Nilfisk UHR 70-1700 User Manual

Advolution™ 2710 UHR 70-1700

INSTRUCTIONS FOR USE INSTRUCCIONES DE USO ADVANCE MODELS 56422000, 56422002 NILFISK MODEL 56422001

A-English B-Español

3/06 Form No. 56041634

WEEE SYMBOL INFORMATION

English

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate

collection systems)

This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.

Español

Eliminación correcta de este producto (material eléctrico y electrónico de descarte)

(Aplicable en la Unión Europea y en países europeos con sistenmas de recogida selectiva de residuos)

La presencia de esta marca en el producto o en el material informativo que lo acompaña, indica que al finalizar su vida útil no deberá eliminarse junto con otros residuos domésticos. Para evitar los posibles daños al medio ambiente o a la salud humana que representa la eliminación incontrolada de residuos, separe este producto de otros tipos de residuos y recíclelo correctamente para promover la reutilización sostenible de recursos materiales.

Los usuarios particulares pueden contactar con el establecimiento donde adquirieron el producto, o con las autoridades locales pertinentes, para informarse sobre cómo y dónde pueden llevarlo para que sea sometido a un reciclaje ecológico y seguro.

Los usuarios comerciales pueden contactar con su proveedor y consultar las condiciones del contrato de compra. Este producto no debe eliminarse mezclado con otros residuos comerciales.

TABLE OF CONTENTS

Page

Introduction ........................................................................................... A-3

Parts and Service ................................................................................. A-3

Nameplate ............................................................................................ A-3

Uncrating the Machine ..........................................................................A-3

Important Safety Instructions ................................................................ A-4

Importantes consignes de sécurité ....................................................... A-5

Know Your Machine .....................................................................A-6 – A-7

Preparing the Machine for Use

Batteries ............................................................................................... A-8

Installation of the Burnishing Pad ......................................................... A-9

Installation of the Dust Collection Bag ................................................ A-10

Operating the Machine

Before Each use ................................................................................. A-11

Plan Your Floor Burnishing ................................................................. A-11

Operating The Machine ...................................................................... A-11

Maintenance

After Use .............................................................................................A-12

Maintenance Schedule ....................................................................... A-12

Lubricating the Machine .....................................................................A-12

Steering Chain Tension ......................................................................A-12

Electromagnetic Brake .......................................................................A-12

Charging the Batteries ........................................................................ A-13

General Machine Troubleshooting

Error Display ....................................................................................... A-14

Swirl Marks ......................................................................................... A-14

Circles on the Floor ............................................................................A-14

Floor Finish Removed ........................................................................A-14

Machine Wobbles During Operation ...................................................A-14

Machine Does Not Run ......................................................................A-14

Technical Speciﬁ cations ..................................................................... A-15

ENGLISH / A-3

INTRODUCTION

This manual will help you get the most from your Nilﬁ sk-Advance Advolution™ 2710 / UHR 70-1700. Read it thoroughly before operating the machine.

Note: Bold numbers in parentheses indicate an item illustrated on pages A-6 – A-7.

This product is intended for commercial use only.

PARTS AND SERVICE

Repairs, when required, should be performed by Nilﬁ sk-Advance service personnel using Nilﬁ sk-Advance original replacement parts and accessories.

Call Nilﬁ sk-Advance for repair parts or service. Please specify the Model and Serial Number when discussing your machine.

NAME PLATE

The Model and Serial Number of your machine are shown on the Nameplate on the machine. This information is needed when ordering repair parts for the machine. Use the space below to note the Model and Serial Number of your machine for future reference.

MODEL ________________________________________________

SERIAL NUMBER ________________________________________

UNCRATING

When the machine is delivered, carefully inspect the shipping packaging and the machine for damage. If damage is evident, save the shipping carton (if applicable) so that it can be inspected. Contact the Nilﬁ sk-Advance Customer Service Department immediately to ﬁ le a freight damage claim. Refer to the unpacking instruction sheet included with the machine to remove the machine from the pallet.

