Nikon COOLPIX S550 Owner Manual

DIGITAL CAMERA
User’s Manual
Trademark Information
Microsoft, Windows and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
Macintosh, Mac OS, and QuickTime are trademarks of Apple Inc.
Adobe and Acrobat are registered trademarks of Adobe Systems Inc.
The SD logo is a trademark of the SD Card Association.
D-Lighting technology is provided by P Apical Limited.
All other trade names mentioned in this manual or the other documentation
provided with your Nikon product are trademarks or registered trademarks of their respective holders.
Introduction
First Steps
A Basic Photography and Playback: Auto Mode
B High Sensitivity Mode
C Shooting Suited for the Scene
a Smile Mode
c More on Playback
D Movies
E Voice Recordings
Connecting to Televisions, Computers and Printers
d Shooting, Playback and Setup Menus
Technical Notes
i

For Your Safety

To prevent damage to your Nikon product or injury to yourself or to others, read the following safety precautions in their entirety before using this equipment. Keep these safety instructions where all those who use the product will read them.
The consequences that could result from failure to observe the precautions listed in this section are indicated by the following symbol:
This icon marks warnings, information that should be read before using this Nikon product, to prevent possible injury.

WARNINGS

Turn off in the event of malfunction
Should you notice smoke or an unusual smell coming from the camera or AC adapter, unplug the AC adapter and remove the battery immediately, taking care to avoid burns. Continued operation could result in injury. After removing or disconnecting the power source, take the equipment to a Nikon-authorized service representative for inspection.
Do not disassemble
Touching the internal parts of the camera or AC adapter could result in injury. Repairs should be performed only by qualified technicians. Should the camera or AC adapter break open as the result of a fall or other accident, take the product to a Nikon-authorized service representative for inspection, after unplugging the product and/or removing the battery.
ii
Do not use the camera or AC adapter in the presence of flammable gas
Do not use electronic equipment in the presence of flammable gas, as this could result in explosion or fire.
Handle the camera strap with care
Never place the strap around the neck of an infant or child.
Keep out of reach of children
Particular care should be taken to prevent infants from putting the battery or other small parts into their mouths.
For Your Safety
Observe caution when handling the battery
The battery may leak or explode if improperly handled. Observe the following precautions when handling the battery for use in this product:
Before replacing the battery, turn the product off. If you are using the AC adapter, be sure it is unplugged.
Only use a Rechargeable Li-ion Battery EN-EL11 (supplied). Charge the battery by inserting it in a Battery Charger MH-64 (supplied).
When inserting the battery, do not attempt to insert it upside down or backwards.
Do not short or disassemble the battery or attempt to remove or break the battery insulation or casing.
Do not expose the battery to flame or to excessive heat.
Do not immerse in or expose to water.
Return the battery to the battery case for transportation. Do not transport or store with metal objects such as necklaces or hairpins.
The battery is prone to leakage when fully discharged. To avoid damage to the product, be sure to remove the battery when no charge remains.
Discontinue use immediately should you notice any change in the battery, such as discoloration or deformation.
If liquid from the damaged battery comes in contact with clothing or
skin, rinse immediately with plenty of water.
Observe the following precautions when handling the battery charger
Keep dry. Failure to observe this precaution could result in fire or electric shock.
Dust on or near the metal parts of the plug should be removed with a dry cloth. Continued use could result in fire.
Do not handle the power cable or go near the battery charger during lightning storms. Failure to observe this precaution could result in electric shock.
Do not damage, modify, forcibly tug or bend the power cable, place it under heavy objects, or expose it to heat or flames. Should the insulation be damaged and the wires become exposed, take it to a Nikon­authorized service representative for inspection. Failure to observe these precautions could result in fire or electric shock.
Do not handle the plug or battery charger with wet hands. Failure to observe this precaution could result in electric shock.
iii
For Your Safety
Use appropriate cables
When connecting cables to the input and output jacks, use only the cables provided or sold by Nikon for the purpose, to maintain compliance with product regulations.
Handle moving parts with care
Be careful that your fingers or other objects are not pinched by the lens cover or other moving parts.
CD-ROMs
The CD-ROMs supplied with this device should not be played back on audio CD equipment. Playing CD­ROMs on an audio CD player could cause hearing loss or damage the equipment.
Observe caution when using the flash
Using the flash close to your subject’s eyes could cause temporary visual impairment. Particular care should be observed if photographing infants, when the flash should be no less than one meter (39 in.) from the subject.
Do not operate the flash with the flash window touching a person or object
Failure to observe this precaution could result in burns or fire.
Avoid contact with liquid crystal
Should the monitor break, care should be taken to avoid injury caused by broken glass and to prevent liquid crystal from the monitor touching the skin or entering the eyes or mouth.
iv

