Nokia 3109 User Manual

Captain_3109_Hello Page_size: 166mm(W) x 120mm(H)

Hello

When you’ve got business to attend to, you want a practical companion that works smarter for you. That’s why you’ve made the right choice with the Nokia 3109 classic.

Reliable and functional, it’s created for your mobile lifestyle with its durable form. A large keymat and sizable active matrix display also make it easy for you to view and access your phone menu.

Not just friendly in appearance, your Nokia 3109 classic also boasts a host of handy features. Now you can check your emails on the go and get online with the easy to use xHTML browser. To transfer data, you can connect seamlessly via Bluetooth and USB. Your phone supports memory cards up to 2GB too, so you can bring your data along.

In addition to these great features, the Nokia 3109 classic includes essential features like an integrated voice recorder for taking notes or setting reminders, and a built-in music player for your entertainment.

To top it off, it’s also made for networking. Talk longer with up to 4 hours of talktime and 16 days of standby time. With 2,000 phonebook contacts at your fingertips, you can also keep your associates and loved ones closer to you.

The Nokia 3109 classic just works harder for you.

Captain_3109_ Welcome Size: 120mm(H) x 166mm(W) Colour: 1C (Black)

Welcome to

your

C M

Y CM

MY CY

CMY

Nokia

Earpiece

5-way navigation key

Use the keys to navigate through names, phone numbers, menus and settings; move the cursor; or highlight in text editing.

Tip: In standby mode, press the navigation key to quickly access these functions.

• Press to create a text message.

• Press to access calendar.

• Press to access list of contacts.

Call key

• Dials a phone number and answers a call.

• In standby mode, press to show the most recently dialled numbers.

Infrared (IR) port

Voice Mailbox key

• Press and hold to call your voice mailbox (network service).

Wireless Internet key

• Press and hold as a shortcut key for accessing mobile services.

Charger and headset connector

Please note that the phone screen displayed may not be the default screen setting.

2.5mm AV connector

phone

Power key

• Switches the phone on and off when pressed and held for a few seconds.

• Press briefly during a call or when the phone is in standby mode to enter the list of profiles.

Volume key

• Adjusts the volume of the earpiece, loudspeaker or headset (when connected to the phone).

• Press and hold the ‘volume up’ key to activate Push-to-Talk.

• Press and hold the ‘volume down’ key to activate voice dialling or voice commands.

Selection keys

• Perform the function indicated by the text above it.

• During a call, press the right selection key to activate Handsfree Loudspeaker.

End key

• Ends or rejects a call. Also exits from any function and goes to standby mode.

Quick Profile key

• Press and hold to switch between General and Silent Profile.

Mini-USB port

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 1 Jun 5, 2007 11:27:26 AM

Nokia 3109 classic User Guide

9202290

Issue 1

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 2 Jun 5, 2007 11:27:26 AM

DECLARATION OF CONFORMITY

0434

Nokia, Nokia Connecting People, Nokia Care, Vi sual Radio, and Navi are trademarks or registered trademarks of Nokia Corpor ation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Includes RSA BSAFE cryptographic or sec urity protocol software from RSA Security.

Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products and applications for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Hereby, NOKIA CORPORATION declares that this RM-274 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at www.nokia.com/phones/ declaration_of_conformity/.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 3 Jun 5, 2007 11:27:26 AM

The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the copy rights or intellectual property rights to th e third-party applications. As such, Nokia does not take any responsibility for end-user support, functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications.

BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.

Export controls This device may contain c ommodities, technology or softwa re subject to export laws and regul ations from the US and other countr ies. Diversion contrary to law is prohibited.

Check www.nokia.com/support to get the latest version of this guide, contacts, information and additional services and also to download PC Suite and other software. Consult the nearest service point and set up your phone.

