NEW HOLLAND T7

T7.170IT7.185IT7.200IT7.210IT7.220IT7.235IT7.250IT7.260IT7.270

23

YOUR NEEDS VARY CONSTANTLY. T7
ADAPTS CONTINUOUSLY.

MORE PRODUCTIVITY AND POWER

T7 tractors boast New Holland's cutting-edge ECOBlue™ SCR technology for Tier 4A compliance.
This means that the 6.7 litre Nef engine benefits from exceptional breathability for a significant
performance advantage. T7 tractors now offer up to 19hp more power and 139Nm of torque over
the existing T7000 range. With Engine Power Management, up to 51hp extra is available for
optimum productivity.

ABSOLUTE DRIVING PLEASURE

T7 tractors are designed to make operation even easier. The new SideWinder™ II armrest ensures
the tractor is less tiring to use over extended periods. The Horizon™ cab offers exceptionally low
noise levels of just 69dB(A) and brilliant all-round visibility.

LOWER OPERATING COSTS

T7 tractors benefit from Nef engines that use ECOBlue™ SCR emission reduction
technology. Matched with the advanced Auto Command™ transmission, fuel use
is cut by up to 10%. 600 hour engine service intervals continue to set the standard.

MAXIMUM VERSATILITY

The nine-model T7 series has a power and transmission choice for every application.
Combined with their exceptional power to weight ratios of up to 25.8kg/hp(CV), these tractors
offer exceptional versatility. From draft to top work, spraying to transport, a T7 tractor will do it all.

EXACTLY WHAT IT SAYS ON THE BONNET

T7 tractors offer improved performance thanks to the Tier 4A ECOBlue™ SCR advantage, and these productivity
enhancing characteristics are immediately obvious to all users. How? Quite simply, it is on the bonnet. The first two
digits ‘T7’ refer to the tractor’s category and the following three, for example ‘270’, refer to the maximum Engine
Power Management horsepower. What does that mean to you? You can buy your T7 safe in the knowledge that it will
be able to cope with even the most demanding applications. New Holland for ultimate productivity peace of mind.

Engine speed

Max power with EPM [hp(CV)]

T7.170
T7.185
T7.200
T7.210
T7.220
T7.235
T7.250
T7.260
T7.270

171
188
203
212
218
234
250
260
269

Rated power

T7.170
T7.185
T7.200
T7.210
T7.220
T7.235
T7.250
T7.260
T7.270

[hp(CV)]

125
140
155
165
167
185
200
215
228

EPM

Horsepower

EPM according to the load on transmission, PTO and hydraulics.

[hp(CV)]

T7.170
T7.185
T7.200
T7.210
T7.220
T7.235
T7.250
T7.260
T7.270

46
48
48
47
51
49
50
45
41

THE RANGE45

A LARGER FAMILY FOR DEMANDING
PROFESSIONALS.

New Holland T7 tractors can be specified to match your specific business needs.
Spanning rated powers from 125hp to 228hp, the nine model T7 range can be fitted with a choice of
semi-powershift, full-powershift or constantly variable transmission (CVT). All models can be fitted with a
New Holland loader, all tractors have the option of a fully integrated front linkage and PTO.

CLASSIC ARMREST

SIDEWINDER™ II ARMREST

AN ARMREST TO SUIT YOU

Range Command™ and Power Command™ tractors’ can be specified either with a classic
armrest or New Holland’s advanced SideWinder™ II armrest, complete with
CommandGrip™ handle and IntelliView™ III monitor, as an option. SideWinder II is standard
on Auto Command™ tractors and benefits from the advanced force based CommandGrip
for speed and direction control.

OPERATOR ENVIRONMENT67

HORIZON™ CAB MORE SPACE, BETTER VISIBILITY.

AT 69DB(A), T7 CABS ARE THE

QUIETEST IN THE SEGMENT

DESIGNED FOR COMFORT AND PRODUCTIVITY

Step up into a standard T7 Horizon™ cab, and regardless
of its specification, you will find it has been designed to fit
you perfectly. Note how the seat and steering wheel adjust
to suit you. All-round visibility is about as good as it gets.
Noise levels are exceptionally low, helping to reduce fatigue.
Enjoy how the seat, cab and axle suspension cushion the
ride. From air-conditioning to optional full climate control,
the Horizon cab will do its best to keep you comfortable.

FROM DUSK TO DAWN

Cab roof, engine hood and fender
worklights are easily controlled
from a dedicated switch panel.
The operator can set the lights to
match a broad range of applications
for safer, more productive operation.

EASY CAB ACCESS

Manufactured from a single piece
of glass, the one-piece doors on
New Holland T7 tractors open
wide to provide easy cab access.
The doors are easy to open from
inside the cab and, equally
important, can be closed from the
operator’s seat. Small details that
make a big difference.

8 sec 5 sec 8 sec 5 sec

HEADLAND TURN SEQUENCING

Automated features are only of use when the operator feels comfortable setting
them up and using them. New Holland Headland Turn Sequencing has been refined
and developed over several years to match ease of operation with in-field efficiency.
The system allows the operator to record and store the sequence of operations at
the headland. These are then ‘played back’ automatically when HTS is activated.
Simple and a great way to reduce fatigue over extended working periods.

AUTO COMFORT™ SEAT

For operators who spend extended
hours in the tractor, the enhanced
comfort provided by the heated
Auto Comfort™ seat is worth
considering. Fitted with a large air
reservoir to further reduce whole
body vibration, the Auto Comfort
seat delivers an even smoother ride.

SIDEWINDER™ II ARMREST & COMMANDGRIP™ HANDLE89

SIDEWINDER II.
DESIGNED BY FARMERS, FOR FARMERS

As modern tractors offer increasingly sophisticated features there is a risk that they
become more difficult to understand and operate. At New Holland we have made
everything simpler with the SideWinder™ II armrest, designed by farmers, for farmers.
All key controls are accessed from the armrest. Throttle, transmission and hydraulics.
Everything you need to control is quickly and easily accessible. More advanced
features can be quickly accessed. It does not take long to master a T7 tractor.

