NEXCOM NISE 104 User Manual

NEXCOM International Co., Ltd.

Industrial Computing Solutions

Fanless Computer NISE 104

User Manual

NEXCOM International Co., Ltd.

Published April 2013

www.nexcom.com

Contents

Preface

Copyright .............................................................................................. iv

Disclaimer .............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements ........................................................ iv

Declaration of Conformity ...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................viii

Installation Recommendations ...............................................................viii

Safety Precautions .................................................................................. ix

Technical Support and Assistance ............................................................ x

Conventions Used in this Manual ............................................................ x

Global Service Contact Information ........................................................ xi

Package Contents ................................................................................. xiii

Ordering Information ............................................................................xiv

Chapter 1: Product Introduction

Overview ................................................................................................1

Key Features ...........................................................................................1

Hardware Specifications ..........................................................................2

Knowing Your NISE 104 .......................................................................... 3

Mechanical Dimensions ...........................................................................5

Chapter 2: Jumpers and Connectors

Before You Begin ....................................................................................6

Precautions ............................................................................................6

Jumper Settings ......................................................................................7

Locations of the Jumpers and Connectors for NISB104 ............................ 8

Locations of the Jumpers and Connectors for NISKIO2 .......................... 10

NISB104 ................................................................................................11

Jumpers ................................................................................................ 11

RTC Clear.......................................................................................11

Connector Pin Definitions .....................................................................11

External I/O Interfaces – Front Panel ................................................... 11

Power On/Off Switch .....................................................................11

COM1 Serial Port ...........................................................................12

COM2 Serial Port ...........................................................................12

COM3 Serial Port ...........................................................................13

COM4 Serial Port ...........................................................................13

External I/O Interfaces – Rear Panel .................................................... 14

9~36V DC Power Input .................................................................. 14

DVI-I/VGA Connector ..................................................................... 14

HDMI ............................................................................................. 15

USB0/1 Ports .................................................................................. 15

USB2/3 Ports .................................................................................. 16

LAN1 Port ......................................................................................16

LAN2 Port .....................................................................................17

Internal Connectors ........................................................................... 17

NISB 104 ...........................................................................................17

CPU Fan Connector ........................................................................17

ii

NISE 104 User Manual

Contents

DC Input/Output Connector ........................................................... 18

GPIO Connector ............................................................................. 18

Keyboard/Mouse Connector ...........................................................19

B to B Connector ...........................................................................19

PWR_BT/RET_BT/LED/SM BUS Pin Header .......................................20

LAN1 LED .......................................................................................20

LAN2 LED .......................................................................................21

USB 6 Connector ...........................................................................21

SATA Connector ............................................................................22

SATA Power Connector ..................................................................22

SIM Card Connector ......................................................................23

3.5G Line-out Pin Header ............................................................... 23

CFast CON ..................................................................................... 24

3.5G Mic-in Pin Header .................................................................. 24

Mini-PCIe Slot ................................................................................25

NISKIO2 .............................................................................................26

B to B Connector ...........................................................................26

Line-out Pin Header ........................................................................26

Line-out Internal Speaker ...............................................................27

Line-in Pin Header .......................................................................... 27

USB1~ USB2 Connector ................................................................. 28

MIC Pin Header .............................................................................. 28

Power LED/ HDD LED .....................................................................29

Chapter 3: System Setup

Removing the Chassis Cover .................................................................30

Installing the DDR3 SODIMM ................................................................30

Installing a SATA Hard Drive ..................................................................32

Installing a CompactFlash Card .............................................................33

Installing a Wireless LAN Module .........................................................35

Installing the SIM Card ..........................................................................39

Installing the SATA DOM .......................................................................40

Installing Wallmount Brackets ...............................................................42

Chapter 4: BIOS Setup

About BIOS Setup ................................................................................ 43

When to Configure the BIOS ................................................................43

Default Configuration ........................................................................... 44

Entering Setup ..................................................................................... 44

BIOS Setup Utility .................................................................................. 45

Main .................................................................................................45

Advanced .......................................................................................... 46

Chipset ..............................................................................................53

Boot .................................................................................................. 57

Security .............................................................................................58

Save & Exit ........................................................................................59

Appendix A: GPI/O Programming Guide...............61

Appendix B: Watchdog Timer.................................62

Appendix C: Power Consumption..........................64

iii

NISE 104 User Manual

Preface

PrefaCe

Copyright

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from NEXCOM International Co., Ltd. However, users may update their knowledge of any product in use by constantly checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

NISE 104 is a trademark of NEXCOM International Co., Ltd. All other product names mentioned herein are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class B devices and describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interfer¬ence, in which case the user will be required to correct the interference (take adequate measures) at their own expense.

CE

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

iv

NISE 104 User Manual

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status Update

NEXCOM is a global citizen for building the digital infrastructure. We are committed to providing green

products and services, which are compliant with European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive 2002/95/EU, to be your trusted green partner and to protect our environment.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force in to implement the introduction of green products. The task force will ensure that we follow the standard NEXCOM development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2006 will be RoHS compliant. They will use the usual NEXCOM naming convention.

v

NISE 104 User Manual

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in accordance with industry standard. NEXCOM warrants that products will be free from defect in material and workmanship for 2 years, beginning on the date of invoice by NEXCOM. HCP series products (Blade Server) which are manufactured by NEXCOM are covered by a three year warranty period.

NEXCOM Return Merchandise Authorization (RMA)

▪ Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪ Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen messages, and describe the problems on the “NEXCOM RMA Service Form” for the RMA number apply process.

▪ Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, please note clearly which components are included. Otherwise, NEXCOM is not responsible for the devices/parts.

▪ Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage and deterioration during transportation. In case of damages occurred during transportation, the repair is treated as “Out of Warranty.”

▪ Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

System Level

▪ Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistor, capacitor.

▪ Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪ Replace with 3rd party products if needed.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪ Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistors, capacitors.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

vi

NISE 104 User Manual

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and the documentation supplied with the chassis, power supply, and accessory modules. If the instructions for the chassis and power supply are inconsistent with these instructions or the instructions for accessory modules, contact the supplier to find out how you can ensure that your computer meets safety and regulatory requirements.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the described procedures only at an ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

vii

NISE 104 User Manual

Preface

Safety Information

Before installing and using the device, note the following precautions:

▪ Read all instructions carefully.

▪ Do not place the unit on an unstable surface, cart, or stand.

▪ Follow all warnings and cautions in this manual.

▪ When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪ Avoid using the system near water, in direct sunlight, or near a heating

device.

▪ The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly necessary in order to provide balance stability.

▪ The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated.

Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following:

▪ A Philips screwdriver

▪ A flat-tipped screwdriver

▪ A grounding strap

▪ An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

viii

NISE 104 User Manual

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been approved for use with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work

according to the user’s manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third pin to ground the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

ix

NISE 104 User Manual

Preface

CAUTION!

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or sales representative, please have the following information ready before calling: – Product name and serial number – Detailed information of the peripheral devices – Detailed information of the installed software (operating system,

version, application software, etc.) – A complete description of the problem – The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card.

Conventions Used in this Manual

Warning: Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself when performing a task.

CAUTION!CAUTION!

Caution: Information to avoid damaging components or losing data.

Note: Provides additional information to complete a task easily.