Notices

Notice for Customers in the U.S.A.
Federal Communications Commission (FCC) Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
CAUTIONS
Modifications
The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Nikon Corporation may void the user’s authority to operate the equipment.
Interface Cables
Use the interface cables sold or provided by Nikon for your equipment. Using other interface cables may exceed the limits of Class B Part 15 of the FCC rules.
Notice for customers in the State of California
WARNING
Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.
Wash hands after handling.
Nikon Inc., 1300 Walt Whitman Road
Melville, New York 11747-3064 USA
Tel: 631-547-4200
v
Notices
Notice for customers in Canada
CAUTION
This Class B digital apparatus complies with Canadian ICES-003.
ATTENTION
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Symbol for Separate Collection in European Countries
This symbol indicates that this product is to be collected separately.
The following apply only to users in European countries:
This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste.
For more information, contact the retailer or the local authorities in charge of waste management.
vi
Table of Contents
For Your Safety......................................................................................................................................ii
WARNINGS................................................................................................................................................ ii
Notices......................................................................................................................................................v
Introduction ...........................................................................................................................................1
About This Manual ................................................................................................................................1
Information and Precautions............................................................................................................. 2
Parts of the Camera............................................................................................................................... 4
The Camera Body ...................................................................................................................................................4
The Monitor................................................................................................................................................................6
Basic Operations.....................................................................................................................................8
The c (Shooting/Playback) Button...........................................................................................................8
The e (Mode) Button..................................................................................................................................8
The Multi Selector...................................................................................................................................................9
The d Button....................................................................................................................................................10
Help Displays..........................................................................................................................................................11
Attaching the Camera Strap.........................................................................................................................11
Shutter-release Button.....................................................................................................................................11
First Steps.............................................................................................................................................12
Charging the Battery ..........................................................................................................................12
Inserting the Battery ...........................................................................................................................14
Removing the Battery.......................................................................................................................................15
Turning On and Off the Camera.................................................................................................................15
Setting Display Language, Date and Time .................................................................................16
Inserting Memory Cards ....................................................................................................................18
Removing Memory Cards...............................................................................................................................19
A Basic Photography and Playback: Auto Mode .................................................................20
Step 1 Turn the Camera On and Select A (Auto) Mode.......................................................20
Indicators Displayed in A (Auto) Mode...............................................................................................21
Step 2 Frame a Picture .......................................................................................................................22
Using the Zoom....................................................................................................................................................22
Step 3 Focus and Shoot.....................................................................................................................24
Step 4 Viewing and Deleting Pictures..........................................................................................26
Viewing Pictures (Playback Mode)............................................................................................................26
Deleting Pictures..................................................................................................................................................26
Using the Flash......................................................................................................................................28
Setting the Flash Mode....................................................................................................................................28
vii
Table of Contents
Taking Pictures with the Self-timer ...............................................................................................30
Macro Mode...........................................................................................................................................31
Exposure Compensation...................................................................................................................32
B High Sensitivity Mode................................................................................................................ 33
Shooting in the High Sensitivity Mode........................................................................................33
C Shooting Suited for the Scene................................................................................................ 34
Shooting in the Scene Mode ...........................................................................................................34
Setting the Scene Mode..................................................................................................................................34
Features .....................................................................................................................................................................35
Taking Pictures for a Panorama..................................................................................................................41
a Smile Mode....................................................................................................................................43
Shooting in the Smile Mode ............................................................................................................43
The Smile Menu....................................................................................................................................45
Adding to List.........................................................................................................................................................45
c More on Playback....................................................................................................................... 46
Viewing Multiple Pictures: Thumbnail Playback ......................................................................46
Taking a Closer Look: Playback Zoom..........................................................................................47
Pictures taken in Face Priority......................................................................................................................47
Editing Pictures.....................................................................................................................................48
Enhancing Brightness and Contrast: D-Lighting..............................................................................49
Compensating Blurring After Shooting: Electronic VR.................................................................50
Creating a Cropped Copy: Crop.................................................................................................................51
g Resizing Pictures: Small Picture...........................................................................................................52
Voice Memos: Recording and Playback.......................................................................................53
Recording Voice Memos.................................................................................................................................53
Playing Voice Memos........................................................................................................................................54
Deleting Voice Memos.....................................................................................................................................54
Viewing Pictures by Date..................................................................................................................55
Selecting a Date in Calendar Mode..........................................................................................................55
Selecting a Date in List by Date Mode...................................................................................................56
Using Calendar Mode and List by Date Mode ..................................................................................57
Calendar and List by Date Menus..............................................................................................................58
Viewing Smile Pictures.......................................................................................................................59
Viewing Pictures Shooting in the Smile Mode..................................................................................59