INTELLIVIEW™ III TOUCHSCREEN.

All the information you need at a
glance. Fingertip adjustment of all key
settings and compatible with the New
Holland IntelliSteer™ guidance system.

As awarded by The Chicago Athenaeum:
Museum of Architecture and Design.

• Headland turn sequencing, HTS.
Press to record, store and activate
automated headland turn.

• Finger tip control for
up to two remote valves.

• Rear linkage raise / lower.

• Optional IntelliSteer™
autoguidance, automated
steering engagement.

• Forward reverse
shuttle switch.

• Change transmission ratio
up and down.

• Engage Auto Field
or Auto Transport mode.

"SideWinder II and CommandGrip make
operating a T7 tractor so simple. Of equal
importance, I can show an operator new to the
tractor how everything operates quickly and
easily. SideWinder II is a real advance in tractor
design and a genuine aid in daily productivity."

EASY ACCESS TO ADVANCED FEATURES

Push the symbol. Activate the feature. The Integrated Control Panel, ICP,
makes it simple to access advanced operating features. No need to
scroll through menus to set up Terralock traction management, HTS
headland turn sequencing, Auto PTO or ESM Engine Speed Managment.

• Select paddle or joystick control
for remote valves 3 and 4.

• Throttle up to your desired engine
speed, select Engine Speed
Management, and the speed is fixed.

• Press the Headland Turn Sequencing
button to record and replay the
functions you use most frequently.

• Engage Terralock and it will
automatically manage four-wheel
drive and differential lock selection.

• Auto PTO will disengage and reengage
the PTO during a headland turn.

• Three point hitch levelling and top link
extension at the touch of a button.

•Multifunction joystick. The joystick can be set
to operate the front linkage, loader or remote valves.

•Electronic remotes. Easy to reach paddles
provide fingertip hydraulic operation.
Flow and timing can be simply adjusted
through the IntelliView™ III touch screen.

•Rear linkage mouse. Lift heavy mounted
implements with absolute precision.

•Personalized positioning of the hydraulic
joystick and rear linkage mouse available
as a factory-fit option.

•Full access to further advanced
controls under the padded armrest.

•Electronic SideWinder™ II
adjustment. Move the armrest
to the position that suits you.

PLM10 11

NEW HOLLAND GUIDANCE SYSTEMS
TO MATCH YOUR FARMING NEEDS

ALL WIRED UP READY FOR YOUR CHOSEN GUIDANCE SYSTEM

Series T7 tractors can be specified with a fully integrated New Holland designed and developed
IntelliSteer™ Automatic Steering System. Matching DGPS or RTK Technology to fully integrated
control, IntelliSteer helps ensure parallel pass to pass accuracy of up to 1 - 2cm*. IntelliSteer
is ideal for precision work in even the most demanding situations. It is designed to dramatically
improve operator performance and comfort. All this and more at the touch of a button.

* Using RTK correction signal.

FULLY INTEGRATED INTELLISTEER™ GUIDANCE

Guidance system choice will relate to the intended applications and the need to
integrate with existing systems. With T7 series tractors, all IntelliSteer options operate
via factory installed systems that facilitate installation and upgrades. This enables the
selected package to be modified and upgraded simply and more economically.

INTELLIVIEW - VISIBLE INTELLIGENCE

The IntelliView™ Plus II and IntelliView™ III monitors can be used to set
up the optional New Holland auto guidance systems, and includes a
visual interface that can be employed when operating the IntelliSteer™
system. The IntelliView™ III monitor has a touchscreen display which
allows the programming of a variety of guidance paths, from straight
A-B runs to the most complex adaptive curves. You can also
personalize your settings simply and easily and even transfer
information from your tractor, direct to your Precision Farming software.

INTEGRATED CONTROL SYSTEMS

The New Holland IntelliSteer™ System uses
built in T3 terrain compensated correction
signals (roll, pitch, yaw) to keep the Navigation
Controller II informed of the tractor's
orientation. Also integrated into the hydraulic
system is a control valve which converts the
signals from the Navigation Controller II into
hydraulic movements of the steering system.

3456

012

15 20 25 30

5678910

IMPROVED PROFIT

GOOD GUIDANCE SAVES MONEY

IntelliSteer helps improve overall
operating efficiency. In poor light
or during long working days,
precision driving is not compromised.
Improved efficiency saves money.
It is as simple as that.

LEVELS OF ACCURACY AND REPEATABILITY

New Holland offer four levels of accuracy. This enables you to select the right
IntelliSteer™ system to match your needs and budget. When using RTK correction
with IntelliSteer you can enjoy guaranteed year on year repeatability.

auto guidance

Total Cost Savings with

0

AUTONOMOUS

HP/XP RTK

Autonomous

30 cm 7 cm 5 cm 2.5 cm

OmniSTAR® XP OmniSTAR® HP

RTK GPS

INTELLISTEER.
ON AND OFF SIMPLICITY

The CommandGrip™ handle
incorporates a single button that is
used to activate the IntelliSteer system.
New Holland makes advanced
technology accessible.

NH 262 RECEIVER

The NH 262 receiver is capable of
working with Autonomous,
OmniSTAR or RTK correction. For
RTK applications a slim profile
radio mounts underneath the
receiver.

RTK BASE STATION

An RTK base station can
be used to broadcasts a
correction signal to
achieve a pass to pass
accuracy of 1-2cm.

ENGINE12 13

ULTIMATE ENGINE BREATHABILITY

T7 tractors are powered by the very
latest generation of Nef engines.
Now with proven ECOBlue™ SCR
technology, to meet the stringent
Tier 4A emissions standards. This
uses AdBlue® to transform the
harmful nitrogen oxides contained
in the exhaust gas into harmless
water and nitrogen. This
aftertreament system is separate
from the main engine which means
only clean, fresh air is fed into the
engine. What does this mean?
Clean running power units with
improved performance and
enhanced fuel efficiency.

