Miele W3370 User Manual

Operating instructions

for Washing machine W 3370 Edition 111

To avoid the risk of accidents or damage to the machine it is essential to read these instructions before it is installed and used for the first time.

en-GB

M.-Nr. 09 491 720

Caring for our environment

Disposal of the packing material

The transport and protective packing has been selected from materials which are environmentally friendly for disposal and should be recycled.

Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation!

Disposal of your old machine

Electrical and electronic machines often contain materials which, if handled or disposed of incorrectly, could be potentially hazardous to human health and to the environment. They are, however, essential for the correct functioning of your machine. Please do not therefore dispose of it with your household waste.

Please dispose of it at your local community waste collection / recycling centre or contact your Dealer for advice. Ensure that it presents no danger to children while being stored for disposal.

Contents

Caring for our environment .........................................2

Warning and Safety instructions .....................................6

Operating the washing machine.....................................13

Control panel .....................................................13

Before using for the first time.......................................15

Washing environmentally and economically ..........................16

Energy and water consumption ....................................16

Detergent .....................................................16

Choosing the correct Extra option (Short, Soak, Pre-wash) ...............16

When drying with a tumble dryer ...................................16

How to wash correctly.............................................17

Spinning ........................................................22

Final spin speed ..................................................22

Rinse and interim spin ...........................................22

To omit the final spin (Rinse hold) ..................................22

To omit the spin between rinses and the final spin .....................22

Delay start.......................................................23

Programme chart .................................................24

Extras ..........................................................27

Short............................................................27

Pre-wash ........................................................27

Soak ............................................................27

Water plus .......................................................27

Programme sequence .............................................28

Garment care label symbols ........................................30

Contents

Changing the programme sequence .................................31

Cancelling a programme ............................................31

Interrupting a programme ...........................................31

Making changes to a programme .....................................31

Adding or removing laundry after a programme has started ................32

Detergent .......................................................33

The correct detergent ..............................................33

Water softeners ...................................................35

Washing with several components ....................................35

Fabric conditioners and liquid starch ..................................36

Automatic dispensing of fabric conditioner or liquid starch to laundry at the end

of a programme ................................................36

Adding fabric conditioner or starch separately ........................36

Colour run and dye removers / dyes ...................................36

Cleaning and care ................................................37

Cleaning the drum (Hygiene info) .....................................37

External casing and fascia panel .....................................37

Cleaning the detergent dispenser drawer...............................37

Cleaning the water inlet filters ........................................39

Problem solving guide ............................................40

The programme does not start .......................................40

The wash programme stops and a fault indicator light comes on. ............41

A maintenance light comes on but the wash programme continues as normal.. . 42

General problems .................................................43

An unsatisfactory wash result ........................................44

The drum door does not open when you press the Door button..............45

Opening the drum door in the event of a blocked drain outlet and/or power failure

................................................................46

Blocked drain outlet .............................................46

After sales service ................................................48

Future updates (PC) .............................................48

Guarantee .....................................................48

Optional spare parts and accessories ...............................48

Contents

Installation and connection ........................................49

Front view........................................................49

Rear view ........................................................50

Installation surface.................................................51

Installing the washing machine ....................................51

Removing the transit bars ...........................................51

Re-fitting the transit bars ............................................53

Levelling the machine ..............................................54

Screwing out and adjusting the feet .................................54

Building under a continuous worktop/in a kitchen run ...................55

Washer and Dryer stack ..........................................55

The Miele water protection system ....................................56

Connection to the water supply .......................................57

Connection to the drainage system....................................58

Electrical connection U.K. ...........................................59

Consumption data ................................................60

Notes for test institutes: ..........................................60

Technical data ...................................................61

Programmable functions...........................................62

Water plus system .................................................62

Gentle action .....................................................63

Suds cooling .....................................................64

Memory function ..................................................65

Soak duration.....................................................66

Optional accessories..............................................67

CareCollection ....................................................67

Warning and Safety instructions

This washing machine conforms to current safety requirements. Inappropriate use can, however, lead to personal injury and damage to property.

To avoid the risk of accidents and damage to the washing machine, please read these instructions carefully before using it for the first time. They contain important information on its installation, safety, use and maintenance.

Keep these instructions in a safe place and ensure that new users are familiar with the content. Pass them on to any future owner.

Correct application

This washing machine is not designed for commercial use. It is

intended for use in domestic households and in similar working and residential environments.

The washing machine is not intended for outdoor use.

It must only be used as a domestic appliance to wash items

which are specified by the manufacturer as being washable on the care label. Any other usage is not supported by the manufacturer and could be dangerous. Miele cannot be held liable for damage resulting from incorrect or improper use or operation of the washing machine.

The washing machine can only be used by people with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, if they are supervised whilst using it or have been shown how to use it in a safe way and understand the hazards involved.

Warning and Safety instructions

Safety with children

Children 8 years and older may use, clean or maintain the

washing machine without supervision only if they have been shown how to do so in a safe way and understand the hazards involved.

Children under 8 years of age must be kept away from the

machine unless they are constantly supervised.

The washing machine is not a toy! To prevent the risk of injury, do

not allow children to play with it or near it, or to play with the controls.

For machines with a 'porthole' door, remember that the porthole

glass will be hot when washing at high temperatures Do not let children touch it.

Warning and Safety instructions

Technical safety

Before setting up the washing machine, check it for any externally

visible damage. Do not install or use a damaged washing machine.

Before connecting the washing machine, ensure that the

connection data on the data plate (voltage and frequency) match the mains electricity supply. If in any doubt, consult a qualified electrician.

The electrical safety of this washing machine can only be

guaranteed when correctly earthed. It is most important that this basic safety requirement is observed and regularly tested, and where there is any doubt the household wiring system should be inspected by a qualified electrician. The manufacturer cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).

Do not connect the washing machine to the mains electricity

supply by an extension lead. Extension leads do not guarantee the required safety of the machine (e.g. danger of overheating).

Faulty components must only be replaced by genuine Miele

original spare parts. Only when these parts are fitted can the safety standards of the machine be guaranteed.

Warning and Safety instructions

Unauthorised repairs could result in unforeseen dangers for the

user, for which Miele cannot accept liability. Repairs should only be undertaken by a Miele approved service technician.

If the connection cable is faulty it must only be replaced by a

Miele approved service technician to protect the user from danger.

The machine must be isolated from the electricity supply in the

event of a fault and during installation, maintenance and repair work.

This washing machine must only be connected to the on-site

water supply using a new hose kit. Old hoses must not be re-used.

In areas which may be subject to infestation by cockroaches or

other vermin, pay particular attention to keeping the machine and its surroundings in a clean condition at all times. Any damage which may be caused by cockroaches or other vermin will not be covered by the guarantee.

This machine must not be used in a non-stationary location (e.g.

on a ship).

Do not make any alterations to the washing machine, unless

authorised to do so by Miele.

Warning and Safety instructions

Correct use

Do not install your washing machine in rooms where temperatures

below freezing may occur. Frozen hoses may burst or split. The reliability of the electronic control unit may be impaired at temperatures below freezing point.

Before using the washing machine for the first time, check that

the transit bars at the rear of the machine have been removed (see section on "Installation and connection"). During spinning, a transit bar which is still in place may result in damage to both the machine and adjacent furniture or appliances.

Turn off the stopcock if the machine is to be left for any length of

time (e.g. holiday), especially if there is no floor drain (gully) in the immediate vicinity.

Flooding danger.

If hooking the drain hose into a wash basin, check that the water can drain off quickly enough to prevent the sink from overflowing. Make sure the drain hose is secure, so that the force of the water flowing out of the hose does not dislodge it.

Take care to ensure that foreign objects (e.g. nails, pins, coins,

paper clips) do not find their way into the machine with the laundry. These may damage components of the machine (e.g. suds container, drum), which in turn can result in damage to the laundry.