Smile Menu in Playback Mode....................................................................................................................60
viii
Table of Contents
D Movies .............................................................................................................................................61
Recording Movies ................................................................................................................................61
The Movie Menu...................................................................................................................................62
Selecting Movie Options.................................................................................................................................62
Electronic VR...........................................................................................................................................................63
Autofocus mode ..................................................................................................................................................63
Time-Lapse Movies.............................................................................................................................................64
Movie Playback.....................................................................................................................................66
Deleting Movie Files...........................................................................................................................................66
E Voice Recordings........................................................................................................................... 67
Making Voice Recordings..................................................................................................................67
Playing Voice Recordings..................................................................................................................69
Deleting Sound Files..........................................................................................................................................70
Copying Voice Recordings................................................................................................................71
Connecting to Televisions, Computers and Printers............................................................ 72
Connecting to a TV..............................................................................................................................72
Connecting to a Computer...............................................................................................................73
Before Connecting the Camera..................................................................................................................73
Transferring Pictures from a Camera to a Computer ....................................................................74
Connecting to a Printer......................................................................................................................77
Connecting the Camera and Printer........................................................................................................78
Printing Pictures One at a Time..................................................................................................................79
Printing Multiple Pictures...............................................................................................................................80
Creating a DPOF Print Order: Print Set.........................................................................................83
d Shooting, Playback and Setup Menus ............................................................................. 85
Shooting Options: The Shooting Menu.......................................................................................85
Displaying the Shooting Menu and High sensitivity Menu......................................................86
A Image Mode ....................................................................................................................................................87
B White Balance.................................................................................................................................................89
C Continuous ......................................................................................................................................................91
E ISO Sensitivity..................................................................................................................................................93
F Color Options .................................................................................................................................................93
G AF Area Mode.................................................................................................................................................94
Q Distortion Control .......................................................................................................................................97
Restrictions on Camera Settings................................................................................................................98
ix
Table of Contents
Playback Options: The Playback Menu ........................................................................................99
Displaying the Playback Menu....................................................................................................................99
b Slide Show.....................................................................................................................................................101
c Delete................................................................................................................................................................102
d Protect ...........................................................................................................................................................102
f Rotate Image................................................................................................................................................103
h Copy..................................................................................................................................................................104
Basic Camera Setup: The Setup Menu.......................................................................................105
Displaying the Setup Menu........................................................................................................................106
a Menus ..............................................................................................................................................................106
c Welcome Screen........................................................................................................................................107
d Date....................................................................................................................................................................108
e Monitor Settings .......................................................................................................................................111
f Date Imprint..................................................................................................................................................112
w Electronic VR ................................................................................................................................................114
h AF Assist .........................................................................................................................................................115
u Digital Zoom ...............................................................................................................................................115
i Sound Settings ...........................................................................................................................................116
k Auto Off ..........................................................................................................................................................116
l Format Memory/m Format Card ...................................................................................................117
n Language ........................................................................................................................................................118
o Video Mode ..................................................................................................................................................118
d Blink Warning ..............................................................................................................................................118
p Reset All...........................................................................................................................................................120
r Firmware Version .....................................................................................................................................122
Technical Notes................................................................................................................................123
Optional Accessories ....................................................................................................................... 123
Approved Memory Cards............................................................................................................................123
Image/Sound File.............................................................................................................................. 124
Image/Sound File and Folder Names..................................................................................................124
Cropped Image Size........................................................................................................................................125
Caring for the Camera.....................................................................................................................126
Cleaning .................................................................................................................................................................128
Storage....................................................................................................................................................................129
Error Messages...................................................................................................................................130
Troubleshooting................................................................................................................................134
Specifications .....................................................................................................................................140
Supported Standards ......................................................................................................................143
Index......................................................................................................................................................144
x