920 /Issue 1

2290

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 4 Jun 5, 2007 11:27:26 AM

Contents

For your safety ...................................................7

About your device..............................................8

Network services...............................................8

Shared memory..................................................9

General information.......................................10

Access codes............................................................................10

Configuration setting service.............................................10

Download content.................................................................11

Software updates..................................................................11

Nokia support.........................................................................11

Get started.........................................................12

Install SIM card and battery................................................12

Insert a microSD card...........................................................13

Charge the battery.................................................................14

Antenna....................................................................................14

Headset.....................................................................................14

Strap...........................................................................................15

Your device........................................................15

Keys and parts.........................................................................15

Switch the device on and off..............................................16

Standby mode.........................................................................16

Flight mode..............................................................................18

Keypad lock (keyguard).......................................................18

Functions without a SIM card............................................18

Call functions....................................................19

Make a call................................................................................19

Answer or reject a call..........................................................20

Options during a call.............................................................20

Write text..........................................................21

Text modes..............................................................................21

Traditional text input...........................................................21

Predictive text input.............................................................21

Navigate the menus........................................22

Messaging.........................................................22

Text messages........................................................................22

Multimedia messages...........................................................23

Message sending process....................................................24

Postcards..................................................................................25

Flash messages.......................................................................25

Nokia Xpress audio messaging.........................................26

Memory full..............................................................................26

Folders.......................................................................................26

E-mail application..................................................................27

Instant messages...................................................................28

Voice messages......................................................................31

Info messages.........................................................................31

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 5 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 5 Jun 5, 2007 11:27:26 AM

Service commands.................................................................31

Delete messages....................................................................32

SIM messages..........................................................................32

Message settings....................................................................32

Contacts.............................................................34

Save names and phone numbers.....................................34

Save details..............................................................................34

Settings.....................................................................................34

Groups.......................................................................................35

Search for a contact..............................................................35

Copy or move contacts.........................................................35

Edit contact details................................................................35

Delete contacts.......................................................................35

Synchronize all........................................................................36

Business cards.........................................................................36

Dialing shortcuts....................................................................36

Info, service, and my numbers..........................................36

Call log................................................................37

Positioning........................................................37

Settings..............................................................38

Profiles......................................................................................38

Themes......................................................................................38

Tones.........................................................................................38

Display.......................................................................................39

Time and date.........................................................................39

My shortcuts............................................................................39

Infrared.....................................................................................40

Bluetooth..................................................................................41

Packet data..............................................................................42

Data transfer...........................................................................42

USB data cable........................................................................43

Call..............................................................................................43

Phone.........................................................................................44

Enhancements........................................................................45

Configuration..........................................................................45

Security.....................................................................................46

Software updates over the air...........................................46

Restore factory settings.......................................................47

Operator menu.................................................47

Gallery................................................................48

Folders and files.....................................................................48

Print images............................................................................48

Memory card............................................................................48

Media..................................................................49

Media player............................................................................49

Music player.............................................................................50

Voice recorder.........................................................................51

Equalizer...................................................................................51

Stereo widening.....................................................................51

Push to talk.......................................................52

PTT channels............................................................................52

Switch PTT on and off...........................................................52

Make and receive a PTT call................................................53

Callback requests...................................................................54

Add a one-to-one contact...................................................54

PTT settings.............................................................................54

Configuration settings.........................................................55

Applications......................................................55

Launch a game.......................................................................55

Contents

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 6 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 6 Jun 5, 2007 11:27:26 AM

Launch an application..........................................................55

Application options...............................................................55

Download an application....................................................56

Organizer...........................................................56

Contents

Alarm clock...............................................................................56

Calendar....................................................................................57

To-do list...................................................................................57

Notes..........................................................................................58

Calculator..................................................................................58

Timers........................................................................................58

Stopwatch................................................................................58

Web....................................................................59

Set up browsing.....................................................................59

Connect to a service..............................................................59

Browse pages..........................................................................60

Bookmarks...............................................................................60

Appearance settings.............................................................61

Security settings.....................................................................61

Download settings................................................................61

Service inbox...........................................................................62

Cache memory........................................................................62

Browser security....................................................................62

SIM services.......................................................64

PC connectivity.................................................64

Nokia PC Suite.........................................................................64

Packet data, HSCSD, and CSD...............................................64

Bluetooth..................................................................................65

Data communication applications...................................65

Enhancements........................................................................66

Battery.......................................................................................66

Nokia Bluetooth Headset BH-201.....................................66

Nokia Wireless Plug-in Car Handsfree HF-33W.............66

Nokia 1 GB microSD Card MU-22........................................67

Battery...............................................................67

Battery information..............................................................67

Nokia battery authentication guidelines.......................68

Care and maintenance....................................70

Additional safety information......................71

Small children.........................................................................71

Operating environment.......................................................71

Medical devices.......................................................................71

Vehicles.....................................................................................72

Potentially explosive environments................................72

Emergency calls......................................................................73

CERTIFICATION INFORMATION (SAR)..................................73

MANUFACTURER’S LIMITED WARRANTY.............................74

Index..................................................................78

Genuine enhancements.................................65

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 7 Jun 5, 2007 11:27:26 AM

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the device off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Do not use the device at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the device where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important inform ation stored in your device.

