N-series Benefits
• Optimized for HDX
• Full Screen HD Video
• Uses Less Than 5 watts
• Centrally Managed
• Low Price Point
N400 Features
• Numo 3 System on Chip (ARM)
• 4 USB 2.0 Ports
N-series Citrix Ready HDX
Verified System-on-Chip (SoC)
thin client devices
For organizations looking to broaden their commitment to Citrix XenApp® and/or
XenDesktop®, the new NComputing N-series Citrix Ready HDX Veried System-on-Chip
(SoC) thin client devices deliver 100% of the HDX experience at a fraction of the cost of
PCs or other thin clients.
NComputing next-generation thin clients are optimized for HDX and powered by the
Numo™ 3 System-on-Chip, which delivers a high performance client supporting HD video
sessions using less than 5 watts of power. With full manageability, support, and at low
cost, enterprise organizations can now cost-eectively extend their Citrix deployments
to more users, allowing them to gain fuller access to the many benets of
desktop virtualization.
• Proximity cards
• Resolution up to 1920 x 1080
• Zero footprint VESA mount
• Audio Out (Headphones)
• Audio In (Microphone)
Additional N500
Features
• Full HD 1080p Video Playback
• 10/100/1000BASE-T Ethernet
• Dual display option
• 802.11b/g/n Wi-Fi option
• 802.1x (PEAP, EAP-TLS, EAP-
TTLS) [N500w only]
N-series in Healthcare
The healthcare industry understands the value of virtualizing their environments and
is always looking for ways to make it faster, easier, more exible, or more powerful.
While the benets of a virtualized environment are ample, the user device often goes
overlooked as a way to fully maximize both user experience and return on investment.
For any virtualized environment running Citrix XenApp® and/or XenDesktop® the
NComputing N-series Citrix Ready HDX Veried System-on-Chip (SoC) thin client
devices are any healthcare provider’s key to making their virtualized
environment even more simple, more powerful and more aordable.
The N-series was built from the ground up to be fully optimized for
(and in fact, solely supports) the Citrix HDX protocol.
NComputing has taken our support for HDX environments in
healthcare one step further by integrating with Imprivata® OneSign®
to ensure that doctors, nurses, clinical, and support sta have secure
No Click Access™ to appropriate data and applications by the
authorized individual at the point of care (POC)—hospitals, satellite
clinics, labs, and doctors’ private-practice and home oces.
N-series N400 and N500
1 2 3 4
2 6 7 8 9
5
N-series Thin Client
1. Power Button
2. USB 2.0 Ports
3. Headphone
4. Microphone
5. Wi-Fi Antenna (optional)
6. Ethernet (RJ-45)
7. DVI-I
8. Power
9. Security Slot
Tested and validated
with these major HDX
N500: The workhorse of the N-series family of thin clients, the N500, provides the full
multimedia capabilities demanded by doctors, physicians, health care providers, and
other demanding environments. The N500 incorporates full client-side rendering for
ecient playback of video content, and uses server-side rendering for ash video
playback. It displays content up to full HD at 1080p. The N500 also provides options for
dual display and wireless connectivity (not available with the N400). Also powered by the
Numo™ 3 SoC, the N500 sets the new standard for price/performance in the thin client
market with its rich set of features and capabilities.
N400: The N400 is the thin client device of choice for nurses and healthcare sta who
don’t need full multimedia capabilities. The N400 combines the proven horsepower of
the third generation Numo™ 3 SoC with the deep understanding of desktop virtualization
to support full HDX sessions up to HD 720p and uses server-side rendering for video and
ash video playback.
