (16.13) .130 (3.30) SMTC-X 21

QFP 100 (rectangular) .650 (16.51) .650 (16.51) .885 (22.48) .885 (22.48) .130 (3.30) SMTC-X 43

QFP 64, 80 .675 (17.15) .675 (17.15) .910 (23.11) .910 (23.11) .130 (3.30) SMTC-X15

QFP 100 .805 (20.45) .805 (20.45) .805 (20.45) .805 (20.45) .190 (4.83) SMTC-X 45*

QFP 144 .805 (20.45) .840 (21.34) .805 (20.45) .840 (21.34) .075 (1.91) SMTC-X 122

QFP 132 .985 (25.02) 1.020 (25.91) .985 (25.02) 1.020 (25.91) .125 (3.18) SMTC-X 86

QFP 100 (square) 1.040 (26.42) 1.040 (26.42) 1.040 (26.42) 1.040 (26.42) .130 (3.30) SMTC-X 44*

QFP 208 DUAL• 1.125 (28.58) 1.770 (44.96) 1.125 (28.58) 1.170 (44.96) .114 (2.90) SMTC-X 81

QFP 120,160 DUAL• 1.165 (29.59) 1.200 (30.48) 1.165 (29.59) 1.200 (30.48) .120 (3.05) SMTC-X48

PQFP 240 DUAL• 1.290 (32.77) 1.330 (33.78) 1.290 (32.77) 1.330 (33.78) .110 (2.79) SMTC-X125

QFP 304 DUAL• 1.600 (40.64) 1.650 (41.91) 1.650 (41.91) 1.600 (40.64) .200 (5.08) SMTC-X158**

B

Please Note: •Dual tip cartridges require two power supply units and two hand-pieces. A Dual Hand-Piece

Support (MX-DHS) is also recommended.

600 SERIES X =0 700 SERIES X=1 FOR ALL QUADS USE 700 SERIES TIP CARTRIDGES

*= NOT RECOMMENDED FOR 600 SERIES **= NOT AVAILABLE FOR 600 SERIES

MX Tips

SOCKET TIP CARTRIDGES (TIP INSIDE SOCKET)

Recommended

SMD COMPONENT A B D Part No. Part No.

PLCC-20 SOCKET .360 (9.14) .360 (9.14) .115 (2.91) SMTC-X144 SMTC-1144

PLCC-32 SOCKET .456 (11.58) .556 (14.12) .120 (3.05) SMTC-X109 SMTC-1109

PLCC-84 SOCKET DUAL• 1.160 (40.64) 1.160 (40.64) .115 (2.91) SMTC-X145 SMTC-1145

Please Note: •Dual tip cartridges require two power supply units and two hand-pieces. A Dual Hand-Piece

Support (MX-DHS) is also recommended.

600 SERIES X =0 700 SERIES X=1 FOR ALL QUADS USE 700 SERIES TIP CARTRIDGES

B2

D

AA2

B

A

D

page

14

MX Tips

SMTC-X60

Blade

0.410” (10.41mm)
Long

SMTC-X61

Blade

0.620” (15.75mm)
Long

SMTC-X62

Blade

0.870” (22.10mm)

Long

SMTC-X110**

Blade
Dual Heater Quad

1.55”

(39.37mm)

Speciality

Speciality Tip Cartridges

30°

0.65"

16.51mm

.03"
.76mm

30°

.60"

15.24mm

.02"
.51mm

60°

.65"

16.51mm

.045"

1.14mm

60°

.45"

11.43mm

.035"
.89mm

.52"

13.2mm

.01"

.25mm

BLADE TIP CARTRIDGES

HOOF AND KNIFE TIP CARTRIDGES FOR DRAG SOLDERING

500 SERIES X =5 600 SERIES X=0 700 SERIES X=1 800 SERIES X=8

* =NOT AVAILABLE FOR 800 SERIES **=NOT AVAILABLE FOR 500 OR 800 SERIES

500 SERIES X =5 600 SERIES X=0 700 SERIES X=1 800 SERIES X=8

**=NOT AVAILABLE FOR 500 OR 800 SERIES

SMTC-X147*

Hoof

SMTC-X167**

Mini-Hoof

SMTC-X169*

Long Reach Hoof

.13"

.70"

60°

3.3mm

17.78mm

.08"

60°

.60"

15.24mm

2.03mm

.19"

.08"

.65"

45°

4.83mm

16.51mm

2.03mm

.06"

30°

.65"

16.51mm

1.52mm

.12"

60°

.60"

15.24mm

3.05mm

.23"

45°

.65"

.19"

16.51mm

5.84mm

4.83mm

.19"

.13"

1.18"

4.83mm

29.97mm

3.3mm

.03"

.08"

.76mm

2.03mm

.09"

.19"

.19"

.14"

4.83mm

4.83mm

3.56mm

2.89mm

.425" sq.

