Operating instructions for condenser tumble dryer T 495 C
It is essential to read these operating instructions before installing or using the machine to avoid the risk of accident, or damage to the machine. M.-Nr. 04 939 841
Q\
Contents
Contents
Guide to the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warning and safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Notes on laundry care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
How to dry correctly
Hints on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1 Switching on and loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Selecting a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Selecting additional option(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Starting a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
After drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Altering a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programmable functions
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Correcting the drying level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Buzzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Anti-crease . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Activating and storing in the memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2
Contents
Cleaning and care
Cleaning the fluff filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cleaning the tumble dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Emptying the condensed water container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning the condenser unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
What to do if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
After sales service
Repairs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Future updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
External condensed water outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3
Guide to the appliance
Guide to the appliance
General view
1 Supply cable for electrical connection 2 Condensed water container 3 Control panel 4 Door 5 Condenser unit cover 6 Drain hose for condensed water (if fitted) 7 Four height-adjustable screw feet
4
Control panel
Guide to the appliance
b“I-On/0-Off” button
for switching the appliance on and off. When the machine is switched on, the drum light will come on as you open the door.
c“Door” button
to open the door/cancel a programme. This button does not stay pressed in.
d“START” button
starts a drying programme. The indicator light: – flashes to indicate that the pro-
gramme can be started;
– remains on once the programme has
commenced.
eAdditional option buttons
Indicator lights: on= option selected
off= option not selected
fProgramme selector
can be turned clockwise or anti-clock­wise.
gSequence indicator and check
lights
Please consult the section “Problem solving guide” for the check lights.
5
Caring for the environment
Caring for the environment
Disposal of packing
The transport and protective packing has been selected from materials which are environmentally friendly for disposal and can normally be recycled. Rather than just throwing these ma­terials away, please ensure they are of­fered for recycling.
Disposal of your old machine/appliance
Old machines/appliances contain ma­terials which can be recycled. Please contact your dealer, your local waste collection centre or scrap merchant about potential recycling schemes. En­sure that the machine/appliance pres­ents no danger to children while being stored for disposal. See the appropri­ate advice in the “Warning and safety” instructions.
6
Warning and safety instructions
Warning and safety instructions
Please read the operating instruc­tions before using the tumble dryer for the first time. They contain im­portant information about the safety, use and maintenance of the machine. This will avoid the risk of accidents and damage to the ma­chine. Keep these operating in­structions in a safe place and en­sure that new users are familiar with the content. Pass them on to any fu­ture owners of the machine.
Correct usage
The tumble dryer is only intended
for drying fabrics which have been washed in a water solution and are marked on the manufacturer’s wash care label as being suitable for tumble drying. Any other applications may be dan­gerous. The manufacturer is not liable for damage resulting from improper use or operation.
Do not let small children play with
the machine and its controls or operate it. Please supervise its use by the elderly or infirm.
Technical safety
Check for visible external damage
before installation. Do not install or operate a damaged machine or appliance.
Before connecting the machine,
ensure that the connection data on the data plate (fusing, voltage and fre­quency) matches the mains electricity supply. If in any doubt, consult a quali­fied electrician.
The electrical safety of this ma-
chine can only be guaranteed when continuity is complete between the appliance and an effective earthing system which complies with local and national regulations. It is most import­ant that this basic safety requirement is regularly tested by a qualified electri­cian. The manufacturer cannot be held responsible for the consequences of an inadequate earthing system.
The machine is built in accordance
with current safety requirements. Unauthorised repairs could result in un­foreseen dangers for the user, for which the manufacturer cannot accept respon­sibility. Repairs should only be under­taken by a Miele approved engineer.
In the event of a fault, or for clean-
ing purposes, the machine is only completely isolated from the electricity supply when:
– the plug is withdrawn, or – it is switched off at the mains, or – the mains fuse is withdrawn.
7
Warning and safety instructions
For safety reasons, do not use an ex­tension cable. There is a danger of
overheating.
Faulty components must only be
exchanged for Miele original spare parts. Only when these parts are fitted can the safety standards of the ma­chine be guaranteed.
Use
Do not install the machine in a
room where the temperature may drop below freezing, as temperatures below zero could damage the ma­chine.
