Page 1

DIGITAL CAMERA

User’s Manual

Page 2

Trademark Information

• Microsoft and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

• Macintosh, Mac OS, and QuickTime are trademarks of Apple Inc.

• Adobe and Acrobat are registered trademarks of Adobe Systems Inc.

• The SD logo is a trademark of the SD Card Association.

• PictBridge is a trademark.

•

Pictmotion is powered by muvee Technologies.

• ImageLink and the ImageLink print system logo are trademarks of Eastman Kodak Company.

• D-Lighting technology is provided by o Apical Limited.

• All other trade names mentioned in this manual or the other documentation provided with your Nikon product are trademarks or registered trademarks of their respective holders.

Page 3

Introduction

First Steps

K n

Basic Photography and Playback: Auto Mode

Shooting Suited for the Scene

- High-sensitivity Shooting Mode, Scene Mode

One-Touch Portrait Mode

More on Playback

Movies

Voice Recordings

Connecting to Televisions, Computers, and Printers

Shooting, Playback, and Setup Menus

Technical Notes

Page 4

Introduction

For Your Safety

To prevent damage to your Nikon product or injury to yourself or to others, read the following safety precautions in their entirety before using this equipment. Keep these safety instructions where all those who use the

Introduction

product will read them. The consequences that could result from failure to observe the precautions

listed in this section are indicated by the following symbol:

This icon marks warnings, information that should be read before using this Nikon product to prevent possible injury.

WARNINGS

Turn off in the Event of Malfunction

Should you notice smoke or an unusual smell coming from the camera or AC adapter, unplug the AC adapter and remove the battery immediately, taking care to avoid burns. Continued operation could result in injury. After removing or disconnecting the power source, take the equipment to a Nikonauthorized service representative for inspection.

Do not Disassemble

Touching the internal parts of the camera or AC adapter could result in injury. Repairs should be performed only by qualified technicians. Should the camera or AC adapter break open as the result of a fall or other accident, take the product to a Nikon-authorized service representative for inspection, after unplugging the product and/or removing the battery.

Do not use the Camera or AC Adapter in the Presence of Flammable Gas

Do not use electronic equipment in the presence of flammable gas, as this could result in explosion or fire.

Handle the Camera Strap with Care

Never place the strap around the neck of an infant or child.

Keep out of Reach of Children

Particular care should be taken to prevent infants from putting the battery or other small parts into their mouths.

Page 5

For Your Safety

Observe caution when handling the battery

The battery may leak or explode if improperly handled. Observe the following precautions when handling the battery for use in this product:

• Before replacing the battery, turn the product off. If you are using the AC adapter, be sure it is unplugged.

• Only use a Rechargeable Li-ion Battery EN-EL8 (supplied). Charge the battery by inserting it in a Battery Charger MH-62 (supplied).

• When inserting the battery, do not attempt to insert it upside down or backwards.

• Do not short or disassemble the battery or attempt to remove or break the battery insulation or casing.

• Do not expose the battery to flame or to excessive heat.

• Do not immerse in or expose to water.

• Replace the terminal cover when transporting the battery. Do not transport or store with metal objects such as necklaces or hairpins.

• The battery is prone to leakage when fully discharged. To avoid damage to the product, be sure to remove the battery when no charge remains.

• Discontinue use immediately should you notice any change in

the battery, such as discoloration or deformation.

• If liquid from the damaged battery comes in contact with clothing or skin, rinse immediately with plenty of water.

Observe the following precautions when handling the battery charger

• Keep dry. Failure to observe this precaution could result in fire or electric shock.

• Dust on or near the metal parts of the plug should be removed with a dry cloth. Continued use could result in fire.

• Do not handle the power cable or go near the battery charger during lightening storms. Failure to observe this precaution could result in electric shock.

• Do not damage, modify, forcibly tug or bend the power cable, place it under heavy objects, or expose it to heat or flame. Should the insulation be damaged and the wires become exposed, take it to a Nikon-authorized service representative for inspection. Failure to observe these precautions could result in fire or electric shock.

Introduction

iii

Page 6

For Your Safety

• Do not handle the plug or battery charger with wet hands. Failure to observe this precaution could

Introduction

result in electric shock.

Use appropriate cables

When connecting cables to the input and output jacks, use only the cables provided or sold by Nikon for the purpose, to maintain compliance with product regulations.

Handle moving parts with care

Be careful that your fingers or other objects are not pinched by the lens cover or other moving parts.

CD-ROMs

The CD-ROMs supplied with this device should not be played back on audio CD equipment. Playing CDROMs on an audio CD player could cause hearing loss or damage the equipment.

Observe caution when using the flash

Using the flash close to your subject’s eyes could cause temporary visual impairment. Particular care should be observed if photographing infants, when the flash should be no less than one meter (39 in.) from the subject.

Do not operate the flash with the flash window touching a person or object

Failure to observe this precaution could result in burns or fire.

Avoid contact with liquid crystal

Should the monitor break, care should be taken to avoid injury caused by broken glass and to prevent liquid crystal from the monitor touching the skin or entering the eyes or mouth.

Page 7

Notices

Notice for Customers in the U.S.A.

Federal Communications Commission (FCC) Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

COOLPIX S51

CAUTIONS

Modifications

The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Nikon Corporation may void the user’s authority to operate the equipment.

Interface Cables

Use the interface cables sold or provided by Nikon for your equipment. Using other interface cables may exceed the limits of Class B Part 15 of the FCC rules.

Notice for customers in the State of California

WARNING: Handling the cord on

this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling.

Nikon Inc., 1300 Walt Whitman Road

Melville, New York 11747-3064 USA

Tel: 631-547-4200

Introduction

Page 8

Notices

Notice for customers in Canada

CAUTION

Introduction

This Class B digital apparatus complies with Canadian ICES-003.

ATTENTION

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

• This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste.

• For more information, contact the retailer or the local authorities in charge of waste management.

Page 9

Introduction .....................................................................................................ii

For Your Safety..................................................................................................ii

WARNINGS ................................................................................................... ii

Notices................................................................................................................v

About This Manual............................................................................................1

Information and Precautions............................................................................2

Parts of the Camera...........................................................................................4

Attaching the Camera Strap..........................................................................4

The Monitor.......................................................................................................6

Shooting .......................................................................................................6

Playback........................................................................................................7

Basic Operations................................................................................................8

The i (shooting/playback) Button ...............................................................8

The C (mode) Button ..............................................................................8

The Rotary Multi Selector ..............................................................................9

The m Button .........................................................................................10

Help Displays...............................................................................................11

First Steps........................................................................................................12

Charging the Battery.......................................................................................12

Inserting the Battery .......................................................................................14

Removing the Battery..................................................................................15

Turning On and Off the Camera..................................................................15

Setting Display Language, Date, and Time....................................................16

Inserting Memory Cards..................................................................................18

Removing Memory Cards ............................................................................19

L Basic Photography and Playback: Auto Mode........................................20

Step 1 Turn the Camera On and Select L (Auto) Mode..............................20

Step 2 Frame a Picture ....................................................................................22

Step 3 Focus and Shoot...................................................................................24

Step 4 Viewing and Deleting Pictures............................................................26

Using the Flash ................................................................................................28

Taking Pictures with the Self-Timer...............................................................30

Macro (Close-up) Mode...................................................................................31

Exposure Compensation .................................................................................32

Introduction

vii

Page 10

Table of Contents

K n Shooting Suited for the Scene - High-sensitivity Shooting Mode,

Scene Mode..........................................................................................33

Introduction

High-sensitivity Shooting Mode .....................................................................33

Scene Modes....................................................................................................34

Features ......................................................................................................35

A One-Touch Portrait Mode.......................................................................42

Taking Pictures in the One-Touch Portrait Mode..........................................42

The One-Touch Portrait Menu........................................................................43

i More on Playback.....................................................................................44

Viewing Multiple Pictures: Thumbnail Playback...........................................44

Viewing Multiple Pictures: Thumbnail Wheel Playback ...............................45

Taking a Closer Look: Playback Zoom............................................................46

Editing Pictures................................................................................................47

Enhancing Brightness and Contrast: D-Lighting ...........................................48

Creating a Cropped Copy: Crop..................................................................49

H Resizing Pictures: Small Picture...............................................................50

Voice Memos: Recording and Playback .........................................................51

Viewing Pictures by Date................................................................................52

Pictmotion by muvee ......................................................................................56

T Movies .......................................................................................................61

Recording Movies............................................................................................61

The Movie Menu .............................................................................................62

Selecting Movie Options..............................................................................63

Stop-Motion Movies....................................................................................64

Auto-Focus Mode........................................................................................65

Movie Playback................................................................................................66

Deleting Movie Files ....................................................................................66

Voice Recordings........................................................................................67

Making Voice Recordings ...............................................................................67

Playing Voice Recordings................................................................................69

Copying Voice Recordings ..............................................................................71

viii

Page 11

Table of Contents

Connecting to Televisions, Computers, and Printers ...................................72

Connecting to a TV..........................................................................................72

Connecting to a Computer .............................................................................73

Before Connecting the Camera...................................................................73

Transferring Pictures from the Camera to a Computer.................................74

Connecting to a Printer...................................................................................77

Connecting the Camera and Printer ............................................................78

Printing Pictures One at a Time....................................................................79

Printing Multiple Pictures.............................................................................80

Creating a DPOF Print Order: Print Set..........................................................83

Connecting to a ImageLink-compatible Printer ............................................85

Removing the Dock Insert............................................................................85

m Shooting, Playback, and Setup Menus .................................................86

Shooting Options: The Shooting Menu .........................................................86

Displaying the Shooting Menu and High-sensitivity Menu............................87

Z Image Mode ..........................................................................................87

d White Balance........................................................................................89

q Continuous............................................................................................91

A Best Shot Selector (BSS) .........................................................................92

W ISO Sensitivity.........................................................................................93

d Color Options.........................................................................................93

k AF Area Mode........................................................................................94

Restrictions on Camera Settings ..................................................................95

Playback Options: The Playback Menu ..........................................................96

Displaying the Playback Menu.....................................................................96

w Print Set .................................................................................................83

z Slide Show .............................................................................................98

A Delete ....................................................................................................99

Protect .................................................................................................99

G Rotate Image .......................................................................................100

H Small Picture..........................................................................................50

L Copy....................................................................................................100

Introduction

Page 12

Table of Contents

Basic Camera Setup: The Setup Menu..........................................................102

Displaying the Setup Menu........................................................................103

Introduction

R Menus..................................................................................................103

V Welcome Screen ..................................................................................104

W Date.....................................................................................................105

Z Monitor Settings..................................................................................108

f Date Imprint.........................................................................................109

b Vibration Reduction..............................................................................111

u AF Assist .............................................................................................111

h Sound Settings.....................................................................................112

I Record Orientation ...............................................................................112

i Auto Off ..............................................................................................112

M Format Memory/O Format Card ..........................................................113

j Language .............................................................................................114

k Video Mode .........................................................................................114

n Reset All...............................................................................................114

B Firmware Version.................................................................................116

Technical Notes ............................................................................................117

Optional Accessories .....................................................................................117

Approved Memory Cards ..........................................................................117

Image/Sound File and Folder Names............................................................118

Caring for the Camera ..................................................................................120

Cleaning ...................................................................................................122

Storage .....................................................................................................122

Error Messages...............................................................................................123

Troubleshooting............................................................................................127

Specifications.................................................................................................132

Supported Standards.....................................................................................135

Index...............................................................................................................136

Page 13

About This Manual

Thank you for your purchase of a Nikon COOLPIX S51 digital camera. This manual was written to help you enjoy taking pictures with your Nikon digital camera. Read this manual thoroughly before use, and keep it where all those who use the product will read it.

Symbols and Conventions

To make it easier to find the information you need, the following symbols and conventions are used:

This icon marks cautions, information that should be read before use to prevent damage to the camera.

This icon marks notes, information that should be read

before using the camera.

Notations

• A Secure Digital (SD) memory card is referred to as a “memory card.”

• The setting at the time of purchase is referred to as the “default setting.”

• The names of menu items displayed in the camera monitor and the names of buttons or messages displayed in the computer monitor are indicated with brackets ([ ]).

Screen Samples

In this manual, images are sometimes omitted from monitor display samples so that monitor indicators can be more clearly shown.

Illustrations and Screen Display

Illustrations and text displays shown in this manual may differ from actual display.

This icon marks tips, additional information that may be helpful

when using the camera.

This icon indicates that more information is available

elsewhere in this manual or in the Quick Start Guide.

Introduction

k Memory Cards

Pictures taken with this camera can be stored in the camera’s internal memory or on removable memory cards. If a memory card is inserted, all new pictures will be stored on the memory card and delete, playback, and format operations will apply only to the pictures on the memory card. The memory card must be removed before the internal memory can be formatted or used to store, delete, or view pictures.

Page 14

Information and Precautions

Life-Long Learning

As part of Nikon’s “Life-Long Learning” commitment to ongoing product support and education, continually updated information is available online at the following sites:

Introduction

• For users in the U.S.A.: http://www.nikonusa.com/

• For users in Europe and Africa: http://www.europe-nikon.com/support/

• For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/

Visit these sites to keep up-to-date with the latest product information, tips, answers to frequently asked questions (FAQs), and general advice on digital imaging and photography. Additional information may be available from the Nikon representative in your area. See the URL below for contact information:

http://nikonimaging.com/

Use Only Nikon Brand Electronic Accessories

Nikon COOLPIX cameras are designed to the highest standards and include complex electronic circuitry. Only Nikon brand electronic accessories (including battery chargers, batteries and AC adapters) certified by Nikon specifically for use with this Nikon digital camera are engineered and proven to operate within the operational and safety requirements of this electronic circuitry.

THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND

MAY VOID YOUR For more information about Nikon brand accessories, contact a local authorized Nikon dealer.

NIKON WARRANTY.

Holographic seal: Identifies this device as an authentic Nikon product.

Rechargeable Li-ion Battery EN-EL8

Before Taking Important Pictures

Before taking pictures on important occasions (such as at weddings or before taking the camera on a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable for damages or lost profits that may result from product malfunction.

About the Manuals

• No part of the manuals included with this product may be reproduced, transmitted,

transcribed, stored in a retrieval system, or translated into any language in any form, by any means, without Nikon’s prior written permission.

• Nikon reserves the right to change the specifications of the hardware and software

described in these manuals at any time and without prior notice.

• Nikon will not be held liable for any damages resulting from the use of this product.

• While every effort was made to ensure that the information in these manuals is accurate

and complete, we would appreciate it were you to bring any errors or omissions to the attention of the Nikon representative in your area (address provided separately).

Page 15

Information and Precautions

Notice Concerning Prohibition of Copying or Reproduction

Note that simply being in possession of material that was digitally copied or reproduced by means of a scanner, digital camera or other device may be punishable by law.

• Items prohibited by law from being copied or reproduced

Do not copy or reproduce paper money, coins, securities, government bonds or local government bonds, even if such copies or reproductions are stamped “Sample”. The copying or reproduction of paper money, coins, or securities which are circulated in a foreign country is prohibited. Unless the prior permission of the government was obtained, the copying or reproduction of unused postage stamps or post cards issued by the government is prohibited. The copying or reproduction of stamps issued by the government and of certified documents stipulated by law is prohibited.

• Cautions on certain copies and reproductions

The government has issued cautions on copies or reproductions of securities issued by private companies (shares, bills, checks, gift certificates, etc.), commuter passes or coupon tickets, except when a minimum of necessary copies are to be provided for business use by a company. Also, do not copy or reproduce passports issued by the government, licenses issued by public agencies and private groups, ID cards and tickets, such as passes and meal coupons.

• Comply with copyright notices

The copying or reproduction of copyrighted creative works such as books, music, paintings, woodcut prints, maps, drawings, movies and photographs is governed by national and international copyright laws. Do not use this product for the purpose of making illegal copies or to infringe copyright laws.

Disposing of Data Storage Devices

Please note that deleting images or formatting data storage devices such as memory cards or built-in camera memory does not completely erase the original image data. Deleted files can sometimes be recovered from discarded storage devices using commercially available software, potentially resulting in the malicious use of personal image data. Ensuring the privacy of such data is the user’s responsibility.

Before discarding a data storage device or transferring ownership to another person, erase all data using commercial deletion software, or format the device and then completely refill it with images containing no private information (for example, pictures of empty sky). Be sure to also replace any pictures selected for the welcome screen (c 104). Care should be taken to avoid injury or damage to property when physically destroying data storage devices.

Introduction

Page 16

Parts of the Camera

Introduction

Power switch (c 20)

Power-on lamp (c 20, 112)

Shutter-release button (c 24)

Eyelet for camera strap

Built-in microphone (c 51, 61, 67)

A (one-touch portrait) button (c 42)/ (D-Lighting) button (c 48)

Lens (c 120, 132)

Self-timer lamp (c 30, 121) AF-assist illuminator (c 29, 35, 111, 121)

Lens cover closed

Built-in flash (c 28)

Lens cover

Attaching the Camera Strap

123

Page 17

Rotary multi selector: c 9

Parts of the Camera

J (flash mode): c 28

Introduction

H (self-timer): c 30

F (macro mode): c 31

C (mode) button (c 8)

Monitor (c 6)

Speaker (c 51, 66, 69)

m button (c 10, 87, 96)

Battery latch (c 14, 15)

I (exposure compensation): c 32

d (apply selection) button: c 9

Zoom buttons (c 22)

The Monitor

9999

+1.0

q w

fg h i j l

A B C D

The following indicators may appear in the monitor during shooting and playback (actual display varies with current camera settings).

Introduction

Shooting

fghijl

cdehi

134

+1.0

ABCD

z ABCD

9 10

9999

151617

Shooting mode*

.......................... 20, 33, 34, 42, 61

2 Exposure lock............................. 41

3 Macro mode .............................. 31

4 Zoom indicator..................... 22, 31

5 Focus indicator........................... 24

6 Flash mode ................................ 28

7 Flash indicator............................ 29

8 Internal memory indicator .......... 21

9 Battery level indicator................. 20

10 ISO sensitivity ....................... 29, 93

11 Vibration reduction icon........... 111

12 Self-timer indicator..................... 30

* Differs according to the current shooting mode. Refer to the sections on each mode

for details.

“Date not set” indicator........... 123

Time zone indicator.................. 105

14 Date imprint.............................109

Number of exposures

remaining (still pictures)..............20

Movie length..............................61

16 Focus area............................24, 94

17 Exposure compensation value..... 32

18 Image mode ...............................87

19 Color options .............................93

20 White balance mode ..................89

21 Best shot selector (BSS)...............92

22 Continuous shooting mode ........ 91

Page 19

The Monitor

15/11/2007 12:00


9999

O P

I J K

Playback

IJK

1 Date of recording....................... 16

2 Time of recording....................... 16

3 Internal memory indicator .......... 26

4 Battery level indicator................. 20

5 File number and type................ 118

Calendar guide/

list by date guide.................. 52, 53

7 Volume indicator.................. 51, 66

8 Voice memo recording guide...... 51

9 Voice memo playback guide....... 51

15/11/2007 12:00


3 4

9999

99999999

101214

Current frame number/total

number of frames.......................26

Movie length..............................66

11 Movie playback indicator............ 66

12 D-Lighting icon...........................48

13 Voice memo icon........................51

14 Image mode ...............................87

15 Small picture ..............................50

16 Protect icon................................99

17 Print-order icon ..........................83

18 Movie indicator* ........................66

O P

Introduction

8 9

* Differs according to the movie option selected in shooting mode.

Page 20

Basic Operations

The i (shooting/playback) Button

Introduction

The C (mode) Button

Shooting-mode Selection Menu

Press i once in shooting mode to enter full-frame playback; press again to switch back to shooting mode. Pressing the shutter-release button halfway in playback mode (c 26) will also activate shooting mode.

If the camera is turned off, hold down i to turn the camera on in playback mode (c 26).

Press C during shooting to display the shootingmode selection menu, or during playback to display the playback-mode selection menu. Use the rotary multi selector (c 9) to choose the desired mode.

• Press i to switch between the mode-selection

menus for shooting mode and playback mode.

Auto mode (c20)

Shooting

Setup mode (c 102)

Movie mode (c 61)

Voice recording mode (c 67)

Playback-mode Selection Menu

Setup mode (c 102)

Audio playback mode (c 69)

High-sensitivity shooting mode (c 33)

Scene mode (c 34)

Playback mode (c 26)

Play

Pictmotion mode (c 56)

Calendar mode (c 52)

List by date mode (c 53)

Page 21

Basic Operations

The Rotary Multi Selector

The rotary multi selector is made up of the rotating ring and the d button. When selecting menus or pictures, you can either press the rotating ring up, down, left, or right, or rotate it. When choosing from numerous menu items or pictures, rotating the ring is recommended for easy scrolling and faster operation.

This section describes standard uses of the rotary multi selector to select modes, select menu options, and to apply selection.

For the Shooting-mode/Playback-mode Selection Menu

Play

Turn counterclockwise.

Press up.

Turn clockwise.

Introduction

Press left.

Press down.

• To move the highlight clockwise, turn clockwise, press down or right.

• To move the highlight counterclockwise, turn counterclockwise, press up or left.

• To apply selection, press d.

Press right.

Press d.

For the Menu Screen

Shooting menu

Image mode White balance Continuous BSS ISO sensitivity

Exit

• To move the highlight upward, turn counterclockwise, or press up.

• To move the highlight downward, turn clockwise, or press down.

• To apply selection, press d or right.

• To cancel setting and return to the previous screen, press left.

Turn counterclockwise.

Press left.

Press down.

Press up.

Turn clockwise.

Press right.

Press d.

k Notes on the Rotary Multi Selector

• In many cases, you can choose how to use the rotary multi selector to perform an operation. For example, rotating the selector clockwise and pressing the selector right may produce the same results. Since the selector can be used in various ways, concrete descriptions such as “Press the rotary multi selector J” are included only in cases where necessary.

• In the manual, the button indicating up, down, left, and right of the rotary multi selector is shown as G, H, I, and J.

Page 22

Basic Operations

Black-and-white Sepia Cyanotype

Vivid color

The m Button

Press m to display the menu for the selected mode. Use the rotary multi selector to navigate the menus (c 9).

Introduction

• L Shooting menu (c 86) • i Playback menu (c 96)

• K High-sensitivity menu (c 86) • J Calendar menu (c 55)

• n Scene menu (c 34) • L List by date menu (c 55)

• A One-touch portrait menu

• T Movie menu (c 62) • Z Setup menu

To display the one-touch portrait menu, enter one-touch portrait mode by pressing A and then press m.

To display the print menu, connect the camera to a PictBridge-compatible printer to display the print selection screen, and then press m.

To display the setup menu for shooting or playback mode, choose Z in the shooting-mode or playback-mode selection menu and then press d.

(c 43) • w Print menu2 (c 80)

(c 102)

Displayed when there are more previous menu items

Displayed when there are one or more menu items to follow

Shooting menu

Color options AF area mode

Exit

Press the rotary multi selector J or d to proceed to the next set of options.

Shooting menu

Image mode White balance Continuous BSS ISO sensitivity

Exit

The selected option

Displayed when the menu contains two or more pages

Color options

Standard color

Vivid color

Vivid color Black-and-white

Black-and-white Sepia

Sepia Cyanotype

Cyanotype

Exit

Press the rotary multi selector J or d to apply selection.

Page 23

Basic Operations

Help Displays

Press v (l) to view a description of the currently selected menu option.

Image mode

Set image quality and size.

Exit Back

• To return to the original menu, press v (l) again.

• Press m to return to shooting or playback mode.

Introduction

Page 24

First Steps

Charging the Battery

The camera uses a Rechargeable Li-ion Battery EN-EL8 (supplied). Charge the battery with the

or when the battery is running low.

Battery Charger MH-62 (supplied) before first use

1 Connect the power cable

First Steps

Connect the power cable to the battery charger 1 and insert the wall plug into a power outlet 2. The CHARGE lamp will light to show that the charger is on 3.

2 Charge the battery

Insert the battery into the battery charger.

CHARGE lamp starts blinking when battery is inserted. Charging is complete when lamp stops blinking.

About two hours are required to charge a fully exhausted battery.

Page 25

Charging the Battery

CHARGE lamp Description

Blinks Battery charging.

On Battery fully charged.

Battery error. If ambient temperature is not 5 to 35 °C (41

Flickers

to 95 °F), wait until temperature is in this range before charging. Otherwise unplug charger and remove battery immediately and take both devices to retailer or Nikonauthorized service representative.

3 Unplug the charger

Remove the battery and unplug the charger.

j Note on the Battery Charger

Be sure to read and follow the warnings for the battery charger on pages iii and iv before using the battery charger.

The supplied battery charger is for use only with a Rechargeable Li-ion Battery EN-EL8. Do not use with incompatible batteries.

First Steps

j Note on the Battery

Be sure to read and follow the warnings for the battery on page iii and the section, “Caring for the Camera” (c 120), before using the battery.

k Alternative Power Resources

• To power the camera continuously for extended periods, use an AC Adapter EH-64

(available separately from Nikon) (c 117). Do not, under any circumstances, use another make or model of AC adapter. Failure to observe this precaution could result in overheating or in damage to the camera.

• The AC adapter and the supplied audio video/USB cable cannot be used at the same time.

Page 26

Inserting the Battery

Insert a Rechargeable Li-ion Battery EN-EL8 (supplied) that has been fully charged, using the Battery Charger MH-62 (supplied), into your camera.

1 Open the battery-chamber/memory card

slot cover.

First Steps

2 Insert the battery.

Confirm that the positive (+) and negative (-) terminals are oriented correctly as described on the label at the entrance of the battery chamber, and insert the battery.

Use the side of the battery to push the orange battery latch up 1 as the battery is inserted 2. The latch drops back into place when the battery is fully inserted.

j Inserting the Battery

Inserting the battery upside down or backwards could damage the camera. Be sure to check the

battery is in the correct orientation.

3 Close the battery-chamber/memory card

slot cover.

Page 27

Removing the Battery

Turn the camera off before removing the battery. To eject the battery, open the battery-chamber/ memory card slot cover and slide the battery latch in the direction shown 1. The battery can then be removed by hand 2.

• Note that the battery may become hot during use; observe due caution when removing the battery.

Turning On and Off the Camera

To turn on the camera, press the power switch. The power-on lamp (green) will light and the monitor will turn on. To turn off the camera, press the power switch again.

If the camera is turned off, hold down i to turn the camera on in playback mode (c 26).

