OKI MC851, MC861 Network Guide

MC851/MC861

Network Guide

REFACE

Every effort has been made to ensure that the information in this document is complete, accurate, and up-to-date. The manufacturer assumes no responsibility for the results of errors beyond its control. The manufacturer also cannot guarantee that changes in software and equipment made by other manufacturers and referred to in this guide will not affect the applicability of the inform a t ion in i t. Mention of software products manufactured by other companies does not necessarily constitute endorsement by the manufacturer.

While all reasonable efforts have been made to make this document as accurate and helpful as possible, we make no warranty of any kind, expressed or implied, as t o the accuracy or completeness of the information contained herein.

The most up-to-date drivers and manuals are available from:

http://www.okiprintingsolutions.com

07118701 Iss.01 Copyright © 2011 Oki Europe Ltd. All rights reserved. Oki is a registered trademark of Oki Electric Industry Company Ltd. Oki Printing Solutions is a tr a d emark of Oki Data Corporation. Energy Star is a trademark of the United States Environmental Protection Agency. Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corporation. Apple, Macintosh, Mac and Mac OS are registered trademarks of Apple Inc. Other product names and brand names are registered trademarks or trademarks of their

proprietors.

Preface > 2

ONTENTS

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Notes, cautions and warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Network configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Self-diagnostic test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Configuration utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using Quick Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using AdminManager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Device setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

IP address setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Option menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Help menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Using a web browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Default user name and password . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Adjusting printer settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Using TELNET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Example TELNET configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Using SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Management utility — PrintSuperVision . . . . . . . . . . . . . . . . . . . . . . . . . .36

Printing utility — LPR (Windows only) . . . . . . . . . . . . . . . . . . . . . . . . . . .36

System requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

To install the LPR utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Uninstallation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Microsoft windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Installing a network printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Using the Oki Driver Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Using the Add Printer Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Configuring the network printer IP address. . . . . . . . . . . . . . . . . . . . . . . .40

Uninstalling the network card setup utility . . . . . . . . . . . . . . . . . . . . . .41

Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Printing the configuration page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Setting up a network printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

MacOS printer setup utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Installing the printer setup utility . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

The printer setup utility interface . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

menu options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Connecting to your printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Snow Leopard (10.6) AND Leopard (10.5) . . . . . . . . . . . . . . . . . . . . . .50

Configuring printer hardware options. . . . . . . . . . . . . . . . . . . . . . . . . . . .51

UNIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Network Interface card setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Logical directories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Self-diagnostic test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Printer does not print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

NG is printed in the self-diagnostic test . . . . . . . . . . . . . . . . . . . . . . . .57

Contents > 3

TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Computer cannot find the network interface card . . . . . . . . . . . . . . . . .57

Cannot print with lpr and ftp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Web browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Microsoft Internet Explorer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Mozilla Firefox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Contents > 4

OTES, CAUTIONS AND WARNINGS

NOTE A note provides additional information to supplement the main text.

CAUTION!

A caution provides additional information which, if ignored, may result in equipment malfunction or damage.

WARNING!

A warning provides additional information which, if ignored, may result in a risk of personal injury.

Notes, cautions and warnings > 5

ETWORK CONFIGURATION

NTRODUCTION

Your machine incorporates a fast 100BASE-TX/10BASE-T network interface. This guide explains the functionality of the built in network interface. Access for interconnection and producing self-diagnostic test and configuration printouts is provided via an interface panel at the rear of the machine.

This network interface supports IEEE802.2, IEEE802.3, Ethernet-II and SNAP, and can detect those frame types automatically.

Also, the interface supports major protocols such as TCP/IP, IPX/SPX (NetWare) and NetBEUI.

This guide details the network interface specification and several software utilities. You should set the emulation in the Print Setup menu to Auto or PS before printing the self-

diagnostic test and settings.

NOTE Not all utilities, features or protocols are supported by every operating system. Please check with your User’s Guide and support website for latest information.

Network configuration > 6

PECIFICATION

NOTE Not all utilities, features or protocols are supported by every operating system. Please check with your User’s Guide and support website for latest information.

ITEM SPECIFICATION

Frame Types IEEE 802.2

IEEE 802.3 Ethernet-II, SNAP, AUTO

Network Interface 100BASE-TX

10BASE-T

Network Protocols TCP/IP V4, V6

IEEE 802.1x Network layer: ARP, IP, ICMP Session layer: TCP, UDP Application layer:LPR, FTP, TELNET, HTTP,

IPP, BOOTP, DHCP, SNMP, DNS, SMTP, POP3, SLP, Bonjour

IPX/SPX (NetWare) Remote printer mode (up to eight file servers

and 32 queues) Print server mode over IPX/SPX (up to eight

print servers) Encrypted password supported in print server

mode EtherTalk NetBEUI NetBIOS, WINS LDAP Kerberos Windows Rally SSL/TLS IPSec

Functions Self-diagnostic test printing

Monitoring and configuration by Web browser Printer status notification by E-Mail

ELF-DIAGNOSTIC TEST

With the machine power switched on, press the push-button located on the network interface panel (at the rear of the machine) for more than three seconds and release. The self-diagnostic test results and configuration settings are printed.

On the first page of the Network Information that is printed out, under the heading “General Information” the MAC or Ethernet address is given. For example:

MAC ADDRESS 00808784E3F1

The Ethernet address is therefore: 00:80:87:84:E3:F1

Network configuration > 7

ONFIGURATION UTILITIES

You can configure the network interface (NIC) by using one of the following methods:

UTILITY FEATURES SYSTEM REQUIREMENTS

Quick Setup Configure the NIC easily and

simply without installing any software packages into your system. You can set the following:

> Enable/disable TCP/IP,

NetWare, EtherTalk, NetBEUI protocols.

> Set IP address, Subnet Mask

and Gateway for TCP/IP manually or by using DHCP.

> Set NetWare Mode and

create Queue/Print Server/ Printer objects.

> Zone name and Port name

for EtherTalk.

Admin Manager Configure the NIC in detail.

Web Browser Configure the NIC and printer

Telnet Configure the NIC using

SNMP The printer and network card

by using a Web browser such as Microsoft Internet Explorer or Mozilla Firefox.

TELNET.

can be controlled using thirdparty vendor developed SNMP application.

Windows:

Windows 2000 Server/Professional Windows XP Home/Professional Windows XP Professional x64 Edition Windows Server 2003 Windows Server 2003 x64 Edition Windows Server 2008 Windows Server 2008 x64 Edition Windows Vista 32-bit Windows Vista 64-bit Windows 7 Windows 7 x64 Edition Windows Server 2008 R2

Mac:

Mac OS X 10.3.0 or greater You need to install Rosetta if using Mac OS X 10.6

Microsoft Internet Explorer or similar.

Third-party vendor developed TELNET client package.

A TELNET Application is standard in Windows/UNIX/Linux.

Third-party vendor developed SNMP application.

SING QUICK SETUP

Quick Setup utility allows you to configure the network interface easily and simply without installing any software packages.

You can configure the following:

> Enable/disable TCP/IP, NetWare, EtherTalk, NetBEUI protocols. > Set IP address, Subnet Mask and Gateway for TCP/IP manually or by using DHCP. > Set NetWare mode and create Queue/Print Server/Printer objects. > Zone name and Port name for EtherTalk.

Configuration requires a PC with a supported Windows Operating System. Ref er to the table above for system requirements.

