Miele SDAE0, SDBE0, SDCE0, SDBE4, SDCE4 Operating instructions
en Operating Instructions Canister Vacuum Cleaner
fr Mode d'emploi Aspirateur-chariot
SDAE0, SDBE0, SDCE0
SDAE4, SDBE4, SDCE4
HS14
M.-Nr. 10 852 961
en ....................................................................................................................... 5
fr ......................................................................................................................... 30
2
Only Miele FilterBags, filters and accessories with
the "Original Miele" logo can be used with this
vacuum. Only then can the suction power of the
vacuum cleaner reach its optimum potential creating
the best possible cleaning results.
USE OF NON-MIELE COMPONENTS MAY VOID
THE WARRANTY.
,
The use of FilterBags made of paper or a similar
material, or FilterBags with a cardboard retaining
plate can lead to serious damage to the vacuum
cleaner and may void the warranty, just as with the
use of FilterBags without the "Original Miele" logo.
The "Original Miele" Logo will appear on the
packaging or directly on the FilterBag.
Purchasing new FilterBags and filters
Original Miele FilterBags and filters can be purchased
from an authorized Miele vacuum dealer or by visiting the
Miele store at www.mieleusa.com.
3
en - Contents
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 5
Caring for the environment ................................................................................11
Appliance description .........................................................................................12
References to illustrations..................................................................................14
Electrobrush / Turbobrush Operating Instructions ..........................................14
Preparing for use.................................................................................................14
Use........................................................................................................................16
Parking, transport and storage.......................................................................... 18
Maintenance ........................................................................................................18
Purchasing new FilterBags and filters................................................................... 19
Ordering the correct FilterBags and filters ............................................................ 19
When to change the FilterBag .............................................................................. 19
How the FilterBag change indicator works ........................................................... 20
How to replace the FilterBag ................................................................................ 20
When to change the motor protection filter........................................................... 20
How to change the motor protection filter ........................................................... 20
When to replace the exhaust filter......................................................................... 21
How to replace the AirClean filter ......................................................................... 21
Replacing the Active AirClean 50 and HEPA AirClean 50 exhaust filters ............. 21
Replacing one type of exhaust filter with another ................................................ 22
When changing the filter, please note: .................................................................. 22
When to change the thread catchers?.................................................................. 22
How to replace the thread lifters .......................................................................... 22
Cleaning the roller on the AllTeQ floorhead .......................................................... 22
Cleaning and care ...............................................................................................23
Frequently Asked Questions .............................................................................. 24
Technical Service................................................................................................. 25
Contact in case of fault ......................................................................................... 25
Warranty................................................................................................................ 25
Optional accessories ..........................................................................................25
Limited Warranty - Vacuum Cleaners USA ....................................................... 27
4
en - IMPORTANT SAFETY INSTRUCTIONS
This vacuum cleaner complies with current safety requirements. Inappropriate use can, however, lead to personal injury and damage to property.
To avoid the risk of accidents and damage to the vacuum
cleaner, please read the operating instructions carefully
before using it for the first time. They contain important
information on its safety, operation and maintenance.
Keep these operating instructions in a safe place and
pass them on to any future user.
Always disconnect the vacuum cleaner from the power
supply when you have finished using it, before changing
any accessories, as well as for maintenance work and
cleaning. Turn the vacuum cleaner off and unplug it.
Correct use
This vacuum cleaner is intended for cleaning flooring in
domestic households and similar residential environments.
This vacuum cleaner can be used for all normal cleaning
of carpets, rugs and hard flooring.
This vacuum cleaner is not intended for outdoor use.
This vacuum cleaner is intended for use at altitudes of
up to 1300ft (4000m) above sea level.
The vacuum cleaner must only be used to vacuum dry
floor surfaces. Do not use on people and animals. Any
other usage, modification or alteration is not supported by
the manufacturer and could be dangerous.
5
en - IMPORTANT SAFETY INSTRUCTIONS
Persons which lack physical, sensory or mental abilities
or experience with the machine should not use it without
supervision or instruction by a responsible person.
Safety with children
Danger of suffocation! Ensure that any plastic wrap-
pings, bags, etc. are disposed of safely and kept out of the
reach of children.
Do not allow the vacuum cleaner to be used as a toy.
Close attention is necessary when used near children.