Inserting the Battery

First Steps

Page 28

Setting Display Language, Date, and Time

A language-selection dialog is displayed the first time the camera is turned on.

1 Press the power switch to turn on the

camera.

First Steps

The power-on lamp will light and the monitor will turn on.

2 Use the rotary multi selector to choose

the desired language and press d.

For information on using the rotary multi selector, see “The Rotary Multi Selector” (c 9).

3 Choose [Yes] and press d.

If [No] is selected, the date and time will not be set.

4 Press d.

The home time zone menu is displayed.

l Daylight Saving Time

If daylight saving time is in effect, turn on [Daylight saving] in the time zone menu and set the date.

1 Before pressing d, press the rotary multi selector H to

choose [Daylight saving].

2 Press d to enable daylight saving time (y).

Pressing d toggles the daylight saving time option on and off.

3 Press the rotary multi selector G, and then press d to

proceed to step 5.

When daylight saving time ends, turn [Daylight saving] off from the date menu (c 105) in the setup menu. The camera’s clock is automatically set back one hour.

Date

Set time and date?

Yes

Time zone

London,Casablanca

Daylight saving

Page 29

Setting Display Language, Date, and Time

5 Select your home time zone (c 107) and

press d.

The date menu is displayed.

6 Edit the day ([D]) (order of the day,

month, and year may differ in some areas) and press d.

7 Edit the month ([M]) and press d.

8 Repeat steps 6 and 7 to edit the year

([Y]), hour, and minutes. Press d after setting each item.

The row for setting the order in which the date is displayed will blink.

9 Choose the order in which the day,

month, and year are displayed and press d.

The settings are applied and monitor display exits to shooting mode.

Home time zone

London,Casablanca

Back

Date

DMY

Date

DMY

Date

DMY

Date

DMY

200701

0000

200711

0000

200711

0000

200711

1015

First Steps

Page 30

Inserting Memory Cards

Pictures are stored in the camera’s internal memory (approx.13 MB) or on removable Secure Digital (SD) memory cards (available separately) (c 117).

If a memory card is inserted in the camera, pictures are automatically stored on the memory card and pictures recorded to the memory card can be played back, deleted, or transferred. Remove the memory card to store pictures in the internal memory, or play back, delete, or

First Steps

transfer pictures from the internal memory.

1 Turn the camera off and open the

battery-chamber/memory card slot cover.

If the power-on lamp is lit, press the power switch to turn off the camera.

Make sure that the camera is off (power-on lamp is off) before inserting or removing the memory card.

2 Insert the memory card.

Slide the memory card in until it clicks into place.

Close the battery-chamber/memory card slot cover.

j Inserting Memory Cards

Inserting the memory card upside down or backwards could damage the camera or the memory card. Make sure that the memory card is

correctly oriented.

Page 31

Inserting Memory Cards

Removing Memory Cards

Before removing memory cards, turn the camera off and confirm that the power-on lamp is off.

Open the battery-chamber/memory card slot cover and press the card in 1 to partially eject the card

2. The card can then be removed by hand.

j Formatting Memory Cards

If the message at right is displayed, the memory card must be formatted before use (c 113). Note that formatting permanently deletes all pictures and other data on the memory card. Be sure to make copies of any pictures you wish to keep before formatting the memory card.

Use the rotary multi selector to choose [Yes] and press d. The confirmation dialog will be displayed. To start formatting, choose [Format] and press d.

• Do not turn the camera off or open the battery-chamber/memory card slot cover

until formatting is complete.

• The first time you insert the memory cards used in other devices into the COOLPIX S51, be

sure to format them (c 113).

Card is not formatted. Format card?

Yes

j The Write Protect Switch

SD memory cards are equipped with a write protect switch. Pictures cannot be recorded or deleted and the memory card cannot be formatted when this switch is in the “lock” position. Unlock by sliding the switch to the “write” position.

Write protect switch

First Steps

j Memory Cards

• Use only Secure Digital memory cards.

• Do not perform the following during formatting, while data are being written to or deleted

from the memory card, or during data transfer to a computer. Failure to observe this precaution could result in the loss of data or in damage to the camera or memory card.

- Eject the memory card

- Remove the battery

- Turn off the camera

- Disconnect the AC adapter

• Do not disassemble or modify.

• Do not drop, bend, or expose to water or strong physical shocks.

• Do not touch the metal terminals with your fingers or metal objects.

• Do not affix labels or stickers to the memory card.

• Do not leave in direct sunlight, closed vehicles, or areas exposed to high temperatures.

• Do not expose to humidity or to corrosive gases.

Page 32

Basic Photography and Playback: Auto Mode

Step 1 Turn the Camera On and Select L (Auto) Mode

This section describes how to take pictures in L (auto) mode, an automatic, “point-and-shoot” mode recommended for first-time users of digital cameras.

1 Press the power switch to turn on the

camera.

The power-on lamp will light and the monitor will turn on.

Basic Photography and Playback: Auto Mode

Proceed to step 4 when M is displayed.

2 Press C.

3 Use the rotary multi selector to choose

L and press d.

The camera enters L (auto) mode.

4 Check the battery level and number of

exposures remaining.

Battery level

Monitor Description

NO INDICATOR Battery fully charged.

Battery low; prepare to charge or replace the battery.

Cannot take pictures. Recharge or replace with a fully charged battery.

Warning!

Battery

exhausted.

Number of exposures remaining

The number of pictures that can be stored depends on the capacity of the memory or memory card and image mode setting.

Shooting

Battery level indicator

Number of exposures remaining

Page 33

Step 1 Turn the Camera On and Select L (Auto) Mode

Indicators Displayed in L (Auto) Mode

Internal memory indicator Pictures will be recorded to internal memory. When memory card is inserted,

Shooting mode

displayed in L (auto) mode

M is not displayed and pictures will be recorded to memory card.

Image mode Choose from seven image-mode options depending on how you plan to use the picture. The default setting is c Normal (3,264 × 2,448).

Vibration reduction icon Vibration reduction can be set up according to the shooting conditions. The default setting is [On].

l Available Functions in L (Auto) Mode

In L (auto) mode, macro mode (c 31) and exposure compensation (c 32) can be applied and pictures can be taken using the flash mode (c 28) and self-timer (c 30). Pressing m in L (auto) mode displays the shooting menu. This menu allows you to specify the image mode (c 87), white balance setting (c 89), and to apply continuous shooting (c 91), BSS (c 92), ISO sensitivity (c 93), color options (c 93), and AF area (c 94) to suit shooting conditions or your own preferences.

l Vibration Reduction

[Vibration reduction] (c 111), when [On] (default setting) is selected, can be applied to effectively reduce blur, caused by slight hand movement known as camera shake, that commonly occurs when shooting with zoom applied or at slow shutter speeds.

Vibration reduction can be used in all shooting modes.

l Auto Power Off in L (Auto) Mode (Standby Mode)

The monitor will dim to reduce the drain on the battery if no operations are performed for about five seconds. The monitor will brighten when camera controls are used. At default settings, the monitor will turn off altogether if no operations are performed for about a minute during shooting and playback. The camera will turn off automatically if no operations are performed for another three minutes (c 112).

Basic Photography and Playback: Auto Mode

Page 34

Step 2 Frame a Picture

1 Ready the camera.

Hold the camera steadily in both hands, keeping your fingers and other objects away from the lens, flash, and self-timer lamp.

Basic Photography and Playback: Auto Mode

2 Frame the picture.

Position the main subject near the center of the monitor.

Using the Zoom

Use the zoom buttons to activate optical zoom. Press t (j) to zoom out, increasing the area visible in the frame, or v (k) to zoom in so that the subject fills a larger area of the frame.

When the camera is zoomed in to the maximum magnification (3×), holding down v (k) triggers digital zoom. The subject is magnified up to 4×, for a total magnification of 12×.

A monitor indicator shows the current zoom ratio.

Zoom out Zoom in

Zoom indicator displayed when the zoom buttons are

Optical zoom (up to 3×)

Zoom indicator turns yellow when digital zoom is in effect.

Page 35

Step 2 Frame a Picture

j Digital Zoom

Unlike optical zoom, data from the camera’s image sensor are processed digitally with digital zoom. Details visible at maximum optical zoom are simply enlarged, producing a slightly “grainy” image.

l High-sensitivity Shooting Mode

In high-sensitivity shooting mode (c 33), sensitivity is increased to reduce blurring caused by camera shake or subject movement under low lighting.

Basic Photography and Playback: Auto Mode

Page 36

Step 3 Focus and Shoot

1 Press the shutter-release button halfway.

By default, the camera automatically focuses on the subject in the center focus area. When the subject is in focus, the focus area and focus indicator (p) glow green.

When the camera is unable to focus, the focus area and focus indicator blink red. Change the composition and try again.

Basic Photography and Playback: Auto Mode

When digital zoom is in effect, the focus area is not displayed and focus is acquired on the subject in the center of the monitor.

2 Press the shutter-release button the rest

of the way down.

The picture will be recorded to the memory card or internal memory.

l Shutter-Release Button

The camera features a two-stage shutter-release button. To set focus and exposure, press the shutter-release button halfway, stopping when you feel resistance. Focus and exposure lock while the shutter-release button is held in this position. To release the shutter and take a picture, press the shutter-release button the rest of the way down. Do not use force when pressing the shutter-release button, as this may result in camera shake and blurred pictures.

Take pictureSet focus and

exposure

Page 37

Step 3 Focus and Shoot

j During Recording

While pictures are being recorded, the y (wait) icon will be displayed, and the M (internal memory) or O (memory card) icon will blink. Do not turn the camera off, open the batterychamber/memory card slot cover, or remove or disconnect the power source while these icons are displayed. Cutting power or removing the memory card in these circumstances could result in loss of data or in damage to the camera or card.

k Autofocus

Autofocus may not perform as expected in the following situations. In some rare cases, the subject may not be in focus despite the fact that the focus area and focus indicator glow green:

• Subject is very dark

• Objects of sharply differing brightness are included in the scene (e.g., the sun is behind the

subject and is in deep shadow)

• No contrast between the subject and surroundings (e.g., when the subject is standing in

front of a white wall, wearing a white shirt)

• Several objects are at different distances from the camera (e.g., the subject is inside a cage)

• Subject is moving rapidly

In the situations noted above, try pressing the shutter-release button halfway to refocus several times, or focus on another subject and use focus lock. When using focus lock, be sure that the distance between the camera and the subject with which focus was locked is the same as that for the actual subject.

l Focus Lock

To focus on off-center subject, use focus lock as described blow.

• Be sure that the distance between the camera and the subject does not change while focus

is locked.

Basic Photography and Playback: Auto Mode

Position the subject in the center focus area.

Press the shutterrelease button halfway.

Confirm that the focus indicator (p) is green.

Continue holding down the shutterrelease button halfway and recompose the

Press the shutterrelease button the rest of the way down

picture.

l AF-assist Illuminator and Flash

If the subject is poorly lit, the AF-assist illuminator may light by pressing the shutter-release button halfway, or the flash may fire by pressing the shutter-release button all the way down.

Page 38

Step 4 Viewing and Deleting Pictures

15/11/2007 15:30


Full-Frame Playback

Press i.

The last picture taken will be displayed. Use the rotary multi selector G, H, I, or J to view

additional pictures.

Pictures taken in “tall” orientation will be rotated automatically (c 112). The rotating direction can be changed (c 100).

Basic Photography and Playback: Auto Mode

Pictures may be displayed briefly at low resolution while being read from the memory card or internal memory.

Press i or the shutter-release button to switch to shooting mode.

When M is displayed, pictures stored in the internal memory will be displayed. When memory card is inserted, M is not displayed and pictures stored on the memory card will be displayed.

Deleting Pictures

1 Press T to delete the picture currently

displayed in the monitor.

nternal memory

indicator


15/11/2007 15:30

2 Use the rotary multi

selector to select [Yes] and press d.

To exit without deleting the

picture, choose [No] and press d.

Erase 1 image?

Yes

Done

Page 39

Step 4 Viewing and Deleting Pictures

k Full-Frame Playback Mode

The following options are available in full-frame playback mode.

Option Use Description c

Playback zoom v (k)

View thumbnails t (j)

Press v (k) to enlarge view of picture currently displayed in monitor up to about 10×.

Press t (j) to display nine, 16, or 25 picture thumbnails.

Display thumbnail wheel

D-Lighting

Record/play voice memo

Switch to shooting mode

Quick Playback Zoom

Pressing v (k) during full-frame playback zooms the current picture in 3×, with the center of the picture displayed in the monitor (Quick Playback Zoom) (c 46). Press d to return to full-frame playback.

Rotate the rotary multi selector to display the thumbnail wheel.

Press A to enhance brightness and contrast in dark portions of pictures.

Press d to record or play back voice memos up to 20 seconds in length.

Press i or the shutter-release button to switch to the shooting mode selected in the shootingmode selection menu.

X3.0

k Viewing Pictures

• When the camera is off, holding down i will turn the camera on in full-frame playback

mode. If the camera is turned off in voice recording mode (c 67) or audio playback mode (c 69), the camera will be turned on in audio playback mode.

• Pictures stored in the internal memory can only be viewed if no memory card is inserted.

k Deleting the Last Picture Taken

In shooting mode, press T to delete the last picture taken. When the confirmation dialog shown at right is displayed, use the rotary multi selector to choose [Yes] and press d.