This utility can only be used on a PC that can be connected to the network with TCP/IP or IPX/SPX (NetWare).

This utility must be used on a PC that is located on the same segment as the printer.

1. Insert the DVD-ROM into the DVD-R OM driv e. The Setup Utilit y starts automatically. If it does not start, double-c l ic k \setup.exe (in the root directory) on the DVDROM.

2. Select the appropriate language.

Network configuration > 8

3. Select your printer model.

4. If you agree to the Software Licence Agreement, click I Agree.

5. Select Device Configuration.

6. Select Run Network Card Setup.

7. Select your language.

8. Select Oki Device Quick Setup and follow the on-screen instructions.

9. When the settings are correct, click Execute. The new settings are transmitted to

the network card but it still operates with pre-transmission settings.

10. Click Finish to validate the new settings.

11. Switch the printer off for 15 seconds and on again.

Network configuration > 9

SING ADMINMANAGER

NOTE Not all utilities, features or protocols are supported by every operating system. Please check with your User’s Guide and support website for latest information.

AdminManager is a powerful Microsoft Windows-based utility to configure all network interface functions easily and intuitively via a graphical user interface.

Configuration requires a PC with a supported Windows Operating System. Refer to

“Configuration utilities” on page 8 for system requirements.

This utility can only be used on a PC that can be connected to the network with TCP/IP or IPX/SPX (Netware) and must be used on a PC that is located on the same segment as the printer.

NSTALLATION

1. Insert the DVD-ROM into the DVD-R OM driv e. The Setup Utilit y starts automatically.

If it does not start, double-c l ic k \autorun.exe (in the root directory) on the DVDROM.

2. Select the appropriate language.

3. Select your printer model.

4. If you agree to the Software Licence Agreement, click I Agree.

5. Select Device Configuration.

6. Select Run Network Card Setup.

7. Select your language.

Network configuration > 10

8. Select Oki Device Standard Setup.

9. If you want to install AdminManager on to your local drive, select Install and Execute. Otherwise, select Execute from CD-ROM. Follow the on-screen

instructions.

10. To run AdminManager, check Yes for Do you wish to execute AdminManager? and click Finish. Otherwise check No and click Finish.

NTERFACE

Select Start > Programs > OkiData > Admin Manager.

MENU ITEM FUNCTION

File Search Search printers in your network and list all printers.

Exit Exit the Admin Manager Utility.

Network configuration > 11

MENU ITEM FUNCTION

Status System

Status

List of Configuration Items

Setup Oki Device

Setup Setup by

HTTP Setup by

TELNET Create

NetWare Queue

Displays current NIC configuration. Configuration data can be saved as log file.

Configure the network interface (NIC).

Launch the default browser in your environment to access the selected printer’s web page.

Launch TELNET application in your environment to access the selected printer’s TELNET port.

Create a NetWare queue.

Note: Only visible when using Netware.

Option

Help

Delete NetWare Object

Delete NetWare object.

Note: Only visible when using Netware.

Reset Reset the selected network interface card. Test Print Print self-diagnostic test pages. IP Address

Setup Use TCP/IP

Set static IP address of network interface card manually.

Enable TCP/IP protocol.

Protocol USe IPX/SPX

Enable IPX/SPX protocol.

Protocol Environment

Set the Environment settings.

Setup About Displays version of Admin Manager.

Network configuration > 12

EVICE SETUP

NOTE Not all utilities, features or protocols are supported by every product. Please check with your User’s Guide and support website for latest information.

Device Setup allows you to configure the network interface. Type the root password (default value is the last 6 characters of the MAC address) to configure. Remember that the root password is case sensitive. If the MAC address contains any alpha characters, type them as upper case. Device Setup contains details for the following tabs:

> General > E-Mail(Receive) > TCP/IP > SNTP > NetWare > Maintenance > EtherTalk > SSL/TLS > NetBEUI/NetBIOS > IEEE 802.1X > SNMP > LDAP > E-Mail(Send) > Kerberos

The following section explains each tab’s functionality.

General Tab

This allows you to set or change the root password used for Admin Manager, TELNET and FTP.

ITEM EXPLANATION

Change root password

You can set/change the root password for AdminManager, TELNET and FTP.

Network configuration > 13

TCP/IP Tab

This allows you to configure TCP/IP related items.

ITEM EXPLANATION

Use TCP/ IP Protocol

Auto Discovery

DNS Server…

Set TCP/IP protocol as enabled/disabled. Use DHCP/BOOTP Check this item if IP address,

Use IPv6 Enables IPv6. IP Address Set the IP address of the

Subnet Mask Set the subnet mask of the

Default Gateway Set the default gateway of the

Configure items related to Network PnP

Use to select Network PnP and Bonjour, and to set device name.

Set IP addresses for DNS primary and secondary servers.

subnet mask, default gateway and IP addresses for DNS primary server and secondary servers are retrieved from the DHCP or BOOTP server. Otherwise, leave unchecked.

selected network interface card.

xxxxx

Windows Rally...

WINS Server...

Use WSD Print Use LLTD check to enable/disable.

Set IP addresses for WINS primary and secondary servers and to enter scope ID.

Network configuration > 14

NetWare Tab

This is where you can configure NetWare related items.

ITEM EXPLANATION

Use NetWare Protocol

Use IPX Protocol / Use TCP/IP Protocol

Print Server Name

Frame Type Set primary NetWare frame type. Operation Mode Set NetWare mode. Check box

beside Bindery Setup

Bindery Setup Configure items related to Bindery

Set NetWare protocol as enabled/disabled.

Set protocol to use.

Set Print Server name.

Check if you want to use the Bindery mode and Bindery Setup button becomes available. If it is unchecked, the button is greyed out.

mode. In this dialogue box, the following

items can be configured:

Password Set password for Print Server. Job Polling Time Set print job polling interval in

seconds.

NDS Setup Set NDS tree and context where

Print Server was created.

Network configuration > 15

ITEM EXPLANATION

RPRINTER Setup

Printer Name Set the NetWare printer object n ame.

EtherTalk Tab

Available if you select RPRINTER mode in Operation Mode.

xxxxx

By selecting the RPRINTER button, this is displayed:

Here you can specify print servers to which the printer can be connected.

Time Out Set duration from the last data’s

arrival to freeing of the port in seconds.

This allows you to configure EtherTalk related items.

ITEM EXPLANATION

Use EtherTalk Protocol

Printer Name Set EtherTalk Printer object name. Zone Name Set the zo ne name to which the printer belongs.

Set EtherTalk protocol to enabled/disabled.

Network configuration > 16

NetBEUI/NetBIOS Tab

This allows you to configure NetBEUI/NetBIOS related items.

ITEM EXPLANATION

SNMP Tab

Use NetBEUI Protocol

Use NetBIOS over TCP

Short Printer Name

Workgroup Set a work group name to which the printer belongs. Comment Set the comments for the printer (optional). Master

Browsing Setting

Set NetBEUI protocol to enabled/disabled.

Set NetBIOS over TCP to enabled/disabled.

Set a name for the printer.

Check to enable the Master Browser setting.

This allows you to configure SNMP related items.

ITEM EXPLANATION

Use SNMP Service

SNMPv3 + SNMPv1

SNMPv1 Settings

SNMPv3 Settings

ENABLE or DISABLE the SNMP protocol.

Select from the drop-down box which (or both) of these to use.

SNMP Read & Write Community.