Warning and Safety instructions

If the correct amount of detergent is dispensed, the machine

should not need to be descaled. If, however, you do wish to descale the machine only use proprietary non-corrosive descaling agents and strictly observe the instructions on the packaging. A special descaling agent is available to order from the Miele Spare Parts Department or via the internet on www.miele-shop.com.

Textiles which have been pre-treated in solvent based cleaning

agents must be thoroughly rinsed in clean water before being washed in the machine.

Do not use solvent based cleaning agents, e.g. those containing

benzine, in this machine, as this may result in damage to component parts and create toxic fumes. Such agents also pose a fire and explosion hazard.

Do not use solvent based cleaning agents, e.g. those containing

benzine, to clean the outside surfaces of this machine. They can cause damage to plastic surfaces.

Only use dyes specified by the manufacturer as being suitable for

use in a domestic washing machine. Always observe the manufacturer's instructions carefully.

Colour run and dye removers contain sulphur compounds which

can cause damage such as corrosion. Do not use these products in this machine.

If detergent comes into contact with the eyes, rinse them

thoroughly with lukewarm water immediately. If swallowed, seek medical assistance immediately and retain the packaging or label for reference. Those with skin problems or sensitive skin should avoid their skin coming into contact with detergent.

Warning and Safety instructions

Accessories

Accessory parts may only be fitted when expressly approved by

Miele. If other parts are used, guarantee, performance and product liability claims will be invalidated.

Miele cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.

Control panel

Operating the washing machine

a Display

See the following page for more information.

b Start button

– For delaying the start of a

programme

– Starts the wash programme

c Extra option buttons

Extra options can be added to the basic programme. Use the top button to select either the Short, Pre-wash,orSoak option. Use the lower button to select the Water plus option. Indicator light on = option selected Indicator light off = option not selected

d Indicator lights for spin speed,

Rinse hold or Without spin.

e Spin button

For selecting the final spin speed, Rinse hold or Without spin.

f Programme selector

For selecting the wash programme and temperature for that programme. The programme selector can be turned clockwise or anti-clockwise.

g Programme sequence indicator

lights

Show which section of the wash programme has been reached.

h Maintenance/check lights

i Button K

For switching the washing machine on and off. To save energy, the washing machine will switch itself off automatically 15 minutes after the end of the programme/anti-crease phase or after being switched on, if no other selection is made.

j Door button

Opens the machine door.

Operating the washing machine

Display

The display shows:

the programme duration (Time left

–

display)

delay start

–

the programmable functions

–

Programme duration

After the start of a programme, the estimated programme duration will appear in the display in hours and minutes.

When delay start is being used, the programme duration will appear after the delay start time has elapsed.

During the first 10 minutes the washing machine measures how much water is being absorbed by the laundry and uses this to calculate the load. The programme duration may be longer or shorter depending on this absorbency rate.

Delay start

The delay start time selected will appear in the display.

After the machine has started, the delay start time counts down. If the delay start time is more than 10 hours, it will count down by the hour. If it is less than 9 hours and 59 minutes it will count down minute by minute.

Once the delay start time has finished, the programme begins and the estimated programme duration shows in the display.

Programmable functions

The programmable functions can be used to tailor washing programmes to suit your individual requirements. In programming mode, the display will show the function selected.

Before using the machine for the first time ensure that it is correctly installed and connected. See "Installation and connection". Also check that the drain filter is securely tightened to prevent the risk of leaks during use.

This washing machine has undergone a complete functional test at the factory and there will be some residual water in the drum from this process.

For safety reasons, spinning is not possible until the machine has been prepared for using for the first time. To activate the spinning function you must run a wash programme without laundry and without detergent.

Before using for the first time

Using detergent could result in an excessive build-up of foam.

This also activates the ball valve. The ball valve prevents detergent escaping from the suds container into the sump during a wash programme, thus making maximum use of the detergent.

Open the stopcock.

Press the K button.

Turn the programme selector to Cottons 60°C.

Press the Start button.

At the end of the programme switch the machine off.

The washing machine is now ready for use.

Washing environmentally and economically

Energy and water consumption

Water consumption and energy

–

usage are determined by the size of the load. To make the most out of your machine, load the maximum dry load for the programme you are using.

When smaller amounts of laundry are

–

washed, the automatic load recognition system will reduce the amount of water, time and energy used. This may mean that the time left shown in the display is adjusted during the course of the wash programme.

– Use the Express 20 programme for

small loads.

– Modern detergents make it possible

to wash at lower temperatures (e.g 20°C). Washing using lower temperature settings will save energy.

– To maintain the hygiene of the

washing machine, carry out a hot wash (60°C or above) using powder detergent at regular intervals. The Hygiene Info maintenance light will remind you to carry out a hot wash.

Detergent

Do not exceed the amounts of

–

detergent recommended by the manufacturer on the packaging.

Adjust the dosage to the degree of

–

soiling of the laundry.

Reduce the amount of detergent with

–

smaller loads (approx.

/3less than the amount recommended can be used when washing a half load).

Choosing the correct Extra option (Short, Soak, Pre-wash)

Select:

– A wash programme together with the

Short extra option for light soiling where there are no obvious marks.

– A wash programme without any extra

options for normal to heavy soiling with visible staining.

– A wash programme together with the

Soak extra option for very heavily soiled laundry.

–

The Pre-wash extra option for laundry with large amounts of dirt (e.g. dust, sand).

When drying with a tumble dryer

Selecting the highest possible spin speed for the wash programme will save energy when drying in a tumble dryer afterwards.

Brief instructions

The headings numbered A, B, C,... show the operating sequence and can be used as brief instructions.

A Sort the laundry

^ Empty all pockets.

Foreign objects (e.g. nails, coins, paper clips, etc.) can cause damage to garments and components in the machine.

Badly soiled areas, stains etc. should be cleaned as soon as possible, preferably whilst still fresh. Spillages should be carefully dabbed off using a soft colourfast cloth. Do not rub!

Badly soiled areas can be pre-treated with liquid detergent, stain removers etc. first, following the manufacturer's instructions. With particularly stubborn stains ask your dry cleaner for advice.

How to wash correctly

If you use a solvent-based

cleaning agent (e.g. one containing benzene) to pre-treat a stain, make sure that any plastic parts (e.g. buttons) are protected, and that the cleaning agent is rinsed off before washing the garment in the machine.

Do not use solvent-based

cleaning agents in or on this machine.

Sort the laundry by colour and by

care label. Most garments have a textile care label in the collar or side seam.

Dark textiles often contain excess dye and should be washed separately several times before being included in a mixed load. Always wash whites and coloureds separately.

– Curtains: Remove lead weights first

or place in a laundry bag.

–

Underwiring and collar stiffeners: Any loose wiring in bras, shirt collar stiffeners, etc. should be removed or sewn in.

–

Knitted garments, trousers and jeans, T-shirts and sweat shirts: Turn inside out, if recommended by the manufacturer.

–

Close any zips, fasten hooks and eyes etc before washing.

–

Fasten duvet covers etc. to prevent small items from being rolled up inside them.

Do not wash any items in this machine which are specified by the manufacturer as not washable on the care label. (h symbol)

How to wash correctly

B Switch on the washing machine

C Load the drum

Press the Door button to open the

drum door.

Unfold the laundry and load loosely

into the drum. Mixing both large and small items gives better wash results and also helps distribute the load evenly during spinning.

The most efficient use of energy and water is achieved when a full load is washed. However, do not overload as this causes creases and reduces cleaning efficiency.

Make sure that items do not get caught between the drum door and the seal.

D Select Delay start (if required)

Make sure that the programme selector is at the , Finish position.

Press the Start button to set the delay

start time.

E Select a programme

^ Turn the programme selector to the

required programme.

