Operating instructions
for condenser tumble dryer
T 4859 Ci SUPERTRONIC
To avoid the risk of accidents
or damage to the appliance
it is essential to read these
instructions before it is installed
and used for the first time.
en-GB
M.-Nr. 07 737 880
Caring for the environment
Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and should be recycled.
Ensure that any plastic wrappings,
bags, etc are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose it with
your household waste.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
Make sure that your laundry is
–
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
Load according to the optimum
–
amount of laundry recommended for
the programme being used (see
Programme chart).
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
– Make sure the room in which the
dryer is located is well ventilated.
– Make sure the fluff filters are clean
before using the dryer.
– Check the condenser unit from time
to time and clean it when necessary.
Please dispose of it at your local
community waste recycling centre or
contact your dealer for advice. Ensure
that it presents no danger to children
while being stored for disposal.
2
Contents
Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the tumble dryer.........................................14
Control panel .....................................................14
Selector sensors ..................................................15
Structure of the main menu ..........................................17
Miele{home .....................................................19
Before using for the first time.......................................21
Notes on laundry care .............................................23
Garment care label symbols .........................................23
Tips on drying ....................................................23
1. Sort the laundry and loading the drum .............................24
2. Select a programme.............................................25
3. Start the programme ............................................28
4. Programme end - unload the drum ................................30
Extras ..........................................................31
Short............................................................31
Low temperature ..................................................31
Favourite programmes ............................................32
Programme chart .................................................34
Cleaning and care ................................................39
Emptying the condensed water container...............................39
Cleaning the fluff filters .............................................40
Cleaning them whilst dry .........................................40
Cleaning them with water .........................................41
Cleaning the tumble dryer ...........................................42
Cleaning the condenser unit .........................................43
Removing the condenser unit......................................43
Checking the condenser unit ......................................44
Cleaning the condenser unit.......................................44
Replacing the condenser unit......................................45
Problem solving guide ............................................46
Check and fault messages in the display ...............................46
An unsatisfactory drying result .......................................48
Other problems ...................................................49
Changing the lamp ................................................51
3
Contents
After Sales service................................................52
Repairs..........................................................52
Future updates (PC) ...............................................52
Appliance guarantee ...............................................52
Optional accessories ...............................................52
Installation and connection ........................................53
Front view........................................................53
Installation site ....................................................54
Building under a continous worktop / in a kitchen run ...................54
Levelling the appliance...........................................55
Room ventilation ................................................55
Washer-dryer stack..............................................55
Before moving the tumble dryer again (e.g. when moving house) .........55
Matching the fascia panel to the height of adjacent drawer fronts ............56
Removing the spacer bars ........................................56
Fitting the front panel ...............................................57
Front panel dimensions ..........................................57
Fitting the front panel ............................................57
Fitting a door front panel made by another manufacturer...................58
Preparing the front panel .........................................58
Preparing the fixing points ........................................59
Fitting a plinth facing ...............................................60
External condensed water outlet ......................................61
Arranging the drain hose .........................................61
External drainage via a sink or gully ................................62
Installation conditions requiring a non-return valve .....................62
4
Contents
Electrical connection .............................................64
Electrical connection U.K. ...........................................64
Consumption data ................................................65
Technical data ...................................................66
Settings menu ...................................................67
Open the Settings menu ............................................67
Language J ......................................................67
Time ............................................................68
Drying levels .....................................................68
Extended cool down ...............................................69
Airways indicator ..................................................69
Code ...........................................................70
Buzzer ..........................................................72
Keypad tone .....................................................72
Brightness .......................................................72
Contrast .........................................................72
Display / keypad illumination .........................................72
Memory .........................................................73
Anti-crease.......................................................73
5
Warning and Safety instructions
It is essential to read these instructions.
~
This tumble dryer conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
This tumble dryer is not designed for commercial use. It is
~
intended for use in domestic households and similar working and
residential environments.
The tumble dryer is not intended for outdoor use.
~
It must only be used as a domestic appliance to dry items which
~
have been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. If
using dry cleaning kits, do so at your own risk, and follow the
instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation.
6
Warning and Safety instructions
The tumble dryer can only be used by people with reduced
~
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are are supervised whilst using it or have been
shown how to use it in a safe way and understand the hazards
involved.
Safety with children
Children under 8 years of age must be kept away from the tumble
~
dryer unless they are constantly supervised.
Children 8 years and older may only use, clean or maintain the
~
tumble dryer without supervision if they have been shown how to do
so in a safe way and understand the hazards involved.
The tumble dryer is not a toy! To prevent the risk of injury, do not
~
allow children to play with it or near it, or to play with the controls.
7
Warning and Safety instructions
Technical safety
Before setting up the tumble dryer, check it for any externally
~
visible damage.
Do not install or use a damaged tumble dryer.
Before connecting the tumble dryer, ensure that the connection
~
data on the data plate (voltage and frequency) match the mains
electricity supply. If in any doubt, consult a qualified electrician.
The electrical safety of this tumble dryer can only be guaranteed
~
when correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician. Miele cannot be held liable for the
consequences of an inadequate earthing system (e.g. electric
shock).
Do not connect the tumble dryer to the mains electricity supply by
~
an extension lead. Extension leads do not guarantee the required
safety of the tumble dryer (e.g. danger of overheating).
If the electrical connection cable is faulty it must only be replaced
~
by a Miele approved service technician to protect the user from
danger.
Unauthorised repairs could result in unforeseen dangers for the
~
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician, otherwise any
subsequent damage will not be covered by the guarantee. Ensure
current is not supplied to the tumble dryer until after maintenance or
repair work has been carried out.
8
Warning and Safety instructions
Faulty components must only be replaced by genuine Miele
~
original spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
The tumble dryer must be isolated from the electricity supply in
~
the event of a fault and during cleaning and maintenance.
The tumble dryer must not be used in a non-stationary location
~
(e.g. on a ship).
Do not make any alterations to the tumble dryer, unless
~
authorised to do so by Miele.
In areas which may be subject to infestation by cockroaches or
~
other vermin, pay particular attention to keeping the tumble dryer
and its surroundings in a clean condition at all times. Any damage
which may be caused by cockroaches or other vermin will not be
covered by the guarantee.
9
Warning and Safety instructions
Correct use
To prevent the risk of fire, the following textiles must not be dried
~
in this appliance:
items which have not been washed.
–
items, such as workwear, which have not been thoroughly
–
cleaned and which are still soiled with grease, oil or other
deposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned there is a danger that
these might self-ignite when heated, even after they have been
removed from the dryer at the end of the programme.
– items (e.g. mops and floor cloths) which have been treated with
inflammable cleaning agents or which contain residues of
acetone, alcohol, benzine, petrol, kerosene, stain remover,
turpentine, wax and wax remover or other chemicals.
– items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items, ensure that you use
additional detergent and select a high temperature. If in doubt,
wash the items several times.
Remove all items such as lighters and matches from pockets.
~
Warning: Do not switch the tumble dryer off before the drying
~
programme has finished. If this is done, the laundry must be hung
up or spread out to cool it down.
10
Warning and Safety instructions
Danger.
~
This tumble dryer must not be connected to a controllable socket
(e.g. a timer switch or a peak load shut-off device).
If the dryer programme were to be interrupted before the end of the
cooling down phase, the laundry could self-combust.
To prevent the risk of fire, the following must not be tumble dried:
~
items which have been cleaned using chemicals (e.g.
–
professional dry-cleaning agents).
fabrics which contain a large proportion of rubber, foam rubber or
–
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of
igniting in the dryer.
In many programmes, the heating phase is followed by a cooling
~
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
Fabric conditioner and similar products must be used according
~
to the instructions on the manufacturer's packaging.
Do not let anyone sit or lean on the door, as this can cause the
~
tumble dryer to tip up.
Always close the door after use. This way you will avoid the
~
danger of:
–
children climbing into the dryer or hiding things in it.
–
pets or other small animals climbing into it.
11
Warning and Safety instructions
The dryer must not be used without the fluff filters in place or if
~
the fluff filters are damaged in any way.
The fluff filters must be cleaned regularly.
~
The dryer must not be used without the condenser unit in place.
