Miele T 5206 Operating instructions

Operating and Installation instructions for Tumble Dryer T 5206

It is essential to read these operating instructions before installing or using the machine, to avoid the risk of accident or damage to the machine.

M.-Nr.

05 493 110

Contents

Warning and safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Help to protect the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Disposal of the packing

material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Disposal of your old machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Energy saving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Guide to the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Explanation of control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Use of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Preparation of laundry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

How to dry correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

A Prepare the laundry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

B Load the drum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

C Select a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

D Start a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

E At the end of a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Changing a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

To cancel a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Adding or removing items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

To select a different

programme during drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Cleaning the fluff filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Casing and drum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

What to do if . . . ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

To change the lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Contents

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

View from the front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

View from the rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Aligning the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Coin mechanism / Time counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Installation - venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Fitting the exhaust ducting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Calculating the duct length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Installation examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Warning and safety instructions

Please read the operating instruc tions before using the tumble dryer for the first time. They contain impor tant information about the safety, use and maintenance of the machine. This way you will avoid the risk of accidents and damage to the ma chine.

Keep these operating instructions in a safe place and ensure that new users are familiar with the content. Pass them on to any future owner of the machine.

Correct use

The tumble dryer is only intended

for drying fabrics which have been washed in a water solution, marked on the manufacturer’s wash care label as being suitable for tumble drying. Any other applications may be dangerous. The manufacturer is not liable for damage resulting from improper use or operation.

Do not let small children play with

the machine or its controls. Super vise its use by the elderly or infirm.

Technical safety

Before setting up the machine

check it for any externally visible damage. Do not install or use a dam aged machine.

supply. If in any doubt, consult a quali fied electrician.

The electrical safety of this ma

chine can only be guaranteed when continuity is complete between the appliance and an effective earthing system which complies with local and national regulations. It is most important that this basic safety requirement is regularly tested by a qualified electrican. The manufacturer cannot be held re sponsible for the consequences of an inadequate earthing system (e.g. elec tric shock).

Do not connect the machine to the

mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the machine (e.g. danger or overheating).

The machine is built in accordance

with current safety requirements. Unauthorised repairs could result in unforeseen dangers for the user, for which the manufacturer cannot accept re sponsibility. Repairs should only be un dertaken by a Miele approved engi neer.

Faulty components must only be

exchanged for Miele original spare parts. Only when these parts are fitted can the safety standards of the ma chine be guaranteed.

Before connecting the machine,

ensure that the connection data on the data plate (fusing, voltage and fre quency) matches the mains electricity

Warning and safety instructions

In the event of a fault or for clean

ing purposes, the machine is only completely isolated from the electricity supply either when:

it is switched off at the mains or

–

the mains fuse is withdrawn.

–

Adequate ventilation is essential,

especially where another appli ance which also uses the room air (e.g. gas, oil or coal fired heater, continuous flow or other water heater), is installed in the same or an adjacent room. To en sure safe operation, and to prevent gases being given off by these appli ances being drawn back into the room, an underpressure of 4 Pa is the maximum permissible. Ventilation can be maintained by air inlets which cannot be blocked, in windows, doors and outside wall vents, or by an automatic window opening arrangement when the tumble dryer is switched on. If in any doubt, the advice of a competent builder, or for gas, a registered gas fitter must be sought.

Vented dryers must be installed

with a suitable venting system. If the machine is not correctly ducted it will draw damp exhaust air back into the drum, increasing running time and energy consumption quite consider ably. If moist air is passed back into the room this may lead to long-term dam age of walls.

smoke or exhaust fumes were drawn back into the room.

If the dryer is installed with other

dryers on one main venting duct, one non-return flap per dryer must be installed directly on the main venting duct. If this is not observed, the dryers could be damaged and their electrical safety impaired.

Always close the door after use.

This way you will avoid the danger of:

anyone sitting or leaning on the door,

–

which can cause the machine to tip up.

– children climbing onto or into the

dryer or hiding things in it.

Do not install the machine in a

room where the temperature may drop below freezing. At very cold temperatures the machine may be difficult to start. Laundry will not dry, and the sequence indicator light ~ r Anticrease/End will flash to indicate a problem.