Frozen condensed water in the pump, hose and condensed water container could also lead to damage.
If the water is drained externally
through the drain hose instead of being collected in the condensed water container, make sure the drain hose is securely attached if you hang it in a sink or basin to avoid the hose slip­ping and the water causing damage.
Condensed water is not drinking water. It can cause health prob-
lems in people and animals.
Always close the door after use to avoid the danger of:
– someone leaning on the door which
could cause the machine to tip;
– children climbing into the machine or
hiding objects in it.
There is a danger of fire with fab­rics which:
– contain rubber, foam rubber or rub-
ber-like materials;
– have been treated with inflammable
cleaning agents;
– have been splashed with hair lac-
quer, hair spray, nail varnish remover or similar;
– also padded items (eg cushions,
jackets) which have been damaged, as the padding could fall out and catch fire;
– are soiled with grease or oil.
8
Warning and safety instructions
In countries where there are areas
which may be subject to infesta­tion by cockroaches or other vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all times. Any dam­age which may be caused by cock­roaches or other vermin will not be covered by the appliance guarantee.
Using accessories
Accessory parts may only be fitted
when expressly approved by Miele. If other parts are used, guaran­tee, performance and product liability claims may be invalidated.
Disposing of your old machine
Before discarding an old machine,
unplug it and render the plug use­less. Cut off the cable directly behind the appliance to prevent misuse.
9
Brief instructions
Brief instructions
Brief description
Programmes are selected by turning the programme selector and can be supplemented by pressing the addi-
tional option buttons. Press the “START” button to begin a
programme.
The indicator lights in the sequence dis­play (on the right hand side of the con­trol panel) show which stage has been reached in the programme.
The Sensitive system automatically ad­justs drying to suit the water quality and ensure more precise results. The Novotronic controls measure and register the conductivity of the water and compensate for variations to achieve a uniform residual moisture level. The automatic reversing action turns the drum clockwise and anti-clockwise to loosen the laundry and prevent uneven drying, ensuring good results.
Once the required degree of dryness is achieved, the laundry is allowed to cool down.
Please read the sections on “Warn­ing and safety” and “Notes on laundry care”.
1 Switching the machine on and
loading the laundry
Switch on by pressing the “I-On/0­Off” button.
Press the “Door” button to open the door.
Place the laundry loosely in the drum. Close the door.
2 Selecting a programme
Turn the programme selector to the drying level you require.
3 Selecting additional options
Press the buttons to switch addi­tional options on or off as required.
4 Starting the programme
Press the “START” push button.
At the end of the programme the anti- crease action period begins. The drum turns intermittently to reduce the forma­tion of creases and folds.
Programmable functions can be used to select or de-select some of the addi­tional options and introduce further functions. These combinations can be stored in the machine’s memory and called up.
10
Notes on laundry care
Notes on laundry care
Before drying, check the drying sym­bol on the textile care label.
Significance of symbols:
q = Dry at normal temperature r = Dry at low temperature
(also push in the “Low temperature” button if required)
s = Do not tumble dry t = Can be tumble dried
If no symbol is featured, dry at your own risk applying the following principles:
Cotton and minimum iron items should be dried in the appropriate programme (see programme charts).
For delicate fabrics, eg acrylic, select "Minimum iron" and also press the "Low temperature" button.
Never overload the drum. Always observe the maximum recom­mended loads given in the “Pro­gramme chart”. Overloading can cause unnecessary wear and tear to the laundry, give a disappointing drying result and cause more creas­ing.
The following fabrics should not be dried in a tumble dryer:
– Woollens and wool blends
These fabrics tend to become matted and shrink. These fabrics can, however, be partially dried using the “Woollens hand care” programme.
– Pure linen*
These items should only be machine dried if specified as suitable by the manufacturer on the textile care label, as the surface of the fabric may other­wise “roughen”.
* Linen and down-filled items can, how­ever, be partially dried using the “Smoothing” programme.
Notes:
Some woven and loopknit materials (eg T-shirts, cotton jersey material) have a tendency to shrink, depending on their quality, and this is often made worse by over-drying. When purchas­ing woven materials, it is advisable to take their shrinkage properties into ac­count.