Dosing Module

Supply module

AdBlue/DEF additive

AdBlue/DEF tank

300

250

200

150

100

Power output (hp)

50

0

T7.170

EPM
Rated power

T7.200

T7.185

T7.210

T7.220

T7.235

T7.250

T7.260

T7.270

ECOBLUE™ SCR:YOUR POWER GUARANTEE

ECOBlue™ SCR guarantees exceptional
performance and high productivity, independent of
fuel quality, sulphur levels and without the need for
costly diesel additives. With rated powers that span
125hp to 228hp, all T7 models generate extra power
of between 171hp to 269hp with EPM.

Exhaust gas containing NOx

Nitrogen and Water

Fuel consumption (%)

EXCEPTIONAL FUEL ECONOMY:

The existing Tier 3 Nef engine series has
established itself as the benchmark for
fuel economy. The new Tier 4A Nef power
units in T7 tractors go one stage further,
with fuel use cut by up to 10% when
compared to existing T7000 models.

T7000

Tier 3

10% FUEL SAVING

T7

Tier 4A

SCR Catalyst

ENGINE SPEED MANAGEMENT

In applications where a constant PTO speed
is required, the operator can select Engine
Speed Management. This will ensure this
selected speed is accurately maintained
under changing loads. In many applications,
this will enable a fixed forward speed to be
maintained in difficult terrain.

Engine speed

51hp

EPM according to the load on the
transmission, PTO and hydraulics.

Horsepower

ENGINE POWER MANAGEMENT

Engine Power Management is an renowned
New Holland tractor feature. In short, the
engine develops more power and torque
according to the load on the transmission,
hydraulics and PTO. On a T7.220 tractor,
EPM will deliver up to 51hp extra, but only
when it is needed, to maintain performance.

POWERTRAIN TECHNOLOGIES

POWERED BY FPT INDUSTRIAL

New Holland are not going it alone when it comes to Tier 4A technology,
they can draw on the experience of their engine development partner:
FPT Industrial.

Pioneers: Fiat invented Common Rail technology in the 1980s and
brought it to the masses in 1997 on the Alfa Romeo 156. They were
the very first to introduce it on agricultural machines. Pioneering. Always.

2

Cleaner: Fiat S.p.A. have the lowest overall CO
automotive manufacturer in Europe. Cleaner. Everywhere.

Proven: FPT Industrial have already produced over 150,000 SCR
engines during the last five years for the haulage industry. Reliability.
Confirmed.
After all, only those who invented it can reinvent it.

emissions of any

RANGE COMMAND™ AND POWER COMMAND™ TRANSMISSION14 15

PUSH BUTTON SIMPLICITY.
YEARS OF PROVEN TECHNOLOGY

Range Command is a simple, rugged and well proven transmission.
It provides clutch-free gear changes within each working range.
It is the ideal choice for general farm applications. Power Command
is a full-powershift transmission: you select the gear speed
you want by simply pushing up or downshift buttons.
Only New Holland offers such a simple transmission choice.

Range Command™ Transmission* Power Command™ transmission*

Reverse ForwardReverse Forward

(1725rpm)

19

42

18

40,7

17

33,8

16

12,4

10,3

8,8

7,3

6,1

5,1

28,8

15

23,9

14

19,9

13

16,6

12

14,3

11

11,9

10

10,2

9

8,4

8

7

7

5,8

6

6,2

5

5,1

4

4,4

3

3,6

2

3

1

2,5

C

B

A

12,9

10,8

9,2

7,6

6,3

5,3

0 1010 2020 30 40 50

kph

*T7.200 19x6 40kph ECO model shown with 650/65R42 tyres fitted

(1725rpm)

19

42

18

40,7

17

33,8

16

28,8

15

23,9

14

19,9

13

16,6

12

14,1

11

11,7

10

10

9

8,3

8

6,9

7

5,7

6

4,9

5

4

4

3,4

3

2,9

2

2,4

1

2,0

0 1010 2020 30 40 50

kph

SEMI-POWERSHIFT UP TO T7.210.
FULL POWERSHIFT
FROM T7.170 TO T7.260

Range Command and Power
Command are based around the
same gear offering. You can choose
between a standard 40kph 18x6
or 28x12 creep speed transmission
or opt for an extra high ratio 19x6
or 29x6 'direct drive' alternative.
This can deliver either 40kph at a
reduced engine speed for economy
or a high 50kph transport speed.

A SMOOTHER SHIFT IN FIELD AND TRANSPORT

IntelliShift™ gear change management ensures T7
tractors deliver a seamless powershift between each
and every ratio. Programmed to scrutinise transmission
load, speed and transmission oil temperature,
IntelliShift delivers smooth changes all day long.

AUTOMATED SHIFT POINT

ENGINE POWER CURVE

OPTIMUM ENGINE SPEED

HIGH TOLERANCE

GEAR CHANGE ENGINE SPEED

LOW TOLERANCE

WORK TOGETHER:
AUTOMATION, COMFORT AND PRODUCTIVITY

Easy to set up and brilliantly effective, Auto Transport and Auto
Field modes can really reduce the effort required to work a T7
tractor over a long working day. With Auto Transport, the tractor
will seamlessly shift ratios like an automatic car.
It will even sense if the tractor is being pushed by a loaded
trailer while descending a hill. If it does, it holds the current
gear to provide engine braking. Auto Field manages both the
engine speed and transmission to optimise performance and
economy. In PTO applications, where a constant engine speed
is the priority, the system will select the transmission ratio to
match the load on the engine. In draft applications, Auto Field
will allow the engine speed to drop to fully exploit the available
torque rise before selecting a lower ratio under load.