N-Series Healthcare Use Cases
N-series thin client devices can be used at nursing workstations, at point of care, within
records management and across the entire workflow of patients and providers. The
cost-effective client enables role-based, secure access for doctors, nurses and other
staff to easily log in to patient records, lab results and clinical applications, as well
as personalized desktops. Some of the most common healthcare use cases for the
N-series include:
• View point-of-care applications in fixed or roaming locations
• Support shared workstations, persistent session state from one station to
another, and high performance for data- and graphics-intensive applications
to support medical imaging
• Enable highly secure access to medical records and hospital systems
offerings including:
• XenDesktop versions:
5.0, 5.5, 5.6, 7.1, 7.5
• XenApp versions:
6.0, 6.5, 6.5 Feature Pack 2,
7.1, 7.5
Centralized Management and Premium Support
With options for centralized management and mission critical premium support, in
addition to a dramatically lower price than alternative endpoints, N-series devices
transform the economics of enterprise desktop virtualization, enabling organizations to
more fully extend their Citrix and HDX deployments.
The new vSpace Management Center includes complete device management capabilities
to inventory, congure, update, reset and organize your N-series devices. NComputing
Premium Support provides additional resources designed to maximize the return on your
technology investment and ensure uptime and end user satisfaction.
FEATURE N400 N500
GENERAL Citrix Ready HDX
Verified
Powered by Numo™ 3 Yes Yes
DRAM Memory 512 MB 1 GB
GRAPHICS CAPABILITY Primary display 1920x1080 1920x1080
Secondary display
option
VIDEO Playback HD 720p (server-side
CODECS Client-side rendering No H.264, MPEG-4, VC1
FLASH VIDEO Playback HD 720p (server-side
POWER MANAGEMENT Power 5 W 5 W
Standby power 1.5 W 1.5 W
Instant on Yes Yes
PERIPHERAL SUPPORT USB keyboard & mouse Yes Yes
USB 2.0 ports 4 4
Proximity cards External USB External USB
MANAGEMENT Centralized
management option
Remote upgrade
option
NETWORKING Ethernet 10/100/1000BASE-T 10/100/1000BASE-T
Wi-fi option No 802.11b/g/n *
Yes Yes
No 1920x1200
Full HD 1080p (client-side rendering
rendering with hardware
acceleration on the client)
rendering with hardware
acceleration on the client)
Yes Yes
Yes Yes
with hardware acceleration)
Full HD 1080p (server-side rendering
with hardware acceleration)
802.1x (PEAP, EAP-TLS, EAP-TTLS) *
WPA-Enterprise, WPA2-Enterprise,
WEP, Open *
*factory install on N500w only
MODEL SKU
PROXIMITY CARD
READERS SUPPORTED
WITH IMPRIVATA ONESIGN
RFIDeas Access Control Reader RDR-80582AKU
RFIDeas pcProx HID RDR-6082AKU
RFIDeas AIR ID (Mifare) CSN RDR-7582AKU
N-series products are RoHS compliant and have been EMI certified according to FCC, EC, KCC and Canada’s
ICES standards. They have also attained UL and EC safety certifications. Declarations of Conformity available
upon request.
Why NComputing, Inc.
NComputing accelerates the adoption of desktop virtualization through a unique
formula of simplicity, performance and value. NComputing serves more than 50,000
businesses across 140 plus countries world- wide with a focus on education, healthcare,
manufacturing, financial services and government markets.
NComputing markets and sells its portfolio of desktop virtualization offerings via a
worldwide network of over 1600 value-added reseller and channel partners delivering
complete solutions to their customers. NComputing maintains strategic global alliance
partnerships with key technology providers in the desktop virtualization market, such as
Citrix and Microsoft. Global sales offices support customers and partners in North and
South America, Europe, India and the Asia Pacific region.
Availability
N-series thin client device is available through a global network of partners:
http://www.ncomputing.com/partners/find
For more information on the N-series, please visit:
http://www.ncomputing.com/products/nseries
About Imprivata Developer Program
The Imprivata Developer program enables software and hardware vendors to seamlessly
integrate strong authentication into any application or physical device through the
Imprivata OneSign ProveID™ API. Critical points in your solutions workflow that
require positive user identification or re-authentication such as medication ordering,
ePrescribing, or chart signing can be simply and quickly enabled. Imprivata OneSign
takes care of securing password information, audit and compliance reporting,
password change automation and out of the box support for the broadest range of
authentication modalities.
For more information, please visit
www.imprivata.com/partners/developer/imprivata-developer-program
®