Starched washing can be dried in the tumble dryer. In order to achieve the usual finish, double the amount of starch should be used.
Minimum iron fabrics and 100% cotton shirts or blouses tend to crease more, when larger loads being dried, particu­lary when the weave of the fabric is very fine. Reduce the load or use the Special care “Minimum iron – Hand iron” programme. If this is unsatisfac­tory use the “Smoothing” setting, then hang the garments on a hanger to dry.
New dark-coloured fabrics should be dried separately from light-coloured fabrics to avoid colours running.
– Down-filled items*
The fine fabric interior tends to shrink, depending on the quality.
11

How to dry correctly

How to dry correctly
Hints on saving energy
Make sure that your laundry has been thoroughly spun at the highest appro­priate spin speed before drying. Spin­ning at 1600 rpm, for example, saves approximately 30% energy and time compared with 800 rpm.
Make sure there is no washing detergent dispenser among the laundry, as this could melt and dam­age the machine and the laundry.
Load the laundry very loosely into the drum.
Load the full amount of laundry ac­cording to the programme chosen (see “Programme chart”) for the most economical drying related to the size of the load. Make sure that
the drum is not over- or underloaded.
As far as possible, sort fabrics for: – the type of fibre or weave – the degree of drying required – similar size of items – the moisture content after spinning. This will help towards an even drying result.
Ensure the room is well ventilated.
1Switching on and loading
Fasten duvet covers etc to prevent small items from being rolled up in­side them.
Do up zips and tie fabric belts and apron strings.
Press the “l-On / 0-Off” button. Press the “Door” button and open
the door.
Do not overload the drum. Over­loading can cause unnecessary wear and tear to the laundry and give a disappointing drying result.
Close the door.
Important: Please check that items of laundry cannot be trapped by the door, as this will cause damage to the fabric.
12
How to dry correctly
2Selecting a programme
Turn the programme selector to the programme required.
See the Programme chart for a de­scription of each programme.
3Selecting additional
option(s)
Additional options are switched on or off by pressing the appropriate buttons.
Indicator lights:
on= additional option selectedoff= additional option not selected
Low temperature
The drying temperature is reduced.
– For delicate fabrics (drying symbol
r), eg acrylic. The programme running time is in­creased.
4Starting a programme
Press the “START” button. The drying stage reached display on
the right hand side of the facia panel will indicate which drying stage the pro­gramme has reached.
The memory function:
If the memory function has been acti­vated, the machine will automatically call up the additional options selected for the last programme used. The indi­cator lights will indicate which options are selected. For further details on the memory func­tion, please see the section “Programm- able functions”.
Short
The programme running time is re­duced.
– For drying fabrics that are not deli-
cate.
13
How to dry correctly
"Clean out airways" indicator light
This indicator light shows that the dryer is not working most efficiently or econ­omically.
The causes of this check message can be:
– the fluff filters in the door and the
secondary filters in the door opening
are blocked; – the condenser unit is blocked. The "Clean out airways" check light will
only go out before the start of a pro­gramme if the dryer has been switched off with the "l-On/0-Off" button.
After drying
When the drying programme has fin­ished the Anti-crease / finish se­quence indicator light comes on.
Press the “Door” button to open the door.
Remove the laundry. Make sure that the drum is empty.
If items are left in the dryer, they could be damaged by overdrying when the dryer is next used.
After every cycle remove the fluff from
the fluff filter in the door the filters in the door opening
(See the section on Cleaning and care).
Empty the condensed water con­tainer (where there is no external drainage of the water). See the sec­tion on Cleaning and care”.
14
Close the door and switch off the ma­chine after each use.
Press the l-On / 0-Off button to switch off.
Altering a programme
Once a programme has started, no changes to the programme or addi­tional options will be accepted.
Altering a programme
To open the door during a pro­gramme to add or remove garments
If the programme selector is turned to a different programme after a pro­gramme has begun, the “Drying” indi­cator light will flash. The programme originally selected will continue to run as normal. The indicator light will go out when the selector is returned to its original position.
To cancel a programme
Open the door or switch off the ma-
chine.
To select a different pro­gramme
Turn the programme selector to “Fin-
ish. – The Anti-crease/Finish indicator
light will flash by itself to indicate that
the programme has been cancelled.