To exit without deleting the picture, choose [No] and press d.

Erase 1 image?

Yes

Basic Photography and Playback: Auto Mode

Page 40

Using the Flash

The flash has a range of about 0.3–6 m (1–19 ft. 8.0 in.) when the camera is zoomed out all the way. With maximum optical zoom applied, the range is about 0.3–4 m (1–13 ft. 1.5 in.) (when [ISO sensitivity] is set to [Auto]). The following flash modes are available.

z Auto (default setting for L (auto) mode)

Flash fires automatically when lighting is poor.

A Auto with red-eye reduction

Reduces “red-eye” in portraits (c 29).

Basic Photography and Playback: Auto Mode

B Off

Flash will not fire even when lighting is poor.

J Fill flash

Flash fires when a picture is taken. Use to “fill-in” (illuminate) shadows and back-lit subjects.

D Slow sync

Flash illuminates main subject; slow shutter speeds are used to capture background at night or under dim light.

1 Press J (flash mode).

The flash mode menu is displayed.

2 Use the rotary multi selector to choose

the desired flash mode and press d.

The icon for the selected flash mode is displayed at the top of the monitor.

When z (auto) is applied, z is only displayed for five seconds.

The flash mode applied in L (auto) mode and highsensitivity shooting mode is stored in the camera’s memory even after the camera is turned off.

If a setting is not applied by pressing d within a few seconds, the selection will be cancelled.

Flash mode

Page 41

Using the Flash

j Shooting When Lighting Is Poor and the Flash Is Disabled (B)

• Use of a tripod is recommended to stabilize the camera during shooting and avoid the

effects of camera shake. Turn vibration reduction (c 111) off when using a tripod.

•The W icon is displayed when the camera automatically increases sensitivity. Pictures taken

when W is displayed may be slightly mottled.

• When W is displayed and higher sensitivity is applied, noise reduction may be automatically

applied as pictures taken are recorded; results in increased recording times.

j Note on Using the Flash

When using the flash at a wide-angle zoom position, reflections from dust particles in the air may appear as bright spots in pictures. To reduce these reflections, set the flash mode to B (Off) or zoom in on the subject.

k The AF-assist Illuminator

If lighting is poor, the AF-assist illuminator may light to assist the focus operation when the shutter-release button is pressed halfway. The illuminator has a range of about 3.5 m (11 ft.

5.7 in.) at the maximum wide-angle position and about 3 m (9 ft. 10.1 in.) at the maximum

telescopic position. The AF-assist illuminator can be set to [Off] manually (c 111), although in this case the camera may not focus when lighting is poor.

k The Flash Indicator and Flash Lamp

The flash indicator and flash lamp show flash status when the shutter-release button is pressed halfway.

• On: Flash will fire when picture is taken.

• Blinks: Flash charging. Wait a few seconds and

try again.

• Off: Flash will not fire when picture is taken.

Basic Photography and Playback: Auto Mode

When pictures are taken using the flash and a low battery, the monitor display will turn off and the flash lamp will blink until the flash is fully charged.

k Red-Eye Reduction

The COOLPIX S51 is equipped with an advanced red-eye reduction system. Pre-flashes are fired several times at low intensity before the main flash to reduce “red-eye.” If the camera detects “red-eye” after a picture is taken, Nikon’s own In-Camera Red-Eye Fix processes the image as it is recorded. Therefore, there is a slight delay before the shutter-release button operates normally to take another picture.

• Not recommended for when shutter-release timing is essential.

• Red-eye reduction may not always produce the desired results.

• In some rare cases, other portions of pictures may be affected.

Use flash modes other than auto with red-eye reduction in above cases.

Page 42

Taking Pictures with the Self-Timer

The camera is equipped with a ten-second and three-second timer for selfportraits. When using the self-timer, use of a tripod is recommended. Turn vibration reduction (c 111) off when using a tripod.

1 Press H (self-timer).

The self-timer menu is displayed.

Basic Photography and Playback: Auto Mode

2 Use the rotary multi selector to choose

[10s] or [3s] and press d.

[10s] (ten seconds): suited for important occasions

[3s] (three seconds): suited for preventing camera

The mode selected for self-timer is displayed. If a setting is not applied by pressing d within a few seconds, the selection will be

cancelled.

3 Frame the picture and press the

shutter-release button halfway.

Focus and exposure will be set.

(such as weddings)

shake

Self-timer

10s

101010

4 Press the shutter-release button

the rest of the way down.

The self-timer starts and the self-timer lamp will blink. The lamp stops blinking one second before the photograph is taken and remains lit until the shutter is released.

The number of seconds remaining before the shutter is released is displayed in the monitor.

To stop the timer before a picture is taken, press the shutter-release button again.

101010

Page 43

Macro (Close-up) Mode

Macro mode is used for taking pictures of objects as close as 4 cm (1.6 in.). Note that the flash may be unable to light entire subject at distances of less than 30 cm (11.8 in.).

1 Press L (macro mode).

The macro mode menu is displayed.

2 Use the rotary multi selector to choose

[ON] and press d.

The macro mode icon (F) is displayed.

The monitor will return to the normal display for the current mode if the setting is not applied by pressing d within a few seconds.

Macro mode

Basic Photography and Playback: Auto Mode

3 Press v (k) or t (j) to frame the

picture.

The camera can focus at a distance of 4 cm (1.6 in.) at the zoom position at which F glows green (the zoom indicator is positioned over F).

FFF

4 Focus and shoot.

The macro mode applied in L (auto) mode or highsensitivity shooting mode is stored in the camera’s memory even after the camera is turned off.

k Macro Mode

In macro mode, the camera focuses continuously, even when the shutter-release button is not pressed halfway to lock focus.

Page 44

Exposure Compensation

Exposure compensation is used to alter exposure from the value suggested by the camera to make pictures brighter or darker.

1 Press the rotary multi selector I

(exposure compensation).

Basic Photography and Playback: Auto Mode

2 Use the rotary multi selector to adjust

exposure.

• When the picture is too dark: adjust the exposure compensation to “+” side.

• When the picture is too bright: adjust the exposure compensation to “-” side.

• Exposure compensation can be set to values between -2.0 and +2.0 EV.

Exposure compensation

3 Press d.

•The I icon is displayed in the monitor.

• The monitor will return to the normal display for the current mode if the setting is not applied by pressing d within a few seconds.

• The exposure compensation applied in L mode or high-sensitivity shooting mode is stored in the camera’s memory even after the camera is turned off.

Page 45

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

High-sensitivity Shooting Mode

In high-sensitivity shooting mode, sensitivity is increased with shooting under low lighting to reduce blurring caused by camera shake or subject movement, allowing you to capture the atmosphere of the scene. ISO sensitivity will be automatically increased to a maximum of 1600 depending upon the brightness of the subject.

1 Enter high-sensitivity shooting

mode by pressing C in

High sensitivity

shooting mode, selecting K (use the rotary multi selector), and then pressing d.

2 Frame the subject and take the

picture.

j Notes on High-sensitivity Shooting Mode

• This mode reduces effects of camera shake even for shooting under low lighting; however, when shooting without the flash, use of a tripod is recommended. Turn vibration reduction (c 111) off when using a tripod.

• Pictures taken in this mode may become somewhat grainy.

• Focus may not be precisely fixed in extremely dark places.

l High-sensitivity Shooting Mode

In high-sensitivity shooting mode, pressing m displays the high-sensitivity menu. The items available from this menu are the same as those available in the L (auto) mode shooting menu (c 86), except that [ISO sensitivity] is not available in the high-sensitivity menu. Just as with L (auto) mode, the flash mode, self-timer, macro mode, and exposure compensation are available.

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

Page 46

Scene Modes

The camera offers a choice of 15 “scene” options. Camera settings are automatically optimized for the selected subject type.

B Portrait H Beach/snow N Museum

E Landscape I Sunset K Fireworks show

P Sports J Dusk/dawn O Copy

D Night portrait G Night landscape L Backlight

C Party/indoor M Close up F Panorama assist

1 Enter scene mode by pressing

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

C in shooting mode, selecting n (use the rotary multi selector), and then pressing d.

2 Press m to display the scene

menu screen, and choose the desired scene and press d.

3 Frame the subject and take the

picture.

l Image Mode

[Z Image mode] (c 87) can be set in the scene menu. Changes made to these settings apply to all shooting modes.

Scene menu

Beach/snow Sunset

Dusk/dawn

Night landscape

Close up

Exit

Scene menu

Image mode

Exit

Scene

Page 47

Scene Modes

Features

B Portrait

Use this mode for portraits in which the main subject stands out clearly. Portrait subjects exhibit smooth, natural-looking skin tones.

• Camera focuses on subject in center of frame.

• Digital zoom cannot be applied.

C A* H Off* F Off I 0.0* u Auto*

* Other settings can be selected.

E Landscape

Use this mode for vivid landscapes and cityscapes.

• Camera focuses at infinity. The focus indicator (c 24)

always glows green when the shutter-release button is pressed halfway. Note, however, that objects in the foreground may not always be in focus.

C B H Off* F Off I 0.0* u Off

* Other settings can be selected.

P Sports

Use this mode for dynamic action shots that freeze the action in a single shot and record motion in a series of pictures.

• While the shutter-release button is pressed halfway, the camera focuses continuously until focus is acquired and locked.

• While shutter-release button is held down, pictures are taken at rate of about 0.8 frames per second (fps) when image mode is set to [c Normal (3264)].

• The maximum frame rate with continuous shooting may vary depending upon the current image mode setting and the memory card used.

C B H Off F Off I 0.0* u Off

* Other settings can be selected.

k Icons Used for Descriptions

The following icons are used for descriptions in this section: J, flash mode (c 28); H, selftimer (c 30); F, macro mode (c 31); I, exposure compensation (c 32); u, AF-assist illumination (c 111).

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

Page 48

Scene Modes

D Night portrait Q

Use this mode to achieve a natural balance between the main subject and background lighting in portraits taken at night.

• Camera focuses on subject in center of frame.

• Digital zoom cannot be applied.

C A1H Off

Fill flash with slow sync and red-eye reduction.

Other settings can be selected.

F Off I 0.02u Auto

C Party/indoor

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

Captures the effects of candlelight and other indoor background lighting.

• Camera focuses on subject in center of frame.

• Turn vibration reduction (c 111) off when using a tripod.

C A1H Off

Fill flash with slow sync and red-eye reduction. Other settings can be selected.

Other settings can be selected.

F Off I 0.02u Auto

H Beach/snow

Captures the brightness of such subjects as snowfields, beaches, or sunlit expanses of water.

• Camera focuses on subject in center of frame.

C z* H Off* F Off* I 0.0* u Auto*

* Other settings can be selected.

Q: For those scene modes with Q, use of a tripod is recommended. Turn vibration reduction

(c 111) off when using a tripod.

Page 49

Scene Modes

I Sunset Q

Preserves the deep hues seen in sunsets and sunrises.

• Camera focuses at infinity. When the shutter-release button is pressed halfway, the focus indicator (c 24) always lights; however, focus may not be set for near subjects, while the camera focuses at infinity.

C B H Off* F Off I 0.0* u Off

* Other settings can be selected.

J Dusk/dawn Q

Preserves the colors seen in the weak natural light before sunrise or after sunset.

C B H Off* F Off I 0.0* u Off

* Other settings can be selected.

G Night landscape Q

Slow shutter speeds are used to produce stunning night landscapes.

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

C B H Off* F Off I 0.0* u Off

* Other settings can be selected.

Q: For those scene modes with Q, use of a tripod is recommended. Turn vibration reduction

(c 111) off when using a tripod.

Page 50

Scene Modes

M Close up

Photograph flowers, insects, and other small objects at close range.

• The camera enters macro mode (c 31) and the camera automatically zooms to the position at the closest distance at which the camera can focus. The camera can focus at distances as close as 4 cm (1.6 in.) when F is green. The closest distance at which the camera can focus varies depending upon zoom position. Digital zoom cannot be applied.

• [AF area mode] is set to [Manual] (c 94). Press d and select the focus area in which the camera will focus.

• While the shutter-release button is pressed halfway, the camera focuses continuously until focus is acquired and

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

locked.

• Turn vibration reduction (c 111) off when using a tripod.

C B* H Off* F On I 0.0* u Auto*

* Other settings can be selected.

N Museum

Use indoors where flash photography is prohibited (for example, in museums and art galleries) or in other settings in which you do not want to use the flash.

• Camera focuses on subject in center of frame.

• BSS (c 92) turns on automatically.

• Turn vibration reduction (c 111) off when using a tripod.

C B H Off* F Off* I 0.0* u Off

* Other settings can be selected.

Page 51

Scene Modes

K Fireworks show Q

Slow shutter speeds are used to capture the expanding burst of light from a firework.

C B H Off F Off I 0.0 u Off

O Copy

Provides clear pictures of text or drawings on a white board or in print.

• Camera focuses on subject in center of frame.

• Use macro mode (c 31) to focus at short ranges.

• Colored text and drawings may not show up well.

C B* H Off* F Off* I 0.0* u Auto*

* Other settings can be selected.

L Backlight

Use when light is coming from behind your subject, throwing features or details into shadow. The flash fires automatically to “fill in” (illuminate) shadows.

• Camera focuses on subject in center of frame.

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

C J H Off* F Off I 0.0* u Auto*

* Other settings can be selected.