EASY SHUTTLE

The clutchless forward reverse shuttle, operated via
the steering column or the CommandGrip™ handle
fitted to the optional SideWinder™ II armrest, can be
programmed to automatically manage transmission
shifts during a direction change. As a further option,
an electronic park brake can be specified. This is
operated via the shuttle lever, securing the tractor
when neutral is selected.

AUTO COMMAND™ TRANSMISSION16 17

INNOVATIVE AUTO COMMAND™ TRANSMISSION
OFFERS ADVANCED NEW HOLLAND FEATURES

Designed and built by New Holland, the T7 Auto Command is available from the T7.170 to the T7.270.
This new generation of CVT transmissions benefits from multi direct drive points offering 100% mechanical
efficiency, plus advanced double clutch control. It is the smoothest and most productive CVT available.

Speed diagram

1

2

3

UP TO 10% ENGINE

SPEED REDUCTION
FOR GREATER FUEL

ECONOMY*

1700

1600

1650

1700

forward

0 5 10 15 20 25 30 35 40 45 50

kph

A SPEED FOR EVERY NEED

Auto Command allows the operator to set a target
speed of between 20m/hr right through to 50km/hr.
No steps. No range changes. Just seamless speed
to match your every need.

1500

1400

Engine speed at 50 kph (rpm)

1300

1550

* only T7.220 - T.270 models

New T7 Competitor A Competitor B

MAKING THE MOST OF AVAILABLE TORQUE

New Holland has developed its Auto Command™
transmissions so they can exploit the low running
speed, high torque New Holland engines. With 50kph
ECO, the engine can run at a fuel efficient 1550 rpm.

• Force based movement enables the operator to change
speed and direction. On the ICP there is a switch to alter
the response of the speed change.

• Target speed adjustment – set a target speed to match
your exact needs. Perfect when moving between fields
or when crop yields have altered.

• Target speed selection – allows you
to change between three target speeds

• 4 DRIVING MODES TO SUIT YOUR DRIVING STYLE

- Auto Mode. Select the desired target

speed and Auto Command will match
the engine and transmission to maintain it.

- Cruise Mode. Once a desired operating

speed has been achieved, Cruise Mode
allows the operator to set the transmission to
maintain the speed for economy and productivity.

- Manual Mode. Allows the operator to set

the required engine and forward speed.

- PTO mode. As soon as the PTO is engaged,

Auto Command will operate to guarantee
a constant engine speed.

ABOUT AUTO COMMAND TRANSMISSION

"Auto Command makes operating at higher
transport speeds considerably safer. The hill
hold function is excellent, making it less stressful
when pulling onto a road from a steep side road
with a heavily laden trailer safer. Excellent fuel
savings too.”

ACTIVE STOPSTART

A key safety feature of Auto Command is Active StopStart.
When the tractor is brought to a standstill, the transmission
prevents the tractor moving backwards or forwards.
Even with a heavy load. When the transmission takes
up drive there is no risk of roll back on steep inclines.
For safe parking, an electronic brake is easily engaged
via the shuttle lever.

AXLES & TRACTION18 19

FASTER TURNS. BETTER TRACTION.
GREATER PERFORMANCE

Axle strength and weight increase with engine power. This ensures a good power
to weight ratio is offered by all models, not just those with highest rated output.
T7.170 to T7.210 models have a gross vehicle weight of up to 11,000kg at 50kph,
this increases to 13,000 kg on the T7.220 and above.

SUPERSTEER +

FAST STEER =

FASTER TURNS

LESS TIME TURNING BOOSTS YOUR OUTPUT

New Holland leads the field in reducing the time it takes to turn on the headland.
Offering a tight 65 degree turn angle, the SuperSteer™ front axle option delivers
rowcrop agility, beating any tractor in the T7's category. The Fast Steer™ system,
compatible with all axle types, means full lock to lock turns are made even more
quickly and with minimal effort. You simply hold down the FastSteer steering rim
and the steering wheel is transformed into a proportional “joystick”.

More

Productivity

ADVANCED TRACTION MANAGEMENT

The New Holland Terralock™ system is well established.
The operator simply selects the traction package needed
for a specific application. Terralock will then manage drive
to the front axle and engage and release the differential
locks automatically. During a headland turn or moving from
work to transport, Terralock will ensure the differentials and
four wheel drive are unlocked without operator intervention.

BRAKE OPTIONS

All models are available with front axle brakes
and a choice of hydraulic or pneumatic trailer
braking systems. On SideWinder™ II models,
an engine exhaust brake is optional. This can
be used to help hold the tractor's speed on a
gradual gradient.

vibration at seat base

TERRAGLIDE™ FRONT AXLE AND COMFORT RIDE™ CAB SUSPENSION.

YOUR COMFORT PARTNERS.

Automatic two stage Comfort Ride™ cab suspension has established itself as a key advance
in operator comfort. Designed to complement the cushioned ride offered by the standard
air suspension seat, Comfort Ride helps reduce fatigue. Terraglide™ front axle suspension
is recommended in operations that include fast top work and extended transport duties.
Terraglide, with integral hub braking, is standard on tractors specified with a 50kph transmission.

PTO AND FRONT / REAR LINKAGE20 21

FEATURES TO BOOST YOUR PRODUCTIVITY

MAKING IT EASIER TO WORK
WITH FRONT MOUNTED IMPLEMENTS

New Holland T7 tractors are designed to
incorporate a fully integrated, factory fitted
front linkage and PTO. All controls are fully
integrated into the armrest and can be
programmed to operate with HTS. The linkage
arms fold up when not in use or can be used
to carry the full standard weight pack.

STRONG, EFFICIENT AND POWERFUL

The maximum lift capacity on T7.170 to T7.210
tractors is 8,275kg, climbing to a massive 10,463kg
on the T7.220 and above. The rear linkage and
hydraulics are designed to work with heavy mounted
equipment over extended periods. The system also
incorporates integral dynamic ride control shock
load protection. This will reduce bounce when
travelling with a heavy linkage load at transport
speeds. Fender mounted controls for the rear
linkage, a rear remote and the PTO are available.