In areas which may be subject to

infestation by cockroaches or other vermin, pay particular attention to keep ing the appliance and its surroundings in a clean condition at all times. Any damage which might be caused by cockroaches or other vermin will not be covered by the appliance guarantee.

The exhaust air must not be vented

into a chimney or vent flue which is in use. Neither should it be connected to ducting which ventilates rooms with fireplaces. It would be dangerous if

Before using the appliance for the first time clean the drum with a pa

per tissue or cloth.

Warning and safety instructions

There is a danger of fire with fab

rics which:

contain rubber, foam rubber or rub

–

ber like materials have been treated with inflammable

–

cleaning agents have been splashed with hair lac

–

quer, hair spray, nail varnish remover or similar substances

which contain padding or fillings

–

(e.g. pillows, jackets). If these were damaged the filling could get out with the risk of igniting in the dryer.

Avoid contact of stainless steel sur-

faces (front, lid, casing) with liquid cleaning and disinfecting agents which contain chlorine or sodium hypochlorite. These agents can have a corrosive effect on stainless steel. Aggressive vapours containing chlorine bleach can also be corrosive. Do not store open containers or these agents near the machine.

Using accessories

Accessory parts may only be fitted

when expressly approved by Miele. If other parts are used, guarantee, per formance and product liability claims may be invalidated.

Disposal of your old machine

Before discarding an old machine

unplug it and render the plug use less. Cut off the cable directly behind the appliance to prevent misuse.

This equipment is not designed for

maritime use or for use in mobile installations such as caravans, aircraft etc. However, it may be suitable for such usage subject to a risk assess ment of the installation being carried out by a suitably qualified engineer.

Help to protect the environment

Disposal of the packing material

The transport and protective packing has been selected from materials which are environmentally friendly for disposal and can normally be recycled.

Rather than just throwing these materi als away, please ensure they are of fered for recycling.

Disposal of your old machine

Old machines contain materials which can be reclaimed or recycled. Please contact your dealer, your local waste collection centre or scrap merchant about potential recycling schemes.

Ensure that the machine presents no danger to children while being stored for disposal.

Energy saving tips

Make sure that your laundry is thor

oughly spun before drying. You will save up to 30% energy and time if laundry is spun at 1200 rpm instead of at 600 rpm.

Load according to the optimum

amount of washing recommended for the programme being used. Underloading is uneconomical. Over loading gives a poorer quality of dry ing and may cause unnecessary

creasing. ^ To save energy and time: – make sure the room in which the

dryer is located is well ventilated.

– Make sure the fluff filter is clean be-

fore using the dryer.

^ The vent ducting should be as short,

straight and smooth as possible. Ex-

pelled air is slowed down in the vent

duct due to friction against the inner

walls of the ducting, therefore the

shorter the duct and the smoother the

inner walls, the less friction occurs

which in turns saves drying time and

energy costs.

Guide to the machine

Control panel

a Pushbutton switches

a Door

Opens the drum door

n Light

Illuminates the drum

L Low temperature

Lower drying temperatures (for delicate fabrics with the care label r, e.g. acrylics)

hStart

Starts a programme

b Additional display

Displays the drying stage reached. Displays "0" at anti-crease stage. Nothing is displayed with timed drying.

c Programme sequence

d Programme selector

The programme selector can be turned clockwise or anti-clockwise.

A Cottons

A Extra dry B Normal+ C Normal D Hand iron r E Hand iron rr F Machine iron

B Minimum iron

G Normal+ H Normal I Hand iron

C Timed drying

J Cool air 15 mins K Hot air 20 mins

! Drying ä Cool air ~ r Anti-crease/End

Guide to the machine

Explanation of control panel

A small panel is supplied with the ma chine to explain the symbols on the control panel. Position this on the left hand side next to the control panel.

^ Set the small panel into the lower

guide, press downwards and at the same time slot into the upper guide.

Use of the appliance

This automatic tumble dryer is particu

larly suitable for use in communal laun dry rooms, laundrettes etc. where con siderable amounts of soiled laundry are dealt with.

Preparation of laundry

Wash care labels

Before drying check the drying symbol on the wash care label.

Significance of symbols:

q = Dry at normal temperature r = Dry at low temperature s= Do not tumble dry

If no symbol is featured dry at your own risk applying the following principles:

Cottons and minimum iron items

should be dried at a normal temperature using the appropriate programme setting.

