Navman SMART ST 2009 User Manual
S-Series
English - Australia/New Zealand
en
Smart 2009 Software
User Manual
Important safety information
PLEASE READ CAREFULLY BEFORE INSTALLING PRODUCT IN VEHICLE
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey
all safety messages that follow this symbol to avoid possible injury or death.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
CAUTION used without the safety alert symbol indicates a potentially hazardous situation
which, if not avoided, may result in property damage.
Removing original equipment, adding accessories or modifying your vehicle could affect the vehicle’s safety or make it illegal to operate
in some jurisdictions.
Follow all product instructions and all instructions in your vehicle owner’s manual regarding accessories or modifications.
Consult your country’s and/or state’s laws regarding operation of a vehicle with any accessories or modifications.
It is your sole responsibility to place, secure and use your Navman in a manner that will not cause accidents, personal injury or property
damage. Always observe safe driving practices.
Do not mount your Navman in a way that may interfere with the safe operation of the vehicle, the deployment of air bags or other safety
equipment.
Do not operate your Navman while driving.
Before you use your Navman for the first time, familiarize yourself with your device and its operation.
On main roads, the distance to an exit calculated by the Navman may be further than the distance shown on road signs. Road signs
show the distance to the start of an exit while the Navman shows the distance to the next intersection, i.e., the end of the exit ramp or
road. To prepare to exit a road, always follow distance information on road signs.
The use of information regarding safety or speed camera locations may be subject to local laws in the country of use. You are
responsible for checking that you can legally use the information in your country or in the country where the information will be used.
Do not handle the Navman while it is hot. Let the product cool, out of direct sunlight.
At full power, prolonged listening to the Navman via headphones or earphones can damage the ear of the user.
Do not expose the Navman to direct sunlight in an unattended vehicle for prolonged periods. Overheating may damage the unit.
To discourage theft, do not leave the Navman, mounting bracket or any cables in plain view in an
unattended vehicle.
Warning Notice to Drivers in the United States
State law may prohibit drivers in states such as Arizona, California and Minnesota from mounting objects on their windshields while
driving. Please make sure you research and follow your most current State laws. An alternative mounting option is provided in the box
with your product; also, stores offer additional mounting alternatives. Navman does not take any responsibility for any fines, penalties, or
damages that may be incurred as a result of disregarding this notice.
Failure to adhere to these warnings and cautions may lead to death, serious injury or property damage. Navman disclaims all
liability for installation or use of the Navman that causes or contributes to death, injury or property damage or that violates
any law.
2
Contents
Important safety information...................................................................................................................2
Welcome................................................................................................................................................5
Important information for using the manual.......................................................................................5
Formatting ....................................................................................................................................5
Icons.............................................................................................................................................5
Terms ...........................................................................................................................................5
How do I use the touch screen?.............................................................................................................6
How do I get started?.............................................................................................................................7
How do I turn my Navman on for the first time? ................................................................................ 7
Home screen .........................................................................................................................................8
How do I go from A to B?.......................................................................................................................9
What if I miss a turn?........................................................................................................................9
Using the Keyboard screen.............................................................................................................10
How can I set my keyboard preference?.....................................................................................10
How do I plan my first trip?..............................................................................................................11
How do I view my route?.................................................................................................................12
How do I search for an address using the FIND address wizard?................................................... 13
How do I search for a Point of Interest (POI)?.................................................................................15
How do I set my route preferences? ...............................................................................................16
How do I use the Explore map?...................................................................................................... 17
How do I explore an area for a POI?...............................................................................................18
How do I explore a map for a POI?.................................................................................................20
How do I set my POI preferences? .................................................................................................21
How do I preview a route? ................................................................................................................... 22
How do I view my route statistics? ....................................................................................................... 23
How do I navigate to a recent place?................................................................................................... 24
My Places ............................................................................................................................................26
How do I save a location as My Place or Home? ............................................................................26
How do I navigate to a location I have saved? ................................................................................27
How do I navigate to Home?...........................................................................................................27
How do I edit the name of a location in My Places? ........................................................................ 28
How do I delete a Favourite? ..........................................................................................................28
How can I view a POI I have downloaded using NavDesk? ............................................................ 29
How do I add or edit a POI description? .....................................................................................29
How do I navigate to a NavPix? ................................................................................................... 30
How do I navigate to a NavPix in an album?............................................................................31
NavPix management................................................................................................................32
How do I view a NavPix in full-screen? ....................................................................................33
How do I delete NavPix from an Album?..................................................................................33
How do I save a NavPix under My Places?..............................................................................34
How do I add or edit a NavPix title?......................................................................................... 34
How do I capture the GPS co-ordinates of my location? .................................................................35
How do I navigate to a location I have captured? .......................................................................35
What is Connect (Local Search)?.........................................................................................................36
How do I search for a POI using Connect? .....................................................................................36
How do I make a hands-free Call?.......................................................................................................39
How do I pair my Navman with a Bluetooth mobile phone? ............................................................39
Paired phone detail screen.........................................................................................................39
Configuring internet settings....................................................................................................... 40
How do I pair my Navman with a Bluetooth headset? .....................................................................40