WARNING To reduce the risk of fire, electric shock or injury:
Check the voltage rating of the vacuum cleaner before
connecting the power cord to an electrical outlet. Your
power source should correspond with the voltage rating
plate located on the underside of the vacuum. Use only
household AC outlets. Never use DC power sources. If you
are not sure of your home’s voltage supply, consult a qualified electrician. Connecting the vacuum cleaner to a
higher voltage than indicated in these instructions may result in damage to the vacuum cleaner or injury.
To reduce the risk of electric shock, this appliance has a
polarized plug (one blade is wider than the other.) This plug
will fit in a polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install the proper outlet. Do not alter the plug in any way.
6
en - IMPORTANT SAFETY INSTRUCTIONS
Technical safety
Before using the vacuum cleaner and its accessories,
check for any visible signs of damage. Do not use a damaged appliance.
Ensure that the connection data on the data plate of the
vacuum cleaner (voltage and frequency) match the household power supply. Without modifications, the vacuum
cleaner is suited for 50Hz or 60Hz.
The electrical outlet must be fitted with a 15A fuse.
Reliable and safe operation of this vacuum cleaner can
only be assured if it has been connected to the electricity
supply.
The socket on the vacuum cleaner (depending on
model) must only be used for the Miele Electrobrushes
listed in these operating instructions.
The Miele Powerbrush is a motor driven accessory for
use only with Miele vacuum cleaners. For safety reasons,
the vacuum cleaner must not be used with an Powerbrush
produced by another manufacturer.
Repairs must only be performed by an authorized ser-
vice agent in accordance with national and local safety
regulations. Unauthorized repairs could cause injury or machine damage. Otherwise the warranty will be void.
7
en - IMPORTANT SAFETY INSTRUCTIONS
Do not pull or carry the vacuum cleaner by the power
cord, and be careful not to damage the cord when withdrawing the plug from the socket. Keep the cord away
from sharp edges and do not let it get pinched, for example, under a door. Avoid running the vacuum cleaner over
the cord. This could damage the cord, plug or socket. The
appliance must not be used if any of these have suffered
damage.
Do not use the vacuum cleaner if the power cord is
damaged. If the power cord is damaged it must be replaced together with the cord reel. For safety reasons this
must only be done by Miele Technical Service or a Miele
authorized service technician.
When vacuuming, in particular fine dust, e.g. sawdust,
sand, plaster, flour, talcum powder etc., electrostatic
charges build up naturally. Under certain conditions these
charges will be released. To avoid the unpleasant effects of
these discharges, a metal inlay has been incorporated into
the underside of the handle. Please make sure that you
keep your hand in constant contact with this metal strip
during vacuuming.
Do not allow the vacuum cleaner or Electrobrush, elec-
tric wand or electric hose to get wet. Clean only with a dry
or slightly damp cloth. If any moisture gets into the appliance, danger of electric shock.
The Electrobrush, electric wand and electric hose con-
tain power cords. The plug connectors must not come in
contact with water. Danger of electric shock. They should
only be cleaned with a dry cloth.
8
en - IMPORTANT SAFETY INSTRUCTIONS
Repairs should only be carried out by a Miele-authorized
service technician. Repairs and other work by unqualified
persons can cause considerable danger to users.
Defective components should be replaced by Miele orig-
inal parts only. Only with these parts can safety of the appliance be assured as intended by the manufacturer.
Proper use
To avoid the risk of damage, do not use the vacuum
cleaner without the FilterBag, dust compartment filter and
exhaust filter in place.
The dust compartment cover will not close without a Fil-
terBag inserted. Do not force it.
Do not vacuum up anything which has been burning or
smoking, e.g., cigarettes, ashes or hot ash, whether glowing or apparently extinguished.
Do not use the vacuum cleaner to vacuum up any water,
liquid or damp dirt. Wait until any freshly cleaned or shampooed rugs or carpets are completely dry before attempting to vacuum.
Do not use the vacuum cleaner to vacuum toner dust.
Toner, such as that used in printers and photocopiers, can
conduct electricity.
Do not vacuum up any flammable or combustible liquids
or gases and do not vacuum in areas where such substances are stored.
Do not vacuum at head height and do not let the suction
get anywhere near a person's head.
9
en - IMPORTANT SAFETY INSTRUCTIONS
Accessories
To avoid the risk of injury when vacuuming with a Miele
Powerbrush or Turbobrush, do not touch the rotating roller
brush.