Delicate fabrics with the following wash care label r, e.g. acrylics should be dried at a low temperature.

The following fabrics should not be dried in a tumble dryer:

Woollens and wool blends

these fabrics tend to become matted and shrink.

Items filled with down

the fine fabric interior tends to shrink, depending on the quality involved.

Pure linen

should only be machine dried if speci fied as suitable by the manufacturer on the wash care label, as the surface of the fabric may otherwise tend to roughen.

General notes

Woven and loopkit materials (e.g.

T-Shirts, knitted garments) tend to shrink to varying extents depending on their quality. This tendency is exagger ated by over-drying. When purchasing woven materials, it is advisable to take their shrinkage properties into account.

Starched laundry can be dried in the tumble dryer. To achieve the usual fin ish, double the amount of starch should be used.

Minimum iron fabrics should be spun briefly at the end of their wash programme, or spun for 10 to 30 seconds if hand washed before they are dried. Some fabrics tend to crease if overdried. These items should be given only a short period in the dryer, and taken out slightly damp. Do not use the B Minimum iron - G Normal+ programme for these fabrics.

Minimum iron shirts in 100% cotton

may crease during tumble drying de pending on the quality of the weave. These should be dried using the Hand iron I setting. In extreme cases drip dry on a coat hanger.

Minimum iron fabrics tend to crease more the greater the load. This is particulary the case with delicate fab rics. The load should be reduced to 2 kg or if necessary to 1.5 kg.

New dark coloured garments should be dried separately from light coloured garments to avoid the danger of colours running.

Programme chart

Programme Laundry / Fabric type max.

load

ACOTTONS

AExtra dry Multi-layered fabrics

6 kg To prevent shrinkage do which would not be thoroughly dried using the B Normal+ programme.

BNormal+ Mixed loads of cotton

6 kg fabrics, e.g. Turkish towelling and jerseywear, i.e. single and multi - layer fab

rics.

CNormal

(EN 61121)

Loads of similar cotton fabrics (jerseywear,

6 kg Should certain items still

flannelette sheets, Turkish towelling).

DHand iron r Cotton or linen fabrics, EHand iron rr

(EN 61121)

e.g. table linen, bedding, starched laundry,

6 kg -

6 kg If fabrics are too damp

etc.

FMachine iron Cotton or linen fabrics,

6 kg Laundry should be also starched laundry, for machine ironing.

Notes

not select the A Extra dry programme for jerseywear.

be slightly damp, select the A Extra dry or B Normal + programmes

for hand ironing, select the D Hand iron r programme.

rolled up to prevent it from drying out until it can be ironed.

Weight of dry laundry

Programme chart

Programme Laundry / Fabric type max.

load

BMINIMUM IRON GNormal + Minimum iron items

3 kg With blended fabrics made of synthetics or blended fabrics, e.g. pullovers,dresses, trou

sers etc., which are not dried adequately in the

H Normal programme.

HNormal

(EN 61121)

Minimum iron shirts, ta

ble cloths, etc., made of blended fabrics, e.g. cot

3 kg

ton/synthetics.

IHand iron Minimum iron shirts, ta-

3 kg ble cloths, etc., made of blended fabrics, e.g. cotton/synthetics which are still to be hand-ironed.

CTimed drying

JCold air Items which are only to

6 kg be aired.

KHot air Individual items,

6 kg e.g. towels.

Notes

consisting of wool and synthetics, con sult the manufac turer’s instructions, as the wool compo nent may cause the fabric to become matted.

Weight of dry laundry

A Prepare the laundry

As far as possible, sort laundry for:

the type of fibre or weave

–

the degree of dryness required

–

How to dry correctly

Do not overload the drum. Over loading can cause unnecessary wear and tear to the laundry and give a disappointing drying result.

similar size of items

–

the moisture content after spinning.

– This will help towards achieving an

even drying result.

Fasten duvet covers etc. to prevent

small items from being rolled up in side them.

^ Do up zips and tie fabric belts and

apron strings.

Make sure there is no detergent dispenser ball etc. in with the laundry, as this could melt and damage the machine and the laundry.

B Load the drum

^ Press the door button a and open

the door.

Load the laundry loosely into the drum.

See the programme chart for maximum loads.

Before closing the door check that

the fluff filter is correctly positioned.

