PRO MAC 72
™HMANTIKE™ ¶†HPOºOPIE™
GR
¢È·‚¿ÛÙ ÙÔ ÚÈv ·fi ÙË ¯Ú‹ÛË Î·È Ê˘Ï¿ÍÙÂ
ÙÔ ÁÈ· v· ÙÔ Û˘Ì‚Ô˘Ï‡ÂÛÙ ÛÙÔ Ì¤ÏÏÔv
A.B.C.
D.
Partner
McCulloch
oil
50 : 12%40 : 1
1 ltr. 20 cm325 cm340 cm
4 80 100 160
5 100 125 200
10 200 250 400
20 400 500 800
oil
2,5%
2 T
oil
25 : 1
4%
3
E.
F.
G.
H.
I.
L.
A SUMMARY CHART TO IDENTIFY THE CORRECT COMBINATION OF BAR/CHAIN - FILE/FILE HOL-
DER
D TABELLA RIASSUNTIVA PER IL CORRETTO ABBINAMENTO BARRA/CATENA - LIMA/GUIDA- LIMA
B TABLEAU RECAPITULATIF POUR LE CORRECT ACCOUPLEMENT CHAINE/GUIDE CHAINE -
LIME/PORTE LIME
C TABELLE FÜR DIE KORREKTE KOMBINATION VON STANGE/KETTE - FEILE/FEILENFÜHRUNG
E TABLA PARA EL CORRECTO ACOPLAMIENTO DE LA CADENA/BARRA DE GUÍA - LIMA/GUÍA DE
AFILADO
F OVERZICHTSTABEL VOOR EEN CORRECTE STANG/KETTING - VIJL/VIJLLEIDER VERBINDING
s SAMMANFATTANDE TABELL FÖR RÄTT KOMBINATION STÅNGE/KEDJA FIL/FILFÖRARE
q GENOPTAGENTE LISTE TIL KORREKT SAMMENFÖJNING/ KÆDE-FIL/FÖLGERFIL
v OIKEAN YHDISTELMÄN TAULIKKO PUTKI/KETJU - HÖYLÄ/HÖYLÄTÄSO
{ SAMMENFATTENDE TABELL FOR KORREKT SAMMENKOBLING AV STANG/KJETTING - FIL/FIL-
SKINNE
p TABELA RESUMIDA PARA O CORRETO EMPARELHAMENTO BARRA/CORRENTE - LIMA/GUIA-
LIMA
k ΠΙΝΑΚΑΣ ΠΕΡΙΕΧΟΜΕΝΩΝ ΠΑ ΤΟ ΣΩΣΤΟ ΣΥΝΑΙΑΣΜΟ ΜΕΤΑΞΥ ΡΑΒ∆ΟΥ/ΑΛΥΣΙ∆ ΑΣ −
ΛΙΜΑΣ/Ο∆ΗΓΟΥ ΛΙΜΑΣ
≤ TÁBLÁZAT A VÁZ/LÁNCÉS RESZELÖ/RESZELÖVEZETÖ KORREKT KOMBINÁCIÓIHOZ
PRO MAC 72
225735 B
225739 B
68T
18”/45cm
3/8”
86826B (7/32”)
225736 B
225740 B
72T
20”/50cm
3/8”
86826B (7/32”)
20”/50cmSP
72T
3/8”
225737 B
225740 B
86826B (7/32”)
24”/60cmSP
82T
3/8”
241366
241367
86826B (7/32”)
28”/70cmSP
92T
3/8”
241368
241369
86826B (7/32”)
Due to a constant product improvement programme, the factory reserves the right to modify technical details mentioned in this manual
g
without prior notice.
La casa produttrice si riserva la possibilità di variare caratteristiche e dati del presente manuale in qualunque momento e senza preavviso.
i
La Maison se réserve la possibilité de changer des caractéristiques et des données de ce manuel à n’importe quel moment et sans préa-
f
vis.
Im Sinne des Fortschritts behält sich der Hersteller das Recht vor, technische Änderungen ohne vorherigen Hinweis durchzuführen.
C
La firma productora se reserva la posibilidad de cambiar las características y datos del presente manual en cualquier momento y sin pre-
e
vio aviso.
Door konstante produkt ontwikkeling behoud de fabrikant zich het recht voor om rechnische specificaties zoals vermeld in deze handlei-
h
ding te veranderen zonder biervan vooraf bericht te geven.
Tilverkaren reserverar sig rätten att ändra fakta och uppgifter ur handboken utan förvarning.
s
Producenten forbeholder sig ret til ændringer, hvad angår karakteristika og data i nærværende instruktion, når som helst og uden varsel.
q
Jatkuvan tuotteen parannusohjelman tähden valmistaja pidättää oikeuden vaihtaa ilman ennakkovaroitusta tässä ohjekirjasessa mainittuja
v
teknisiä yksityiskohtia.
Produsenten forbeholder seg all rett og mulighet til å forandre tekniske detaljer i denne manualen uten forhåndsvarsel.
{
A casa productora se reserva a possibilidade de variar características e dados do presente manual em qualquer momento e sen aviso
p
prévio.
Λγω προγράµµατος συνεχούς βελτίωσης προϊντων, το εργοστάσιο επιφυλάσσεται του δικαιώµατος να τροποποιεί τις
k
τεχνικές λεπτοµέρειες που αναφέρονται στο εγχειρίδιο αυτ χωρίς προηγούµενη ειδοποίηση.