For your safety

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 8 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 8 Jun 5, 2007 11:27:26 AM

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone function of the device is sw itc he d on and i n ser vice. Press the end key

About your device

The wireless device described in this guide is approved for use on the EGSM 900 and GSM 1800 and 1900 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Copyright protections may prevent s ome images, music (including ringing tones), and other content from being copied, modified, transferred, or forwarded.

Network services

To use the phone you must have service from a wireless service provider. Many of the features require special

network features. These features are not available on

as many times as needed to clear the display and return to the standby mode. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 9 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 9 Jun 5, 2007 11:27:26 AM

provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such

Shared memory

The following features in this device may share memory: gallery, contacts, text messages, multimedia messages, and instant messages, e-mail, calendar, todo notes, Java™ games and applications, and note application. Use of one or more of these features may reduce the memory available for the remaining features sharing memory. Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing.

as changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as multimedia messaging (MMS), e-mail application, instant messaging, remote synchronization, and content downloading using the browser or MMS, require network support for these technologies.

Shared memory

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 10 Jun 5, 2007 11:27:26 AM

General information

Access codes

Security code

The security code (5 to 10 digits) helps to protect your

General information

phone against unauthorized use. The preset code is

12345. You can change the code, and set the phone to request the code. See "Security," p. 46.

PIN codes

The personal identification number (PIN) code and the universal personal identification number (UPIN) code (4 to 8 digits) help to protect your SIM card against unauthorized use. See "Security," p. 46.

The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is required for some functions.

The module PIN is required to access the information in the security module. See "Security module," p. 63.

The signing PIN is required for the digital signature. See "Digital signature," p. 63.

PUK codes

The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code, respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code. If the codes are not supplied with the SIM card, contact your local service provider for the codes.

Barring password

The barring password (4 digits) is required when using the Call barring service. See "Security," p. 46.

Configuration setting service

To use some of the network services, such as mobile internet services, MMS, Nokia Xpress audio messaging, or remote internet server synchronization, your device needs the correct configuration settings. For more information on availability, contact your service provider, the nearest authorized Nokia dealer, or visit the support area on the Nokia website. See "Nokia support," p. 11.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 11 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 11 Jun 5, 2007 11:27:26 AM

When you have received the settings as a configuration message and the settings are not automatically saved and activated, Configuration sett. received is displayed.

To save the settings, select Show > Save. If required, enter the PIN code supplied by the service provider .

To discard the received settings, select Exit or Show >

Discard.

Download content

You may be able to download new content (for example, themes) to your phone (network service).

Important: Use only services that you trust and that offer adequate security and protection against harmful software.

For the availability of different services, pricing, and tariffs, contact your service provider.

Software updates

Nokia may produce software updates that may offer new features, enhanced functions, or improved performance. You may be able to request these updates through the Nokia Software Updater PC application. To update the device software, you need the Nokia Software Updater application and a compatible PC with Microsoft Windows 2000 or XP operating system, broadband internet access, and a compatible data cable to connect your device to the PC.

To get more information and to download the Nokia Software Updater application, visit www.nokiaasia.com/softwareupdate or your local Nokia website.

If software updates over the air are supported by your network, you may also be able to request updates through the device.

See "Software updates over the air," p. 46. Downloading software updates may involve the

transmission of large amounts of data through your service provider's network. Contact your service provider for information about data transmission charges.

Make sure that the device battery has enough power, or connect the charger before starting the update.

Important: Use only services that you trust and that offer adequate security and protection against harmful software.

