Medion GoPal E3240, MD98030 Operating Instructions
Notes on these Operating Instructions
The operating instructions and installation guidelines have been organized so that subjectrelated information can be easily found using the contents list.
Note
You will find comprehensive Operating Instructions for navigation on DVD
and at the online help of the device.
The section "Frequently Asked Questions" contains answers to questions that are frequently addressed to our customer service department.
Document Your Navigation Unit
It is important to record the details of your Navigation Unit and the purchase thereof. In
the event you require warranty support you may be asked for this information. The serial
number can be found on the back of the device:
Serial Number ....................................................................................
Password ....................................................................................
Information note ....................................................................................
SuperPIN ....................................................................................
UUID ....................................................................................
Date of Purchase ....................................................................................
Place of Purchase ....................................................................................
Please record the serial number into any appropriate guarantee documents.
You will enter your own password and information note using the Security Function.
The SuperPIN and the UUID will be provided following the activation of the Security Func-
tion. See Page 17.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
Quality
The components used have been selected to provide a product that has a high level of
functionality and is user friendly, safe and reliable. A well-balanced hardware and software
design allows us to offer you a technologically advanced navigation system, which is both
practical and enjoyable to use.
Service
Our customer care is there to provide support and assistance whenever you have questions or are experiencing problems.
This manual contains a section specific to Customer Service starting on page 41.
Copyright © 2010, version 05/01/2010. All rights reserved. Microsoft®, MS-DOS®, and Windows are
registered trademarks of Microsoft Corporation in the U.S. and other countries. Pentium
tered trademark of Intel Corporation. The names of actual companies and products mentioned herein
may be the trademarks of their respective owners. Information in this document is subject to change
without notice
.
®
is a regis-
-ii-
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
Contents
Safety and Maintenance .................................................................................. 1
Safety Instructions ......................................................................................................... 1
Data Security ................................................................................................................. 1
Operating Environment ................................................................................................. 2
Repair ............................................................................................................................ 2
Ambient temperature .................................................................................................... 2
Electromagnetic Compatibility ...................................................................................... 3
Connection ................................................................................................................... 3
Power supply through Car Adapter ............................................................................ 3
Cabling ......................................................................................................................... 3
Information about the Regulatory Compliance according to R&TTE .............................. 4
Battery Operation .......................................................................................................... 4
Cleaning and Maintenance ............................................................................................ 4
Care of the Display ........................................................................................................ 5
Recycling and Disposal .................................................................................................. 5
Transport ...................................................................................................................... 6
Supplied Items .............................................................................................................. 7
Views ............................................................................................................... 8
Front Components ........................................................................................................ 8
Back Components ......................................................................................................... 9
Bottom Components ..................................................................................................... 9
Top Components ........................................................................................................ 10
Initial Set up .................................................................................................. 11
I. Charging the Battery ................................................................................................ 11
II. Power Supply .......................................................................................................... 12
Car adapter .............................................................................................................. 12
Alternative possibility of charging the battery ........................................................... 12
III. Switching on the Device ......................................................................................... 13
IV. Installing the Navigation Software .......................................................................... 14
General Operating Instructions ..................................................................... 15
Switching on/off the device ......................................................................................... 15
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
- iii -
Security ......................................................................................................... 16
Storing the password and the information note .......................................................... 16
Making settings ........................................................................................................... 17
SuperPIN and UUID ..................................................................................................... 18
Making subsequent settings ........................................................................................ 19
Password Request ....................................................................................................... 20
Resetting the Navigation System ................................................................... 21
Reset ........................................................................................................................... 21
Switching the Device off Completely / Hard Reset ....................................................... 22
Navigation ..................................................................................................... 23
Safety Instructions for Navigation ................................................................................ 23
General Instructions ................................................................................................. 23