Safety Warning: This equipment is intended for installation in a Restricted Access Location only.

x

NISE 104 User Manual

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

15F, No. 920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7786 Fax: +886-2-8226-7782 www.nexcom.com

America

USA NEXCOM USA

2883 Bayview Drive,Fremont CA 94538, USA Tel: +1-510-656-2248 Fax: +1-510-656-2158 Email: sales@nexcom.com www.nexcom.com

Asia

Taiwan Central Taiwan Office

16F, No.250, Sec. 2, Chongde Rd., Beitun Dist., Taichung City 406, R.O.C. Tel: +886-4-2249-1179 Fax: +886-4-2249-1172 Email: sales@nexcom.com.tw www.nexcom.com.tw

Japan NEXCOM Japan

9F, Tamachi Hara Bldg.,4-11-5, Shiba Minato-ku, Tokyo, 108-0014, Japan Tel: +81-3-5419-7830 Fax: +81-3-5419-7832 Email: sales@nexcom-jp.com www.nexcom-jp.com

China NEXCOM China

2F, Block 4, Venus Plaza, Bldg. 21, ZhongGuanCun Software Park, No. 8, Dongbeiwang West Rd., Haidian District, Beijing, 100193, China Tel: +86-10-8282-5880 Fax: +86-10-8282-5955 Email: sales@nexcom.cn www.nexcom.cn

Shanghai Office

Room 1505, Greenland He Chuang Bldg., No. 450 Caoyang Rd., Shanghai, 200062, China Tel: +86-21-6150-8008 Fax: +86-21-3251-6358 Email: sales@nexcom.cn www.nexcom.cn

Nanjing Office

Hall C, Block 17, Tian Xing Cui Lang Bldg., No. 49 Yunnan North Rd., Nanjing, 210018, China Tel: +86-25-8315-3486 Fax: +86-25-8315-3489 Email: sales@nexcom.cn www.nexcom.cn

Shenzhen Office

Western Room 708, Block 210, Tairan Industry & Trading Place, Futian Area, Shenzhen, 518040, China Tel: +86-755-8332-7203 Fax: +86-755-8332-7213 Email: sales@nexcom.cn www.nexcom.cn

Wuhan Office

1-C1804/ 1805, Mingze Liwan, No. 519 South Luoshi Rd., Hongshan District, Wuhan, 430070, China Tel: +86-27-8722-7400 Fax: +86-27-8722-7400 Email: sales@nexcom.cn www.nexcom.cn

xi

NISE 104 User Manual

Preface

Chengdu Office

9F, Shuxiangxie, Xuefu Garden, No.12 Section 1, South Yihuan Rd., Chengdu, 610061, China Tel: +86-28-8523-0186 Fax: +86-28-8523-0186 Email: sales@nexcom.cn www.nexcom.cn

Europe

France NEXCOM France

La Grande Arche-Paroi Nord, 92044 Paris La Défense, France Tel: +33 (0) 1 40 90 33 35 Fax: +33 (0) 1 40 90 31 01 Email: sales.fr@nexcom.eu www.nexcom.eu

Germany

NEXCOM GmbH Leopoldstraße Business Centre, Leopoldstraße 244, 80807 Munich, Germany Tel: +49-89-208039-278 Fax: +49-89-208039-279 Email: sales.de@nexcom.eu www.nexcom.eu

Italy

NEXCOM ITALIA S.r.l Via Gaudenzio Ferrari 29, 21047 Saronno (VA), Italia Tel: +39 02 9628 0333 Fax: +39 02 9286 9215 Email: nexcomitalia@nexcom.eu www.nexcomitalia.it

United Kingdom NEXCOM EUROPE

10 Vincent Avenue, Crownhill Business Centre, Milton Keynes, Buckinghamshire MK8 0AB, United Kingdom Tel: +44-1908-267121 Fax: +44-1908-262042 Email: sales.uk@nexcom.eu www.nexcom.eu

xii

NISE 104 User Manual

Preface

Package Contents

Before continuing, verify that the NISE 104 package that you received is complete. Your package should have all the items listed in the following table.

Item Part Number Description Qty

1 4NCPF00204X00 2 Pin Phoenix Contact: (1777989), 5.08mm pitch 1 2 50311F0110X00 FLAT HEAD SCREW LONG F3x5ISO+NYLOK NIGP 4 3 50311F0294X00 I HEAD SCREW LONG I2x4 NYLOK NIGP 2 4 50344C0021X00 COPPER POST LONG 15x5xM3 1 5 60177A0268X00 NISB104 QUICK REFERENCE GUIDE VER:A 1 6 60233DVI18X00 DVI-I Y cable for DVI-D & VGA 1 7 602DCD0502X00 NISE104 CD DRIVER VER:1.0 1

xiii

NISE 104 User Manual

Preface

Ordering Information

The following provides ordering information for NISE 104.

• Barebone

NISE 104 (P/N: 10J00010400X2)

- Intel® Atom™ Dual Core D2550 Fanless System

• 12V, 60W AC/DC power adapter w/o power cord

(P/N: 7400060013X00)

xiv

NISE 104 User Manual

Chapter 1: Product Introduction

ChaPter 1: ProduCt IntroduCtIon

Overview

Key Features

▪ On-board Intel® Atom™ Dual Core D2550 processor, 1.86 GHz

▪ Intel® NM10 Express chipset

▪ 1x DVI-I & 1x HDMI display output

▪ Dual Intel® 82574L GbE LAN ports

▪ 2x RS232/422/485 and 2x RS232

▪ 6x USB2.0

▪ 1x external CFast socket

▪ 1x mini-PCIe with two antenna holes

▪ Support 10-28V DC input

▪ Supports ATX power mode, WoL, LAN teaming and PXE function

1

NISE 104 User Manual

Chapter 1: Product Introduction

Hardware Specifications

CPU Support

▪ On-board Intel® Atom™ Dual Core processor D2550, 1.86 GHz, 1M L2

cache

▪ Intel® NM10 Express chipset

Main Memory

▪ 1x DDR3 SO-DIMM sockets, support up to 4G DDR3-800/1066 SDRAM,

un-buffered and non-ECC

I/O Interface-Front

▪ ATX power on/off switch ▪ HDD access/power status LEDs ▪ 4x COM ports (COM2 & 3: RS232/422/485) ▪ 2x USB2.0 port ▪ Audio jack (speaker-out & mic-in) ▪ 2x antenna holes

I/O Interface-Rear

▪ 2x Intel® 82574L GbE LAN port ▪ 4x USB2.0 port ▪ 1x HDMI ▪ 1x DVI-I (support VGA & DVI-D display via cable) ▪ 1x 2-pin DC input, Support 9-36V DC input ▪ 1x external screwed type CFast socket

Device

▪ 1x 2.5” HDD drive bay ▪ 1x External CFast Socket

▪ 1x mini-PCIe socket (support optional Wi-Fi or 3.5G module)

Power Requirements

▪ Support 10-28V DC input ▪ 1x optional 12V, 60W power adapter

Dimensions

▪ 185mm(W) x 131mm(D) x 54mm(H) (7.28”x 5.2”x 2.13”)

Construction

▪ Aluminum chassis with fanless design

Environment

▪ Operating temperature: Ambient with air flow: -5°C ~ 55°C (according

to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14) ▪ Storage temperature: -20°C ~ 80°C ▪ Relative humidity: 10% to 93% (non-Condensing) ▪ Shock protection: 20G, half sine, 11ms, IEC60068-2-27 ▪ Vibration protection

Random: 0.5Grms @5~500 Hz according to IEC68-2-64 Sinusoidal: 0.5Grms @5~500 Hz according to IEC68-2-6

Certifications

▪ CE approval ▪ FCC Class A

2

NISE 104 User Manual

Chapter 1: Product Introduction

Knowing Your NISE 104

Front Panel

Antenna Hole

COM1

(RS232)

Power Switch

Press to power-on or power-off the system.