AUTO PTO OPERATION

Auto PTO can be selected to
automatically disengage the PTO
as the rear linkage is raised above
a pre-set position. This protects the
PTO shaft and tractor. The system
will also reengage drive as the
linkage is lowered.

DIRECT DRIVE FOR FUEL EFFICIENCY

All T7 tractors are fitted with a direct drive PTO to minimise power loss
between engine and implement. The PTO is engaged via a push-pull
control, with advanced Soft Start management. This modulates
engagement of high intertia attachments to protect the driveline.
Speed selection is via mechanical levers; SideWinder II T7.220 and
above feature electronic speed selection. Four speeds: 540, 540E,
1000 and 1000E are available.

22 23

HYDRAULICS AND FRONT LOADERS

HYDRAULIC POWER TO MEET YOUR DEMANDS

CLOSED CENTRE LOAD SENSING HYDRAULICS

Hydraulic efficiency makes an important contribution to the overall performance of the tractor. T7.170
to T7.210 models are fitted with a 113 or 125 litres per minute hydraulic pump, this increases to 120
or 150 litres per minute on the T7.220 and above. T7 Auto Command models benefit from a priority valve
which guarantees optimum steering response in demanding hydraulic applications. For T7 Range Command
and Power Command models, a separate 65 litres per minute pump takes care of the steering. Full hydraulic
power is always available at the remote valves and lift linkage, but only as much as is needed. The variable
displacement pump only works on demand, which reduces fuel consumption.

CLASSIC ARMREST

SIDEWINDER™ II ARMREST

ELECTRONIC OR MECHANICAL - YOU DECIDE

The Classic armrest incorporates mechanical controls for the remote valves.
SiderWinder™ II armrest models have electronic controls, with two controls on
the CommandGrip™ handle for ease of use. A hydraulic control joystick can be
specified. This can be set to operate front or rear valves.

MAXIMUM
VISIBILITY

PURPOSE DESIGNED FOR PRODUCTIVITY

Purpose designed New Holland front loaders are available to fit T7.170 to T7.210 tractors.
From the operator’s seat, visibility remains excellent when the loader is both at ground level
and, thanks to the standard high visibility roof panel, when raised progressively to its full lift
height. This is an important design advantage of both the tractor and loader and a key to
ensuring the combination can deliver full productivity.

ADJUST THE FLOW ON UP TO NINE REMOTES

The electronic remote valves fitted on SideWinder™ II tractors each have individual
flow control. Hydraulic flow and timing to each valve can be individually adjusted
using simple ‘pop-up’ menus on the IntelliView™ III touch-screen.

All T7 models fitted with the classic armrest boast up to four deluxe mechanical rear
remote valves, whereas models equipped with the SideWinder™ II armrest benefit
from as many as five electro-hydraulic rear remotes. All models in the T7.170 to
T7.210 range offer three mid-mount valves, which is upped to four for the T7.220
to T7.270 models.

SERVICE AND BEYOND THE PRODUCT24 25

360°: T7

The new T7 range has been designed to spend more time
working and less time in the yard. All service points are easy
to access, and super long service intervals mean they will
spend more time in their natural environment: the field!

• Single piece engine
hood opens wide for
full service access.

• The engine air filter is easy
to check, clean or replace,
with no need for tools.

• Top up the screen
wash bottle through
the rear window.

• Hydraulic oil levels
can be viewed via
sight glass at the
rear of the tractor.

• Cooling package opens
out to make cleaning
faster and easier.

WILL I BE ABLE
TO FIND ADBLUE® EASILY?

The answer is yes! It will be available on
your doorstep, through CNH Parts &
Service; just contact your local dealer for
more information. If that wasn’t enough,
AdBlue can even be delivered direct to
your farm for absolute convenience.

• The 48 litre AdBlue® tank's filler neck is
narrower than that of the standard fuel
tank, which prevents inadvertent filling
with fuel. It only needs to be filled once
every two refills of the fuel tank.

• Engine oil check and fill points are

easy to reach, with no need to lift
the hood. This makes routine checks
faster and servicing simpler. You will
also still be able to enjoy the long
600 hour service intervals that you’ve
come to expect of New Holland.

FINANCE TAILORED
TO YOUR BUSINESS

CNH Capital, the financial services
company of New Holland, is well
established and respected within the
agricultural sector. Advice and finance
packages tailored to your specific
needs are available. With CNH Capital,
you have the peace of mind that
comes from dealing with a financing
company that specialises in agriculture

TRAINED TO GIVE YOU
THE BEST SUPPORT

Your dedicated New Holland dealer
technicians receive regular training
updates. These are carried out both
through on-line courses as well as
intensive classroom sessions. This
advanced approach ensures your
dealer will always have the skills
needed to look after the latest and
most advanced New Holland products.

DEALER INSTALLED
ACCESSORIES

A comprehensive range of
approved accessories to
optimise machine performance
in all conditions can be supplied
and fitted by your dealer.

WWW.NEWHOLLANDSTYLE.COM

Want to make New Holland
a part of your everyday life?
Browse the comprehensive selection
on www.newhollandstyle.com.
A whole range of items are available

NATURAL LEADER

including hard wearing work clothing
and a vast selection of scale models,
together with so much more.
New Holland. As individual as you.