Notes for Use in a Vehicle ......................................................................................... 24
Aerial Orientation ........................................................................................................ 25
I. Mounting the Car Holder ......................................................................................... 25
II. Attaching the Navigation System ............................................................................. 26
III. Connecting the Car Adapter ................................................................................... 27
IV. Starting the Navigation Software ............................................................................ 28
Warning function for traffic monitoring points ............................................ 29
Picture Viewer ............................................................................................... 32
Operating the Picture Viewer ....................................................................................... 32
Main Screen ................................................................................................................ 32
Full Image View........................................................................................................ 33
Travel Guide .................................................................................................. 35
AlarmClock (Waking function) ...................................................................... 38
Overview of the main screen ....................................................................................... 38
Description of the Interfaces ........................................................................................ 39
Setting the System Time ........................................................................................... 40
Selecting an Alarm Signal ......................................................................................... 41
Setting the Volume .................................................................................................. 42
Snooze Function ...................................................................................................... 43
Ending the Alarm Clock Application ......................................................................... 43
Sudoku .......................................................................................................... 44
Main Screen ................................................................................................................ 44
Description of the switch fields .................................................................................... 45
Overview of the game area .......................................................................................... 46
Description of the switch fields ................................................................................. 46
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-iv-
FAQ ................................................................................................................ 47
Customer Service ........................................................................................... 48
Faults and Possible Causes .......................................................................................... 48
Additional Support ...................................................................................................... 48
Appendix ....................................................................................................... 49
Special CleanUp Function............................................................................................ 49
Synchronisation with the PC ........................................................................................ 52
I. Installing Microsoft® ActiveSync® ............................................................................ 52
II. Connecting with the PC ....................................................................................... 53
Mass Storage Mode .................................................................................................. 53
ActiveSync® mode ..................................................................................................... 54
Alternative possibility of charging the battery ........................................................... 54
III. Working with Microsoft® ActiveSync® .................................................................... 55
GPS (Global Positioning System) ................................................................................. 56
TMC (Traffic Message Channel) ..................................................................... 57
Pay TMC ...................................................................................................................... 57
Connecting an additional TMC Dipole Aerial (optional) ........................................... 58
Working with Memory Cards ....................................................................................... 58
Inserting Memory Cards ........................................................................................... 59
Removing Memory Cards ......................................................................................... 59
Accessing Memory Cards ......................................................................................... 59
Data Exchange via Card Reader ................................................................................... 60
Additional Card Material .............................................................................................. 60
Transfer of card material to a memory card .............................................................. 60
Alternate method of installing Navigation Software (using a Memory Card) ........... 61
Transferring Installation Files and Map Material to the Internal Memory .................. 61
Specifications ................................................................................................ 62
Index ............................................................................................................. 63
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-v-
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-vi-
Safety and Maintenance
Safety Instructions
Please read this section carefully and follow all the instructions provided. This will help
ensure reliable operation and prolong the life for your appliance.
Keep the packaging and the user instructions for future reference or inquiries at a later
date. If you pass the article on to another person, you should pass on these instructions.
Never allow children to play with electrical equipment unsupervised.
Keep the packing materials, such as plastic bags away from children as there is a
danger of suffocation.
Please operate your navigation system with an approved power supply only.
Never open up the housing of the appliance or the power adapter. These contain
no user-serviceable parts. If the housing is opened there is a danger of electric
shock.
Do not place any objects on the appliance and do not exert any pressure on the
display. Otherwise there is a danger that the screen will break.
To avoid damage, do not touch the screen with sharp objects. We recommend us-
ing only the stylus provided or finger when using the touch-screen functionality of
the product.
There is a risk of injury if the display breaks. If this should occur, use protective
gloves to pack the broken parts and contact customer support to arrange for disposal. Then wash your hands with soap, since there is a possibility that chemicals
may have escaped.
Remove the power adapter from the outlet, switch the appliance off immediately, or do
not switch it on, and contact Customer Service.
If the housing of the appliance or the power pack becomes damaged or liquid may
have leaked into it the components must be checked by Customer Service in order
to avoid damage!