Power Status LED

Indicates the system’s power status.

HDD Activity LED

Indicates the hard drive’s activity.

COM1 and COM4 RS232

Used to connect RS232 compatible devices.

COM2 and COM3 RS232/RS422/RS485

Used to connect RS232/422/485 compatible serial devices.

COM2

(RS232/422/485)

COM3

(RS232/422/485)

USB

Line-out

COM4

(RS232)

Mic-in

Power Switch

Power LED Antenna Hole

HDD LED

USB2.0 Ports

Two USB2.0 ports to connect the system with USB2.0/1.1 devices.

Line-out

Line-out jack to connect speakers or headphones.

Mic-in

Mic-in jack to connect microphones.

Antenna Holes

Empty antenna holes reserved for installing optional Mini-PCIe Wi-Fi module.

3

NISE 104 User Manual

Chapter 1: Product Introduction

Rear Panel

10~28 DC

DVI-I HDMI LAN1 LAN2

CF USB

10~28V DC Input

Used to plug a DC power cord.

DVI-I

Used to connect a digital LCD panel.

HDMI

Used to connect a high-definition display.

USB2.0 Ports

Four USB2.0 ports to connect the system with USB2.0/1.1 devices.

Gigabit LAN Ports

Dual Gigabit LAN ports to connect the system to a local area network.

CompactFlash

Used to insert a CompactFlash card.

4

NISE 104 User Manual

Chapter 1: Product Introduction

Mechanical Dimensions

12.50

60.00

94.00

115.00

131.00

185.00

194.00

206.00

60.00

54.00

5

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

ChaPter 2: JumPers and ConneCtors

This chapter describes how to set the jumpers and connectors on the NISE 104 motherboard.

Before You Begin

▪ Ensure you have a stable, clean working environment. Dust and dirt can

get into components and cause a malfunction. Use containers to keep small components separated.

▪ Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following: – A Philips screwdriver – A flat-tipped screwdriver – A set of jewelers screwdrivers – A grounding strap – An anti-static pad

▪ Using your fingers can disconnect most of the connections. It is

recommended that you do not use needle-nosed pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

▪ Before working on internal components, make sure that the power is off.

Ground yourself before touching any internal components, by touching a metal object. Static electricity can damage many of the electronic components. Humid environments tend to have less static electricity than

dry environments. A grounding strap is warranted whenever danger of

static electricity exists.

Precautions

Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous.

Follow the guidelines below to avoid damage to your computer or yourself:

▪ Always disconnect the unit from the power outlet whenever you are

working inside the case.

▪ If possible, wear a grounded wrist strap when you are working inside the

computer case. Alternatively, discharge any static electricity by touching

the bare metal chassis of the unit case, or the bare metal body of any

other grounded appliance.

▪ Hold electronic circuit boards by the edges only. Do not touch the

components on the board unless it is necessary to do so. Don’t flex or

stress the circuit board.

▪ Leave all components inside the static-proof packaging that they shipped

with until they are ready for installation.

▪ Use correct screws and do not over tighten screws.

6

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

Jumper Settings

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off).

Two-Pin Jumpers: Open (Left) and Short (Right)

Three-Pin Jumpers: Pins 1 and 2 are Short

3

2

1

3

2

7

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors for NISB104

The figure below shows the location of the jumpers and connectors.

Top View

LAN2

19

14

2

8

2

JP7

H8

2

H7

13

JP8

1

7

3

1

10

13 12

4 11 2

JP5

1

3

6449

1

U18

16

17

JP6

COM1

15

69

1

2

1

2

11

33 32

J3

LAN1

12

48

13 12

JP4

34

6449

1

16

17

64

65

102

14

4

8

9

10

32

USB2

16

2

3

J2

48

33

128 103

1

6

J1

38

1

U16

1

5

3

AD

AE

1

10

H6

COM2

USB1

4

85

AA

C

HJG

N

K

R

L

UVT

D

F

W

Y

R251

JP3

31

3

1

JP2

H5

H4

24

16

1

8

CN5

BA

1

3 5 7

9

11

13 15

17 19

21

23

25

U9

1

17

64

49

32

48 33

COM3

5

15

9

69

17

9

1

CN4

1

CN3

2

1

CN2

4

M6

H2

262524232221201918161413121110

272930

9875432

1 A B C

D

E F G H J K L M N P T V W Y AA AB AC AD AE AG AH AJ AK AL

31

U5

1

CN1

H3

COM4

1

6

5

9

JP1

4

1

3

H1

8

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

Bottom View

R624

2

1

S7

2

1

DIMM1

7472

71

P17

CN9

R530

R506

1

2

15

16

17

51

CN8

18

CN6

CN7

J4

1

10

7

1

JP9

12

52

NISE 104 User Manual

U34

204

203

19

20

1

G SB E

2

JP10

9

Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors for NISKIO2

10

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

NISB104

Jumpers

RTC Clear

Connector type: 1x3 3-pin header Connector location: JP6

1

2

3

Normal (default)

Pin Settings

1-2 On Normal 2-3 On Clear BIOS

NOTE: 1-2 On: default

1

2

3

clear CMOS

Connector Pin Definitions

External I/O Interfaces – Front Panel

Power On/Off Switch

Connector location: SW1

Pin Settings

1 GND 2 I_PWRBT# 3 I_PWRBT#

4 GND A1 PWRLED_N C1 PWRLED_P

11

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

COM1 Serial Port

Connector type: DB-9 port Connector location: COM1

Pin Definition Pin Definition

1 DCD1 2 RXD1 3 TXD1 4 DTR1 5 GND 6 DSR1 7 RTS1 8 CTS1 9 RI1

COM2 Serial Port

Connector type: DB-9 port Connector location: COM2

RS232 RS485 RS422

Pin Definition Pin Definition Pin Definition

1 SP2_DCD 1 SP2_DATA- 1 SP2_TX2 SP2_RXD 2 SP2_DATA+ 2 SP2_TX+ 3 SP2_TXD 3 NC 3 SP2_RX+ 4 SP2_DTR 4 NC 4 SP2_RX5 GND 5 GND 5 GND 6 SP2_DSR 6 NC 6 SP2_RTS7 SP2_RTS 7 NC 7 SP2_RTS+ 8 SP2_CTS 8 NC 8 SP2_CTS+ 9 SP2_RI 9 NC 9 SP2_CTS-

12

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

COM3 Serial Port

Connector type: DB-9 port Connector location: COM3

RS232 RS485 RS422

Pin Definition Pin Definition Pin Definition

1 SP3_DCD 1 SP3_DATA- 1 SP3_TX2 SP3_RXD 2 SP3_DATA+ 2 SP3_TX+ 3 SP3_TXD 3 NC 3 SP3_RX+ 4 SP3_DTR 4 NC 4 SP3_RX5 GND 5 GND 5 GND 6 SP3_DSR 6 NC 6 SP3_RTS7 SP3_RTS 7 NC 7 SP3_RTS+ 8 SP3_CTS 8 NC 8 SP3_CTS+ 9 SP3_RI 9 NC 9 SP3_CTS-