Turn the programme selector to the
drying level required.
Cancel the programme by:
Pressing the “Door” button and open­ing the door.
– Items can now be added or removed
early.
Restart the programme by:
Closing the door. Pressing the “START” button.
– The programme will restart.
If there is a power cut, TIMED DRYING programmes have to be re­started once the power supply is re­stored.
Switch additional options on or off as
required.
Press the “START” button.
15
Programme chart
Programme chart
Programme Fabric type maximum
COTTONS Extra dry
Multi-layered fabrics, not
thoroughly dried with
Normal +
Normal +
Mixed load of cotton fabrics,
eg towelling, jerseywear, ie
single and multi-layered
fabrics.
Normal
(1)
Load of similar fabrics (jersey
wear, flannelette sheets,
towelling).
Hand iron Hand iron rr
Machine iron
r Cotton or linen fabrics (eg
(1)
table linen, bedlinen,
starched laundry etc)
Cotton or linen fabrics,
including starched laundry,
for machine ironing
MINIMUM IRON Normal+
Minimum iron items which
are made of synthetics or
blended fabrics, (eg
pullovers, dresses, trousers)
which are not dried
adequately in the “Normal”
programme
Normal
(1)
Minimum iron shirts, Table
cloths etc made of blended
fabrics, (eg cotton/synthetics) .
Hand iron
Minimum iron shirts, Table
cloths etc made of blended
fabrics, (eg cottons and
synthetics), which are still to
be hand ironed.
(2)
load
5 kg Do not dry jersey wear in the
5 kg
5 kg If fabrics are too damp,
5 kg – 5 kg If laundry is still too damp for
5 kg The laundry should be rolled
2.5 kg Spin minimum iron fabrics for
2.5 kg
2.5 kg Spin minimum iron fabrics for
Special notes
Extra dry programme –
tendency to shrink.
select Normal +”.
hand ironing, then select
Hand iron r” in the future.
up to prevent it from drying
out until it can be ironed.
at least 30 seconds in the
washing machine before
drying
at least 30 seconds in the
washing machine before
drying. For extra special care
of delicate fabrics and to
reduce creacing even more,
reduce the load to 1 kg.
(1)
Note for Test Institutes: These are the programmes that should be tested according to the EN 61121/A11 Standard.
(2)
Weight of dry laundry
16
Programme chart
Programme Fabric type Maximum
TIMED DRYING Warm air
Cool air
Special care programmes Woollens
hand care
Smoothing
Individual items, (eg bathing costumes, bath towels, tea towels)
Multi-layered fabrics whose layers have different drying
characteristics.
Items which are only to be
aired
Woollen fabrics 1 kg To refresh and fluff up woollen
Minimum iron items made of
cotton, blended fabrics or
synthetics
(2)
load
5 kg
5 kg
2.5 kg Smooths out creases caused
Special notes
garments quickly.
Remove garments immediately
at the end of the programme.
Do not repeat. Woollen fabrics
are not dried completely by this
programme.
during the spin cycle in the
washing machine.
Fabrics are not dried
completely in this programme.
Remove garments immediately
at the end of the programme
and hang on a line or coat
hangers to dry.
(2)
Weight of dry laundry
17

Programmable functions

Programmable functions
Notes
The programmable functions can be used to create drying programmes to suit your individual requirements. They will remain in the machine’s memory until cancelled.
One or all of the programmable func-
tions can be activated or cancelled
(See following page).
Correcting the drying level
The Sensitive System aims to dry using as little energy as possible. However, if you require the washing to be drier, it is possible to reduce the final moisture level on all pro­grammes. (It is not possible to alter an individual programme).
The machine is delivered with this func­tion switched off.
2. Press the “START button. The indicator light for machine iron
goes out.
3. Press the “START” button again and keep it pressed in. The indicator light for machine iron will light up.
4. Release the START button when
the volume you want is reached.
5. Turn the programme selector to the Finish position.
6. Switch the machine off with the I-On/0-Off button. The change to the volume has been stored in memory.
To switch the buzzer off altogether see the next page (points
Memory
The additional options selected pre­viously for specific programmes are stored in the machines memory.