~
The fluff filters must be thoroughly dried after cleaning. Damp or
~
wet filters could cause operational faults.
Do not install the tumble dryer in a room where there is a risk of
~
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and in the
drain hose. The ambient room temperature should be between +2°C
and +35°C.
If the water is drained externally instead of being collected in the
~
condensed water container, make sure the drain hose is securely
attached if you hang it in a sink or basin to avoid the hose slipping
and the water causing damage.
Condensed water is not drinking water.
~
It can cause health problems in both people and animals.
Always keep the area around the tumble dryer free of dust and
~
fluff. Dust drawn into the tumble dryer can cause blockages in the
condenser unit over time.
The tumble dryer must not be hosed down.
~
12
Warning and Safety instructions
Accessories
Only use genuine Miele original spare parts and accessories with
~
this tumble dryer.
If non-Miele parts are used, guarantee, performance and product
liability claims may be invalidated.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
13
Operating the tumble dryer
Control panel
a Miele{home
Symbol for Miele|home enabled
appliance
b Information sensor :
The sensor lights up when
information about the menu in the
display is available.
c Service interface
This is used by service technicians
to run diagnostic checks on your
machine, or to update programming
data in the future.
d Selector sensors
A sensor is active when it is lit up.
See next page for more information.
e Display
For showing:
–
the functions selected
–
the programme sequence
–
information
–
error messages
–
the time of day
–
the position of an entry using the
scroll bar
f Clear sensor U
For returning to the previous menu.
–
– For returning to the main menu when
touched twice.
– For deleting the values set
previously.
– For cancelling the programme.
g Start sensor
The programme selected is started
by touching this sensor when it is
illuminated green.
h K button
For switching the dryer on and off.
To save energy the dryer will switch
off automatically 15 minutes after the
end of the programme/anti-crease
phase or 15 minutes after the dryer is
switched on if it is not operated.
i / button
For opening the door. The dryer
does not need to be switched on at
the mains.
14
Selector sensors
Selecting an option
Operating the tumble dryer
The selector sensors are on the left and right of the display.
They light up when they are active. The selector sensors are
used for the following:
A dot (
The selector sensor on the left is active when the dot (
front of the word, the selector sensor on the right is active
when the dot (
Scrolling through the menus
If the menu lists more options than are visible in the display, a
scroll bar will appear on the right to show the position in the
list:
The sensors on the right can be used to scroll up or down the
list. Each touch of the sensor will move the list up or down
one line.
A dotted line will appear under the last option in the list.
Changing a value in the display
Use the + and - sensors on the right to alter the value
highlighted. Once altered confirm the value with the l
sensor at the bottom right hand side.
#) next to an option indicates that it can be selected.
Main menu
\
$ Favourite programmes
# Cottons
\
! Minimum iron
\
Time
#) is behind the word or symbol.
10 :21
10:21
m
+ $
– #
OK !
OK
#)isin
[
[
[
[
[
15
Operating the tumble dryer
Favourite programmes
You can save up to ten of your own
customised programmes under names
of your choice.
Drying assistant
This helps you find the correct wash
programme. The drying assistant
guides you step by step so that you
can select the best programme for the
fabrics and garments you want to dry.
Settings menu
The Settings menu
tumble dryer's electronics to suit
different requirements. See "Settings
menu" for more details.
Information sensor :
The Information sensor : will light up if
information about an option is available.
Touch the sensor if you want to read
the information.
! is used to alter the
Programme sequence display
Symbols in the display show which
section of the programme has been
reached.
Symbol Programme sequence
Start at / Finish at
R
Drying
G
Machine iron
I
Hand iron rr
G
Hand iron r
H
Normal
E
Normal+
F
Cooling down / Cancel
7
16
C
Cool air
Warm air
D
Anti-crease/Finish
O
Structure of the main menu
Favourite programmes
Cottons
– Minimum iron
– Delicates
– .... – Drying level: (depending on programme)
– .... – Duration(depending on programme)
Drying tips
Operating the tumble dryer
Favourite programmes
–
(listed alphabetically)
Create
–
Change
–
Delete
–
– Extras (depending on programme)
– Start at
– Finish at
– Cottons*
–
Delicates*
–
Cotton + synthetic*
–
Woollens
–
Silks
–
Microfibre*
–
Linen*
* This option has further choices.
17
Operating the tumble dryer
Settings !
Language
–
Time*
–
Drying levels*
–
Extended cool down
–
Airways indicator
–
Code
–
Buzzer
–
Keypad tone
–
– Brightness
– Contrast
– Display / keypad illumination
– Memory
– Anti-crease
– Miele|home**
– Remote control**
!
* This option has further sub-menus.
** Appears if the dryer has been fitted with the optional communication module.
18
Miele{home
a Communication enabled appliances
b Communication module
c SuperVision master appliance
d Power supply
e Miele|home Gateway
f (WLAN) Router
Possible connections (optional)
g PC, Notebook
h iPod* or iPhone*
i Connection with a domestic bus
system display
j Possible internet connection
* iPod und iPhone are registered trade
marks of Apple Inc.
19
Miele{home
This appliance is communication
enabled and can be linked into the
Miele|home system via a
communication module b (optional
accessory).
Miele|home enabled appliances send
information via the household power
supply network d to the master
appliance c / e about the operational
status of the appliances, as well as
information about the progress of the
programme.
Displaying information, controlling
appliances
– SuperVision master appliance c
The status of other communication
enabled appliances in the system
can be shown in the display of the
SuperVision master appliance.
– Mobile terminal appliances g/h
A PC, Notebook or an iPod* /
iPhone* can be used within the
operating radius of a WLAN f to
display status information about the
networked appliances and to carry
out some operational commands.
Optional accessories required
Communication module XKM 2000
–
Miele|home Gateway
–
Both of these are supplied with their
own installation and operating
instructions.
Further information
Further information about Miele|home,
SuperVision and future options can be
found on the Miele website and in the
operating instructions of the individual
Miele|home components, for example,
the Miele|home Gateway.
–
Household network i
Miele|home enables smarter living.
With the Miele|home Gateway e
communication-enabled appliances
can be integrated into the domestic
bus system.
* iPod und iPhone are registered trade
marks of Apple Inc.
20
1. Welcome screen
2. Set the language
Before using for the first time
Before using the dryer for the first time ensure that it is
correctly installed and connected. See "Installation and
connection".
Preparing the dryer for use is done in five stages. The dryer
guides you automatically through steps 1. to 5.
Switch the dryer on with the K button.
^
The welcome screen will appear in the display for 3 seconds.
The display for setting the language will then appear.
Sprache
\
$ deutsch (
# english
\
! español
\
^ Select the language you want.
^ The sensors on the right can be used to scroll up or down
the list.
^ Confirm the language you have selected with
10:21
p
OK !
OK.
[
[
[
21
Before using for the first time
3. Set the time of day (if required)
Enter the time of day.
Time
10 :21
OK !
+ and - to set the hour.
Use
^
Confirm with
^
4. Miele|home message
This communication enabled dryer can transmit programme
data through the power lines to the Miele|home system if it
has been fitted with a communication module (optional
accessory).
^ Confirm the message with
5. Continue setting the dryer up as described in the Operating instruction manual.
The dryer is correctly set up once a programme lasting
longer than one hour has been run (See "2. Selecting a
programme").
The welcome screen and request to set the language will
appear in the screen after switching the dryer on again if a
programme lasting less than 1 hour was run.
OK. Then set the minutes and confirm with OK.
OK.
+ $
– #
[
[
[
22
^
Confirm the message with
OK.
Notes on laundry care
Garment care label symbols
Drying
q Normal/higher temperature
r Reduced temperature:
Select Low temperature
(for delicate textiles)
s Do not tumble dry
Ironing
I Very hot
H Hot
G Warm
J Do not iron
Tips on drying
– Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
–
Do not put soaking wet items into the
tumble dryer. Spin fabrics for at least
30 seconds before drying.
–
Open jackets
evenly.
–
Use the Automatic plus programme
for drying mixed loads of cotton and
minimum iron fabrics.
–
Woollens and wool blends
become matted and shrink if dried in
a tumble dryer. They can, however,
be "fluffed up" using the Woollens
handcare programme.
so that they can dry
tend to
Down-filled garments
–
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Gentle smoothing programme.
