ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Put Your PoE Ports Exactly Where You Need Them

The NETGEAR ProSAFE® GS408EPP Easy-Mount 8-port Gigabit Ethernet
PoE+ Web Managed Switch features a unique Virtually Anywhere™
mounting system that allows to install more PoE+ ports exactly where you
need them. The unique mounting system allows you to put the Easy-Mount
Switch up in the ceiling, strapped to a pole, or mounted under a desk or
tabletop, making it the perfect switch for deploying Wireless APs, Pan/Tilt/
Zoom and fixed IP Cameras, VoIP Phones, access-limited security door locks
or any other IoT PoE-powered devices.

Should you decide to rack mount the GS408EPP switch, you can save
space by installing two (2) switches in just a single 1U slot as all connections
(power and Ethernet) are located on the front side, allowing back-to-back
installation. As a member of the NETGEAR Web Managed (Plus) Switch
family, the GS408EPP also includes a full set of soware features such as
trac prioritization, VLANs, QoS, Port Trunking/Link Aggregation and PoE
power allocation. The GS408EPP also features Energy Ecient Ethernet (IEEE

802.3az) for maximum power savings and comes with the NETGEAR Lifetime
Limited Warranty and 24/7 support including lifetime chat.

Highlights

Hardware Highlights

• 8 PoE/PoE+ ports (124W total PoE power
budget) to power up AC Wave 2 Access
Points, Pan/Tilt/Zoom Security Cameras,
VoIP/video conferencing phones, security
door locks, etc.

• Easy-Mount Virtually Anywhere mounting
system allows for wall, pole, under-surface,
in-ceiling, and even two per 1U rack slot
mounting (back-to-back) as all connections
(power and Ethernet) are located on the
front side.

• Secure placement above drop-down
ceilings, or along ventillation ducts
(plenum-rated), and where other switches
cannot go, vertical or horizontal, at or
perpendicular

• Whisper quiet 26.9dB acoustics when
operating at 25°C (77°F), well below
normal oces ambient background noise

Page 2 Models at a glance

Page 3 Features and benefits

Page 4 Example applications

Page 5-8 Technical specifications

Page 9 Ordering information

• Internal power supply to eliminate power
brick

• Turn LED lights ON/OFF for non-distracting
operation in dark environments

Soware Highlights

• VLAN support for trac segmentation

• Quality of Service (QoS) for trac
prioritization

• Auto Denial-of-Service (DoS) prevention

• Advanced per-port PoE controls

• Loop detection and broadcast
storm controls

• IGMP snooping v1, v2 and v3 support
for multicast optimization

• Rate limiting for better bandwidth allocation

• Port mirroring for network monitoring

• Port trunking for bigger uplink bandwidth

• Jumbo frame support

• Energy Ecient Ethernet (IEEE 802.3az)
support for maxium power savings

Industry Leading Warranty

• LIFETIME Hardware Warranty

• LIFETIME 24/7 Technical Support

• LIFETIME Next Business Day Replacement

*

Page 1 of 9

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Hardware at a Glance

Model name Form-Factor

Easy-Mount Virtually

GS408EPP

• 8 x Gigabit Copper Ports

• 8 x PoE/PoE+ Capable Ports (124W budget)

AnywhereTM plus 1U

rackmount (up to two

per slot)

10M/100M/1G

Copper Ports

8 Yes

Soware at a Glance

Management VLANs QoS

Web Browser-based
GUI (HTTP),
PC-Based ProSAFE
Plus Utility

Port-based, IEEE 802.1Q-

based, Voice

Port-based, IEEE

802.1p/DSCP­based

Internal Power

Supply

Mounting Options PoE/PoE+ ports

Attached to a wall, round

or rectangular pole.

Vertical, horizontal,

flat or perpendicular

mounting

Port Trunking

(Manual LAG)

Static LAG

• Dimensions WxDxH : 380 x 100 x 43mm
(15.0 x 3.9 x 1.7in)

IP Multicast

Filtering

IGMP

Snooping

(124W budget)

Case

Material

8-port PoE+

Rate Limiting

& Priority
Queueing

Yes Yes Yes

Metal

Jumbo

Frame

Support

Fans

1 (Fixed)

Side-to-side

26.9dB

Low acoustics

IEEE (802.3az)

Energy Eecient

Ethernet

Performance at a Glance

Model name Fabric

GS408EPP

16Gbps

line-rate

Packet

Buer

192KB

Latency

(Max Connection Speed)