.08"

10.80mm sq.

2.03mm

SMTC-X170*

Long Reach Hoof

SMTC-X161*

Knife
(Tinned Area, .08”

2.03mm)

SMTC-X173

Knife
(Increased Tinned Area,
.23” 5.84mm)

page

15

MX-Tips

500 SERIES X =5 600 SERIES X=0 700 SERIES X=1 800 SERIES X=8

**=NOT AVAILABLE FOR 500 OR 800 SERIES

SMTC-X136**

Hot Plate
.425” sq. (10.8mm sq.)

Microfine

Microfine Rework Tip Cartridges

30°

0.65"

16.51mm

.03"
.76mm

SMTC-X171

Use to remove 0201 and 0402 components from a "topside" angle.
This design increases microscope viewing when reworking/removing
micro chip capacitors/components.

30°

.60"

15.24mm

.02"
.51mm

SMTC-X172

Designed for fine drag soldering and point-to-point soldering. This
tip increases access between components and allows for lead to lead
or solder bridge clean-up.

60°

.65"

16.51mm

.045"

1.14mm

SMTC-X174

Long reach micro hoof tip designed with a smaller surface area than
the mini-hoof for optimal drag soldering of components in tight
spots.

60°

.45"

11.43mm

.035"
.89mm

SMTC-X175

Micro-hoof tip designed with a smaller surface area than the mini­hoof for drag soldering of small/micro leaded components.

.52"

13.2mm

.01"

.25mm

STTC-X90

Microfine tip designed for soldering and touch-up of micro
components such as 0201s and 0402s.

OTHER SPECIALITY TIP CARTRIDGES

The Microfine rework tip cartridge series is designed for reworking 0201 and 0402 or microfine

components in tight spaces with the help of a microscope. This series includes tips that can be used

to remove 0402 and 0201 components from the topside approach or can also be used for multi-lead

drag soldering on micro PLCC and QFP components with access problems. Depending on your

application, one of these tips will meet your micro component rework needs.

SMTC-X98**

SMT Connector
28 Pin

SMTC-X100

Micro XMT
Small Package
Co-Axial Tip

.19"

.13"

1.18"

4.83mm

29.97mm

3.3mm

.03"

.08"

.76mm

2.03mm

.09"

.19"

.19"

.14"

4.83mm

4.83mm

3.56mm

2.89mm

.425" sq.

.08"

10.80mm sq.

2.03mm

500 SERIES X =5 600 SERIES X=0 700 SERIES X=1 800 SERIES X=8

page

16

MX-500

MX-500

Accessories & Spare Parts

Part No. Description

A MX-RM3E ESD Solder Handle W/CP2 for MX-500 Systems

B MX-RM6E ESD Long Reach Solder Handle W/CP2 for MX-500

C MX-TALON Talon® Hand-Piece with Cord

D MX-DS1 Desolder Hand-Piece

E MX-RM8E DS1 Desolder Cord

F MX-DAH4 ESD Air Hose, U.S standard fitting

MX-RM5E Standard Robotic Cable, 1-piece, 6’ (1.83m)**

A

B

C

D

E

F

G MX-WS5 DS1/Talon®Workstand with YS3 Sponge

H MX-WS4 MX Workstand with YS3 Sponge

I MX-WSC5 Talon®Cradle

J MX-WSC4 MX-RM3E / 6E Cradle

AC-YS1-P WS1 Sponge (1.7” x 2.7” x 1.0”) (Pack of 50)**

AC-YS3-P MX, SP & DP Workstand Sponge (Pack of 50)**

G

H

I

J

K

L

M

N

P

O

K AC-TSTAND Tip Stand

L AC-CP2 Cartridge Removal Pad

M AC-BRUSH-P Soft Brass Brush Cleaner (Pack of 6)

N MX-DHS Dual Handle Support (use with dual heater SMTCs)