1 to 0).
Buzzer
An audible tone sounds repeatedly at the end of a programme.
The machine is delivered with the buzz­er switched on, but it can be switched off (see next page).
The volume of the buzzer can be al­tered (the pitch changes at the same time).
Proceed as follows:
1. Select the programmable function
Buzzer(see next page, points
18
1 to 6).
The memory programmable function can be used to switch the memory function on or off. The machine is delivered with the memory function activated.
Anti-crease
Once a programme has ended, the drum will turn at regular intervals to prevent the laundry from settling into creases and folds.
This programmable function can be used to switch the memory function on or off. The machine is delivered with the Anti-crease function activated.
Programmable functions
Activating and storing in the memory
The programmable functions are acti­vated using the additional option but­tons in special combinations with the programme selector to introduce extra features not marked up on the control panel.
1 Switch the machine off and shut the
door. Turn the programme selector to “Fin- ish”.
2 Press the “Short and Low tempera-
ture buttons in. Hold them there and ...
3 ... switch the machine on by pressing
the I-On / 0-Off button.
4 Release all the buttons. 5 The Drying and Cool air indicator
lights will flash.
6 Turn the programme selector to one
of the following positions:
COTTONS / Extra dry for the func-
tion
Correcting the drying level
COTTONS / Normal + for the function
Buzzer
COTTONS / Normal for the
"Memory function"
7 If the “Machine iron indicator light
comes on, then the chosen function has been activated.
8 Each programmable function can be
switched on or off by pressing the START button:
Machine iron indicator light
- on = Programmable function
activated
- off = Programmable function
de-activated.
9 If you wish to activate a further pro-
grammable function, repeat steps to 8. If not:
6
0 To store in the memory:Turn the pro-
gramme selector to “Finish” and switch the machine off by pressing the I-On/0-Off button.
To de-select a programmable func­tion
Carry out steps 1 to 0.
To check whether a programmable function is activated:
Carry out steps 1 to 7. Switch the machine off.
This completes the check.
COTTONS / Hand iron r
for the function Anti-crease
19

Cleaning and care

Cleaning and care
Cleaning the fluff filters
The fluff which is created by the drying process is collected in the fluff filters in the door and door opening.
Clean the filters after every pro­gramme to reduce drying time and save energy.
These filters should only be removed for cleaning with water.
Dry the filters well after rinsing and put back in place.
Cleaning the tumble dryer
Open the door. Grip the filter by the recessed handle and pull upwards to remove. Remove the fluff from:
the filter in the doorthe filters in the door opening
Do not use any sharp or pointed ob­jects.
Remove any fluff from the hollow part of the door holder through the wide slit at the bottom. A cleaning brush is available at extra cost from the Miele Spare Parts Department. Push the cleaned filter back into the door holder and close the door.
If there i s a g rea t de al o f com pa c ted fluff on the filters, the y can be clea ned un der hot running wa te r .
20
Disconnect the machine from the power supply.
Clean . . .
. . . the housing and control panel:
with a mild detergent or soapy water;
. . . the drum and other stainless steel parts: with a suitable proprie-
tary stainless steel cleaner following the manufacturers instructions.
Never use abrasive substances, scouring pads, glass or general pur­pose cleaners. These could damage plastic surfaces and other parts. The machine must never be hosed down.
Dry all parts with a soft cloth.
Emptying the condensed water container
If the hose drain has not been fitted and connected, the condensed water will be collected in the condensed water container.
The condensed water container should be emptied after every drying cycle, or as soon as the Empty out container indicator light comes on.
If . . . . . . the condensed water container is full when a programme is started or . . . it becomes full during a drying cycle: – the Empty out container light will come on,
the buzzer will sound,the programme will be stopped,the washing will be cooled down and the Cool air light will come on.
Cleaning and care
Slide back the cap and pour the water away.
Push the container back into the ma­chine until it engages into place.
Condensed water should not be drunk. It could lead to health prob­lems for humans and animals.
Pull the container out of the machine, gripping it firmly with both hands.
Condensed water can be put to house­hold use, eg used in a steam iron or hu­midifier.
Note:
To ensure that no particles of fluff are left which could damage the ap­pliance, pass the condensed water through a fine sieve or paper filter.