≤ Folyamatos gyártmány felùjítási müsorunk következtében, a gyártó cég fenntartja a jogát ebben a Használati leirt müszaki adatok elözetes
értesítés nélküli változtatására.
THIS PRODUCT MEETS THE SAFETY STANDARD REQUIREMENT OF THE EUROPEAN
MACHINERY DIRECTIVE
DISPLACEMENT (cm3)..................................................................................................
BORE AND STROKE (mm)...........................................................................................
ENGINE OUTPUT (kW).................................................................................................
ENGINE SPEED AT MAX POWER (min
MINIMUM SPEED (min
-1
)...............................................................................................
-1
) ......................................................................
DRY WEIGHT (Kg) (NO BAR AND CHAIN)....................................................................
CHAIN PITCH (9,525 mm)............................................................................................
CHAIN GAUGE (mm)....................................................................................................
BAR LENGTHS (cm).....................................................................................................
No. OF SPROCKET TEETH .........................................................................................
OIL TANK CAPACITY (cm
SPECIFICATIONS
FUEL TANK CAPACITY (cm
3
)...........................................................................................
3
) .......................................................................................
SOUND PRESSURE LEVEL (AT THE OPERATOR’S EAR). LpAav (dBA) (ISO 7182) ...
GUARANTEED SOUND POWER LEVEL LwAav (dBA) (EN ISO 9207)..........................
MEASURED SOUND POWER LEVEL LwAav (dBA)......................................................
VIBRATION LEVEL (ISO 7505) (m/s
2
) ..........................................................................
UK
70
50x36
3,24
9.000
2.500
7,3
3/8”
1,5
45/50/60/70
7
400
900
98
114
112,8
6
QUESTO PRODOTTO È CONFORME ALLA DIRETTIVA EUROPEA SULLA SICUREZZA
DELLE MACCHINE
CILINDRATA (cm3)......................................................................................................
ALESAGGIO x CORSA (mm)......................................................................................
POTENZA (kW) ..........................................................................................................
REGIME Dl MASSIMA POTENZA (min
REGIME DI MINIMO (min
-1
) .........................................................................................
-1
) ....................................................................
PESO A SECCO (Kg) (SENZA BARRA E CATENA).....................................................
PASSO CATENA (9,525 mm).....................................................................................
SPESSORE CATENA (mm) ........................................................................................
LUNGHEZZA BARRA (cm) .........................................................................................
No. DENTI DEL PIGNONE .........................................................................................
DATI TECNICI
CAPACITÀ SERBATOIO OLIO (cm
CAPACITÀ SERBATOIO MISCELA (cm
3
) ...........................................................................
3
) ....................................................................
PRESSIONE SONORA ALL’ORECCHIO DELL’OPERATORE LpAav (dBA) (ISO 7182) ..
LIVELLO POTENZA SONORA GARANTITA LwAav (dBA) (EN ISO 9207)....................
LIVELLO POTENZA SONORA MISURATA LwAav (dBA) ............................................
VIBRAZIONI (ISO 7505) (m/s
2
) ...................................................................................
CE PRODUIT EST CONFORME À LA NORME EUROPÉENNE POUR LA SÉCURITÉ DES
MACHINES
CYLINDRÉE (cm3).......................................................................................................
ALÈSAGE / COURSE (mm) ........................................................................................
PUISSANCE MOTEUR (kW) .......................................................................................
REGIME MOTEUR PUISSANCE MAX (min
REGIME DE RALENTI (min
-1
) ......................................................................................
-1
)...............................................................
POIDS A VIDE (Kg) (SANS BARRE NI CHAÎNE)..........................................................
PAS DE LA CHAÎNE (9,525 mm) ...............................................................................
JAUGE (mm) ..............................................................................................................
LONGUEUR DE GUIDE (cm) ......................................................................................
NOMBRE DES DENTS DE PIGNONS ........................................................................
CAPACITÉ DU RÉSERVOIR HUILE (cm
CAPACITÉ DU RÉSERVOIR ESSENCE (cm
3
)....................................................................
3
)..............................................................
PRESSION SONORE À L’OREILLE DE L’OPERATEUR. LpAav (dBA) (ISO7182)........
NIVEAU DE PUISSANCE SONORE GARANTI LwAav (dBA) (EN ISO 9207) ................
NIVEAU DE PUISSANCE SONORE MESURÉ LwAav (dBA) .......................................
CARACTÉRISTIQUES TECHNIQUES
VIBRATIONS (ISO 7505) (m/s
2
)...................................................................................
I
70
50x36
3,24
9.000
2.500
7,3
3/8”
1,5
45/50/60/70
7
400
900
98
114
112,8
6
F
70
50x36
3,24
9.000
2.500
7,3
3/8”
1,5
45/50/60/70
7
400
900
98
114
112,8
6
UK
ENGLISH
A
GENERAL
DESCRIPTION
1. SAFETY CHAIN BRAKE
2. STARTER HANDLE
3. THROTTLE TRIGGER
4. THROTTLE TRIGGER LOCKOUT
5. CHOKE KNOB
6. FUEL TANK CAP
7. CHAIN CATCHER
8. CHAIN BRAKE AND CLUTCH COVER
9. FRONT HANDLE
10. REAR HANDLE
11. STOP SWITCH
12. OIL TANK CAP
13. THROTTLE ADVANCE
14. BAR
15. CHAIN
16. AIR FILTER COVER
17. CARBURETTOR ADJUSTMENT SCREWS
18. BAR RETAINING NUTS
19. DECOMPRESSION VALVE
20. SPIKE
21. CHAIN ADJUSTER SCREW
B
SAFETY
PRECAUTIONS
1 All operators should read this manual carefully
before using this chainsaw.
