Mustek DV4500, DV5000 User Manual
Digital Video
User Guide
Table of Contents
Getting Started
Getting to Know Your Digital Video...............................................3
Using the Panel....................................................................... 5
Power...................................................................................6
Modes...................................................................................7
DV Mode
Taking Movies........................................................................11
Video Out............................................................................ 12
DSC Mode
Taking Pictures......................................................................1 3
DVR Mode
Recording Voice Messages........................................................ 15
MP3 Mode
Listening To MP3 Music............................................................ 17
PLAYBACK Mode
Basic Playback.......................................................................19
Advanced Playback................................................................. 21
Main Functions
Changing the Quality Setting.....................................................23
Using Self-timer......................................................................25
Using Guide Line/The LCD Display............................................... 26
Using Hold............................................................................ 27
Volume Adjust........................................................................27
Advanced Functions
Attention Icon...................................................................... 28
Menu.................................................................................. 29
En 2
Getting to Know Your Digital Video
Front View
Getting Started
Front LED
Microphone
Back View
Status LED
(Power On/USB)
Shutter
Speaker
LCD Viewfinder Panel
Zoom
Power Button
Lens
Flash Light
S
E
T
En 3
Getting Started
Getting to Know Your Digital Video-continued
Side View
S
E
T
S
E
T
Battery/SD/MMC Cover
SD/MMC card Slot
En 4
USB port
Earphone jack
AV out
Battery Slot
Using the Panel
Display
Menu DV/DSC/DVR/MP3 Mode Switch
Exit/
Stop
Back/Down/Self-timer Volume/Hold(P ress 2 Sec.)
Next/Up/Resolution
Getting Started
Record/
Playback
Mode Switch
Play/Pause/
Enter
En 5
Getting Started
Power
Power On/Off
Nudge the Power slider to activate your
Digital Video. When Power is on, the Power
S
E
T
indicator lights in green. Nudge it again to
turn this Digital Video off.
Power Low
If your battery is low, you will see a battery
icon ( )shown on the top center of the LCD.
If your battery is about to run out, you will see
a blinking battery icon ( ) shown on the top
center of the LCD. Your Digital Video will turn
off itself in several seconds.
En 6
Modes
Getting Started
Power On
USB connected
DV Record Mode
DSC Record Mode
DVR Record Mode
MP3 Mode
PLAYBACK Mode
PC Camera Mode Mass Storage Mode
En 7
Getting Started
Modes-continued
DV Mode/DSC Mode/DVR Mode/MP3 Mode/PLAYBACK Mode
There are four main modes and PLAYBACK mode in this Digital Video.
The four main modes are DV Mode, DSC Mode, DVR Mode and MP3 Mode.
1.DV Mode: take videos with sound
2.DSC Mode: take pictures
3.DVR Mode: record voice messages.
4.MP3 Mode: listen to MP3 music.
You can switch among these four modes by pressing . By pressing
, you can switch to PLAYBACK mode to review your videos, pictures
and voice messages. DV Mode/DSC Mode/DVR mode shares the same
PLAYBACK mode. You can switch back to the previous mode by pressing
again.
En 8
Modes-continued
Connected to PC(Mass Storage Mode/PC Camera Mode)
S
E
T
USB Cable
USB port
Using Console (Not Available for MAC)
By connecting your Digital Video to a computer, the Console opens.
Meanwhile your Digital Video switches to Mass Storage, too. You may
choose either to transfer the camera data through Console program or
through Mass Storage Mode.
Getting Started
En 9
Getting Started
Modes-continued
Mass Storage Mode
Connect your Digital Video to a computer, it will turn to Mass Storage
Mode. In Mass Storage Mode, your Digital Video acts exactly like a hard
disk. That means you can access it via the Windows user interface. You
can copy, move or delete files (pictures, movies, voice messages or MP3
music) exactly the way you manipulate files under Windows user interface.
Note:
1.Please do not copy any files into the DCIM folder of your Digital Video.
Otherwise it may cause Digital Video unstable or crash.
2.Remember to copy the MP3 files into the MP3 folder of your Digital Video.
PC Camera Mode
You can connect this Digital Video to a computer with its supplied USB
cable and use it as a PC camera.
After USB connecting, the screen will show as below.
By pressing , it will turn to PC Camera Mode. With a compatible video
capture program, you can capture movies.
En 10
MENU
MENU
Taking Movies
Taking Your First Movie
1
Press Power
S
E
T
Slide Zoom-in or Zoom-out to frame your picture2
3
Press Shutter to start recording
2
Switch to DV Mode
Zoom in or Zoom out
DV Mode
S
E
T
Press Shutter again to stop
4
En 11