Important: Please check that items

of laundry cannot be trapped by the door, as this will cause damage to the fabric.

Shut the door with a firm swing.

How to dry correctly

C Select a programme

Turn the programme selector to the

programme required. Select low temperature L if required.

If the machine is fitted with a coin mechanism / time counter:

Insert coins or tokens.

Remember to empty the coin / token box regularly, so that it does not be come blocked.

For further information on operating the dryer with a coin mechanism / time counter see "Installation".

D Start a programme

^ Press the Start h button.

E At the end of a programme

Turn the programme selector to the

r End position. Press the door a button to open the

door. Press the Light n button.

Remove the laundry from the dryer.

Make sure that the drum is empty. If items are left in the dryer, they could be damaged by overdrying when the dryer is next used.

If laundry is not taken out of the dryer at the end of the programme the dryer will commence an anti-crease phase, during which the drum rotates at timed intervals to keep the laundry suspended and reduce the risk of creasing.

^ To save both energy and operation

time the fluff filter in the door should be cleaned after every programme (see "Cleaning and Care").

Shut the door when you have fin ished. As a safety precaution do not leave the door open when not in use.

Changing a programme

To cancel a programme

Turn the programme selector switch

to the r End position.

For safety reasons all programmes where the residual moisture content is monitored have a maximum running time of 130 minutes, after which period the heater elements are switched off and the cooling down phase com mences.

Adding or removing items

Press the door a button to open the

door.

If the door is opened during drying the programme will have to be started again. Take out or add items as required.

^ Close the door. ^ Press the Start h button.

The programme selected will then continue from the point it was at when the door was opened.

To select a different programme during drying

Turn the programme selector to the

required programme.

The new programme starts from the be ginning.

The programme is not continued –

if there is a power failure lasting more than 30 minutes

–

if the programme has already reached the ä cooling down phase or the ~ r Anti-crease stage.

Cleaning and care

Cleaning the fluff filters

The fluff which occurs during drying is collected in the fluff filters in the door and in the door opening. Clean the filters after every programme to reduce drying time and save energy.

Open the door and pull the fluff filter

up out of the door holder.

Push the cleaned filter back into the

door holder and close the door.

If there is a great deal of compacted fluff on the filters, they can be cleaned under hot running water.

The filter in the door opening should

only be removed for cleaning with water (see illustration for instructions on how to remove it).

Remove the fluff from:

–

the filter in the door

–

the filters in the door opening

(do not use sharp or pointed ob jects.).

Remove any fluff from the hollow part of the door holder through the wide slit at the bottom.

A cleaning brush is available at extra cost from the Miele Spare Parts De partment.

After cleaning shake any excess wa ter off the filters.

Dry them carefully and thoroughly.

Replace the filters in the door opening.

Replace the filter in the door, ensur ing it is fitted the correct way round in its holder.

Casing and drum

Disconnect the machine from the mains electricity supply.

Cleaning and care

Avoid contact of stainless steel sur faces (front, lid, casing) with liquid cleaning and disinfecting agents which contain chlorine or sodium hypochlorite. These agents can have a corrosive effect on stainless steel. Aggressive vapours contain ing chlorine bleach can also be cor rosive. Do not store open containers or these agents near the machine.

^ Clean the housing and control panel

with a mild detergent or soapy water.

^ Clean the drum and other stainless

steel parts with a suitable proprietary stainless steel cleaner following the manufacturer’s instructions.

Never use abrasive substances, disinfecting agents or solvents. These could damage the machine because of their chemical content. The ma chine must never be hosed down.

Dry all parts with a soft cloth.

Cleaning and preserving stainless steel surfaces

Please contact your local Spare Parts department for information on the ap propriate cleaning product.

Problem solving guide

What to do if . . . ?

With the help of the following notes minor faults in the performance of the machine, some of which may result from incorrect operation, can be put right without contacting the Service Department.

Repairs to the machine should only be undertaken by a suitably qualified service engineer to ensure safety. Unauthorised repairs could be dangerous.

Fault Possible cause Remedy

The machine fails to start when switched on.

The progamme has been interrupted.

Laundry is not sufficiently dried.

No obvious cause. Check that

the door is properly

–

shut. the machine is

–

switched on at the mains and the fuse is not defective.