COM4 Serial Port

Connector type: DB-9 port Connector location: COM4

Pin Definition Pin Definition

1 DCD4 2 RXD4 3 TXD4 4 DTR4 5 GND 6 DSR4 7 RTS4 8 CTS4 9 RI4

13

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

External I/O Interfaces – Rear Panel

9~36V DC Power Input

Connector type: Phoenix 1x2 2-pin Connector location: CN3

Pin Definition

1 GND 2 VIN+

DVI-I/VGA Connector

Connector type: 24-pin D-Sub, 2.0mm-M-180 (DVI) Connector location: CN4A (DVI) and CN4B (VGA)

Pin Definition Pin Definition

1 TX2 2 TX2+ 3 GND 4 NC 5 NC 6 DDC_CLK 7 DDC_DATA 8 VSYNC_VGA

9 TX1- 10 TX1+ 11 GND 12 NC 13 NC 14 DVI_VCC(+5V) 15 GND 16 HotPlugDet 17 TX0- 18 TX0+ 19 GND 20 DDCCLK_VGA 21 DDCDATA_VGA 22 GND 23 TXCLK+ 24 TXCLK-

C1 RED C2 GREEN C3 BLUE C4 HSYNC_VGA

C5A VGADET C5B GND

MH1 CHASSIS_GND MH2 CHASSIS_GND

14

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

HDMI

Connector type: HDMI port Connector location: CN5

Pin Definition Pin Definition

1 HDMI_DATA2_P 2 GND 3 HDMI_DATA2_N 4 HDMI_DATA1_P 5 GND 6 HDMI_DATA1_N 7 HDMI_DATA0_P 8 GND

9 HDMI_DATA0_N 10 HDMI_CLK_P 11 GND 12 HDMI_CLK_N 13 NC 14 NC 15 HDMI_CTRL_CLK 16 HDMI_CTRL_DATA 17 GND 18 HDMI_VCC5 19 HDMI_HPD_R 20

USB0/1 Ports

Connector type: Dual USB port, Type A Connector location: USB1

Pin Definition Pin Definition

1 +5V 2 Data 03 Data 0+ 4 GND 5 +5V 6 Data 17 Data 1+ 8 GND

15

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

USB2/3 Ports

Connector type: Dual USB port, Type A Connector location: USB2

Pin Definition Pin Definition

1 +5V 2 Data 2-

3 Data 2+ 4 GND

5 +5V 6 Data 3-

7 Data 3+ 8 GND

LAN1 Port

Connector type: RJ45 port with LEDs Connector location: LAN1

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off No link

Act Status

Flashing Yellow Data activity

Off No activity

Pin Definition Pin Definition

1 LAN1_MDI0P 2 LAN1_MDI0N 3 LAN1_MDI1P 4 LAN1_MDI1N 5 LAN1TCT 6 LAN1TCTG 7 LAN1_MDI2P 8 LAN1_MDI2N

9 LAN1_MDI3P 10 LAN1_MDI3N 11 LAN1_LEDACT# 12 LAN1_ACTPW 13 LAN1_LINK 14 LAN1_LINK1G#

MH1 GND MH2 GND

16

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

LAN2 Port

Connector type: RJ45 port with LEDs Connector location: LAN2

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off No link

Act Status

Flashing Yellow Data activity

Off No activity

Pin Definition Pin Definition

1 LAN2_MDI0P 2 LAN2_MDI0N 3 LAN2_MDI1P 4 LAN2_MDI1N 5 LAN2TCT 6 LAN2TCTG 7 LAN2_MDI2P 8 LAN2_MDI2N

9 LAN2_MDI3P 10 LAN2_MDI3N 11 LAN2_LEDACT# 12 LAN2_ACTPW 13 LAN2_LINK 14 LAN2_LINK1G#

MH1 GND MH2 GND

Internal Connectors NISB 104

CPU Fan Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN1

4

1

Pin Definition

1 GND 2 +12V 3 CPUFANIN(CPU_FAN_SPEED) 4 CPUFANOUT(CPU_FAN_PWM)

17

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

1

9

102

DC Input/Output Connector

Connector type: 1x4 JST, 4-pin, 2.5mm pitch Connector location: CN2

4

1

Pin Definition Pin Definition

1 VIN 2 VIN

3 GND 4 GND

GPIO Connector

Connector type: 2x5 10-pin header, 2.0mm pitch Connector location: JP9

Pin Definition Pin Definition

1 +5V 2 GND 3 SIO_GPO24(Pin58) 4 SIO_GPI20(Pin52) 5 SIO_GPO25(Pin59) 6 SIO_GPI21(Pin54) 7 SIO_GPO26(Pin60) 8 SIO_GPI22(Pin56) 9 SIO_GPO27(Pin61) 10 SIO_GPI23(Pin57)

18

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

1

7

82

Keyboard/Mouse Connector

Connector type: 2x4 8-pin header, 2.54mm pitch Connector location: JP7

Pin Definition Pin Definition

1 KBMSVCC 2 KBMSVCC 3 LKBDAT 4 LMDAT 5 LKBCLK 6 LMCLK 7 GND 8 GND

B to B Connector

Connector type: 2x10 20-pin header Connector location: JP10

12

1920

Pin Definition Pin Definition

1 VCC5 2 VCC5 3 I_USBN5 4 I_USBN4 5 I_USBP5 6 I_USBP4 7 GND 8 GND

9 I_USBOC#45 10 VCC3 11 HDD_LED_PWR 12 POWER_LED_PWR 13 HDD_LED_N 14 PWR_LED_N 15 CODEC_HDASYNC 16 CODEC_HDASDO 17 CODEC_HDARST# 18 CODEC_HDABCLK 19 I_SPKR 20 I_HDASDI0

19

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

PWR_BT/RET_BT/LED/SM BUS Pin Header

Connector type: 2x7 14-pin header, 2.0mm pitch Connector location: JP8

142

1

Pin Definition Pin Definition

1 PWR_LED_N 2 PWR_LED_P 3 SATA_LED# 4 SATA_LED_P 5 SMB_C 6 SMB_D 7 3VSB 8 GND

9 PM_SLP_S3 10 PSON 11 POWER BOTTOM 12 GND 13 RESET BOTTOM 14 GND

13

LAN1 LED

Connector type: 2x2 4-pin header, 2.0mm pitch Connector location: JP4

2 4 1

3

Pin Definition

1 LAN1_ACTPW 2 LAN1_LEDACT# 3 LAN1_LINK1G# 4 LAN1_LINK

20

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

1

6

LAN2 LED

Connector type: 2x2 4-pin header, 2.0mm pitch Connector location: JP5

2 4 1

3

Pin Definition

1 LAN2_ACTPW 2 LAN2_LEDACT# 3 LAN2_LINK1G# 4 LAN2_LINK

USB 6 Connector

Connector type: 1x6 6-pin header, 2.0mm pitch Connector location: J2

Pin Definition Pin Definition

1 +5V 2 Data 63 Data 6+ 4 NC 5 NC 6 GND

21

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

SATA Connector

Connector type: Standard Serial ATAII 7P (1.27mm, SATA-M-180) Connector location: CN6

71

Pin Definition

1 GND 2 SATA_TXP0_C 3 SATA_TXN0_C 4 GND 5 SATA_RXN0_C 6 SATA_RXP0_C 7 GND

SATA Power Connector

Connector type: 1x2 JST, 2-pin header, 2.5mm pitch Connector location: J4

12

Pin Definition

1 GND 2 +5V

22

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

C1

C6

C5

C3

C2

C1

SIM Card Connector

Connector location: CN7

Pin Definition Pin Definition

C1 UIM_PWR C2 UIM_RESET C3 UIM_CLK C4 GND C5 UIM_VPP C6 UIM_DATA

3.5G Line-out Pin Header

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP2

1

3

Pin Definition

1 LOUT_RL 2 LOUT_RR 3 ANGND

23

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

S7

CFast CON

Connector type: CFast socket Connector location: CN9

Pin Definition Pin Definition

S1 GND PC1 CDI S2 SATA_TXP1 PC2 GND S3 SATA_TXN1 PC3 NC S4 GND PC4 NC S5 SATA_RXN1 PC5 NC S6 SATA_RXP1 PC6 NC S7 GND PC7 GND

