NComputing L150 Users Manual

User’s guide for OfficeStation

(L150 Series)

-PCI

documentation is prohibited by law. All other brand- and product names a re trad emarks of

registered trademarks of the respective owners.

Safety Instructions

The following instructions pertain to the risk of fir e, electric shock or bodily injury. Please read all of thes e instructions carefully.

- Do not use this system on an unstable cart, stand or table. The product may fall, causing serious damage to the product.

- Slots and openings in the cabinet and the back have been provided for ventilation. To ensure reliable operation of your computer, and to protect it from overheating, do not block or cover these openings.

- Never push objects of any kind into the system through the cabinet openings. Objects may touch dangerous voltage points or short out parts that could result in a fire or electrical shock. Never spill liquid of any kind on the product.

- This computer should only be connected to the adapter comes with your system. If you want to use other adapter, consult your dealer.

- Do not allow anything to rest on the power cord. Do not locate this product where people will walk on the cord.

- Unplug your system form the main electrical power outlet before cleaning.

Warning

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

- Do not use this system near water.

- Your adapter plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert or replace your obsolete outlet, contact your electrician to replace your obsolete outlet. Do not defeat the purpose of the grounding-type plug.

- To avoid generating an electric shock, be sure to plug the power cord into the system before plugging it into the wall socket.

- For protection of your system and other devices during a lightning storm, or when it is left unattended and unused for long periods of time, unplug the computer and other devices form the wall outlet and disconnect the cable form system. This will prevent damage to the system and other devices due to lighting and power line surges.

FCC Information to Use

Note : This equipment has been tested and found to comply with the limit for a Class B digital device, pursuant 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions. May cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. IF this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off nad on, the user is encourage to try to correct the interference by one or the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

- Consult the dealer or an experience radio TV technician for help

Change or modification not expressly approved by the party responsible for Compliance could void the user’s authority to operate the equipment

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation

Introductions

What is OfficeStationTM ?

OfficeStationTM is an unique networking device using WoIPTM (Windows over IP) based on networking standards. You can share the resources of the host PC system by connecting OfficeStation several networked PCs. You can connect one or more OfficeStation Host PC directly using a LAN adapter and cable or via network using a hub/router.

Features of I/O Ports (PCI Bracket)

- One speaker Jack

- One PS/2 Keyboard connector

- One PS/2 Mouse connector

- One RJ-45(LAN) Jack

- One VGA Monitor connector

System Requirements of Host PC

- To connect one OfficeStation

terminal(s) to it, thus giving you the benefit of having

terminals to one

terminal to a single host PC, the following system requirement si needed of the host PC : Intel Pentium 4 1.0GHz processor with at least 256MB RAM or higher

- To connect two to three OfficeStation system requirement si needed of the host PC : Intel Pentium 4 2.4GHz processor with Hyper - Threading technology with at least 512MB RAM or higher

- To connect four to seven OfficeStation system requirement si needed of the host PC : Intel Pentium 4 3.0GHz processor with Hyper - Threading technology with at least 1024MB RAM or higher

- To connect eight to ten OfficeStation system requirement si needed of the host PC : Intel Pentium 4 3.2GHz processor with Hyper - Threading technology with at least 2048MB RAM or higher

terminal to a single host PC, the following

OS (Operating System)

- Windows XP Home Edition

- Windows XP Professional Edition

- Windows 2000 Professional Edition

Setting up the OfficeStation

1. Component Names and Functions

1-1 Product Photo