Nokia support

Support information

Check www.nokia-asia.com/3109/support or your local Nokia website for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

General information

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 12 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 12 Jun 5, 2007 11:27:26 AM

Configuration settings service

You may also download free configuration settings such as MMS, GPRS, e-mail, and other services for your device model at www.nokia-asia.com/setup.

Get started

Nokia PC Suite

You may find PC Suite and related information on the Nokia website at www.nokia-asia.com/pcsuite.

Customer service

If you need to contact customer service, check the list of local Nokia Care contact centers at www.nokia-

Get started

Install SIM card and battery

Always switch the device off and disconnect the charger before removing the battery.

For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider or other vendor.

asia.com/contactus.

Maintenance

For maintenance services, check your nearest Nokia service center at www.nokia-asia.com/repair.

This device is intended for use with a BL-5C battery. Always use original Nokia batteries. See "Nokia battery authentication guidelines," p. 68.

The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 13 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 13 Jun 5, 2007 11:27:26 AM

Slide the release button (1) to unlock and remove the back cover (2). Remove the battery as shown (3).

Open the SIM card holder (4). Insert the SIM card (5) with the contact surface facing down into the holder. Close the SIM card holder (6).

Observe the battery contacts (7), and insert the battery (8). Place the upper part of the back cover on the device (9), and close it (10).

Insert a microSD card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

1. Switch the device off, and remove the back cover

and the battery of the device.

2. Slide the memory card

holder to unlock (1).

3. Open the card holder (2),

and insert the memory card into the card holder with the contact surface facing inwards (3).

4. Close the card holder (4),

and slide the card holder to lock it (5).

5. Insert the battery, and attach the back cover to the

device.

Get started

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 14 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 14 Jun 5, 2007 11:27:26 AM

Charge the battery

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from the AC-3 or AC-4 charger.

Get started

Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

1. Connect the charger to a wall socket.

2. Connect the lead from the

charger to the socket on the bottom of your device.

If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

The charging time depends on the charger used. Charging a BL-5C battery with the AC-3 charger takes approximately 2 hours and 45 minutes while the device is in the standby mode.

Antenna

Your device has an internal antenna.

Note: As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. To optimize antenna performance and battery life, avoid contact with the antenna area when operating the device.

Headset

Warning: Listen to music at a moderate level.

Continuous exposure to high volume may damage yo ur hearing.

Pay special attention to volume level if you connect any other headsets to the device.

Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 15 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 15 Jun 5, 2007 11:27:26 AM

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

When connecting any external device or any headset, other than those approved by Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Strap

1. Open the back cover.

Your device

Keys and parts

1 — Earpiece 2 — Display

2. Hook a strap behind the clamp as shown in the picture (1) and close the back cover (2).

3 — Left selection key 4 — Call key 5 — Infrared (IR) port 6 — Navi™ key: 4-way scroll key and middle selection

key 7 — Right selection key 8 — End key 9 — Keypad 10 — Microphone 11 — Charger connector 12 — Nokia AV Connector (2.5 mm) 13 — Mini USB cable connector

Your device

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 16 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 16 Jun 5, 2007 11:27:26 AM

14 — Volume down key 15 — Volume up key 16 — Power key 17 — Loudspeaker

Your device

Switch the device on and off

To switch the device on or off, press and hold the power key. See "Keys and parts," p. 15.

If the device prompts for a PIN or a UPIN code, enter the code (displayed as ****), and select OK.

The device may prompt you to set the time and date. Enter the local time, select the time zone of your location in terms of the time difference with respect to Greenwich mean time (GMT), and enter the date. See "Time and date," p. 39.

When you switch on your device for the first time and the device is in the standby mode, you may be prompted to get the configuration settings from your service provider (network service). For more information refer to Connect to service provider

support. See "Configuration," p. 45. See

"Configuration setting service," p. 10.

Standby mode

When the device is ready for use, and you have not entered any characters, the device is in the standby mode.

Display

1 — Signal strength of the cellular network

2 — Battery charge status

3 — Indicators 4 — Name of the network or the operator logo 5 — Clock 6 — Main screen 7 — The function of the left selection key is Go to or a

shortcut to another function. See "Left selection key," p. 39.