Pure linen
–
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough.
Loopknit garments
–
underwear) tend to shrink depending
on their quality. Do not over-dry
these textiles. When purchasing
these garments it is advisable to take
their shrinkage properties into
account.
– Minimum iron fabrics
more, the larger the load. This is also
the case for garments made from
very fine weave fabrics, such as
shirts or blouses.
If in doubt, divide the garments into
smaller loads.
–
Starched laundry
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–
New dark coloured garments
be washed and dried separately
from light coloured garments to avoid
the danger of colours running and
discolouring other garments or even
plastic components in the dryer.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
should only be machine
have linings
(e.g. T-shirts and
tend to crease
can be dried in the
should
23
1. Sort the laundry and loading the drum
Prepare the laundry
To ensure an even drying result sort the
washed laundry according to:
..
. . . the drying level required,
. . . the type of fibre or weave,
. . . size,
. . . the moisture content after spinning.
Make sure that objects, e.g.
,
detergent dispensing balls, have
been removed from the laundry.
They could melt and cause damage
to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
– Fasten duvet covers, pillow cases
etc. to prevent small items from
being rolled up inside them.
– Fasten zips, hooks and eyes etc.
– Tie fabric belts and apron strings.
Load the tumble dryer
Press the a button to open the
^
door.
Load the laundry loosely into the
^
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause unnecessary
wear and tear to the laundry, and
give a disappointing drying result.
^ Before closing the door make sure
the fluff filter is correctly positioned.
– Sew in or remove underwiring from
bras.
24
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^
Shut the door either with a gentle
swing, or lean against it and push it
shut.
Switch the dryer on with the K button
2. Select a programme
Main menu
\
$ Favourite programmes
# Cottons
\
! Minimum iron
\
Select the programme you want: Use the right hand
^
sensors to show more programmes.
An additional menu may appear depending on programme selected:
– Programmes with drying levels
e.g. Cottons ... : You have a choice of drying levels with this
programme.
Cottons 1-6 kg 1:19 h
\
$ Drying level: Normal
# Extras
\
# Start at
\
^ Touch the Drying level sensor.
Drying level:
\
$ Normal (
# Hand iron r
\
! Hand iron rr
\
^
If there are more than 3 levels to choose from: Use the right
hand sensors to show more levels.
OK !
10:21
m
10:21
m
10:21
p
[
[
[
[
[
[
[
^
Touch the left hand sensor to confirm the drying level
required.
^
Confirm with OK.
25
2. Select a programme
– Programmes which operate by time
e.g. Warm air ... : You have to select a duration.
– Other programmes
Warm air 1-6 kg 0:15 h
\
$ Duration
# Extras
\
# Start at
\
Touch the Duration sensor.
^
Use the
^
highlighted.
Confirm the value you have set with
^
– Cool air: 20 mins - 1 hour
– Warm air: 15 mins - 2 hours
– Timed drying hygiene: 1 hour - 2 hours
e.g. Gentle smoothing ... : These programmes have fixed
drying levels / durations and cannot be altered.
\
\
+ and - sensors on the right to alter the value
Gentle smoothing 1 kg 0:58 h
$ Start at
# Finish at
0:25
h:min
OK.
10:21
+ $
– #
OK !
10:21
[
[
[
26
Select Extras
2. Select a programme
Start at / Finish at
OK.
10:21
OK !
10:21
+ !
[
[
[
[
Extras
\
$ 8 Short
# 9 Low temperature
\
Select the Extra you require.
^
9 will appear to show which Extra has been selected.
A tick
Confirm with
^
You can set the start (Start at) or the end (Finish at) time of
a programme.
The start and end time can be set in steps of 15 minutes. You
can delay the programme start time or the programme end
time up to a maximum of 24 hours. With the first 15 minute
step the time will be adjusted to the next quarter of an hour.
^ Select the Start at or the Finish at option.
Cottons 1-6 kg 1:19 h
\
$ Extras
# Start at
\
! Finish at
\
^
+ and - to select the time you want for Start at or Finish
Use
at. Confirm the time you have selected with
OK.
01:11 – !
02:30 OK !
Please note: If you subsequently select or deselect an Extra
or alter the drying level, this can postpone the programme
end time.
27
3. Start the programme
Starting a programme
Touch the green illuminated Start sensor.
^
In order to start the programme you must place your finger
in the centre of the Start sensor when touching it.
If the programme does not start: wait for 4 seconds and
touch the Start sensor in the middle again.
G
– The time remaining counts down in the display.
– Symbols in the display show which section of the
programme has been reached.
Time left
The following factors all affect the estimated time remaining:
the residual moisture after spinning; the type of textile; the
load; the ambient room temperature; fluctuations in the power
supply or a programme interruption.
The time left during drying is continually monitored and
altered. This is why the time shown in the display may
fluctuate duration the programme. This is quite normal.
Programmes can also finish earlier than expected, if, for
example, particularly fine fabrics are being dried, the load is
very small or items were partially dry beforehand.
Cottons 10:21
Normal - Extras (See :)
Time left: 1:19 h
Change !
[
Some changes can be made after starting a programme:
Selecting a different programme
You cannot change to another programme once a
programme has started (this prevents unintentional
alterations).
You will need to cancel the current programme before you
can select a new one.
28
Cancelling a programme
Touch the U sensor.
^
3. Start the programme
Cottons
: Cancel programme?
! Continue:
\
Select Cancel.
^
The items will be cooled down
temperature reached and how long they have been dried
for.
If you select U and Cancel,
display.
^ Press the s button to switch the dryer off.
^ Press the s button to switch the dryer on.
^ Select another programme and start it.
An alternative way to cancel
^ Press the a button.
Adding or removing laundry after a programme has started
^
Press the a button.
^
Open the door.
7, depending on the
O Finish will appear in the
10:21
Cancel !
[
,
Danger of burning:
Do not touch the back of the drum when adding or
removing items. The drum and the items can get very hot.
^
Add or remove items as required.
^
Close the door.
^
Select a programme.
^
Press the Start button.
29
4. Programme end - unload the drum
Before the end of a programme
There is a cooling down phase at the
end of the drying sequence:
7
"Cooling down" appears in the display.
The programme is not finished until the
cooling down phase has been
completed.
Programme end - unload the drum
O Anti-crease and Finish will appear in
the display to indicate that the
programme has finished. The buzzer
will sound at intervals.
The dryer has an energy saving mode:
After the programme has finished, the
display will go out and the indicator
light for the Start button will start to
flash slowly (see also Display/button
allocation in the the "Settings" menu.
During the Anti-crease phase, the
drum will rotate at intervals to prevent
laundry creasing. This is quite normal.
^ Press the a button to open the
door.
Press the s button to switch the
^
dryer off.
Close the door.
^
Empty the condensed water
^
container unless the dryer has been
connected to an external drainage
system in which case it does not
have to be emptied.
Please see "Cleaning and care" for
^
details.
Drum lighting
The lighting only comes on when the
door is opened if the dryer is switched
on. It will go out after a short while if the
door is left open to save energy.
^
Remove the laundry.
Check that all items have been
removed from the drum. If items are
left in the dryer, they could be
damaged by overdrying when the
dryer is next used.
The dryer will switch off automatically
15 minutes after the end of a
programme/the end of the anti-crease
phase.
If the dryer is signed on to the
Miele|home system, it will not switch
off automatically.
30
Extras
Short
For drying fabrics which can withstand
higher temperatures and have q on the
care label. Do not use on minimum iron
or delicate fabrics.
This option uses a higher
–
temperature for a shorter drying time.
Low temperature
Delicate and minimum iron fabrics with
the r symbol on the care label (e.g.
acrylic garments) are dried at a lower
temperature.
– This option uses a lower temperature
and a longer drying time.
Note
You can also alter the drying levels and
cooling down periods for some
programmes (see "Settings menu").
This dryer also has a buzzer and an
anti-crease phase at the end of the
programme which can be altered (see
"Settings").
Optional extras
This dryer offers the following extras:
Short
Cottons ##
Minimum iron ##
Warm air #
However, You have to choose either
the Short or the Low temperature
option.