Data Security
Every time your data is updated or modified backup copies should be made on an
external storage medium. The supplier assumes NO liability for data loss or damage
to data storage units, and no claims can be accepted for damages resulting from
the loss of data or for consequential damages.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-1-
Operating Environment
Failure to follow these instructions may lead to your appliance being damaged. In cases
where products are damaged as a result of misuse of neglect the associated guarantee will
be considered void.
Keep your navigation System and all connected devices away from moisture and
avoid exposure to dust, heat and direct sunlight, especially in the car.
Make sure you prevent your appliance from getting wet, e.g. from rain and hail, at
all times. Please note that moisture can even build up inside a protective pouch as a
result of condensation.
Avoid heavy vibrations and shaking.
Please note the device should be installed vertically, this will ensure that the device
remains secured within its holder.
Repair
Please contact our Service Center if you encounter technical problems with your
appliance.
In the event repair becomes necessary, please use only our authorized Service
Partners. You will find the address on the back of your guarantee card.
Ambient temperature
The appliance will operate effectively at an ambient temperature of between +32°F
and +95°F (0° C and 35° C) and at a relative humidity of between 10% and 90%
(non-condensing).
In the powered down state the appliance can be stored at between -4°F and
+140°F (-20°C and +60°C).
Store the appliance in a safe location, away from high temperatures (e.g. when
parking or from direct sunlight).
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-2-
Electromagnetic Compatibility
When connecting additional or other components the “Electromagnetic Compati-
bility Directive” (EMC) must be adhered to. Please note that only screened cable
(maximum 10ft) should be used with this appliance.
For optimal performance, maintain a distance of at least 10 ft. from sources of high-
frequency and magnetic interference (televisions, loudspeaker systems, mobile
telephones etc. This will help to avoid malfunctions and loss of data.
Electronic devices emit electromagnetic waves during operation.
These emissions are harmless, but can interfere with other devices operated in close
proximity.
While our devices are tested and optimized for electromagnetic compliance in our
laboratories, interference during operation may still occur in the device itself and
with other devices in its proximity.
Should such interference occur, try to eliminate it by adjusting the positions of and
the distances between the devices.
Before driving, please ensure that the electronic systems of the car are working
properly.
Connection
When connecting your appliance it is important to observe the following instructions:
Power supply through Car Adapter
The car adapter should only be connected to the lighter socket of a car
(car battery = DC 12V , truck battery = DC 24V ). If you are in any doubt about
the power source in your car, please contact your car manufacturer.
Cabling
Arrange cables so that they do not cause unnecessary obstruction or risk entangle-
ment or snaring. E.g. ensure that the cables cannot be trod on, or tripped over.
Do not put any objects on the cable, because it could be damaged if you do so.
Do not use any force and pay attention to the correct orientation of the plug when
connecting the cables and plugs.
Do not permit any great forces to be exerted on the plug connections, from the
side, for example. This will lead to damage in and to your device if you do so.
Avoid short circuiting and broken cable by not crushing or bending it sharply.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-3-
Information about the Regulatory Compliance according
to R&TTE
The following radio equipment has been supplied with this device (optional):
The company declares that this device is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC. Complete declarations of conformity
are available under www.medion.com/conformity
.
Battery Operation
Your appliance is powered by an integrated battery. In order to prolong the life and efficiency of your battery and ensure safe operation, follow the instructions below:
Batteries cannot withstand excessive heat. Take care to avoid overheating of appli-
ance and the integrated battery. Failure to comply with this instruction may lead to
damage to or, even explosion of the battery.
Only use the car adapter to charge the battery from the navigation kit.
The batteries are special category waste. When disposing of the appliance en-
sure that this is done correctly. Contact Customer Service for more details.
Cleaning and Maintenance
Warning
There are no user-serviceable or parts which require cleaning inside the
housing of the appliance.
You can prolong the life of the appliance by taking the following simple steps:
Always remove the power plug and all connecting cables before cleaning.
Clean the appliance only with a damp, lint-free cloth.
Do not use solvents, caustic or gaseous cleaners.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-4-
Care of the Display
Avoid scratching the display surface as this may be easily damaged. We recom-
mended using a display protection film (mylar) to prevent scratching to the screen.
