New Holland T6000 Delta Series Tractor Specifications

T6020 T6030 T6050

T6000 DELTA SERIES T6020 T6030 T6050

NGINE

Gross, hp (KW) 110 (82.5) 115 (86.3) 125 (93.8) Rated PTO, hp (kW) 90 (67.1) 95 (71) 105 ( 78.3)

Rated speed, rpm.................................................................................................................................2200 ...............................................................................................................

Cylinders/displacement, cu. in. (L) 4 / 274 (4.5) 6 / 411 (6.75) 6 / 411 (6.75) Number of valves 8 12 12

Aspiration.............................................................................................................................Turbocharged/intercooled...............................................................................................

Fuel injection ...................................................................................................................Mechanical Bosch rotary pump..........................................................................................

ELECTRICAL

Standard alternator .....................................................................................................................120 amp/12 volt......................................................................................................

Battery capacity (1 battery), CCA 960 960 960

TRANSMISSION

24x24 DualCommand™ Standard Standard NA 16x16 ElectroShift™ Optional Optional Standard

Creeper ..............................................................................................................................................Optional.............................................................................................................

PTO – standard (reversible shaft).........................................................................................540/1000 rpm, 1-3/8 in. ...............................................................................................

AXLES

Standard rear diameter, in. (mm) ......................................................................................................3.6 (92).............................................................................................................

Rear axle length – standard, in. (mm).............................................................................................98 (2489) ...........................................................................................................

2WD axle...........................................................................................................................................Standard............................................................................................................

Conventional FWD axle w/ limited slip ..............................................................................................Optional.............................................................................................................

2WD tread adjustability, in. (mm) .......................................................................................63.2 - 86.2 (1605 - 2190)...............................................................................................

FWD tread adjustability, in. (mm) .........................................................................................62.2 - 92 (1580 - 2337) ................................................................................................

Wheelbase (2WD), in. (mm) 93.3 (2370) 104.4 (2652) 104.4 (2652) Wheelbase (FWD), in. (mm) 94.9 (2410) 104.7 (2661) 104.7 (2661)

HYDRAULICS

Hydraulic type ..........................................................................................................................Open center system ...................................................................................................

Remotes – std./opt...............................................................................................................................2 / 3................................................................................................................

Main/implement pump flow, gpm (L/min) .......................................................................................16.6 (63)............................................................................................................

Steering and services pump flow for 24x24, gpm (L/min)..............................................................10.5 (40)............................................................................................................

Steering and services pump flow for 16x16, gpm (L/min)..............................................................12.4 (47)............................................................................................................

Total tractor hydraulic flow 24x24 / 16x16, gpm (L/min)....................................................27.1 (102.6) / 29 (109.8)...............................................................................................

Draft control – std./opt. ........................................................................................................Mechanical draft control................................................................................................

3-point hitch category .........................................................................................................................Cat. II ..............................................................................................................

3-point hitch lift capacity – std./opt., lb. (kg)....................................................................7,509 (3406) / 8,813 (3998) ............................................................................................

CAPACITIES

Fuel tank, gal. (L) 46.5 (180) 67 (254) 67 (254) Engine oil, gal. (L) 10.6 (10) 16 (15) 16 (15)

Hydraulic fluid, gal. (L) .....................................................................................................................17.1 (65)............................................................................................................

HORIZON™ CAB W/ HI-VISIBILITY PANEL

Glass area including hi-visibility panel, sq. ft. (m

Sound level, dBA .................................................................................................................................71-73...............................................................................................................

SHIPPING WEIGHT

Std 2WD ROPS, lb. (kg) 9,090 (4110) 9,980 (4527) 9,986 (4530) Std MFD ROPS, lb. (kg) 9,435 (4280) 10,360 (4700) 10,360 (4700) Std 2WD cab, lb. (kg) 10,000 (4550) 10,165 (4610) 10,235 (4642) Std MFD cab, lb. (kg) 10,383 (4710) 11,336 (5141) 11,406 (5173) Height to top of ROPS / Cab, in. (mm) 112.4 (2856) / 114.1 (2898) / 114.1 (2898) /

Height to top of exhaust, in. (mm) 107.3 (2726) 109.0 (2770) 109.0 (2770)

) ..........................................................................63 (5.85)............................................................................................................

109.2 (2775) 111.0 (2819) 111.0 (2819)

Page 1 of 4

New Holland T6000 Plus Series Tractor Specifications

T6020 T6030 T6050 T6070

T6000 PLUS SERIES T6020 T6030 T6050 T6070

NGINE

Gross, hp (kW) 110 (82.5) 115 (86.3) 125 (93.8) 140 (105.0) Rated PTO, hp (kW) 90 (67.1) 95 (71) 105 (78.3) 120 (89.5)

Rated speed, rpm........................................................................................................................................2200 ........................................................................................................