Low
temperature
31
Favourite programmes
You can save up to ten programmes with the settings you
have selected for them under names of your choice. The
name can have up to 12 characters.
The favourite programmes which have been set are stored
alphabetically.
To save a favourite programme
There are two ways of saving a programme as a favourite.
1. Open the Favorite programmes menu and select Create.
You can then select a programme in the usual way.
2. If you alter a drying level or select an Extra when you
select the programme: Also select Save as.
To enter a name for a favourite programme
Name: ? A A A A A A A A A A A
) A BCDEFGHIJKLMNOPQRS
\
! Select character
\
^ Select the first character and confirm this with Select
character.
Use the
the characters.
^
After the first letter in upper case has been entered the
display will change automatically to display letters in lower
case. After a space has been entered the display will revert
to upper case again.
* sensor to scroll to the right to select the rest of
10:21
*
[
32
To save a name for a favourite programme
Favourite programmes
Name:Dry_______
\
$ Space
) ghijklmnopqrstuvwx y
\
! Select character
\
Select Confirm name.
^
To select a favourite programme
Call up the Favorite programmes menu. The saved
^
programmes will appear in alphabetical order.
Select the favourite programme you want.
^
^ Touch the green illuminated Start sensor. The programme
will start.
To change a favourite programme
^ Select the Change option.
^ Select the favourite programme you wish to change.
^ Make any changes and then save it under the same name.
The altered parameters will be active the next time the
favourite programme is started.
To delete a favourite programme
10:21
Delete character $
*
Confirm name !
[
[
[
If you have already saved ten favourite programmes then you
will have to delete one of them before you can save a new
programme.
^
Select the Delete option.
^
Select the favourite programme you wish to delete.
^
Confirm the deletion.
33
Programme chart
Cottons Max. load 6 kg*
Extra dry, Normal+, Normal**
Use for Single and multi-layered cotton fabrics such as towelling, T-shirts,
underwear, flannelette bed linen and baby clothes.
Tip
Hand iron r, Hand iron rr, Machine iron
Use for Cotton or linen fabrics e.g. Table linen, bed linen, starched laundry.
Tip To prevent laundry from drying out, it should be rolled up until you are
Minimum iron Max. load 3 kg*
Normal+, Normal, Hand iron r
Use for Minimum iron cotton, synthetic and mixed fibre fabric. e.g. tops,
Delicates Max. load 2 kg*
Normal+, Normal, Hand iron r, Hand iron rr
Use for Synthetic, mixed fibre, rayon and easy care cotton, e.g. shirts, blouses,
* Weight of dry laundry
Note for test institutes:
** Test programme (without selecting any Extra options) in accordance with
Regulation 392/2012/EU for energy labelling measured in accordance
with EN 61121.
Select Extra dry for multi-layered and very thick fabrics.
–
Do not use Extra dry for loopknit fabrics (e.g. T-shirts, underwear,
–
baby clothes), as they have a tendency to shrink.
ready for ironing.
dresses, trousers, skirts and table cloths.
lingerie and appliquéd garments.
34
Programme chart
Automatic plus Max. load 3.5 kg*
Normal+, Normal, Hand iron r
Use for Mixed loads of garments suitable for the Cottons and Minimum iron
programmes. Sort according to colour.
Shirts Max. load 2 kg*
Normal, Hand iron r
Use for Shirts and blouses.
Denim Max. load 3 kg*
Normal, Hand iron r
Use for Denim jeans, jackets, skirts and shirts.
Express Max. load 3.5 kg*
Extra dry, Normal+, Normal, Hand iron r, Hand iron rr, Machine iron
Use for Fabrics which can tolerate high temperatures and which can be dried
using the Cottons programme.
Tip – Short programme duration.
Woollens handcare Max. load 2 kg*
Use for Woollen garments and fabrics containing wool.
Tip – This programme only fluffs up woollen garments. They are not dried
completely by this programme.
–
Remove garments as soon as the programme has finished and
leave to finish drying at room temperature.
Silks handcare Max. load 1 kg*
Use for Silks (those suitable for drying in a tumble dryer), e.g. blouses and
shirts.
Tip
* Weight of dry laundry
–
Smooths out creasing caused during the spin cycle in the washing
machine.
–
Remove garments as soon as the programme has finished so that
they are easy to iron.
35
Programme chart
Sportswear Max. load 2 kg*
Normal+, Normal, Hand iron r
Use for Sportswear which is suitable for drying in a tumble dryer.
Outerwear Max. load 2 kg*
Normal, Hand iron r
Use for Outerwear which is suitable for drying in a tumble dryer.
Proofing Max. load 2 kg*
Use for Drying microfibre fabrics, skiwear, fine, closeweave cotton garments
(poplin) or tablecloths which are suitable for drying in a tumble dryer
and have been treated to provide a water and dirt resistant finish.
Tip
Pillows 1-2 pillows up to 80 x 40 cm
Large pillows 1 pillow up to 80 x 80 cm
Use for Pillows suitable for drying in a tumble dryer, with feather, down or
Tip Please observe the instructions on the care label. Pillows can still feel
* Weight of dry laundry
This programme includes a proofing fixing phase.
–
– Only use proofing agents containing fluorochemical compounds
which are stated by the manufacturer as being "suitable for use
on membrane textiles".
– Do not dry items which have been treated with proofing agents
containing paraffin. Fire hazard!
synthetic fillings.
damp after being dried. You can use this programme several times
until the pillow feels dry.
36
Programme chart
Gentle smoothing Max. load 1 kg*
Use for
Tip
Cool air Max. load 6 kg*
Use for Any item which only needs airing.
Warm air Max. load 6 kg*
Use for – Voluminous and multi-layered fabrics whose layers have different
Tip – Do not select the longest drying time to start with. Check the
Note You can use the Warm air programme to help remove odours from
* Weight of dry laundry
Cotton and linen fabric.
–
Minimum iron mixed fibre, cotton or synthetic fabrics, e.g.
–
trousers, anoraks, shirts.
Suitable for both dry and damp laundry.
–
Smooths out creasing caused during the spin cycle in the
–
washing machine.
Remove garments as soon as the programme has finished so
–
that they are easy to iron.
drying characteristics, e.g. jackets, pillows.
– For drying individual items, e.g. bath towels, swimwear,
tea-towels.
items as you are drying them to find the optimum time.
clean cotton clothing (select a duration of between 1/2 and 1 hour).
Items must be suitable for drying in a tumble dryer. Dampen the
garments a little beforehand or add a fabric conditioner sheet.
Odours will not be removed as effectively from any parts of the
garments which are made of synthetic fibres.
37
Programme chart
Hygiene programmes
In the Hygiene programmes the temperature is held constant for a longer period
of time to deactivate micro-organisms, e.g. bacteria or house dustmites, and also
to reduce the number of allergens in the laundry.
These programmes should not be interrupted as this would prevent the
micro-organisms from being deactivated.
Cottons hygiene Max. load 6 kg*
Normal
Use for Cottons and linen fabrics which are in direct contact with the skin, e.g.
underwear, nappies, towelling, bed linen, pillow and mattress covers.
Tip Only for drying fabrics which can withstand higher temperatures and
which have the q symbol on the care label.
Minimum iron hygiene Max. load 3 kg*
Normal
Use for Minimum iron items made of synthetic or mixed fibre, e.g. skirts, shirts
and blouses.
Tip Only for drying fabrics which can withstand higher temperatures and
which have the q symbol on the care label.
Timed drying hygiene Max. load: Depends on
fabric type
Use for – 6 kg* of items made of cotton or linen fabric.
–
3 kg* of minimum iron items made of synthetic or mixed fibre.
–
For airing individual items of laundry which are already dry or for
deactivating lice, dustmites and micro-organisms in washable
materials which are suitable for drying in a tumble dryer, e.g.
stuffed toys, and which have the q symbol on the care label.
Tip
* Weight of dry laundry
–
Do not select the longest drying time to start with. Check the items
as you are drying them to find the optimum time.
38
Emptying the condensed water
container
The condensed water will be collected
in the condensed water container
unless the appliance has been set up
to drain via the drain hose (see
installation).
Empty the condensed water
container after every drying
programme.