It is not advisable to vacuum directly with the handle,
i.e., without an accessory attached, as the rim could get
damaged and you could hurt yourself on sharp edges.
Only use genuine FilterBags, filters and accessories with
the “Original Miele” logo on them. Otherwise the manufacturer cannot guarantee the safety of the product.
California Proposition 65
THE FOLLOWING WARNING IS REQUIRED BY THE STATE OF CALIFORNIA FOR CALIFORNIA RESIDENTS ONLY:
WARNING:
Cancer and Reproductive Harm -
www.P65Warnings.ca.gov.
SAVE THESE INSTRUCTIONS
10
en - Caring for the environment
Disposal of the packing material
The cardboard box and packing materials protect the appliance during shipping. They have been designed to be
biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children. Danger of suffocation!
Disposing of the FilterBags and filters
Filterbags and filters are made from environmentally friendly materials, and can
be disposed of with the normal household waste, as long as they have been
used exclusively for general household
dust.
Disposing of your old appliance
Before disposing of your old appliance
remove the FilterBag and filters and dispose of them with your household
waste.
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials, compounds and components which were
essential for their correct functioning
and safety. These could be hazardous
to your health and to the environment if
disposed of with general waste or if
handled incorrectly. Please do not,
therefore, dispose of your old appliance
with general waste.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle electrical and electronic appliances. By law,
you are solely responsible for deleting
any personal data from the appliance
prior to disposal. Please ensure that
your old appliance poses no risk to children while being stored for disposal.
11
en - Appliance description12en - Appliance description
a
XXL handle *
b
Air inlet valve *
c
Release buttons *
d
Telescopic suction wand release mechanism *
e
Telescopic suction wand *
f
Dust compartment lid release button
g
Floorhead *
h
Carrying handle
i
Socket for Electrobrush *
j
Original Miele FilterBag
k
Motor protection filter
l
Original Miele exhaust filter *
m
Power cord *
n
Foot switch for automatic cord rewind
o
Rotary selector
p
Park system for pauses during vacuuming
q
On/off foot switch
r
FilterBag change indicator
s
Connection socket *
t
Suction hose *
u
Accessories holder with three accessories
Park system for storage (on both sides of the vacuum cleaner - not shown)
* These features are model-specific and may vary or may not be available on your
vacuum cleaner.
13
en-US
References to illustrations
The illustrations referred to in the text
are shown on the fold-out pages at
the end of these Operating Instructions.
Electrobrush / Turbobrush Operating Instructions
Your vacuum cleaner is equipped with
an Electrobrush or Turbobrush as standard. Please read the separate operating instructions supplied with the Electrobrush or Turbobrush before using it
for the first time.
Preparing for use
Attaching the suction hose (Fig. 01)
Insert the hose connector into the
suction socket on the vacuum
cleaner until it clicks into position. To
do this, line up the guides on the two
pieces.
Disconnecting the suction hose (Fig. 02)
Press the release buttons at the side
of the hose connector, and lift the
hose from the socket.
Connecting the suction hose to the handle (Fig. 03)
(required depending on model)
Insert the suction hose into the han-
dle until it clicks into position.
Connecting the handle to the wand (Fig. 04)
Insert the handle into the wand until it
clicks into position. To do this, line up
the guides on the two pieces.
14
To release the handle from the wand,
press the release button and pull the
handle out of the wand, twisting it
slightly as you do so.
Adjusting the telescopic suction wand
Depending on the model, your vacuum
cleaner will be fitted with one of the following suction wands:
– Telescopic suction wand
– Comfort telescopic suction wand
One part of the telescopic suction wand
is packed inside the other and it can be
adjusted to suit your height for comfortable vacuuming.
Telescopic suction wand (Fig. 05)
Press the release button and adjust
the telescopic suction wand to the required length.
Comfort telescopic suction wand (Fig. 05)
Grasp the release mechanism and
adjust the telescopic suction wand to
the required length.
Connecting the telescopic wand to the floorhead/floorbrush (Fig. 06)
(included as standard depending on
model)
Push the telescopic wand into the
suction nozzle and turn it clockwise
or counter-clockwise until it clicks
into position.
en-US
To detach these parts from each
other, press the release button and
pull the telescopic wand out of the
suction nozzle, twisting it slightly as
you do so.