Introduction

About This Manual

Thank you for your purchase of a Nikon COOLPIX S550 digital camera. This manual was written to help you enjoy taking pictures with your Nikon digital camera. Read this manual thoroughly before use, and keep it where all those who use the product will read it.
Symbols and Conventions
To make it easier to find the information you need, the following symbols and conventions are used:
This icon marks cautions, information that should be read
B
before use, to prevent damage to the camera.
This icon marks notes, information that should be read before using
C
the camera.
Notations
A Secure Digital (SD) memory card is referred to as a “memory card.”
The setting at the time of purchase is referred to as the “default setting.”
The names of menu items displayed in the camera monitor, and the names of
buttons or messages displayed in the computer monitor appear in bold.
Screen Samples
In this manual, images are sometimes omitted from monitor display samples so that monitor indicators can be more clearly shown.
Illustrations and Screen Display
Illustrations and text displays shown in this manual may differ from actual display.
This icon marks tips, additional information that may be helpful
D
when using the camera.
This icon indicates that more information is available elsewhere
A
in this manual or in the Quick Start Guide.
Introduction
C Memory Cards
Pictures taken with this camera can be stored in the camera’s internal memory or on removable memory cards. If a memory card is inserted, all new pictures will be stored on the memory card and delete, playback and format operations will apply only to the pictures on the memory card. The memory card must be removed before the internal memory can be formatted or used to store, delete or view pictures.
1

Information and Precautions

Life-Long Learning
As part of Nikon’s “Life-Long Learning” commitment to ongoing product support and education, continually updated information is available online at the following sites:
Introduction
For users in the U.S.A.: http://www.nikonusa.com/
For users in Europe and Africa: http://www.europe-nikon.com/suppor t/
For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.co m/
Visit these sites to keep up-to-date with the latest product information, tips, answers to frequently asked questions (FAQs), and general advice on digital imaging and photography. Additional information may be available from the Nikon representative in your area. See the URL below for contact information:
http://nikonimaging.com/
Use Only Nikon Brand Electronic Accessories
Nikon COOLPIX cameras are designed to the highest standards and include complex electronic circuitry. Only Nikon brand electronic accessories (including battery chargers, batteries and AC adapters) certified by Nikon specifically for use with this Nikon digital camera are engineered and proven to operate within the operational and safety requirements of this electronic circuitry.
THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND MAY
VOID YOUR For more information about Nikon brand accessories, contact a local authorized Nikon dealer.
NIKON WARRANTY.
Holographic seal: Identifies this device as an authentic Nikon product.
Rechargeable Li-ion Battery EN-EL11
Before Taking Important Pictures
Before taking pictures on important occasions (such as at weddings or before taking the camera on a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable for damages or lost profits that may result from product malfunction.
About the Manuals
No part of the manuals included with this product may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in any form, by any means, without Nikon’s prior written permission.
Nikon reserves the right to change the specifications of the hardware and software described in
these manuals at any time and without prior notice.
Nikon will not be held liable for any damages resulting from the use of this product.
While every effort was made to ensure that the information in these manuals is accurate and
complete, we would appreciate it were you to bring any errors or omissions to the attention of the Nikon representative in your area (address provided separately).
2
Information and Precautions
Notice Concerning Prohibition of Copying or Reproduction
Note that simply being in possession of material that was digitally copied or reproduced by means of a scanner, digital camera or other device may be punishable by law.
Items prohibited by law from being copied or reproduced
Do not copy or reproduce paper money, coins, securities, government bonds or local government bonds, even if such copies or reproductions are stamped “Sample.” The copying or reproduction of paper money, coins, or securities which are circulated in a foreign country is prohibited. Unless the prior permission of the government was obtained, the copying or reproduction of unused postage stamps or post cards issued by the government is prohibited. The copying or reproduction of stamps issued by the government and of certified documents stipulated by law is prohibited.
Cautions on certain copies and reproductions
The government has issued cautions on copies or reproductions of securities issued by private companies (shares, bills, checks, gift certificates, etc.), commuter passes or coupon tickets, except when a minimum of necessary copies are to be provided for business use by a company. Also, do not copy or reproduce passports issued by the government, licenses issued by public agencies and private groups, ID cards and tickets, such as passes and meal coupons.
Comply with copyright notices
The copying or reproduction of copyrighted creative works such as books, music, paintings, woodcut prints, maps, drawings, movies and photographs is governed by national and international copyright laws. Do not use this product for the purpose of making i llegal cop ies or to infringe copyright laws.
Disposing of Data Storage Devices
Please note that deleting images or formatting data storage devices such as memory cards or built­in camera memory does not completely erase the original image data. Deleted files can sometimes be recovered from discarded storage devices using commercially available software, potentially resulting in the malicious use of personal image data. Ensuring the privacy of such data is the user’s responsibility.
Before discarding a data storage device or transferring ownership to another person, erase all data using commercial deletion software, or format the device and then completely refill it with images containing no private information (for example, pictures of empty sky). Be sure to also replace any pictures selected for the welcome screen (A 107). Any pictures registered in Add to list (A 45) will be completely removed using Remove from list. Care should be taken to avoid injury or damage to property when physically destroying data storage devices.
Introduction
3