Enables Authorisation and Privacy (Encryption) setup to be done.

Network configuration > 17

Enables these passwords to be changed.

ITEM EXPLANATION

MIB-II Parameters SysContact Set SysContact (printer manager) name. SysName Set SysName (printer model name). SysLocation Set SysLocation (the location where the printer is installed). Printer Trap

Setup…

By selecting the button, the following dialogue box is displayed:

In the dialogue box, the following items can be configured:

Printer Trap Community Name

TCP#1–5 Set the IP addresses to which a Trap

IPX Set node address and network address

This community name is assigned to outgoing printer status traps such as offline, paper out, etc.

packet will be sent. You can set up to five IP addresses, with the following details: Printer Reboot Receive Illegal Online Offline Paper Out Paper Jam Cover Open Printer Error

to which a Trap packet will be sent. By selecting the button, the following

dialogue box is displayed: In the dialogue box, the following items

can be configured: Online Offline Paper Out Paper Jam Cover Open Printer Error

Network configuration > 18

E-Mail (Send) Tab

This allows you to configure SMTP related items.

ITEM EXPLANATION

Use SMTP Transmit

SMTP Server Name

Printer E-Mail Address

Destination Address 1 - 5

When PERIOD is selected: Check time Used to set the interval at which the

Period mode Set ENABLE/DISABLE for the events

When EVENT is selected:

Check to enable SMTP.

Enter name of the SMTP server.

Enter the printers e-mail address.

Set the following parameters: Destination Address Set E-Mail address to which email

should be sent.

Notify Mode Select PERIOD or EVENT.

selected events are checked. An email will be sent at the specified interval for each event selected.

listed.

Event Mode Select:

ENABLE (ON), DISABLE (OFF) or IMMEDIATE (NOWAIT) for the listed events. If ENABLE (ON) is selected, the check interval can be set (in

hours and intervals of 15 mins). Attach Info... Select whichever information is to be included in the e-mail. Comment... Set up to four lines of text to be included with the e-mail as

comments.

Network configuration > 19

ITEM EXPLANATION

Authentication... Used to set the following security information:

Others... Set the following:

E-mail (Receive) Tab

SMTP Encryption Algorithm

SMTP Authentication Method

User ID Set the User ID for Authentication. User Password Set the User Password for

SMTP Port Number Set the SMTP port number (default

Reply to address Set the E-mail address used for the

Select required option from the

drop-down menu. Select from:

None, SMTPS, STARTTLS

Select required option from the

drop-down menu. Select from:

None, SMTP, POP

Authentication.

is 25).

[Reply to] field in the mail header.

Your machine supports an e-mail reception function (SMTP/POP3) allowing the printer to print PDF files attached to e-mails.

ITEM COMMENTS

Use POP Receive Ena ble/disable receiving E-Mail via POP3. POP3 Server Set the IP address or host name of the POP3 server. POP3 Server UserID Set User ID for POP3 server.

POP3 Server Password Set a password for the POP3 server.

POP Detail… Set the following:

Use APOP Select if you want to use APOP. POP3 Port

Number Mail Polling

Time

POP Encryption Algorithm

Use SMTP Receive Enable/disable SMTP receive.

Set the port number for APOP (default is 110).

Set interval to retrieve E-Mail(s) from the POP3 server. Selectable values, OFF, 1min, 5min (default), 10min, 30 min, 60 min.

Select required option from the dropdown menu. Select from: None, POP3S, STARTTLS

Network configuration > 20

ITEM COMMENTS

SMTP Detail... SMTP Receive

Port Number

Domain Filter… Set the following:

Use Domain Filter

Filter Policy Select ACCEPT (the default) or DENY. Domain Filter Define up to five domain filters.

Set port number (default is 25).

Enable/disable domain filtering.

SNTP Tab

In this Tab, you can configure SNTP related items.

ITEM COMMENTS

Use SNTP Enable/disable SNTP (S imple Network Time Protocol). NTP Server 1

Address NTP Server 2

Address Adjust Interval Set the interval for sending time update requests to the

Local Time Zone Set the local time zone from -12:00 to +13:00. Minute

Daylight Saving When this is selected, one hour is added to the local time.

Set the IP address or host name for NTP Server 1.

Set the IP address or host name for NTP Server 2.

server. Select 1 hour (the default), 12 hours or 24 hours.

interval is selectable from 00 (the default), 15, 30 or 45.

Network configuration > 21

Maintenance Tab

ITEM COMMENTS

LAN Scale Select NORMAL (the default) or SMALL.

IP Filter Setup… The following items can be configured:

Note: For small scale networks (with no routing), choose the

SMALL setting. For more complex networks choose NORMAL.

Use IP FIlter Enable/disable IP Filtering. Default is

disabled.

Admin IP Address

IP Address Range

Printing Enable/disable printing of the specified

Configuration Enable/disable changing IP address

Service… The following fe atures can be selected by c licking thei r check

box. Use TCP/IP Protocol

Use NetBEUI Protocol Use NetBIOS over TCP Use NetWare Protocol Use EtherTalk Protocol Use FTP Service Use Telnet Service Use Web Service Use IPP Service Use SNMP Service Use SMTP Transmit Use POP3 Protocol Use SNTP Use encrypted communication for configuration data

Set the administrator IP address.

Set up to 10 IP Filter address ranges: IP

Filter Range 1 through IP Filter Range 10.

IP address range. Default is disabled.

ranges. Default is disabled.

Network configuration > 22

SSL/TLS Tab

ITEM COMMENTS

Cipher Level Set the strength of encryption:

Strong = highest security, slowest speed Standard = medium security, medium speed Weak = least security, fastest speed

Self-signed Certificate

Create Certificate…

For IPP encryption within an organization’s internal network (intranet).

When Self-signed Certificate is selected, the following items are configured:

Common Name The printer’s IP Address appears here. Organization Enter the name of your organization. Organization

Unit Locality Enter the name of the city where the

State/Province Enter the state or province where the

Country/Region Enter the country or region where the

Key Exchange Method

Key size Select 512, 1024 (the default), or 2048

Term of Validity Enter a starting and ending date

Optional. Allows you to enter a subdivision or department name.

organization is located.

organization is located. Select RSA (the default) or

Diffie-Hellman(DSS).

bits.

(month/date/year) for which the certificate is valid.

Network configuration > 23

ITEM COMMENTS

CA-signed Certificate…

Create Certificate…

Used for web encryption to provide security when printing over the internet. Requires an outside certification service which must be purchased separately.

When CA-signed Certificate is selected, the f oll owing items are configured:

Common Name The printer’s IP Address appears here. Organization Enter the name of your organization. Organization

Unit Locality Enter the name of the city where the

State/Province Enter the state or province where the

Country/Region Enter the country or region where the

Key Exchange Method

Key size Select 1024 (the default) or 2048 bits.

Optional. Allows you to enter a subdivision or department name.

organization is located.

organization is located. Select RSA (the default) or

Diffie-Hellman(DSS).

Network configuration > 24

IEEE802.1X Tab

ITEM COMMENTS

Use IEEE802.1X

EAP Type The following Extensible Authentication Protocols

Use SSL/TLS Certificate

Authenticate server

Certificate Client

Enable/disable.

can be configured: EAP-TLS Selects Extensible Authentication

PEAP Selects Protected Extensible

EAP User Enter EAP User name. EAP Password Enter EAP password. Enable SSL/TLS certification.