PC8 NC

PC9 CFAST_ACCESS PC10 NC PC11 NC PC12 NC PC13 +3.3V PC14 +3.3V PC15 GND PC16 GND PC17 NC

3.5G Mic-in Pin Header

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP3

1

3

Pin Definition

1 MIC_RL 2 MIC_RR 3 ANGND

24

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Slot

Connector location: CN8

1 2

51 52

Pin Definition Pin Definition

1 PCIEWAKE# 2 +3VSB 3 NC 4 GND 5 NC 6 +1.5V 7 CLKREQ# 8 NC

9 GND 10 NC 11 REF CLK- 12 NC 13 REF CLK+ 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 Disable# 21 GND 22 RST# 23 PCIERX0- 24 +3VSB 25 PCIERX0+ 26 GND

Pin Definition Pin Definition

27 GND 28 +1.5V 29 GND 30 SMBCLK 31 PCIETX0- 32 SMBDATA 33 PCIETX0+ 34 GND 35 GND 36 USB_D37 GND 38 USB_D+ 39 +3VSB 40 GND 41 +3VSB 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 +1.5V 49 NC 50 GND 51 NC 52 +3VSB

25

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

NISKIO2

B to B Connector

Connector type: 2x10 20-pin header Connector location: JP1

12

1920

Pin Definition Pin Definition

1 VCC5 2 VCC5

3 I_USBN4 4 I_USBN5

5 I_USBP4 6 I_USBP5

7 GND 8 GND

9 VCC3 10 I_USBOC#45 11 POWER_LED_PWR 12 HDD_LED_PWR 13 PWR_LED_N 14 HDD_LED_N 15 CODEC_HDASDO 16 CODEC_HDASYNC 17 CODEC_HDABCLK 18 CODEC_HDARST#

19 I_HDASDI0 20 I_SPKR

Line-out Pin Header

Connector type: 3.5mm TRS Connector location: SPK1

Pin Definition

1 GND 2 OUT_L 3 EXLINEOUT_JD 4 NC 5 OUT_R

26

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

Line-out Internal Speaker

Connector type: 1x5 5-pin header, 2.0mm pitch Connector location: JP3

1

Pin Definition

5

1 FRONT_L+ 2 FRONT_L3 FRONT_R+ 4 GND 5 FRONT_R-

Line-in Pin Header

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: JP2

1 4

Pin Definition

1 FLIN_L 2 LIN_JD 3 FLIN_R 4 GND

27

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

USB1~ USB2 Connector

Connector type: USB port, Type A Connector location: CN1 and CN2

Pin Definition

1 VCC5 2 DATA_N 3 DATA_P 4 GND

MIC Pin Header

Connector type: 3.5mm TRS Connector location: MIC1

Pin Definition

1 AU_GND 2 MIC_OUT-L 3 AU_GN 4 MIC_JD1 5 MIC_OUT-R

28

NISE 104 User Manual

Chapter 2: Jumpers and Connectors

PWR

HDD

Power LED/ HDD LED

HDD Access LED Power Status LED

Pin Definition

PWR Green HDD Yellow

29

NISE 104 User Manual

Chapter 3: System Setup

CAUTION!

ChaPter 3: system setuP

Removing the Chassis Cover Installing the DDR3 SODIMM

Prior to removing the chassis cover, make sure the unit’s power is

CAUTION!CAUTION!

off and disconnected from the power sources to prevent electric shock or system damage.

1.With the bottom side of the chassis facing up, remove the mounting screws of the bottom cover and then put them in a safe place for later use.

2.Lift up the cover and remove it from the chassis.

1.Locate the SODIMM socket on the board.

DDR3 SODIMM Socket

30

NISE 104 User Manual

Chapter 3: System Setup

2.Insert the module into the socket at approximately 30 degrees angle. Apply firm even pressure to each end of the module until it slips into the socket. The gold-plated connector on the edge of the module will almost completely disappear inside the socket.

SODIMM

Socket

SODIMM

3.Push the module down until the clips on both sides of the socket lock into position. You will hear a distinctive “click” sound, indicating the module is correctly locked into position.

Clip

31

NISE 104 User Manual

Chapter 3: System Setup

Installing a SATA Hard Drive

1.The inner side of the bottom cover is where you will install the SATA drive. Align the mounting holes of the SATA drive with the mounting holes on the cover.

SATA Drive

2.While supporting the SATA drive, turn the cover to the other side. This will be the outer side of the cover. Use the provided screws to secure the drive in place.

Inner Side of the Cover Outer Side of the Cover

Cover

32

NISE 104 User Manual

Chapter 3: System Setup

Installing a CompactFlash Card

3.Connect the SATA data/power cable to the connector on the SATA drive.

SATA Data/Power Cable

SATA Drive

CN6

J4

1.The CompactFlash slot is located at the rear side of the chassis

CompactFlash Slot

4.Connect the SATA data/power cable to connectors CN6 and J4 on the motherboard respectively.

33

NISE 104 User Manual

Chapter 3: System Setup

2. Remove the mounting screws on the CompactFlash slot’s cover. 3. Remove the slot’s cover to access the CompactFlash slot.

Mounting Screws

CompactFlash Slot

4. Fasten the CompactFlash cover after installation.

34

NISE 104 User Manual

Chapter 3: System Setup

Installing a Wireless LAN Module

1.Locate the Mini PCI Express slot on the motherboard. 2.Insert the wireless LAN module into the Mini PCI Express slot at a 45 degrees angle until the gold-plated connector on the edge of the module completely disappears inside the slot.

Wireless LAN Module

Mini PCI Express Slot

35

Mini PCI Express Slot

NISE 104 User Manual

Chapter 3: System Setup

3.Push the module down and then secure it with mounting screws.

Mounting Screws

4.Remove the antenna hole covers located at the front panel of the chassis.

Antenna Hole Covers

Note: If it is full-size module, please remove this bracket.

36

NISE 104 User Manual

Chapter 3: System Setup

5.Insert the antenna jacks into the antenna holes. 6.Insert the 2 rings (ring 1 and ring2) onto the antenna jacks

Antenna Jack (with long cable)

Antenna Jack (with short cable)

37

Ring 1

Ring 2

NISE 104 User Manual

Chapter 3: System Setup

7.Attach RF cables of the antenna jacks onto the module. 8.Connect an external antenna to the antenna jack.

RF Cables

38

NISE 104 User Manual

Chapter 3: System Setup

Installing the SIM Card

1.Slide the SIM card holder to the “OPEN” position.

2.Slide the SIM card into the SIM card holder.

SIM Card Holder SIM Card

39

NISE 104 User Manual

Chapter 3: System Setup

Installing the SATA DOM

3. Move the holder down and then slide it to the “LOCK” position.

1.Locate the SATA connector on the motherboard and remove the screw as marked.

SATA Connector

Screw

40

NISE 104 User Manual

Chapter 3: System Setup

2.Screw and tighten the copper post (included in the accessory bag) into

the screw hole.