O STSS-TEMPLATE SMTC Tip Selection Template

P AC-TCASE Tip Case for STTC/SSC (holds 10 tips)*

MX-FX2 Fume Extraction Tube and Clamp**

* Tips not included ** Not shown

HAND-PIECES AND CORDS

WORKSTAND ITEMS

MISCELLANEOUS ACCESSORIES

page

17

MX-500

MX-DMK1 DS1 Maintenance Kit

INCLUDES

Z Long Phillips Screws (Pack of 2)***

AA Short Phillips Screws (Pack of 4)***

BB MX-DSB Desolder Gun Swivel Bushing

CC Hex Screws (Pack of 2)***

DD MX-DLA Desolder Gun Latch Adjustment (Pack of 10)

EE Large Springs (Pack of 2)***

FF Nylon Screws (Pack of 2)***

GG MX-DSL2 DS1 Cartridge Seal (Pack of 2)

HH Hinge Pins (Pack of 4)***

II O-Rings (Pack of 2)***

JJ MX-DSL1 DS1 Chamber Seal (Pack of 2)

KK Small Springs (Pack of 6)***

MX-DUC DS1 Upper Chamber (Type II Desolder Tool only)**

Q

Q MX-DCF1 DS1 Filter Pack: 15 chamber liners, 6 fume filters

MX-DCF1L DS1 Chamber Liners (Pack of 40)**

MX-DCF1F DS1 Fume Filters (Pack of 20)**

R MX-DAR1 Air Regulator and Filter with Fittings

S AC-TC-P Desolder Tip Cleaner (Pack of 12)

T AC-CB1-P Desolder Chamber Cleaning Brush (Pack of 25)

U AC-CB2-P Desolder Tube Cleaning Brush (Pack of 6)

V MX-DVC1 Venturi Cartridge for Desolder Gun

W MX-DSL1 DS1 Chamber Seal

X MX-DSL2 DS1 Cartridge Seal

Y MX-DSB Desolder Gun Swivel Bushing

R

S

T

U

V

W

X

Y

POWER SUPPLY AND POWER METER

MX-500P-11 Two Port 100/120 VAC Power Supply

MX-500P-21 Two Port 220/240 VAC Power Supply*

MX-NPM Net Power Meter

Z

AA

BB

CC

DD

EE

FF

JJ

GG

HH

KK

II

** Not shown *** Not sold separately

DESOLDERING ACCESSORIES

DESOLDERING MAINTENANCE KIT

OTHER SYSTEM COMPONENTS

*220/240 VAC Power Supply does not include power cord.

page

18

SP200

SP200

Economical Soldering System Cuts Costs, Not Corners

The SP200 Soldering System is the most cost-effective and easiest to use compact soldering system

available today.

For flawless soldering, technicians need only select the correct tip cartridge, insert it into the hand-

piece and switch on. As the unit works at a lower temperature than a conventional iron and requires

no calibration, operators always apply the correct level of thermal energy needed to produce solder

joints of the highest quality without risking component or PCB damage.

In addition, the system’s design is extremely reliable, with very few parts that ever need repairing,

ensuring that the SP200 Soldering System is practically maintenance-free.

Metcal’s SP200 Soldering System, for through-hole soldering and SMT touch-up, is designed to

perfectly complement our MX-500 Soldering, Desoldering & Rework System.

SP200 Soldering System

Part No. Description

SP200-11 115 VAC Soldering System

SP200-21 220/240 VAC Soldering System*

*220/240 VAC system does not include power cords

ACCESSORIES & SPARE PARTS

SP-PW1-10 Power Supply with Power Cord

SP-PW1-20 Power Supply with Power Cord*

AC-CP2 Cartridge Removal Pad

AC-YS3-P Workstand Sponge (Pack of 50)

AC-BRUSH-P Soft Brass Brush Cleaner (Pack of 6)

AC-TCASE Tip Case (holds 10 tips)**

AC-TSTAND Tip Stand

SP-HC1 ESD Solder Handle W/CP2 for SP200 Systems

SP-OR O-Ring Replacement Kit

SP-WSK1 SP Workstand with YS3 Sponge

SP-CRADLE Universal Cradle

*220/240 VAC system does not include power cords

**Tips not included

SP200 SOLDERING SYSTEM

System Includes Power Supply With Power Cord*, Hand-Piece With

Cord, Workstand With Sponge And Cartidge Removal Pad

.40"

.21"

5.3mm

10mm

.30"

.13"

7.6mm

3.3mm
.65"

.12"

3.0mm

16.5mm

.10"

.39"

2.5mm

9.9mm

.63"

.07"

1.78mm

16mm

.65"

.07"

1.78mm

16.5mm

.40"

.07"

9.9mm

1.78mm

.40"

1.5mm

10mm

.06"

.43"

1.0mm

.04"

11mm

15mm

.055"

.590"

1.4mm

.04"

.60"