If delay start has not been selected, the estimated programme duration will appear in the display.

Shut the door with a gentle swing.

How to wash correctly

F Select any Extra option(s)

Each press of the top button selects the Extra options in the following order: Short, Pre-wash, Soak or no option.

Use the lower button to select the Water plus Extra option.

^ Select the Extra option you require.

Not all Extra options are suitable for use with every programme.

G Select a spin speed

Press the "Spin" button repeatedly

until the indicator light for the spin speed you want comes on.

You can only select Extra options which are compatible with the programme being used.

How to wash correctly

H Add detergent

It is important to dispense the correct amount, because...

. . . too little detergent results in:

Laundry not getting properly clean

–

and and in time becoming grey and hard to the touch.

Greasy particles clinging to the

–

laundry.

Limescale deposits on the heater

–

elements.

. . . too much results in:

– Excessive foam which causes a low

level of agitation and poor wash, rinse and spin results.

– Higher water consumption (an

additional rinse cycle will automatically switch in).

– A burden to the environment.

Pull out the detergent drawer and

place detergent in the compartments as follows:

Detergent for the pre-wash (divide the total recommended amount as follows: add

and

/3to compartment j).

/3to compartment i

Detergent for the main wash, including Soak if selected

Fabric conditioners or liquid starch

Close the detergent drawer.

See "Detergent" for further information.

I Start the programme

Press the flashing Start button.

If a delay start time has been selected, then this will count down in the display. At the end of the delay start time or im mediately after the programme has started (if a delay start time has not been selected) the estimated programme duration will appear in the display. During the first 10 minutes the machine measures how much water is being absorbed by the laundry. The programme duration may be longer or shorter depending on this absorbency rate.

J Unload the drum

When the programme has finished, the Anti-crease/Finish indicator light will come on.

The washing machine will switch off automatically 15 minutes after the end of the anti-crease phase. You will need to press the K button to switch it back on again.

How to wash correctly

Check the folds in the door seal for

any small articles, e.g. buttons, which might be lodged there.

^ Switch the washing machine off with

the K button and turn the programme selector to Finish.

^ Close the drum door. Otherwise there

is the danger of objects being placed inadvertently in the drum. If these remained unnoticed and were washed in the next load, they could damage the laundry.

Press the Door button to open the drum door.

Remove the laundry.

Check that all items have been removed from the drum. Items left in the drum could discolour other items in the next wash or become discoloured themselves.

Spinning

Final spin speed

Programme rpm

Cottons 1400

Minimum iron 1200

Automatic plus 900

Dark garments / Denim 1200

Express 20 1400

Shirts 600 Woollens / 1200

Delicates 600

Drain/Spin 1400

Separate rinse/Starch 1200

You can reduce the final spin speed. However, you cannot select a final spin speed higher than that shown in the chart above.

Rinse and interim spin

There is a spin after the main wash and between the rinses. A reduction in the final spin speed will also reduce the interim spin speed. If a spin speed of less than 700 rpm is selected for a Cottons programme, an additional rinse is introduced.

To omit the final spin (Rinse hold)

Press the "Spin" button repeatedly

until the Rinse hold indicator light comes on. The laundry will not be spun and will remain suspended in the final rinse water. This reduces creasing if the laundry is not going to be removed from the drum immedi ately after the end of the programme.

To start the final spin

–

Use the "Spin" button to select the spin speed you want. The final spin will then begin.

– To end the programme

Press the Door button. The water will drain away. Press the Door button again to open the door.

To omit the spin between rinses and the final spin

^ Press the "Spin" button repeatedly

until the Without spin indicator light comes on. The laundry is not spun after the final rinse. The water will drain away and the machine will go straight into the anti-crease stage. With some programmes an additional rinse is introduced if this setting is selected.

Delay start

With Delay start you can choose when you want the programme to start. The start of a programme can be delayed from 30 minutes up to a maximum of 24 hours, allowing you to make use of night-time economy electricity rates, for example.

To select Delay start

Make sure that the programme selector is at the , Finish position.

The , Delay start indicator will flash in the display.

You can now use the Start button to enter the start time you want.

To alter Delay start

It is not possible to alter the Delay start time after the programme has been selected.

To cancel Delay start

Press the Start button again when 24 ^ is showing in the display.

To cancel Delay start after you have pressed the Start button:

You will have to cancel the programme. See "Changing the programme sequence".

Press the Start button. Each press on the button increases the start time:

–

in 30 minute steps up to 10 hours,

–

in 1 hour steps from 10 hours upwards.

If you keep the Start button pressed in, the time will continue to count up to 24 hours.

Programme chart

Cottons 9876* 30°C to 90°C Max. load 7.0 kg

Use for Cotton, linen or cotton mix fabrics, e.g. table linen, towelling,

underwear, T-shirts etc.

Note The 60°/40°C programmes differ from the r/s programmes

as follows:

Shorter programme duration

–

Longer temperature holding times

–

Higher energy consumption

– Where particularly high levels of hygiene are required please

select a temperature of 60°C or higher.

Cottons r/s Max. load 7.0 kg

Use for Normally soiled cotton garments

Note – These settings are the most efficient in terms of energy and

water consumption for washing cottons.

– With r the actual wash temperature reached will be lower

than 60°C although the wash performance is the same as with the standard Cottons 60°C programme.

Note for test institutes:

The test programme conforms to EN 60456 and the energy label with Directive 1061/2010.

Minimum iron 43218E76*

Use for Synthetic, mixed fibre and easy care cotton. If fabrics have a high

proportion of man-made fibres it is advisable to programme the machine for "Gentle action".

Note Reduce the spin speed for fabrics which crease easily.

Automatic plus 72* 40°C Max. load 5.0 kg

Use for Mixed loads of garments suitable for the Cottons and Minimum

iron programmes. Sort according to colour.

Note The wash parameters (e.g. water level, wash rhythm and spin

speed) are adjusted automatically in this programme to ensure the best possible care and wash result for each item.

20°C to 60°C Max. load 3.5 kg

Programme chart

Dark garments / Denim 40°C Max. load 3.0 kg

Use for Black and dark garments made from cotton, mixed fibre or denim.

Notes

Express 20 7* 40°C Max. load 3.0 kg

Use for Cotton and minimum iron garments that have hardly been worn or

Note The Short extra option will be activated automatically.

Shirts 40°C Max. load 2.0 kg

Notes – Pre-treat collars and cuffs if necessary.

Woollens /c* cold to 30°C Max. load 2.0 kg

Use for Machine-washable or hand-washable wool or wool blend fabrics.

Note Reduce the spin speed for items which crease easily.

Delicates 21ac* cold to 40°C Max. load 2.0 kg

Use for Delicate garments made from synthetic fibre, mixed fibre, rayon

Note

Wash inside out.

–

Denim often contains excess dye and may run during the first

–

few washes. Wash light and dark coloured items separately.

are only very lightly soiled.

– Wash silk garments in the Silks programme.

If the care label does not specify a temperature, wash using the cold setting.

and easy care cotton. Curtains, including net curtains, specified as machine-washable

by the manufacturer.

–

Dust in curtains usually makes using a programme with pre-wash advisable.

–

Deselect the spin for items which crease easily.

* Please note that the "buckets" represent garment care label symbols. See

"Garment care label symbols".

Programme chart

Drain/Spin

Notes

Separate rinse/Starch Max. load 7.0 kg

Use for

Notes

Drain only: Select Without spin.

–

Make sure you select the appropriate spin speed.

–

Rinsing hand-washed items.

–

Starching table cloths, serviettes and workwear

–

Reduce the spin speed for fabrics which crease easily.

–

Items for starching should be freshly laundered but not treated

–

with fabric conditioner. You can achieve a particularly good rinse result with two rinses

–

by activating the Water plus extra option. For this, option P3 or P4 of the Water plus system programmable function must be activated (see "Programmable functions" at the end of this booklet).