Enable Server Authentication.

certificate

CA certificate File: (User can specify).

Protocol - TLS.

Authentication Protocol.

File: (User can specify). Password: (User can specify). Options to Import, Delete, View.

Password: (User can specify). Options to Import, Delete, View.

Network configuration > 25

LDAP

ITEM COMMENTS

LDAP Server Enter LDAP Server name. LDAP Port

Number LDAP Timeout Set LDAP timeout (default is 30). Maximum

Entries Authentication

Method

Authentication User ID

Authentication User Password

Encryption Algorithm

Search Filter... Search root Search root.

Enter LDAP port number (default is 389).

Set maximum entries (default is 100).

Select authentication method from the drop-down menu. Select from: Anonymous (default), Simple, Digest-MD5, Secure Protocol

Enter user ID.

Enter user password.

Select encryption algorithm from the drop-down menu. Select from: None (default), LDAPS, STARTTLS

Attribute Name1: cn

Name2: sn Name3: givenName Mail Address: mail

Additional Filter

Enter additional detail (optional).

Network configuration > 26

Kerberos

ITEM COMMENTS

Domain Enter Domain.

ADDRESS SETUP

If you only use TCP/IP and the printer has not yet been configured, occasionally it may not be displayed on AdminManager. You can configure the IP address of the printer by this function.

1. Select IP Address Setup from the Setup menu.

2. Set Ethernet Address and IP Address then select OK.

The Ethernet Address (MAC address) is displayed during the self-diagnostic test.

Network configuration > 27

PTION MENU

In the Option menu, the following item can be selected:

ITEM EXPLANATION

Use TCP/IP Protocol

Use IPX/SPX Protocol

Environment Setup

If this item is selected, AdminManager uses TCP/IP protocol to search/configure network interface cards.

If this item is selected, AdminManager uses IPX/SPX protocol to search/configure network interface cards.

TCP/IP Tab Set broadcast addresses that are used

to search printers using the TCP/IP protocol. If Use TCP/IP protocol is unchecked, the search will not be carried out using TCP/IP.

NetWare Tab Set network addresses that are used to

search printers via NetWare protocol. If there any many NetWare file servers on your network, specify the network address to which the network card belongs. If Use NetWare protocol is unchecked, the search will not be carried out using NetWare, but if Auto Search is selected, AdminManager will search all networks that AdminManager can detect.

SNMP Tab Obtain the printer name via SNMP -

Select. Enter Community name. Add and Delete.

TimeOut Tab Search Every: Set response waiting

time from a network card in seconds. Time Out: Set time out between

AdminManager and the network interface card in seconds.

Retry: Set how many times the retry will be carried out between AdminManager and the network interface card.

ELP MENU

In the Help menu, About is available and it displays AdminManager version number.

Network configuration > 28

SING A WEB BROWSER

If you do not wish to launch or install the Network Card Setup utility, you can access the printer’s Web Page directly through a web browser.

If the printer is connected to the network using TCP/IP, its settings and the printer menu settings can be configured using a Web browser. Refer “Adjusting printer settings” on

page 29 and the relevant manuals for details of how to launch and use the browser. Refer

also to “Web browser” on page 58 for instructions on how to prevent your browser caching the printer’s web pages.

EFAULT USER NAME AND PASSWORD

To apply configuration changes using a Web browser, you will be prompted for a username and password. The username is root and the default password is aaaaaa.

NOTE To apply configuration changes using AdminManager, the username is root and the default password is the last six characters of the Ethernet (MAC) address (any alpha characters must be in upper case).

The root password can be changed to allow you to configure the printer by using a Web browser/TELNET/AdminManager. To change password from the Web browser, select

Admin Setup > Management > Admin Password and follow on-screen instructions.

DJUSTING PRINTER SETTINGS

The network addresses used in this manual are shown as examples only. Network addresses used in your installation must be generated from your own network.

1. Launch the Web browser and enter the IP Address of the network interface card in Address (Location/Position) and press the Enter key. The Web Page is displayed.

You can find the IP Address on the Self-Diagnostic Test printout, refer to “Self-

diagnostic test” on page 7.

NOTE On the web page you can view printer status, job lists and links. You can also configure the IP Address, Subnet Mask and Gateway for the network card. However, to configure printer settings, you need to log in as “root” and enter the correct password to be able to configure all items.

2. To access and adjust control settings, such as printer, scanner, fax network, security and maintenance, click the Administrator Login button in the left-hand pane.

3. Enter the username, “root” and password as aaaaaa.

4. As this is the first time logging into the printer We b Page, the Printer Identification

(basic setup) page is launched. You have two options:

> You can enter the printer location, asset number, administrator name and select

“Do not show this page again”. Click OK to save these details. Allow a few seconds for the settings to save and the printer to restart automatically.

> If you do not wish to enter any details, click SKIP.

Network configuration > 29

5. The printer’s Web Page with full menu options opens up. Browse the menu and update information as appropriate.

The following table outlines the menu options for the printer Web Page.

MENU OPTION DESCRIPTION

View Info

Status View information relating to your Counter Supplies Life Usage Report Network System

printer status, consumables and network settings.

Network configuration > 30

MENU OPTION DESCRIPTION

Reports

Configuration View and print information and Information File List

Demo Page Error Log Scan to Log MFP Usage Report Network Information

Print PCL Font List

PSE Font List PPR Font List FX Font List Color Tuning Pattern Color Profile List

Paper Setup

reports.

Profile

Admin Setup

Tray Configuration View and adjust tray settings Select Tray

Profile Create, edit or delete Profile(s).

PIN ID Change your password and

change any admin settings relating to your machine.

Network configuration > 31

MENU OPTION DESCRIPTION

Admin Setup Cont...

Network General Network

Settings TCP/IP Netware Ethertalk NBT/NetBEUI Email SNMP IPP Windows Rally IEEE802.1X Secure Protocol

Server LDAP Mail Server Security Maintenance

Copy Setup Default Settings View and adjust copy settings.

View and change Network settings and apply access restrictions for your printer network.

Fax Setup Default Settings View and adjust Fax settings.

Security Function Other Settings

Scanner Setup Default Settings View and adjust scanner settings.

E-mail Setup USB Memory Setup

Print Setup Print Menu View and adjust Print settings.

Color Menu Sys Config Menu Emulation

Management Local Interface Reset your printer and restore

System Setup Power Save Memory Setup Admin Password Reset Settings

User Install User Install View and adjust settings.

default settings for your printer and Network Interface Card.

Time Setup

Network configuration > 32

MENU OPTION DESCRIPTION

Job Setup

Job List Allows you to manage pending

jobs for your printer.

Direct Print

Web Printing View and adjust settings. Email Printing Email Printing

Receive Settings Send Settings

Transmission Settings

Links

Automated Delivery Setup View and change Transmission Transmission Settings Automated Delivery Log Transmission Log

Links Add links for easy access to Edit Links

settings.

customer support and on-line information.

Network configuration > 33

SING

TELNET

CAUTION!

Please ensure a valid IP address for your network environment is used. Use of an incorrect IP address can cause serious problems on your network.

XAMPLE

TELNET requires the print server to have a valid IP address configured. If the NIC already has an IP address configured, skip steps 1 to 3 below.

1. Use the PING command to confirm the connection with the network card.

2. Login to the network card using TELNET.

TELNET

NOTE The method of configuring commands may differ between workstations. Refer to the workstation’s manual.