Adjusting the floorhead (Fig. 07)
(only for models with a reversible floorhead included in the standard version)
This vacuum cleaner can be used for
the everyday cleaning of carpets, rugs
and hard flooring.
Miele offers a range of other floorheads,
brushes and accessories for other types
of flooring and special applications (see
“Optional accessories”).
Please always follow the flooring
manufacturer's cleaning and care instructions.
Vacuum carpets and rugs with the
brush retracted:
Press the foot switch .
Clean hard flooring which is not sus-
ceptible to scratching, and flooring with
gaps or deep crevices in it with the
brush protruding:
Press the foot switch .
If the suction power of the adjustable
floorhead seems too high, reduce the
suction until the floorhead is easier
to maneuver (see “Use – Regulating
the suction power”).
Activating the TimeStrip® exhaust filter change indicator on the exhaust
filter
Depending on the model, your vacuum
cleaner will be fitted as standard with
one of the following exhaust filters (Fig.
08).
a AirClean
b Active AirClean 50 (black)
c HEPA AirClean 50 (white)
If your vacuum cleaner is fitted with exhaust filter b or c, you need to activate
the TimeStrip® exhaust filter change indicator.
Press the release button on the re-
cessed grip and raise the dust compartment lid as far as it will go (Fig.
09).
Remove the indicator strip (Fig. 10).
Press the TimeStrip® exhaust filter
change indicator(Fig. 11).
After approx. 10–15 seconds a thin red
line will appear in the left-hand side of
the display (Fig. 12).
Close the dust compartment lid se-
curely, making sure it clicks into position. Take care not to trap the FilterBag when doing so.
How the TimeStrip® exhaust filter
change indicator works
The TimeStrip® exhaust filter change
indicator shows the remaining functional life of the exhaust filter. After approx. 50 operating hours, or approx.
one year of average use, the display will
be completely filled with red (Fig. 13).
15
en-US
Using the accessories supplied (Fig. 14)
Dusting brush / Dusting brush
with natural bristles
(depending on model)
For cleaning baseboards, as well
as ornate, carved or particularly
delicate objects.
The head can be swiveled to adjust the angle.
Upholstery nozzle
For cleaning upholstery, mattresses, cushions, curtains, etc.
Crevice nozzle
For cleaning in folds, crevices or
corners.
Accessories holder for the
above three accessories (Fig.
15)
Symbols on the holder show
where to attach the different accessories.
Attach the accessories holder to the
suction hose where it joins the handle
or to the hose connecter socket on
the vacuum cleaner. Make sure it
clicks into position.
Convertible floorhead / floor brush (Fig. 16)
(included as standard depending on
model)
For general use and also for vacuuming
the stairs.
For safety reasons when vacu-
uming stairs, it is best to start at the
bottom of the stairs and move upwards.
Use
Power cord
Unwind the cord completely to
aid the vacuum in dissipating heat.
Do not pull or carry by the cord, use
the cord as a handle, close a door on
the cord, or pull the cord around
sharp edges or corners. Do not run
the appliance over the cord. Keep
the cord away from heated surfaces.
Do not unplug by pulling the cord. To
unplug grasp the plug, not the cord.
This appliance is equipped with a
power cord reel. Hold the plug when
rewinding onto cord reel. Do not allow plug to whip when rewinding.
Some models are supplied as standard
with one of the following accessories
which are not illustrated.
– Electrobrush
– Turbobrush
These vacuum cleaners are supplied
with separate operating instructions for
the relevant accessory part.
16
Unwind the power cord (Fig. 17)
Pull the power cord out to the re-
quired length.
Insert the plug into the electrical
socket.
en-US
If vacuuming for longer than
30minutes, the power cord must be
pulled out all the way. Otherwise
there is a danger of overheating and
damage.
Rewinding the power cord (Fig. 18)
Unplug the power cord from the
socket.
Step on the cord rewind foot switch.
The power cord will then retract itself
into the vacuum cleaner.
If you do not want the cord to retract
completely into the vacuum cleaner
you can deactivate this function. To do
this, take hold of the end of the cord
while rewinding it and give it a short
pull when you want the rewinding to
end.
Turning the vacuum cleaner on and off (Fig. 19)
Press the On/Off foot control .
Regulating the suction power (Fig. 20)
The suction power can be regulated to
suit the type of flooring being cleaned.
Reducing the suction power reduces
the amount of effort required to maneuver the floor brush.