3.Install the SATA DOM and connect the SATA power cable to the SATA DOM connector on the motherboard.

Screw

4.Tighten a screw on the top of the copper post.Copper Post

41

NISE 104 User Manual

Chapter 3: System Setup

Installing Wallmount Brackets

The wallmount brackets provide a convenient and economical way to mount the system on a wall.

1.The mounting holes are located at the bottom of the system. Secure the brackets on each side of the system using the mounting screws provided.

Secure with screws

Wallmount Bracket

2.Mount the system on the wall by fastening screws through the bracket’s mounting holes.

Fasten screws to mount the system to the wall

42

NISE 104 User Manual

Chapter 4: BIOS Setup

ChaPter 4: BIos setuP

This chapter describes how to use the BIOS setup program for the NISE 104. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future.

To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.

About BIOS Setup

The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

These parameters are stored in non-volatile battery-backed-up CMOS RAM that saves this information even when the power is turned off. When the system is turned back on, the system is configured with the values found in CMOS.

With easy-to-use pull down menus, you can configure such items as:

▪ Hard drives, diskette drives, and peripherals ▪ Video display type and display options ▪ Password protection from unauthorized use ▪ Power management features

The settings made in the setup program affect how the computer performs. It is important, therefore, first to try to understand all the setup options, and second, to make settings appropriate for the way you use the computer.

When to Configure the BIOS

This program should be executed under the following conditions:

▪ When changing the system configuration ▪ When a configuration error is detected by the system and you are

prompted to make changes to the setup program

▪ When resetting the system clock ▪ When redefining the communication ports to prevent any conflicts ▪ When making changes to the Power Management configuration ▪ When changing the password or making other changes to the security

setup

Normally, CMOS setup is needed when the system hardware is not consistent with the information contained in the CMOS RAM, whenever the CMOS RAM has lost power, or the system features need to be changed.

43

NISE 104 User Manual

Chapter 4: BIOS Setup

Default Configuration

Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

Entering Setup

When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways:

▪ If the error occurs before the display device is initialized, a series of

beeps will be transmitted.

▪ If the error occurs after the display device is initialized, the screen will

display the error message.

Powering on the computer and immediately pressing <Del> allows you to enter Setup. Another way to enter Setup is to power on the computer and wait for the following message during the POST:

Key Function

Right and Left arrows Moves the highlight left or right to select a

menu.

Up and Down arrows Moves the highlight up or down between

sumenus or fields.

<Esc> Exits the BIOS Setup Utility.

+ (plus key) Scrolls forward through the values or options of

the highlighted field.

- (minus key) Scrolls backward through the values or options of the highlighted field.

Tab Selects a field.

<F1> Displays General Help.

<F2> Load previous values

<F3> Load optimized default values.

<F4> Saves and exits the Setup program.

<Enter> Press <Enter> to enter the highlighted submenu.

TO ENTER SETUP BEFORE BOOT PRESS <CTRL-ALT-ESC> Press the <Del> key to enter Setup:

Scroll Bar

When a scroll bar appears to the right of the setup screen, it indicates that there are more available fields not shown on the screen. Use the up and down arrow keys to scroll through all the available fields.

Submenu

When “u“ appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press <Enter>.

44

NISE 104 User Manual

Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit. Use arrow keys to select among the items and press <Enter> to accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.

Advanced Chipset BootMain

BIOS Informat ion BIOS Verdor Core Version Compliancy Project Version Build Date and Time

Intel RC version

System Date System Time

Access Level

American Megatrends

4.6.5.1 UEFI 2.3; PI 1.2 N104-003 04/05/2012 16:05:57

[Tue 06/12/2012] [04:37:08]

Administrator

Security

Save & Exit

Intel Reference Code version

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Intel RC Version

Displays the Intel Reference Code version.

System Date

The date format is <day>, <month>, <date>, <year>. Day displays a day, from Monday to Sunday. Month displays the month, from January to December. Date displays the date, from 1 to 31. Year displays the year, from 1999 to 2099.

System Time

The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.

Access Level

Displays the access level of the current user in the BIOS.

45

NISE 104 User Manual

Chapter 4: BIOS Setup

Advanced

The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.

Setting incorrect field values may cause the system to malfunction.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM

Launch Lan2 PXE OpROM

CPU Conguration IDE Conguration USB Conguration Super IO Conguration

H/W Monitor

PPM Conguration

Disabled

[Disabled]

Launch Lan1 PXE OpROM

Enabled

Save & Exit

Enable or Disable Boot Option for Lan1

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Launch LAN1/2 PXE OpROM

Enables or disables the boot option for legacy network devices connected to LAN1 and LAN2.

CPU Configuration

This section is used to configure the CPU.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM Launch Lan2 PXE OpROM

CPU Conguration

IDE Conguration USB Conguration Super IO Conguration

H/W Monitor

PPM Conguration

[Disabled] [Disabled]

Save & Exit

CPU Conguration Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

46

NISE 104 User Manual

Chapter 4: BIOS Setup

Hyper-Threading

Advanced

CPU Conguration

Processor Type EMT64 Proceddor Speed System Bus Speed Ratio Status Actual Ratio System Bus Speed Processor Stepping Microcode Revision L1 Cache RAM L2 Cache RAM Processor Core Hyper-Threading

Hyper-Threading

Execute Disable Bit Limit CPUID Maximum

Intel(R) Atom (TM) CPU Supported 2132 MHZ 533MHZ 16 16 533MHZ 30661 262 2x56 k 2x512 k Dual Supported

[Enabled]

[Enabled] [Disabled]

Enabled for Windows XP and Linux (OS optimized for HyperThreading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology).

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Advanced

CPU Conguration

Processor Type EMT64 Proceddor Speed System Bus Speed Ratio Status Actual Ratio System Bus Speed Processor Stepping Microcode Revision L1 Cache RAM L2 Cache RAM Processor Core Hyper-Threading

Hyper-Threading

Execute Disable Bit Limit CPUID Maximum

Disabled

Enabled

Intel(R) Atom (TM) CPU Supported 2132 MHZ 533MHZ 16 16 533MHZ 30661 262

Launch Lan1 PXE OpROM

2x56 k 2x512 k Dual Supported

[Enabled]

[Enabled] [Disabled]

This field is used to enable or disable hyper-threading.

Enabled for Windows XP and Linux (OS optimized for HyperThreading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology).

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

47

NISE 104 User Manual

Chapter 4: BIOS Setup

Execute Disable Bit

Advanced

CPU Conguration

Processor Type EMT64 Proceddor Speed System Bus Speed Ratio Status Actual Ratio System Bus Speed Processor Stepping Microcode Revision L1 Cache RAM L2 Cache RAM Processor Core Hyper-Threading

Hyper-Threading

Execute Disable Bit Limit CPUID Maximum

Intel(R) Atom (TM) CPU Supported 2132 MHZ 533MHZ 16 16 533MHZ 30661 262

Launch Lan1 PXE OpROM

Disabled

Enabled

2x56 k 2x512 k Dual Supported

[Enabled]

[Enabled] [Disabled]

XD can prevent certain classes

of malicious buffer overow

attacks when combined with a supporting OS (Windows Server 2003 SP1,Windows XP SP2, SuSE Linux 9.2, RedHAT Enterprise 3 Update 3.)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

This field is used to enable or disable execute disable bit. When this field is set to Disabled, it will force the XD feature flag to always return to 0. XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3).

Limit CPUID Maximum

The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or lesser than 3.