Example

For IP address 172.168.20.127:

ping 172.168.20.127

If there is no reply, there is a problem with the configuration of the IP address (the IP address has been already set manually or by the DHCP/RARP server), or with the network. Reset the network interface card settings to the default and try to set a temporary IP address. If you still have the problem after resetting the network interface card, consult the network manager.

Example

For IP address 172.168.20.127

CONFIGURATION

telnet 172.168.20.127

You should see a sequence similar to the following example:

Trying 172.168.20.127 Connected to 172.168.20.127 Escape character is ‘^]’. myprn TELNET Server (Ver 01.05). login: root ‘root’ user needs password to login. password: User ‘root’ logged in. No. MENU (level.1)

----------------------------------- 1:Status / Information

2:Device Config 3:Network Config 4:Security Config 5:Maintenance 99:Exit setup Please select (1-99)?

3. Enter the number of the item to be changed. The details window for that item displays.

Network configuration > 34

4. When the configuration is complete, selec t Exit Setup to save your change. To exit without saving your modification, select Quit.

5. Turn the printer off and on again.

NOTE The network card continues to use pre-transmission settings until the printer is turned off and back on again.

Network configuration > 35

SING

SNMP

NOTE Not all utilities, features or protocols are supported by every product. Please check with your User’s Guide and support website for latest information.

The machine and network card can be managed via a standard SNMP management station. The network card supports SNMPv1, MIB-II, Oki Data Private MIB and SNMP V3. In order for the machine to be managed correctly from an SNMP management station, the Oki Data Private MIB needs to be added to that management station. Please refer to the SNMP manager documentation for information on how to do this.

NOTE The Oki Data Private MIB file can be found in the MIB folder on the DVD-ROM or support website. Please refer to the readme file for further information.

The printer’s trap address can be set in five places using TCP/IP and in one place with IPX. Printer trap settings can be made with TELNET and a Web browser.

ANAGEMENT UTILITY

NOTE Not all utilities, features or protocols are supported by every product. Please check with your User’s Guide and support website for latest information.

— P

RINTSUPERVISION

PrintSuperVision is a Windows server applicatio n designed for managing and monitoring printing devices connected to a network. The core application is server-based and is accessible from any browser enabled device connected to the network.

For full details of how to install and use PrintSuperVision, please refer to the PrintSuperVision Configuration Guide which is available on the support website.

RINTING UTILITY

NOTE Not all utilities, features or protocols are supported by every product. Please check with your User’s Guide and support website for latest information.

The LPR Utility is a utility that allows printing data to printers connected to the network via TCP/IP. It is an alternative method of connecting printers instead of using the Microsoft TCP/IP port; however, the LPR utility offers some additional and very useful features:

> Displays printer status - print job status can be viewed, paused or cancelled. > Download files directly to the printer - send PRN or PostScript files directly to

the printer.

> Redirect print jobs - send print jobs to other printers if the original printer is busy

or has an error.

> Multicast printing - send the same print job to many printers simultaneously

1.The printers all have to be of the same model.

— LPR (W

INDOWS ONLY

)

YSTEM REQUIREMENT

Operating Systems with TCP/IP support and Oki printer that support TCP/IP.

Network configuration > 36

INSTALL THE

1. Set up the printer driver by designating the output destination to Local Printer

(LPT1:). For information on setting up your printer driver, see the printer user guide.

2. Insert the DVD-ROM into the DVD-R OM driv e. The Setup Utilit y starts automatically. If it does not start, double-click setup.exe on the DVD-ROM.

3. Select the appropriate language.

4. Select your printer model.

5. Select Software Utilities.

6. Select Install LPR.

7. Follow the on-screen instructions.

8. Click Next when the Welcome screen is displayed.

9. Verify Destination Folder and Spool Folder and click Next.

10. Check Register in Startup if you want automatic startup as Windows boots up. Check Launch as minimized if you want to startup in the Icon state and click Next.

LPR

UTILITY

NOTE Some Operating Systems require administrator privileges in order to make changes.

11. Verify the program folder name and click Next. The installation starts.

12. When the installation ends, the Setup complete screen is displayed. Check Yes, I want to launch LPR Utility now and click Finish. Check Yes, I want to view the ReadMe File if you want to read Readme. The LPR utility will start.

13. You may be asked whether it is OK to change write permissions for the spool directory. Click Yes to allow the utility to be correctly installed.

14. Select Add Printer on the Remote Print menu.

15. Click Discover… to search for the IP address of a suitable printer on your network.

16. Highlight the printer you will use and click OK.

17. If your printer is not discovered, click Cancel and you can type the IP address directly at IP Address:.

18. Enter an IP address at IP Address and click OK. A printer is added to the main

window.

Refer to the On-line Help for information on how to use the utility.

NINSTALLATION

1. Stop the LPR Utility.

2. Select Start > Programs > Okidata > LPR Utility > Uninstall LPR Utility. You may find this under Start > All Programs in Windows XP.

3. Click Yes when the Confirm File Deletion dialogue is displayed. Deletion of the LPR

utility starts.

4. When the deletion has finished, the Uninstall Complete s creen is displayed. Click OK.

If a file that has been added after installation exists in the folder to install the LPR util ity or the folder to spool, you cannot delete the folder. Delete any unwanted files before running Uninstall LPR Utility.

Network configuration > 37

ICROSOFT WINDOWS

VERVIEW

This chapter provides guidelines on how to print over the network from various Microsoft Windows platforms. There are numerous ways of printing from Windows and the exact setup will vary depending upon your environment. There are also numerous versions of Windows, which can be configured as either a client, server or both.

Although there are many variants of Windows, the principles of network printing are the same. Microsoft provides on-line help with all of their operating systems and this is a good reference point for the exact details of each configuration option with in Wi nd ows .

The network printer supports TCP/IP protocols that can be used in conjunction with the Windows operating system,

NOTE Not all utilities, features or protocols are supported by every operating system. Please check with your User’s Guide and support website for latest information.

NSTALLING A NETWORK PRINTER

There are two ways to set up a Network Printer:

> Install automatically, using the Oki Driver Installer > Install it yourself using the Add Printer Wizard

SING THE OKI DRIVER INSTALLER

The Oki Driver Installer program searches for compatible printers on the Network, then installs and configures the printer drivers with the correct port settings automatically.

Using the Oki Driver Installer program, you can install to the following connected printer types:

1. Locally connected printers

> USB port > Parallel port

2. Networked printers

> Directly connected (peer-to-peer) printers via TCP/IP. The Microsoft standard

TCP/IP is installed and configured to use Port 9100 with the printer’s IP address.

> Printers not directly connected, bu t s hared via a PC (Client Server)

Why use the Driver Installer?

> Automatically discovers printers on the Network (TCP/IP) > Installs driver and correctly assigns the appropriate port and IP address > Allows easy configuration and sharing of the printer with other Network users > Automatically configures the printer driver with the appropriate hardware device

options such as hard disc drive, duplex unit, etc. (via the Oki Network Extension software)

Microsoft windows > 38

SING THE ADD PRINTER WIZARD

Method summary:

The following table shows the different ways to connect to the printer (port types).

WINDOWS

2000

Windows Rally NO NO YES Windows

standard TCP/IP Oki LPR YES YES YES IPP YES YES YES NetBEUI YES YES NO

YES YES YES

WINDOWS XPWINDOWS VISTA/

SERVER 2003/

SERVER 2008/7

About the differ e nt methods

Windows Rally

Windows Rally is an automated “Plug-n-Play” type utilit y that allows users t o discover and configure network devices effortlessly.