Wear suitable clothing. This should include
snugly-fitting (safety) clothing, sturdy boots,
heavy duty gloves, goggles or a face screen
and ear plugs or ear mufflers. Wear a helmet
if there is risk of falling objects or projections
from trees.
2 Always hold the chainsaw firmly with both
hands when the engine is running. Always
maintain a firm foothold. Ensure you are able
to stop the engine quickly if necessary. Do
not work up a tree unless you have received
suitable training and have the appropriate
equipment (belts, ropes, safety hooks etc)
for this type of work. We strongly recommend
that all first-time chainsaw users obtain
practical instruction on safe chainsaw usage
before operating the chainsaw. Do not operate
this machine when tired or under the influence
of any substances, drugs or alcohol which
can impair vision, dexterity or judgement.
Prolonged use of chainsaws or other machines
exposing the operator to vibration may
produce Whitefinger’s Disease (Raynaud’s
Phenomenon). This may reduce the hands’
ability to feel and regulate temperature and
may produce general numbness. Continual
or regular users should therefore monitor
closely the condition of their hands or fingers.
If any of the symptoms appear, seek
immediate medical advice.
3 Never carry the chainsaw with the engine
running. Whenever carrying a chainsaw, even
for short distances, the chain should be
covered by the chain guard (scabbard) and
the bar should point backwards. When
transporting the chainsaw in a vehicle, secure
the saw to prevent fuel spillage.
4 To avoid kick-back, do not attempt to cut with
the nose of the bar. Ensure the engine is
running at full throttle before commencing to
cut. To avoid kick-back, do not let the nose of
the bar come into contact with logs, branches,
the ground or any other obstruction. Do not
allow any part of the chain to come into
contact with rock, nails or wire fence. Ensure
the chain is kept sharp and correctly
3
tensioned. Keep the spike or the saw body
against the wood when cutting. Use only
genuine accessories and spare parts. We
recommend you have your unit periodically
checked and serviced by an authorised
dealer. Do not use chainsaw above shoulder
height.
5 Do not operate the chainsaw near a naked
flame or spilled fuel. Only operate the
chainsaw outside and in well ventilated areas.
After re-fueling, always wipe off any spilled
fuel. Move the chainsaw away from the fueling
point before starting the engine.
6 Keep by-standers and animals out of the
work area; at a minimum distance of 10 m or
twice the timber length necessary, use
warning signs to keep on-lookers at a
distance.
Carefully survey the working site to note any
hazards, eg. roads, paths, electricity cables,
dangerous trees etc. Do not use the chainsaw
if the device stopping the chain (safety
chainbrake) does not work correctly.
Never place hands on the chain whilst the
engine is running.
Ensure someone is within hearing distance in
case of an accident. If this is not possible, it
is recommended that users operating
chainsaws in remote areas carry an adequate
first-aid kit with them and ensure someone
knows their location.
Never leave the engine running whilst the tool
is unattended.
ONLY USE ORIGINAL SPARE PARTS AND
ACCESSORIES.
Remove the clutch guard (A) and the outer bar
plate (F). Check that the oil hole (E) is free from
impurities. Fit the chain over the sprocket (H).
Ensure correct direction of cutter tooth. Put the
bar in position over studs (C) slide it towards the
sprocket. Fit the chain into the bar groove and
slide the bar forwards.
Make sure that the tang chain tensioning screw
(D) fits into the hole in the bar (E). Replace the
outer bar plate and the clutch guard. Screw the
two bar retention nuts finger tight (G). Tension
the chain by turning the adjusting screw (I)
clockwise while raising the tip of the bar. The
tension is sufficient if the chain is snug on the bar
but still moves freely around the bar when pulled
by hand. Tighten the two bar retention nuts
securely.
Always use the combination tool to install and
tension the chain.
WARNING
Mount the bumber spike as shown in illustration.
RUNNING IN A NEW CHAIN
The chain must always be cold when carrying
out adjustment.
1 Let the chain run slowly for a few minutes.
Check that the oil pump is delivering oil onto
the chain.
2 Stop the engine and adjust the chain tension.
3 Check the tension of a new chain more
frequently during initial usage and adjust as
necessary.
4 Repeat adjusting until the chain does not
stretch any more.
Never touch the chain while the engine is running.
BAR AND CHAIN
C
INSTALLATION
Ensure engine is always switched off before fitting
or adjusting chain. Wear a pair of protective gloves
when fitting or adjusting chain.
A . Clutch guard
B . Inner bar plate
C . Bar mounting bolts
D . Chain tensioning screw
E . Oil hole
F . Outer bar plate
G . Bar retention nuts
H . Sprocket
I . Adjusting screw
4
FUEL MIX
D
Use only fuel recommended by this manual. This
product is fitted with a 2-stroke engine and
therefore requires a 2-stroke petrol and oil mix.
Use leaded or unleaded petrol with a minimum
octane rating of 90. When using leaded petrol,
use 2.5% (40:1) of McCulloch oil, otherwise use
5% (20:1) of a high quality 2-stroke engine oil
(from a recognised brand). When using unleaded
petrol, use 2.5% (40:1) of McCulloch oil or use
2.5% (40:1) of a high quality synthetic 2-stroke
engine oil..