10Mbps: <76.9µs
100Mbps: <9.1µs

1000Mbps:<2.7µs

VLANS

64

Page 2 of 9

MAC

Address Table

4K Entries
(dynamic)

Priority
Queues

4 (WRR) 128 11.9 Mfps up to 9K

Multicast

IGMP Group

Packet

Forwarding Rate

(64 byte)

Standard Rack MountingAttaching the Switch to a Wall or Under Tabletop/Desktop Attaching the Switch to a Round Pole

Jumbo Frames

(bytes)

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Features and Benefits

Hardware Features Benefits

PoE/PoE+ support • All 8 ports are PoE+ for a total of 124W of power enabling powering of all types of PoE devices

• 802.3af and 802.3at Power-over-Ethernet (PoE/PoE+) for exibility of deployment

• Single wire deployment of power and network connectivity to PoE+ devices

• Perfect switch for deploying Wireless AP, IP Cameras, VoIP Phones, Access-Controlled Security Door Locks or any

other IoT PoE-powered devices

Virtually AnywhereTM Mounting • Deploy your PoE switch closest to your PoE devices

• Put your PoE ports exactly where you need them

• Orient the switch ports up, down, or out (belly-mount or spine-mount)

• Vertical, horizontal, at or perpendicular mounting

Unique 2 per 1U Rack-Mountable • Deploy more PoE+ devices in less rack space

• As both Ethernet ports and power connection are on the same side of the Easy-Mount switch, two GS408EPP

switches can fit back-to-back in a single 1U rack slot

Soware Features Benefits

Port-based and 802.1Q-based VLANs Segment network into smaller groups for more secure and ecient use of network resources.

Comprehensive QoS features:

• Port-based or 802.1p-based
prioritization

• Layer 3-based (DSCP) prioritization

• Port-based ingress and egress

rate limiting

IGMP Snooping For improved network eciency on delivering multicast trac. Save cost and improve network eciency by ensuring

Port trunking/Link Aggregation Build up bigger bandwidth to support aggregated uplink/downlink trac or to provide redundant link(s) using Static

Advanced per-port PoE Controls Advanced per port PoE controls for remote power management of PoE connected devices (eg. Wireless AP, IP security

Voice VLAN The feature enables auto assignment of voice trac (based on OUI) to a special VLAN (AKA Voice VLAN), allowing the

Loop detection and auto DoS prevention Detect accidental network loops and protect against DoS attacks.

Port Mirroring For better and quicker network diagnostics and troubleshooting.

Energy Ecient Ethernet (IEEE 802.3az) For maximum power savings and reduced energy costs.

Cable Test Easily identify bad Ethernet cables.

Advanced controls for optimized network performance and better delivery of mission-critical trac such as voice and
video. Ingress and egress rate limiting allows for bandwidth shaping for mitigating network resources constraints or for
optimizing guest access bandwidth on the network.

multicast trac only reaches designated receivers without the need of an extra multicast router.

Manual LAGs.

cameras, LED lighting, door locks, IoT devices...)

assignment of special QoS parameters to that trac, and tagging the port automatically, giving it high priority services.
Voice VLAN must be enabled on a per port basis.

Page 3 of 9

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Example Applications

Security and Surveillance

Why Easy-Mount and Why
from NETGEAR?

Why the NETGEAR GS408EPP
Easy-Mount Switch is the ideal
upgrade for SMB networks:

1. Full PoE+ Easy-Mount Switch
for in-ceiling, wall, pole or desk
mount capabilities

2. 8-ports Gigabit Ethernet PoE+
ports (124W total PoE power)
allows connection of up to 7
PoE+ (802.3af and 802.3at)
devices (1 port for uplink)

In a Business Environment

3. Full set of Web Managed (Plus)
Switch soware features such as
trac prioritization, VLANs, QoS,
Port Trunking/Link Aggregation
(manual LAG), and multicast

4. Per port PoE controls to turn
on/o PoE for remote power
management of PoE connected
devices (eg. Wireless APs, IP
security cameras, LED lighting,
secure access door locks, IoT
devices…)

5. Lifetime limited warranty,
lifetime support chat and
24/7 support

Page 4 of 9

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Technical Specifications

PRODUCT SPECIFICATIONS

Product GS408EPP

100M/1G/10G RJ-45 copper ports 8

PoE/PoE+ ports 8 PoE+ (124W PoE Budget)