IDE Configuration

This section is used to configure the IDE devices.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM Launch Lan2 PXE OpROM

CPU Conguration

IDE Conguration

USB Conguration Super IO Conguration

H/W Monitor

PPM Conguration

[Disabled] [Disabled]

Save & Exit

IDE Devices Conguration

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

48

NISE 104 User Manual

Chapter 4: BIOS Setup

Configure SATA as

Advanced

SATA Port0 SATA Port1

SATA Controller(s)

Congur SATA as

IDE

AHCI

Not Present Not Present

[Enabled]

[AHCI]

Congure SATA as

Configures the SATA as IDE or AHCI mode.

IDE

This option configures the Serial ATA drives as Parallel ATA physical storage device.

AHCI

This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance.

Select a conguraton for SATS

Controller

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

SATA Controller(s)

Enables or disables SATA controller.

USB Configuration

This section is used to configure USB devices.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM Launch Lan2 PXE OpROM

CPU Conguration IDE Conguration

USB Conguration

Super IO Conguration

H/W Monitor

PPM Conguration

[Disabled] [Disabled]

Save & Exit

USB Conguration Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

49

NISE 104 User Manual

Chapter 4: BIOS Setup

Super IO Configuration

This section is used to configure the I/O board Super I/O chip.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM Launch Lan2 PXE OpROM

CPU Conguration IDE Conguration USB Conguration

Super IO Conguration

H/W Monitor

PPM Conguration

[Disabled] [Disabled]

Save & Exit

System Super IO Chip Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port 0 Configuration

Advanced Chipset Boot SecurityMain

Serial Port 0 Conguration

Serial Port

Device Settings

Onboard Serial Port Max Baud Rate

115200 bps

921600 bps

[Enabled]

IO=3F8H; IRQ=4;

[IO=3F8H; IRQ=4;] [115200 bps]

Save & Exit

Change the Serial Port Max Baud Rate. Select <115200 bps> or <921600 bps>

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

This field configures the maximum baud rate of the serial port 0, the options are 115200 bps and 921600 bps.

50

NISE 104 User Manual

Chapter 4: BIOS Setup

Onboard Serial Port Mode

Advanced Chipset Boot SecurityMain

Serial Port 1 Conguration

Serial Port

Device Settings

Chang Settings

Onboard Serial Port 1 Mode

Onboard Serial Port Max Baud Rate

RS232 RS422 RS485 RS485 AUTO

Onboard Serial Port 1 Mode

[Enabled]

IO=2F8H; IRQ=3;

[IO=2F8H; IRQ=3;]

[RS232]

[115200 bps]

Save & Exit

Change the Serial Port 1 mode. Select <RS232> or <RS422> or <RS485> mode

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Onboard Serial Port Max Baud Rate

Advanced Chipset Boot SecurityMain

Serial Port 0 Conguration

Serial Port

Device Settings

Chang Settings Onboard Serial Port 1 Mode

Onboard Serial Port Max Baud Rate

115200 bps

921600 bps

[Enabled]

IO=2F8H; IRQ=3;

[IO=2F8H; IRQ=3;] [RS232]

[115200 bps]

Save & Exit

Change the Serial Port Max Baud Rate. Select <115200 bps> or <921600 bps>

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

This field is used to configure the mode of serial port 1 as RS232, RS422, RS485 or RS485 AUTO.

This field configures the maximum baud rate of the serial port 1, the options are 115200 bps and 921600 bps.

51

NISE 104 User Manual

Chapter 4: BIOS Setup

H/W Monitor

This section is used to configure the hardware temperature, fan speed and voltages.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM Launch Lan2 PXE OpROM

CPU Conguration IDE Conguration USB Conguration Super IO Conguration

H/W Monitor

PPM Conguration

[Disabled] [Disabled]

Save & Exit

Monitor hardware status

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Advanced Chipset Boot SecurityMain

Pc Health Status

CPU Temperature System Temperature CPU FAN Speed CPU:Vcore +3.3V +5V +12V

: +33 C : +35 C : N/A : +1.168 V : +3.264 V : +5.120 V : +11.932 V

Save & Exit

Monitor hardware status

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

52

NISE 104 User Manual

Chapter 4: BIOS Setup

PPM Configuration

This section is used to configure Intel SpeedStep.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM Launch Lan2 PXE OpROM

CPU Conguration IDE Conguration USB Conguration Super IO Conguration

H/W Monitor

PPM Conguration

[Disabled] [Disabled]

Save & Exit

PPM Conguration

Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Chipset

This section is used to configure the system based on the specific features of the chipset.

Advanced

Host Bridge

South Bridge [Disabled]

Chipset Boot SecurityMain

[Disabled]

Save & Exit

Host Bridge Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

53

Setting incorrect field values may cause the system to malfunction.

NISE 104 User Manual

Chapter 4: BIOS Setup

Host Bridge

Displays the memory information

Advanced

Chipset Boot SecurityMain

Save & Exit

Intel IGD Conguration

******* Memory Information******* Memory Freauency Total Memory

1067 MHZ (DDR3) 2048 MB

Cong Intel IGD Settings

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

54

NISE 104 User Manual

Chapter 4: BIOS Setup

Intel® IGD Configuration

Settings for Intel® IGD.

IGFX – Boot Type

Advanced

Intel IGD Conguration

IGFX - Boot Type

Fixed Graphics Memory Size

CRT

DVI

CRT + HDMI

Chipset Boot SecurityMain

IGFX - Boot Type

[DVI]

[128MB]

Save & Exit

Select the Video Device Which will be activated during POST. This has no effect if external graphics present.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

This field is used to configure which video device will be activated during POST. This has no effect if external graphics present. The options are CRT, DVI and CRT + HDMI.

Due to Intel® VBIOS wrong address issue in HDMI mode, there is no “HDMI” display output option in the BIOS menu.

Please refer to the following table for the display reference when a HDMI monitor is connected to NISE 104.

Connected Monitor Type BIOS setting

Display output at

POST mode

HDMI only DVI HDMI

HDMI only CRT + HDMI HDMI

HDMI+ DVI via Y cable DVI DVI

HDMI+ VGA via Y cable CRT + HDMI CRT + HDMI

HDMI+ VGA via Y cable VGA VGA

55

NISE 104 User Manual

Chapter 4: BIOS Setup

Fixed Graphics Memory Size South Bridge

Advanced

Intel IGD Conguration

IGFX - Boot Type

Fixed Graphics Memory Size

128MB

256MB

Chipset Boot SecurityMain

[CRT + HDMI]

[128MB]

Fixed Graphics Memory Size

Save & Exit

Congure Fixed Graphics

Memory Size

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

This field is used to configure the memory size of the fixed graphics, the options are 128MB and 256MB.

Advanced

Azalia Controller SMBus Controller

High Precision Event Timer Conguration

High Precision Timer

Restore AC Power Loss

Chipset Boot SecurityMain

[HD Audio] [Enabled]

[Enabled]

[Power On]

Azalia Controller

This section disables Azalia or enables HD Audio.

SMBus Controller

This section is used to configure SMBus.

Save & Exit

Select AC power state when power is re-applied after a power failure.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

High Precision Timer

This section is used to configure High Precision Event Timer.

56

NISE 104 User Manual

Chapter 4: BIOS Setup

Restore AC Power Loss

This section is used to configure Restore AC Power Loss.