Only use oil from sealed containers. In order to
obtain a good fuel mix, put the oil into the
container before the petrol.
UK
IMPORTANT
Always shake this fuel mix vigorously each time
you use it. Fuel mix properties deteriorate with
time, we therefore recommend that you only
make the quantity of fuel mix you will need for
each usage. Do not use fuel mix more than a week
old as this could damage the engine.
WARNING
Do not smoke when re-fuelling. Always open the
fuel cap slowly. Re-fuel in open spaces only,
keeping away from naked flames or sparks.
Always store fuel in an approved container.
SAFE STORAGE OF FUEL
Petrol is highly inflammable. Put out all cigarettes,
pipes and cigars before working with petrol.
Avoid spilling petrol. Store fuel in a cool, well
ventilated place, in an approved container
specifically designed for the purpose. Never
store engine with fuel in the tank in enclosed,
poorly ventilated areas, where fuel fumes may
reach an open flame, spark or pilot light such as
in a furnace, water heater, clothes dryer etc.
Petrol fumes can cause an explosion or a fire. Do
not store large amounts of fuel. To prevent
possible restarting problems avoid running the
fuel tank dry. This also helps to extend engine
life.
CHAIN LUBRICATION
IMPORTANT The service life of the bar and chain
depends on good lubrication.
Always use chain lubricating oil of medium
viscosity. We recommend special McCulloch
chain lubricating oil. Never use waste oil for this
purpose. This results in damage to the bar, the
chain and the oil pump. Refill the chain oil tank
each time the saw is refuelled.
NOTE: Saw chain stretches during use, particularty
when it is new, and it will occasionally be necessary
to adjust and tighten it. A new chain will require
adjustment after about 5 minutes of operation.
• The mechanical oil pump for chain lubrication
can be adjusted.
The feed rate of the chain oil pump can be
adjusted by means of the regulating screw (A)
(see details in the illustration). The oil feed rate is
increased by turning the regulating bolt
counterclockwise
IMPORTANT - The chain oil feed is reduced to a
minimum when the regulating bolt
closed (turning clockwise) .
.
ENGLISH
is completely
STARTING AND
E
STOPPING
IMPORTANT - Never start or operate the saw
unless bar and chain are properly installed.
Before starting always move the saw away from
the fuelling area and place it on firm, flat
surface, the guide bar to the front.
STARTING A COLD ENGINE
Check that the chain brake is in the disengaged
position moving the lever (L) backwards (towards
the front handle). Check that the ignition switch is
not in the “STOP” position.
Depress thrtottle trigger lockout (A). Depress
throttle trigger (B) and then pull up the throttle
lock (C).
Release first the throttle trigger (B) and then the
throttle lock (C).
In this way the throttle lock engages and your left
hand is free to grip the saw firmly.
Pull out the choke control (E). Activate the
decompression pressing the valve (D). Hold the
saw firmly as shown in illustration and pull the
starter rope until the engine fires once.
Push in the choke control (E). Re-activate the
decompression system by depressing valve (D).
Pull the starter rope until the engine starts.
Allow engine to warm up for a few seconds,
holding the saw firmly.
Beware of moving chain.
Release the safety lock by pressing the throttle
trigger (B).
STOP. The engine is stopped by moving the
ignition switch to STOP position.
IMPORTANT. After lengthy use of the chain saw at
full speed, we recommend to run the engine for a
few seconds at idle speed before stopping it.
STARTING A WARM ENGINE
Check that the ignition switch is not in the “stop”
position and do not use the throttle lock.
Hold the saw firmly, press valve (D) for
decompression and pull the starter rope.
STARTING A WARM ENGINE AFTER FUELLING
In the fuel tank as run completely dry, procede to
start as with a cold engine.
5
F
USAGE
IMPORTANT. Before using a chain saw read
carefully the Operator’s Manual and all safety
precautions carefully.
FELLING TREES.
- Make sure that there are no bystanders or
animals in the work area.
- Study the direction of the fall of the tree and
then plan your exit path away from the planned
direction of fall.
- Don’t fell trees when there is a strong wind.
1 Clear the tree base of interfering limbs and
brush. Clean the work area from stones or
other objects which could damage the chain.
If the tree has large protruding roots, remove
them before felling (see illustrations).
2A) Cut a felling notch (A) of 45°on the side
you want the tree to fall to a depth of about one
third of the trunk diameter (d).
Then make a felling cut (B) about 5 cm higher
than the felling notch on the opposite side of
the tree. Make sure that the felling cut does not
go right through the trunk. A hinge (C) must
always be left to provide control over the
direction of the fall.
B) Use wedges to control the moment and
direction of the fall.
3 When the tree starts to fall, walk away along
your preplanned escape path.
CUTTING FALLEN TRUNKS.
4A) Limbing thick branches. For limbing and
bucking leave the lower limbs to support
the log off the ground.
B) Supported at one end only. Begin with a
bottom cut made by the upper side of the bar
(A); the depth of the cut should be about one
third of the log diameter (A). Finish with a top
cut (B) meeting the first one. With this technique
splitting, cracking can be avoided.
C) Supported at both ends. Begin with a top
cut about one third of the log diameter. Then
finish with a bottom cut (B) meeting the first
one. This technique avoids the risk of pinching
the bar in the log.
D) If the log is supported along its whole
length it may be cut normally from above. Take
care not to touch the ground with the chain.
• When working on a slope always stand on the
uphill.