Extras

You can use the extra option buttons to augment the basic wash programmes.

Short

For light to normal soiling with no visible staining.

This shortens the programme running time.

Pre-wash

For laundry with large amounts of dirt e.g. dust, sand.

Soak

For heavily soiled and stained items with protein stains (e.g. blood, fats and oils, cocoa).

– A length of time of between 30

minutes and 2 hours can be programmed in 30 minute increments for the soak process.

– The default setting is 2 hours.

To programme in a different soak period see "Programmable functions – Soak".

Water plus

The water level in the main wash and the rinses will be increased.

You can select other settings for Water plus. These are described in "Programmable functions".

The following extra options can be selected in addition to the programme:

Only one of the following can be selected at a time: Short, Pre-wash or Soak.

Short

Pre-wash

Soak

Water plus

Cottons XXXX

Minimum iron XXXX

Automatic plus

Dark garments / Denim

Express 20 X

Shirts X X X

Woollens !

Delicates X X X

Drain/Spin

Separate rinse/ Starch

X1)This extra option is activated

automatically as part of the programme.

XXX

Programme sequence

Main wash Rinses Spinning

Water

level

Cottons d a ( 2-4 Minimum iron ( c e 2-3 Automatic plus ( abc e 2-3

Wash

rhythm

Water

level

Rinses Interim

1)2)

Final

spin

Dark garments /

( b d 3 – L

Denim Express 20 d b d 1-3

Shirts e c e 2 – L Woollens /ef e 2 LL Delicates e d e 3 – L

Drain/Spin – – –––L Separate rinse/Starch – – e 1 – L

Please see next page for description of the symbols

Programme sequence

d = Low water level ( = Medium water level e = High water level

a = Intensive rhythm

b = Normal rhythm

c = Gentle rhythm

d = Sensitive rhythm

e = Ultra sensitive rhythm

f = Handwash rhythm

This machine has fully electronic controls with automatic load recognition. It takes in the right amount of water required for the programme depending on the amount of laundry and its absorbency rate. This means that programme cycles and durations can vary.

The programme sequences outlined in the chart are based on the basic programme with a full load. Extra options which can be selected have not been taken into account.

Special features in the programme sequences:

Anti-crease:

At the end of the programme, the drum continues to turn at intervals for up to 30 minutes to help prevent creasing. Exception

: There is no anti-crease phase in the Woollens programme. The door can be opened and laundry removed at any time during the anti-crease phase.

A second rinse is carried out when a temperature of 60°C to 90°C has been selected. A third rinse is carried out when a temperature below 60°C is selected.

An third or fourth rinse is carried out if:

– there is too much foam in the drum

– a spin speed lower than 700 rpm has

been selected

– Without spin has been selected

A third rinse is carried out if:

The display shows the stage the programme has reached.

Without spin has been selected

Garment care label symbols

Washing

The figure quoted in the bucket is the maximum temperature the garment can be washed at. The number of bars under the symbol indicates the level of agitation permitted.

9 No bar under the symbol: =

normal agitation

4 One bar under the symbol: =

reduced agitation

c Two bars under the symbol: =

much reduced agitation

/ Hand wash (if no temperature

is specified use the lowest temperature or cold)

h Do not wash

Drying

The number of dots indicates the drying temperature

q Normal temperature r Low temperature s Do not tumble dry

Ironing

The number of dots indicates the ironing temperature

I Hot iron (max sole plate temp.

approx. 200°C)

H Medium hot iron (max sole

plate temp. approx. 150°C)

G Cool iron (max sole plate

temp. approx. 110°C). Do not steam iron garments carrying this symbol.

J Do not iron

Professional cleaning

f Dry clean only. The letters

indicate the type of cleaning

agent required.

w Professional Wet Clean only D Do not dry clean

Bleaching

x Any oxidising bleaching

agent can be used

{ Only use an oxygen based

bleach or a non-chlorine bleach

z Do not bleach

Changing the programme sequence

Cancelling a programme

You can cancel a programme at any time after it has started.

Turn the programme selector to ,

Finish.

The programme has been cancelled when the Anti-crease/Finish indicator light comes on.

If you want to select a different programme:

Switch the washing machine off and

then back on again with the K button.

^ Check that there is still detergent in

the detergent drawer. Add detergent, if necessary.

^ Select and start a new programme.

If you want to remove the laundry:

^ Turn the programme selector to

Drain/Spin. Make sure the spin speed is appropriate for the laundry.

Making changes to a programme

After the start of a programme it is no longer possible to select a different programme.

Temperature

It is possible to select a different temperature up to 6 minutes after the programme has started.

Spin speed

It is possible to change the spin speed at any time.

Extra options

It is possible to select or deselect the Water plus Extra option up to 6 minutes after the programme has started.

Press the Start button.

The suds will be pumped away.

Press the Door button.

Interrupting a programme

Switch the machine off with the K button.

To continue with the same programme:

Switch the machine on with the K button.

Changing the programme sequence

Adding or removing laundry after a programme has started

Press the Door button in until the

drum door springs open.

Add or remove items.

Close the door.

The programme will continue automatically.

Please note:

Once a programme has started the machine cannot recognise any adjustment to the load.

For this reason, if laundry is added or removed after the start of a programme, the machine will always complete the programme cycle assuming a full load which can lead to an increase in the programme duration shown in the display.

The door cannot be opened, if:

–

the suds temperature is above 55°C.

–

the water is above a certain level.

–

the programme has reached the Final spin stage.

Detergent

The correct detergent

All modern detergents produced for automatic washing machines are suitable. Use dispensing aids, e.g. balls, if these are supplied with the detergent. Tablets are suitable for full loads, but note that it may be impractical to reduce tablets for smaller loads. Some tablets do not dissolve as rapidly as others, and may not be suitable for programmes with short durations.

Do not use biological detergents on silk as the enzymes may damage the silk! Instructions for use and recommended dosage amounts are given on the detergent packaging.

See "Optional accessories" at the end of this booklet for details of Miele branded care products including detergents and fabric conditioner.

Detergent

Universal

detergent

Detergent

for

coloureds

Detergent

for

delicates

Specialist

detergent*

Proofing

agent**

Fabric

conditioner

Cottons X X – – – X

Minimum iron X X – – – X

Automatic plus X X – – – X

Dark garments /

Denim

Express 20

XXX ––X

XX– ––X

Shirts X X – – – X Woollens / –––X–X

Delicates X X X – – X

Drain/Spin – – – – – –

Separate rinse/

–––X–X

Starch

Liquid detergent For programmes with a pre-wash you will need to purchase a special container from the Miele Spare Parts Department which sits in the main wash compartment j. Add liquid detergent to this container for the main wash and to compartment i for the pre-wash

Use powder detergent

* Specialist detergent

Detergent designed specifically for the wash programme or type of fabric.

** Only use proofing agents containing fluorochemical compounds which are

stated by the manufacturer as being "suitable for use on membrane textiles". Do not use proofing agents which contain paraffin. Add proofing agents to compartment §.

Detergent

The right amount to dispense will depend on the following:

The quantity of laundry.

–

The soiling level of the laundry.

–

Lightly soiled No visible dirt or stains. Possibly slight body odour.

Normally soiled Visibly dirty and/or just a few slight stains.

Heavily soiled Visible dirt and stains and/or dried on soiling.

– The water hardness level.

Check with your local water supplier if you do not know the hardness level in your area.

Water hardness levels

Hardness

scale

I (soft) 0 - 1.5 0 - 8.4

II (medium) 1.5 - 2.5 8.4 - 14

III (hard) Above 2.5 Above 14

Hardness level

mmol/l

German

°d

Refill packs of detergent

When purchasing detergent buy refill packs wherever possible. This helps reduce the amount of waste packaging.