1.0mm

15.2mm

.45"

0.51mm

.02"

11.4mm

.39"

.07"

9.9mm

1.78mm

.36"

.04"

1.0mm

9.1mm

.73"

.02"

.51mm

18.5mm

.45"

.02"

0.51mm

11.4mm

.07"

14.2mm

60°

1.78mm
.56"

.75"

.016"

0.4mm

19mm

.70"

.05"

17.8mm

1.27mm

.64"

45º

.02"

.18"

16.25mm

0.5mm

4.5mm

.70"

.016"

17.8mm

2.3mm

.64"

45º

.02"

.18"

16.25mm

0.5mm

4.5mm
.24"

6.1mm

page

19

SP200

Tip Cartridges For Soldering Applications

The SP200 Soldering System’s tip cartridges are designed to suit a wide range of soldering applications.

For optimum performance, operators should select the tip that allows maximum contact with the work

surface. We suggest that you start with a 600 series tip cartridge.

SP200 SOLDER TIP CARTRIDGES

500 SERIES X =5 600 SERIES X=6 700 SERIES X=7

SSC-X17A

Extra Large Chisel
.21” (5.3mm)

SSC-X13A

Chisel 90º
.13” (3.3mm)

SSC-X46A

Long Reach Chisel
.12” (3.0mm)

SSC-X36A

Chisel 30º
.10” (2.5mm)

SSC-X42A

Long Reach Chisel 60º
.07” (1.78mm)

SSC-X70A

Long Chisel
.07” (1.78mm)

SSC-X37A

Chisel 30º
.07” (1.78mm)

SSC-X38A

Chisel 30º
.06” (1.5mm)

SSC-X25A

Chisel 30º
.04” (1.0mm)

SSC-X74A

Conical Sharp
.055” (1.4mm)

SSC-X01A

Conical Sharp
.04” (1.0mm)

.40"

.21"

5.3mm

10mm

SSC-X22A

Conical Sharp
.02” (0.51mm)

SSC-X72A

Conical Chisel
.07” (1.78mm)

SSC-X71A

Conical Chisel
.04” (1.0mm)

SSC-X54A

Sharp Bent 30º
.02” (0.51mm)

SSC-X26A

Sharp Bent 30º
.02” (0.51mm)

SSC-X47A

Bevel 60º
.07” (1.78mm)

SSC-X45A

Bevel 60º
.016” (0.4mm)

SSC-X67A

Drag Soldering Tip
(Mini-Hoof)

SSC-X61A

Drag Soldering Tip
(Knife)

SSC-X39A

Drag Soldering Tip
(Hoof)

SSC-X73A

Drag Soldering Tip
(Increased Tinned
Area, .24” 6.1mm)

.30"

.13"

7.6mm

3.3mm
.65"

.12"

3.0mm

16.5mm

.10"

.39"

2.5mm

9.9mm

.63"

.07"

1.78mm

16mm

.65"

.07"

1.78mm

16.5mm

.40"

.07"

9.9mm

1.78mm

.40"

1.5mm

10mm

.06"

.43"

1.0mm

.04"

11mm

15mm

.055"

.590"

1.4mm

.04"

.60"

1.0mm

15.2mm

.45"

0.51mm

.02"

11.4mm

.39"

.07"

9.9mm

1.78mm

.36"

.04"

1.0mm

9.1mm

.73"

.02"

.51mm

18.5mm

.45"

.02"

0.51mm

11.4mm

.07"

14.2mm

60°

1.78mm
.56"

.75"

.016"

0.4mm

19mm

.70"

.05"

17.8mm

1.27mm

.64"

45º

.02"

.18"

16.25mm

0.5mm

4.5mm

.70"

.016"

17.8mm

2.3mm

.64"

45º

.02"

.18"

16.25mm

0.5mm

4.5mm
.24"

6.1mm

Powerful, Portable Through-Hole Rework

Metcal’s SP440 Self-Contained Desoldering System is specifically designed for through-hole rework,

delivering powerful and portable desoldering.

The system’s built-in vacuum pump clears through-holes quickly and completely, making it ideally

suited to areas without shop air. This lightweight, ergonomic pencil grip desoldering tool

maximizes operator productivity and reduces the risk of damage to components and substrates.