• When cutting prepared timber, use clamps or
chocks to secure work.
• Use extreme caution when cutting small size
brush and saplings which may catch the chain
and pull you off balance.
CARBURETTOR
G
ADJUSTMENT
N.B. We suggest carburetor adjustments are
made by an authorized service dealer.
The carburetor has three adjustment
possibilities:
• L: The needle screw (L) governs the fuel flow
at low speed and also the acceleration from
low to full speed.
To set screw (L): close screw (L) turning it
clockwise without forcing
1 full turn
If acceleration is not smooth, open
1/8 turn to increase fuel flow.
• H: The needle screw (H) governs fuel flow at
high speed (throttle valve fully open).
To set hi speed screw (H): close screw (H)
turning it clockwise
Then open screw 1-1/2 full
clockwise) .
If the engine speed is too high (the maximum
speed with bar and chain on should not
exceed 11.500 min
about 1/8 turn (counterclockwise).
• I: The (I IDLE) screw controls the throttle
opening to govern idle speed (2.500 min
CAUTION: increased idle speed may cause
chain movement. The carburator is adjusted
for normal operation during production. Wen
considerable changes of altitude require a
supplementary adjustment, contact an
authorised service station which offers the
latest in tools, parts and technical assistance.
H
(counterclockwise).
ROUTINE
. Then open screw
another
without forcing .
-1
), open the screw
turn (counter-
-1
).
MAINTENANCE
Ensure engine is always switched off before any
kind of maintenance operation.
6
UK
ENGLISH
CHAIN: Check tension regularly. A new chain
will require more frequent adjustment. Loosen
retention nuts. adjust chain (see assembly
instructions). Tighten retention nuts.
1 BAR
- Clean the bar groove (K) and check the
lubrication holes (L) in the bar to ensure that
they are not clogged.
- Grease sprocket periodically. Rotate sprocket
and repeat.
- Rotate bar periodically to maximise bar life.
2 AIR FILTER
- A dust clogged air filter may cause carburetor
problems. This may prevent the engine from
reaching its maximum r.p.m. and cause high
fuel consumption.
- Remove cover.
- Wash filter in petrol (do not use fuel which is
mixed with oil).
- The filter can also be cleaned with compressed
air.
- Replace filter if damaged or if it does not seal
tightly in the air box.
3 SPARK PLUG
Remove and clean the spark plug every 30
hours. Check the electrode gap (0,5/0,6 mm).
- Replace spark plug about every 100 working
hours or whenever it is extremely encrusted.
- Heavily encrusted electrodes can result from
an incorrect carburetor setting or from wrong
fuel mixture (too much oil in the fuel mix) or a
poor quality of oil in the fuel mix. Check and
correct.
4 OIL FILTER
The oil filter is end of the oil suction hose inside
the oil tank .To clean and replace the filter pull
it out through the oil tank filter opening. Use a
piece of bent wire or long forceps. To remove
deposits from the oil tank half fill it with kerosene
or petrol and shake thoroughly. Drain off and
fill the tank with fresh saw chain oil. Never use
waste oil.
5 FUEL FILTER
To change fuel filter remove the tank cap and
pull out the filter with a piece of bent wire
or long forceps. Replace the filter as shown in
the illustration and reposition it.
It is recommended to replace the fuel filter at
least once a year.
CHAIN BRAKE
WARNING: Contact your service dealer if
anything appears wrong with your chain brake.
Do not disassemble or manipulate the
mechanism of the chain brake.
- Clean the brake mechanism periodically
(without disassembling it) and control the wear
of the band visually.
• PERIODICALLY: It is important to clean the saw
thoroughly particularly around cylinder fins to
avoid overheating of the engine.
• LONG STORAGE: Empty fuel and run engine
until dry.
CHAIN BRAKE
I
TESTING
Your chainsaw is fitted with an automatic safety
chainbrake designed to stop the chain in milliseconds
in case of kickback. Always hold the saw firmly in
both hands.
The chain brake does not provide total protection
if the machine is used without taking the necessary
precautions or carrying out proper maintenance.
The chain brake can also be engaged manually by
pushing the chain brake lever forwards.The manual
use of the chain brake is recommended only at
idle.
Always test the chain brake before using your
saw. Do this at idle by engaging the brake (see
below).
Always release the brake before starting.
Kickback may occur if the end of the bar (see
illustrated angle) touches any solid object or if the
top of the bar becomes pinched in the wood.
Never attempt to start a cut with the end of the
bar.
Kickback is a violent upward or rearward
movement of the bar and may cause you to lose
control of the machine.
Always keep a firm grip on the saw with both
hands because,in case of kickback, it is the
contact of the left hand with the brake lever which
will help to engage the brake.
CAUTION: Initial contact with the wood may
occasionally cause the chain to buck, and if the
chain teeth are not correctly sharpened, the chain
may skate on the wood.
TESTING THE CHAIN BRAKE :
1 The chain brake is disengaged when brake
lever is pulled back and locked (chain can
move).
2 The chain brake is engaged when brake lever
is in forward position (chain is stopped).
7
The chain brake should snap into both
positions.If strong resistance is felt or lever
does not move into either position, DO NOT
USE YOUR SAW.
Take it immediately to an authorized servicing
dealer.
3 CHAIN CATCHER
This unit is fitted with a chain catcher below the
drive spocket. This is intended to stop the
rearward movement of th chain in case of
breakage or if it should come out of the bar, It
should never be removed.