SPECIFICATIONS26 27

MODELS

Armrest type

New Holland engine* Nef Nef Nef Nef Nef Nef Nef Nef Nef

No. of cylinders / Aspiration / Valves / Emission level 6/ T / 4 / Tier 4A 6/ T / 4 / Tier 4A 6/ T / 4 / Tier 4A 6/ T / 4 / Tier 4A 6/ T / 4 / Tier 4A 6/ T / 4 / Tier 4A 6/ T / 4 / Tier 4A 6/ T / 4 / Tier 4A 6/ WT / 4 / Tier 4A
ECOBlue™ SCR system (Selective Catalytic Reduction) ●
Fuel system - High pressure Common Rail ●
Approved biodiesel blend** B20 B20 B20 B20 B20 B20 B20 B20 B20
Capacity (cm3) 6728 6728 6728 6728 6728 6728 6728 6728 6728
Bore and Stroke (mm) 104x132 104x132 104x132 104x132 104x132 104x132 104x132 104x132 104x132
Max. EPM horsepower - ISO TR14396- ECE R120 [kW / hp(CV)] 126 / 171 138 / 188 149 / 203 156 / 212 160 / 218 172 / 234 184 / 250 191 / 260 198 / 269
Max. horsepower - ISO TR14396- ECE R120 [kW / hp(CV)] 106 / 144 117 / 159 126 / 171 133 / 181 138 / 188 149 / 203 160 / 218 172 / 234 183 / 249
Rated EPM horsepower - ISO TR14396- ECE R120 [kW / hp(CV)] 118 / 160 129 / 175 140 / 190 147 / 200 151 / 205 162 / 220 173 / 235 181 / 246 192 / 261
Rated horsepower - ISO TR14396- ECE R120 [kW / hp(CV)] 92 / 125 103 / 140 114 / 155 121 / 165 123 / 167 136 / 185 147 / 200 158 / 215 168 / 228
Rated engine speed (rpm) 2200 2200 2200 2200 2200 2200 2200 2200 2200
Max. EPM torque - ISO TR14396 (Nm) 741@1500 810@1500 866@1500 912@1500 960@1500 1019@1500 1082@500 1120@1500 1160@1500
Max. torque ISO TR14396 (Nm) 612@1500 679@1500 740@1500 766@1500 825@1500 862@1500 927@1500 995@1500 1089@1500
Torque rise Standard / EPM (%) 53 / 45 52 / 45 49 / 42 45 / 43 54 / 47 46 / 45 45 / 44 45 / 43 50 / 39
Viscous coupled cooling fan ●
Reversible fan ○ O ○OO○O ○OOO○OO
Exhaust brake ○ O ○OO○O ○OOO○OO
Diesel tank capacity (Litres) 330 330 330 330 395 395 395 395 395
DEF/AdBlue® tank capacity (Litres) 48 48 48 48 48 48 48 48 48
Service interval (hours) 600 600 600 600 600 600 600 600 600
Range Command™ transmission (if equipped)
IntelliShift™ system
Armrest type
Auto transmission functions
Range Command™ Semi-Powershift (40 kph) OOO
Number of gears / with Creeper (F x R) 18 x 6 / 28 x 12 18 x 6 / 28 x 12 18 x 6 / 28 x 12
Min. speed / Min. speed with Creeper (kph) 2.4 / 0.40 2.4 / 0.40 2.2 / 0.37
Range Command™ Semi-Powershift (40kph ECO or 50 kph) OOOO
Number of gears / with Creeper (F x R) 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19x6 / 29x12***
Min. speed / Min. speed with Creeper (kph) 2.4 / 0.40 2.4 / 0.40 2.2 / 0.37 2.0 / 0.34
Power Command™ transmission (if equipped)
IntelliShift™ system
Armrest type ○
Auto transmission functions ●
Power Command™ Full-Powershift (40 kph) O ○OO○O ○OOO○O
Number of gears / with Creeper (F x R) 18 x 6 / 28 x 12 18 x 6 / 28 x 12 18 x 6 / 28 x 12 18 x 6 / 28 x 12 18 x 6 / 28 x 12 18 x 6 / 28 x 12 18 x 6 / 28 x 12 18 x 6 / 28 x 12
Min. speed / Min. speed with Creeper (kph) 1.9 / 0.31 1.9 / 0.31 1.8 / 0.29 1.8 / 0.29 1.98/ 0.33 1.98/ 0.33 1.98/ 0.33 1.98/ 0.33
Power Command™ Full Powershift (40kph ECO or 50 kph) O ○OO○O ○OOO○O
Number of gears / with Creeper (F x R) 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19 x 6 / 29 x 12 19 x 6 / 29 x 12
Min. speed / Min. speed with Creeper (kph) 1.9 / 0.31 1.9 / 0.31 1.8 / 0.29 1.8 / 0.29 1.98/ 0.33 1.98/ 0.34 1.98/ 0.35 1.98/ 0.36
Auto Command™ transmission (if equipped)
Armrest type●●●
Active StopStart function ●
Force base propulsion control
Auto Command™ Constantly Variable Transmission (40kph or 40 kph ECO)○
Min. speed / Max. speed (kph)

Auto Command™ Constantly Variable Transmission (50 kph ECO)
Min. speed / Max. speed (kph)

Electrical

12 volt alternator (Amps) 150 150 150 150 150 150 150 150 150
Battery capacity (CCA / Ah) 960/132 960/132 960/132 960/132 1300 /176 1300 /176 1300 /176 1300 /176 1300 /176

Axles

4WD front axle ●
Terraglide™ front axle suspension○ O ○OO○O ○OOO○O○ O
Supersteer™ front axle ○O ○OO○O ○OOO○O○ O
Steering angle Standard / Terraglide™ / SuperSteer™ axle (°) 55 / 55 / 65 55 / 55 / 65 55 / 55 / 65 55 / 55 / 65 55 / 55 / 65 55 / 55 / 65 55 / 55 / 65 55 / 55 / 65 55 / 55 / 65
Fast Steer™ system O ○OO○O ○OOO○O○ O○
Terralock™ functions●●
Dynamic front fenders O ○OO○O ○OOO○O○ O○
Bar rear axle○ O ○OO○O ○OOO○O○ O
Turning radius with SuperSteer™ front axle (mm) 4950 4950 4950 4950 5705 5705 5705 5705 5705
Turning radius with Standard / Terraglide™ suspension front axle (mm) 5450 5450 5450 5450 6100 6100 6100 6100 6100