Cylinders/displacement, cu. in. (L) 4 / 274 (4.5) 6 / 411 (6.75) 6 / 411 (6.75) 6 / 411 (6.75) Number of valves 8 12 12 12

Aspiration .............................................................................................................................................Turbocharged .................................................................................................

ELECTRICAL

Standard alternator............................................................................................................................120 amp/12 volt ...............................................................................................

Battery capacity (1 battery), CCA.................................................................................................................960 .........................................................................................................

TRANSMISSION

16x16 ElectroShift™ ................................................................................................................................Standard .....................................................................................................

16x16 AutoShift™.....................................................................................................................................Optional......................................................................................................

Creeper with additional 32F/32R..............................................................................................................Optional......................................................................................................

PTO – standard (reversible shaft) ...............................................................................................540/1000 rpm, 1-3/8 in. ........................................................................................

AXLES

Standard rear diameter, in. (mm).............................................................................................................3.6 (92)......................................................................................................

Rear axle length - standard, in. (mm).....................................................................................................98 (2489) ....................................................................................................

Heavy duty 2WD axle Standard Standard Standard NA Conventional FWD axle w/ limited slip Optional Optional Optional Standard

Conventional FWD axle w/ TerraLock™....................................................................................................Optional......................................................................................................

SuperSteer™ FWD axle w/ TerraLock.......................................................................................................Optional......................................................................................................

TerraGlide™ active suspended axle w/ TerraLock ....................................................................................Optional......................................................................................................

FastSteer™................................................................................................................................................Optional......................................................................................................

2WD tread adjustability, in. (mm) ..................................................................63.2 - 86.2 (1605 - 2190) ............................................................ NA

FWD tread adjustability, in. (mm)................................................................................................62.2 - 92 (1580 - 2337) .........................................................................................

Wheelbase (2WD), in. (mm) 93.3 (2370) 104.4 (2652) 104.4 (2652) NA Wheelbase (FWD), in. (mm) 94.9 (2410) 104.7 (2661) 104.7 (2661) 104.7 (2661)

HYDRAULICS

Hydraulic type............................................................................................................................Closed center load sensing.......................................................................................

Remotes, std./opt.....................................................................................................2 / 3 or 4 (mechanical) or 2 / 3 or 4 (electronic)......................................................................

Main/implement pump flow, gpm (L/min)............................................................................................26.5 (100.3) ..................................................................................................

Steering and services pump flow, gpm (L/min)......................................................................................10.5 (40).....................................................................................................

Total tractor hydraulic flow, gpm (L/min)................................................................................................37 (140)......................................................................................................

Draft control, std./opt. ................................................................Mechanical draft control / electronic draft control.......................................... Electronic draft control

3-point hitch category – MDC./EDC. Cat. II / Cat. II/IIIN Cat. II / Cat. II/IIIN Cat. II / Cat. II/IIIN NA / Cat. II/IIIN

3-point hitch lift capacity – MDC./EDC., lb. (kg)..........................................9,285 (4211) / 9,620 (4363) .......................................................... NA / 12,185 (5527)

CAPACITIES

Fuel tank, gal. (L) 46.5 (180) 67 (254) 67 (254) 67 (254) Fuel tank w/ SuperSteer, gal. (L) 40.2 (152) 60.8 (230) 60.8 (230) 60.8 (230) Engine oil, gal. (L) 10.6 (10) 16 (15) 16 (15) 16 (15) Hydraulic fluid, gal. (L) 16.3 (62) 16.3 (62) 16.3 (62) 16.3 (62)

HORIZON™ CAB W/ HI-VISIBILITY PANEL

Glass area including hi-visibility panel, sq. ft. (m2)................................................................................63 (5.85).....................................................................................................

Sound level, dBA ........................................................................................................................................70-72........................................................................................................

SHIPPING WEIGHT

Std 2WD, lb. (kg) 10,008 (4540) 10,890 (4940) 10,890 (4940) NA Std MFD, lb. (kg) 10,383 (4710) 11,336 (5141) 11,336 (5141) 11,336 (5141) Height to top of cab, in. (mm) 112.4 (2855) 114.1 (2898) 114.1 (2898) 114.1 (2898) Height to top of exhaust, in. (mm) 113.2 (2875) 114.9 (2918) 114.9 (2918) 114.9 (2918)

Page 2 of 4