Water softeners

A water softener can be used to cut down on the use of detergents in hard water areas. Dispense according to the amount specified on the packaging. First add detergent and then the water softener.

Miele branded water softening tablets are available from the Miele Spare Parts Department or via the internet at www.miele-shop.com

Use a quantity of detergent as for soft water.

Washing with several components

If you wash using several components (e.g. special application detergents), we recommend always dispensing the agents into compartment j in the following order:

1. Detergent

2. Water softener

3. Stain remover

This way the agents are distributed more evenly.

Detergent

Fabric conditioners and liquid starch

Fabric conditioners make garments soft to handle and help prevent static cling when tumble drying.

Starch stiffens and gives body to items of laundry, e.g. shirts, tablecloths and bed linen.

Automatic dispensing of fabric conditioner or liquid starch to laundry at the end of a programme

If starching frequently, the dispenser compartment and especially the siphon tube and fabric conditioner channel will need regular cleaning to remove any residual starch. See "Cleaning the detergent dispenser drawer". Do not add powder starch formulations or viscous liquid starch to the § compartment as it will clog up. See below.

Adding fabric conditioner or starch separately

^ Dispense in accordance with

manufacturer's instructions on the packaging.

^ Add powder or viscous starch to

compartment i.

^ Add the fabric conditioner or liquid

starch to compartment §.

Add the fabric conditioner or liquid starch to compartment §. Do not

exceed the maximum level mark.

It will be automatically dispensed in the last rinse. At the end of the programme a small amount of water remains in the fabric conditioner compartment §.

^ Turn the programme selector to

Separate rinse/Starch

Select a spin speed.

Press the Start button.

Colour run and dye removers / dyes

Do not use removers in this washing machine.

Dyes suitable for use in domestic washing machines can be used. However, please note that the salt used in the dyeing process can cause corrosion to stainless steel components in the machine if you dye frequently. Always observe the manufacturer's instructions carefully.

colour run or dye

A range of Miele branded cleaning agents and conditioning products is available to order from the Miele Spare parts department or online at www.miele.co.uk

Cleaning the drum (Hygiene info)

Washing at low temperatures and/or using liquid detergent can cause bacteria and unpleasant odours to build up in the machine. In order to clean the drum and also to prevent unpleasant odours building up, run a wash programme of at least 60°C with powder detergent once a month or when the Hygiene info maintenance light comes on.

External casing and fascia panel

Cleaning and care

Do not use solvents, abrasive

cleaners, glass cleaners or multi-purpose cleaning agents. These could damage plastic surfaces and other parts.

Cleaning the detergent dispenser drawer

The pre-wash and main wash compartments of the detergent dispensing drawer are self-cleaning. For hygiene reasons, clean the entire drawer at regular intervals.

Disconnect the machine from the mains electricity supply and withdraw the plug from the socket before cleaning the machine.

The machine must not be hosed down.

Clean the casing using a Miele E-cloth or with a mild non-abrasive cleaning agent or soap and water using a well wrung-out cloth. Wipe dry with a soft cloth.

The drum can be cleaned with a proprietary stainless steel cleaning agent, following the manufacturer's instructions on the packaging.

Pull out the detergent dispenser drawer until a resistance is felt. Press down the release catch and at the same time pull the drawer right out of the machine.

Clean the drawer with hot water.

Cleaning and care

Clean the siphon.

Cleaning the detergent dispenser drawer housing

1. Remove the siphon from

compartment § and rinse under hot running water. Clean the siphon tube in the same way.

2. Replace the siphon.

If starching frequently, thoroughly clean the siphon and siphon tube regularly. A build-up of liquid starch will cause them to get clogged.

^ Use a bottle brush to remove

detergent residues and limescale from the jets inside the detergent dispenser drawer housing.

Cleaning and care

Cleaning the water inlet filters

The washing machine has two filters to protect the inlet valves.

These filters should be checked every six months or so, or more often if there are frequent interruptions to the water supply.

To clean the filter in the union in the open end of the inlet hose:

First turn off the stopcock.

Unscrew the inlet hose from the

stopcock.

To clean the filter in the water inlet valve:

Using pliers, carefully loosen the

ribbed plastic nut on the inlet valve and unscrew.

^ Use pointed nose pliers to withdraw

the plastic filter by the bar (see illustration). Clean, put back and secure.

The two filters must be put back in place after cleaning.

Remove rubber seal 1 from the recess.

Using pointed pliers, take hold of plastic filter bar 2, remove the filter and clean it.

Put the filter and seal back in the reverse order and reconnect the hose.

Turn on the stopcock and check the connection is watertight. If it leaks, tighten the connection.

Problem solving guide

With the help of the following notes, minor faults in the performance of the appliance, some of which may result from incorrect operation, can be put right without contacting the Service Department.

Repair work to electrical appliances should only be carried out by a

suitably qualified person in strict accordance with current local and national safety regulations. Repairs and other work by unqualified persons could be dangerous. The manufacturer cannot be held liable for unauthorised work.

The programme does not start

Problem Possible cause Remedy

The Anti-crease/Finish indicator light is not on, or the indicator light for the Start button is not flashing.

There is no power to the machine.

The washing machine has turned itself off automatically to save energy.

Check whether – the mains plug is

plugged in and switched on.

– the fuse or circuit breaker

has tripped.

– the drum door is closed

properly.

Switch the machine back on again with the K button.

Problem solving guide

The wash programme stops and a fault indicator light comes on.

Problem Possible cause Remedy A

The Check drain light flashes and "– – –" appears in the display.

The Check inlet light flashes and "– – –" appears in the display.

The Check inlet and Check drain lights are flashing and "– – –" appears in the display.

The Soak/Pre-wash or Rinses indicator light is flashing and "– – –" appears in the display.

The water outlet is blocked.

The drain hose has been fixed too high.

The water inlet is blocked.

The filter in the water inlet hose is dirty

The water protection system has reacted.

There is a fault. Start the programme again. If

Clean the drain filter and the drain pump as described in "Problem solving guide – Opening the drum door in the event of a blocked water outlet and/or a power failure".

The maximum delivery head is1m.

Open the stopcock.

Clean the filter.

Call Miele Service.

the fault indicator occurs again, contact Miele Service.

A To switch off the fault indicator: Switch the washing machine off with the K

button and turn the programme selector to Finish.

Problem solving guide

A maintenance light comes on but the wash programme continues as normal.

Problem Possible cause Remedy A

The Hygiene Info maintenance light comes on.

The Excess detergent maintenance light comes on.

The Main wash or Rinse indicator light is flashing in the programme sequence display.

The Anti-crease / Finish indicator light flashes in the programme sequence display.

A programme using a temperature above 60°C has not been run for a long time.

Excessive foam has built up during washing.

The washing machine has encountered a fault during the wash programme.

The position of the programme selector was altered after the start of the programme. Turn the programme selector back to the programme previously chosen.

In order to prevent bacteria and unpleasant odours building up in the machine, run a Cottons 90°C programme using powder detergent.

Use less detergent next time and follow the manufacturer's instructions on dosage given on the packaging.

Start the programme again. If the fault indicator occurs again, contact Miele Service.

A To switch off the fault indicator: Switch the washing machine off with the K

button and turn the programme selector to Finish.

The maintenance lights come on at the end of the programme and when the washing machine is switched on.

General problems

Problem Possible cause Remedy

The machine shakes during the spin cycle.

The laundry has not been spun properly and is still wet.

The laundry has not been spun satisfactorily.

The pump makes strange noises.

Large amounts of detergent residue remain in the detergent dispenser drawer.

Fabric conditioner is not completely dispensed or too much water remains in the § compartment.

When laundry is dry it feels hard to the touch.

Problem solving guide

The machine feet are not level.