Advanced

Azalia Controller SMBus Controller

High Precision Event Timer Conguration

High Precision Timer

Restore AC Power Loss

Chipset Boot SecurityMain

Restore AC Power LOSS

Power off

Power on

[HD Audio] [Enabied]

[Enabied]

[Power On]

Save & Exit

Select AC power state whenpower is re-applied after a power failure.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Boot

Boot Configuration

This section is used to configure settings during sytem boot.

Setup Prompt Timeout

This section configures the number of seconds to wait for the setup activation key.

Quiet Boot

When Enabled, the BIOS will shorten or skip some check items during POST. This will decrease the time needed to boot the system.

GateA20 Active

Configures the GateA20 function.

Option ROM Messages

Configures the ROM message.

This field is used to configure the AC power state when power is restored after power failure, the options are Power Off and Power On.

57

NISE 104 User Manual

Chapter 4: BIOS Setup

Interrupt 19 Capture

When enabled, it allows the optional ROM to trap interrupt 19.

Boot Option Priorities

Boot option #1

Advanced

Boot conguration

Setup Prompt Timeout Bootup NumLock State

Quiet Boot

CSM16 Module Version

GateA20 Active

Option ROM Messages Interrupt 19 Capture

Boot Option Priorities

Boot Option #1

Boot Option #2

Hard Drive BBS Priorities

Chipset

SATA SM:TS4GCFX500I UEFI: -Pretec 01GB 2.00

Disabled

Boot SecurityMain

1 [On]

[Disabied]

07.65

[Upon Reauest] [Force BIOS]

Boot Option #1

Save & Exit

Select AC power state whenpower is re-applied after a power failure.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Security

Advanced

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password and must be entered to boot or enter Serup. In Setup the User will have Administrator rights. The password length must be in the following range: Minimum length 3 Maximum length 20

Administrator Password

User Password

Administrator Password

Sets the administrator’s password

Chipset

Boot

SecurityMain

Save & Exit

Set Administrator Password

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

This field is used to adjust the boot sequence of the system. Boot Option #1 is the first boot device that the system will boot from, next will be #2 and so forth.

User Password

Sets the user’s password.

58

NISE 104 User Manual

Chapter 4: BIOS Setup

Save & Exit

Advanced

Save Changes and Exit

Discard changes and Exit Save Changes and Reset Discard Changes and Reset

Save Options

Save Changes Discard Changes

Restore Defaults Save as User Defaults Restore User Defaults

Boot Override

Launch EFI Shell from lesystem device

Chipset

Boot SecurityMain

Save & Exit

Exit systm setup after saving the changes.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Save Changes and Exit

To save the changes and exit the Setup utility, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes. You can also press <F4> to save and exit Setup.

Discard Changes and Exit

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting. You can also press <ESC> to exit without saving the changes.

Save Changes and Reset

To save the changes and reset, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes and Reset

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting.

Save Changes

To save changes and continue configuring the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes

To discard the changes, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes to discard all changes made and restore the previously saved settings.

Restore Defaults

To restore the BIOS to default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Save as User Defaults

To use the current configurations as user default settings for the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

59

NISE 104 User Manual

Chapter 4: BIOS Setup

Restore User Defaults

To restore the BIOS to user default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Boot Override

To bypass the boot sequence from the Boot Option List and boot from a particular device, select the desired device and press <Enter>.

Launch EFI Shell from filesystem device

To launch EFI shell from a filesystem device, select this field and press <Enter>.

60

NISE 104 User Manual

Appendix A: GPI/O Programming Guide

aPPendIx a: GPI/o ProGrammInG GuIde

Digital I/O (Digital Input/Output) pins are provided for custom system design. This appendix provides definitions and its default setting for the Digital I/O pins in the NISE 104. The pin definition is shown is the following table:

PIN Description PIN Description

1 +5V 2 GND 3 GPO24 4 GPI20 5 GPO25 6 GPI21 7 GPO26 8 GPI22 9 GPO27 10 GPI23

IO base address : A00h Bit0 : GPI20 Bit1 : GP I21 Bit2 : GP I22 Bit3 : GP I23 Bit4 : GPO24 Bit5 : GPO25 Bit6 : GPO26 Bit7 : GPO27

1. Read/Write GPIO data by I/O port A04h

61

NISE 104 User Manual

Appendix B: Watchdog Timer

aPPendIx B: WatChdoG tImer

NISE104 Watch Dog Function Configuration Sequence Description:

Step1. See “SetupWDT” procedure #Setup Watchdog Timer Environment

Step2. See “TimeBaseWDT” procedure #Initial Watchdog Timer. Users can select second or minute.

Start

Step3. See “TimeCountWDT” procedure #Set Watchdog Timer Time-out Value. Users can set time-out value.

Step4: See ExitSetup procedure #Exit Setup Environment

End

62

NISE 104 User Manual

Appendix B: Watchdog Timer

ITE8783F WatchDog Programming Guide

=============================================== SetupWDT PROC mov dx, 2eh mov al, 087h out dx, al nop nop mov al, 01h out dx, al nop nop mov al, 55h out dx, al nop nop out dx, al ;Write operations to special address port (2E) for entering MB PnP Mode.

mov al, 07h out 2eh, al mov al, 07h ;Select logical device for Watch Dog. out 2fh, al ret SetupWDT ENDP

or al, 80h ;Here!! set 80h for second, set 00h for minute out 2fh, al ret TimeBaseWDT ENDP

=============================================== TimeCountWDT PROC mov al, 73h ;WDT Time-out register. out 2eh, al mov al, 03h ;Here!! Set count 3. out 2fh, al ret TimeCountWDT ENDP =============================================== ExitSetup PROC mov al, 02h out 2eh, al mov al, 02h out 2fh, al ret ExitSetup ENDP ===============================================

=============================================== TimeBaseWDT PROC mov al, 72h out 2eh, al mov al, 10h ;Set WDT reset upon PWROK

63

NISE 104 User Manual

Appendix C: Power Consumption

aPPendIx C: PoWer ConsumPtIon

1.Test Configuration 2.Power Consumption Measurement

System Configuration Description

Chassis CHASSIS NISE104 VER:A

CPU

Memory

CPU board N/A

Motherboard NISB104 REV:B

HDD

FDD N/A

CD-ROM N/A

CFast Transcend CFast 4GB (TS4GCFX5001)

Power Supply POWER ADAPTER FSP060-DBAB1

Add-on Card N/A

CPU Cooler NISE104 CPU HEATSINK SHYUNG SHUHN System FAN N/A

Keyboard Microsoft Wired Keyboard 600

Mouse Microsoft Basic Optical Mouse

Intel® Atom™ Processor D2550

(1M Cache, 1.86 GHz)

Apacer 2GB DDR3 1066MHz SODIMM

(78.A2GC9.AF0)

SATA2 HDD 2.5 250GB 7200RPM

HTE725025A9A364

Purpose

The purpose of the power consumption test is to verify the power dissipation of system, and the loading of power supply.

Test Equipment

PROVA CM-07 AC/DC CLAMP METER

Device Under Test

DUT: sys#1/

Test Procedure

1.Power up the DUT, boot into Windows 7 x32 Ultimate.

2.Entering standby mode (HDD power down).

3.Measure the power consumption and record it.

4.Run Burn-in test program to apply 100% full loading.

5.Measure the power consumption and record it.

3.Test Data

Sys #1 Sys #1

+12V +24V

Full-Loading Mode 1.81A 0.96A

Total

Standby S1Mode 0.84A 0.45A

Total

21.72W 23.04W

10.08W 10.8W

64

NISE 104 User Manual

NEXCOM NISE 104 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