PERFORMANCE SPECIFICATION

Packet buer memory
(Dynamically shared across only used ports)

Forwarding modes Store-and-forward

Bandwidth (full-duplex fabric) 16Gbps

Priority queues 4

Priority queuing Weighted Round Robin (WRR)

MAC address database size (48-bit MAC addresses) 4K

Multicast groups 128

Number of VLANs 64

Packet forwarding rate (64 byte packet size) (Mfps or Mpps)

Speed/Latency 10Mbps: <76.9µs

Jumbo frame support Up to 9K packet size

Acoustic noise level @ 25° C (dBA) (ANSI-S10.12) 26.9 dBA

Mean Time Between Failures (MTBF) @ 25° C 2,715,369 hours

L2 SERVICES - VLANS

IEEE 802.1Q VLAN tagging Yes

Port-based VLANs (physical) Yes

L2 SERVICES - AVAILABILITY

Broadcast, multicast, unknown unicast storm control Yes

Link Aggregation/Port Trunking (Static Manual LAGs only)

IEEE 802.3x (full duplex and flow control)

2 LAGs with max 4 members in each LAG

L2 SERVICES - MULTICAST FILTERING

IGMP snooping (v1, v2 and v3) Yes

IGMP snooping queries No

Block unknown multicast Yes

Static multicast router port No

L3 SERVICES - DHCP

DHCP Client Yes

LINK AGGREGATION

Static Manual LAGs (Port Trunking)

# of Static LAGs/# of members in each LAG

2 LAGs with max 4 members in each LAG

192KB

11.9Mfps

100Mbps: <9.1µs

1000Mbps: <2.7µs

Yes

Yes

Page 5 of 9

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Technical Specifications

NETWORK SECURITY

Broadcast, multicast, unknown unicast storm control Yes

DoS attacks prevention Yes

QUALITY OF SERVICE (QOS)

Port-based rate limiting Ingress and egress

Port-based QoS Yes

IEEE 802.1p COS Yes

IPv4 DSCP Yes

IPv4 ToS Yes

TCP/UDP-based No

Weighted Round Robin (WRR) Ye s

Strict Priority queue technology No

Voice VLAN Yes, based on OUI bytes in the phone source MAC address

IEEE NETWORK PROTOCOLS

• IEEE 802.3 Ethernet • IEEE 802.1Q VLAN Tagging

• IEEE 802.3i 10BASE-T • IEEE 802.3x Full-Duplex Flow Control

• IEEE 802.3u 100BASE-TX • IEEE 802.1p Class of Service

• IEEE 802.3ab 1000BASE-T • IEEE 802.3az Energy Ecient Ethernet (EEE)

• IEEE 802.3af Power-Over-Ethernet (PoE

• IEEE 802.3at Power-Over-Ethernet (PoE)

• IEEE 802.3ad Port Trunking (Manual LAG)

MANAGEMENT

Password management Yes

Web browser-based graphical user interface (GUI) Yes

ProSAFE Plus Configuration Utility (PCU) for multi-switch management Yes

Firmware upgrade TFTP (Plus Utility) / HTTP (Web GUI)

Config file transfers (backup, restore) Plus Utility or Web GUI

Firmware upgrade through Plus Utility (TFTP) Yes

Config download (to switch) through Plus Utility Yes

Config upload (to server) through Plus Utility Yes

Firmware upgrade through web GUI (HTTP) Yes

Config download (to switch) through web GUI (HTTP) Yes

Config upload (to server) through web GUI (HTTP) Yes

Cable test utility Yes

Port mirroring Yes

Max number of source ports allowed (one-to-one port mirroring) 1

Mirroring port can still work normally? Yes

Page 6 of 9

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Technical Specifications

LEDs

Per port Le port LED: Speed, Link, Activity

Right port LED: PoE Status

Per device Power, PoE Max, Fan

POE CONFIGURATION

Number of PoE/PoE+ ports 8 PoE+

Total PoE power budget (watts) 124W

PHYSICAL SPECIFICATIONS

Dimensions (W x D x H) 380 x 100 x 43mm (15.0 x 3.9 x 1.7in)

Weight 1.6kg (3.53lb)

POWER CONSUMPTION

Power Supply Fixed internal PSU, 100-240VAC, 50-60Hz, 3A max

Power cord localized to country of sale

Max power (worst case, all ports used, line-rate trac) (Watts) 5.8W (no PoE)