8 — The function of the middle selection key is Menu. 9 — The function of the right selection key is Names or

a shortcut to another function. See "Right selection key," p. 40. Operator variants may have an operatorspecific name to access an operator-specific website.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 17 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 17 Jun 5, 2007 11:27:26 AM

Power saving

Your device has a Power saver and a Sleep mode feature in order to save battery power in the standby mode when no key of the device is pressed. These features may be activated. See "Display," p. 39.

Active standby

The active standby mode displays a list of selected device features and information that you can directly access.

To switch active standby on or off, select Menu >

Settings > Display > Active standby > Active standby mode > On or Off.

In the standby mode, scroll up or down to navigate in the list, and choose Select or View. The arrows indicate that further information is available. To stop navigation, select Exit.

To organize and change the active standby mode, select

Options and from the available options.

Shortcuts in the standby mode

To access the list of dialed numbers, press the call key once. Scroll to the number or name, and press the call key to call the number.

To open the web browser, press and hold 0.

To call your voice mailbox, press and hold 1.

Use keys as a shortcut. See "My shortcuts," p. 39.

Indicators

unread messages

unsent, cancel ed, or failed messages

missed call

/ Your phone is connected to the IM service, and

the availability status is online or offline.

instant messages received

The keypad is locked.

The phone does not ring for an incoming call or text

message.

The alarm clock is activated.

The countdown timer is running.

The stopwatch is running in the background.

/ The phone is registered to the GPRS or EGPRS

network.

/ A GPRS or EGPRS connection is established.

/ The GPRS or EG PRS connection is suspended (on

hold).

A Bluetooth connection is active.

/ A push-to-talk co nnection is active or suspended.

If you have two phone lines, the second phone line

is selected.

All incoming calls are diverted to another number.

Your device

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 18 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 18 Jun 5, 2007 11:27:26 AM

The loudspeaker is activated, or the music stand

is connected to the device.

Calls are limited to a closed user group.

The timed profile is selected.

Your device

/ / A headset, handsfree, or loopset is

connected to the device.

Flight mode

You can deactivate all radio frequency functions and still have access to offline games, calendar, and phone numbers.

Use the flight mode in radio sensitive environments— on board aircraft or in hospitals. When the flight mode is active,

Select Menu > Settings > Profiles > Flight >

Activate or Personalise to activate or set up the flight

mode.

To deactivate the flight mode, select any other profile.

Emergency call in flight mode, Enter the emergency number, press the call key, and select Yes when Exit

flight profile? is displayed. The phone attempts to

make an emergency call.

make or receive any calls, including emergency calls, or use other features that require network coverage. To make calls, you must first activate the phone function by changing profiles. If the device has been locked,

enter the lock code. If you need to make an emergency

is shown.

Warning: With the flight profile you cannot

call while the device is locked and in the flight profile, you may be also able to enter an official emergency number programmed in your device in the lock code field and select 'Call'. The device will confirm that you are about to exit flight profile to start an emergency call.

Keypad lock (keyguard)

To prevent accidental keypresses, select Menu, and press * within 3.5 seconds to lock the keypad.

To unlock the keypad, select Unlock, and press * within

1.5 seconds. If Security keyguard is set to On, enter the security code if requested.

To answer a call when keyguard is on, press the call key. When you end or reject the call, the keypad automatically locks.

Further features are Automatic keyguard and

Security keyguard. See "Phone," p. 44.

When the keyguard is on, calls may be possible to the official emergency number programmed into your device.

Functions without a SIM card

Several functions of your device may be used without installing a SIM card (for example, the data transfer with a compatible PC or another compatible device). Some functions appear dimmed in the menus and cannot be used.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 19 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 19 Jun 5, 2007 11:27:26 AM

Call functions

Make a call

Number dialing

1. Enter the phone number, including the area code. For international calls, press * twice for the

international prefix (the + character replaces the international access code), enter the country code, the area code without the leading 0, if necessary, and the phone number.

2. To call the number, press the call key. To adjust the volume in a call, press the volume key up or down.

3. To end the call or to cancel the call attempt, press the end key.

You can search for a name or phone number that you have saved in Contacts. See "Search for a contact," p. 35. Press the call key to call the number.

To access the list of dialed numbers, press the call key once in the standby mode. To call the number, select a number or name, and press the call key.