The machine detected an imbalance during the final spin and reduced the spin speed automatically.

The spin speed selected was too low.

This is not a fault. These noises occur at the end of a pump sequence as a normal part of the operation.

The water pressure is too low.

Powder detergent used with water softeners can become sticky.

The siphon tube is not correctly positioned or is clogged up.

Too vigorous wash action.

Not enough detergent used.

No fabric conditioner. Use fabric conditioner in

Level the machine (see "Installation and connection").

Include both large and small items in the load as this will give better distribution during spinning.

Select a higher spin speed next time.

– Clean the filter in the

water inlet.

– Select Water plus.

– Clean the detergent

drawer.

– Add washing powder and

then add the water softener.

Clean the siphon (see "Cleaning and care Cleaning the detergent dispenser drawer").

Programme in gentle action and more water.

Increase detergent dose to prevent limescale build up in laundry.

last rinse.

Problem solving guide

An unsatisfactory wash result

Problem Possible cause Remedy

Liquid detergent does not give the required result.

Grey, greasy particles cling to washed laundry.

White residues which look like powder detergent are seen on dark textiles after washing.

Liquid detergents usually contain no bleaching agents. They do not remove fruit, coffee and tea stains.

Insufficient amounts of detergent were used to break down the particles of grease in heavily soiled laundry.

The detergent contained compounds (zeolites) to aid water softening which are not soluble in water. They have ended up on the laundry.

Use a general purpose

–

detergent containing a bleaching agent.

Add stain removers into

–

compartment j of the detergent dispenser drawer and liquid detergent into a dispenser ball.

Never put stain removers

–

and liquid detergent together in the dispenser drawer.

– Use more detergent. – Before washing the next load

run a Cottons programme at 60°C or above with powder detergent but without a load.

– Try and brush off the

residues with a soft brush once the laundry is dry.

–

Wash dark textiles using a detergent which contains no zeolites. Liquid detergents usually contain no zeolites.

–

Use the Dark garments / Denim programme for dark coloured laundry.

Problem solving guide

The drum door does not open when you press the Door button

Possible cause Remedy

The washing machine is not connected to the electricity supply and/or is not switched on.

Power cut. Open the drum door as described in "Opening the

The door was not correctly engaged.

There is still water in the drum and the machine is unable to drain.

For safety reasons the drum door cannot be opened if the suds temperature is higher than 55°C.

Insert the plug in the socket and switch on and / or switch the machine on with the K button.

drum door in the event of a blocked drain outlet and/or power failure".

Press hard against the lock side of the drum door and then press the Door button.

Clean the drain filter and the drain pump.

Problem solving guide

Opening the drum door in the event of a blocked drain outlet and/or power failure

Switch the washing machine off.

There is a lever behind the detergent drawer fascia panel.

^ Remove the lever.

Caution: if laundry has been

washed at a high temperature, water draining out of the machine will still be hot. Danger of scalding!

Procedure for draining the machine

Be careful not to release too much water at once. If the flow of water is too strong, some water can seep into the washing machine base and activate the water protection system float switch. This will prevent the washing machine from functioning.

Use it to open the access flap.

Blocked drain outlet

If the drain outlet is blocked, up to 25 litres of water will be retained in the machine.

Place a suitable container under the access flap.

When draining water from the machine, do not unscrew the drain filter completely or take it right out.

Slowly and carefully unscrew the drain filter to let the water out.

If you need to interrupt the flow of water:

Tighten the drain filter back up again.

Once the flow of water ceases:

Remove the drain filter completely.

^ Clean it thoroughly.

Problem solving guide

Make sure the drain filter is

securely tightened. Otherwise there is a risk of water leakage during use.

To avoid loss of detergent, pour approx. 2 litres of water into the detergent dispenser drawer after cleaning the drain filter. Excess water will be pumped out automatically before the next wash programme.

Opening the drum door

Always make sure that the drum

is stationary before reaching into the machine to remove laundry. Reaching into a moving drum is extremely dangerous.

Remove any foreign objects (e.g. buttons, coins, etc.) and fluff from the filter housing. Turn the impeller by hand to check that it rotates freely. Any foreign object causing an obstruction should be removed.

Put the drain filter back in place and secure.

Pull the emergency release downwards (see illustration). The drum door will open.

After sales service

In the event of any faults which you cannot remedy yourself, please contact:

your Miele Dealer or

–

Miele (see back cover for contact

–

details).

When contacting your Dealer or Miele, please quote the model and serial number of your machine, both of which are shown on the data plate visible above the porthole glass when the door is open.

Future updates (PC)

The indicator light marked PC is the interface used by Miele service technicians during servicing work for testing purposes and for updating the machine's programme data.

Guarantee

For information on the appliance guarantee specific to your country please contact Miele. See back cover for contact details.

In the U.K. your appliance is guaranteed for 2 years from the date of purchase. However, you must activate your cover by calling 0845 365 6640 or registering online at www.miele.co.uk.

Optional spare parts and accessories

Optional spare parts and accessories for this washing machine are available from your Miele Dealer, the Miele Spare Parts Department or via the internet at www.miele-shop.com.

N.B. A call-out charge will be applied for service visits where the problem could have been resolved as described in these instructions.

Please note that telephone calls may be monitored and recorded for training purposes.

Front view

Installation and connection

a Inlet hose (tested to withstand

pressure of at least 7,000 kPa)

b Electricity supply cable

c - f Flexible drain hose (with

detachable swivel elbow)

g Control panel

h Detergent dispenser drawer

i Drum door

j Access to drain filter, drain pump

and emergency release

k Handle recesses for moving the

machine

l Four height adjustable feet

Installation and connection

Rear view

a Protruding lid for holding when

moving the machine

b Electricity supply cable

c Inlet hose (tested to withstand

pressure of at least 7,000 kPa)

d Drain hose

e Transit bar covers

f Restraining clip for inlet hose and

drain hose

g Restraining clips for transit bars

when removed

Installation and connection

Installation surface

A concrete floor is the most suitable installation surface for a washing machine, being far less prone to vibration during the spin cycle than wooden floorboards or a carpeted surface.

Please note the following points:

The machine must be level and

securely positioned.

To avoid vibrations during spinning,

the machine should not be installed on soft floor coverings.

If installing on a wooden joist floor:

^ We recommend a plywood base

(at least 59x52x3 cm). The base should span several joists and be bolted to the joists and not only to the floorboards. Check for the presence of pipes and cables.

If possible, install the machine in a corner, as this is usually the most stable part of the floor.

Installing the washing machine

To manoeuvre the machine out of its packing case to its installation site hold it by the edge of the lid where it protrudes to the rear of the washing machine as well as by the handle recesses at the front.

Ensure that the machine feet and

the floor are dry to prevent the machine from slipping during the spin cycle.

Removing the transit bars

If the machine is installed on a raised plinth, it has to be secured against slippage during spinning using retaining clips (available from the Miele Spare Parts Dept). Otherwise there is a danger of the machine moving and falling off the plinth.

To remove the left and right covers

1. Use a screwdriver to prise out the

cover as illustrated.

2. Pull the cover forwards to remove.

Installation and connection

Using the spanner supplied turn the

left-hand transit bar 90°, then

withdraw the transit bar.

Turn the right-hand transit bar 90°,

then

withdraw the transit bar.

To avoid the risk of injury the

holes for the transit bars must be covered after the transit bars have been removed.

^ Fit the covers on to the two holes.

Then plug the holes as shown with the caps.

Installation and connection

Secure the transit bars to the back of

the washing machine. Make sure that holes b are fitted over retainers a.

The washing machine must not

be moved without the transit bars in place. Store them as shown or keep them in a safe place for future use. They must be re-fitted if the machine is to be moved again (e.g.when moving house).

Re-fitting the transit bars

Re-fitting is carried out by reversing the procedure.