FORM NO. 56041634 - Advolution™ 2710 / UHR 70-1700 - A-3

A-4 / ENGLISH

IMPORTANT SAFETY INSTRUCTIONS

This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and ofﬁ ces other than normal residential housekeeping purposes.

Read all instructions before using.

WARNING!

To reduce risk of ﬁ re, electric shock, or injury:

• Use only as described in this manual. Use only manufacturer’s recommended attachments.

• This machine shall be used only by properly trained and authorized persons.

• This machine is for dry use only and shall not be used or stored outdoors in wet conditions.

• Do not allow to be used as a toy. Close attention is necessary when used by or near children.

• Keep sparks, ﬂ ame and smoking materials away from batteries. Explosive gases are vented during normal operation.

• Charging the batteries produces highly explosive hydrogen gas. Charge batteries only in well-ventilated areas, away from open

ﬂ ame. Do not smoke while charging the batteries.

• Remove all jewelry when working near electrical components.

• Turn the key switch off (O) and disconnect the batteries before servicing electrical components.

• Never work under a machine without safety blocks or stands to support the machine.

• Do not dispense ﬂ ammable cleaning agents, operate the machine on or near these agents, or operate in areas where ﬂ ammable

liquids exist.

• Do not clean this machine with a pressure washer.

• This machine is not approved for use on public paths or roads.

• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may

reduce air ﬂ ow.

* Do not use on surfaces having a gradient exceeding that marked on the machine.

• When operating this machine, ensure that third parties, particularly children, are not endangered.

• Before performing any service function, carefully read all instructions pertaining to that function.

• Do not leave the machine unattended without ﬁ rst turning the key switch off (O) and removing the key. The parking brake is

automatically activated at this time.

* Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.

• Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.

• Do not use without dust bag and / or ﬁ lters in place.

• Do not stand on the pad housing.

• This machine is not suitable for picking up health endangering dust.

• The batteries must be removed from the machine before the machine is scrapped. The disposal of the batteries should be safely done in accordance with your local environmental regulations.

* All doors and covers are to be positioned as indicated in the instruction manual before using the machine. * Refer to the battery charger OEM product manual for additional speciﬁ c battery charger warnings.

SAVE THESE INSTRUCTIONS

A-4 - FORM NO. 56041634 - Advolution™ 2710 / UHR 70-1700

ENGLISH / A-5

IMPORTANTES CONSIGNES DE SECURITE

Cette machine ne convient qu´à un usage industriel, par exemple dans les hôtels, les écoles, les hôpitaux, les usines, les boutiques et les bureaux et autres utilisations que le ménage domestique résidentiel.

Lisez toutes les instructions avant l´utilisation.

ATTENTION!

Pour réduire le risque d´incendie, d´électrocution, ou de blessure:

• Ne l´utilisez que comme décrit dans ce manuel. N´utilisez que des attachements recommandés par le fabricant.

• Cette machine ne doit être utilisée que par des personnes proprement formées et autorisées.

• Cette machine n´est destinée qu´à un usage à sec et ne doit pas être utilisée ou emmagasinée à l´extérieur par des temps

pluvieux.

• Ne permettez pas que l´on l´utilise comme un jouet. Une attention particulière est nécessaire lorsqu´elle est utilisée par ou près

d´enfants.

• Gardez toute étincelle, ﬂ amme ou matériaux fumants éloignés des batteries. Des gaz explosifs sont ventilés pendant un

fonctionnement normal.

• Charger les batteries produit du gaz hydrogène hautement explosif. Ne chargez les batteries que dans des zones bien aérées,

loin de toute ﬂ amme. Ne fumez pas lors de la charge des batteries.

• Retirez tout bijou lorsque vous travaillez près des composants électriques.

• Tournez l´interrupteur à clé sur (O) pour l´éteindre et déconnectez les batteries avant l´entretien des composants électriques.

