Miele S 2110, S 2120, S 2130 Operating instructions
Operating instructions
Vacuum cleaners
S 2110 / S 2120 / S 2130
To avoid the risk of accidents or damage
to the appliance, it is essential to read these
instructions before using it for the first time.
These operating instructions apply to
standard models S 2110 / S 2120 / S 2130
as well as to other S 2000 series vacuum cleaners
which are distinguished by names rather than numbers.
en - AU, NZ
M.-Nr. 07 861 720
Contents
Caring for the environment..........................................3
Description of the vacuum cleaner ...................................4
Warning and safety instructions .....................................6
Preparing for use ..................................................9
Using the accessories supplied .....................................11
Use ............................................................12
Pull out the mains cable.............................................12
Rewinding the cable ...............................................12
Switching on and off ...............................................12
Adjusting the suction power .........................................13
Opening the air inlet valve ...........................................13
Parking and storing ...............................................14
Maintenance and care .............................................15
Purchasing new dustbags and filters ..................................15
Ordering the correct dustbags and filters ...............................15
When to change the dustbag ........................................16
Replacing the dustbag .............................................17
When to change the dust compartment filter (for motor protection) ...........18
How to change the dust compartment filter .............................18
Replacing the Air Clean filter .........................................18
Replacing the Air Clean filter .........................................18
Replacing one type of exhaust filter with another .........................19
When to replace the Active Air Clean or Active HEPA filter .................19
How to replace the Active Air Clean or Active HEPA filter ..................19
When to change the thread lifters .....................................20
To replace the thread lifters..........................................20
Problem solving guide ............................................21
After sales service / Warranty.......................................22
Electrical connection..............................................23
2
Caring for the environment
Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposing of the dustbag and
filters
These are made from environmentally
friendly materials, and can be disposed
of with the normal household waste, as
long as they have been used
exclusively for general household dust.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Therefore, please do not dispose of
your old appliance with your household
waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
3
Description of the vacuum cleaner
4
Description of the vacuum cleaner
a Handle
b Air inlet valve
c Release button
d Connection piece for storage *
e Telescopic tube *
f Connection socket
g EasyLock tube *
h Slide controls for the telescopic tube *
i Dust compartment release button
j Suction power selector *
k Floorhead *
l Carrying handle
m Dustbag
n Dust compartment filter (for motor protection)
o Air Clean filter (AC)
p On/Off foot control s
q ParkSystem
r Mains cable
s Foot switch for automatic cable rewind
t Dustbag change indicator
u VarioClip with three-piece accessories
v Suction hose
Those features marked * depend on the model, and may vary or not be available
on your model.
Optional accessories
Miele accessories including floorheads, filters and dustbags are available to order
from your Miele Vacuum Cleaner Specialist, the Miele Spare Parts Department or
on the internet at www.miele-shop.com.
5
Warning and safety instructions
Safety with children
This appliance conforms to current
safety requirements. Improper use
of the appliance can, however,
present a risk of both personal injury
and material damage.
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before installation and before using
it for the first time. They contain
important notes on its safety,
operation and maintenance.
Keep these instructions in a safe
place and ensure new users are
familiar with the content. Pass them
on to any future owner.
Children should be supervised to
~
ensure that they do not play with the
appliance.
Older children may only use the
~
appliance when its operation has been
clearly explained to them and they are
able to use it safely, recognising the
dangers of misuse.
Technical safety
Ensure that the connection data on
~
the data plate (voltage and frequency)
match the mains electricity supply. This
data must correspond in order to avoid
the risk of damage to the appliance.
Correct application
This vacuum cleaner must only be
~
used for domestic household purposes
to vacuum dry floor surfaces. Do not
use on people or animals.
Any other usage, modification or
alteration is at the owner's risk and
could be dangerous.
The manufacturer cannot be held liable
for damage resulting from improper or
incorrect use of the appliance.
This appliance is not intended for
~
use by young children or infirm persons
unless they have been adequately
supervised by a responsible person to
ensure that they can use the appliance
safely.