Parts of the Camera

The Camera Body

Introduction
23 41
Lens cover closed
65
1 Shutter-release button..............................24
2 Power-on lamp ...................................20, 116
3 Power switch...................................................20
Self-timer lamp....................................30, 127
4
AF-assist illuminator.............. 25, 115, 127
5 Eyelet for camera strap..............................11
4
8 97
6 Built-in flash......................................................28
7 Lens .........................................................128, 140
8 Lens cover ......................................................126
9 Built-in microphone....................53, 61, 67
Parts of the Camera
231
7 9 10 14 15 16 176
8
1 Monitor ..................................................................6
2 Multi selector......................................................9
3 e (mode) button....................................8
Zoom buttons ................................................22
f : wide .......................................................22
g : tele..........................................................22
4
h : thumbnail playback.....................46
i : playback zoom................................47
j : help........................................................11
Indicator lamp ................................................67
5
Flash lamp.........................................................29
6 Tripod socket
7 Speaker................................................54, 66, 69
4
5
13
12
11
8 Multi connector.............................72, 74, 78
Battery-chamber/
9
memory card slot cover....................14, 18
10 d button...................... 10, 34, 62, 86, 99
11 l (delete) button......... 26, 27, 54, 66, 70
12 k (apply selection) button......................9
c (shooting/playback) button
13
............................................................................8, 26
14 Power connector cover.........................123
15 Memory card slot..........................................18
16 Battery-chamber............................................14
17 Battery latch.............................................14, 15
Introduction
5
Parts of the Camera
9
h
59
m
59
s
59
m
59
s
F5.61/250
+1.0
999
999
9999
1600