Hydraulics

Closed Centre Load Sensing (CCLS)
Main pump flow Standard / MegaFlow™ option**** (Lpm) 113 / 125***** 113 / 125***** 113 / 125***** 113 / 125***** 120 / 150 120 / 150 120 / 150 120 / 150 120 / 150
Electronic Draft Control (EDC)●●

Remote valves

Type

STD. no. rear valves / Max. no. rear valves 2 / 4 3 / 5 2 / 4 3 / 5 2 / 4 3 / 5 2 / 4 3 / 5 4 / 5 4 / 5 4 / 5 4 / 5 4 / 5
Joystick control ○OG○ O
Max. no. mid mount valves - Optional 333344444

Linkage

Max. lift capacity at ball ends (kg) 8257 8257 8257 8257 10463 10463 10463 10463 10463
Max. lift capacity through the range (610 mm behind ball ends) (kg) 6616 6616 6616 6616 9266 9266 9266 9266 9266
Front linkage lift capacity at ball ends (through the range) (kg) 3568 3568 3568 3568 3785 3785 3785 3785 3785

PTO

Auto Soft Start ●

T7.170 T7.185 T7.200 T7.210 T7.220 T7.235 T7.250 T7.260 T7.270

Classic

GG●GGG●G

G

GG●GGG●G

GG●GG–––––

G

GG●GG–––––

GG●GG–––––

G

G

Classic

SideWinder II

●

GG●GGG●G

O

G

O

G

●

G

SideWinder II

O

O

Classic

G

G

●

G

– G – G – G – GGGGGG
– G – G – G – GGGGGG
– G – G – G – GGGGGG
–

○O

–

○O

–

0.02/40@

–

1550rpm 1550rpm 1550rpm 1550rpm

–

○O

–

GG●GGGG●GG●G

GG●GGGG●GG●G

GG●GGGG●GG●G

GG●GGGG●GG●G

Deluxe Electro Deluxe Electro Deluxe Electro Deluxe Electro Electro hydraulic Electro hydraulic Electro hydraulic Electro hydraulic Electro hydraulic

GG●GGGG●GG●G

–

0.02/50@

–

1700rpm 1700rpm 1700rpm 1700rpm

hydraulic hydraulic hydraulic hydraulic

0.02/40@

○O

0.02/50@

G

–
–

0.02/40@

–
–

0.02/50@

○OG○ O

Classic

SideWinder II

SideWinder II

O

G

SideWinder II

O

–––––

SideWinder II

●

●

SideWinder II

GG●G

●

GG●G

SideWinder II

G

●

––––––
––––––
––––––

–––––
–––––
–––––

O

G

O

●

G

○O

–

○O ○OOO○O ○O

–

0.02/40@ 0.3 / 40@1450rpm 0.3 / 40@1450rpm 0.3 / 40@1450rpm 0.3 / 40@1450rpm 0.3 / 40@1450rpm

○O

–

○O ○OOO○O ○O○

–

0.02/50@ 0.3 / 50@1550rpm 0.3 / 50@1550rpm 0.3 / 50@1550rpm 0.3 / 50@1550rpm 0.3 / 50@1550rpm

GGGGGG

GG●GG–

●

GG●GG–

SideWinder II

●

G

●

●●

–
–
–
–
–
–

●

●

●

●

●

●

●

G Standard

O

Optional – Not available * Developed by FPT Industrial ** Biodiesel blend must fully comply with the latest fuel specification EN14214:2009 and operation is in accordance with operator
manual guidelines *** Only 40kph ECO @ 1890 on 580/70R42 tyres **** Engine speed for Range & Power Command @ 2200rpm and Auto Command @ 1800rpm ***** MegaFlow™ option only
available on Auto Command versions

MODELS

T7.170 T7.185 T7.200 T7.210 T7.220 T7.235 T7.250 T7.260 T7.270

Classic

Engine speed at:
540 / 1000 (rpm) 1969 / 1924 1969 / 1924 1969 / 1924 1969 / 1924 1893 / 1950 1893 / 1950 1893 / 1950 1893 / 1950 1893 / 1950
540E / 1000 (rpm)
540 / 540E / 1000 (rpm) 1969/1546/1893 1969/1546/1893 1969/1546/1893 1969/1546/1893
540E / 1000 / 1000E (rpm) 1592/1893/1621 1592/1893/1621 1592/1893/1621 1592/1893/1621
540 / 540E / 1000 / 1000E (rpm)

Electronic PTO selection
Auto PTO management ●
Front PTO (1000rpm)○○OO○OO○OO○OOO

Brakes

Exhaust brake○○OO○OO○OO○OOO○
Range and Power Command electronic park brake ○○OO○OO○OO○OO–○
Auto Command electronic park brake
Hydraulic trailer brakes OO○OO●
Optional pneumatic trailer braking system ○OO○OO○OO○OOO○

Cab

Four pillar 360° Horizon™ cab with FOPS - OECD code 10 level 1 ●
Horizon™ cab category level - EN 15695 222222222
High visibility roof hatch ●
High visibility RHS door●●
Opening RHS door ○
Heated front and rear windscreen ○ OO○OO○OO○OOO○
HID lighting pack○○OO○OO○OO○OOO○
Deluxe air suspension seat with seat belt○ OO○OO○OO○OOO○
Auto Comfort™ seat with seat belt○ OO○OO○OO○OOO○
Auto Comfort™ heated seat with seat belt ●
Auto Comfort™ heated leather seat with seat belt ○
Instructors seat with seat belt
SideWinder™ II armrest
CommandGrip™ handle
Electronic adjustment of SideWinder™ II armrest
Air conditioning
Automatic climate control ○OO○OO○OO○OOO○
Air recirculation filters ●
MP3 radio O○ OOO○ OOO○ OO
MP3 Bluetooth radio (hands free phone calls) O○ OOO○ OOO○ OO
Telescopic shatterproof mirrors ●●
Comfort Ride™ cab suspension ●●
Headland Turn Sequence (HTS) ●
Fender mounted external PTO & linkage controls ●●
Fender mounted external remote valve control
Performance Monitor with enhanced key pad O
IntelliView™ III colour monitor with O
ISO 11783 connector, Std on Sidewinder version ● ●●●●
IntelliView™ Large Plus colour monitor with
ISO 11783 connector, for window mount ○○○
Up to 3 viewing cameras (IntelliView™ III monitor only)○○O○ OOO○ OOO○ OO○○
IntelliSteer™ guidance ready●●O
Range and Power Command optimum cab noise level - 77/311EEC (dB(A) 70 70 70 70 70 70 70 70 70
Auto Command optimum cab noise level - 77/311EEC (dB(A) 69 69 69 69 69 69 69 69 69
Optimum seat vibration level - EN 1032 (m/s²) 0.91 0.91 0.91 0.91 0.91 0.91 0.91 0.91 0.91
Factory fit rotating beacon ●

