Nokia 2660 Flip User guide

Nokia 2660 Flip

User guide

Isyu 2022-08-20 fil-PH

Nokia 2660 Flip User guide

Index

1 Tungkol sa gabay para user na ito 4

2 Magsimula 5

Keys and parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Set up and switch on your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

I-charge ang iyong telepono . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3 Mga tawag, contact, at mensahe 11

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Send messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4 I-personalize ang iyong telepono 13

Change tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Change the look of your home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

5 Camera 15

Photos and videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6 Bluetooth 16

Bluetooth® connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

7 Orasan, kalendaryo, at calculator 17

Alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

8 Empty your phone 18

Restore factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 2

Nokia 2660 Flip User guide

9 Impormasyon ng produkto at kaligtasan 19

Para sa iyong kaligtasan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Mga emergency na tawag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Pangangalagaan ang iyong device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Recycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Simbolo ng nakaekis na wheelie bin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Impormasyon sa baterya at charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Maliliit na bata . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Mga medical na device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Mga naka-implant na medical na device . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Pandinig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Protect your device from harmful content . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Mga Sasakyan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Mga kapaligirang potensyal na sumasabog . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Impormasyon sa sertipikasyon (SAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Tungkol sa Digital Rights Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Copyrights and other notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 3

Nokia 2660 Flip User guide

1 Tungkol sa gabay para user na ito

Mahalaga: Para sa mahalagang impormasyon tungkol sa ligtas na paggamit ng iyong device at

baterya, basahin ang impormasyong “Para sa iyong kaligtasan” at “Kaligtasan ng Produkto” sa
naka-print na gabay para sa user, o sa www.nokia.com/support bago mo gamitin ang device.
Alamin kung paano magsimula sa iyong bagong device, basahin ang naka-print na gabay para
sa user.

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 4

Nokia 2660 Flip User guide

2 Magsimula

KEYS AND PARTS

Your phone

This user guide applies to the following models: TA-1469, TA-1474, TA-1480, TA-1478, TA-

1491.

1. Call key

2. Shortcut key

3. Left selection key

4. Scroll key

5. Earpiece

6. Right selection key

7. Back key

8. Power/End key

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 5

9. Camera

10. Flash

11. Microphone

12. USB connector

13. Headset connector

14. Volume keys

15. SOS call key

16. Charging cradle connector

Nokia 2660 Flip User guide

Do not connect to products that create an output signal, as this may damage the device. Do
not connect any voltage source to the audio connector. If you connect an external device
or headset, other than those approved for use with this device, to the audio connector, pay
special attention to volume levels. Parts of the device are magnetic. Metallic materials may be
attracted to the device. Do not place credit cards or other magnetic storage media near the
device, because info stored on them may be erased.

Some of the accessories mentioned in this user guide, such as charger, headset, or data cable,
may be sold separately.

Note: You can set the phone to ask for a security code to protect your privacy and personal
data. Select Menu > Settings > Security > Keyguard > Security code and enter a code.
Note, however, that you need to remember the code, as HMD Global is not able to open or
bypass it.

SET UP AND SWITCH ON YOUR PHONE

Nano-SIM

Important: This device is designed to be used with a nano-SIM card (see figure) only. Use of

incompatible SIM cards may damage the card or the device, and may corrupt data stored on
the card.

Tandaan: I-off ang device at idiskonekta ang charger at anumang iba pang device bago
mag-alis ng anumang mga takip. Iwasang hawakan ang mga electronic na bahagi habang
pinapalitan ang anumang mga takip. Palaging iimbak at gamitin ang device nang nakakabit ang
anumang takip.

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 6

Nokia 2660 Flip User guide

Open the back cover

1. Put your fingernail in the small slot at the top of the phone, lift and remove the cover.

2. If the battery is in the phone, lift it out.

Insert the SIM card

Slide the SIM card in the SIM card slot with the contact area face down.

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 7

Nokia 2660 Flip User guide

Insert the second SIM

If you have a dual-SIM phone, slide your SIM card in the SIM1 slot and the second SIM in the
SIM2 slot. Both SIM cards are available at the same time when the device is not being used, but
while one SIM card is active, for example, making a call, the other may be unavailable.

Tip: Para malaman kung makakagamit ng 2 SIM card ang iyong telepono, tingnan ang label sa
sales box. Kung may 2 IMEI code sa label, dual-SIM ang telepono mo.

Insert the memory card

1. Slide the memory card holder down and
open it up.

2. Place the memory card in the slot.

3. Close down the holder and slide it up to
lock it in place.

4. Put back the battery.

5. Put back the back cover.

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 8

Nokia 2660 Flip User guide

Tip: Use a fast, up to 32 GB microSD memory card from a well-known manufacturer.

I-on ang iyong telepono

Pindutin at diinan ang  key.

I-CHARGE ANG IYONG TELEPONO

Ang iyong baterya ay na-charge nang bahagya sa factory, ngunit maaaring kailanganin mo itong
i-charge muli bago mo magamit ang iyong telepono.

I-charge ang baterya

1. Isaksak ang charger sa isang saksakan.

2. Ikonekta ang charger sa telepono. Kapag tapos na, alisin ang pagkakasaksak ng charger sa
telepono, pagkatapos ay alisin sa saksakan.

Kung ganap na nadiskarga ang baterya, maaaring tumagal nang ilang minuto bago lumabas ang
indicator ng pag-charge.

Tip: Maaari mong gamitin ang pag-charge gamit ang USB kapag walang available na saksakan.
Maaaring maglipat ng data habang china-charge ang device. Malaki ang pagkakaiba ng lakas
ng power ng pagcha-charge gamit ang USB, at maaaring matagal bago magsimula ang pag­charge at magsimulang gumana ang device. Tiyaking naka-on ang iyong computer.

KEYPAD

Use the phone keys

• To see the apps and features of your phone, on the home screen, select Menu .

• To go to an app or feature, press the scroll key up, down, left, or right. To open the app or
feature, press the scroll key.

• To go back to the home screen, press the end key.

• To change the volume of your phone during a call or when listening to the radio, press the
volume keys.

Lock the keypad

To lock the keys, close the fold. To unlock the keys, press the scroll key and select Unlock >

* .

© 2022 HMD Global Oy. Nakalaan ang lahat ng karapatan. 9