21
Cleaning and care
Cleaning the condenser unit
The machine must be disconnected from the electricity supply before cleaning.
Check the condenser unit at least twice a year and clean it if necessary. If the dryer is used frequently then clean the condenser unit after approx. 100 drying cycles.
Turn the inner cover lock downwards to the vertical position.
Pull the cover off.
Keep hold of the outer condenser unit cover while removing it, then place it to one side.
22
Turn both the levers on the conden­ser unit to the vertical position.
Cleaning and care
Pull the condenser unit out.
Clean the condenser unit at both ends (front and back).
Wipe the rubber seals at both ends gently but thoroughly.
Clean the two long sides of the unit. Stand the condenser unit lengthwise
on a towel until it is quite dry. Replace the condenser unit correctly
(see illustration above left). Return both levers on the condenser
unit to the horizontal position. Pull forwards on the unit to check that it is firmly in place.
Replace the inner cover and check that it is also firmly in place, other­wise water may leak from the ma­chine.
Reposition the outer cover and push back into place.
23
Problem solving guide
Problem solving guide
What to do if ...
Electrical appliances should only be repaired by qualified perso nn el. Incorrectl y repai red ma­chines may pose a considerable risk to the user.
What to do if . . . Cause . . . Remedy . . . . . . the tumble dryer fails to
start when switched on
. . . items made of s yn t hetic fibres are charged with static electricity after drying
. . . the laundry is not suffi­ciently dry
. . . there is a build-up of fluff
This may be due to an incorrect selection procedure sequence when switching on the machine.
The load consists of different fabrics.
Fluff is principally the result of friction when garments are being worn and washed. Machine drying hardly causes any fluff to form and, as has been established by research institutes, has no effect on the lifetime of fabric.
Repeat the switch-on procedure (see section on “Drying correctly). Also check the following:
Is the machine plugged in at
the mains switch?
Is the door closed properly?Was the “”I-On/0-Off button
pushed in?
– Was the “START button
pushed in?
Has the fuse or circuit
breaker tripped? If so, contact the Miele Service Department.
Static charge can be reduced by adding a fabric conditioner for the final rinse in the washing machine.
Select a more suitable drying programme next time.
24
Problem solving guide
What to do if . . . Cause . . . Remedy . . . . . . the drying process goes
on too long.
. . . water dro plets appear at the upper edge of the drum aperture.
. . . water leaks from the ma­chine after the condenser unit has been cleaned.
. . . the interior drum lighting does not come on.
. . . you need to open the door during a power cut.
Ventilation to and from the dryer is insufficient (eg in a small room). This could cause the room temperature to rise sharply.
The vent below the door is blocked.
The dryer cannot blow air out correctly.
The laundry was not sufficiently spun.
A double filter system with dual insulation prevents fluff from being deposited in the condenser unit. This insulation can lead to a build-up of condensation.
The condenser unit has not been correctly locked into place.
It only lights up when the machine is switched on. The bulb may be defective.
Open a door or window while the machine is in operation for increased air flow.
Remove any objects that are blocking the vent below the door.
Clean the fluff filters in the
door and the door opening.
Clean the condenser unit.
Spin the laundry in the washing machine at the highest possible spin speed.
Laundry being removed from the machine may come into contact with these water droplets, but they will dry off in a matter of minutes.
Ensure that the condenser unit and cover are firmly in position and lock into place again.
Change the bulb. See instructions at the end of this section.
See instructions at the end of this section.
25
Problem solving guide
Check and indicator lights What to do if . . . Cause . . . Remedy . . . . . . the “Drying” indicator
light flashes.
. . . the “Anti-crease/Finish” light flashes.
. . . the Empty out container light comes on.
. . . the Clean out airways light comes on.
. . . the programme is interrupted and the “Anti-crease/Finish” light comes on.
The programme selector was moved after the beginning of the programme, but the programme continues to run correctly.
There could be a fault.
Cold surrounding temperatures below freezing are affecting the machine (frozen condensed water).
The condensed water container is full.
The fluff filters are blocked.
The condenser unit may be blocked because it has not been cleaned for a long time.