How do I make a phone call?..........................................................................................................41
How do I receive a phone call?....................................................................................................... 42
How do I add a contact to my Navman?..........................................................................................42
How do I search for a contact in my phonebook? ....................................................................... 42
How do I make a phone call to a contact? .................................................................................. 43
3
How do I view my call history? ........................................................................................................44
How do I play media? ..........................................................................................................................45
Playing audio files........................................................................................................................... 45
How do I listen to a music file on my Navman?...........................................................................45
Playing video files ...........................................................................................................................47
How do I view a video file on my Navman?.................................................................................47
How do I view the video file on a full screen? ............................................................................. 48
FM Radio ........................................................................................................................................49
How do I receive audio through my vehicle speakers?.........................................................................50
How do I set the audio output channel of my Navman through my car’s FM radio? ........................50
How do I receive current traffic information? ........................................................................................51
How does my Navman receive traffic information? .........................................................................51
Traffic status...............................................................................................................................51
How will I know when a Traffic Event occurs?.................................................................................52
Traffic Overview screen ..................................................................................................................53
How do I view a list of all events on my route? ...........................................................................54
How do I view traffic details? ......................................................................................................55
How do I know if a detour is recommended? .............................................................................. 56
How do I avoid an event on my route?........................................................................................56
How do I cancel a detour around an event on my route?............................................................ 56
Traffic Messages.............................................................................................................................57
Detour Not Available messages..................................................................................................57
Detour recommended messages................................................................................................57
Traffic preferences..........................................................................................................................58
TMC service ...............................................................................................................................58
Traffic Event Notification.............................................................................................................58
Select event sorting type ............................................................................................................59
Walking mode ......................................................................................................................................60
How can I set my navigation mode to walking?...............................................................................60
What can I customize?.........................................................................................................................61
Volume ...........................................................................................................................................61
Route options..................................................................................................................................62
Map display.....................................................................................................................................62
Screen brightness........................................................................................................................... 63
Bluetooth ........................................................................................................................................63
Language........................................................................................................................................64
Voice...............................................................................................................................................64
Power management........................................................................................................................65
Connect ..........................................................................................................................................65
Units ...............................................................................................................................................66
Touch audio....................................................................................................................................66
Audio output....................................................................................................................................66
Delete saved information ................................................................................................................67
Reset GPS......................................................................................................................................67
About ..............................................................................................................................................67
Shop demo .....................................................................................................................................67
Screen saver...................................................................................................................................68
Reference ............................................................................................................................................69
Points of Interest categories............................................................................................................69
Point of Interest categories by subscription.................................................................................70
My Places categories by Navman...............................................................................................70
Traffic and other TMC Events.........................................................................................................71
For more information.......................................................................................................................72
Online support ............................................................................................................................72
Phone support ............................................................................................................................72
Safety Camera POIs.......................................................................................................................72
Speed Limit.....................................................................................................................................72
Disclaimer.......................................................................................................................................72
Compliance.....................................................................................................................................73
Copyright ........................................................................................................................................73
4
Welcome
This manual has been prepared to guide you through the operation of your Navman from first set-up through to
continuous use. Please read this manual carefully before using your Navman for the first time. Keep this manual in a
safe place and use as your first point of reference.
Important information for using the manual
It is important to understand the terms and typographical conventions used in this manual.
Formatting
The following formatting in the text identifies special information:
Convention Type of Information
Bold Navman components or items displayed on screen, including buttons, headings, field names and
Italics
Icons
The following icons are used throughout this manual:
Icon Description
Terms
The following terms are used throughout this manual to describe user actions.
Term Description
Tap Press and release an item displayed on the touch screen.
Tap and hold Tap and hold an item displayed on the touch screen for 2-3 seconds.