148.0W (with PoE max)

Min power (link-down standby) (Watts) 4.7W

Heat Dissipation (max and min) (BTU/hr) Max: 505.27 BTU/hr

Min: 16.05 BTU/hr

Energy Ecient Ethernet (EEE) IEEE 802.3az

Short cable power reduction Yes

Auto power-down Yes

Fan(s) 1

ENVIRONMENTAL SPECIFICATIONS

Operating

Operating Temperature 0° to 50°C (32° to 122°F)

Humidity 90% maximum relative humidity (RH), non-condensing

Altitude 10,000  (3,000 m) maximum

Storage

Storage Temperature –20° to 70°C (– 4° to 158°F)

Humidity 95% maximum relative humidity (RH), non-condensing

Altitude 10,000  (3,000 m) maximum

Yes

Page 7 of 9

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Technical Specifications

ELECTROMAGNETIC EMISSIONS AND IMMUNITY CERTIFICATIONS

Certifications CE mark, commercial

47 CFR FCC Part 15, SubpartB, ClassA

ICES-003:2016 Issue 6, ClassA

ANSI C63.4:2014

EN 55022:2010 + AC:2011, Class A

EN 55024:2010

EN 61000-3-2:2014, Class A

EN 6100-3-3:2013

CISPR 22:2008, Class A

AS/NZS CISPR 22:2009 + A1:2010, Class A

VCCI V-3/2015.04, Class A

V-4/2012.4

Russia EAC mark

Korea KC mark

CNS 13438

Electromagnetic Compliance (Class A or B) Class A

SAFETY CERTIFICATIONS

Certifications CB mark, commercial

IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013

UL/cUL Listed (UL 60950-1)/CAN/CSA C22.2 No. 60960-1-07

EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013

AN/NZS 60950.1:2015

Russia EAC mark

WARRANTY AND SUPPORT

ProSAFE Lifetime Warranty*

ProSUPPORT OnCall 24x7 Service Packs**

Lifetime Online Technical Support*

Lifetime Next-Business-Day (NBD) Replacement

Category 1: PMB0311 (1 yr.)

PMB0331 (3 yrs.)

PMB0351 (5 yrs.)

Page 8 of 9

ProSAFE® Easy-Mount Switch Data Sheet

GS408EPP

Ordering Information

PACKAGE CONTENTS

All models ProSAFE Easy-Mount Web Managed (Plus) Switch

Power cord (localized to country of sale)

Rack-mounting kit

2 x Rubber belts

1 x Easy-Mount bracket

Quick install guide

Resource CD with installation guide, ProSAFE Plus Utility soware

and links to additional online documentation including the Web

browser-based management GUI User Manual and datasheet.

19-inch Rack-Mount Kit Easy-Mount Bracket for Virtually

Anywhere Mounting

Rubber Belts for Pole Mounting

ORDERING INFORMATION

GS408EPP-100NES North America, Latin America and Europe

GS408EPP-100AJS Asia Pacific and Australia

* This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller, and modications to product may void the warranty; covers hardware, fans,
and internal power supplies - not soware or external power supplies; see http://www.netgear.com/about/warranty/ for details. Lifetime technical support includes basic phone support
for 90 days from purchase date and lifetime online chat support when purchased from a NETGEAR authorized reseller.

** The NETGEAR OnCall 24x7 contract provides unlimited phone and email technical support for your networking product. For ProSAFE products purchased prior to 06/2014, also includes
Next-Business-Day (NBD) hardware replacement.

†

NETGEAR #1 in Fixed Web(Smart)-Managed Worldwide Market Share according to IHS Infonetics Ethernet Switches Market Share and Forecast, 1Q16 Edition, June 2016. NETGEAR #1

in US Market Share according to NPD data for Unmanaged and Web/Smart Switches, June 2016.

NETGEAR, the NETGEAR Logo, Click Switches, Virtually Anywhere and ProSAFE are trademarks or registered trademarks of NETGEAR, Inc. in the United States and/or other countries. Other brand
names mentioned herein are for identification purposes only and may be trademarks of their respective holder(s). Information is subject to change without notice.

© 2016 NETGEAR, Inc. All rights reserved.

NETGEAR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, 1-888-NETGEA R (638-4327), E-mail: info@NETGE AR.com, www.NETGEAR.com DS-GS408EP-1

Page 9 of 9