Q: For those scene modes with Q, use of a tripod is recommended. Turn vibration reduction

(c 111) off when using a tripod.

Page 52

Scene Modes

F Panorama assist

Use when taking a series of pictures that will later be joined to form a single panorama using Panorama Maker.

C B* H Off* F Off* I 0.0* u Auto*

* Other settings can be selected.

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

Taking Pictures for a Panorama

The camera focuses on the subject in the center of the frame. Use a tripod for best results. Turn vibration reduction (c 111) off when using a tripod.

1 Use the rotary multi selector to choose

[F Panorama assist] in the scene menu and press d.

The yellow panorama direction icon (E) is displayed to show the direction in which pictures will be joined.

2 Use the rotary multi selector to choose

the direction and press d.

Select how pictures will be joined together in the completed panorama; right (V), left (U), up (S), or down (T). The panorama direction icon (E) is displayed to the direction pressed, and changes to white when d is pressed. Apply flash mode (c28), self-timer (c30), macro mode (c31), and exposure compensation (c32) settings with this step, if necessary. Press d to reselect the direction.

3 Take the first picture.

The first picture is displayed in the first third of the monitor.

Scene menu

Museum

Fireworks show

Copy

Backlight

Panorama assist

Exit

Page 53

Scene Modes

4 Take the second picture.

Compose the next picture so that it overlaps the first picture.

Repeat until you have taken the necessary number of pictures to complete the scene.

5 Press d when shooting is completed.

The camera returns to step 2.

j Panorama Assist

Flash mode (c 28), self-timer (c 30), macro mode (c 31), and exposure compensation (c 32) settings cannot be adjusted after the first picture is taken. Pictures cannot be deleted, nor can zoom or image-mode setting (c 87) be adjusted until the series is finalized.

The panorama series is terminated if the camera enters standby mode with the auto off function (c 112) during shooting. Setting the time allowed to elapse before the auto off function is enabled to a longer setting is recommended.

l Exposure Lock

or (when macro mode is applied) is displayed to indicate that white balance and exposure have been locked at the values set with the first shot. All pictures taken in a panorama series have the same exposure and white-balance settings.

Shooting Suited for the Scene - High-sensitivity Shooting Mode, Scene Mode

l Panorama Maker

Install Panorama Maker from the supplied Software Suite (CD). Transfer pictures to a computer (c 73) and use Panorama Maker (c 76) to join them in a single panorama.

l Image File Names and Folder Names

See “Image/Sound File and Folder Names” (c 118).

Page 54

One-Touch Portrait Mode

Taking Pictures in the One-Touch Portrait Mode

For portrait shots, press A when the camera is in L (auto) mode, highsensitivity shooting mode, scene mode, and movie mode.

The following features are automatically activated:

• Portrait: The portrait subject stands out clearly.

• Face-priority AF: The camera automatically detects and focuses on faces.

• Advanced red-eye reduction: Reduces “red-eye” caused by the flash

(c 29). Macro mode is not available in one-touch portrait mode.

Press A again to return to the shooting mode selected in the shootingmode selection menu.

1 Press A (one-touch portrait mode).

One-Touch Portrait Mode

2 Frame the subject.

When the camera detects a face, the guide is displayed with a double yellow border.

When the camera detects more than one face, the closest face is framed by a double border and the rest by a single border. The camera focuses on the face framed by the double border and adjusts exposure accordingly. If the camera loses its ability to detect a face (for example, because the subject has looked away from the camera), borders are no longer displayed. Digital zoom cannot be applied.

3 Press the shutter-release button

halfway.

Focus and exposure are set, and the double border glows green.

4 Press the shutter-release button the rest

of the way down to take a picture.

Page 55

The One-Touch Portrait Menu

Press m in one-touch portrait mode to display the one-touch portrait menu. In addition to image mode, portrait effects (reducing vividness of skin tones, softening overall image) can be set.

Z Image mode

Choose an image size and quality (c 87).

B Portrait effect

Choose from [Normal], [Brighter] (reduces vividness of skin tones), and [Softer] (soft effect).

j Face-Priority AF

• If no face is recognized when the shutter-release button is pressed halfway, the camera

focuses on the center of the frame.

• The camera may be unable to detect faces in the following situations:

- When faces are partially hidden by sunglasses or other obstructions

- When the subject is not looking directly at the camera

- When faces take up too much or too little of the frame

• The camera’s ability to detect faces depends on a variety of factors, including whether or

not the subject is facing the camera.

• If the yellow double border blinks when the shutter-release button is pressed halfway, the

camera was unable to focus. Release the button and try again.

• In some rare cases shooting subjects with which autofocus may not perform as expected

(c 25), the subject may not be in focus despite the fact that the double border glows green. Should this occur, switch to L (auto) mode, refocus on another subject positioned at the same distance from the camera as the actual portrait subject, and use focus lock (c 25).

One-Touch Portrait Mode

k Settings for One-Touch Portrait Mode

• Flash mode: Changeable

• Self-timer: Available

• Macro mode: Off

• Exposure compensation: Available

Page 56

More on Playback

15/11/2007 30

Viewing Multiple Pictures: Thumbnail Playback

Press t (j) in full-frame playback (c 26) to display pictures in “contact sheets” of thumbnail images. The following operations can be performed while thumbnails are displayed.

To Use Description c

Choose pictures

Change number of pictures displayed

Cancel thumbnail

More on Playback

playback

D-Lighting A

Use the rotary multi selector to choose pictures.

When t (j) is pressed, display picture thumbnails in the following order:

9 → 16 → 25

When v (k) is pressed, the number of thumbnails changes reversely.

Press d to cancel thumbnail playback and

return to full-frame playback.

Press A to enhance brightness and contrast in dark portions of pictures.

Switch to shooting mode

Press i or the shutter-release button to return to the last shooting mode selected.

15/11/2007 30

–

k 9-picture Thumbnail Playback Mode Display

When protected pictures (c 99) are displayed in 9-picture thumbnail playback mode, the icon shown at right is displayed with them. Movies are displayed as film frames. Icon is not displayed with protected pictures in 16- or 25-picture thumbnail playback modes.

Q: Protect icon

Film frames

Page 57

Viewing Multiple Pictures: Thumbnail Wheel Playback

15/11/2007 0010

Rotate the rotary multi selector in full-frame playback (c 26) to display the thumbnail wheel.

15/11/2007 0010

The thumbnail wheel is displayed at the right of the monitor. When a thumbnail is selected, the thumbnail is displayed at the left of the monitor. The following operations can be performed while thumbnail wheel is displayed.

To Use Description c

Choose pictures

Cancel thumbnail playback

D-Lighting A

Rotate the rotary multi selector, or press the rotary multi selector GH, to choose pictures.

Press d or v (k) to cancel thumbnail

playback and return to full-frame playback.

v (k)

Press A to enhance brightness and contrast in dark portions of pictures.

15/11/2007 0010

Switch to shooting mode

Press i or the shutter-release button to return to the last shooting mode selected.

More on Playback

Page 58

Taking a Closer Look: Playback Zoom

Pressing v (k) during full-frame playback (c 26) zooms the current picture in 3×, with the center of the picture displayed in the monitor (Quick Playback Zoom).

The guide at lower right shows which portion of the picture is enlarged. Change the portion of the picture displayed by pressing the rotary multi selector G, H, I, or J.

Use the zoom buttons with quick playback zoom to enlarge pictures to the desired magnification ratio. While the image is zoomed in, the zoom ratio is displayed in the monitor. The following operations can be performed while pictures are zoomed in.

To Use Description c

Zoom in v (k)

More on Playback

Zoom out t (j

View other areas of picture

Switch to fullframe playback

Crop picture

Zoom increases each time v (k) is pressed, to a maximum of 10×.

Zoom decreases each time t (j) is pressed.

)

When the magnification ratio reaches 1×, the display returns to full-frame playback.

Press the rotary multi selector G, H, I, or J to scroll to areas of the picture not visible in the monitor.

Press d to cancel playback zoom and return to full-frame playback.

Press m to crop current picture to contain only the portion visible in the monitor.

Switch to shooting mode

Press i or the shutter-release button to return to the last shooting mode selected.

X3.0

X4.0

–

Page 59

Editing Pictures

Use the COOLPIX S51 to edit pictures in-camera and store them as separate files (c 118). The editing features described below are available.

Editing function Description

D-Lighting

Crop

Small picture

k Picture Editing

• Pictures taken at an image mode setting of [16:9] (c 87) cannot be edited.

• The COOLPIX S51 editing functions may not be available for pictures taken with non-

COOLPIX S51 digital cameras.

• If a copy created using the COOLPIX S51 is viewed on a different digital camera, the picture

may not be displayed or may not be transferred to a computer.

• Editing functions are not available when there is not enough free space in the internal

memory or on the memory card.

k Restrictions on Picture Editing (y: available, –: not available)

1st editing D-Lighting Crop Small picture

D-Lighting – yy

Crop –––

Small picture –––

• Pictures cannot be edited twice with the same editing function.

• The D-Lighting should be done first while the restricted use of combination exists.

Create a copy of the current picture with enhanced brightness and contrast, brightening dark portions of the picture.

Enlarge the image or refine the composition and create a copy containing only the portion visible in the monitor.

Create a small copy of pictures suitable for use on web pages or as e-mail attachments.

More on Playback

2nd editing

l Original Pictures and Edited

• Copies created with editing functions are not deleted if the original pictures are deleted.

The original pictures are not deleted if copies created with editing functions are deleted.

• Edited copies are stored with the same recording date and time as the original.

• Edited copies are not marked for printing (c 83) or protecting (c 99) as the original.

Page 60

Editing Pictures

15/11/2007 15:30


Enhancing Brightness and Contrast: D-Lighting

D-Lighting can be used to create copies with enhanced brightness and contrast, brightening dark portions of a picture. Enhanced copies are stored as separate files.

1 Select the desired picture from full-

frame (c 26), thumbnail (c 44), or thumbnail wheel (c 45) playback and press A.

The results of D-Lighting enhancement can be confirmed in the monitor.

2 Use the rotary multi selector to choose

[OK] and press d.

A new copy with enhanced brightness and contrast is

More on Playback

created. To cancel D-Lighting, choose [Cancel] and press d.

D-Lighting copies can be recognized by the z icon displayed during playback.

D-Lighting

Cancel

15/11/2007 15:30


Page 61

Editing Pictures

Creating a Cropped Copy: Crop

This function is only available when D is displayed in the monitor with playback zoom (c 46) enabled. Cropped copies are stored as separate files.

1 Press v (k) to zoom in on the image.

2 Refine copy composition.

Press v or t to adjust the zoom ratio. Press the rotary multi selector G, H, I, or J to

scroll the picture until only the portion you want to copy is visible in the monitor.

X4.0

3 Press m.

The confirmation dialog will be displayed.

4 Use the rotary multi selector to choose

[Yes] and press d.

A new picture, containing only the portion visible in the monitor, is created.

Depending on the size of the original picture and the zoom ratio in effect at the time the copy was created, the camera will automatically select one of the following image-mode settings for cropped copies (unit: pixels).

• c 3,264 × 2,448 • d 2,592 × 1,944 • a 2,272 × 1,704 • e 2,048 × 1,536

• f 1,600 × 1,200 • g 1,280 × 960 • h 1,024 × 768 • i 640 × 480

• J 320 × 240 • K 160 × 120

Save this image as displayed?

Yes

More on Playback

Page 62

Editing Pictures

H Resizing Pictures: Small Picture

Create a small copy of the current picture. Small copies are stored as JPEG files with a compression ratio of 1:16. The following sizes are available.

Option Description

I 640×480 Suited to television playback. J 320×240 Suited to display on web pages. K 160×120 Suitable for e-mail attachments.

1 Select the desired picture from full-

frame (c 26), thumbnail (c 44), or thumbnail wheel (c 45) playback mode and press m.

The playback menu is displayed.

2 Use the rotary multi selector to choose

[Small pic.] and press d.

More on Playback

3 Choose the desired copy size and press

A confirmation dialog will be displayed. To cancel, press m.

4 Choose [Yes] and press d.

A new, smaller copy is created.

Playback menu

Small pic. Copy

Exit

Small pic.

640

480

320

240

160

120

Exit

Create small picture file?

Yes

Page 63

Voice Memos: Recording and Playback

15/11/2007 15:30


17s

15/11/2007 15:30


Use the camera’s built-in microphone to record voice memos for pictures marked with E in full-

15/11/2007 15:30


frame playback (c 26).

Recording Voice Memos

A voice memo, up to 20 seconds in length, will be recorded while d is pressed down.

Recording ends after about 20 seconds or when d is released.

• Do not touch the built-in microphone

during recording.

• During recording, F and P blink in the monitor display.

Playing Voice Memos

Press d while a picture is displayed in full-frame playback to play voice memo. Playback ends when the voice memo ends or d is pressed again.

• Pictures with voice memos can be

recognized by the A:P and P icons.

• Use the zoom buttons to adjust

playback volume. Press t (j) to lower volume, or v (k) to raise volume.

15/11/2007 15:30


Deleting Voice Memos

Select a picture with a voice memo and press T. Use the rotary multi selector to choose [P] and press d. Only the voice memo will be deleted.

Erase 1 image?

Yes

17s

More on Playback

j Voice Memos

• Voice memos are assigned the picture file name they are attached to with the three-letter

extension “.WAV” (e.g., DSCN0015.WAV) (c 118).

