CR12 Multizone A/V Control Center
MC7108 8-Channel Power Amplifier
McINTOSH MULTIZONE A/V
Page 2
McINTOSH MULTIZONE A/V
or more than a decade McIntosh has offered multizone systems distinguished not
only by musical excellence but also by operating ease and adaptability. A
McIntosh multizone A/V system integrates seamlessly with non-McIntosh products
and can be scaled for any size installation. If you love music and you want
McIntosh performance, a multizone system gives you more of both. But it’s also a
F
number of rooms or areas in your home. The CR12 Multizone A/V Control Center and the
MC7108 8-Channel Power Amplifier go together like hand in glove, offering abundant
possibilities for a house-wide entertainment system with true McIntosh performance.
smart investment, as it uses just one set of audio and video sources to supply any
Page 3
McINTOSH MULTIZONE A/V
CR12
Multizone A/V Control Center
Featured Technologies
FOUR INDEPENDENT ZONES (CR12). The CR12 is four audio/video preamps in one
chassis, each with its own input selector, volume control, and tone controls. For example,
you can listen to FM stereo in one zone, CD in a second, watch satellite in a third, and
watch a DVD movie in a fourth – all at the same time. In addition, a local “private” A/V
source can be connected for each zone for use only by that zone. As many as six CR12s
can be linked (“cascaded”) for a total of 24 independent A/V zones.
CONTROL DATA OUTPUTS (CR12). To facilitate system integration, the CR12 outputs
control data for source components. This allows remote operation of non-McIntosh components
either by direct connection to compatible data inputs or via a McIntosh Remote Translator.
REMOTE POWER CONTROL (CR12 + MC7108). The MC7108 receives power on/off
data via its single cable link to the CR12. In addition, power control jacks provide the
same capability when the units are not linked. A special multipin jack on the CR12 connects
to the PC3 AC Power Controller, which coordinates power on/off of zone amps, audio
sources, and video components.
EXCLUSIVE MCINTOSH TONE CONTROLS (CR12). Judicious use of well-designed bass
and treble controls can compensate for acoustical irregularities. Each zone of the CR12 has
its own bass and treble control that offers ±12dB adjustments with fine resolution, yet in
the “flat” position is completely removed from the signal path.
MATCHED AND BUFFERED VIDEO SWITCHING (CR12). High-resolution video sources
such as DVDs demand high-quality video switching. Each CR12 video input is terminated
with 75 ohms to maintain a proper impedance match. Video buffer amplifiers feed the
CR12’s monitor video output, ensuring no loss in picture quality. In addition, the input
buffers feed a line-matched signal to the individual video outputs, preventing signal
degradation if those sources are in turn fed to another CR12 or a master preamp.
BALANCED CONNECTIONS (CR12). Balanced connections guard against induced noise
and allow long cable runs without compromising sound quality. The CR12’s four balanced
outputs can be used to feed larger power amps (such as the MC162) for installations that
require high sound levels.
CONFIGURABLE POWER OUTPUT (MC7108). Channels 1/2, 3/4, 5/6, and 7/8 can be
operated either in the normal mode (40W x 8) or with each channel pair independently
bridged (100W x 4). Configurations of 7, 6, 5, and 4 channels are also possible. For example,
a 5-channel configuration for home theater would comprise three bridged channel pairs
plus two normal channels, resulting in 100Wx3 for left/center/right speakers and 40Wx2
for the surround speakers.
EXCLUSIVE MCINTOSH POWER ASSURANCE SYSTEM (MC7108). Power Assurance is
a collection of technologies that enhance performance and reliability and protect the amp
and the loudspeakers.
All it takes is one cable to join
the CR12 and the MC7108…
and one more to link a multizone system to a home theater.
Power Guard
deliver full power without causing clipping distortion. If an amplifier channel is overdriven, Power Guard automatically reduces the input volume just enough to keep distortion
below 2% and prevent any clipping distortion. Thanks to an optical resistor, Power Guard
MC7108
8-Channel Power Amplifier
®
clipping protection. Power Guard ensures that the amplifier will always
Page 4
About the CR12/MC7108 Companion Products
The McIntosh products shown at right are logical companions for the CR12/MC7108. Separate
literature is available. Check with your McIntosh dealer for any late additions. McIntosh speaker
systems are also covered in detail in separate literature.
WK2, WK3, WK4 Keypad Controllers and R649 IR Sensor. The wall-mount, illuminated keypads
enable pushbutton operation and include IR sensors that relay commands from handheld
remotes. The CR12 can accommodate as many as four keypads or IR sensors in each of its four
zones. (See the separate McIntosh System Accessories literature for more on keypads and IR sensors.)
RCT3 Remote Translator. The Translator allows non-McIntosh components to be operated with
a McIntosh IR remote or keypad controller. It connects to the data outputs on the CR12.
HC1 Home Controller. The HC1 connects to the CR12’s HOME data output and allows remote
operation of other home devices such as lights and movie screens.
