Nokia 3520 Service Manual 3 rh21 parts

Nokia Customer Care

RH-21 Series Transceivers

Parts Lists

Issue 2 07/2004  2004 Nokia Corporation. Page 1

Company Confidential

RH-21 Company Confidential
Parts Lists Nokia Customer Care

Page 2  2004 Nokia Corporation. Issue 2 07/2004

Company Confidential RH-21

Nokia Customer Care Parts Lists

Contents

Page No

Component Layout......................................................................................................... 5

3520 Component Layout - Top ....................................................................................5

Exploded Views ............................................................................................................. 7

Main Assembly ............................................................................................................7

Assembly Parts List .....................................................................................................7

Internal Module Assembly Structure ...........................................................................8

Assembly Parts List .....................................................................................................8

D-cover Assembly .......................................................................................................9

Assembly Parts List .....................................................................................................9

Parts List ...................................................................................................................... 10

RH-21 (3520) — EDMS Issue 2.10 Code: 0202092 .................................................10

Issue 2 07/2004  2004 Nokia Corporation. Page 3

RH-21 Company Confidential
Parts Lists Nokia Customer Care

Page 4  2004 Nokia Corporation. Issue 2 07/2004

Company Confidential RH-21

Nokia Customer Care Parts Lists

Component Layout

3520 Component Layout - Top

Issue 2 07/2004  2004 Nokia Corporation. Page 5

RH-21 Company Confidential
Parts Lists Nokia Customer Care

Page 6  2004 Nokia Corporation. Issue 2 07/2004

Company Confidential RH-21

Nokia Customer Care Parts Lists

Exploded Views

Main Assembly

Assembly Parts List

Table 1:

Item No. Qty. Part Code Value

1 1 (Internal) Module Dual Band 0510315 DMC06652

2 1 (INTERNAL) MODULE SINGLE

BAND

3 1 Keymat Assembly - Latin 9790837 DMC06537

4 1 Keymat Assembly - Hebrew 9790846 DMC05982

5 1 A-cover Assembly - Pearl White 9491237 DMC06073

6 1 B-cover Assembly - Pearl White 9491242 DMC06032

0510318 DMC06652

Issue 2 07/2004  2004 Nokia Corporation. Page 7