Installation and connection

Levelling the machine

The machine must stand perfectly level on all four feet to ensure safe and proper operation.

Incorrect installation may increase electricity and water consumption and may cause the machine to move about.

Screwing out and adjusting the feet

The four adjustable screw feet are used to level the machine. All four feet are screwed in when the machine is delivered.

Use a spirit level to check the

machine is standing level.

^ Hold foot 1 securely with a pipe

wrench. Turn counternut 2 again using the spanner supplied until it sits firmly up against the housing.

All four counternuts must be firmly up against the housing. Please also check this for the feet which did not need adjustment. Otherwise there is the danger of the machine moving about.

Using the spanner supplied turn counternut 2 in a clockwise direction. Then turn counternut 2 together with foot 1 to unscrew.

The fitting of building-under kits* and stacking kits* must only be undertaken by qualified and competent persons, in accordance with the instructions supplied with the kit.

Building under a continuous worktop/in a kitchen run

If you wish to push your machine under a worktop and there is space to do this without removing the lid, the conversion kit is not necessary. Otherwise the conversion kit is essential.

– A special building-under conversion

kit* is required. To ensure electrical safety, the washing machine lid must be replaced by the cover plate supplied with the conversion kit.

Installation and connection

Washer and Dryer stack

A Miele tumble dryer can be stacked with the washing machine. A "WTV" stacking kit* is necessary.

Please note:

– For installation under a work surface

900/910 mm from the floor, a raising kit* is required.

–

Connections for electricity, water and drainage should be installed in such a way that they remain accessible when the machine is in place.

Fitting instructions are supplied with the conversion kit.

All parts marked* are available from your Dealer, the Miele Spare Parts Department or via the internet at www.miele-shop.com.

a Safety distance to wall:

at least 2 cm

b Height:

Stacking kit with pull-out shelf: approx. 169 cm Stacking kit without pull-out shelf: approx. 170 cm

Installation and connection

The Miele water protection system

The Miele water protection system protects the washing machine from water damage.

The system consists of three main components:

1) the inlet hose

2) the electronic unit and the washing machine housing

3) the drain hose

1) Inlet hose

The inlet hose is tested to withstand pressure of more than 7,000 kPa.

2) Electronic unit and washing machine housing

– Sump

Overflow protection

–

This prevents the washing machine taking in too much water. If the water level exceeds a certain level, the drain pump switches in and pumps the excess water away.

3) Drain hose

The drain hose is protected by a ventilation system which prevents the washing machine from being emptied completely.

Any leaking water is collected in a sump in the base of the machine. A float switches off the safety valves, preventing any more water flowing into the machine and water in the suds container is pumped away.

Connection to the water supply

The machine should be connected to a mains water supply in accordance with local and national safety regulations. The German authorities do not require it to have a non-return valve as the washing machine has been designed to comply with DIN regulations.

The machine is designed to operate with a flow pressure of between 100 kPa and 1,000 kPa. If it is higher than 1,000 kPa it is essential to fit a pressure reducing valve.

Connection to the mains water supply should incorporate a mains stopcock

with

/4" thread. The stopcock should

be fitted by a qualified plumber.

The connection point is subject to mains water pressure. Turn on the stopcock slowly and check for leaks. Correct the position of the washer and union if appropriate.

Installation and connection

In order to protect the water inlet valve, the two dirt filters - one in the open end of the inlet hose, one at the inlet point in the machine - must not be removed.

Extension hose

Longer hoses 2.5 or 4.0 m in length

–

are available from your Miele dealer or the Miele Spare Parts Department as optional extras.

The washing machine is not suitable for connection to a hot water supply.

Maintenance and care

Only use a genuine Miele hose should you ever need a replacement or extension. These are tested to withstand pressure of at least 7,000 kPa.

Installation and connection

Connection to the drainage system

The machine drains via a drain pump with a delivery head of 1 metre*. The drain hose must not be kinked as this restricts drainage. The swivel elbow at the end of the hose can be turned in either direction, or can be detached if required, with a sharp twist and pull.

If required, the drain hose can be extended to a length of 5 m. The necessary parts can purchased from the Miele Spare Parts Department or your Miele dealer.

* For a delivery head of more than 1 m (up to a max. of 1.8 m) a replacement drain pump will need to be fitted. Please contact the Miele Spare Parts Department or your Miele Dealer.

Drain hose connection:

1. Direct into a sink or basin:

Please note the following:

–

Hook the hose over the edge and secure.

Please note:

a Adapter

b Nut

c Hose clip

d End of the hose

^ Fit adapter a to the sink drain outlet

using nut b.

^ Attach the end of the hose d to

adapter a.

Use a screwdriver to tighten hose clip c up close to the nut.

–

Make sure that the water can drain away freely without hindrance. Otherwise there is a risk of water overflowing or of some of the drained water being sucked back into the machine.

2. Connected securely to a plastic

drain pipe with a rubber nipple. There is no need to use a non-return valve.

3. Connected securely to a standpipe.

4. Connected securely to a floor gully.

Installation and connection

Electrical connection U.K.

All electrical work should be carried out by a suitably qualified and competent person, in strict accordance with current national and local safety regulations (BS 7671 in the UK).

Ensure power is not supplied to the appliance until after installation work has been carried out.

The appliance is supplied with a mains cable with moulded plug ready for connection to a 230-240V mains supply.

Please ensure the connection data quoted on the data plate match the household mains supply.

Connection should be made via a suitable switched socket which is easily accessible after installation.

For extra safety it is advisable to protect the machine with a suitable residual current device (RCD). Contact a qualified electrician for advice.

Non-rewireable plugs BS 1363

The fuse cover must be refitted when changing the fuse, and if the fuse cover is lost, the plug must not be used until a suitable replacement is obtained. The colour of the correct replacement cover is that of the coloured insert in the base of the plug, or the colour that is embossed in words on the base of the plug (as applicable to the design of plug fitted).

Replacement fuses should be ASTA approved to BS 1362 and have the correct rating. Replacement fuses and fuse covers may be purchased from your local electrical supplier.

WARNING: THIS APPLIANCE MUST BE EARTHED

Do not connect via an extension lead. Extension leads do not guarantee the required safety of the appliance (e.g. danger of overheating).

Consumption data

Load Consumption data

Energy Water Duration Residual

in kWh in litres

Cottons 90°C 7.0 kg 2.20 52 2 h 29 min 52%

60°C 7.0 kg 1.33 52 1 h 59 min 52%

60°C 3.5 kg 1.00 45 1 h 59 min 52%

r* 7.0 kg 0.95 52

r* 3.5 kg 0.82 45 2 h 59 min 52%

40°C 7.0 kg 0.84 67 2 h 29 min 52%

40°C 3.5 kg 0.73 45 2 h 29 min 52%

s 7.0 kg

s* 3.5 kg 0.58 45 2 h 59 min 52%

Minimum iron 40°C 3.5 kg 0.56 50 1 h 52 min 30%

Automatic plus 40°C 5.0 kg 0.52 62 1 h 29 min –

Dark garments / Denim 40°C 3.0 kg 0.60 52 1 h 12 min –

Express 20 40°C 3.0 kg 0.32 30 20 min –

Shirts 60°C 2.0 kg 0.95 59 1 h 11 min – Woollens / 30°C 2.0 kg 0.23 39 39 min –

Delicates 30°C 2.0 kg 0.35 69 59 min –

2h59min

moisture

52%

Notes for test institutes:

* The test programme conforms to EN 60456 and the energy label with

Directive 1061/2010.

Consumption data can vary from the nominal values given depending on water pressure, water hardness, water inlet temperature, room temperature, type and volume of load, fluctuations in the electricity supply and any extra options selected.