Windows standard TCP/IP port

The standard TCP/IP port simplifies connecting to remote printers using the TCP/IP protocol. A computer that acts as a print server must run the TCP/IP protocol in order to print.

Can be configured to use either LPR or RAW (e.g. Port9100).

OkiLPR

Used to connect your printer over TCP/IP using an LPR port. OkiLPR also includes useful tools enabling you to download PS and PRN files direct ly to your

printer and automatically redirect jobs to other printers on the network.

IPP

The IPP (Internet Printing Protocol) defines a standard protocol for printing as well as managing print jobs, media, resolution, etc.

NetBEUI

NetBEUI (NetBios Extend ed User Interface) is a protocol that was designed for use in small workgroups or LANs. Within Windows NetBEUI is used for file and printer sharing between computers. It provides a simple method of printing, but it does have limitations, and i s not as robust as TCP/IP or IPX. Typically it is employed in small business or home networks.

Microsoft windows > 39

ONFIGURING THE NETWORK PRINTER

ADDRESS

Use the Standard Set-up Utility to configure the IP Address, Subnet Mask and Gateway.

NOTE It will not be necessary for printers connected to a network using DCHP to use this setup method.

Some steps may not display depending on the network protocols installed.

1. Connect the machine to the network and turn on.

2. Insert the DVD-ROM into the DVD-R OM driv e. The Setup Utilit y starts automatically.

If it does not start, double-c l ic k \setup.exe (in the root directory) on the DVDROM.

3. Select the appropriate language.

4. Select your printer model.

5. If you agree to the Software Licence Agreement, click I Agree.

6. Select Device Configuration.

7. Select Run Network Card Setup.

8. Select your language.

9. Select Oki Device Quick Setup and follow the on-screen instructions.

10. Select the appropriate network card, using the Ethernet address to identify it, and

click Next.

Microsoft windows > 40

The Ethernet address of the printer can be found on the self-diagnostic printout, which can be printed by pressing the push-button on the network card panel for more than three seconds and then releasing it. See “Self-diagnostic test” on page 7.

Using TCP/IP protocol

When using lpr in UNIX and other TCP/IP environments, please select Yes. To use in a TCP/IP environment, an IP address should be assigned to the Ethernet card.

If Yes has been selected and TCP/IP is the only working protocol and the IP address has not already been assigned, you can either obtain an IP address automatically or assign an IP address.

When Obtain an IP address automatically is selected, the device IP address will be automatically assigned by the DHCP se rver. In an environment without a DHCP server, please assign the IP address manually.

If you are manually assigning an IP address, you need to enter:

> An IP address > Subnet mask > Gateway address.

11. Click Next. Using Bonjour protocol

Bonjour is the preferred protocol for printing data from the Macintosh environment.

Using NetBEUI protocol

Using NetBEUI makes it easy to manage your Oki product and print within the network environment of Windows.

12. When the settings are correct, click Execute. The new settings are transmitted to the network card but it still operates with pre-transmission settings.

13. Click Finish to validate the new settings.

14. Switch the printer off for 15 seconds and on again.

Now that both Windows and the printer have been configured to use TC P/IP, the next step is to configure Windows to print to the network printer.

NINSTALLING THE NETWORK CARD SETUP UTILITY

To uninstall the Network Card Setup utility:

1. Select Start > Control Panel.

2. Select Add or Remove Programs.

3. Select AdminManager (Oki Setup Utility) and click Remove. This removes the

Network Card Setup utility from your computer.

4. Restart your computer to ensure that the utility has been fully removed.

Microsoft windows > 41

OS X

VERVIEW

This section is for administrators and it should be used in conjunction with the relevant Mac OS X manual. Please ensure your Mac has the latest Mac OS X updates installed.

To get the best results from your printer, install the Postscript Printer Description (PPD) file supplied with your printer and use this to customise the Apple PostScript d river that is builtin to the OS X. Features provided by the PPD file include:

> Supported paper types > Paper trays > Printer resolution

> Printer colour matching

NOTE The PPD file must be installed using the Oki Driver Installer to ensure that all essential files are copied.

RINTING THE CONFIGURATION PAGE

The printer’s configuration page reports information that is required for Macintosh configuration. To print a configuration page, while the printer is switched on, depress the NIC’s push-button for more than three seconds and then release.

The first six characters of the Ethernet address are the same for all network cards. The last six characters of the Ethernet address are unique to each card.

ETTING UP A NETWORK PRINTER

1. If the printer does not already have an IP address, us e t he Printer Setup Utility to

assign an IP address. See “The printer setup utility interface” on page 44 To do this, you will need to know the printer's MAC address. This can be found on the

print server's network summary printout. See “Self-diagnostic test” on page 7.

2. Install the printer driver software. This copies the printer driver files to the correct location on your Mac OS X system.

3. Make a connection to the printer by USB, TCP/IP, Rendezvous or AppleTalk. See

“Connecting to your printer” on page 50

4. If required, enable hardware device options such as additional paper tr ays or printer hard disk. See “Configuring printer hardware options” on page 51

MACOS

You can use the Setup Utility to:

PRINTER SETUP UTILITY

> Assign IP addresses and modify TCP/IP settings > Configure settings for Netware, EtherTalk, NetBEUI and SNMP

The Printer Setup Utility is a powerful MacOS-based utility for configuring all print server functions using a graphical user interface.

Mac OS X > 42

NSTALLING THE PRINTER SETUP UTILITY

1. Insert the DVD into the DVD-ROM drive.

2. Open the Printer Setup Utility folder and double-click Installer.

3. Select the destination directory, then click Next.

4. Ensure the Yes option is selected to activate the utility, then click Finish.

Mac OS X > 43

THE

PRINTER SETUP UTILITY INTERFACE

The Printer Setup Utility au t o -d i sc o vers Oki compatible network cards.

1. Select the correct printer NIC to configure and choose Setup menu > Oki Device Setup.

2. At the prompt, enter the Admin password.

NOTE The default admin password is the last six digits of the MAC Address, minus any punctuation marks. e.g., for a MAC (Ethernet) Address of 00:80:87:A4:55:79, the password would be A45579. Password is case sensitive.

3. Select the TCP/IP tab and assign your machine’s IP address.

4. Click Apply.

Mac OS X > 44

MENU OPTIONS

Discover Printers

Locates and lists all printers in your network which have an Oki compatible network card installed.

System Status

Displays the network card summary details.

Oki Device Setup

Use this to configure the network card settings (requires Admin password).

General Tab

The General tab allows you to change the admin password.

1. Click Change.

2. Enter the current value, then enter the new value and re-enter it under Confirm ….

3. Click OK.

4. Click Apply.

Mac OS X > 45

TCP/IP Tab

ITEM COMMENTS

Use TCP/IP Protocol Enable/disable TCP/IP protocol. Use DHCP/BOOTP Click to select this item if the IP address, subnet

mask, default gateway and IP addresses for DNS primary server and secondary servers are retrieved from the DHCP or BOOTP server.

IP Address Set the IP address of the selected network interface

card.

Subnet Mask Set the subnet mask of the selected network

interface card.

Netware Tab

Default Gateway Set the default gateway of the selected network

Use IPv6 Function Use to enable/disable IPv6.

interface card.