If there is no laundry in the drum when the programme is started, the electronics will register this and stop the programme. The programme will also be interrupted if the laundry placed in the drum is already dry.
Turn the programme selector back to its original position and the light will go out.
Switch the machine off and
on again.
Select the programme and
press START”.
Install the appliance in a
warmer room.
If the light continues to flash there is a problem. Contact Miele Service Department.
Empty the container. Check that the condensed water container is correctly positioned.
Switch the dryer off with the
"l-On/0-Off" button.
Clean the fluff filters after
every use. (See "Cleaning and care").
Switch the dryer off with the
"l-On/0-Off" button.
Please note that the
condenser unit must be cleaned regularly (see "Cleaning and care").
26
Problem solving guide
The interior drum lighting does not come on: changing the bulb
Open the door.
Before changing the bulb, discon­nect the machine from the mains power supply.
Unscrew the plastic cover above the door inside the drum.
The cover must be fixed securely otherwise moisture may seep in and cause a short circuit.
The temperature resistant bulb should only be ordered from your Miele dealer or the Miele Spare Parts Department.
Opening the door in the event of a power failure.
Replace the bulb.
The light bulb must not exceed the maximum wattage quoted on the data plate and the light cover.
Replace the plastic cover and screw back on.
27
After sales service
After sales service
Repairs
In the event of any fault which you can­not remedy yourself, please contact:
– your Miele dealer or – your nearest Miele Service Depart-
ment (see back cover for the ad­dress).
When contacting the Service Depart­ment, please quote the model and ser­ial numbers of your appliance, both of which are shown on the data plate which is located beneath the drum opening on the right.
Future updates
The indicator or check light marked PC allows a service engineer to update your machine in future years.
When, for example, new programmes are developed or new fabrics are intro­duced, a service engineer will be able to modify existing programme cycles accordingly.
Miele will provide information when such possibilities become available.
Please note that telephone calls may be monitored and recorded to improve our service.
28
Installation
The machine must be perfectly level to ensure safe and proper operation. Minor differences do not, however, have an adverse effect on operation.
Installation
The ventilation slots beneath the door must on no account be blocked as this will prevent a sufficient intake of cold air.
The UBT/UBW building under kit cannot be used with sloping facia machines.
The machine complete with its own lid which must not be removed can still be slid under a worktop, if there is enough space.
The machine must be allowed to jut out sufficiently for the control panel not to be obscured.
The tumble dryer can also be com­bined with a Miele washing machine in a washer and dryer stack. For this pur­pose the appropriate stacking kit* to match your washing machine is re­quired.
*Available from your Miele dealer.
The screw feet can be adjusted to compensate for any uneveness in the floor surface.
29
Installation
External condensed water out­let
The condensed water can be drained off directly if the machine is installed near a sink, drain outlet etc.
Maximum drain hose length: 3.00 metres Maximum delivery head: 1.00 metre
Accessories supplied:
2 metre drain hoseHose clampAdapter sleeveHose clip
Push the drain hose onto the drain outlet.
Secure the hose firmly with the clip. Make sure that the hose is not
kinked.
Unscrew the hose clip from the drain outlet at the back of the machine.
Remove the rubber plug.
30
Installation
The dryer is fitted with a non-return valve as standard to prevent water from flowing back into the machine.
Close the water inlet port to the con­densed water container with the bot­tom part of the rubber plug. The plug must face towards the inte­rior of the machine so that the con­densed water container can be pushed in easily.
Connection to wash basin drain out­let (where appropriate)
Push the hose clip (1) and the knurled nut connector from the sink drain outlet (2) over the drain hose.
Push the adapter sleeve (3) into the hose.
Screw the drain hose to the drain out­let with the knurled nut connector.
Tighten the hose clip up close to the nut.
31
Electrical connection
Electrical connection
Electrical connection U.K.
All electrical work should be carried out only by a suitably competent person, in strict accordance with national and local safety regulations.
The appliance is supplied with a mains cable with moulded plug for connection to a 230-240V mains supply. The volt­age, rated load and fuse rating are given on the data plate. Please ensure these match the household mains supply.
Connection should be made via a fused plug and suitable switched socket which is easily accessible after installation. For extra safety it is advis­able to install a residual current device (RCD), with a trip current of 30 mA. Do not connect via an extension lead.