Select Tap an item in a list or tap a command from a menu.
options.
Indicates the name of a screen.
Note
Tip
Warning
5
How do I use the touch screen?
Your Navman touch screen options change dynamically:
To see all options on a menu, drag the screen up or down.
To display the next screen, tap an icon or select an option.
To dock a menu to the left, tap the left edge of the menu. To dock a menu to the right, tap the right edge of
the menu.
6
How do I get started?
The first time you use your Navman, it may take up several minutes to establish a GPS connection. For more
information about GPS, refer to the GPS Frequently Asked Questions
How do I turn my Navman on for the first time?
To get started for the first time, complete the following steps:
1. Read the Important Safety Information on page 2.
2. Position your Navman in your vehicle.
Follow the instructions in the Hardware User Manual.
CAUTION: Ensure that your Navman does not obstruct the driver's view, or interfere with the operation of the
vehicle airbags and safety devices.
3. Turn your Navman on
Your Navman will turn on and display the Language screen.
4. Select your preferred language
From the Select Language screen, tap your preferred language.
guide on the enclosed DVD.
To prevent the Select Language screen from displaying on each start-up, tap the Show this screen on start-up
option to deselect it.
You can change your preferred language while using your Navman, see "Language" on page 63.
5. Read the warning message
a) The Safety Agreement screen will display after you have selected your preferred language.
Read the Safety Agreement message.
b) To confirm that you have read and understood the message, tap Accept.
The Tutorial will display.
6. View the Tutorial
To skip the Tutorial screens, tap Skip.
To move forward through the Tutorial screens, tap Next.
To view the previous screen, tap
To prevent the Tutorial from displaying on each start-up, tap the Show on start-up option to deselect it.
When you have finished the Tutorial, the Map screen will display. If you have a GPS fix, your current location will be
displayed on the map.
.
7
Home screen
The Home screen is your starting point for searching for a destination. The Home screen also allows you to
customize your Navman, receive updated traffic information and make and receive phone calls.
The Home screen can be accessed from the map screens by tapping
Easiest way to set your destination
and GO!
Search for places, areas and streets to
help plan your route.
Explore the area around your current
position or destination.
Search online for live Point of Interest
(POI) information.
Display the Map screen.
Save your important destinations, places,
NavPix, etc.
Home screen options and the order of the options may differ from the above, depending on your region, maps
installed or model of Navman.
on your Navman.
Configure your Navman to enhance your
navigation experience.
Receive live traffic information on your route and
set traffic preferences.
Use your Navman as a hands-free car kit.
Play FM radio or audio and video files and set
media preferences.
Search for the nearest parking places when
travelling.
Search for the nearest petrol stations when
travelling.
8
How do I go from A to B?
Your Navman is equipped with maps that provide street-level detail for door-to-door navigation, including Points of
Interest such as accommodation, parking areas, petrol stations, railway stations and airports.
When you ... Then ...
know the address of your destination use the GO address wizard to enter the address. See "How do I plan
need to search for an address use the FIND address wizard to search for the address. See “How do I
need to find a named site, feature,
landmark or public venue
search for live POI information search for a POI using Connect. See "How do I search for a POI using
want to navigate to a NavPix™ location use the My Places screen to navigate to a NavPix. See "How do I
WARNING: For your safety, enter destination information before you start a journey. Do not enter a
destination while driving.
What if I miss a turn?
Back-On-Track™ Automatic Rerouting
You will be redirected if you make a wrong turn. A message informing you that your route is being re-calculated will
display at the top of the screen.
To cancel a route re-calculation tap x. A warning will display, asking you to confirm the cancellation. If confirmed,
both the re-calculation and your current route will be cancelled.
my first trip?" on page 11.
search for an address using the FIND address wizard?” on page 13.
search for a Point of Interest. See "How do I search for a Point of
Interest (POI)?" on page 15.
Connect?" on page 36.
navigate to a NavPix?" on page 30.
9
Using the Keyboard screen
The Keyboard screen will display when you are required to enter text, such as when searching for a street name.
Search results will be listed in matching order, with the closest matches appearing on the screen. A maximum of 99
results will display.
The Keyboard screen can display with various layouts depending on the information you need to enter, including
alphabet, number, alternate characters and combinations of these.
To select a character, tap the character.
To enter upper case letters, tap .
To delete a character, tap
Tap and hold
to delete the entire text.
.
To display more characters, tap
to select an alternate keyboard screen.