• Ne travaillez jamais sous une machine sans cale de sécurité ou de socles pour supporter la machine.

• Ne répandez pas d´agents nettoyants inﬂ ammables, n´utilisez pas la machine sur ou près de ces agents, ou ne l´utilisez pas

dans des zones où ces produits existent.

• Ne nettoyez pas cette machine avec un jet à haute pression.

• Cette machine n´est pas destinée à un usage sur les voies publiques.

• Ne mettez aucun objet dans les ouvertures. Ne l´utilisez pas avec une ouverture de bouchée; gardez la à l´abri de la poussière,

de la charpie, des cheveux et de tout ce qui pourrait réduire le ﬂ ux de l´air.

* N’utilisez pas sur des surfaces dont la pente dépasse celle mentionnée sur la machine.

• Lors de l´utilisation de cette machine, assurez - vous que des tiers, particulièrement des enfants, ne soient pas en danger.

• Avant d´entreprendre toute fonction d´entretien, lisez attentivement toutes les instructions se rapportant à cette fonction.

• Do not leave the machine unattended without ﬁ rst turning the key switch off (O) and removing the key. The parking brake is

automatically activated at this time.

* Positionnez la clé de contact sur off (O) avant de remplacer les brosses ou d’ouvrir tout panneau d’accès.

• Prenez les précautions nécessaires pour éviter que les cheveux, bijoux et vêtements amples ne soient pris dans les parties

mobiles.

• Ne l´utilisez pas sans que le sac de poussière et / ou les ﬁ ltres ne soient en place.

• Ne vous appuyez pas sur la chambre du disque.

• Cette machine n´est pas conçue pour le ramassage de poussière dangereuse à la santé.

• Prenez soin d’enlever les batteries de la machine avant de mettre cette dernière au rebut. Pour ce qui est de l’élimination des batteries, conformez-vous aux réglementations locales en matière d’environnement.

* Toutes les portes et couvercles doivent être dans la position mentionnée dans le manuel d’instruction avant de mettre la

machine en service.

* Consultez le manuel du fabricant du chargeur de batterie pour plus de consignes de sécurité spéciﬁ ques sur le chargeur de

batterie.

CONSERVEZ CES INSTRUCTIONS

FORM NO. 56041634 - Advolution™ 2710 / UHR 70-1700 - A-5

A-6 / ENGLISH

KNOW YOUR MACHINE

As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item shown on these pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in the text. NOTE: Refer to the service manual for detailed explanations of each item illustrated on the next 2 pages.

1 Pad Drive Deck 2 Dust Control Shroud 3 Burnishing Pad 4 Pad Retainer 5 Dust Collection Bag 6 Machine Tie Down 7 Battery Connector Assembly 8 FWD/REV Drive Pedal 9 Tilt Steering Wheel Adjuster 10 Emergency Power Disconnect 11 Steering Wheel 12 Operator’s Seat W/Safety Switch 13 Battery Compartment Cover 14 Drive / Steer Wheel 15 Circuit Breakers 40 Amp (Wheel Drive) 5 Amp (Control Circuit) 16 Deck Latch 17 Control Panel 18 Spare Dust Bag Storage 19 Beacon (Optional) 20 Headlight (Optional) 21 Active Dust Control (Optional) 22 Onboard Charger (Optional) 23 Charger Plug

A-6 - FORM NO. 56041634 - Advolution™ 2710 / UHR 70-1700

KNOW YOUR MACHINE

A Master Key Switch B Battery Condition Indicator C Hour Meter / Error Display D Pad Drive Indicator Light E Pad Drive Raise / Lower Switch F Horn Indicator Light G Horn Switch

ENGLISH / A-7

FORM NO. 56041634 - Advolution™ 2710 / UHR 70-1700 - A-7

A-8 / ENGLISH

BATTERIES

If your machine shipped with batteries installed do the following:

• Check that the batteries are connected to the machine (7).