Important
The wires in the mains lead are col­oured in accordance with the following code:
Green/yellow = earth Blue = neutral Brown = live
Where it is necessary to change plugs, if the colours of the wires in the mains lead of this appliance do not corre­spond with the coloured markings identifying the terminals of your plug, proceed as follows:
The wire which is coloured green and yellow must be connected to the termi­nal in the plug which is marked with the letter E or by the earth symbol z or col­oured green, or green and yellow.
The wire which is coloured blue must be connected to the terminal in the plug which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal in the plug which is marked with the letter L or coloured red.
WARNING: THIS APPLIANCE MUST BE EARTHED
Ensure power is not restored to the ap­pliance while installation work is being carried out.
Non-rewireable plugs BS 1363
If this machine is fitted with a non-re­wireable plug, the following information applies:
If the socket outlets are not suitable for the plug supplied with the product, it must be cut off and an appropriate plug fitted. The plug cut from the flexible cord should be disposed of and on no account be in­serted into any socket elsewhere in the house (electric shock hazard). The fuse cover must be refitted when changing the fuse, and if the fuse cover is lost, the plug must not be used until a suit­able replacement is obtained. The colour of the correct replacement cover is that of the coloured insert in the base of the plug, or the colour that is embossed in words on the base of the plug (as applicable to the design of plug fitted). Replacement fuses should be ASTA ap­proved to BS 1362 and have the cor­rect rating. Replacement fuse covers may be purchased from your local elec­trical supplier or Service agent.
32
Consumption data
Programme Cap-
COTTONS Extra dry
Normal +
(1)
Normal Normal
Hand iron rr Hand iron
(1)
rr 5 1200
Machine iron
acity
Consumption data
Final spin speed
(in a domestic
washing machine)
Electricity
consump-
tion
kg rpm kWh 10 A
5 1200
1400 1600
5 1200
1400 1600
3.4
3.3
3.0
2.9
2.75
2.45
5 800 (70 % residual moisture) 3.5 109 88
5 1200
1400 1600
2.75
2.6
2.35
5 800 (70 % residual moisture) 2.85 91 74
2.1 1400 1600
5 1200
1400 1600
1.95
1.65
1.7
1.55
1.25
Drying time incl.
cooling down time
Minutes
(2)
16 A
102
99 89
92 88 79
88 85 77
67 66 57
58 55 47
(2)
84 81 74
74 71 64
71 68 62
57 54 47
47 44 38
MINIMUM IRON Normal Hand iron
(1)
2.5 1000 (50 % residual moisture) 1.3 52 44
2.5 1000 1.15 48 40
Special care Woollens, Ha nd care Smoothing
(1)
Test performance in accordance with EN 61121/A11.
(2)
Drying times may vary slightly. For fuse rating see data plate.
1 0.2 3 3
2.5 0.3 8 8
All values obtained in accordance with standard test EN 61121/A11.
Different types of fabric, the load and residual moisture after spinning may affect the figures given.
33
Technical data
Technical data
Height. . . . . . . . . . . . . . . . . . . . . . . . . .
850 mm (adjustable +10/-5 mm)
Width . . . . . . . . . . . . . . . . . . . . . . . . . .
Depth . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . . .
Drum volume . . . . . . . . . . . . . . . . . . . .
Maximum capacity. . . . . . . . . . . . . . . .
Capacity of condensed
water container . . . . . . . . . . . . . . . . . .
Maximum delivery head. . . . . . . . . . . .
Maximum drain hose length. . . . . . . . .
Voltage . . . . . . . . . . . . . . . . . . . . . . . . .
Rated load . . . . . . . . . . . . . . . . . . . . . .
Fuse rating . . . . . . . . . . . . . . . . . . . . . .
Electricity consumption . . . . . . . . . . . .
Test certificates awarded. . . . . . . . . . .
595 mm
600 mm (incl. distance from wall)
52 kg
103 l
5 kg dry weight
approx 4 l
1 m
3 m
see data plate
}
see section Consumption data
Radio/TV suppressed, VDE
34
35
Alteration rights reserved/002 0600
This paper is made from 100% chlorine free bleached cellulose and is recyclable.
Loading...