Please contact your nearest dealer for this accessory.
The foil on the display at delivery is purely for protection during transportation!
Ensure that no traces of water remain on the screen. Water can cause irreversible
discoloration.
Use only a soft, lint-free cloth to clean the screen.
Do not expose the screen to strong sunlight or ultraviolet radiation.
Recycling and Disposal
The device and its packaging are recyclable.
Device
At the end of its life, the appliance must not be disposed of in household rubbish. Consult
your local waste disposal company to enquire about environmentally-friendly options for
disposal.
Packaging
To avoid damage during transport, the appliance is supplied in protective packaging. The
majority of packaging is manufactured from materials which can be disposed of in an
environmentally friendly manner and be recycled professionally.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-5-
Transport
When transporting the appliance please follow the instructions below:
After transporting the appliance wait until the unit has acclimatised and adjusted to
surrounding conditions (e.g. room temperature and humidity) prior to use.
In the event of large fluctuations in temperature or humidity, condensation or
moisture may form inside the appliance. This can cause an electrical short-circuit.
In order to protect the appliance from dirt, knocks and scratching, please use an
appropriate protective case.
Before travelling ensure that you are aware of the power and communications pro-
visions at your destination. Before travelling obtain any power or communications
adapters that may be required for the operation of your device.
When shipping your appliance we recommend using the original packaging. If the
original packaging isn’t available please contact customer service for advice.
When passing through baggage control at airports, it is recommended that you
pass the appliance and all magnetic storage media (external hard drives) through
the X-ray system (the machine on which your bags are placed). Avoid the magnetic
detector (the structure through which you yourself pass) or the magnetic wand
(the hand device that the security staff use), since this may corrupt your data.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-6-
Supplied Items
Please check the condition of items supplied and check for missing items using the list
below. If you find your package to be incomplete, please forward us all claims for missing
items within 14 days from the date of purchase.
The package should include the following:
Navigation system
Power cable for cigarette lighter
Car holder
TMC dipole antenna
USB cable
Adapter 2.5mm to 3.5 mm for earphones
DVD with navigation software, digital maps, ActiveSync®, data for rapidly resetting
the contents of the memory card/internal memory
Instruction manual and warranty card
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-7-
Views
Front Components
Ref Component Description
Battery charge
indicator
Touch Screen Displays the output of your appliance. Tap on
The LED will flash orange during the charging
process. It will shine constant green when the
accumulator is fully charged.
the screen with the stylus (found in the holder,
see page 26) to select menu commands or
enter data.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-8-
Back Components
Ref Component Description
Loudspeaker Provides audible language statements and warn-
Bottom Components
ings.
GPS
aerial
Ref Component Description
Slot for mem-
ory card
Mini-USB-
Connector
Headphone
connection
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
Accepts an optional memory card for
removable storage.
Connection for connecting to a PC by means of a
USB cable (for data transfer) as well as connection to
external power supply.
Connection for a pair of stereo headphones
Using this appliance at full or
high volumes for extended
periods of time may cause
damage to the hearing of the
listener.
You also have the possibility to connect a TMC dipole antenna here.
-9-
Top Components
Ref Component Description
On/Off button
Turn the device on or off by pressing and holding
the On/Off button. You will switch to the stand-by
mode or reactivate the device by quickly pressing
the button.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-10-
Initial Set up
The following is a step by step guide to assist in the initial Set-up of the navigation system.
Start by removing the protective plastic sheet from the display.
I. Charging the Battery
The battery of your navigation system can be charged in the following ways:
Using the supplied car adapter,
using a suitable USB cable or
by using a mains adapter (purchased as an optional extra).
Attention!
It may be necessary to initially charge the battery for a considerable period
of time prior to commencing and running through the initial installation,
this is dependent on the level of charge held at the time by the internal
battery.
Please observe the following notes:
The charging status display LED will flash orange until the navigation system is
charged. If possible, do not interrupt the charging process until the
battery is fully charged. This may take a few hours. The charging status LED will
shine constant green if the battery has a high level of charge. Leave the device
charging for 20 further minutes, to ensure the battery is charged-up fully.