The vacuum cleaner has symbols on
the controls which indicate the type of
use the settings are suitable for.
Curtains, fabric
Upholstery, cushions
Deep pile carpets, rugs and run-
ners
Energy-saving vacuuming. This
setting is also very quiet
Low pile carpet and rugs
Hard flooring and heavily soiled
carpets and rugs
When using the adjustable floorhead,
if the suction seems too high, reduce
the suction until the floorhead is easier to maneuver.
Turn the suction power selector man-
ually to the suction power setting you
require.
Opening the air inlet valve (Fig. 21 + 22)
(depending on model)
It is easy to reduce the suction power
for a short time, e.g., to prevent rugs or
other objects being sucked into the
vacuum cleaner.
Open the air inlet valve on the handle
far enough to reduce the suction
power.
This reduces the suction on the respective nozzle used.
During vacuuming
When vacuuming, pull the vacuum
cleaner behind you on its wheels. You
can stand it upright for vacuuming
stairs and curtains, etc.
17
en-US
When vacuuming, in particular
fine dust, e.g. dust, sand, plaster,
flour, etc., electrostatic charges build
up naturally. Under certain conditions
these charges will be released. To
avoid the unpleasant effects of these
discharges, a metal inlay has been
incorporated into the underside of
the handle. Please make sure that
you keep your hand in constant contact with this metal strip during vacuuming (Fig. 23 + 24).
Parking, transport and storage
Park system for pauses during vacuuming (Fig. 25)
(cannot be used with the Electrobrush
SEB 228)
The park system allows you to conveniently park the suction wand and floorhead during pauses.
Slot the floorhead into the parking at-
tachment on the vacuum cleaner.
If your vacuum cleaner is on a sloping surface, e.g., a ramp, retract the
telescopic suction wand fully.
Slot the floorhead downwards into
one of the parking attachments on either side of the vacuum cleaner.
This makes the vacuum cleaner easier
to carry or store.
If your vacuum cleaner has an XXL handle, you can detach this so that the
vacuum cleaner requires less storage
space (Fig. 27).
Detach the XXL handle from the re-
tracted telescopic suction wand.
Wind the suction hose around the
telescopic suction wand and then slot
the XXL handle into the second parking attachment.
Maintenance
Always switch off the vacuum
cleaner for maintenance work and
remove the plug from the outlet.
The Miele filtration system consists of
three components:
– Original Miele FilterBag
– Motor protection filter
– Original Miele exhaust filter
Park system for storage (Fig. 26)
Always disconnect the vacuum
cleaner from the power supply when
you have finished using it. Remove
the plug from the socket.
Stand the vacuum cleaner upright.
It is a good idea to retract the telescopic suction wand fully.
18
These will need to be replaced from
time to time to ensure that your vacuum
cleaner performs efficiently.
en-US
We recommend only using genuine
FilterBags, filters, and accessories
with the “Original Miele” logo on
them. This will ensure that the suction power of the vacuum cleaner is
maintained, giving the best possible
cleaning results.
FilterBags with the “Original Miele”
logo on them are not made from paper or paper-based materials and nor
do they have a cardboard collar. This
is why our FilterBags are particularly
long-lasting and reliable.
Please note that appliance faults and
damage originating from the use of
accessories which do not carry the
“Original Miele” logo will not be covered by the appliance guarantee.
Purchasing new FilterBags and filters
Original Miele FilterBags and filters are
available from the Miele web store,
Miele Technical Service, and your Miele
dealer.
Ordering the correct FilterBags and filters
Only use original Miele FJM FilterBags
with a red collar and original Miele filters. These are identified by the “ORIGINAL Miele” logo on the packaging.
Every packet of original Miele FilterBags
contains four bags, one AirClean exhaust filter and one motor protection filter. Original Miele multipacks contain 16
FilterBags, four AirClean exhaust filters
and four motor protection filters.
Original Miele exhaust filters can also
be purchased separately from your
Miele dealer or Miele Technical Service.
Please quote the model number of your
vacuum cleaner when ordering to make
sure you get the correct filter. You can
also order all accessories via the Miele
web store.
When to change the FilterBag (Fig. 28)
Change the FilterBag when the color
marker in the FilterBag change indicator
turns red.
FilterBags are disposable and intended to be used only once. Dispose of the entire FilterBag. Do not
attempt to re-use. Blocked pores reduce the efficiency of the vacuum
cleaner.