Using SmartHeat

®

technology, the SP440 Self-Contained Desoldering System supplies higher Watt

density power at lower temperatures than other desoldering tools with no overshoot. Its 50-Watt

power rating and tips, specifically designed to maximize heat transfer, make the system ideal for

heavy load desoldering of components on ground-planes and multi-layer PCBs.

page

20

SP440

SP440

Self-Contained Desoldering System

B

A

page

21

SP440

Advanced Operating And Safety Features

The SP440 Self-Contained Desoldering System has a number of features, which combine to ensure

that it is the most reliable and cost-effective solution available for self-contained desoldering. The

system’s time-out feature switches off the power supply after a 30-minute redundancy period, thus

significantly extending tip life and conserving energy.

Coupled with these features are elements that reflect our dedication to operator and process safety.

The SP440 Self-Contained Desoldering System’s ESD cable and vacuum line are burn-proof, which

safeguards operators from injury and prevents damage to expensive process elements. The unit’s

readily accessible paper solder collection chamber renders the former glass cartridges obsolete and

speeds the desoldering process.

Desoldering Tips

The SP440 Self-Contained Desoldering System’s tips are available in two temperature ranges: 600

and 700 series. To ensure the best results, choose a tip with an interior diameter only slightly larger

than that of the lead on the component to be desoldered.

SP440-11 115 VAC Self-Contained Desoldering System

SP440-21 220/240 VAC Self-Contained Desoldering System*

*220/240 VAC system does not include power cords

ACCESSORIES & SPARE PARTS

SP-PW3-11 Power Supply with Power Cord

SP-PW3-21 Power Supply with Power Cord*

DP-DSG2 Hand-Piece Assembly

(handle, cord, vac line, coil assembly)

DP-WSK2 SP440 Workstand Kit with YS3 Sponge

DP-SL3 Front Seal for DSG2

AC-TC-P Tip Cleaners (Pack of 12)

AC-CP2 Cartridge Removal Pad

DP-CA2 Coil Assembly

DP-CC Solder Collection Chamber for DSG2

DP-CF Filter Pack (12 fume filters, 24 chamber liners)

DP-LF Filter Pack (5 inline filters)

DP-VB1 Valve Body Assembly (clip, valve, ESD vac. hose)

DP-VL1 Vacuum Line, ESD

DP-WSC2 SP440 Cradle

AC-YS3-P Workstand Sponge (Pack of 50)

*220/240 VAC system does not include power cords

TIP RANGE

Par t No. A B

SDC-X02 .025 (0.64) .055 (1.40)

SDC-X03 .030 (0.76) .060 (1.52)

SDC-X04 .040 (1.02) .070 (1.78)

SDC-X05 .050 (1.27) .080 (2.03)

SDC-X06 .060 (1.52) .090 (2.29)

SDC-X07 .095 (2.41) .125 (3.18)

DIAMETER IN INCHES (mm)

B

A

600 SERIES X =6 700 SERIES X=7

SP440 DESOLDERING SYSTEM

System Includes Power Supply With Power Cord*, Hand-Piece Assembly,

Workstand Kit With Sponge, Tip Cleaners And Cartidge Removal Pad

page

22

QX2

QX2

Convection Rework Made Easy

The QX2 Convection Rework System combines sophisticated process control and wide-ranging

capabilities with a user-friendly, ergonomic design to speed and simplify the rework process. With

its constant temperature and variable power, the QX2 Convection Rework System minimizes the risk

of thermal damage, providing a safe environment for delicate components and substrates.

In comparison with other convection systems, the simplicity and power of this machine is clear.

Simplified push-button controls and advanced automation reduce the need for extended operator

training while greatly reducing the likelihood of human error. Older convection systems are difficult

to operate and require extensive user training. This is not the case with the QX2 Convection Rework

System. Even its initial set-up is a fast and easy process, requiring no special tools.

Please note: The QX2 Convection Rework System is shown below alongside a Metcal BVX-100 Fume

Extraction System which is available separately.

Precise Nozzles Increase Flexibility

A wide range of focused convection nozzles is available for the QX2 Convection Rework System.

These direct heat precisely where it is needed. With Metcal’s quick-release system, these nozzles

can be changed in seconds, for unsurpassed speed and flexibility.

QX2 Convection Rework System

page

23

QX2

Streamlined Operation

The QX2 Convection Rework System’s vacuum pick-up gently removes components after reflow.

The time of each removal cycle is stored and displayed as a guide to help operators quickly establish

a minimum time for component placement. The system then automatically turns off the heat to

minimize the risk of thermal shock to adjacent components or to the PCB itself. An integrated

under-board pre-heater is also available to prevent the warping of large boards during rework.