L
CHAIN SHARPENING
1 The cutter teeth should be sharpened with a
round 7/32" file.
The job can be made easier by also using a file
holder.
The chain can remain fitted on the bar during
sharpening.
Before commencing, the chain should be
tensioned correctly and the chain brake should
be activated to prevent the chain from moving.
2 To obtain a correct sharpening the file must be
carefully held to maintain 3 basic angles:
FAULT FINDING TABLE
Engine runs badly
or looses power
when cutting
Check STOP switch is in the position I
– A Top angle 30 ° - 35 °
– B External,side angle 85 ° - 90 °
– C Internal, side angle 60 °.
File in one direction only, from the “inside” of
the cutter tooth towards the “outside”.
Do not allow the file to touch the chain as you
bring it back to re-position it. Each cutter tooth
should be filed with the same number of strokes.
3 The file should be held horizontally to the cutter
tooth being sharpened.
4 Best results to obtain a precise sideways
angle can be obtained by holding the file so
that it rises 0,5 mm above the top face of the
cutter tooth.
5 DEPTH GAUGE
Correct depth gauge height is vital to ensure
maximum chain life and cutting efficiency.
The height of the depth gauge should be
lowered as the cutter tooth is filed back; this
height should be checked every 4 or 5
sharpenings.
The best way to do this is to use a flat file and
a depth gauge tool.
The correct setting is 0.65 mm below the top
edge of the cutter tooth.
The cutter tooth depth gauge should then be
rounded (D).
Engine will not start
The machineruns
butdoes not cut
well
Control fuel level min. 25% tank capacity
Check air filter is clean
Remove spark plug ,dry it, clean it and
adjust it, and replace it, if necessary
Control and adjust the carburetor screws if
necessary
Change fuel filter. Contact your dealer
Carefully follow the cutting accessory
assembly instructions
Check metal cutting accessory is sharp
Otherwise, contact your dealer
Engine still gives trouble: contact your dealer.
8
000001➔ 99999
A EC Declaration of conformity
In accordance with the EC Machine Directive (89/392/EEC, modified by 91/368/EWG),
tromagnetic compatibility).
saw: PRO MAC 72 serial number as above, with chain bar of cutting length 45/50/60/70 cm, manufactured by E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia,
conform to the machine that was the object of the EC type testing in accordance with Annex VI of the Machine Directive.
The EC type examination was conducted by Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), EC type examination certificate no. IMQ AS 068 DM.
This type testing established that the machine conforms to the essential health and safety requirements of the EC Machinery Directive.
Directive 2000/14/CEE (Annex V). The undersigned, Pino Todero, authorised by E.O.P.I., declares that the petrol-driven chain-
C EU-Erklärung der Übereinstimmung
Nach den Europäischen Richtlinien 98/37/CEE (Maschinenrichtlinie), 73/23/EEC (Niederspannungsdirektive), 93/68/CEE (CE Kennzeichnungsrichtlinie) & 89/336/CEE
(EMV Richtlinie) entspricht. Richtlinie 2000/14/CEE (Anhang V)
Der Unterzeichnete Pino Todero, bevollmächtigt durch E.O.P.I., erklärt daß die Kettensägen mit Benzinmotor: PRO MAC 72 Seriennummer wie oben angegeben,
Kettenstange mit Schneidlänge von 45/50/60/70 cm, hergestellt durch E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, der Maschine entsprechen, die Gegenstand
der EG-Typenprüfung gemäß Anhang VI der Maschinendirektive war.
Die EG-Typenkontrolle wurde durchgeführt von Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), Bescheinigung der EG-Typenkontrolle Nr. IMQ
AS 068 DM.
Diese Typenprüfung hat ergeben, daß die Maschine den grundlegenden Gesundheits - und Sicherheitsbestimmungen der EG-Maschinendirektive entspricht.
E Declaracion de cumplimiento de la directriz de la UE
En cumplimiento con la Directiva sobre Maquinaria de la UE (89/392/EEC, enmendada según 91/368/EEC),
& 89/336/EEC (Directiva sobre ‘Compatibilidad Electro Magnética’). Directiva 2000/14/CEE (Anexo V).
El abajo firmante Pino Todero, autorizado por E.O.P.I., declara que las motosierras de gasolina: PRO MAC 72 con número de serie indicado anteriormente con barra
portacadena de longitud de corte de 45/50/60/70 cm, fabricadas por E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, cumplen con las especificaciones de la
máquina objeto de la prueba de la UE conforme al Anexo VI de la Directiva sobre Maquinaria.
La prueba realizada por la UE se llevó a cabo en Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), certificado de tipo de prueba de la UE No.
IMQ AS 068 DM.
Esta clase de prueba establece que la máquina cumple con las normativas imprescindibles sobre sanidad y seguridad de la Directriz de la UE sobre
Maquinaria.
B Déclaration de conformité Européenne
En accord avec la directive européenne (89/392/EEC, modifiée par 91/368/EWG),
2000/14/CEE (Annexe V).
Le soussigné Pino Todero, dûment mandaté par E.O.P.I., déclare que, les tronçonneuses thermiques: PRO MAC 72 dont le numéro de série est cité ci-dessus équipées
d’un guide chaîne de 45/50/60/70 cm de longueur, fabriquées par E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, sont identiques à la machine soumise aux
tests européens en accord avec l’annexe VI de la directive ci-dessus.
Les tests ont été effectués par Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), certificat de tests européens numéro IMQ AS 068 DM.