ITEM COMMENTS

Use NetWare Protocol Enable/disable NetWare protocol. Print Server Name Set a Print Server name. Frame Type Set the primary NetWare frame type. Operation Mode Select the NetWare mode:

PSERVER Mode (the default) RPRINTER Mode

Bindery Setup Configure Bindery mode items, including:

File Server to be connected.

Password. Set a password for the

Job Polling Time Set the print job

Specify up to 8 file servers to connect.

Print Server.

polling interval in seconds.

NDS Setup Set the NDS Tree and Context where the Print

Server was created.

Printer Name Set the NetWare printer object name.

Mac OS X > 46

EtherTalk Tab

ITEM COMMENTS

NetBEUI Tab

Use EtherTalk Protocol

Printer Name Set the EtherTalk Printer object name. Zone Name Set t he name of the zone to which the print server

Enable/disable EtherTalk protocol.

belongs.

ITEM COMMENTS

Use NetBEUI Protocol

Enable/disable NetBEUI protocol.

Short Printer Name Set a name for the print server. Workgroup Set a name for the work group to which the print server

belongs.

Comment Set the comments for the print server.

Mac OS X > 47

SNMP Tab

ITEM COMMENTS

SysContact Set the printer manager name. SysName Set the printer model name. SysLocation Set the location where the printer is installed.

Configuration via HTTP

NOTE To apply configuration changes using a web browser, you will be prompted for a username and password. The username is root and the default password is aaaaaa.

Displays the printer web page.

Environment setup

Use this to configure the utility preferences for broadcast addresses for TCP/IP protocol and Time Out.

Mac OS X > 48

TCP/IP Tab

ITEM COMMENTS

Timeout Tab

Set Broadcast Address

Add Click Add to add the address to the list in the box. Delete Select an address in the box, then click Delete to

Set broadcast addresses that are used to search Oki network interface cards using the TCP/IP protocol.

remove it.

ITEM COMMENTS

Set Timeout: Printer Search

Search Every (20-180sec)

Set the response waiting time from the network card in seconds. Default is 30 seconds.

Set Timeout: Data Send/ Receive

Time Outs (1-60sec)

Set time out between AdminManager and the network interface card in seconds. Default is 5 seconds.

Retry (1-5)

Sets how many times AdminManager will retry to transmit/receive data to/from the network interface card. Default is 3 retries.

Mac OS X > 49

ONNECTING TO YOUR PRINTER

NOTE The steps below are for Snow Leopard (10.6) and Leopard (10.5) Operating Systems. The principle of connecting to your printer is the same, though the steps may vary for different Operating Systems. Please refer to the ReadMe file on the driver DVD.

NOW LEOPARD

(10.6) AND L

EOPARD

(10.5)

USB

1. Choose Apple Menu > System Preferences > Print & Fax.

2. If the printer is already in the li s t of pr i nt ers, click “-” to remove it.

NOTE This is necessary as Leopard may not be using the correct printer driver files.

3. Click “+” to add a new printer.

4. Ensure the Default tab is selected and select your printer from the list.

> Your printer is displayed as type USB in the list of available printers. > Ensure that the Print Using: selection matches your printer. If Generic

PostScript Printer is displayed, select a dr iver that matches.

5. Click Add.

6. Click Configure... and ensure the hardware options displayed match your printer.

NOTE Hardware options are not configured automatically.

The printer is added to the list of printers.

7. Restart your computer.

Bonjour

1. Choose Apple Menu > System Preferences > Print & Fax.

2. Click “+”.

3. Select your printer model from the Default Browser.

4. Click Add….

5. Depending on the connection type, you may be prompted to configure any additi onal

printer hardware options. If your printer has options such as a storage device or second tray, switch on the relevant options.

Mac OS X > 50

AppleTalk (Leopard only)

NOTE AppleTalk is not supported in Snow Leopard.

1. Choose Apple Menu > System Preferences > Print & Fax.

2. Click “+”.

3. Select your printer model from the Default Browser.

4. Click Add….

5. Depending on the connection type, you may be prompted to configure any additi onal

printer hardware options. If your printer has options such as a storage device or second tray, switch on the relevant options.

TCP/IP Connection

1. Choose Apple Menu > System Preferences > Print & Fax.

2. Click “+”.

3. Click the IP Printer button.

4. From the Protocol menu, choose Line Printer Daemon – LPD.

5. Enter the printer's IP address in Address.

To find the printer's IP address, you can print a configuration page from the printer's operator panel. Refer to “Printing the configuration page” on page 42.

6. Check the correct PPD file for your printer is selected in the Print Using menu.

7. Click Add.

8. You will be prompted to configure any additional printer hardware options. If your

printer has options such as a storage device or second tray, switch on the relevant options. Refer to “Configuring printer hardware options” on page 51.

ONFIGURING PRINTER HARDWARE OPTIONS

NOTE Applies to IP and Rendezvous network connections only.

If you have added additional hardware, for example additional paper trays, to your printer these must be enabled in the printer driver.

1. Choose Apple Menu > System Preferences > Print and Fax.

2. Click the Printers menu, and choose Show Info.

3. From the popup menu, select Installable Options.

4. Select any options appropriate to your hardware, and click Apply Changes.

Mac OS X > 51

UNIX

NOTE Not all utilities are provided for every operating system. Please check with your User’s Guide and your support websit e for latest information. This section applies to devices which support PCL or Postscript.

VERVIEW

The printer supports many protocols such as LPD, FTP, TELNET, SNMP and IPP, and works within the UNIX environment.

To use the network card within the UNIX environment, the following steps are required:

ONFIGURATION

ETWORK INTERFACE CARD SETTING

The first step in installing the network card under UNIX is to set up the IP address, Subnet Mask and Gateway. This section explains one way to set them up from a UNIX workstation.

> The network addresses used in this manual are shown as examples only. Network

addresses used in your installation must be generated for your own network.

> Log in as root to change the configuration of the printer. > If an incorrect IP address, Subnet Mask or Gateway is entered, the network may go

down or other damage may occur. Check the address with your network manager.

The following explanation uses Sun Solaris 2.8 (Solaris 8) as an example. The actual commands may differ between versions of UNIX, so refer to the workstation manuals for more information.

NOTE If you do not have superuser rights, the network manger should conduct the configuration.

1. Log in as root to the workstation.

2. If the printer does not have an IP address already assigned, use the arp command t o

set a temporary IP address.

Example: for IP address 192.68.20.127 and network card address 00:80:87:01:00:D2

# arp –s 192.168.20.127 00:80:87:01:00:D2

3. Use the ping command to confirm the connection with the network interface card. Example: for IP address 192.168.20.127

# ping 192.168.20.127

If there is no reply, there is a problem with the configuration of the IP address (the IP address has already been set manually or dynamically), or with the network. Reset the network interface card settings to default and try to set a temporary IP address.

If you still have the problem after resetting the network interface card, consult the network manager.

UNIX > 52

4. Login to the network interface card using TELNET.

Example: Logging in to IP address 192.168.20.127

#telnet 192.168.20.127 Trying 192.168.20.127 Connected to 192.168.20.127 Escape character is ‘^’. myprn TELNET server (Ver 01.01). login: root ‘root’ user needs password to login. password: User ‘root’ logged in. No. MENU (level.1) 1 : Status / Information 2 : Device Config 3 : Network Config 4 : Security Config 5 : Maintenance 99 : Exit setup Please select (1- 99)?