Dialing shortcuts

Assign a phone number to one of the number keys, 2 to

9. See "Dialing shortcuts," p. 36.

Call the number in one of the following ways: Press a number key, then the call key. OR If Speed dialling is set to On, press and hold a number

key until the call begins. Further details are described in Speed dialling. See

"Call," p. 43.

Enhanced voice dialing

You can make a phone call by saying the name that is saved in the contact list of the device.

Voice commands are language-dependent. Set the

Voice recognition language before using voice

dialing. See "Phone," p. 44.

Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialing in all circumstances.

Call functions

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 20 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 20 Jun 5, 2007 11:27:26 AM

1. In the standby mode, press and hold the right selection key or the volume down key. A short tone sounds, and Speak now is displayed.

2. Speak the name of the contact you want to dial clearly. If the voice recognition is successful, a list with matches is shown. The device plays the voice command of the first match on the list. If it is not

Call functions

the correct command, scroll to another entry.

Using voice commands to carry out a selected device function is similar to voice dialing. See "Voice commands," p. 40.

Answer or reject a call

To answer an incoming call, press the call key. To end the call, press the end key.

To reject an incoming call, press the end key. To mute the ringing tone, select Silence.

To answer a waiting call during an active call (network service), press the call key. The first call is put on hold. To end the active call, press the end key. You may also activate the Call waiting function. See "Call," p. 43.

Options during a call

Many of the options that you can use during a call are network services. For availability, contact your service provider.

During a call, select Options and from the following options:

Call options are Mute or Unmute, Contacts, Menu,

Lock keypad, Record, Voice clarity, Loudspeaker or Handset.

Network options are Answer or Reject, Hold or

Unhold, New call, Add to conference, End call, End all calls, and the following:

• Send DTMF — to send tone strings

• Swap — to switch between the active call and the

call on hold

• Transfer — to connect a call on hold to an active call and disconnect yourself

• Conference — to make a conference call

• Private call — to have a private discussion in a

conference call

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 21 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 21 Jun 5, 2007 11:27:26 AM

Write text

Text modes

To enter text (for example, when writing messages) you can use traditional or predictive text input.

When you write text, press and hold Options to toggle between traditional text input, indicated by

predictive text input, indicated by languages are supported by predictive text input.

The character cases are indicated by To change the character case, press #. To change from the letter to number mode, indicated by hold #, and select Number mode. To change from the

number to the letter mode, press and hold #.

To set the writing language, select Options > Writing

language.

. Not all

, and

, , and .

, press and

Traditional text input

Press a number key, 2 to 9, repeatedly until the desired character appears. The available characters depend on the selected writing language.

If the next letter you want is located on the same key as the present one, wait until the cursor appears and enter the letter.

To access the most common punctuation marks and special characters, repeatedly press the number key 1 or press * to select a special character.

Predictive text input

Predictive text input is based on a built-in dictionary to which you can also add new words.

1. Start writing a word, using the keys 2 to 9. Press each key only once for one letter.

2. When you finish writing the word and it is correct, to confirm it by adding a space, press 0.

If the word is not correct, press * repeatedly, and select the word from the list.

If the ? character is displayed after the word, the word you intended to write is not in the dictionary. To add the word to the dictionary, select Spell. Enter the word using traditional text input, and select

Save. To write compound words, enter the first part

of the word, and press the scroll key right to confirm it. Write the last part of the word, and confirm the word.

Write text

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 22 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 22 Jun 5, 2007 11:27:26 AM

3. Start writing the next word.

Navigate the menus

The device offers you an extensive range of functions that are grouped into menus.

1. To access the menu, select Menu.

2. Scroll through the menu, and select an option (for

Navigate the menus

example, Settings).

3. If the selected menu contains further submenus, select one (for example, Call).

4. If the selected menu contains further submenus, repeat step 3.

Messaging

You can read, write, send, and save text, multimedia, email, audio, and flash messages and postcards. All messages are organized into folders.

Text messages

Your device supports the sending of text messages beyond the character limit for a single message. Longer messages are sent as a series of two or more messages.

Your service provider may charge accordingly.

5. Select the setting of your choice.

6. To return to the previous menu level, select Back. To exit the menu, select Exit.

To change the menu view, select Options > Main

menu view > List or Grid.