Checking the FilterBag change indicator
Attach the floor brush to the vacuum
cleaner (depending on the model).
Switch the vacuum cleaner on and
select the highest power setting.
Lift the floor brush off the floor a little.
19
en-US
How the FilterBag change indicator works
The FilterBag change indicator is set for
normal household dust. This generally
contains a mixture of dust, hair,
threads, carpet lint, grit, etc.
However, if the cleaner has been used
to vacuum up fine dust, such as plaster,
brick dust, cement or flour, the pores of
the FilterBag will become blocked very
quickly.
This affects the air permeability of the
bag, and the marker will indicate that
the bag is “full” even when it is not. If
this happens you must still change the
FilterBag because suction power will be
greatly reduced by blocked pores in the
FilterBag.
If, on the other hand, a large amount of
hair and carpet lint which typically contains a lot of air is vacuumed up, the indicator may fail to react even though
the bag is full. You should still change it.
Both these extremes can occur.
How to replace the FilterBag (Fig. 29 + 30)
Press the release catches at the side
of the hose connector, and remove
the hose from the socket (Fig. 02).
Press the release button on the re-
cessed grip and raise the dust com-
partment lid as far as it will go (Fig.
09).
The FilterBag has a flap which closes
automatically when the dust compartment lid is raised to prevent any dust
escaping.
Pull the FilterBag out by the grip on
the collar.
20
Fit the new FilterBag into the red
holder as far as it will go. Leave it
folded up when you take it out of the
box.
Close the dust compartment lid se-
curely, making sure it clicks into position. Take care not to trap the FilterBag when doing so.
An empty operation lock prevents
the dust compartment lid from closing without a FilterBag in place. Do
not use force!
Insert the hose connector into the
suction socket on the vacuum
cleaner until it clicks into position. To
do this, line up the guides on the two
pieces (Fig. 01).
When to change the motor protection filter
Replace this filter every time you start a
new packet of filter bags.
Every packet of original Miele filter bags
contains a motor protection filter. Multipacks contain four motor protection filters.
How to change the motor protection filter (Fig. 31)
Open the dust compartment lid.
Pull the filter bag out by the grip on
the collar.
Lift up the filter frame until it clicks
and remove the old motor protection
filter. Hold by the clean, unsoiled section to remove it.
Replace with a new motor protection
filter.
Close the filter frame.
en-US
Fit the filter bag into the holder as far
as it will go.
Close the dust compartment lid se-
curely, making sure it clicks into posi-
tion. Take care not to trap the filter
bag when doing so.
When to replace the exhaust filter
Depending on the model, your vacuum
cleaner will come with one of the following exhaust filters (Fig. 08) as standard:
a AirClean
Replace this filter every time you start a
new packet of Miele FilterBags. An AirClean exhaust filter is supplied with every packet of Miele FilterBags.
b Active AirClean 50 (black)
c HEPA AirClean 50 (white)
Replace if the display for the exhaust filter change indicator is completely filled
with red (Fig. 13). This occurs after approx. 50 hours of operation which is
equivalent to about a year of average
use. The vacuum cleaner can still be
used.
However, the suction power will be reduced as will the effectiveness of the filter if it is not replaced in good time.
How to replace the AirClean filter (Fig. 32 + 33)
Do not use more than one exhaust filter at a time.
Open the dust compartment lid.
Press the release catch on the filter
grille and open the grille until it clicks.
Grasp the used AirClean exhaust filter
by one of the clean, unsoiled sections
and take it out.
Replace it with a new AirClean ex-
haust filter.
If you wish to fit an Active AirClean
50 or HEPA AirClean 50 exhaust filter, see “Replacing one type of exhaust filter with another.”
Close the filter frame.
Close the dust compartment lid.
Replacing the Active AirClean 50 and HEPA AirClean 50 exhaust filters (Fig. 34 + 35)
Do not use more than one exhaust filter at a time.
Open the dust compartment lid.
Lift the exhaust filter and remove it.
Insert a new exhaust filter, making
sure it goes in properly, then push it
down into position.
Press the TimeStrip® exhaust filter
change indicator(Fig. 11).
After approx. 10 –15 seconds a thin red
line will appear in the left-hand side of
the display (Fig. 12).
If you wish to fit the AirClean exhaust
filter, see “Replacing one type of exhaust filter with another”.
Close the dust compartment lid.
21
Loading...