Operators can fine-tune the power by adjusting the airflow rate, but to minimize thermal stress, the

system automatically sustains the heater exhaust temperature while maintaining a consistently low

set point temperature. To accommodate any process change, including the use of new soldering

alloys, the manufacturing engineer can easily reprogram this set temperature.

page

24

QX2

Remote Controller Functions

Timer: By counting up during removal and down during attachment, the timer removes

subjective guesswork from the rework process.

Temperature Display: Displays the temperature of the heater exhaust or the

temperature measured by an auxiliary thermocouple in either °F or °C. The heater exhaust

temperature is preset at 662ºF (350°C) and may be reset by the process engineer to

anywhere between 482ºF (250°C) and 842ºF (450°C) by entering an unlock code.

Attach Mode: This mode reflows a new component to the PCB. By adjusting the time

stored in Remove mode with the + - keys, you can ensure an appropriate reflow time,

which may be adjusted on the fly if desired.

Airflow Selector: The airflow selector determines the rate at which thermal energy is

transferred to the component.

Remove Mode: This mode activates the vacuum pick-up, which applies a gentle upward

force to the component. When component lift off is sensed, the heater is automatically

turned off.

Start/Stop Button: Pressing the Start/Stop button initiates or ends the Remove or

A ttach cycle. In Remove mode, stopping the cycle also shuts off the vacuum, to release

components after lift off.

Advanced Process Control

The system’s digital controller clearly displays critical parameters during operation while its

automated functions reduce process variability. Its expanded level of process control provides

superior quality of operation and final product, with less scrap and greater throughput.

A

B

A

B

A

B

page

25

QX2

QX2 Convection Rework Nozzles

Metcal has a comprehensive range of nozzles for the QX2 Convection Rework System. For non-standard

components we offer a custom nozzle program. Please contact your local Metcal representative for more

information about custom nozzles.

A

B

STANDARD NOZZLE RANGE

Part No. Component Types A B

NZ-D1113 Nozzle Dual 0.43 (11) 0.51 (13)

NZ-D1116 Nozzle Dual (for SOL 28) 0.43 (11) 0.63 (16)

NZ-D1420 Nozzle Dual 0.55 (14) 0.79 (20)

NZ-D2109 Nozzle Dual 0.35 (09) 0.83 (21)

NZ-D2113 Nozzle Dual 0.51 (13) 0.83 (21)

NZ-Q11 Nozzle Quad (for PLCC 20) 0.43 (11) 0.43 (11)

NZ-Q13 Nozzle Quad (for PLCC 28) 0.51 (13) 0.51 (13)

NZ-Q1415 Nozzle Quad 0.55 (14) 0.60 (15)

NZ-Q17 Nozzle Quad 0.67 (17) 0.67 (17)

NZ-Q18 Nozzle Quad (for QFP 80) 0.71 (18) 0.71 (18)

NZ-Q19 Nozzle Quad (for PLCC 44) 0.75 (19) 0.75 (19)

NZ-Q1925 Nozzle Quad (for QFP 100) 0.75 (19) 0.98 (25)

NZ-Q22 Nozzle Quad 0.87 (22) 0.87 (22)

NZ-Q23 Nozzle Quad 0.91 (23) 0.91 (23)

NZ-Q27 Nozzle Quad (for PLCC 68) 1.06 (27) 1.06 (27)

NZ-Q28 Nozzle Quad 1.10 (28) 1.10 (28)

NZ-Q32 Nozzle Quad (for PLCC 84, QFP 208) 1.26 (32) 1.26 (32)

NZ-Q33 Nozzle Quad (for QFP 120/128/144/160) 1.30 (33) 1.30 (33)

NZ-Q35 Nozzle Quad 1.38 (35) 1.38 (35)

NZ-Q38 Nozzle Quad 1.50 (38) 1.50 (38)

NZ-Q43 Nozzle Quad 1.70 (43) 1.70 (43)

DIMENSIONS IN INCHES (mm)

A

B

Box Reflow Nozzles

In addition to our broad range of standard nozzles, we also offer a range of box reflow nozzles

designed for the removal of shielding cans, connectors and other square components.