PC3 AC Power Controller. The PC3 provides a total of 14 AC outlets (11 switched, 3 unswitched)
for automatic AC control of zone amps, audio sources, and video components. It connects to a
multipin jack on the CR12.
PC4 AC Power Control. The PC4 provides five AC outlets (four switched) for turning nonMcIntosh components on and off automatically when it is connected to the power control output
of a Control Center or Integrated Amplifier.
MR7084 AM/FM Tuner with RAA1 Remote AM Antenna. Likely to be the most-used source in
a multizone system, the MR7084 tuner is a thoroughly engineered broadcast monitor that reveals
the upper limits of AM and FM performance. The optional RAA1 antenna can be positioned away
from sources of interference (e.g., TV sets, fluorescent lights) for greatly improved AM quality.
MX132 A/V Control Center + Processor. A single cable connection between the MX132 and
the CR12 integrates a McIntosh home theater and multizone system. This lets the two systems
share one group of source components. (The MX132 has a built-in AM/FM tuner and is supplied
with the RAA1 antenna, obviating the need for the MR7084.)
CR12/MC7108
Companions
WK2, WK3, WK4 KEYPAD CONTROLLERS
AND R649 IR SENSOR
RCT3 REMOTE TRANSLATOR
abc
The patented McIntosh Power Guard in the
MC7108 provides real-time clipping protection
without affecting power output or sound quality.
a) test signal
b) overdriven amp without Power Guard produces
SEVERE clipping
c) overdriven amp with Power Guard produces
NO clipping
Featured Technologies (cont’d.)
acts literally at the speed of light, producing absolutely no audible side effects. An amplifier
with Power Guard will actually deliver clipping-free output well above its rated power.
Sentry Monitor
current of the output stage and confines it to a safe limit. Sentry Monitor does not limit
power output.
Thermal Cutout. If the cooling air is blocked and the power transistors become too hot,
thermal cutouts protect against overheating until the amp cools.
Turn-On Delay. This circuit delays operation for about two seconds after turn-on in
order to avoid any pops or thumps generated as other equipment turns on.
Soft Start inrush protection. Thermistors in the power transformer act as a cushion
against inrush current, eliminating component stress during turn-on. Soft Start is one of
many design details that contribute to the remarkable longevity of McIntosh equipment.
®
current protection. Sentry Monitor continually senses the voltage and
HC1 HOME CONTROLLER
PC3, PC4 AC POWER CONTROLLERS
MR7084 AM/FM TUNER
MX132 A/V CONTROL CENTER
+ PROCESSOR
ost consumer electronics products are necessarily viewed
as short-term investments because either they don’t last
M
or they quickly become obsolete in some way. Coincidentally,
manufacturers supply a steady stream of “new-and-improved”
products that you can buy. Again.
Behind every McIntosh is a fifty-year heritage of excellence,
proudly carried forward by every employee. No production
lines, no “price-point” engineering, no planned obsolescence.
McIntosh equipment is made to sound better and last longer.
When McIntosh products are presented to customers, the
criteria they have been conditioned to overlook – reliability,
longevity, craftsmanship, ease-of-use, adaptability, pride of
ownership – suddenly leap to the top of their list.
The choice becomes clear: There is nothing like a McIntosh.
Page 5
CR12 Multizone A/V Control Center
FEATURES
Multizone A/V Control Center
4 independent zones comprising 4 McIntosh A/V preamps
Single-cable connection to McIntosh MC7108
8-Channel Power Amplifier
Single-cable connection to a “master” preamp (e.g., to link CR12
multizone system to MX132-based home theater system)
Single-cable connections for cascading as many as six
CR12s for a total of 24 independent zones
8 common (shared) sources (4 audio, 4 A/V)
1 additional local “private” A/V source for each zone
LED status indicators for all 4 zones
Programmable “wake-up” conditions for each zone
Output level trim for each zone (can also be used to set
maximum permissible volume)
Exclusive McIntosh tone controls for each zone
Balanced outputs for each zone (fixed or variable)
Unbalanced outputs for each zone (variable)
Matched and buffered video switching
Control data output for source components
Remote operation of lights, screens, and drapes with
McIntosh HC1 Home Controller
Remote power control
Selectable control priority for limiting operation from any zone
Accommodates as many as 4 keypads or IR sensors per zone
Front panel reset does not affect memory
Gold-plated input and output jacks
Modular construction with steel chassis
Glass front panel with illuminated nomenclature
MC7108 8-Channel Power Amplifier
FEATURES
8-Channel Power Amplifier for multizone and home theater systems
Single-cable connection to CR12 Multizone A/V Control Center
8 x 40 watts (4 ohms) or 8 x 25 watts (8 ohms)
Any pair can be bridged for 1 x 100 watts (4 ohms)
Configurable to 7, 6, 5, or 4 channels
Theater power configuration: (3 x 100W) + (2 x 40W)
Wide power bandwidth
Ultra-low distortion
Exclusive McIntosh Power Assurance System:
MC7108
EIGHT CHANNEL
POWER AMPLIFIER
McINTOSH LABORATORY INC. BINGHAMTON, NY 13903
SERIAL
POWER
NUMBER
CONTROL
LOCAL
REMOTE
WARNINGSHOCK HAZARD-DON NOT OPEN. FOR
CONTINUED PROTECTION AGAINST FIRE HAZARD,
REPLACE ONLY WITH SAME TYPE AND RATING FUSE.