The navigation system can be used during the charging process, but the power
supply must not be interrupted during initial set-up.
Leave the external power supply connected to the navigation system for around
24 hours, so that the backup battery also charges-up fully.
The external power supply can remain connected; this is recommended for con-
tinuous operation.
Even after a power source has been connected to the device it may take several
minutes until the device is once again ready to operate again, this occurs if the
charging state of the battery is exceptionally low. The battery will continue to be
charged if the power supply is connected and the device is switched off.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-11-
II. Power Supply
Car adapter
1. Plug the jack () of the connection cable into the corresponding receptor at the
bottom of your navigation system.
2. Insert the power adapter () into the cigar lighter socket ensuring, that it will not
lose contact while driving. This could cause a malfunction.
Alternative possibility of charging the battery
The battery will charge as soon as you connect your navigation device to a switched-on PC
or notebook by means of a USB cable.
No additional software or updates are required for your PC to perform this function. Do
not interrupt the charging process if possible during the initial charge.
Note
The brightness will be adjusted downwards, if necessary, if a USB connection is being set up when the device is switched on.
It is recommended to set the device to the stand-by mode, in order to
shorten the charging time by USB.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-12-
III. Switching on the Device
You will switch your navigation device on or off again completely by pressing the On/Off
key for a long time (> 3 sec.). The Navigation System will start the initial installation auto-
matically. First of all choose the requested language. The brand logo will appear and after
some seconds your device shows the following screen:
Button Description Screen
Menu Map overview
Navigation menu
Other applications
Settings
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-13-
Note
You will not be able to select the Navigation Menu or Settings, if the navigation software has not found any map data in the device or on the memory card. Then, the ‘Other applications’ Menu will appear
automatically.
Note
Brief pressure on the On/Off button will be enough to switch the device
on or off, provided that your navigation system is connected to an external
source of electricity or is running in battery operation (standby mode). The
device will be reactivated by pressing the On/Off button once .
You can adjust the period of operation to suit your needs using the
Settings button on the main screen of your device. Your device is delivered in a status in which it will not switch off independently.
Press and hold the On/Off key (> 3 sec.), to completely switch off the
device.
No data will be lost as data is stored in the internal memory. The starting
process will only take slightly longer.
Your navigation system will use a low amount of electricity and the batteries will be discharged, even when in standby mode.
IV. Installing the Navigation Software
The final installation of the navigation software will take place automatically from the internal memory, during the initial setting up, if your device has already been equipped with
the basic data of the navigation software at the factory. Follow the instructions on the
screen.
An optional memory card must always be inserted in the device while the navigation system is being used.
It will be necessary to carry out a Reset to restart the navigation system if the memory card
has been removed (see page 21).
Please also read the chapter Navigation starting on page 23.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-14-
General Operating Instructions
Switching on/off the device
Your device will be in its normal operating state after the initial setting up. You can activate
and deactivate your device with the On/Off button.
1. To start your navigation system press briefly the On/Off button. The battery charge
indicator will blink briefly and the application screen will appear.
Note
Your device is delivered in a status in which it will not switch off independently. You can adjust the period of operation to suit your needs using the
Settings button on the main screen of your device.
Your navigation system will use a low amount of electricity and the batteries will be discharged, even when it is in the standby mode.
2. To switch off your navigation system briefly press the Power button.
The following screen will appear:
You have three possible choices:
Button Description
Cancel/Back
Return to previous view with this key, if you have accidently called
up this screen.
Standby Mode
The device will go into Standby Mode if this key is clicked.
Reset
You can carry out a reset by tapping this key.
The device will go into the Standby mode automatically after a few seconds if you do not
want to select any of these three possibilities.
UK/ N. IRELAND HELPLINE 0871 3761020
REP. IRELAND HELPLINE 1-800-992508
(calls are charged at 7p per min from a standard landline, calls from mobiles could be higher)
-15-
Loading...