Technical data

Height 850 mm

Width 595 mm

Depth 580 mm

Depth with door open 975 mm

Height for building under 820 mm

Width for building under 600 mm

Depth for building under 600 mm

Weight 98 kg

Capacity 7 kg dry laundry

Voltage see data plate

Connected load see data plate

Fuse rating see data plate / plug

Consumption data see "Consumption data"

Water flow pressure minimum 100 kPa (1 bar)

Water flow pressure maximum 1000 kPa (10 bar)

Inlet hose length 1.60 m

Drain hose length 1.50 m

Mains connection cable length 1.60 m

Delivery head max. 1.00 m

Maximum drainage length 5.00 m

Test certificates awarded see data plate

Power consumption when switched off 0.3 W

Power consumption when not switched off

2.0 W

Programmable functions

The programmable functions can be used to tailor washing programmes to suit your individual requirements. Programmable functions can be altered at any time.

The programmable functions are accessed via the Start button and the programme selector.

Water plus system

This setting is used to specify one of three options for the Water plus button.

P2: (Factory default) The water level is increased in the wash and rinse stages.

P3: An extra rinse is carried out.

P4: The water intake is increased in the wash and rinse stages and an extra rinse is carried out.

Follow steps A to G to programme and store in memory.

Before you begin, ensure that:

The washing machine is switched off.

–

The machine door is closed properly.

–

The programme selector is at Finish.

–

A Press the Start button and keep it

pressed in whilst carrying out steps

B-C.

B Switch the machine on with the K

button.

C Wait until the indicator light for the

Start button lights up constantly.

D . . . and then release the Start

button.

E Turn the programme selector to

Cottons 60°C:

A P will flash in the display alternating with the number 2, 3 or 4.

F Each subsequent press on the Start

button selects a different setting.

The number flashing in the display indicates the option selected.

G Switch the washing machine off

using the K button.

Programmable functions

Gentle action

Activating Gentle action reduces the drum action and is suitable for washing slightly soiled items more gently. It should be activated for garments with a single bar under the "bucket" in the care label and for articles which feel too hard after they have been dried.

Gentle action can be activated for the Cottons and the Minimum iron programmes.

The washing machine is delivered with the Gentle action setting deactivated.

Follow steps A to G to programme and store in memory.

Before you begin, ensure that:

– The washing machine is switched off.

– The machine door is closed properly.

– The programme selector is at Finish.

A Press the Start button and keep it

pressed in whilst carrying out steps

B-C.

B Switch the machine on with the K

button.

C Wait until the indicator light for the

Start button lights up constantly.

D . . . and then release the Start

button.

E Turn the programme selector to

Cottons r:

A P will flash in the display alternating with the number 0 or 1.

0 = deactivated

1 = activated

F Each subsequent press on the Start

button selects a different setting.

The number flashing in the display indicates the option selected.

G Switch the washing machine off

using the K button.

Programmable functions

Suds cooling

When this is activated, additional water flows into the drum at the end of the main wash to cool the suds down. Hot suds can damage plastic drainage pipes.

Suds cooling takes place when the Cottons 90°C programme is selected.

Suds cooling should be activated:

to prevent the danger of scalding if

–

the drain hose is hooked over the edge of a sink or basin.

– where the drainage pipes do not

comply with DIN 1986.

The machine is delivered with Suds cooling deactivated.

Follow steps A to G to programme and store in memory.

Before you begin, ensure that:

The washing machine is switched off.

–

The machine door is closed properly.

–

The programme selector is at Finish.

–

A Press the Start button and keep it

pressed in whilst carrying out steps

B-C.

B Switch the machine on with the K

button.

C Wait until the indicator light for the

Start button lights up constantly.

D . . . and then release the Start

button.

E Turn the programme selector to

Cottons 40°C:

A P will flash in the display alternating with the number 0 or 1.

0 = deactivated

1 = activated

F Each subsequent press on the Start

button selects a different setting.

The number flashing in the display indicates the option selected.

G Switch the washing machine off

using the K button.

Programmable functions

Memory function

If an extra option is selected for a programme, and / or the spin speed is altered, the machine stores these changes in memory at the start of a programme.

When that particular programme is chosen again, the washing machine will display the extra option(s) and / or spin speed which have been stored for that programme in the memory.

The machine is delivered with the memory function deactivated.

Follow steps A to G to programme and store in memory.

Before you begin, ensure that:

– The washing machine is switched off.

– The machine door is closed properly.

– The programme selector is at Finish.

A Press the Start button and keep it

pressed in whilst carrying out steps

B-C.

B Switch the machine on with the K

button.

C Wait until the indicator light for the

Start button lights up constantly.

D . . . and then release the Start

button.

E Turn the programme selector to

Cottons s:

A P will flash in the display alternating with the number 0 or 1.

0 = deactivated

1 = activated

F Each subsequent press on the Start

button selects a different setting.

The number flashing in the display indicates the option selected.

G Switch the washing machine off

using the K button.

Programmable functions

Soak duration

A length of time of between 30 minutes and 2 hours can be programmed in 30 minute increments for the soak process.

If the Soak option is pressed, the selected soak time will be carried out for the period selected before the wash programme is run.

The machine is delivered with a two hour soak time set as standard.

Follow steps A to G to programme and store in memory.

Before you begin, ensure that:

The washing machine is switched off.

–

The machine door is closed properly.

–

The programme selector is at Finish.

–

A Press the Start button and keep it

pressed in whilst carrying out steps

B-C.

B Switch the machine on with the K

button.

C Wait until the indicator light for the

Start button lights up constantly.

D . . . and then release the Start

button.

E Turn the programme selector to

Cottons 30°C:

A P will flash in the display alternating with the number 1, 2, 3 or 4.

1 = the soak time is 2 hours

(default setting)

2 = the soak time is 1 hour 30 minutes

3 = the soak time is 1 hour

4 = the soak time is 30 minutes

F Each subsequent press on the Start

button selects a different setting.

The number flashing in the display indicates the option selected.

G Switch the washing machine off

using the K button.

Optional accessories

Miele washing machines offer perfect care for your laundry and feature a wide range of special programmes designed to suit the fabric being washed. Miele have also developed a range of specialist CareCollection detergents and conditioning products to offer you a complete package for cleaning and caring for your laundry.

The Miele CareCollection detergents and conditioning products are listed below. You can order these and many other useful products via the internet at:

All the products can also be ordered via the Miele Customer Contact Centre (see back cover for contact details).

CareCollection

Miele specialist detergents

"Outdoor wear"

This specialist detergent will clean your water-repellent outerwear with care.

"Sportswear"

The Miele Sportswear detergent is designed to clean sportswear and remove odours whilst taking care of the special microfibres used in these garments.

"Down Items"

This special-purpose detergent contains a mild tenside and has been specially formulated to keep down-filled items supple and to give them bounce.

Miele proofing agent

This special finishing agent reproofs garments against wind and water and provides a dirt-repellent finish whilst retaining elasticity and breathability.

Optional accessories

"UltraWhite" detergent

This multi-purpose powder detergent has excellent stain removal properties and is suitable for white and light coloured laundry as well as heavily soiled coloured items.

"UltraColor" detergent for coloured garments

This liquid detergent is particularly suitable for cleaning coloured and dark garments. The special formulation offers effective stain removal, even at low temperatures, while helping to prevent colours fading.

Liquid detergent "For Delicates"

This liquid detergent is ideal for the gentle treatment of delicate fabrics, such as wool and silk. Its special formulation cleans effectively at temperatures as low as 20°C, while protecting the colour of your delicate garments.

Fabric conditioner

The Miele fabric conditioner will give your laundry a fresh, natural fragrance. It makes garments soft to handle and prevents static build-up during tumble drying.

686970

Alteration rights reserved/3912/W 3370 Edition 111

M.-Nr. 09 491 720 / 00

Miele W3370 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