• If a voice memo already exists for the current picture, it must be deleted before a new voice

memo can be recorded.

• The COOLPIX S51 may be not able to attach a voice memo to pictures recorded by other

cameras.

Page 64

Viewing Pictures by Date

15/11/2007 15:30


In calendar mode or list by date mode, pictures taken on a specified date can be displayed. When m is pressed, the calendar menu or the list by date menu is displayed, and all pictures taken on a specified date can be selected for deletion, printing, and protection.

Selecting a Date in Calendar Mode

1 Enter calendar mode by pressing

C in playback mode, selecting J (use the rotary multi selector), and then pressing d.

2 Choose the desired date and press d.

Dates for which pictures exist are underlined in yellow.

Press t (j) to view previous month, press v (k) to

More on Playback

view following month.

The first picture for that date will be displayed fullframe.

Press t (j) in full-frame playback to return to calendar mode.

15/11/2007 15:30

Calendar


Page 65

Selecting a Date in List by Date Mode

20/11/2007 15:30


Enter list by date mode by

pressing selecting selector), and then pressing

Dates for which pictures exist will be listed.

in playback mode,

(use the rotary multi

Viewing Pictures by Date

List by date

2 Choose the desired date and press d.

Camera lists up to 29 dates. If pictures exist for more than 29 dates, all pictures recorded earlier than most recent 29 dates will be listed together as [Others].

The first picture for that date will be displayed fullframe.

Press t (j) in full-frame playback to return to the date list.

List by date

20/11/2007 3

15/11/2007 Others

20/11/2007 15:30


More on Playback

Page 66

Viewing Pictures by Date

Using Calendar Mode and List by Date Mode

To Use Description c

Select date Use the rotary multi selector to select a date. –

Select month (calendar mode only)

Switch to fullframe playback

Delete picture

More on Playback

View calendar or list by date menu

View playback mode menu

Switch to shooting mode

Press t (j) to view previous month, press v (k) to view following month.

Press d to display the first picture taken on the selected date. Press t (j) in full-frame playback to return

to the calendar or list by date mode selected before viewing in full-frame playback.

Press T after selecting a date, and a confirmation dialog will be displayed. Choose

[Yes] and press d to delete all pictures taken on the selected date.

Press m to display the calendar or list by

date menu. Press C to display the playback-mode

selection menu.

Press i to return to the last shooting mode

selected.

j Notes on Calendar Mode and List by Date Mode

• Only the most recent 9,000 pictures can be displayed in calendar mode or in list by date

mode. If a date includes the 9,001st picture, an asterisk [*] is displayed next to the number of pictures for that date.

• Pictures taken with no date stamp are not listed in these modes.

–

Page 67

Viewing Pictures by Date

Calendar and List by Date Menus

Press m in either mode to display the following menus for only the pictures taken on the specified date.

Print set c 83 Slide show c 98 Delete c 99 Protect c 99 Rotate image* c 100 Small picture* c 50 * During full-frame playback only

The procedure for selecting pictures in calendar or date list playback differs from that in full-frame playback as follows:

• In calendar or date list playback, the options apply to all pictures taken on

the currently selected date.

• In full-frame playback, although the options apply only to the picture

currently displayed full frame, other pictures taken on the same date can be selected.

More on Playback

j Print Set

When print marking already exists for pictures taken on dates other than that specified, a confirmation dialog [Save print marking for other dates?] will be displayed. Select [Yes] to add the new print marking to the existing marking. Select [No] to remove the existing print marking and leave only the new marking.

Page 68

Pictmotion by muvee

Pictmotion* creates slide show movies with custom transitions and background music.

It is only available when a memory card is inserted in the camera.

* Pictmotion is powered by muvee Technologies.

Creating a Pictmotion Movie

This section describes the easiest way to create a Pictmotion movie.

1 Enter Pictmotion mode by

pressing C in playback mode, selecting P (use the rotary multi selector), and then pressing d.

2 Choose M and press d.

More on Playback

3 Choose [All images] and press d.

A Pictmotion movie using the 30 most recent pictures (default setting) will be created.

After the created Pictmotion movie is automatically played back, a confirmation dialog will be displayed.

4 Choose [Yes] and press d.

The Pictmotion movie is saved and the monitor display returns to that shown in step 2. An icon for the saved movie will be displayed in the monitor.

Settings for saved Pictmotion movies cannot be changed. If you wish to change the settings, create a new Pictmotion movie with the desired settings.

Pictmotion by muvee

Picture selection

All images

List by date

View images

Save Pictmotion?

Yes

Change settings

Page 69

Creating a Custom Pictmotion Movie

Pictmotion by muvee

1 Use the rotary multi selector to choose

[View images] in the picture selection screen (c 56, step 3) and press d.

The check box is selected (y).

Picture selection

All images

List by date

View images

2 Choose [All images] or [List by date] and press d.

[All images]: Proceed to step 4 [List by date]: Proceed to step 3

3 Select a date.

• Press d to select a date in the list by date screen (y). Press d again to cancel the selection.

• Multiple dates can be selected.

• Press the shutter-release button to finalize date selection.

4 Choose pictures.

If [All images] is selected in step 2, all pictures will be displayed. If [List by date] is selected, only pictures taken on the date selected in step 3 will be displayed. Rotate the rotary multi selector to choose pictures, and press the rotary multi selector G or H to select pictures (up to 200) in the select image screen (y). Remove chosen pictures from the selection by highlighting them and pressing the rotary multi selector G or H a second time. Press v (k) to view selected picture full-frame; press t (j) to return to thumbnail display. Press d to finalize picture selection. After the created Pictmotion movie is automatically played back, a confirmation dialog will be displayed.

List by date

10/12/2007

26/11/2007 23/11/2007

images total

Back

Select image

Back

[List by date]

5 Choose [Yes] and press d.

The Pictmotion movie is saved.

Save Pictmotion?

ON/OFF

2 5

Confirm

More on Playback

Yes

Change settings

Page 70

Pictmotion by muvee

j Notes on Pictmotion

• Pictmotion supports both still pictures and movie files (up to five); note, however, that in the case of movies only a small portion selected from the first 60 seconds of each movie will be included.

• The current memory card holds up to 20 Pictmotion movies. If the current memory card holds 20 Pictmotion movies, delete unnecessary movies before creating new movies.

• The pictures in a Pictmotion movie are automatically protected when the movie is saved (c 99).

l Nikon Transfer (Windows only)

When the Windows version of the supplied Nikon Transfer software (c 73) is used to transfer pictures stored on the memory card to a computer, Pictmotion movies created with the camera can be transferred to the computer and converted to movie files. Up to ten ten-minute user-defined music tracks for use with Pictmotion can also be copied from a computer to the memory card inserted in the camera. For more information, refer to help information contained in Nikon Transfer.

l Deleting Pictmotion Movies

To delete a Pictmotion movie, choose the desired movie file in the Pictmotion menu (c 56, step 2), and press T. Protection (c 99) is not removed when the Pictmotion is deleted.

Other Options for Pictmotion Movies

Pressing m in the Pictmotion screen (c 56, step 2) displays the Pictmotion settings screen, where the options described below (1 to 5) can be specified. Selecting [Change settings] in the save confirmation dialog (c 56,

More on Playback

step 4) displays the change settings screen, where the options described below (except 5) can be specified.

Pictmotion settings screen Change settings screen

1 Background Music

Rotate the rotary multi selector to display [Background music] and press the rotary multi selector J. Choose from five preset music tracks and ten user-defined music tracks. Preset music tracks include [High-speed] (default setting), [Emotional], [Natural], [Up-tempo], and [Relaxed].

• Preset tracks can be played back by pressing v (k). User-defined music tracks cannot be played back.

• Music tracks from a computer will be added to the user-defined music track list. Names of the tracks are displayed in the list only when

transferred from a computer.

Background music

High-speed

Motion

Random

Fit to music length

Auto select 30

Exit

Background music

High-speed

Motion

Random

Fit to music length

Back

Background music

Exit

High-speed

Fit to music length Auto select 30

Motion

Random

Page 71

Pictmotion by muvee

2 Effects

Rotate the rotary multi selector to display [Effects] and press the rotary multi selector J. Choose from [Motion]

(default setting),

[Moody], [Pro-slow], [Pro-fast], and [Classic].

• Press v (k) to preview selected style on the left side of the monitor.

Effects

High-speed

Random Fit to music length Auto select 30

Exit

3 Playback Order

Rotate the rotary multi selector to display [Playback order], and press the rotary multi selector J. Choose [Random] (default setting) or [Play in order].

Random: Play back pictures in

random order.

Play in order: Play back pictures in order

Playback order

High-speed

Random

Fit to music length Auto select 30

Exit

recorded.

4 Playback duration

Rotate the rotary multi selector to display [Playback duration], and press the rotary multi selector J. Choose [Fit to music length] (default setting) or [Show all images].

Fit to music length: Play background track once,

repeating or omitting pictures as necessary.

Playback duration

High-speed

Random

Fit to music length

Auto select 30

Exit

Show all images: Repeat background track until all pictures have been

played at least once.

5 Selected Images

Rotate the rotary multi selector to display [Select images] and press the rotary multi selector J.

Choose from [Auto select 30] (default setting), [Auto select 50], [Auto select 100], [Auto select 200], or [No auto select].

For example, if [Auto select 30] is selected, the

Select images

High-speed

Random Fit to music length

Auto select 30

Exit

last 30 pictures are chosen for the Pictmotion movie. This number can be changed, however, when creating a customized Pictmotion movie. When [View images] is selected in the picture selection screen (c 57, step1), the number of pictures chosen in step 4 will be used.

Motion

More on Playback

Motion

Page 72

Pictmotion by muvee

Viewing Pictmotion Movies

1 Enter Pictmotion playback mode

by pressing C in playback mode, selecting P (use the rotary multi selector), and then pressing d.

2 Use the rotary multi selector to choose

the desired Pictmotion movie and press d.

3 Choose [Play] and press d.

More on Playback

Playback starts.

If [Loop] is selected, the movie will repeat automatically. To select or deselect [Loop], choose [Loop] and press d.

Zoom buttons control volume. To pause the movie, press d during playback.

4 Choose [End] and press d.

Monitor returns to that shown in step 2. To resume playback, choose [Restart] and press d.

Pictmotion by muvee

Play

Pictmotion

Pause:

Play

Loop

Restart

End

k Pictmotion Playback

The COOLPIX S51 cannot play Pictmotion movies created with another make of camera.

Page 73

Movies

12s

Recording Movies

To shoot movies with sound recorded via the built-in microphone, select shooting mode and follow the steps below.

1 Enter movie mode by pressing

C in shooting mode,

Movie

selecting S (use the rotary multi selector), and then pressing d.

Exposure count display shows maximum total length of movie that can be recorded.

2 Press the shutter-release button

all the way down to start

recording.

A progress bar at the bottom of the monitor shows the amount of recording time remaining.

To end recording, press the shutter-release button all the way down a second time.

Recording will automatically stop if the internal memory or memory card becomes full.

12s

j Recording Movies

•Flash mode (c 28) and exposure compensation (c 32) can only be used for stop-motion movies. Macro mode (c 31) is available in all modes. Self-timer (c 30) cannot be used.

• Apply optical zoom before beginning movie recording. Optical zoom cannot be applied or adjusted once movie recording begins. Digital zoom cannot be applied before movie recording begins. However, digital zoom (up to 2×) can be applied while movies, other than stop-motion movies, are being recorded.

• The maximum file size for movies is 2 GB.

Movies

l Changing Movie Settings

Movie options or auto-focus mode can be changed (c 62).

Page 74

The Movie Menu

Press m in movie mode to display the movie menu.

T Movie options c 63

Choose type of movie that will be recorded.

Y Auto-focus mode c 65

Choose how camera focuses in movie mode.

Movies

Page 75

The Movie Menu

Selecting Movie Options

The movie menu offers the options shown below.

Maximum movie length/

Option Image size and frame rate

TV movie 640A

Pictmotion 640

Small size 320A (default setting)

Smaller size 160

Stop-motion

movie

* All figures are approximate. Maximum movie length varies with make of memory

card. The maximum file size for movies is 2 GB. However, when recording to the internal memory, or memory cards with capacities of less than 2 GB, the time remaining display indicates the amount of free space remaining in the internal memory or memory card. When 4-GB memory cards are used, up to 2-GB movies can be recorded, and the time remaining display indicates the amount of time until the maximum 2-GB file size will be recorded.

Image size: 640 × 480 pixels Frame rate: 30 frames per second

Recording automatically stops after 60 seconds. Suited for Pictmotion movies (c 56). Image size: 640 × 480 pixels Frame rate: 10 frames per second

Image size: 320 × 240 pixels Frame rate: 30 frames per second

Image size: 160 × 120 pixels Frame rate: 15 frames per second

Pictures can be taken and joined into a silent movie (c 64). Image size: 640 × 480 pixels Frame rate for playback: choose from five, ten, or 15 frames per second

Internal

memory

(approx.13 MB)

8 sec. 2 min. 50 sec.

16 sec. 1 min.

22 sec. 7 min.

2 min. 47 sec.

265, 260, or

255 frames (when frame rate for playback is set

to [5 fps], [10 fps], or [15 fps] respectively)

frames

Memory

card

(256 MB)

54 min.

1,800 frames

Movies

Page 76

The Movie Menu

Stop-Motion Movies

1 Use the rotary multi selector to choose

[Movie options] > [Stop-motion movie] and press d.

