PDW 909 [EL DP DD]
Professional washer-dryer stack, electric heating, with drain pump
For washing/drying in the smallest of spaces.
Construction type and version
Construction type Front-loading stack
Range Performance Plus
Front Stainless steel
Washer-extractor load capacity in kg 9.0
9.0
Washer-extractor drum volume in l 80
180
Drying system Exhaust air
Washer-extractor door opening [Ø] in mm
440
Door opening angle in degrees 180
Door hinge Washing right/drying left
Automatic door lock •
•
Application
•
•
•
•
•
• Drum volume 80 l and/or 180 l,
load size 2 x 9.0 kg
•
*
• Ergonomic – centred M Touch Pro
(Plus) control unit
• High laundry throughput – very
short programme cycles
• Connected for the future using LAN
and WiFi
*
Based on the Coloured items 60 °C programme with a
warm water connection, compared to predecessor.
•
•
•
•
•
•
•
•
•
Performance data
•
Proven hygiene •
6.60
0.51
Washer-extractor programme duration in min. 45
44
44
Washer-extractor spin speed in rpm.
Washer-extractor g-factor 518
Control system
Control type for washing machine M Touch Pro Plus
M Touch Pro
Page 2
PDW 909 [EL DP DD]
Professional washer-dryer stack, electric heating, with drain pump
For washing/drying in the smallest of spaces.
Max. delay start in h for washing machine
24
Time left display •
Programme sequence indicator •
•
Standard/target grp programmes
Basic programmes •
Programmes for the hotel and catering industry •
Programmes for retirement and care homes •
Programmes for launderettes •
Programmes for residential homes and apartments •
Programmes for dry cleaners •
Programmes for commercial laundries •
•
•
Programmes for universities, nurseries, and school •
Programmes for hospitals •
Programmes for camp sites •
•
•
Programmes for domestic use •
•
Washing machine dispensing
Detergent drawer
6
Empty sensor •
Standard electrical connection
Type of heating washing machine Electric
Electric
Electrical connection washing machine
Heater rating washing machine in kW 5.20
Total connected load washing machine in kW 5.50
Fuse rating washing machine in A 25.0
5.22
5.50
25.0
Possible voltage options
Electrical connection washing machine
Heater rating washing machine in kW 5.20
Total connected load washing machine in kW 5.50
Fuse rating washing machine in A 25.0
5.22
5.50
25.0
Page 3
PDW 909 [EL DP DD]
Professional washer-dryer stack, electric heating, with drain pump
For washing/drying in the smallest of spaces.
Water connection/drainage
Drain pump DN 22
Dimensions and weight
External dimensions, net height in mm 1940
External dimensions, net width in mm 692
External dimensions, net depth in mm
Net weight in kg 208.0
Net weight in kg
Emissions data
Emission sound pressure level in the workplace
Washing machine heat dissipation into the room in MJ/h
1.62
Features
Washer-extractor disinfection rinse •
Washer-extractor temperature monitoring •
•
Special heater element washing machine •
•
•
•
•
•
•
Machine-independent accessories •
Connection options
Payment system (optional) •
•
Peak-load negotiation / energy management (optional) •
LAN for washing machine •
WiFi •
Connector Box •
Capacities
4
1
2
1
2
1
2
204
42
union
union
Page 4
PDW 909 [EL DP DD]
Professional washer-dryer stack, electric heating, with drain pump
For washing/drying in the smallest of spaces.
2
Standards, test certicates and symbols
CE •
•
•
Splash-proof safety rating IPX4 •
Regulation 4 compliant •
UKCA •
WEEE •
Complies with Machinery Directive 2006/42/EC •