5. Type 1 and press the Enter key. Perform the following settings:

Please select (1- 99)? 1 No. MENU (level.2) 1 : Device 2 : Network 3 : Version 99 : Back to prior menu Please select (1- 99)?

6. Logout from the network interface card. Turn the printer off for about 15 seconds and on again to validate the settings.

LPD Printing

Line Printer Daemon (LPD) is the most common protocol for printing with TCP/IP to a network printer. Refer to the workstation’s manual for details of lpr and lp commands. The following explanation in this section uses the printing of print file test.prn with printer name myprn_lp as an example.

UNIX > 53

Logical printers

The printer’s network interface includes three logical printers.

> lp must be used for printing a file created using the printer driver. > sjis must be used for printing a text file of Shift JIS Kanji code. > euc must be used for the printing a text file of the EUC Kanji code.

LOGICAL PRINTER PRINTER FUNCTION

lp For direct output sjis For Shift JIS Kanji converted output euc For EUC Kanji converted output

> sjis and euc function only as PostScript printers.

BSD-based UNIX

Print using the lpr command.

# lpr myprn_lp test.prn

If the lprm command is used, the print job is cancelled.

Example: To delete a print job (Job ID 123) on the myprn_lp

# lprm myprn_lp 123

Verify the printer status using the lpq command.

> The result of lpq may not be displayed correctly depending on UNIX operating

system specification.

# lpq myprn_lp

System V-based UNIX

Print using the lp command.

# lp –d myprn_lp_lp test.prn

Delete a print job using cancel command.

Example: To delete a print job (Job ID 456) in the myprn_lp

# cancel myprn_lp -456

Verify the printer status using the lpstat command.

# lpstat

The result of lpstat may not be displayed correctly depending on UNIX operating system specification (e.g. Solaris 2.x).

FTP printing

FTP (File Transfer Protocol) is used for transferring a file with TCP/IP. If the print data is sent to a logical printer via FTP, it is printed.

Refer to the workstation’s manual for details of the ftp command. The following explanation uses print file test.prn with printer name myprn_lp as an example.

UNIX > 54

OGICAL DIRECTORIES

The printer’s network interface includes three logical directories.

LOGICAL DIRECTORY PRINTER FUNCTION

lp For direct output sjis For Shift JIS Kanji converted output euc For EUC Kanji converted output

> jis and euc function only as PostScript printers. > You can not send data to the root directory.

1. Log in to the network interface card.

When printing with ftp, use any values for name and password. However, if the user name is root, the password set under TELNET or the utility is required. See the appropriate section for details.

Example: Logging in with host name myprn (or IP address 192.168.20.127).

# ftp myprn (or ftp 192.168.20.127) Connected to myprn 220 EthernetBoard 8100e Ver 01.50 FTP Server Name (myprn:<none>) : root 331 Password required. Password:<CR> 230 User Logged in ftp>

The network card logical directory structure is hierarchical. Move to the logical directory; it is not possible to output print data to the root directory.

2. Move to the preferable logical directory using the cd command. Example: moving to the lp directory and confirming the current directory.

ftp> cd /lp 250 Command OK. ftp> pwd 257 ”/lp” is current directory ftp>

3. Configure the transfer mode. There are two types of transfer mode: BINARY mode, in which the file content is

output as it is and ASCII mode, which converts the LF code to the CR+LF code. If a binary file converted by the printer driver is transferred, the transfer mode has to be BINARY mode.

Example: Changing transfer mode to binary mode and verifying the current mode:

ftp> type binary 200 Type set to I. ftp> type Using binary mode to transfer files. ftp>

UNIX > 55

4. Transfer the print data to the network card us ing the put c ommand. Two methods of file transfer using the put command are available.

Example: Transferring print data test.prn

ftp> put test.prn

Example: Transferring print data specified by absolute path/users/test/test.prn

ftp> put /users/test/test.prn

5. Logout from the network card using the quit command.

ftp> quit

Three states can be verified using the quote command stat: the IP address, login user name and transfer mode. In addition, printer status can be verified by specifying the directory after the stat (lp, sjis, euc).

Example: Displaying network card st at us

ftp> quote stat 211-FTP server status: Connected to: 192.168.20.10.000.00 User logged in: root Transfer type: BINARY Data connection: Closed. 211 End of status. ftp>

Example: Displaying the network card status (directory name: lp)

ftp> quote stat /lp 211-FTP directory status: Ready 211 End of status ftp>

UNIX > 56

ROUBLESHOOTING

The network addresses used in this manual are shown for example only. Network addresses used in your installation must be generated from your own network.

ELF-DIAGNOSTIC TEST

RINTER DOES NOT PRINT

> Check that your printer is switched on. > Check the printer status. > Ensure that the printer is connected to your computer.

NG IS

If NG is printed in the self-diagnostic test or a Flash ROM Check Registers NG:

1. Turn the printer off for 15 seconds and then on again.

2. Press the reset button, located close to the Network Interface Panel at the back of

PRINTED IN THE SELF-DIAGNOSTIC TEST

your printer, to re-initialize it.

TCP/IP

OMPUTER CANNOT FIND THE NETWORK INTERFACE CARD

Carry out the following procedures to veri fy the printer settings:

> Turn the printer off for 15 seconds and then on again. > Confirm the network interface is enabled on the printer. > Check there is a response to the PING command. > Check that the network cable is correctly connected and that the green LED close to

the printer’s network interface is lit. If not, change the cable and try again.

> Run the Self-diagnostic test as described on page 7. > Check the IP Address, Subnet Mask and Gateway are correct. > Check that the TCP/IP protocol is set to Enable. > Reset the network interface card to factory default settings. > If DHCP, BOOTP and RARP are not used, ensure they have been set to Disable.

ANNOT PRINT WITH LPR AND FTP

> Turn the printer off for 15 seconds and then on again. > Check there is a response to the ping command. > Check the network cable is correctly connected. > Change the cable and try again. > Check the host name and IP address are configured in the workstation. > Check the printer port name is configured in the workstation. > There are three port names: lp, euc and sjis. Use lp by default as euc and sjis are

specific to PostScript printers.

Troubleshooting > 57

WEB

BROWSER

If you are using the Web browser to configure your machine settings, but do not see the most recent settings displaying on the Web page, you should temporarily switch off your browser’s page caching. To prevent your web browser caching the printer web pages, carry out the following steps as appropriate for your web browser.

NOTE Keeping this setting enabled all the time may slow down web browsing. You may want to revert to the browser default setting once you have finished using the printer web page.

ICROSOFT INTERNET EXPLORER

1. Select Tools > Internet Options.

2. Select the General tab and, in Temporary Internet files, click Settings.

3. Under Check for newer versions of stored pages, select Every visit to the page.

4. Click OK.

OZILLA FIREFOX

1. In the Firefox address bar, type about:config.

2. In the Filter field, type frequency.

3. Double click on the entry browser.cache.check_doc_frequency.

4. Change the Va lue to 1.

> 0: Check once per browser session > 1: Check every time I view the page > 2: Never check (always use cached page) > 3 (default): Check when the page is out of date (automatically determined)

Troubleshooting > 58

5. Click OK.

Troubleshooting > 59

OKI MC851, MC861 Network Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

ITEM SPECIFICATION

1. Select IP Address Setup from the Setup menu.

MENU OPTIONS

UNIX

TCP/IP