2 Choose [Playback speed] and press d.

Movie options

TV movie 640

Pictmotion 640

Small size 320

Smaller size 160

Stop-motion movie

Exit

Playback speed

Exit

3 Press m.

The camera returns to shooting mode.

4 Press the shutter-release button to record the first frame.

The recorded picture will be superimposed on the view through the lens.

Movies

5 Press the shutter-release button to record the second frame.

Use the frame superimposed in the camera monitor as a guide for recording consecutive frames. The monitor turns off automatically with the auto off function (c 112) if no operations are performed for 30 minutes, and recording ends.

6 Press d to end recording.

Recording will automatically stop if the internal memory or memory card becomes full, or when 1,800 frames have been recorded.

5 fps 10 fps 15 fps

j Stop-Motion Movie

•Flash mode (c 28), macro mode (c 31), and exposure compensation (c 32) cannot be

adjusted after the first picture is taken. Apply the appropriate settings before shooting begins.

• To prevent the camera from turning off unexpectedly during recording, use a fully charged battery.

Page 77

Auto-Focus Mode

Choose how the camera focuses in movie mode.

Option Description

Z Single AF

(default setting)

a Full-time AF

Camera focuses when shutter-release button is pressed halfway and locks at this position during shooting.

Camera focuses continuously until focus is acquired and locked. To prevent sound of camera focusing from interfering with recording, use of [Single AF] is recommended.

The Movie Menu

Movies

k Movie File Names and Folder Names

See “Image/Sound File and Folder Names” (c 118).

Page 78

Movie Playback

0010.AVI

15/11/2007 15:30

10s

In full-frame playback (c 26), movies are recognized by movie mode icons. To play a movie, display it in full-frame playback and press d.

The movie mode icon varies depending upon a movie option (c 63) selected in shooting mode.

Use the zoom buttons to adjust playback volume. Press t (j) to lower volume, or v (k) to raise volume.

Rotate the rotary multi selector to advance or rewind the movie.

Playback controls appear at the top of the monitor. Press the rotary multi selector I or J to choose a control, then press d to perform the selected operation. The following operations are available.

To Press Description

Rewind Q Rewind movie. Playback resumes when d is released.

Advance U Advance movie. Playback resumes when d is released.

Pause playback.

Movies

Pause R

End S End playback and return to full-frame playback.

While paused, use the rotary multi selector to advance or rewind the movie. The following operations can be performed while playback is paused.

Rewind movie by one frame. Rewind continues while

d is pressed.

Advance movie by one frame. Advance continues

while d is pressed.

z Resume playback.

S End playback and return to full-frame playback.

During playback

0010.AVI

10s

4s4s4s

15/11/2007 15:30

Pausing

Volume indicator

Deleting Movie Files

Press T when displayed in full-frame playback (c 26), or when selected in thumbnail (c 44) or thumbnail wheel (c 45) playback. A confirmation dialog is displayed. Choose [Yes] and press d to delete the movie, or choose [No] and press d to return to the normal playback display without deleting the movie.

Erase 1 image?

Yes

Page 79

Voice Recordings

Making Voice Recordings

Audio voice recordings can be recorded over the built-in microphone and played back over the built-in speaker.

1 Enter voice recording mode by

pressing C in

shooting mode

Voice recording

selecting (use the rotary multi selector), and then pressing d.

The length of recording that can be made will be displayed.

Voice recording

001 17:30

15/11/2007

Max. rec. time

00:09:38

2 Press the shutter-release button all the way down to start

recording.

The indicator lamp lights during recording. After about 30 seconds, the camera’s auto off function is enabled and the monitor turns off.

Pause indicator

File number

Length of recording

Progress indicator

Voice recording

Index:

001 17 00:01:00/00:04:00

3015/11/2007

Date of recording

Time remaining Index number

3 Press the shutter-release button all the way down a second

time to end recording.

Recording will end automatically if the internal memory or memory card becomes full, or after five hours of recording on the memory card.

Voice Recordings

Page 80

Making Voice Recordings

Operations During Recording

The following operations are available during recording. If the monitor has turned off, press i to reactivate.

To Press Description

Pause/resume recording

Create index

Press once to pause recording; indicator lamp will

blink.

During recording, press the rotary multi selector to create index. Camera can skip to any index during playback. Start of recording is index number 01; other index numbers that follow are assigned in ascending order, up to index number 98.

End recording

Press the shutter-release button all the way down a second time to end recording.

Sound Quality

Press m in voice recording mode to display the following sound quality options. Choose the sound quality for the recording.

Maximum voice recording length*

Option Description

Voice Recordings

Normal

High

(default setting)

* Voice recordings can be as long as free space in the internal memory or on the

memory card allows (up to five hours). All figures are approximate. Maximum voice recording length varies with make of memory card.

Suited for longer recordings.

Record with high quality sound.

Internal memory

(approx.13 MB)

26 min. 30 sec. 5 hours

9 min. 38 sec. 3 hours 4 min.

Memory card

j Voice Recordings

The files transferred to a computer can be played back using QuickTime or any other WAVcompatible audio player. Note that index points created with the camera cannot be used when voice recordings are played back on computers.

l Sound File Names and Folder Names

See “Image/Sound File and Folder Names” (c 118).

(256 MB)

Page 81

Playing Voice Recordings

1 Enter audio playback mode by

pressing C in

playback mode

selecting q (use the rotary multi selector), and then pressing d.

2 Choose the desired file and press d.

The selected file will be played back.

Audio playback

Control icons

File number

Playback time

Progress indicator

15/11/2007 17:30

001 00:00:05/00:00:20

Index:

Audio playback

Select sound file

001 15/11/2007 17:30

15/11/2007 18:30

002

26/11/2007 13:00

003

29/11/2007 16:40

004 005

03/12/2007 08:00

Copy Play

Date and time of recording Sound quality

Length of recording Index number

VolumeIndex

Voice Recordings

Page 82

Playing Voice Recordings

Operations During Playback

Use the zoom buttons to adjust playback volume. Press t (j) to lower volume, or v (k) to raise volume. Rotate the rotary multi selector to advance or rewind the voice recording.

Playback controls appear at the top of the monitor. Press the rotary multi selector I or J to choose a control, then press d to perform the selected operation. The following operations are available.

To Press Description

Rewind Q

Advance U

Skip to previous index

Skip to next index

Pause

End S End playback and return to the sound file selection screen.

Voice Recordings

Rewind voice recording. Playback resumes when d is released.

Advance voice recording. Playback resumes when d is released.

s Skip to previous index.

r Skip to next index.

RzPause playback.

The following operations can be performed while playback is paused. Resume playback.

l Deleting Sound Files

Press T during playback or after selecting a sound file (use the rotary multi selector). A confirmation dialog will be displayed. To delete the file, choose [Yes] and press d. To cancel deletion, choose [No] and press d.

Page 83

Copying Voice Recordings

Copy voice recordings between the internal memory and a memory card. This option is available only when a memory card is inserted.

1 Press m in the select sound file screen

(c 69, step 2).

2 Use the rotary multi selector to choose

the option and press d.

MNO: Copy recordings from internal memory to memory card

ONM: Copy recordings from memory card to internal memory

3 Choose the copy option and press d.

[Selected files]: Proceed to step 4

[Copy all files]: Proceed to step 5

4 Choose the desired file.

Press the rotary multi selector J to select the file (y). Press the rotary multi selector J again to cancel the selection.

• Multiple files can be selected.

•Press d to finalize file selection. A confirmation dialog will be displayed.

Copy sound files

Exit

Camera to card

Selected files

Copy all files

Exit

Select sound files

001 15/11/2007 17:30

15/11/2007 18:30

002

26/11/2007 13:00

003

29/11/2007 16:40

004 005

03/12/2007 08:00

Exit Select

5 Choose [Yes] and press d.

Copying starts.

k Voice Recordings

The COOLPIX S51 may be unable to play or copy sound files created with another make of camera.

k [No sound file.] Message

If there are no sound files stored on the memory card when q is selected (c 69, step1), the message, [No sound file.], will be displayed. Press m to display the copy sound files screen, and copy the sound files stored in the camera’s internal memory to the memory card.

Voice Recordings

Page 84

Connecting to Televisions, Computers, and Printers

Connecting to a TV

Connect the camera to a television using the supplied audio video/USB cable to play back pictures on the television.

1 Turn off the camera.

2 Connect the camera to the TV using the supplied audio video/

Connecting to Televisions, Computers, and Printers

USB cable.

Connect the yellow plug to the video-in jack on the TV, and the white plug to the audio-in jack.

3 Tune the television to the video channel.

See the documentation provided with your television for details.

4 Hold down i to turn on the camera.

The camera enters playback mode, and the pictures taken will be displayed on the television.

While connected to the TV, the camera monitor will remain off.

WhiteYellow

j Connecting an Audio Video/USB Cable

• When connecting the audio video/USB cable, be sure that the camera connector is oriented correctly. Do not use force when connecting the audio video/USB cable to the camera. When disconnecting the audio video/USB cable, do not pull the connector at an angle.

• When connecting to a TV, do not use the audio video/USB cable’s USB connector. If the USB connector is inserted in a computer or printer’s USB port, be sure to disconnect it.

j Video Mode

Be sure that the camera’s video mode setting conforms to the standard used by your television. The video mode setting is an option set in the setup menu (

102) > [Video mode] (c114).

Page 85

Connecting to a Computer

When the camera is connected to a computer using the supplied audio video/USB cable, pictures recorded with the camera can be copied (transferred) to the computer for storage using the Nikon Transfer software.

Before Connecting the Camera

Installing the Software

Before connecting the camera to a computer, software, including Nikon Transfer and Panorama Maker for creating panorama images, must be installed from the supplied Software Suite (CD).

For more information on installing the software, refer to the Quick Start Guide.

Operating Systems Compatible with COOLPIX S51

Windows

Preinstalled versions of Windows Vista (32-bit Home Basic/Home Premium/ Business/Enterprise/Ultimate editions), Windows XP Service Pack 2 (Home Edition/Professional)

If your computer is running Windows 2000 Professional, use a card reader or similar device to transfer pictures stored on the memory card to the computer (c 75).

Macintosh

Mac OS X (version 10.3.9, 10.4.9)

Refer to the Nikon website for the latest information on operating system compatibility.

Connecting to Televisions, Computers, and Printers

j Note on Power Source

When connecting the camera to a computer, use a fully charged battery to prevent the camera from turning off unexpectedly.

Page 86

Connecting to a Computer

Transferring Pictures from the Camera to a Computer

1 Start the computer to which Nikon Transfer has been installed. 2 Turn off the camera. 3 Connect the camera to the computer using the supplied audio

video/USB cable.

Connecting to Televisions, Computers, and Printers

4 Turn on the camera.

Windows Vista/XP

When the AutoPlay dialog is displayed, select [Copy pictures to a folder on my computer using Nikon Transfer] (Windows Vista) or [Nikon Transfer Copy pictures to a folder on my computer] (Windows XP), and click [OK] (Windows XP only). To bypass this dialog in the future, check [Always do this for this device:] (Windows Vista), or [Always use this program for this action.] (Windows XP). Nikon Transfer will start.

Mac OS X

Nikon Transfer will start automatically if [Yes] was selected in the Auto-Launch setting dialog when Nikon Transfer was first installed.

j Connecting the Audio Video/USB Cable

When connecting the audio video/USB cable, be sure that the connectors are oriented correctly. Do not use force when connecting the audio video/USB cable. When disconnecting the audio video/USB cable, do not pull the connector at an angle.

Connection may not be recognized when the camera is connected to a computer via a USB hub.

Page 87

Connecting to a Computer

5 Transfer pictures when Nikon Transfer has finished loading.

Click [Start Transfer] in Nikon Transfer. At the default setting, all pictures are transferred to the computer.

At the Nikon Transfer default setting, the folder to which pictures are transferred is automatically opened when transfer is complete.

For more information on using Nikon Transfer, refer to help information contained in Nikon Transfer.

6 Disconnect the camera when transfer is complete.

Turn the camera off and disconnect the audio video/USB cable.

For Users of Windows 2000 Professional

Use a card reader or similar device to transfer the pictures stored on the memory card to the computer.

If your memory card has a capacity greater than 2 GB, the intended device must support the memory card.

• At the Nikon Transfer default settings, Nikon Transfer will start automatically when a memory card is inserted into the card reader or similar device. See step 5 above to transfer pictures.

• Do not connect the camera to the computer. If the camera is connected to the computer, the [Found New Hardware Wizard] dialog will be displayed. Select [Cancel], close the dialog, and disconnect the camera from the computer.

• To transfer pictures stored in the camera’s internal memory to the computer, the pictures must first be copied to a memory card using the camera (c 71, 100).

Connecting to Televisions, Computers, and Printers

Page 88

Connecting to a Computer

l Using Standard OS Operations to Open Image/Sound Files

• Navigate to the folder on the computer’s hard disk to which pictures were saved and open a picture in the viewer supplied with your operating system.

• Sound files copied to the computer can be played back using QuickTime or any other WAVcompatible audio player.

l Panorama Creation with Panorama Maker

• Use a series of pictures taken using the [Panorama assist] option in scene mode (c 40) to create a single panorama photo with Panorama Maker.

• Panorama Maker can be installed to a computer using the supplied Software Suite (CD).