The drying programme will be
interrupted if the maximum level of the
condensed water container is reached.
A message will appear in the display.
Cleaning and care
^ Open the shutter and empty out the
water.
^ To replace the container, hold it at a
slight angle (as when removing it)
and push it in gently until you feel it
click into position.
^ To remove the message from the
display, switch the dryer off and then
on again.
^
Holding the container firmly in both
hands, as shown, pull it out slightly
towards the right-hand side.
^
Hold the container in a horizontal
position when carrying it.
Condensed water should not be
consumed. It could lead to health
problems for people and animals.
Condensed water can be put to
household use (e.g. used in a steam
iron or humidifier). To ensure that any
residual particles of fluff in the
condensed water are removed before
use, pass it through a fine sieve or
paper filter first.
39
Cleaning and care
Cleaning the fluff filters
The fluff which is created by the drying
process is collected by the fluff filters in
the door and the door opening. Clean
the filters after each drying
programme*.
Cleaning them whilst dry
Tip: You can also use a vacuum
cleaner to remove the fluff.
Remove any fluff from the hollow part
^
of the door opening. You could also
use a cleaning brush which is
available as an optional extra from
your Miele dealer or the Miele Spare
Parts Department, or use a vacuum
cleaner.
Also clean the door seal (2) with a
^
damp cloth.
Once clean, push the filter back into
^
the door holder until it clicks into
position. Ensure it is facing the
correct way.
^
Open the door and pull the fluff filter
(1) out of the door as illustrated.
^
Use your fingers to remove the fluff
from the surface of the filter.
40
^
Use your fingers or a vacuum cleaner
to remove the fluff from the two fluff
filters in the door opening.
^
Close the door.
* Always check the fluff filters if the
Clean out airways message
appears.
Cleaning them with water
If there is a great deal of compacted
fluff on any of the filters, they can be
removed and cleaned under hot
running water.
Open the door and pull the fluff filter
^
out of the door as described
previously.
The two filters in the door opening can
also be removed if you need to clean
them with water.
Cleaning and care
Do not replace them if they are
,
damp or wet. Damp or wet filters
could cause operational faults.
Push the large filter back into the
^
door holder until it clicks into position.
Ensure it is facing the correct way.
Replace the filters in the door
^
opening by first inserting them at the
bottom and then pressing them into
place at the top.
Lock both dials.
^
^
Turn dial a and pull the filter by the
dial out of the door opening as shown
b. Do the same on the other side.
^
Rinse all the filters under hot, running
water.
^
Then shake the filters until no more
water droplets are visible.
^
Dry the filters thoroughly with care.
^
Clean the area underneath these
filters, e.g. with a vacuum cleaner.
41
Cleaning and care
Cleaning the tumble dryer
Disconnect the tumble dryer from
the mains electricity supply.
Miele branded cleaning and
conditioning products are available to
order via the internet on
www.miele-shop.com.
Clean the housing and control panel
^
with a slightly damp cloth and a mild
detergent or soapy water.
The drum and other stainless steel
^
parts can be cleaned with a suitable
stainless steel cleaner following the
manufacturer's instructions.
Do not use solvents, abrasive
cleaners, glass cleaners or
all-purpose cleaners. These could
damage plastic sufaces and other
parts.
^ Dry all parts with a soft cloth.
42
Cleaning the condenser unit
Detergent residue, hair and fine fluff
from the dryer can get through the fluff
filters and block the condenser unit.
Dust from the room in which the dryer is
installed can also get into the
condenser unit and cause a blockage.
Check the condenser unit at least
once a year. Always check it if the
Clean out airways message
appears. Clean it if necessary.
Removing the condenser unit
Cleaning and care
Turn the lever on the inner cover
^
downwards to the vertical position.
^ Tilt the cover forwards.
^ Remove it by pulling it diagonally
upwards.
^
Open the service panel. Hold the
panel securely when doing this.
^
Now remove the panel by pulling it
diagonally upwards and place it to
one side.
^
Turn the lever on the condenser unit
upwards to the vertical position.
43
Cleaning and care
Pull the condenser unit out of its
^
housing by the handle.
Checking the condenser unit
If you cannot see any fluff:
Replace the condenser unit (see
^
following page).
If you can see some fluff:
Clean the condenser unit as
^
described below.
Cleaning the condenser unit
When rinsing the condenser unit,
^
make sure you position it as
shown in the next two illustrations.
^
Hold the condenser unit up to the
light as shown.
^
Check to see if there is any fluff
inside it.
The arrows in the illustration above
indicate where to look.
44
^
Use a shower head or similar to rinse
the unit out as shown.
Then flush the unit through from the
^
front.
^ Check the condenser unit again for
any visible fluff and if necessary flush
it through again until it has all gone.
^ Repeat as required.
^ Also make sure the rubber seals are
clean.
The rubber seals must not be
removed and must be free of kinks.
^
Shake the water off the condenser
unit until no more droplets of water
are visible.
Cleaning and care
Replacing the condenser unit
With the handle facing upwards,
^
push the condenser unit back into
position in its housing.
Turn the lever down to the horizontal
^
position, making sure that the hook
on the lever clicks into the groove.
When replacing the inner cover after
cleaning, ensure that the rubber seal
fits correctly into the groove.
Replace the inner cover making sure
^
the hooks locate correctly. Hold it at
an angle and push it gently
downwards.
^ Then turn the lever upwards into the
horizontal position to lock the cover.
^ Replace the service panel and press
the upper edge until it clicks into
position.
,
It is important to ensure that both
the condenser unit and the cover
are correctly positioned and locked,
otherwise water may leak from the
dryer.
Checking and cleaning the
condenser unit housing
^
Remove any soiling still visible inside
the housing unit by hand using a
damp cloth. Do not try and access
areas you cannot reach by hand!
45
Problem solving guide
With the help of the following notes minor faults in the performance of the
appliance, some of which may result from incorrect operation, can be put right
without contacting the Service Department.
Repair work to electrical appliances should only be carried out by a
,
suitably qualified person in strict accordance with current local and national
safety regulations. Repairs and other work by unqualified persons could be
dangerous. The manufacturer cannot be held liable for unauthorised work.
Check and fault messages in the display
Problem Possible cause Remedy
You are asked to enter a
code.
Adjust the load
1
N
The programme is
cancelled, the
buzzer sounds.
Empty the
container
The programme is
cancelled, the
buzzer sounds.
Access via a code has
been activated.
This is not a fault.
In some programmes, if
the drum has been
overloaded or
underloaded, the
programme will be
cancelled. This can also
happen if the items are
already dry.
The condensed water
container is full or there is
a kink in the drain hose.
Enter the code (see
Settings menu).
Use the Warm air
programme in future for
drying individual items.
– Open and shut the
door.
–
Empty out the
condensed water
container or check the
drain hose.
–
Switch the dryer off
and back on again.
46
Problem solving guide
Problem Possible cause Remedy
Clean out airways
You are asked to clean
the airways at the end of
a programme.
Clean out airways
,
A prompt which has not
been described
previously appears in
the display.
Comfort cooling
The programme
is cancelled, the
buzzer sounds.
The dryer is not working
efficiently or
economically.
Possible reason for this:
The fluff filter is clogged
with fluff or with detergent
residues.
See above for possible
causes and their
remedies.
A programme cannot be
started while there is a
fault message in the
display.
The programme has
finished but the laundry is
still being cooled down.
Cleaning the filters is
–
usually all that is
required.
However, if the
message does not go
out after you have
cleaned the filters, then
also check all the
possible causes
described under "The
drying process goes
on too long or even
switches off". (See
"Other problems").
– Open and shut the
door.
You can change the
parameters for this
message (See the
Settings menu).
– Make a note of what is
shown in the display.
– Try to resolve the
problem yourselft.
–
Switch the dryer off
and then on again.
–
If you do not succeed:
Call the Service
Department.
You can either unload the
drum and leave the
laundry to cool at room
temperature or leave it in
the tumble dryer to
continue cooling.
47
Problem solving guide
An unsatisfactory drying result
Problem Possible cause Remedy
The laundry is not
sufficiently dry.
Feather filled pillows
smell after drying.
Items made of synthetic
fibres are charged with
static electricity after
drying.