The load was too small or consisted of individual items which caused the programme to finish prematurely.

The load consisted of too many types and thicknesses of fabric.

– Dry small amounts of

laundry using the Timed Drying C programme.

– Select a more suitable

programme next time (see "Programme over view")

Fault Possible cause Remedy

Drying times are too long.

There is conden sate water in the drum.

Problem solving guide

The fluff filters might be clogged up.

Ventilation to and from the dryer is insufficient (e.g. in a small room).

The ventilation ducting or room ventilation (e.g. window or wall vents are blocked.

The laundry was not suf ficiently spun.

Metallic components e.g. zips have prevented the dryer from registering the correct moisture level in the laundry.

If after checking all the above, drying times are still too long, there may be a fault. Contact the Service Dept.

The heater limiter has automatically switched off one or more heater elements.

The dryer is installed on a main venting duct and the non-return flap is not functioning properly.

Clean as described in

–

"Cleaning and Care". Open a door or window while

–

the machine is operating to increase air flow.

Remove any objects that are

–

causing the blockage.

Spin the laundry in the wash

–

ing machine at the highest possible speed.

– Complete the drying process

using a Timed Drying progamme.

– Contact the Service Dept.

–

The dryer may only be con nected to a main venting duct fitted with a non-return flap (see chapter on "Installa tion of the main venting duct").

–

Check the non-return flap regularly for possible defects and exchange it if neces sary.

Problem solving guide

Fault Possible cause Remedy

There is a build up of fluff.

Items made of syn thetic fibres are charged with static electricity after drying.

The interior drum light ing does not come on when the n button is pressed.

Fluff comes off textiles nat urally during wearing and washing. The fluff that col lects in the filters of a tum ble dryer has no effect on the lifetime of your laundry.

The lamp is defective.

Remove any fluff from

–

the fluff filter (see "Cleaning and Care").

Static charges can be

–

reduced by adding liq uid fabric conditioner to the final rinse of the wash programme.

Change the lamp as

–

described on the next page.

Problem solving guide

To change the lamp

Disconnect the machine from the mains electricity supply.

Open the door.

^ Unscrew the plastic cover inside the

drum, above the door.

To open the door during a power cut

^ Pull the door open.

The lamp must not exceed the maxi mum wattage quoted on the data plate and on the plastic light cover.

The temperature resistant lamp should be ordered from your Miele Dealer or the Miele Spare Parts Department only.

Replace the lamp and screw the plastic cover back on.

The cover must be fixed securely, as otherwise moisture may seep in and cause a short circuit.

Problem solving guide

Service

In the event of any faults which cannot be remedied, or if the machine is under guarantee, please contact

Your Miele Dealer or

–

The nearest Miele Service

–

Department (see back cover for address)

When contacting the Service Depart ment, please quote the Model and Se rial numbers, both of which are shown on the data plate, located on the right hand side below the opening to the drum.

Example:

View from the front

Installation

1 Isolator switch 2 Coin mechanism (optional) 3 Control panel 4 Door

5 Exhaust connection DN 100

Exit to the rear or through the left hand side of the machine

6 Hexagon headed nut M 10 7 Clamp 8 Screw, Washer, Plug (8 x 40)

Installation

View from the rear

1 Cable connection point for

coin mechanism / time counter

2 a.c. connection cable

(approx. 2 m long)

3 Exhaust ducting

4 Four height adjustable screw feet 5 Plinth base if required:

- masonry base built on site or

- Miele steel plinth S 5005 available at extra cost

Installation

Aligning the machine

The machine must be perfectly level to ensure safe and proper installation.

Take into consideration the space re quired by the vent duct when calculat ing the distance between the machine and a wall or other appliances etc. to the sides or rear of the machine.

A ventilation gap of 10 mm must be maintained between the base of the machine and the floor. This must not be blocked by sealing strips, deep pile carpet etc., as otherwise there will be insufficient flow of cool air for the machine to function correctly.

The machine must not be built under.

Coin mechanism / Time counter

This dryer can be fitted with a coin mechanism.*

It can also be connected to an existing time counter using a special connection cable*.

The screw feet can be adjusted to compensate for any unevenness in the floor.

Do not use devices to turn the machine off automatically, (e.g. automatic tim ers).

The tumble dryer can be combined with a Miele washing machine in a washer-dryer stack. For this purpose the appropriate stacking kit * is re quired.