The Monitor

The following indicators may appear in the monitor during shooting and playback (actual display varies with current camera settings).
Introduction
The information on indicators in the monitor during shooting and playback will display only for a few seconds (A 111).
Shooting
4
5
24
23
22
21
1 Shooting mode* ....................20, 33, 34, 61
2 Macro mode....................................................31
3 Zoom indicator......................................22, 31
4 Exposure lock..................................................42
5 Focus indicator..............................................24
6 Flash mode.......................................................28
7 Battery level indicator................................20
8 Electronic VR icon .....................................114
9 Distortion control.........................................97
“Date not set” indicator.........................130
10
Time zone indicator.................................108
11 Date imprint .................................................112
Image mode....................................................87
12
Movie options ................................................62
*
Differs according to the current shooting mode. Refer to the sections on each mode for details.
6
123
20 19
101010
+1.0
+1.0
1600
7 8 9
10
999
999
F5.6
1/250
1518
14
13
1617
13
14 Internal memory indicator......................21
15 Aperture.............................................................24
16 Focus area.................................................24, 94
17 Focus area (Face Priority).................24, 94
18 Shutter speed.................................................24
19 ISO sensitivity..........................................29, 93
20 Exposure compensation value............32
21 Self-timer indicator......................................30
22 Color options ..................................................93
23 White balance mode..................................89
24 Continuous shooting mode..................91
9h59m59
a Number of exposures remaining
(still pictures)..............................................20
b Movie length..............................................61
999
999
9999
9999
59
59
59m59 59
59
a
b
s s
6
11
12
Playback
15/05/2008 12:00
999
999
9999
9999
999
999
9
h
59
m
59
s
59
m
59
s
Parts of the Camera
Introduction
13
17
15
12
15/05/2008 12:00
15/05/2008 12:00
16
14
34
12
999
8
11
9 10
1 Date of recording.........................................16
2 Time of recording.........................................16
3 Volume indicator.......................... 53, 66, 69
4 Battery level indicator................................20
a Compensated image
5
b Electronic VR not available..... 50, 114
Image mode*..................................................87
6
Movie options*..............................................62
a Current frame number/
7
total number of frames....................... 26
b Movie length .............................................66
8 Internal memory indicator......................26
* The displayed icons vary with the settings in shooting mode.
9 Electronic VR guide.....................................50
10 Movie playback indicator........................66
11 Calendar/List by Date guide..........55, 56
12 Print-order icon..............................................83
13 Small picture....................................................52
14 D-Lighting icon..............................................49
15 Protect icon...................................................102
16 Voice memo icon.........................................53
17 File number and type.............................124
999999
999
999
9999
59
59m59 59
9h59m59
5
7
999999
999
9999
99999999
59 59
a b
6
a
b
s s
7

Basic Operations

The c (Shooting/Playback) Button
Introduction
The e (Mode) Button
Shooting-mode Selection Menu
Auto mode (A 20)
Scene mode (A 34)
Setup mode (A 105)
Playback-mode Selection Menu
Press c once in shooting mode to enter playback mode; press again to switch back to shooting mode. Pressing the shutter-release button halfway in playback mode (A 26) will also activate shooting mode.
If the camera is turned off, hold down c to turn the camera on in playback mode (A 26).
Press e during shooting to display the shooting­mode selection menu, or during playback to display the playback-mode selection menu. Use the multi selector (A 9) to choose the desired mode.
Press c to switch between the mode-selection
menus for shooting mode and playback mode.
Smile mode (A 43)
Calendar mode (A 55)
Shooting
High sensitivity mode (A 33) Movie mode (A 61) Voice recording mode (A 67)
Playback mode (A 26)
Smile mode (A 59)
8
Play
List by date mode (A 56) Setup mode (A 105)
Sound file playback mode (A 69)
Basic Operations
44
15/05/2008 15:30

The Multi Selector

This section describes standard uses of the multi selector to select modes, select menu options and to apply selection.
For Shooting
Display m (flash mode) (A 28) menu or move cursor up.
Introduction
Display n (self-timer) (A 30) menu.
Display o (exposure compensation) (A 32) menu.
Apply selection.
Display p (macro mode) (A 31) menu or move cursor down.
For Playback
Display the previous picture.
Display the next picture.
For the Menu Screen
Move cursor up.
Move cursor to left or return to the previous screen.
Move cursor down.
Apply selection (Go to the next screen).
Move cursor to right or go to the next screen (Apply selection).
Flash mode
15/05/2008 15:30
Shooting menu
Image mode White balance Continuous ISO sensitivity Color options
Exit
44
Shooting
C Notes on the Multi Selector
Multiple operations are available with the multi selector but no detailed operation is described here. In the manual, the button indicating up, down, left and right of the multi selector is shown as H, I,
J and K.
9
Basic Operations
The d Button
Press d to display the menu for the selected mode. Use the multi selector to navigate the menus (A 9).
Introduction
To exit the menu display, press d again.
Displayed when there are more previous menu items
Image mode White balance Continuous ISO sensitivity
Displayed when
Color options
there are one or more menu items to follow
Shooting menu
AF area mode Distortion control
Exit
Press the multi selector K or k to proceed to the next set
of options.
Shooting menu
Exit
The selected option
Displayed when the menu contains two or more pages
AF area mode
Face priority
Auto Manual Center
Exit
Press the multi selector K or k to apply selection.
10
Basic Operations