There is a build-up of
fluff.
* You can alter the drying levels for some programmes (see "Settings menu").
The load consisted of
different fabrics.
Feathers are a natural
product and this is quite
normal.
Synthetic fibres tend to
attract static charge.
Fluff is principally the
result of friction when
garments are being worn
and to some extent when
they are being washed.
Machine drying hardly
causes any fluff to form
and has no appreciable
effect on the lifetime of
the fabric.
Finish drying using the
–
Warm air programme.
Select a different
–
programme next time*.
The smell will dissipate
after sufficient airing.
Static charge can be
reduced by adding a
fabric conditioner to the
final rinse in the washing
programme or a fabric
conditioner sheet to the
load when drying.
Fluff is collected by the
fluff filters and can be
removed easily (see
"Cleaning and care").
48
Problem solving guide
Other problems
Problem Possible cause Remedy
The drying
process goes on
too long or even
switches off.
The request to clean the
airways may appear in the
display.
Ventilation to and from the
dryer may be insufficient,
e.g. because it is installed
in a room which is too
small. This can cause the
temperature in the room to
rise sharply.
The vents below the door
are blocked.
The fluff filters are clogged
up.
The fluff filters were wet
when replaced.
Detergent residues, hair
and fine fibres can block
the condenser unit.
The laundry has not been
spun sufficiently.
The tumble dryer has been
overloaded.
Metallic components, e.g.
zips have prevented the
dryer from registering the
correct moisture level in the
laundry.
Please check all the possible
causes and switch the dryer off
and then back on again.
Open a door or window while
–
the dryer is in operation for
increased air flow.
– Remove any objects that are
blocking the vents.
See "Cleaning and care".
– Remove any fluff.
– The fluff filters must be
completely dry.
See "Cleaning and care".
– The condenser unit must be
checked and cleaned if
necessary.
–
Make sure that your laundry is
thoroughly spun at the
appropriate spin speed in the
washing machine.
–
Do not exceed the maximum
load for the programme
selected.
–
Open zips next time.
–
If the problem occurs again,
dry garments with long zips
using the Warm air
programme (timed drying).
49
Problem solving guide
Problem Possible cause Remedy
Water leaks from the
dryer after the
condenser unit has
been cleaned.
The display and the
sensors are not lit up
and the Start sensor is
flashing slowly.
The programme does
not start.
The display is in a
different language.
The interior drum
lighting does not
come on.
The inner cover of
–
the condenser unit
has not been locked
properly and/or the
condenser unit has
not been positioned
correctly.
Fluff has collected in
–
the condenser unit
housing.
Standby. To save
energy the display and
sensor illumination
switches off
automatically.
No obvious cause. – Is the dryer switched on?
A different language
has been selected.
The lighting switches
off automatically (to
save energy).
The lock has been
activated.
Ensure that the condenser
–
unit is positioned correctly
and lock the inner cover.
Check the rubber seals.
–
Use a cloth to remove any
–
visible fluff from the inside
of the condenser unit
housing.
Touch the Start sensor. The
–
display and sensors will
light up.
– See "Settings".
– Is the plug correctly
inserted into the socket and
switched on?
– Is the door closed
properly?
– Has the fuse or circuit
breaker tripped?
Set the language you want.
The flag symbol J will guide
you.
–
Switch the dryer off and
then on again.
–
If the lamp needs to be
replaced, follow the
instructions in "Changing
the lamp" at the end of this
section.
–
Enter the code to
deactivate it and the light
will come on.
50
Changing the lamp
Disconnect the tumble dryer from
the mains electricity supply.
Problem solving guide
The light specification and maximum
wattage is stated on the data plate
and on the light cover.
Open the door.
^
You will find the interior light cover at
the top of the drum aperture.
^ Insert a suitable tool, such as a wide
bladed screwdriver, under the side
edge of the light cover as illustrated.
^
Apply a little pressure and whilst
doing so turn your wrist in the
direction of the arrow to open the
cover.
Turn the light anti-clockwise to
^
remove.
Replace the lamp.
^
To close the cover push it upwards
^
and press it on the left and right until
you hear it click into position.
Ensure that it is fitted into
,
position securely, as any moisture
could cause a short circuit.
The cover will open downwards.
The temperature resistant lamp should
only be ordered from your Miele Dealer
or the Miele Spare Parts Department.
51
After Sales service
Repairs
In the event of any faults which you
cannot remedy yourself, please contact
your Miele dealer or
–
the Miele Service Department (see
–
back cover for contact details).
When contacting your dealer or the
Service Department, please quote the
model and serial number of your
appliance, both of which are shown on
the data plate. This is visible when you
open the door.
Future updates (PC)
The indicator or check light marked PC
on the fascia panel is the interface used
by the Miele service technicians during
service work for testing purposes and
for updating the appliance's
programme data.
Appliance guarantee
In the U.K. your appliance is
guaranteed for 2 years from the date of
purchase. However you must activate
your cover by calling 0845 365 6640 or
registering online at www. miele.co.uk.
For information on the appliance
guarantee specific to your country
please contact Miele. See back cover
for contact details.
Optional accessories
Optional accessories for this dryer are
available from your Miele Dealer, the
Miele Spare Parts Department or via the
internet at www.miele-shop.com.
N.B. A call-out charge will be
applied for service visits where the
problem could have been resolved
as described in these instructions.
52
Please note that telephone calls may
be monitored and recorded for
training purposes.
Front view
Installation and connection
a Mains connection cable
b Condensed water container
c Control panel
d Door (can be fitted with a decor
panel)
e Service panel for condenser unit
f Hose for external drainage of
condensed water
(see "External condensed water
outlet")
g Rear view: Slot for Miele|home
communication module
h Intake and exhaust vents for cooling
the condenser unit
i Four height adjustable screw feet
53
Installation and connection
Installation site
Make sure the dryer door can be
,
opened without hindrance after
installation.
Building under a continous worktop /
in a kitchen run
This tumble dryer is specially designed
for installation under a continuous
worktop run in a fitted kitchen.
Slides* can be used to protect the
–
floor from damage when the machine
is pushed into position or taken out
for servicing.
– The electrical socket must be
located in an accessible position
near the tumble dryer.
N = Niche height (820-930 mm)
When moving the dryer do not lift it
by the drum door.
The dryer is supplied fitted with a
cover plate instead of a machine lid.
The cover plate is necessary to
ensure electrical safety and must not
be removed.
54
Please note:
Niche height Additional accessories
820 mm None
from
830-840 mm
from
870-885 mm
from
915-930 mm
* these accessories are available to order
required
Fit longer screw feet* (set to
approx. 40 mm)
One raising kit*
Two raising kits*
The tumble dryer must not be used
without the front panel in place.
If the kitchen run has a continuous
furniture plinth in place, a gap must
be made for the tumble dryer.
Installation and connection
Levelling the appliance
^ Turn the 4 screw feet to adjust the
dryer to the correct height and level.
Longer screw feet are available as
an optional accessory. Unscrew and
remove the feet supplied with the
appliance before fitting the longer
screw feet.
The cover plate on the dryer must
be aligned horizontally underneath
the worktop.
,
The ventilation gaps in the plinth
must not be covered over. This
would hinder a sufficient flow of air
to the dryer.
Room ventilation
Air taken in for use in the drying
process will be warm when it is
expelled from underneath the dryer.
This expelled air heats up the air in the
room. It is therefore very important to
ensure that the room is adequately
ventilated, particularly if the dryer is
located in a small room. Otherwise
running times and energy consumption
could be increased.
Washer-dryer stack
The tumble dryer can also be
combined with a Miele washing
machine in a washer-dryer stack. The
appropriate "WTV" stacking kit
(available to order) to match your dryer
is required.
,
The stacking kit must be fitted by
a suitably qualified fitter.
Before moving the tumble dryer
again (e.g. when moving house)
After each use a small quantity of
condensed water will collect in the area
around the pump. This water can run
out if the dryer is tipped up when it is
being moved. It is therefore a good
idea to run the Cool air programme for
approximately 1 minute before moving
it. Any remaining condensed water will
then be fed into the condensed water
container or out through the drain hose.