How can I set my keyboard preference?
7. From the Keyboard screen, tap .
The Keyboard preference screen will display.
8. Complete the following:
If you want to... Then...
use an alphabetic keyboard for entering
information
use a QWERTY keyboard for entering
information
use an accented keyboard for entering special
character
use a symbolic keyboard for entering symbols select the Use symbolic keyboard option.
use a keypad-type keyboard (predictive text)
when searching for an address
How does predictive text (abc, def…) work?
Predictive text allows addresses to be searched by a single key-press for each letter, as opposed to the multiple keypresses. As you enter a letter of an address, your Navman will compare all possible combinations against the maps
you have installed and determine which address you intended to type.
For example:
To enter Sydney, tap PQRS WXYZ DEF MNO
Your Navman will compare all possible combinations and display Sydney in the list of search results. You can add
further letters to narrow the search.
select the Use alphabetic type (a, b, c...) option.
select the Use QWERTY option.
select the Use accented keyboard option.
select the Use keypad type (abc, def...) for address
searches option.
10
How do I plan my first trip?
Using your Navman to plan your first trip is easy. There are several ways to select your destination. Complete the
following to navigate to a street address that you know using the GO address wizard.
Your Navman will calculate the route from your current location. The Map screen will display.
11
How do I view my route?
When a route has been calculated, the Map screen will display. You will be directed to your destination by spoken
and visual instructions.
Item Description
Direction and
distance of next turn
Add waypoint to trip Adds a location as a waypoint on your trip.
Next turn and current
route
Detour Detours your route to avoid next 1, 2, 5, 10 or 20 kilometres/miles
Current position
The direction and distance to your next turn
Tap
Tap
to repeat the vocal instruction.
to remove the waypoint from your trip.
Your next turn and current route are highlighted.
In Driving mode, your current position is marked with
In Walking mode, your current position is marked with
Cancel route Cancels your current route.
Distance and Time
Information
Tap to expand and select the following options:
Time
km/h or mph (speed) and heading
TTG (Time to Go)
DTG (Distance to Go)
ETA (Estimated Time of Arrival).
Pause route Pauses your current route.
Zoom
Volume Mute or unmutes the volume.
Tap to unpause your current route.
To zoom out, tap and hold -.
To zoom in, tap and hold +.
.
.
12
13
The below address is fictitious and used as an example only.
How do I search for an address using the FIND address wizard?
2 Navman Street
Bossley Park
Sydney
Complete the following:
If you want to ... Then ...
calculate the route, open the Map screen and
tap GO.
start navigating
save the location as Home
tap Add to My Places.
tap Save as Home.
save the location as a favourite
tap Add to My Places.
tap Save as My Place.
navigate to a place near the location
tap Pick on Map.
tap an area and tap OK.
explore the area near the location
tap Explore this area.
The Map screen will display.
The Save screen will display.
The Save screen will display.
The Pick on Map screen will display.
The Preview screen will display.
The Find screen will display.
14
How do I search for a Point of Interest (POI)?
A POI is a named site, feature, landmark or public venue which can be displayed as an icon on the map. POIs are
grouped by category, such as petrol stations, parks, beaches and museums.
Sydney Opera House
Macquarie St, Sydney
Complete the following:
If you want to ... Then ...
calculate the route, open the Map screen and
start navigating
save the location as Home
save the location as a favourite
place a phone call to the POI
navigate to a place near the location
explore the area near the location
tap GO.
The Map screen will display.
tap Add to My Places.
The Save screen will display.
tap Save as Home.
tap Add to My Places.
The Save screen will display.
tap Save as My Place.
tap Call.
This feature is not available on all models.
tap Pick on Map.
The Pick on Map screen will display.
tap an area and tap OK.
The Preview screen will display.
tap Explore this area.
The Find screen will display.
15
How do I set my route preferences?
You can enhance your navigation experience by modifying aspects of your route and route calculations.
1. From the GO screen, tap Other options.
The Other options screen will display.
2. Complete the following:
If you want to... Then...
set route type options for your
route
tap Route type.
The Route type screen will display.
select your route type preference form the list
• Economical - The route with least number of stops, turns
and urban areas which should save on fuel useage
• Easiest - The simplest route with the least number of turns
and favours motorways where appropriate
• Fastest - The route that should be the fastest when
navigating
• Shortest - The route with the shortest physical length
Selecting Shortest route type over Fastest route type can cause
a much longer journey time.
set types of road options for your
route
tap Types of road.