Help Displays

Press g (j) when M is displayed at the lower right of the menu screen to view a description of the currently selected menu option.
To return to the original menu, press g (j) again.
Continuous
Choose single frame, continuous mode, BSS (camera chooses sharpest shot in series), multi-shot 16, or interval timer shooting.
Exit
Back

Attaching the Camera Strap

Shutter-release Button

The camera features a two-stage shutter-release button. To set focus and exposure, press the shutter-release button halfway, stopping when you feel resistance. Focus and exposure lock while the shutter-release button is held in this position. To release the shutter and take a picture, press the shutter-release button the rest of the way down. Do not use force when pressing the shutter-release button, as this may result in camera shake and blurred pictures.
Introduction
Press the shutter­release button halfway to set focus and exposure.
Press the shutter­release button the rest of the way down to take picture.
11

First Steps

Charging the Battery

The camera uses a Rechargeable Li-ion Battery EN-EL11 (supplied). Charge the battery with the Battery Charger MH-64 (supplied) before first use or
when the battery is running low. It is recommended to charge the battery within six months after it was used.
First Steps
1 Connect the power cable.
Connect the power cable to the battery charger 1 and insert the wall plug into a power outlet 2. The CHARGE lamp will light to show that the charger is on 3.
E
G
3
CHARGE
R
A
H
C
R
E
G
R
A
H
MH-64
C
Y
R
E
T
T
A
B
N
IO
M
IU
H
IT
L
1
2
2 Charge the battery.
Insert the battery 1 to set it to the battery charger 2.
CHARGE lamp starts blinking when battery is inserted 3. Charging is complete when lamp stops blinking 4.
About 120 minutes are required to charge a fully depleted battery.
12
1
2
E G R
A H
C
R
E
G
R
A
H
MH-64
C
Y
R
E
T
T
A
B
N
IO
M
IU
H
IT
L
34
Charging the Battery
CHARGE lamp Description
Blinks Battery charging.
On Battery fully charged.
Battery is incorrectly inserted. Remove and reinsert battery at a
low angle as shown in Figure 2-1.
Flickers
If ambient temperature is not 5 to 35 °C (41 to 95 °F), wait until temperature is in this range before charging.
Battery error. Unplug charger and remove battery immediately and take both devices to retailer or Nikon-authorized service representative.
3 Unplug the charger.
Remove the battery and unplug the charger.
B Note on the Battery Charger
Be sure to read and follow the warnings for the battery charger on pages iii and iv before using the battery charger. The supplied battery charger is for use only with a Rechargeable Li-ion Battery EN-EL11. Do not use with incompatible batteries. When recharging, the ambient temperature should be in the vicinity of 5 to 35 °C (41 to 95 °F). The battery will not charge if its temperature is below 0 °C (32 °F) or above 60 °C (140 °F). Charging times may increase at battery temperatures from 0 °C to 10 °C (32 °F to 50 °F) and from 45 °C to 60 °C (113 °F to 140 °F).
First Steps
B Note on the Battery
Be sure to read and follow the warnings for the battery on page iii and the section, “The Battery” (A 127), before using the battery.
C Note on AC power supply
To power the camera continuously for extended periods, use an AC Adapter EH-62E (available separately from Nikon) (A 123) Do not, under any circumstances, use another make or model of AC adapter. Failure to observe this precaution could result in overheating or in damage to the camera.
13