55
Installation and connection
Matching the fascia panel to
the height of adjacent drawer
fronts
The fascia panel can be aligned with
the drawer fronts by adjusting the
spacer bars.
^ Using a socket spanner, turn
clockwise or anti-clockwise until the
required height is reached.
If necessary individual bars can be
removed or more added.
^
To do this, use the socket spanner to
loosen the nuts.
An adapter kit with spacer bars and
longer screws can be ordered as an
optional accessory. This can be used to
add spacer bars from below up to a
maximum of 25 mm.
Removing the spacer bars
All the spacer bars can be removed if
the upper edge of the front panel needs
to be flush with the upper edge of the
appliance front directly underneath the
fascia panel. See "Fitting a front panel
made by another manufacturer".
Open the door.
^
^ Unscrew and remove the 3 screws
(see arrows).
^
Remove all the spacer bars.
The 3 holes which are now free should
be used to screw the front panel to the
machine front later on.
After fitting the bars, cut or pinch off
any excess length from the screws.
56
Installation and connection
Fitting the front panel
The appliance front can be fitted with a
door panel to match other kitchen units.
If fitted in a Miele kitchen, the door
panel can be ordered pre-drilled with
the necessary fixing holes.
If fitted in a non-Miele kitchen, a
suitable panel will have to be drilled
to suit by a qualified kitchen fitter.
See "Fitting a door front panel made
by another manufacturer" for details
on preparing and drilling the fixing
holes.
Front panel dimensions
Width
: 592-596 mm
Thickness
to the thickness of the adjacent unit
door front panels)
: 17 to 19 mm (corresponding
Fitting the front panel
Open the door.
^
Hold the front panel in the correct
^
position in front of the appliance
door.
^ Screw the front panel to the machine
door.
If all the spacer bars have been
removed:
Height
: The height of the door front
panel corresponds to the door height
(H) of the adjacent units.
You can also make use of the 3 holes at
the top of the door plate to screw the
front panel to the door plate.
57
Installation and connection
Fitting a door front panel made
by another manufacturer
Preparing the front panel
A Measure distance X for drilling the
hinge holes.
with spacer bars:
–
– without spacer bars:
(the front panel must be
correspondingly higher)
B Mark the two hinge holes and the
four smaller holes as shown in the
diagram.
Depending on country, this tumble
dryer is supplied either left or right
hand hinged.
For left hand hinging only:
front panel shown decor side face
–
down, upper edge at the bottom:
if width (b) increases, measurement a
must also be increased
58
b = 592 mm N a = 21.5 mm
b = 593 mm N a = 22.0 mm
b = 594 mm N a = 22.5 mm
b = 595 mm N a = 23.0 mm
b = 596 mm N a = 23.5 mm
H = height of adjacent furniture unit
doors.
Installation and connection
For right hand hinging only:
front panel shown decor side face
–
down, upper edge at the bottom:
if width (b) increases, measurement a
must also be increased
b = 592 mm N a = 21.5 mm
b = 593 mm N a = 22.0 mm
b = 594 mm N a = 22.5 mm
b = 595 mm N a = 23.0 mm
b = 596 mm N a = 23.5 mm
C Drill the two hinge holes (C 35
mm/15.5 mm deep) in the back of
the front panel.
D Next, drill the four smaller holes
(C 7 mm/10 mm deep) in the back of
the front panel.
E Shorten the front panel from the
bottom to height H.
Preparing the fixing points
F Hold the pre-drilled front panel in the
correct position in front of the
machine door.
H = height of adjacent furniture unit
doors.
G Mark the fixing points on the back of
the front panel through the holes in
the machine door plate (see arrows
in the illustration).
H Remove the front panel.
I Now drill holes (C 2.5 mm/10 mm
deep) in the back of the front panel.
59
Installation and connection
Fitting a plinth facing
The gap between the lower edge of the
tumble dryer plinth and the floor can be
closed up using a suitable kitchen
furniture plinth facing.
The tumble dryer plinth has a special
groove in which a plinth facing can be
fitted.
Plinth facing dimensions
Length
Thickness
Height (
must be calculated after aligning the
height of the appliance with the screw
feet or after fitting the raising kit(s).
Installation
: 592 - 596 mm
:8mm
H): The plinth facing height
Useful tip:
If the dryer is fitted on a raising kit, you
can use double-sided adhesive tape on
the back of the plinth facing to secure it
to the raising kit.
^
Calculate height (H) from the floor up
into the groove (on the underside of
the tumble dryer).
^
Cut the plinth facing to size.
^
Slide it into the groove.
60
External condensed water
outlet
General notes
When drying is in progress, condensed
water is pumped into the condensed
water container through the drain hose
at the back of the dryer. The
condensed water can also be drained
off directly if the dryer is installed near a
sink, drain outlet etc. so that the
condensed water container does not
have to be emptied.
Drain hose length ............1.00 m
Extension hose ..............2.00 m
(accessory)
Maximum delivery head .......1.50 m
Maximum drain hose length ....4.00 m
,
If the on-site water drainage
system is not fitted with a non-return
valve or an appropriate air gap, an
air gap or the non-return valve
supplied with the dryer must be
fitted to prevent the risk of
back-flow. (See "Installation
conditions requiring a non-return
valve").
Installation and connection
Unclip the drain hose from clips (1)
^
and (2).
^ Then pull it off connection (3).
Maximum delivery head
with non-return valve fitted .....1.00 m
Arranging the drain hose
,
Do not pull on the drain hose
and do not stretch it or allow it to
become kinked as it could get
damaged.
^
The lower clip (4) can be opened to
allow you to take the drain hose out
or to feed the mains cable through it.
61
Installation and connection
External drainage via a sink or gully
See "Front view" illustration.
^
If you want to drain the water off
,
into a sink you will need to secure
the hose carefully, e.g. by tying it to
a tap to make sure it cannot slip
during use. Otherwise there is a risk
of overflowing water which could
cause damage.
Use the bow-shaped guide to
^
prevent the drain hose from
becoming kinked (see "Front view"
illustration).
Installation conditions requiring a
non-return valve
If the on-site water drainage
,
system is not fitted with a non-return
valve or an appropriate air gap, an
air gap or the non-return valve
supplied with the machine must be
fitted to prevent the risk of
back-flow. Otherwise water could
leak out of the dryer and cause
damage.
Example: Connection to a sink drain
outlet
The drain hose with non-return valve
fitted can be connected directly to a
suitable sink drain outlet.
^ Remove the following from the back
of the dryer at the bottom:
Adapter 1 and hose clip 3 behind it.
A non-return valve is required:
–
If the tumble dryer is connected to a
sink drain outlet (see the following
section).
–
If the tumble dryer is to be
connected to a drainage system
already in use by another
appliance, e.g. a dishwasher or
washing machine.
62
1 Adapter
2 Nut
3 Hose clip
4 Extension hose (accessory)
Installation and connection
Fit adapter 1 to the sink drain outlet
^
using nut 2.
If this nut has a flat disc in it you
should take the disc out first.
Attach the end of the extension hose
^
4 to adapter 1.
Use a screwdriver to tighten hose
^
clip 3 up close to the nut.
Non-return valve 5 has to be
,
fitted with the arrow pointing in the
direction of flow (i.e. towards the
sink). Otherwise water will not drain
out of the machine.
^ Fit non-return valve 5 to the drain
hose on the dryer 6 (make sure it is
fitted correctly (see arrow on
non-return valve).
^ Secure the non-return valve using
hose clips (accessory).
5 Non-return valve (accessory)
6 Tumble dryer drain hose
63
Electrical connection
Electrical connection U.K.
All electrical work should be carried out
by a suitably qualified and competent
person, in strict accordance with
current national and local safety
regulations (BS 7671 in the UK).
Ensure power is not supplied to the
appliance until after installation work
has been carried out.
The appliance is supplied with a mains
cable with moulded plug ready for
connection to a 230-240V mains
supply. Please ensure the connection
data quoted on the data plate match
the household mains supply.
Connection should be made via a
suitable switched socket which is easily
accessible after installation.
For extra safety it is advisable to protect
the appliance with a suitable residual
current device (RCD). Contact a
qualified electrician for advice.