A

B

BOX REFLOW NOZZLES

Part No. Component Types A B

NZ-B23 Nozzle Box 0.91 (23) 0.91 (23)

NZ-B27 Nozzle Box 1.06 (27) 1.06 (27)

NZ-B33 Nozzle Box 1.30 (33) 1.30 (33)

NZ-B35 Nozzle Box 1.38 (35) 1.38 (35)

NZ-B40 Nozzle Box 1.57 (40) 1.57 (40)

NZ-B44 Nozzle Box 1.73 (44) 1.73 (44)

INTERNAL DIMENSIONS IN INCHES (mm)

page

26

QX2

TECHNICAL SPECIFICATIONS

QX2-S-11 QX2-S-21

Input Voltage 90-132 VAC, 50/60 Hz 220-260 VAC, 50/60 Hz

Convection System

Heater 550 W 550 W

Rated Current 5 Amps 2.5 Amps

Airflow 20-50 l/min 20-50 l/min

Source Temperature

(Default Set Point) 662°F 350°C

Source Temperature Range 482°F - 842ºF 250°C - 450°C

Pre-Heater

Heater 950 W 950 W

Rated Current 8.5 Amps 4.5 Amps

Heating Surface 6” x 6” 152mm x 152mm

Board Temperature Range 194°F - 248°F 90°C - 120°C

Board Holder

Minimum Board Size 2” x 2” 50mm x 50mm

Maximum Board Size 14” x 18” 360mm x 460mm

Weights

Convection Rework System 18 lb 8.2 kg

Board Holder 5.5 lb 2.5 kg

Pre-Heater 6.4 lb 2.9 kg

Outer Dimensions (W x D x H

)

Convection Rework System

(Operating) 11.5” x 20.5” x 14.2” 292mm x 521mm x 361mm

(Stored) 11.5” x 16.8” x 21.0” 292mm x 427mm x 533mm

Board Holder 20.5” x 15.0” x 5.0” 521mm x 381mm x 127mm

Pre-Heater 8.2” x 15.5” x 2.5” 208mm x 394mm x 64mm

FEATURES

Vacuum Self-contained

Operator Moveable controller with:

•Start/Stop button

•Airflow control

•Time control

•LCD display

•Remove/attach control

Component Removal Automatic component lift off

and heater shut off

Component Attachment Manual, timer controlled

Nozzle Attachment/Removal Push on, quick-release

Other Auxiliary thermocouple port for

component temperature monitoring

SYSTEMS

ACCESSORIES

AC-BH Board Holder

AC-BP-11 Board Holder/Pre-Heater

Kit 115V

AC-BP-21 Board Holder/Pre-Heater

Kit 230V*

AC-PH-11 Pre-Heater 115V

AC-PH-21 Pre-Heater 230V*

AC-BS Board Support

QX2-S-11

115V Convection Rework System

QX2-SBH-11

115V Convection Rework System

with Board Holder

QX2-SBP-11

115V Convection Rework System

with Board Holder & Pre-Heater

QX2-S-21

230V Convection Rework System*

QX2-SBH-21

230V Convection Rework System

with Board Holder*

QX2-SBP-21

230V Convection Rework System
with Board Holder & Pre-Heater*

115V CONVECTION REWORK

SYSTEM INCLUDES:

QX2-P-11 Power Supply, 115V

QX2-CT QX2 Controller

AC-WT Work Tray

AC-RP Nozzle Removal Pad

AC-CC1 QX2 Controller Cable

AC-CC2 Pre-Heater Control Cable

AC-VC Vacuum Cup Kit

230V CONVECTION REWORK

SYSTEM INCLUDES:

QX2-P-21 Power Supply 230V*

QX2-CT QX2 Controller

AC-WT Work Tray

AC-RP Nozzle Removal Pad

AC-CC1 QX2 Controller Cable

AC-CC2 Pre-Heater Control Cable

AC-VC Vacuum Cup Kit

QX2

QX2 Convection Rework System

* 230V systems do not include power cords

page

27

SMT

1160

SMT-1160

Non-Contact Hot Air Rework Station

With its precise forced air convection, Metcal’s SMT-1160 Hot Air Pencil is designed for those rework

applications requiring very low thermal stress, including SMDs and temperature-sensitive ceramic

capacitors. This non-contact system, with variable temperature flow, can also capably remove SMT

chip capacitors and SOICs.

The SMT-1160 Hot Air Pencil is equipped with a broad range of features for assured effectiveness

and sensitivity of operation. These include an ESD-safe housing and hand-piece, variable airflow

control, variable closed-loop temperature control, a nitrogen input facility to suit inert soldering

applications and specialized split, fan and fine nozzle options.

The SMT-1160 Hot Air Pencil’s capacity for non-contact soldering avoids alignment disruption and

eliminates the risk of thermal shock to components.