Before installation, check the
~
appliance for visible signs of damage.
Do not use a damaged appliance. A
damaged appliance could be
dangerous.
Repairs should only be carried out
~
by a Miele authorised service
technician. Repairs and other work by
unqualified persons could be
dangerous. The manufacturer cannot
be held liable for unauthorised work.
It is important to switch the vacuum
~
cleaner off before changing over
accessories and floorheads, especially
an Electro- or Turbobrush.
6
Warning and safety instructions
There is a metal inlay underneath
~
the handle which is designed to avoid
the unpleasant effects of electrostatic
discharges. Please make sure that you
keep your hand in constant contact with
this metal strip during vacuuming.
Do not pull or carry the vacuum
~
cleaner by the cable and be careful not
to damage the cable when withdrawing
the plug from the socket.
Keep the cable away from sharp edges
and do not let it be squashed, for
example, under a door.
Avoid running the vacuum cleaner over
the cable.
This could damage the cable, plug or
socket and pose as a safety hazard.
The appliance must not be used if any
of these have suffered damage.
If the cable is damaged it must be
~
replaced together with a complete
cable rewind. For safety reasons this
must only be done by the Miele Service
Department or a Miele authorised service technician.
While the vacuum cleaner is under
~
guarantee, repairs should only be
undertaken by a service technician
authorised by Miele. Repairs and other
work by unqualified persons could be
dangerous. The manufacturer cannot
be held liable for unauthorised work.
It is important to switch off the
~
vacuum cleaner after use and before
any cleaning or maintenance. Switch
off at the wall socket and remove the
plug.
Do not let the vacuum cleaner get
~
wet. Clean only with a dry cloth or
slightly damp cloth when disconnected
from the mains supply. If moisture gets
into the appliance, there is a risk of
electric shock.
Correct use
To avoid the risk of damage, do not
~
use the vacuum cleaner without the
dustbag, dust compartment filter and
exhaust filter in place. Otherwise it
could get damaged.
If a dustbag is not inserted, the dust
~
compartment cover does not normally
close. Do not force it.
Do not vacuum up any water, liquid
~
or damp dirt. This will cause major
faults and could seriously impair the
functioning and electrical safety of the
appliance. Wait until any freshly
cleaned or shampooed carpets or floor
coverings are completely dry before
attempting to vacuum.
Do not vacuum up anything which
~
has been burning or is still glowing e.g.
cigarettes, ashes or coal, whether
glowing or apparently extinguished.
The cleaner might catch fire.
Do not vacuum toner dust. Toner,
~
such as that used in printers and
photocopiers, can conduct electricity.
The filter system in the vacuum cleaner
may not filter it completely, causing the
toner to be blown back into the room by
the fan.
7
Warning and safety instructions
Do not vacuum up any inflammable
~
or combustible liquids or gases and do
not vacuum in areas where such
substances are stored. The cleaner
might explode.
Do not vacuum up items which are
~
heavy, hard or have sharp edges. They
could cause a blockage and damage
the appliance.
Floor attachments, accessories and
~
tubes must not be used at head level to
avoid the risk of injury, e.g. to eyes and
ears. Danger of injury.
Monitor the change dustbag
~
indicator and change the dustbag if
necessary.
Check the exhaust and dust
compartment filters at the same time
and change them too if necessary. A
full bag or blocked filter will reduce the
suction power of the cleaner. A
temperature limiter switches the
vacuum cleaner off automatically if it
gets too hot. See "Problem solving
guide".
Accessories
It is not advisable to vacuum directly
~
with the handle, i.e. without an
accessory attached as the rim could
get damaged and you could hurt
yourself on sharp edges. Danger of
injury.
Miele vacuum cleaner bags are
~
disposable and intended to be used
only once. Do not attempt to re-use.
Blocked pores reduce the efficiency of
the cleaner.
To ensure safety only use genuine
~
Miele dustbags, filters and accessories.
This will ensure optimum performance
of the appliance throughout its life.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
8