* These items are all available from your Miele Dealer or the Miele Professional Sales Dept.

Installation - venting

Fitting the exhaust ducting

The moist air produced during drying has to be vented to the outside.

The dryer must only be operated when it is correctly fitted with ex haust ducting.

The exhaust connection may be made:

to the rear of the machine (the ma

–

chine is supplied as standard with

this connection point open) or – to the left of the machine. The side exhaust connection has a

cover cap.

Exhaust connection to the side of the machine

Disconnect the machine from the mains electricity supply.

At the same time turn the cover cap

anti-clockwise.

Vent socket

In the same way remove the vent

socket from the rear vent outlet. Secure into the side outlet by turning

clockwise. Close the rear outlet with the cover

cap.

Avoid:

very long exhaust systems

– – too many corners – tight corners. These reduce efficiency and increase

time and energy consumption.

Remove the cover cap.

Insert a thin screwdriver into the slit on the retaining hook and press the hook gently upwards.

The following materials are suitable for the exhaust ducting:

galvanized steel

–

plastic ducting

–

flexible ducting.

–

Note that all ducting must be of a suitable heat resistant specification.

Install the exhaust ducting so that the expelled exhaust air cannot be sucked into the machine again.

Standard accessories include an adapter for the exhaust ducting:

Installation - venting

Application In installations where conditions do not

allow the machine to be permanently connected to a ducting system.

Purpose The adapter enables rapid, simple con

nection or disconnection of the exhaust ducting.

Installation The adapter is fitted to the non-con

nected end of the vent duct.

Important Connection must not be made to a flue used by gas or solid fuel boilers or heaters.

Installation - venting

Calculating the duct length

The shortest passage for the expelled air is preferable, to ensure the tumble dryer functions most efficiently. Ex pelled air is slowed down in the vent duct due to friction against the inner walls of the duct, therefore the shorter the duct and the smoother the inner walls, the less friction occurs.

An elbow or bend creates more friction than a straight duct. An additional duct length factor should therefore be calcu lated for each elbow or bend (see Table

1). This factor expresses the resistance of the bend in terms of a straight length of duct.

The additional length factor is then added to the actual duct length to give the effective total duct length.

A larger duct diameter also helps to reduce friction. The duct diameter should therefore increase with increasing duct length.

To calculate the effective duct length:

Measure the actual duct length.

Establish the number of elbows or

bends necessary, noting the type of bend, angle and radius involved (see Table I).

Add the additional length factor as

specified in Table I to the actual duct length to give the effective duct length.

The appropriate duct length can then

be taken from Table II.

Note

Drying times and energy consumption remain unaltered for Ø100 mm ducting up to a total length of 15 metres. Longer ducting may lead to slight increases in drying times and energy consumption, but does not impair the function of the machine, if the necessary duct diameter is adhered to (see Table II).

Table I

Type of bend Angle Radius R

Flexible ducting (heat resistant) 90°

Plain ducting (heat resistant) Plastic ducting (heat resistant)

Elbow 2.3 Concertina bend 90° 200 0.7 Wall vent with grille or window vent kit

Wall vent kit with flap or window vent kit Non-return flap 14.3 Exhaust connection to the left 1.0

45° 90°

90°

in mm

100 to 400 100 to 400

100 200

Additional duct

length in metres

0.35

0.25

1.25

0.5

0.3

3.6

Installation - venting

Table II

Overall duct

length

0 - 15 m 15 - 21 m 21 - 34 m

Flexible ducting has been used for the following example. See Table I for addi tional duct length factors for other types of ducting.

Internal

diameter

100 mm 110 mm 120 mm

Example:

Side connection . . . . . . . . . . . . . 1.00 m

Length (L) . . . . . . . . . . . . . . . . . . 2.50 m

Lower radius R = 400 mm . . . . . 0.50 m

Height (H) . . . . . . . . . . . . . . . . . . 2,00 m

Upper radius R = 200 mm . . . . . 0.50 m

Wall duct with

louvred vent . . . . . . . . . . . . . . . . 3.60

Result:

A duct diameter of 100 mm is ade quate, since the overall length is less than the 15 metres specified in Table II.

