Navman X300 Quickstart guide

Send completed registration card to us, or
register at www.sport-tool.com, to go in the
draw to receive a special gift from Navman.
Your registration will enable us to optimize
our service to you.
Customer information
Product purchased
A300 M300 S300 R300 W300 X300
Date of purchase (dd/mm/yy)
User profile
Age: yrs male female
How will you mainly use your Sport.Tool?
(You can choose more than one)
Other
NAVMAN
First Name:
Last Name:
Country:
Street 1:
Street 2:
City:
Postal Code:
E-mail:
Navman product information
Please tick here to receive offers and product information from
Navman.
Expected use
I expect to use the Sport.Tool approx days per month.
X300
Setting options
NAVMAN
Press and hold
to enter setup
Press
repeatedly to step through the setting options.
Press both buttons together (
) to start or stop editing
a setting option.
While editing, press
or
repeatedly to step through selectable states,
or increase/decrease values. Press and hold the appropriate button
to
increase/decrease values quickly
.
Set (12hr)
lets you set 12hr or 24hr time format
Set (31-12)
lets you set dd-mm or mm-dd date format
Calc up
When ‘calc up’ is «ON» the X300 calculates data for all movement (uphill and downhill). When ‘calc up’ is «OFF» the X300 calculates information for downhill movement only.
Beep
When beep is «ON» a beep will sound when the buttons are pushed.
Set units (km/h)
lets you set speed units to «km/h» or «mph»
Distance and altitude are displayed in units corresponding to the speed units, i.e. if you choose «km/h» for speed units, then distance is displayed in «km» and altitude in «m».
Set offset
lets you adjust the X300 to display local time
The date is displayed to ensure that time adjustments are made in the correct direction, i.e. both correct time and correct date should be displayed. GPS signals must be obtained to set local time.
Press and hold
to leave setup
X300 — Settings
X300
Use the settings
NAVMAN
X300 — Settings
KEY = press this button = press this button = press both buttons together
settings editing details
edit
accept
beep
beep
beep ON
beep OFF
set units (km/h)
set units (mph)
set units (km/h)
set offset
set 12hr
set 31-12
set 24hr
set 12-31
set units (km/h)
set (12hr) set (12hr)
set (31-12)set (31-12)
time (date)
Calc up
Calc up ON
Calc up OFF
Calc up
edit
accept
edit
accept
edit
accept
edit
accept
edit
accept
X300
Normal operating modes
Press
to start normal operation
Press
repeatedly to step through the modes (hold
to
cycle automatically through modes).
Speed
shows session distance and current speed
Speed (AVG)
shows session distance and average speed
Speed (MAX)
shows session distance and maximum speed
Odometer
shows total distance from last odometer reset
Altitude
shows total accumulated altitude and current altitude
Zone OFF
lets you skip the zone setting options
Zone alerts do not sound if zone status is «OFF».
Zone ON
makes the min and max zone setting options available
If zone status is «ON», alerts sound when zone limits are passed.
Zone MIN
lets you set your minimum target speed
Zone MAX
lets you set your maximum target speed
Clock
shows the current time and date
(You may need to adjust the settings to display your local time.)
Timer
shows session and lap times
The timer starts automatically whenever you start moving and stops whenever you stop moving.
Timer Recall
lets you recall stored lap data. Repeatedly pressing
recalls
lap data starting from the last stored lap, then lap 1, 2, 3 etc.
Press and hold
to shut down the X300
NAVMAN
X300 — Modes
X300
Use the modes
*
KEY = press this button = press this button = press both buttons together = press and hold both buttons together
NAVMAN
X300 — Modes
modes
operating details
Speed (AVG)
Speed (MAX)
Speed
Clock
Timer
Odometer
clear all session data*
Timer recall
Altitude
store current lap data
clear max speed only
clear odometer only
clear accumulated altitude only
restart recall from lap 1
recall lap data
(*does not clear odometer)
RCL
AVG
MAX
8 7
2
clear all session data*
clear all session data*
clear all session data*
store current lap data
store current lap data
store current lap data
store current lap data
store current lap data
store current lap data
Zone OFF
Zone MAX
Zone MIN
Zone OFF
Zone MIN
Zone OFF
Zone ON
Zone ON
Zone MAX
accept
���
edit
ZONE
SET
accept
edit
edit
accept
edit
accept
X300
QUICK START GUIDE
X300
NOW YOU KNOW.
X300
Be outdoors
The X300 is not intended for operation indoors or under water as it uses Global Positioning System (GPS) satellites to get time and date information, and to calculate distance and speed. For best results, always use the X300 outdoors with an unobstructed view of the sky.
L
1. Turn D-ring anti-clockwise and slide enclosure cover down to open battery enclosure.
2. Insert battery with «» end as indicated inside enclosure.
3. Replace enclosure cover (ensuring lugs at the bottom of the cover are aligned with slots in the enclosure surround), turn D-ring clockwise to seal.
Get ready
Step 1
Fit the battery
Fit the X300
The X300 is designed to be worn on the left upper arm. You may wish to adjust some of the settings prior to fitting.
For best performance:
General use =
Alkaline
Below 5
o
C = NiMH
!
X300
The control buttons,
and
(as shown above) are pressed separately or together to turn the unit «ON» and «OFF», cycle through modes, and select mode options.
Know the buttons
Get set
Step 2
!
Always enter setup first if you wish to change settings. To enter setup after starting normal operation, you must shut down and re-start the X300.
Flashing icon = seeking GPS signals Constant icon = GPS signals obtained
Startup could take up to 80 seconds to get all satellite data.
If you release
before the counter reaches zero, the X300
will immediately start normal operation.
For details about system settings see over page or consult User Guide.
Press and hold
to leave setup
counter
counter
After leaving setup, the X300 automatically starts normal operation displaying the speed mode first.
Enter setup
Press and hold
to enter setup
Know the startup options
1. enter setup
2. start normal operation
X300
Start normal operation
Press
to start normal operation
When starting directly into normal operation X300 will start in the mode it was in at last shutdown.
The X300 automatically operates whenever you are moving and pauses operation while you are stationary. Modes are accessed in the following order:
Go
Step 3
Mode icons appear in the lower section of the screen. While in Speed mode you can monitor session distance and current speed. You can also store laps or clear session data.
While in Speed mode
Press to store lap data
Press and hold
to clear all* session data
Press
to go to next mode
(*Does not clear odometer)
When you want to shut down the X300
Press and hold
Now you know.
speed mode icon
session distance
current speed
For details about modes or setting zone limits, see over page or consult User Guide.
Mode example (speed)
837
2
Speed
Speed AVG
Speed MAX Odometer
Altitude
ClockTimer
Timer RCL
MAX
AVG
RCL
Zone OFF
Zone ON
Zone MINZone MAX
ZONE
SET
km km/h
LA000550B © 2005 Navman NZ Ltd. All rights reserved. "Sport.Tool" and "Now you know" are trademarks of Navman NZ Ltd.