To rearrange the menu, scroll to the menu to be moved, and select Options > Organise > Move. Scroll to where you want to move the menu, and select OK. To save the change, select Done > Yes.

Characters that use accents or other marks, and characters from some language options, take up more space, limiting the number of characters that can be sent in a single message.

With the short message service (SMS) you can send and receive text messages and receive messages that can contain pictures (network service).

Before you can send any text message, you must save your message center number. See "Message settings," p. 32.

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 23 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 23 Jun 5, 2007 11:27:26 AM

To check SMS e-mail service availability and to subscribe to the service, contact your service provider. You can save an e-mail address in Contacts. See "Save details," p. 34.

Write and send a text message

1. Select Menu > Messaging > Create message >

Text message.

2. Enter one or more phone numbers or e-mail addresses in the To: field. To retrieve a phone number or e-mail address, select Add.

3. For a SMS e-mail, enter a subject in the Subject: field.

4. Write your message in the Message: field. An indicator at the top of the display shows the total

number of characters left and the number of messages needed for sending. For example, 673/2 means that there are 673 characters left and that the message will be sent as a series of 2 messages.

5. To send the message, select Send. See "Message sending process," p. 24.

Read and reply to a text message

1. To view a received message, select Show. To view it later, select Exit.

2. To read the message later, select Menu >

Messaging > Inbox.

unread messages in the inbox.

is shown if you have

3. To reply to a message, select Reply and the message type.

4. Create the reply message.

5. To send the message, select Send. See "Message sending process," p. 24.

Multimedia messages

Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depend ing on the receiving device.

The wireless network may limit the size of MMS messages. If the inserted picture exceeds this limit, the device may make it smaller so that it can be sent by MMS.

A multimedia message can contain text and objects such as images, sound clips, or video clips.

To check availability and to subscribe to the multimedia messaging service (MMS), contact your service provider. See "Message settings," p. 32.

Write and send a multimedia message

1. Select Menu > Messaging > Create message >

Multimedia.

2. Create your message. Your device supports multimedia messages that

contain several pages (slides). A message can contain a calendar note and a business card as attachments. A slide can contain text, one image,

Messaging

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 24 Jun 5, 2007 11:27:26 AM

Cyan

Magenta

Yellow

Black

file:/D:/temp/overmode/GUID-1CEEB162-7A20-44BD-B810-5A0A723017F0.20070605111227243.en1181031959639/en/1/GUID-99309606-A5AF-4368-A45B-BF2275776152.xml Page 24 Jun 5, 2007 11:27:26 AM

and one sound clip; or text and a video clip. To insert a slide in the message, select New; or select

Options > Insert > Slide. To insert a file in the

message, select Insert.

3. To view the message before sending it, select

Messaging

Options > Preview.

4. To send the message, select Send.

5. Enter one or more phone numbers or e-mail addresses in the To: field. To retrieve a phone number or e-mail address, select Add.

6. For an SMS e-mail, enter a subject in the Subject: field.

7. To send the message, select Send. See "Message sending process," p. 24.

Write and send a multimedia plus message

Any content can be added to the multimedia plus message. Such content might be images, video clips, sound clips, business cards, calendar notes, themes, streaming links, or even unsupported files (for example, files received with an e-mail).

1. Select Menu > Messaging > Create message >

Multimedia plus.

2. Enter one or more phone numbers or e-mail addresses in the To: field. To retrieve a phone number or e-mail address, select Add.

3. Enter a subject and write your message.

4. To insert a file in the message, select Insert or

Options > Insert and the file type.

5. To view the message before sending it, select

Options > Preview.

6. To send the message, select Send. See "Message sending process," p. 24.

Read and reply to a multimedia message

Important: Exercise caution when opening

messages. E-mail messages or multimedia message objects may contain malicious software or otherwise be harmful to your device or PC.

1. To view the received message, select Show. To view it later, select Exit.

2. To view the whole message if the received message contains a presentation, select Play. To view the files in the presentation or the attachments, select

Options > Objects or Attachments.

3. To reply to the message, select Options > Reply and the message type.

4. Create the reply message.

5. To send the message, select Send. See "Message sending process," p. 24.

Message sending process

To send the message, select Send. The phone saves the message in the Outbox folder, and the sending starts.

Cyan

Magenta

Yellow

Black