AVISRISQUE DE CHOCK-ELECTRIQUE-NE
PAS OUVRIR. REMPLACER PAR UN FUSIBLEDE DE MEME
TYPE AMPERAGE ET VOLTAGE.
CAUTION SEE OPERATING MANUAL
ATTENTION VOIR LE CAHIER
D’INSTRUCTION
8A 250V
SLO-BLO
120V 50/60Hz
4.5A
8
IN
OUT
LEVEL
87
Power Guard®clipping protection
Sentry Monitor
Thermal Cutout
7
IN
BRIDGED
OUT
OUT
1V
2.5V
8
LEVEL
1V
2.5V
7
BRIDGED
BRIDGED
STEREO
MODE
MONO
BRIDGED
8 CHANNEL
5
6
IN
IN
BRIDGED
OUT
1V
2.5V
6
1V
2.5V
5
BRIDGED
POWER
CONTROL
BRIDGED
OUT
STEREO
MODE
MONO
BRIDGED
6
MULTI
ROOM
3
4
IN
IN
IN
OUT
LEVEL
43
IN
BRIDGED
OUT
1V
2.5V
1V
2.5V
BRIDGED
BRIDGED
STEREO
MODE
MONO
BRIDGED
1
2
IN
IN
BRIDGED
OUT
OUT
1V
2.5V
4
3
3
LEVEL
1V
2.5V
2
BRIDGED
BRIDGED
STEREO
MODE
MONO
BRIDGED
215
Turn-On Delay
Soft Start inrush protection
Low-noise toroid power transformer
Remote power control
Gold-plated high-current output terminals
Fanless convection cooling
Modular construction with steel chassis
Glass front panel with illuminated nomenclature
®
current protection
Page 6
CR12 Multizone A/V Control Center
SPECIFICATIONS
Frequency Response
20Hz to 20kHz, +0 / -0.5dB
S/N Ratio (A-Weighted)
90dB below rated output
Rated Voltage Output
2.5V
Maximum Voltage Output
8V from 20Hz to 20kHz
Output Impedance
600 ohms balanced and unbalanced
Total Harmonic Distortion
0.019% max. 20Hz to 20kHz
at rated output
Input Sensitivity
250mV for rated output
Maximum Input Signal
8V
MC7108 8-Channel Power Amplifier
SPECIFICATIONS
RMS Power Output
Min. sine wave continuous avg. output
per channel with all channels operating:
Normal: 40 watts (4Ω) or 25 watts (8Ω)
Bridged: 100 watts (4Ω)
(Can also be configured for 7, 6, 5, or 4 channels)
Output Load Impedance
8 or 4 ohms
Rated Power Band
20Hz to 20kHz
Peak Output Current
> 10 amperes
Total Harmonic Distortion
0.005% max. at any level from 250mW
to rated output from 20Hz to 20kHz
Input Impedance
22k ohms
Voltage Gain
Input to variable outputs: 14dB
Input to fixed (balanced) outputs: 0dB
Tone Controls
Bass and treble ±12dB
Power Requirements
120V 50/60Hz, 25W
Dimensions (h x w x d)
inch: 7.062 x 17.5 x 20
cm: 17.9 x 44.5 x 50.8
Weight
15 lbs. (6.8kg) net
27 lbs. (12.2kg) shipping
Input Sensitivity
1V (2.5V at gain control center detent)
A-Weighted Signal-to-Noise Ratio
92dB (112dB below rated output)
Wide Band Damping Factor
200 (8 ohms); 100 (4 ohms)
Input Impedance
20k ohms
Power Guard®
Clipping is prevented and THD
does not exceed 2% with up to
14dB overdrive at 1kHz
Power Requirements
120V 50/60Hz, 4.5A
Intermodulation Distortion
0.005% maximum if instantaneous
peak output does not exceed twice
the output power rating
Dynamic Headroom
1.8dB
Frequency Response
20Hz to 20kHz, +0 / -0.25dB
10Hz to 100kHz, +0 / -3.0dB
tel (607) 723–3512
Dimensions (h x w x d)
inch: 7.062 x 17.5 x 20
cm: 17.9 x 44.5 x 50.8
Weight
40 lbs. (18.1kg) net
58 lbs. (26.4kg) shipping
McIntosh Laboratory, Inc., 2 Chambers Street, Binghamton, New York 13903
• U.S. toll-free (888) 979–3737 • fax (607) 772–3308 • www.mcintoshlabs.com
0999.CR12.25k.essecomm
Loading...