SMT-1160 Hot Air Pencil

SMT-1161-V 115V Hot Air Pencil Rework Station

SMT-1162-V 230V Hot Air Pencil Rework Station

ACCESSORIES & SPARE PARTS

SHP-1060A Hot Air Pencil Hand-Piece

VP-50 Vacuum Pencil with Nozzle kit

VTM-1 Variable Temperature Module

S6-025 Fine Nozzle 0.025” (0.64mm)

S6-FAN Fan Nozzle 0.347” x 0.030” (8.8mm x 0.76mm)

S6-SOIC Dual Nozzle 0.265” (6.7mm)

S6-SOL Dual Nozzle 0.428” (10.9mm)

NK-1060A 3 Piece Nozzle Kit (includes 16812, 16813, 16846)

17319S Pump Assembly

16806 Collar Sub-Assembly SHP-1060A

16844 Nipple Assembly SHP-1060A

AC-HAPWS Workstand

AC-HAPWSC Replacement Workstand Cradle

16812 Nozzle, Oval, .101” (2.57mm)

16813 Nozzle, Round, .080” (2.03mm)

16846 Nozzle, Sharp 30°, .080” (2.03 mm)

SMT-1160 HOT AIR PENCIL

System Includes Hot Air Pencil Hand-Piece, 3 Piece Nozzle Kit

(NK-1060A), Workstand And Variable Temperature Module

page

28

Metcal

Metcal

Metcal Product Lines

Array Package Rework

Metcal Array Package Rework systems are advanced, versatile machines offering the repeatability,

accuracy and thermal control essential for the safe and effective rework of today’s leading edge BGA,

CSP, Land Grip Array (LGA), micro SMD, Micro-lead Frame (MLF) and Bumped Chip Component packages.

For more information on the full line of Metcal Array Package Rework products, visit www.metcal.com,

or contact your local Metcal representative.

Fume Extraction

For the safety of your operators and working environment, Metcal offers a full line of fume extraction

systems. From volume to tip to bench-top fume extraction, Metcal has systems to purify the air by

filtering harmful smoke and particulates from the working area. Fume extraction systems are also useful

for extracting potentially noxious fumes from the use of certain adhesives and chemicals on the

workbench. For more information on the full line of Metcal Fume Extraction products, visit

www.metcal.com, or contact your local Metcal representative.

Global

Metcal Global Locations

Menlo Park, California, is home to Metcal’s corporate headquarters, and the central location for

research and development, manufacturing and administration.

To meet the needs of customers throughout the world, Metcal has sales, service and distribution

centers in North America, Asia, and Europe. Drawing on its organizational strengths and industry

experience, Metcal’s distribution network offers seamless, proactive support and access to the

company’s full range of products - around the globe.

Wherever electronics manufacturing facilities are located, Metcal’s network of expertly trained

distributors is there, to supply essential technical support and advanced process solutions.

Metcal Headquarters

1530 O'Brien Drive

Menlo Park, CA 94025

USA

Phone: [phone]

Fax: [phone]

Germany

OK International GmbH

Frankfurter Strasse 74

D-64521 Gross-Gerau

Germany

Phone: [phone]

Fax: [phone]

Europe Headquarters

OK International Ltd

Eagle Close, Chandler's Ford

Hampshire, SO53 4NF U.K.

Phone: [phone]

Fax: [phone]

Italy

OK International Spa

Strada Statale 11 -No. 28,

20010 Vittuone (Milano),

Italia

Phone: [phone]

Fax: [phone]

Asia Headquarters

OK International Taiwan Ltd

5F No. 79 Sec. 1

Hsin-Tai-Wu Road, His-Chih

Taipei Hsien, Taiwan

Phone: [phone]

Fax: [phone]

China

OK International China

No. 22 Chao Yang Men Wai Avenue

Beijing Prime Tower, Room 1901

Chao Yang District,

Beijing, P. R. China 100020

Phone: [phone]

Fax: [phone]

France

OK International SA

Rue Ampere - ZI Lyon Nord

69730 Genay, France

Phone: [phone]

Fax: [phone]

Japan

OK International Japan Ltd

2F ASK Bldg.

1-24-4 Ebisu

Shibuya-Ku

Tokyo 150-0013, Japan

Phone: [phone]

Fax: [phone]

©2001 Delaware Capital Formation, Inc. All Rights Reserved. DOVER and the Dover logo are registered trademarks of
Delaware Capital Formation, Inc., a wholly-owned subsidiary of Dover Corporation.

WORLD HEADQUARTERS AND NORTH AMERICAN OFFICE

1530 O’BRIEN DRIVE • MENLO PARK • CA 94025 • USA

TEL: [phone] • FAX: [phone]

www.metcal.com

Precision Systems for the Electronics Bench

MET-US-001