The Types of road screen will display.
select your road preference form the list
Avoiding ferry routes may prevent you from navigating between
certain countries, even when a bridge or tunnel exists.
set your map screen preference tap the Map option to select between a 3D or 2D view of the Map
screen.
display 3D landmarks on your
tap the 3D landmark option to turn it On or Off.
route
display Junction views on your
tap the Junction views option to turn it On or Off.
route
record mileage for your route to
tap the Mileage recorder option to turn it On or Off.
generate expense reports
record a GPS log of your trip tap the GPS logging option to turn it On or Off.
16
How do I use the Explore map?
The Explore map allows you to explore the local area to find Points of Interest (POIs) or navigate to an address. If
you do not have a GPS fix, the map will display your last known position.
Tap and drag the map to explore the local area.
Tap the map to display a POI Burst showing POIs in the surrounding area. Tap a POI icon to show more
information and navigate to the POI.
Item Description
Angle options Tap to adjust the horizontal viewing angle.
Zoom options To zoom in or out, tap and hold - or +.
Rotate options Tap or tap and hold to rotate the map clockwise or anticlockwise.
Panning options Tap or tap and hold to pan the map forward, back, left or right.
To display a POI Burst, tap an area on the Explore map.
Tap an icon or street name in the POI Burst to view information and options.
POI Burst
17
How do I explore an area for a POI?
An amusement park near Sydney Opera House, Sydney.
18
Complete the following:
If you want to ... Then ...
calculate the route, open the Map screen and
tap GO.
start navigating
save the location as Home
tap Add to My Places.
tap Save as Home.
save the location as a favourite
tap Add to My Places.
tap Save as My Place.
place a phone call to the POI
tap Call.
This feature is not available on all models.
navigate to a place near the location
tap Pick on Map.
tap an area and tap OK.
The Map screen will display.
The Save screen will display.
The Save screen will display.
The Pick on Map screen will display.
The Preview screen will display.
19
How do I explore a map for a POI?
If you want to ... Then ...
calculate the route, open the Map screen and
start navigating
save the location as Home
save the location as a favourite
place a phone call to the POI
navigate to a place near the location
tap GO.
tap Add to My Places.
tap Save as Home.
tap Add to My Places.
tap Save as My Place.
tap Call.
This feature is not available on all models.
tap Pick on Map.
tap an area and tap OK.
The Map screen will display.
The Save screen will display.
The Save screen will display.
The Pick on Map screen will display.
The Preview screen will display.
20
How do I set my POI preferences?
Points of Interest (POIs) are grouped into categories. You may choose to either display (or hide) icons of all POI
categories on the map screens, or only display the icons from selected categories.
For example, you may only be interested in entertainment venues and want to disable other categories such as
schools.
1. From the EXPLORE screen, tap Places settings.
The Places settings screen will display.
2. Complete the following:
If you want to... Then...
display all POI icons (i.e. icons from all
categories)
display no POI icons tap Hide all.
show/hide select a specific POI category icon
for display on the map screen
Your preferences are automatically saved.
tap Show all.
tap the required POI category to Show/Hide on the map
screen; repeat until all required categories are selected.
21
How do I preview a route?
Route simulation allows you to:
Preview a route.
Plan and view a route without a GPS fix, for example when you are inside a building.
The following steps will show you how to preview a route:
1. Select a departure point.
If you have a GPS fix, you do not need to select a departure point unless you want the demonstrated route
to start elsewhere.
a)
b) Tap From.
c) Tap Find a place, then follow the example steps on page 10.
2. Select a destination point using the GO or FIND address wizards, or the Explore map.
3. From the Preview screen, tap GO.
Your route is calculated and the Map screen will display.
4. Tap the edge of the docked menu.
The GO screen will display.
5. Tap Route simulation.
The Map screen will display the calculated route in route simulation mode.
6. Complete the following:
If you want to... Then...
skip to the next turn
increase the speed of the simulation
decrease the speed of the simulation
cancel the simulation
The Leaving from… screen will display.
tap
tap
tap
tap
.
.
.
.
22
How do I view my route statistics?
Your Navman provides information on your:
distance to go
estimated time of arrival
distance travelled
average speed
maximum speed
time taken for trip
stationary time.
To view your route statistics during a planned route:
1. Tap
2. Tap
and then tap
The GO screen will display.
.
The Route Statistics screen will display.
23
Loading...