• Turn ON the Key Switch (A) and check the Battery Indicator (B). If the green light is ON, the batteries are ready for use. If the green light is OFF, the

batteries should be charged before use. See the “Charging The Batteries” section.

If your machine shipped without batteries installed do the following:

• Consult your Authorized Nilﬁ sk-Advance dealer for recommended batteries.

• Install the batteries by following the instructions below.

• DO NOT install three 12 volt batteries in your machine. This affects the stability of the machine.

WARNING!

Use extreme caution when working with batteries. Sulfuric acid in batteries can cause severe injury if allowed to contact the skin or eyes. Explosive hydrogen gas is vented from the batteries through openings in the battery caps. This gas can be ignited by any electrical arc, spark or ﬂ ame. Do not install any lead-acid battery in a sealed container or enclosure. Hydrogen gas from overcharging must be allowed to escape.

When Servicing Batteries... * Remove all jewelry * Do not smoke * Wear safety glasses, rubber gloves and a rubber apron * Work in a well-ventilated area * Do not allow tools to touch more than one battery terminal at a time

* ALWAYS disconnect the negative (ground) cable ﬁ rst when replacing batteries to prevent sparks. * ALWAYS connect the negative cable last when installing batteries.

CAUTION!

Electrical components in this machine can be severely damaged if the batteries are not installed and connected properly. Nilﬁ sk- Advance, a qualiﬁ ed electrician, or the battery manufacturer should install batteries.

1 Remove the batteries from their shipping crate and carefully inspect them for cracks or other damage. If damage is evident, contact the carrier that delivered

them or the battery manufacturer to ﬁ le a damage claim.

2 Turn the Master Key Switch (A) OFF and remove the key. 3 Open and prop the Battery Compartment Cover (13). Remove the battery cables from inside the battery compartment. 4 Your machine comes from the factory with enough battery cables to install six 6 volt batteries. Carefully lift the batteries into the battery compartment and

arrange them exactly as shown in FIGURE 1. Secure the batteries as close to the back of the machine as possible.

5 Install the battery cables as shown. Position the cables so the battery caps can be easily removed for battery service. 6 Carefully tighten the nut in each battery terminal until the terminal will not turn. Do not over-tighten the terminals, or they will be very difﬁ cult to remove for

future service.

7 Coat the terminals with spray-on battery terminal coating (available at most auto parts stores). 8 Put one of the black rubber boots over each of the terminals and connect the Battery Connector Assembly (7).

FIGURE 1

A-8 - FORM NO. 56041634 - Advolution™ 2710 / UHR 70-1700

ENGLISH / A-9

INSTALLATION OF THE BURNISHING PAD

WARNING!

Disconnect the machines Battery Pack Connection (7) by pulling up on the Emergency Power Disconnect (10) handle, when ever servicing the machine.

CAUTION!

Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.

1 See Figure 2. Grab hold of the right side of the Pad Drive Deck (1) and lift up until it Latches (16) in place as shown. 2 Place your hand underneath the Dust Control Shroud (2) and remove the Pad Retainer (4) from the ﬂ exible pad holder assembly. NOTE:

Grip the retainer ﬁ rmly and turn clockwise (to the right) as the retainer uses a Left Hand thread.

3 Select a 27 inch (68 cm) Dia. Burnishing Pad (AA). See your local Nilﬁ sk-Advance Distributor for a complete selection of pads and

accessories.

4 Insert the plastic Pad Retainer (4) into the center of the Pad (AA). Then reinstall by turning the retainer counter-clockwise (to the left).

NOTE: Important !!! Turn the retainer in until you hear a clicking ratchet sound, this insures proper tightening of the pad by properly

compressing the pad material and drawing up the retainer so it will not strike the ﬂ oor.

FIGURE 2

FORM NO. 56041634 - Advolution™ 2710 / UHR 70-1700 - A-9
