Navman GPS 4400 User Manual

Wireless Bluetooth GPS Receiver & Smart ST™Professional Navigation software solution for Pocket PCs
GPS 4400
Wireless
Ultimate in-car GPS navigation. No strings attached. The new Navman
GPS 4400 is a complete wireless GPS navigation system for any Bluetooth embedded Pocket PCs.
With wireless connectivity, the GPS receiver unit can be placed out of the way, on the rear winshield for example, freeing the Pocket PC and dashboard of wires and cables and allowing greater flexibility of use whilst driving.
In addition, the GPS receiver unit can be attached with a lanyard or armband, both of which are supplied as standard, making the GPS 4400 mobile, versatile and easy to install whatever the circumstances.
Mobile
Works in or out of the car.
To fit all Pocket PC’s with integrated Bluetooth support
Voice
Male and female, turn-by-turn voice instructions.
Languages
English, French, German, Dutch, Spanish, Italian.
Safe
Finger controlled touch screen menu system for easy mobile use, with additional controls via the Pocket PC hardware keys.
Style
Day and night screen display with multiple map style options.
Power
Three AAA Batteries (included). 10 to 30 hours of continuous operation.
External Power
12.0 V DC cigarette lighter vehicle power cable.
Drive safely and enjoy the ride.The Navman GPS 4400 gives you precise,
vocal turn by turn, instructions throughout your journey. It indicates which lane to get into when approaching difficult intersections, such as motorway entrances and large roundabouts.
No small maps to read. No hard signs to find. Just listen.
GPS 4400
Wireless
technical specifications
GPS Antenna
Multi-directional – lncreased capability to receive GPS signal from any direction. External Antenna Connection via MCX connector.
GPS Receiver Type
12 channel parallel, automatic selection.
Time to First Fix
Hot start 8s typical Warm start 38s typical Cold start 45s typical
Accuracy of Position Fix
The accuracy of the GPS position is typically better than 5m (16ft) for 95% of the time under optimum conditions.
Interface
Bluetooth ™ SSP (Serial Port Profile) V 1.1
Update Rate
Typically every second once fix established.
Output Message
NMEA 0183 Ver:2.20, GPGGA, GPGSA, GPRMC and GPGSV.
The difference is
30 hours
total wireless performance
16 countries
mapping supplied as standard
GPS 4400 Wireless
Display
Variable map and navigation screens allowing you to choose your preferred navigation screen. Map Display only, Map and Navigation Instructions or Key Instructions display screen only.
Navigate and Arrive
By an address to a door, a street name, an intersection or to a point of interest selected from the integrated map data base included.
Routing
Automatic calculation of of any route bring you Back-On­Track™ fast if you take the wrong turn.
Visual Guidance
Automatic zooming when driving with overlay arrows showing the exact turn to take when you approach a junction or a roundabout.
Menu
Edit Destination menu to navigate to your Home, Office, Hotel, Restaurant etc… with out having to enter the same details over and over again.
Maps
Full colour maps display showing parks, lakes and rivers over view or at street level detail.
Arrive on time. For those hard to find locations, the Navman GPS 4400 is an
indispensable business tool. Sales people on the road, delivery staff, service engineers, any business that regularly needs to send staff to unfamiliar locations, will benefit hugely from the help of a GPS 4400.
And because it is a mobile system, you can easily use it in different vehicles. Which makes it a cost effective solution.
That anyone can use. On any Bluetooth embedded Pocket PC.
Map and Navigation screen Clear Navigation Navigation screen Instruction list
Enjoy Europe. The Navman
GPS 4400 comes complete with road and street level maps of no less than sixteen major Western European countries. Its unique new Map Management feature allows you to load only those maps which are relevant to your current journey, freeing your Pocket PC’s memory for other use and providing faster searching and routing.
Combine this with its unique door to door routing, its automatic map­stitching and Back-on-Track
features, and you have the means to easily and efficiently find your way in
Map selection PC Graphical User Interface
the most remote part of any European country.
Countries Covered
Pan European: United Kingdom Ireland France Germany Italy Belgium Netherlands
Luxembourg Austria Switzerland Portugal Spain Norway Denmark Sweden
(North America optional)
Complete Navigation System
GPS Receiver with Embedded Class 2 Bluetooth ™ Technology
Lanyard for GPS receiver
Armband for GPS receiver
Vehicle windshield mount for GPS receiver
Non-slip adhesive mount for GPS receiver
3 AAA Batteries
Vehicle power cable
Quickstart guide
SmartSTMProfessional Voice Navigation Software
CD-ROM includes: User manual
SmartS Adobe Acrobat Reader
SE software
System Requirements
Your computer system requirements
®
Compatible 486 PC
IBM or higher, Dual Speed CD-ROM or higher, Microsoft Windows®98SE, ME, 2000 or XP, Microsoft
3.5 or higher, internet
®
ActiveSync
®
connection (when installing)
Pocket PC Requirements
20MB RAM for application software,64MB recommended map storage space on handheld (memory card - MMC or SD), Pocket PC 2002 or higher, embedded Bluetooth™ interface.
Important note
Vehicles that have heated or heat reflective windshields may require a re-radiating antenna (not included)
®
Europe
Navman Europe Ltd The Office Building Gatwick Road Manor Royal Crawley West Sussex RH10 9RZ United Kingdom
www.navman-europe.com support@navman-europe.com
Committed to GPS. Navman is one of the largest
manufacturers of GPS systems in the world, providing the highest quality solutions to businesses and consumers alike.
Because we manufacture our own products and design our own software, our navigation systems are reliable, well integrated and offer the very latest
Americas
Navman USA, Inc 18 Pine Street Ext Nashua New Hampshire 03060 United States
www.navmanusa.com support@navmanusa.com
Australasia
Navman Australia Pty. Ltd. Unit 6, 5-13 Parsons St., Rozelle, Sydney NSW 2039
T +61 2 9818 8382 F +61 2 9818 8386
Headquarters
Navman NZ Ltd 13 -17 Kawana Street Northcote,North Shore City Auckland New Zealand
www.navman.com support@navman.com
NAVMAN is a registered trademark of Navman NZ Limited. All rights reserved.
©1993–2003 Navigation Technologies B.V. All rights reserved.
Windows
® is a registered trademark
of Microsoft Corporation. All other trademarks and registrations
are the property of their respective owners.
Copyright©Navman NZ Limited NAVMAN is a registered trademark of Navman NZ Limited.
Smarts™ is a trademark of Navman NZ Limited.
All rights reserved.
advances in cutting edge GPS technology.