10.10 m

Installation - venting

Main venting duct

There must be one non-return flap per dryer installed directly on the main venting duct R, upper picture). Extra Miele equipment is required for this purpose. If this not observed, the dryers could be dam aged and their electrical safety im paired!

When up to five dryers are being in

stalled, the pipe diameter D must be in creased according to Table III.

Table III

Number of Dryers Magnification factor for

2 3 4 5

the pipe diameter from

Table II

1.5

1.75 2

2.3

1 Connection to the main venting duct 2 Miele non-return flap 3 Additional Miele adapter 4 Miele vent hose, very flexible

Push the non-return flap (2) completely into the adapter (3).

Installation - venting

Installation examples

The moist air can be directed to the outside using a Wall vent kit* or a Win dow vent kit*.

The kits/parts (marked *) are available from your Miele Dealer or the Miele Spare Parts Dept.

Wall vent kit* (with necessary parts)

1. Louvre frame

2. Wall pipe

3. Connecting piece

4. Louvre grill

5. Flap

6. Wood screw

7. Wall plug

Connection directly to a wall vent

If the dryer is connected direclty to a wall vent a flexible foam gasket* is re

quired.

1. Wall pipe*

2. Flexible foam gasket* ^ Fit the gasket to the connecting piece

on the wall pipe and push the dryer up against the wall.

Installation - venting

Upward ducting via plastic vent ducting* to wall vent*

Adapter* required.

1. Wall pipe*

2. Adapter*

3. Plastic ducting (external Ø 110 mm)

Connect the plastic vent ducting to the dryer

Upward ducting via flexible vent ducting* to exhaust flue

A = Wire wound spiral ducting B = Flexible ducting

1. Wall pipe*

2. Adapter*

3. Flue / chimney, insulated against

damp

1. Plastic ducting

2. Adapter* between exhaust outlet and plastic ducting

The exhaust air must not be vented into a chimney or vent flue which is in use. Neither should it be con nected to ducting which ventilates rooms with fireplaces. It would be dangerous if smoke or exhaust fumes were drawn back into the room!

Installation - venting

Window vent kit* (with necessary parts)

1. Louvre frame 4. Grille

5. Flap 8. Clip (4x)

9. Raised head screws (4x)

Window vent kit* with flexible ducting*

Washer/Dryer stack

Height of venting outlet for washer/dryer stack.

1. Window vent*

2. Adapter for flexible ducting C 100 mm

(Window vent fitted in plexiglass pane)

Electrical connection

All electrical work should be carried out only by a suitably qualified and compe tent person, in strict accordance with national and local safety regulations.

Ensure power is not supplied to the appliance while installation work is being carried out.

The appliance is supplied with a mains cable for connection to a 230-240V sin gle phase supply. The voltage, rated

load and fuse rating are given on the data plate. Please ensure these match

the household mains supply. Connection should be made via a

suitable switched socket which is easily accessible after installation.

For extra safety it is advisable to install a residual current device (RCD), with a trip current of 30 mA. Do not connect via an extension lead.

Important

The wires in the mains lead are col

oured in accordance with the following code:

Green/yellow = earth Blue = neutral Brown = live

WARNING:

THIS APPLIANCE MUST BE EARTHED

Where it is necessary to change plugs, if the colours of the wires in the mains lead of this appliance do not correspond with the coloured markings identifying the terminals of your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol z or coloured green, or green and yellow.

The wire which is coloured blue must be connected to the terminal in the plug which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal in the plug which is marked with the letter A or coloured red.

Height 85.0 cm

(adjustable +1/-0.5 cm) Width 59.5 cm Depth (incl. distance from the wall) 70.0 cm Weight 57 kg Drum volume 126 litres Capacity 6 kg dry weight Voltage 230 - 240 V, 50 Hz Rated load 5000 - 5400 W Plug rating 25 A Max. load bearing

in operation approx. 68 kg Test certificates awarded Typetest Mark,

C - Tick Mark Electrically suppressed

according to AS/NZS 1044 * Noise level

(according to 3. GSGV)

* Tested on standard machine for the German market.

< 70 dB(A)

Technical data

Alteration rights reserved/3902

This paper consists of cellulose which has been bleached without the use of chlorine.

M.-Nr. 05 493 110 / V

Miele T 5206 Operating instructions

Specifications and Main Features

Frequently Asked Questions

User Manual