Ces tests ont établi que la machìne est conforme aux recommandations d’hygiène et de sécurité de la directive européenne
ci-dessus.
G Declaração de conformidade da CE
De acordo com a Directive de Máquinas (89/392/EEC, alterada pela 91/368/CEE),
Compatibilidade Electromagnética). Directiva 2000/14/CEE (Apêndice V).
O abaixo assinado Pino Todero, autorizado por E.O.P.I., declara que: as serras mecänícas a gasolina: PRO MAC 72 com número de série acima indicado com uma
barra de corrente com o comprimento de corte de 45/50/60/70 cm, fabricada por E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, estäo em conformidade com
a máquina que foi submetida ao ensaio tipo da CE de acordo com o Anexo VI da Directiva de Máquinas. A inspecção tipo da CE foi efectuada por Marchio di
Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), No. de certificado de inspecção tipo da CE IMQ AS 068 DM.
Este ensaio tipo constata que a máquina esta em conformidade com os requisitos mínimos de Saude e Segurança de Directiva de Máquinas da CE.
D Dichiarazione di conformità CE
In accordo con la Direttiva Macchine CE (89/392/EEC, modificata dalla 91/368/EEC),
Compatibilità Eletrtromagnetica). Direttiva 2000/14/CEE (Allegato V).
na portatile da legno modello: PRO MAC 72 numero di serie come sopra riportato, con barra guida catena con lunghezza di taglio da 45/50/60/70 cm, costruita da
E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, è conforme al modello di macchina che è stato sottoposto all’esame per la certificazione CE in accordo con l’allegato VI della Direttiva Macchine.
L’esame per la certificazione CE è stato condotto dall’Istituto del Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), autorizzato dalla Repubblica
Italiana con Decreto Ministeriale del 23/12/1993. Attestato di certificazione CE no. IMQ AS 068 DM.
Questo esame ha stabilito che la macchina è conforme ai requisiti essenziali di salute e di sicurezza della Direttiva Macchine CE.
/ EU julistus vastaavuudesta
Yhteneväinen EU’n koneista annetun määräyksen (89/392/EEC, 91/368/CEE n muuttama),
Direktiivi 2000/14/CEE (Liite V).
Allerkirjoittanut Pino Todero, E.O.P.I., in valtuuttama, vakuuttaa että bensiinimoottorisahat: PRO MAC 72 yllä merkityllä sarjanumerolla, 45/50/60/70 cm:n ketjulevyllä,
E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, valmistama, mukautuu koneeseen, joka oli EY tyyppitestin objekti koneohjeellisen Annex VI mukainen.
EY tyypitarkastus oli Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), johtama, EY tyyppitarkastustodistus
no. IMQ AS 068 DM.
Tämä tyyppitesti vahvisti, että kone mukautuu EY koneohjeellisen välttämättömiin terveys-ja turvallisuusmääräyksììn.
; EU Konformitetsdirektiv
I følge EU Maskindirektiv (89/392/EEC, endret av 91/368/EWG),
patibilitet). Direktiv 2000/14/CEE (Annex V).
Undertegnede Pino Todero, autorisert av E.O.P.I., erklærer at bensindrevne kjedesager: PRO MAC 72 med serienummer som vist oventor, med et kjedesverd med
skjærelengde 45/50/60/70 cm, produsert av E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, er i samsvar med den maskinen som var gjenstand for EU typeprøvning i følge Vedlegg VI til Maskindirektivet.EU typeundersøkelsen ble utført av Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), EU
Typeundersøkelsessertifikat nr. IMQ AS 068 DM.
Denne typeprøvningen fastslo at maskinen tilfredstiller de nødvendige helse- og sikkerhetskravene i EU Maskindirektiv.
93/68/CEE (CE-merkingsdirektiv) & 89/336/CEE (Direktiv om elektromagnetisk kom-
93/68/EEC (CE Marking Directive) & 89/336/EEC (Directive on elec-
93/68/EEC (Directiva sobre Marcas de la CE)
93/68/CEE (Directive Marquage CE) & 89/336/CEE (Directive EMC). Directive
93/68/CEE (Directiva de Marcação CE) e 89/336/CEE (Directiva de
93/68/EEC (Direttiva Marcatura CEE) & 89/336/EEC (Direttiva
Il sottoscritto Pino Todero, autorizzato dalla E.O.P.I., dichiara che la sega a cate-
93/68/CEE (CE mærkningsdirektiv) & 89/336/CEE (EMC-direktiv).
000001➔ 99999
L Intyg angående överenstämmelse med EG
I enlighet med EGs Maskindirektiv (89/392/EEC, modifierat i 91/368/EEC),
tet). Direktiv 2000/14/CEE (Annex V).
Undertecknad Pino Todero, auktoriserad av E.O.P.I., intygar att bensindrivna kedjesågar: PRO MAC 72 med 45/50/60/70 cm långt svärd, vars serienummer visas
ovan, tillverkade av E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, överenstämmer med den maskin som var föremål för EG-provning i enlighet med Annex
VI av Maskindirektivet.
EG-provet utfördes av Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), EG-provets certifikatsnummer IMQ AS 068 DM.
Denna provningsmetod fastställer att maskìnen överenstämmer med de väsentliga hälso- och säkerhetsföreskrifterna i EGs Maskindirektiv.
: EF Konformitetserklæring
I overensstemmelse med EF Maskindirektivet (89/392/EEC, ændret ved 91/368/EWG), 93/68/EEC (CE mærkningsdirektiv) & 89/336/EEC (EMC-direktiv).