Weights

Minimum unballasted / shipping weights
Standard front axle (Range & Power Command / Auto Command) (kg) 5750 / 5800 5750 / 5800 5950 / 6000 5950 / 6000 6950 6950 6950 6950 6950
Terraglide™ suspended front axle 6050 / 6100 6050 / 6100 6250 / 6300 6250 / 6300 7300 7300 7300 7300 7300
(Range & Power Command / Auto Command) (kg)
SuperSteer™ front axle (Range & Power Command / Auto Command) (kg) 6030 / 6080 6030 / 6080 6230 / 6280 6230 / 6280 7100 7100 7100 7100 7100
Max. permissible weight at 50kph (Class 3) (kg) 10000 10000 10000 10000
Max. permissible weight at 50kph (Class 4) 10500 / 11000 10500 / 11000 10500 / 11500 10500 / 11500 13000 13000 13000 13000 13000
(Range & Power Command / Auto Command) (kg)

––––

––––

––––GGGGG

GGGGGGGGG

–

GGGGGGGGG

GGGGGGGGG

–

GGGGGGGG

GGGGGGGGG

–

GGGGGGGGG

–
–
–

GGGGGGGGG

GGGGGGGGG

GGGGGGGGG

GGGGGGGGG

GGGGGGGGG

GGGGGGGGG

–

O○ OOO○ OOO○ OO

GGGGGGGGG

Classic

SideWinder II

●

G –●G

●

G –●G

○

––○–

●

G –●G

●

G –●G

●

G –●G

●O

–

G

O

G

O

G

O

SideWinder II

●

–

●

–

●

–

●

–

●

–

●O

–

G

●O

G

●O

G

●O

Classic

●

G –●G

●

G –●G

●

G –●G

●

G –●G

●

G –●G

●O

G

G

G

Classic

SideWinder II

–

O
O

O

SideWinder II

SideWinder II

1569 / 1893 1569 / 1893 1569 / 1893 1569 / 1893 1569 / 1893

SideWinder II

SideWinder II

SideWinder II

SideWinder II

–––––
–––––

1931 / 1598 / 1931 / 1598 / 1931 / 1598 / 1931 / 1598 / 1931 / 1598 /

1912 / 1583 1912 / 1583 1912 / 1583 1912 / 1583 1912 / 1583

●

●

GGGGG

GGGGG

●

●

GGGGG

OO○ OOO

●

GGGGG

●

GGGGG

●

GGGGG

●OOOOOO

GGGGGG

GGGGGG

GGGGGG

○O○

●

●

●●

●

●

–––––

C

D

G

F
B

DIMENSIONS

With rear tyre size****** 520/70R38 650/65R38 650/65R42 650/65R38 650/60R42 710/60R42
A Overall length inc. weight pack and rear linkage (mm) 5347 5347 5347 5773 5773 5773
B Min. width (mm) 2446 2446 2446 2470 2470 2470
C Height at centre of rear axle to top of cab (mm) 2215 2215 2215 2140 2140 2140
D Overall height (mm) 3040 3090 3140 3065 3115 3165
E Wheelbase

Standard axle (mm) 2734 2734 2734 2884 2884 2884
Terraglide™ suspended axle (mm) 2789 2789 2789 2884 2884 2884
SuperSteer™ axle (mm) 2880 2880 2880 2977 2977 2977

F Track width (min. / max.) (mm) 1630/2234 1734/2234 1734/2234 1806/2236 1806/2236 1806/2236
G Ground clearance (depends on hitch or tow hook) (mm) 515 540 565 423 473 523

****** Rear tyres other than those mentioned are available: T7.170 - T7.210, 520/70R38, 600/65R38, 650/60R38, 580/70R38, 650/65R38, 710/60R38, 18.4R38, 20.8R38, 18.4R42. For T7.200 and T7.210 models 20.8R42, 650/65R42
and 580/70R42 are also available. T7.220 - T7.270, 520/85R38, 580/70R38, 650/75R38, 710/70R38, 460/85R42, 580/85R42, 580/70R42, 620/70R42.

E
A

F
B

T7.170 - T7.210 T7.220 - T7.270

G

E
A

C

D

NEW HOLLAND.
A REAL SPECIALIST IN YOUR
AGRICULTURAL BUSINESS.

AT YOUR OWN DEALER

YOUR SUCCESS - OUR SPECIALTY

Visit our web site at: www.newholland.com - tel: [phone]
31-53 Kurrajong Road, St Marys NSW 2760

The data indicated in this folder is approximate. The models described here can be subjected to modifications without any notice by the manufacturer.
The drawings and photos may refer to equipment that is either optional or intended for other countries. Please apply to our Sales Network for any further
information. Published by New Holland Brand Communications. Bts Adv. - Printed in Australia - 11NHT7 05/11

Safety begins with a thorough understanding of the

equipment. Always make sure you and your operators

read the Operator’s Manual before using the

equipment. Pay close attention to all safety and

operating decals and never operate machinery

without all shields, protective devices and

structures in place.