Non-rewireable plugs BS 1363
The fuse cover must be refitted when
changing the fuse, and if the fuse cover
is lost, the plug must not be used until a
suitable replacement is obtained. The
colour of the correct replacement cover
is that of the coloured insert in the base
of the plug, or the colour that is
embossed in words on the base of the
plug (as applicable to the design of
plug fitted).
Replacement fuses should be ASTA
approved to BS 1362 and have the
correct rating. Replacement fuses and
fuse covers may be purchased from
your local electrical supplier.
WARNING: THIS APPLIANCE
MUST BE EARTHED
Do not connect via an extension lead.
Extension leads do not guarantee the
required safety of the appliance (e.g.
danger of overheating).
64
Consumption data
1
Load
Cottons Normal
Cottons Normal 6.0
Cottons Normal
+ Short
+ Low temperature
Cottons Hand iron rr 6.0
Minimum iron Normal 3.0 1200 40 1,15 34
Minimum iron Normal
+ Short
+ Low temperature
Minimum iron Hand iron 3.0 1200 40 0,95 30
Automatic plus Normal 3.5 800 50 2,10 119
Shirts Normal 2.0 600 60 1,25 43
Delicates Normal 2.0 800 50 1,20 81
Proofing Normal 2.0 800 50 1,25 59
Denim Normal 3.0 900 60 2,40 119
Woollens handcare 2.0 1000 50 0,15 4
Sportswear Normal 2.0 600 50 1,35 61
Outerwear Normal 2.0 800 50 1,40 72
Cottons hygiene 6.0 1000 60 3,70 118
1
Weight of dry laundry
2
Test programme in accordance with Regulation 392/2012/EU for energy labelling measured in
accordance with EN 61121.
All data was calculated using EN 61121 unless otherwise stated.
Notes for test institutes:
Before testing in accordance with EN 61121, drya3kgload of cotton laundry with 70% residual
moisture as per the above standard using the Cottons Normal programme without any extra options.
Consumption data can vary from the nominal values given above depending on the size of the
load, types of textiles, residual moisture levels after spinning, fluctuations in the electricity
supply and any extra options selected.
2
kg rpm % kWh min.
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
3.0
3.0
Final spin speed
in a domestic
washing machine
1000
1000
1200
1400
1600
1800
1000
1000
1000
1200
1400
1600
1800
1200
1200
Residual
moisture
60
60
53
50
44
43
60
60
60
53
50
44
43
40
40
Energy Duration
3,58
2,00
3,25
3,10
2,75
2,70
3,35
3,60
2,65
2,35
2,20
1,90
1,80
1,15
1,20
99
59
91
86
78
77
88
120
71
63
60
52
51
32
39
65
Technical data
Height 820 mm
Width 595 mm
Depth 575 mm
Suitable for stacking Yes
Weight 54 kg
Drum volume 100 litres
Maximum capacity 6 kg dry weight
Capacity of condensed water container approx. 3.5 litres
Drain hose length 950 mm
Maximum delivery head 1.5 m
Maximum drain hose length 4 m
Length of connection cable 2 m
Voltage see data plate
Connected load see data plate
Fuse rating see data plate / plug
Lamp wattage see data plate
Energy consumption see "Consumption data"
Test certificates awarded see data plate
66
The Settings menu is used to alter the dryer's electronics to
suit different requirements.
Settings can be altered at any time.
Open the Settings menu
Settings menu
To select a setting
Language J
Main menu
\
$ Settings !
# Favourite programmes
\
# Cottons
\
Use the top right hand sensor to select the Settings
^
menu.
^ Confirm with
Settings
\
$ Language !
# Time
\
! Drying levels
\
^ The sensors on the right can be used to scroll up or down
the list.
The display can be set to appear in one of several different
languages.
OK.
10:21
m
!
10:21
m
[
[
[
[
To select the language you want, go to the Language J
sub-menu.
The flag after the word Language acts as a guide to prevent
a language which will not be understood from being set.
67
Settings menu
Time
Clock format
The time can be set to appear as a 24 hour or 12 hour
clock. You can also use this setting to adjust the time of
day.
Set the time of day
Drying levels
Time
\
$ 24 h clock (
# 12 h clock
\
Select the format you want.
^
The dryer is delivered with the clock format set as a 24 hour
clock.
Time
10 :21
^ Use the
^
Confirm the hours with
You can alter the drying levels for the Cottons, Minimum
iron and Automatic plus programmes.
+ and - sensors to set the hour.
OK and then enter the minutes.
10:21
OK !
+ $
- #
OK !
[
[
[
[
68
The bars show you the setting.
The default is: the middle setting.
–
Drier
PPPPPPP
the programme duration increases.
–
Damper
the programme duration is shorter.
P
Settings menu
Extended cool down
The cooling down phase which takes
place before the end of a programme
can be lengthened by 2, 4, 6 ... up to
18 minutes if required. This helps
textiles cool down more intensely.
The programme duration increases in 2
minute increments.
Extended cooling down can only be
selected for programmes that offer
different drying stages.
Factory default: Normal cooling down
phase.
Airways indicator
Fluff should be removed after drying.
The Clean out airways message will
remind you to do this when a certain
amount of fluff has collected. You can
decide at what level of fluff this
reminder should be given.
You will have an idea of how often this
should be done after a few drying
programmes.
Off
Clean out airways does not appear.
Heavy
Clean out airways only appears when
there is a heavy build-up of fluff
Normal
Factory default
Light
Clean out airways appears when there
is only a small build-up of fluff.
69
Settings menu
Code
To activate the code
The code prevents the dryer being used without your
knowledge.
When the code has been activated, you have to enter a code
after switching the dryer on. Otherwise the dryer cannot be
operated.
The door can be opened and items removed at any time.
The display will now request that a code is entered. The code
is 250 and cannot be altered.
Activate code
2 AA
Please enter code OK !
^ Use + to enter the first number.
^ Confirm the first number with
number. Repeat the process until all three numbers have
been entered.
^
After the last number has been entered, you must confirm
the code with
Information
0
^
Confirm with
^
Switch the dryer off.
OK.
Input OK. Code active when machine is
switched off.
OK.
OK and then enter the second
10:21
+ $
– #
10:21
OK !
[
[
[
[
70
To use the dryer when the lock code is activated
When the dryer is switched on again, the display will request
the code.
Settings menu
^
The dryer is now unlocked and ready for use.
To deactivate the code
^
^ Confirm with
You can now switch on the dryer without being asked to enter
a code.
Enter code 250 with the
Proceed as for activating the code.
Information
1
Code OK. Ready
OK.
+ and - sensors.
OK !
[
71
Settings menu
Buzzer
When the buzzer function has been
activated, an audible tone sounds at
the end of a programme.
Off
Factory default
The buzzer is switched off but sounds
at maximum volume if there is a fault.
Normal
The buzzer sounds at the end of a
programme.
Loud
The buzzer sounds louder at the end of
a programme.
Keypad tone
An audible tone sounds each time a
button is pressed.
If you make an alteration it will appear
in the display immediately.
Display / keypad illumination
The display and sensor illumination
switches off to save energy.Start
flashes slowly to save energy.
The display and the sensors are not
illuminated.
if a programme is not selected within
–
10 minutes of the tumble dryer being
switched on.
– 10 minutes after the end of a
programme.
Press the Start sensor to activate the
display and sensor illumination again.
Off after 10 minutes
The display and sensor illumination will
switch off 10 minutes after the
programme has started.
Off
Factory default
On
Brightness
Contrast
The display contrast and brightness
can be altered in stages.
The bars
which level is set.
72
PPPPPPPshow you
"On" whilst programme is running
Factory default
The display and sensors remain lit up
whilst the programme is running.
Memory
The electronics will memorise the
drying level and some of the extra
options selected for the current
drying programme and the duration
of a timed drying programme.
When the programme is chosen again
these settings will appear in the
display.
Off
Factory default
On
Anti-crease
Anti-crease helps prevent creasing, if
laundry is not normally removed immediately after the end of a
programme.
Settings menu
After the programme has finished, the
drum will continue to rotate at intervals.
There is no anti-crease phase with
Wollens.
Off
1 hour
2 hours
(Factory default)
737475
Alteration rights reserved/0113
M.-Nr. 07 737 880 / 08
Loading...