Connecting to Televisions, Computers, and Printers

• After installation is complete, follow the procedure described below to start Panorama Maker.

Windows

Open [All Programs] ([Programs] under Windows 2000) from the [Start] menu > [ArcSoft Panorama Maker 4] > [Panorama Maker 4].

Macintosh

Open Applications by selecting [Applications] from the [Go] menu, and double-click the [Panorama Maker 4] icon.

• For more information on using Panorama Maker, refer to the on-screen instructions and help information contained in Panorama Maker.

l Image File Names and Folder Names

See “Image/Sound File and Folder Names” (c 118) for more information.

Page 89

Connecting to a Printer

Users of PictBridge-compatible (c 135) printers can connect the camera directly to the printer and print pictures without using a computer.

Take pictures

Select pictures for printing

using [Print set] option

(c 83).

Connect to printer (c 78)

Connecting to Televisions, Computers, and Printers

Print pictures one at

a time (c 79)

Turn camera off and disconnect audio video/USB cable

Print multiple pictures (c 80)

j Note on Power Source

When connecting the camera to a printer, use a fully charged battery to prevent the camera from turning off unexpectedly.

l Printing Pictures

In addition to printing pictures transferred to a computer from your personal printer and printing over a direct camera-to-printer connection, the following options are also available for printing pictures:

• Insert a memory card into a DPOF-compatible printer’s card slot

• Take a memory card to a digital photo lab

For printing using these methods, specify the pictures and the number of prints each using your camera’s print set menu (c 83).

l ImageLink-compatible Printers

Users of ImageLink-compatible printers can connect the camera directly to the printer and print pictures without using a computer. See “Connecting to a ImageLink-compatible Printer” (c 85) and the documentation provided with your printer for details.

Page 90

Connecting to a Printer

Connecting the Camera and Printer

1 Turn off the camera.

2 Turn on the printer.

Connecting to Televisions, Computers, and Printers

Check printer settings.

3 Connect the camera to the printer using the supplied audio

video/USB cable.

4 Turn on the camera.

When connected correctly, the PictBridge start-up screen 1 will be displayed in the camera monitor. Then the print selection screen will be displayed 2.

Print selection

15/11 2007

NO. 1 [ 57]

j Connecting the Audio Video/USB Cable

Page 91

Connecting to a Printer

Printing Pictures One at a Time

After connecting the camera to the printer correctly (c 78), print pictures by following the procedure below.

1 Use the rotary multi selector to choose

the desired picture and press d.

The PictBridge menu is displayed. Press t (j) to switch to thumbnail display. Press v (k) to switch back to full-frame playback.

2 Choose [Copies] and press d.

3 Choose the number of copies (up to nine)

and press d.

4 Choose [Paper size] and press d.

5 Choose the desired paper size and press

To specify paper size using printer settings, choose [Default] in the paper size menu and press d.

Print selection

PictBridge

Start print

Copies

Paper size

Exit

Copies

Exit

PictBridge

Start print

Copies

Paper size

Exit

Paper size

Default

3.5 × 5 in. 5 × 7 in.

100 × 150mm

Exit

15/11 2007

NO. 1 [ 57]

Connecting to Televisions, Computers, and Printers

Page 92

Connecting to a Printer

6 Choose [Start print] and press d.

7 Printing starts.

Connecting to Televisions, Computers, and Printers

Monitor display returns to that shown in step 1 when printing is complete.

To cancel before all copies have been printed, press d.

PictBridge

Start print

Copies

Paper size

Exit

Printing

002/004

Current print/ total number of prints

Printing Multiple Pictures

After connecting the camera to the printer correctly (c 78), print pictures by following the procedure below.

1 When the print selection screen is

displayed, press m.

The print menu is displayed.

2 Use the rotary multi selector to choose

[Paper size] and press d.

Print menu

Print selection Print all images DPOF printing

Paper size

Exit

Cancel

Page 93

Connecting to a Printer

3 Choose the desired paper size and press

To specify paper size using printer settings, choose [Default] in the paper size menu and press d.

4 Choose [Print selection], [Print all images]

or [DPOF printing] and press d.

Print selection

Choose the pictures and number of copies (up to nine) of each. Rotate the rotary multi selector to select pictures, and press G or H to set the number of copies for each. Pictures selected for printing can be recognized by the check mark (y) and the numeral indicating the number of copies to be printed. A check mark is not displayed with pictures for which 0 copies have been specified and these pictures will not be printed. Press v (k) to switch to full-frame playback. Press t (j) to switch back to thumbnail display. Press d when setting is complete. The menu shown at right will be displayed. To print, choose [Start print] and press d. Choose [Cancel] and press d to return to the print menu.

Print all images

All pictures stored in the internal memory, or on the memory card, are printed one at a time. The menu shown at right will be displayed. To print, choose [Start print] and press d. Choose [Cancel] and press d to return to the print menu.

Paper size

Default

3.5 × 5 in. 5 × 7 in.

100 × 150mm

Exit

Print menu Print selection

Print all images DPOF printing Paper size

Exit

Print selection 10

Back

Print selection

010 prints

Start print

Cancel

Exit

Print all images

018 prints

Start print

Cancel

Exit

Connecting to Televisions, Computers, and Printers

Page 94

Connecting to a Printer

DPOF printing

Print pictures for which a print order has been created in [Print set] (c 83). The menu shown at right will be displayed. To print, choose [Start print] and press d. Choose [Cancel] and press d to return to the print menu.

Connecting to Televisions, Computers, and Printers

To view the current print order, choose [View images] and press d. To print pictures, press d again.

DPOF printing

010 prints Start print

View images

Cancel

Exit

Back

10View images

5 Printing starts.

Monitor display returns to the print menu (step 2) when printing is complete.

To cancel before all copies have been printed, press

Printing

002/010

Current print/ total number of prints

j Paper Size

The camera supports the following paper sizes: [Default] (the default paper size for the current printer), [3.5 × 5 in.], [5 × 7 in.], [100 × 150mm], [4 × 6 in.], [8 × 10 in.], [Letter], [A3], and [A4]. Only sizes supported by the current printer will be displayed. To specify paper size using printer settings, choose [Default] in the paper size menu.

Cancel

Page 95

Creating a DPOF Print Order: Print Set

The [Print set] option in the playback menu is used to create digital “print orders” for printing on DPOF-compatible devices (c 135).

In addition to pictures themselves, shooting date and photo information (shutter speed, aperture, etc.) can also be printed.

When the camera is connected to a PictBridge-compatible printer, pictures can be printed from the printer according to the DPOF print order you have created for pictures on the memory card. If the memory card is removed from the camera, you can create the DPOF print order for pictures in the internal memory and print pictures according to the DPOF print order.

1 Press m in playback mode.

The playback menu is displayed.

Connecting to Televisions, Computers, and Printers

2 Use the rotary multi selector to choose

[Print set] and press d.

The print set menu is displayed.

3 Choose [Print selected] and press d.

4 Choose the pictures and number of

copies (up to nine) of each.

Rotate the rotary multi selector to select pictures, and press G or H to set the number of copies for each.

Pictures selected for printing can be recognized by the check mark (y) icon and the numeral indicating the number of copies to be printed. A check mark is not displayed with pictures for which 0 copies have been specified and these pictures will not be printed.

Press v (k) to switch to full-frame playback. Press t (j) to switch back to thumbnail display. Press d when setting is complete.

Playback menu

Print set Slide show Delete Protect Rotate image

Exit

Print set Print selected

Delete print set

Exit

Print selection

Back

Page 96

Creating a DPOF Print Order: Print Set

15/11/2007 15:30


15. 11.2 007

5 Choose whether or not to also print

shooting date and photo information.

[Date]: Print date of recording on all pictures in the

print order.

[Info]: Print shutter speed and aperture on all pictures

in the print order. Note that this information is

Print set

Exit

Done

Date Info

not printed with direct connection to a printer.

Connecting to Televisions, Computers, and Printers

[Done]: Complete the print order and exit.

Pictures selected for printing are recognized by the w icon displayed with playback.

15/11/2007 15:30

j Print Set

[Date] and [Info] are reset each time the print set menu is displayed.

k Deleting All Print Orders

Choose [Delete print set] in step 3 and press d. Print orders for all pictures will be deleted.

k Note on the Print Set [Date] Option

The date and time printed on pictures with DPOF printing when [Date] in the print set menu is enabled are those recorded with the picture when it was taken. Date and time printed using this option are not affected when the camera’s date and time setting are changed from the setup menu after pictures are recorded.


15.11.2007

l Differences Between Print Set and Date Imprint

Date and time can only be printed on pictures using the [Date] option in the print set menu when pictures are printed from a DPOF-compatible printer (c 135). Use the [Date imprint] (c 109) option in the setup menu to print the date on pictures from a printer that does not support DPOF (position of the date is fixed). When the date option for both [Print set] and [Date imprint] is enabled, only the date from the [Date imprint] option is printed, even when a DPOF-compatible printer is used.

Page 97

Connecting to a ImageLink-compatible Printer

See documentation provided with your printer for information on operating the printer.

1 Attach the Dock Insert PV-12 (supplied)

to the printer.

2 Turn the camera off and attach it to the

dock insert.

3 Print pictures.

Follow the procedures described in the printer manual.

Removing the Dock Insert

Place your thumbs where indicated, press, and lift.

Connecting to Televisions, Computers, and Printers

j Note on Connecting to an ImageLink-compatible Printer

The monitor will dim automatically if no operations are performed for about one minute while the camera is connected to an ImageLink printer. The camera will turn off if no operations are performed for about another seven minutes.

Page 98

Shooting, Playback, and Setup Menus

Shooting Options: The Shooting Menu

The shooting menu and high-sensitivity menu contain the following options.

Z Image mode

Choose image size and quality.

d White balance

Match white balance to the light source.

q Continuous

Take pictures one at a time or in a sequence.

A BSS

Use the “best shot selector” to choose the sharpest picture.

W ISO sensitivity

Control camera’s sensitivity to light.

d Color options

Apply color effects to pictures as they are recorded.

Shooting, Playback, and Setup Menus

k AF area mode c 94

Choose where the camera focuses.

See the information on restrictions that may apply to these settings (c 95).

This setting cannot be set in the high-sensitivity menu.

c 87

c 89

c 91

c 92

c 93

Page 99

Shooting Options: The Shooting Menu

Displaying the Shooting Menu and High-sensitivity Menu

Enter L (auto) or high-sensitivity shooting mode by pressing

mode, selecting

to display the shooting menu or high-sensitivity menu.

(auto) or K (high-sensitivity), and then pressing d. Press

Shooting

• Use the rotary multi selector (c 9) to choose and apply settings.

• To exit the shooting or high-sensitivity menu, press m.

Shooting menu

Image mode White balance Continuous BSS ISO sensitivity

Exit

in shooting

Z Image Mode

Pictures taken with a digital camera are recorded as image files. The size of the files, and with it the number of images that can be recorded, depends on the size and quality of the images. Before shooting, choose an image mode according to how you plan to use the picture.

Option Size (pixels) Description

R High (3264A) 3,264 × 2,448

Normal (3264)

(default setting)

d Normal (2592) 2,592 × 1,944

e Normal (2048) 2,048 × 1,536

h PC screen (1024) 1,024 × 768

i TV screen (640) 640 × 480

B 16:9 3,200 × 1,800

3,264 × 2,448

The icon for the current setting is displayed in the monitor in shooting and playback modes (c 6, 7).

Highest quality, suitable for enlargements or high-quality prints. The compression ratio is approximately 1:4.

Best choice in most situations. The compression ratio is approximately 1:8.

Smaller size allows more pictures to be stored. The compression ratio is approximately 1:8.

Suited to display on computer monitor. The compression ratio is approximately 1:8.

Suited to full-screen display on a television or distribution by e-mail or the web. The compression ratio is approximately 1:8.

Pictures with an aspect ratio of 16:9 can be taken. The compression ratio is approximately 1:8.

Shooting, Playback, and Setup Menus

Page 100

Shooting Options: The Shooting Menu

k Image Mode and the Number of Exposures Remaining

The following table lists the number of pictures that can be stored in internal memory and on a 256 MB memory card, together with the size of still pictures. Note that the number of pictures that can be stored will differ depending on the composition of the picture (due to JPEG compression). In addition, this number may differ depending on the make of memory card, even if the capacity for the memory card is the same.

Setting

Internal memory

(approx. 13 MB)

Memory card

(256 MB)

Print size (printed

at 300 dpi; cm/in.)

R High (3264A) 36028 × 21/11 × 8

c Normal (3264) 5 115 28 × 21/11 × 8

d Normal (2592) 9180

e Normal (2048) 14 285

Shooting, Playback, and Setup Menus

h PC screen (1024) 44 900

i TV screen (640) 88 1,750

B 16:9 8160

All figures are approximate. If the number of exposures remaining is 10,000 or more, the number of exposure remaining display shows [9999].

All figures are approximate. The size of images when printed depends on the printer

22 × 16.5/

8.8 × 6.6

17 × 13/

6.8 × 5.2

9 × 7/

3.6 × 2.8

5 × 4/

2 × 1.6

27 × 15.5/

10.7 × 6

resolution: the higher the resolution, the smaller the final print size.

l Image Mode

The image mode setting can also be applied from the scene and one-touch portrait menus. Changes made to the image mode setting from any of the three menus apply to all shooting modes.