2000/14/CEE (Annex V).
Undertegnede Pino Todero, bemyndiget af E.O.P.I., erklærer at benzindrevne kædesave: PRO MAC 72 serienummer som angivet ovenor, med 45/50/60/70 cm lang
kædestang, fremstillet af E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, er i overensstemmelse med den maskine, som var genstand for EF-typeafprøvning ifølge Tillæg VI af Maskindirektivet.
EF-typeundersøgelsen blev gennemført af Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), EF-typeundersøgelsescertifikatnummer IMQ AS 068 DM.
Denne typeafprøvning fastslog, at maskinen er i overensstemmelse med de grundlæggende krav af sikkerhed og sundhed ifølge EF Maskindirektivet.
F EC Verklaring van Overeenstemming
In overeenstemming met de EC Machine Richtlijn (89/392/EEC,anngepast met 91/368/EEC),
aangaande elektromagnetische compatibiliteit). Richtlijn 2000/14/CEE (Annex V).
Ondergetekende Pino Todero, gemachtigd door E.O.P.I., verklaart dat de benzine aangedreven kettingzaag: PRO MAC 72 met bovenstaand serienummer met zwaard
lengte van 45/50/60/70 cm, geproduceerd door E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, overeenstemt met de machine die gebruikt is voor het EC type
onderzoek volgens de Annex VI van de Machine Richtlijn.
Het EC type onderzoek is uitgevoerd door Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), EC type onderzoek certificaat nr. IMQ AS 068 DM.
it typeonderzoek toont aan dat de machine overeenstemt met de fundamentele eisen van veiligheid en gezondheid volgens de Machine Richtlijn.
@ ∆ήλωση Συµµορφωσης της EK
Σύµφωνα µε την περί Mηχανών Eντολή της EK (89/392/EEC οπως τροποποιηθηκε απο την 91/368/EEC), 93/68/EEC (η περί του Σήµατος CE Eντολή) &
89/336/EEC (η περί Hλεκτροµαγνητικης Συµβαττητας Eντολή). Kαvovιδµς 2000/14/CEE (V).
O υποφαινοµενος Pino Todero, µε εξουσιοδοτηση της E.O.P.I., δηλωνω τι: τα βενζινοκίνητα αλυσοπρίονα: PRO MAC 72 µε αλνσιδωτη λαµα µηκονς
κοπης 45/50/60/70 εκ., κατασκευασθεντα απo την E.O.P.I., Via Como 72, 23868 Valmadrera (LC), Italia, ανταποκρίνονται προς τη µηχανή που υπηρξε
αντικειµενο εξετασης τυπου της EK συµφωνα µε το Παραρτηµα VI της περι Mηχανων Eντολης.
H εξεταση τυπου της EK εγινε απο Marchio di Qualità (IMQ), Via Quintiliano 43, 20138 Milano (Italia), (διευθυνση), εγγεγραµµενο πρακτορείο του
Γαλλικου ∆ικαιου (Πιστοποιητικο εξετασης τυπου υπ αρ IMQ AS 068 DM.
Mε την εξεταση τυπου διαπιστώθηκε οτι η µηχανη συµµορφωνεται προς τις στοιχειωδεις απαιτήσεις υγειας και ασφάλειας της περί Mηχανων
Eντολης της EK.
≤ EC Megegyezési nyilatkozat
Az EC Gépek direktiva (89/92/EWG, módosított a 91/368/EWG által), 93/68/EEC & 89/336/EEC szerint. Direktiva 2000/14/CEE (Melléklet V).
Az alulírott, Pino Todero, a E.O.P.I. feljogosításával, kijelentem hogy a benzinmotoros láncfűrész: PRO MAC 72 gyártási sorszám a fentiek szerint, egy 45/50/60/70 cm vágó hosszal rendelkező vezetőlappal, gyártott a E.O.P.I. Via Como 72, 23868 Valmadrera (LC), Olaszország által, megegyezik avval a géppel amelyik tárgya volt az EC típusvizsgálatnak a Gépek direktiva VI Mellékletének megfelelően.
Az EC típusvizsgálat vezetve volt a Marchio di Qualita (IMQ)-nál, Via Quintiliano 43, 20138 Milano, Olaszország, EC típusvizsgálat bizonyítvány szám IMQ AS 068 DM.
Ez a típusvizsgálat megállapította azt, hogy a gép megfelel az EC Gép Direktiva alapvető egészségi és biztonsági követelményeinek.
93/68/CEE (CE märkningsdirektiv) & 89/336/CEE (Elektromagnetisk kompatibili-
Direktiv
93/68/EEC (EG Markering Richtlijn) & 89/336/EEC (Richtlijn
Valmadrera, 01.10.01
Pino Todero (Direttore Tecnico), E.O.P.I., 23868 Valmadrera (LC), Via Como 72, Italy
Electrolux Outdoor Products
McCulloch Italiana s.r.l. - Via Como 72, 23868 Valmadrera (LECCO) - ITALIA
Tel: 800 017829, Fax: 0341 581671
Our policy of continuous improvement means that the specification of products may be altered from time to time
without prior notice.
Electrolux Outdoor Products manufacture products for a number of well known brands under various registered
patents,designs and trademarks in several countries.
© Electrolux Outdoor Products
The Electrolux Group. The world’s No. 1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use.
More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners,
chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries
around the world.
P/N. 247768 (09.02)
Loading...
