LBEE6ZZ1PY User Manual
Product Outline
This product has a function as an IEEE802.11 a/b/g/n/ac + BT + BLE
・Product Size ：20.9 x 14.8 x 2.6(max) [mm]
・RF-IC ：Marvell 88W8987 (AEC-Q100 compliant)
・Reference Clock ：38.4MHz X’tal
Feature
・Product Name ：Communication Module
・Model Name ：LBEE6ZZ1PY
・Purpose of the equipment ：Telecommunication
・Equipment Type ：Transceiver
・Frequency ：2412-2462MHz/2402-2480MHz/5180-5320MHz/5500-5720MHz/
5745-5825MHz
・Channel ：(WLAN)1~11ch/36~64ch/100~144ch/149~165ch
(BT)0~78ch (BLE)0~39ch
・Bandwidth ：(WLAN) 2.4GHz 11b(20MHz)/11g(20MHz)/11n (20MHz)
5GHz 11a(20MHz)/11n(20/40MHz)/11ac(20/40/80MHz)
(BT) Hopping off 1MHz/Hopping on 79MHz
(BLE) 2MHz
・Input Voltage to RF parts ：VDD33 Typ.3.3V
CONFIDENTIAL
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
08 April 2019
2
LBEE6ZZ1PY User Manual
FCC ID: VPYLB1PY
The OEM integrator has to be aware not to provide information to the
end user regarding how to install or remove this RF module in the
user’s manual of the end product which integrates this module. The
end user manual shall include all required regulatory
information/warming as shown in User manual.
●Please describe the following warning on the final product which contains this module.
Contains Transmitter Module FCC ID:VPYLB1PY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
If it is difficult to describe this statement on the host product due to the size, please describe in the User's manual.
CONFIDENTIAL
Contains FCC ID: VPYLB1PYor
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
08 April 2019
3
Notice
●The following statements must be described on the user manual of the host device
of this module;
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital
and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the
only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the
packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In
other words, this device automatically discontinue transmission n case of either absence of information to transmit
or operational failure.
Frequency Tolerance: ±20 ppm
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
CONFIDENTIAL
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
08 April 2019
4
Notice
●When installing it in a mobile equipment. Please describe the following warning to the manual.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC
radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least
20cm or more away from person’s body.
●When installing it in a portable equipment. Please describe the following warning to the manual.
The available scientific evidence does not show that any health problems are associated with using low power
wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power
Wireless devices emit low levels of radio frequency energy (RF)in the microwave range while being used. Whereas
high levels of RF can produce health effects (by heating tissue), exposure of low-level RF that does not produce
heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not found
any biological effects. Some studies have suggested that some biological effects might occur, but such findings have
not been confirmed by additional research. LBEE6ZZ1PY has been tested and found to comply with FCC
radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF)
Exposure Guidelines.
It is necessary to take a SAR test with your set mounting this module.
Class II permissive change application is necessary using the SAR report.
Please contact Murata.
Note)
Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm.
Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
CONFIDENTIAL
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
08 April 2019
5
Notice
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter
module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further
transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed
CONFIDENTIAL
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
08 April 2019
6