Inserting the Battery

Insert a Rechargeable Li-ion Battery EN-EL11 (supplied) that has been fully charged, using the Battery Charger MH-64 (supplied), into your camera.
1 Open the battery-chamber/memory card slot
cover.
First Steps
2 Insert the battery.
Confirm that the positive (+) and negative (-) terminals are oriented correctly as described on the label at the entrance of the battery chamber, and insert the battery.
The orange battery latch is pushed aside as the battery is inserted.
The battery is fully inserted when the battery latch clicks back into place.
B Inserting the Battery
Inserting the battery upside down or backwards will not set the power supply to ON. Be sure to check the battery is in the
correct orientation.
Battery latch
3 Close the battery-chamber/memory card slot
cover.
14
Inserting the Battery

Removing the Battery

Turn the camera off and make sure that the power-on lamp and the monitor have gone out before opening the battery-chamber/memory card slot cover.
To eject the battery, open the battery-chamber/ memory card slot cover and slide the battery latch in the direction shown removed by hand
1. The battery can then be
2.
Note that the battery may become hot during use; observe due caution when removing the battery.

Turning On and Off the Camera

To turn on the camera, press the power switch. The power-on lamp (green) will light for a moment and the monitor will turn on.
To turn off the camera, press the power switch again. When the camera turns off, both the power-on lamp
and monitor will turn off. If the camera is turned off, hold down c to turn the camera on in playback mode.
First Steps
D Auto Power-Off in A (Auto) Mode (Standby Mode)
The monitor will dim to reduce the drain on the battery if no operations are performed for about five seconds. The monitor will brighten when camera controls are used. At default settings, the monitor will turn off altogether if no operations are performed for about a minute during shooting and playback. The camera will turn off automatically if no operations are performed for another three minutes (A 116).
15

Setting Display Language, Date and Time

A language-selection dialog is displayed the first time the camera is turned on.
1 Press the power switch to turn on the camera.
The power-on lamp (green) will light for a moment and the monitor will turn on.
First Steps
2 Use the multi selector to choose the desired
language and press k.
For information on using the multi selector, see “The Multi Selector” (A 9).
3 Choose Yes and press k.
If No is selected, the date and time will not be set.
4 Press k.
The home time zone menu is displayed.
D Daylight Saving Time
If daylight saving time is in effect, turn on Daylight saving in the Time zone menu in Step 4 and set the date.
1 Before pressing k, press the multi selector I to choose Daylight saving. 2 Press k to enable daylight saving time (w). Pressing k toggles the daylight saving time
option on and off.
3 Press the multi selector H, and then press k to proceed to step 5.
16
Date
Set time and date?
No
Ye s
Time zone
London,Casablanca
Daylight saving
Setting Display Language, Date and Time
5 Select your home time zone (A 110) and press
k.
The Date menu is displayed.
6 Change the date and time.
Press H or I to edit the highlighted item.
Press K to move the cursor in the following order.
D ->M ->Y ->Hour ->Minute ->D M Y
Press J to return to the previous cursor.
7 Choose the order in which the day, month and
year are displayed and press k or press
The settings are applied and monitor display returns to shooting mode.
K.
Home time zone
London,Casablanca
Back
Date
DMY
01
Date
DMY
15
200803
0000
200805
1015
First Steps
D Changing the date and time
To change the date and time, select Date from Date (A 108) in the setup menu (A 105) and
follow the instructions starting from the above step 6.
To change the time zone and the daylight saving settings, select Time zone from Date in the
setup menu (A 108, 109).
17

Inserting Memory Cards

Pictures are stored in the camera’s internal memory (approximately 50 MB) or on removable Secure Digital (SD) memory cards (available separately) (A 123).
If a memory card is inserted in the camera, pictures are automatically stored on the memory card and pictures recorded to the memory card can be played back, deleted or transferred. Remove the memory card to store pictures in the internal memory, or play back, delete or transfer pictures from the internal memory.
First Steps
1 Turn the camera off and open the battery-
chamber/memory card slot cover.
Make sure that the camera is off (the power-on lamp and the monitor are off) before opening the battery­chamber/memory card slot cover.
Make sure that the camera is off (power-on lamp is off) before inserting or removing the memory card.
2 Insert the memory card.
Slide the memory card in correctly until it clicks into place.
Close the battery-chamber/memory card slot cover.
B Inserting Memory Cards
Inserting the memory card upside down or backwards could damage the camera or the memory card. Make
sure that the memory card is correctly oriented.
18
Loading...
+ 134 hidden pages
