Axiom DirectLink for Logic Pro
User Guide
Legal Notices
This guide is copyrighted ©2010 by Avid Technology, Inc., with all rights
reserved. Under copyright laws, this guide may not be duplicated in whole or in
part without the written consent of Avid Technology, Inc.
Avid, Axiom, DirectLink and M-Audio are either trademarks or registered
trademarks of Avid Technology, Inc. All other trademarks contained herein are
the property of their respective owners.
Product features, specifications, system requirements, and availability are
subject to change without notice.
Guide Part Number 9329-65025-00 REV A 6/10
Documentation Feedback
We are always looking for ways to improve our documentation. If you have
comments, corrections, or suggestions regarding our documentation, email us
at techpubs@avid.com.
Contents
Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
DirectLink Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 2. Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 3. Axiom Controls with DirectLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 4. Instrument Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting Up Instrument Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using Instrument Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Appendix A. DirectLink Control Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Contents3
Chapter 1: Introduction
This guide covers DirectLink, which automatically maps Axiom® controls to common functions in Logic Pro
9.1 and later
eration with a level of integration that makes Axiom feel like a “dedicated” hardware controller.
Once Logic Pro has been launched, DirectLink is activated in its default state which is Mixer Mode. In Mixer
Mode, Axiom faders, buttons and knobs are mapped to Logic Pro mixer functions such as track and master
channel volume, as well as the pan, track selection, mute, solo, and record arm, as explained in Chapter 3,
“Axiom Controls with DirectLink.”
Although Mixer mode provides effective control of the Logic Pro Mixer, Axiom DirectLink also gives you
hands on control over any virtual instrument in your project. The first step towards controlling virtual instruments within your project is selecting a “target” track using the dedicated Track “<“ and “>” buttons.
The target track determines which track Axiom will control. If there is a virtual instrument in the target track,
pressing the Instrument button (Inst) instantly maps all Axiom controls to the most useful parameters. Each
Logic instrument has a corresponding Axiom Instrument Map. Axiom Instrument Maps are available for
download and installation at www.m-audio.com/drivers. Further information about Axiom Instrument Maps
can be found in Chapter 4, “Instrument Mode.”
. DirectLink offers two-way communication with Logic Pro, featuring two distinct modes of op-
Whenever DirectLink is switched to Instrument mode, the Instrument button will also illuminate to confirm
that you are controlling an instrument. Pressing the Patch Up and Down buttons scrolls through patches to
audition and select sounds in the targeted instrument. Pressing either of the Track buttons targets an adjacent
track, allowing you to switch from one instrument to another.
Pressing the Instrument button a second time returns Axiom to Mixer mode. While in Instrument Mode,
holding the Shift button and pressing the Instrument button opens the virtual instrument window. This lets
you to see the on-screen controls update in real time as mapped Axiom controls are used. Holding down the
Shift button then pressing Instrument button again, closes instrument windows.
Instrument Mode has no affect on the Axiom Transport buttons, and they will remain mapped to their counterparts in Logic Pro.
Although this introduction explains how DirectLink with Axiom can enhance your workflow, please take the
time to read the rest of this User Guide. Combined with the Axiom User Guide, it will explain how to get the
most out of your Axiom Keyboard in Logic Pro.
Axiom DirectLink for Logic Pro User Guide
4
Chapter 1: Introduction
DirectLink Requirements
System Requirements
The latest system requirements can be found at www.m-audio.com.
Logic Pro Software
DirectLink requires Logic Pro version 9.1 or later. Earlier versions of Logic Pro do not support DirectLink. To
learn more about upgrading your Logic Pro software, please visit http://www.apple.com.
Axiom Hardware
DirectLink requires that Axiom is connected to the host computer, and this guide assumes the process has already been completed. The installation and connection procedure, is covered in the Axiom User Guide.
A list of qualified recording applications, along with current drivers, DirectLink installers and User Guides
can be found at www.m-audio.com.
Axiom DirectLink for Logic Pro User Guide
5
Chapter 1: Introduction
Chapter 2: Installation and Configuration
Before beginning the DirectLink installation, please make sure Axiom is connected to the host computer, and
that Logic Pro is not running. The instructions below will indicate when Logic Pro should be launched.
To install DirectLink and configure Logic Pro:
1 Download the latest DirectLink installer for Logic Pro from www.m-audio.com/drivers.
2 Locate and double-click on the installer icon then follow the on-screen instructions.
3 Once the installation is complete, launch Logic Pro.
4 Navigate to the Logic Pro menu > Preferences > Control Surfaces > Setup.
5 Choose “New” and double-click “Axiom” (for Axiom 49 or 61) or “Axiom 25” as appropriate.
6 Close the Control Surfaces window.
7 Axiom will be in DirectLink Mode and ready to control Logic Pro.
Whenever Logic Pro is launched, DirectLink will activate automatically and map Axiom controls.
Axiom DirectLink for Logic Pro User Guide
6
Chapter 2: Installation and Configuration
Chapter 3: Axiom Controls with DirectLink
4 763
EF
E1
E2
1
2
E5
204
F9F8F7F6F5F4F3F2F1
Patch
12
F18F17F16F15F14F12F11F10 F13
Recall Ctrl Mute Panic
Shift
Vel Lo ck
Tra c k
Bank
Mute
SoloBank
Solo
E9 E10 E11 E12 E13 E14
E3
E6 E7
E4
E8
5
11
10 9
8
This chapter provides an overview of how Axiom controls function when controlling qualified versions of
Logic Pro via DirectLink. Where applicable, both Mixer and Instrument Mode will be covered.
1 Shift Button
This button is used to access alternate functions of the Faders, Encoder knobs and Instrument button, as
well as the Mute and Track (< and >) buttons, as described later in this chapter.
2 Instrument Button (Inst)
DirectLink offers two different modes of operation as described below.
Mixer Mode
This is the default DirectLink mode, in which Axiom Faders, Encoder knobs, and Fader buttons are
mapped to their corresponding Logic Pro mixer functions.
When a mapped Axiom control is used, its parameter assignment and numerical or positional value will
appear on the LCD screen. After one second the screen will revert to the track name.
Pressing the Instrument button at any time switches Axiom controls to Instrument Mode.
Instrument Mode
Pressing the Instrument button (Inst) selects Instrument Mode. The LCD screen will momentarily display
the name of the instrument being controlled, and then revert to the target track name. This maps Axiom
Faders, Fader buttons, and Encoder knobs to instrument parameters within the target track in your Logic
Pro project.
The target track determines the destination of MIDI notes and control data transmitted from your Axiom
keyboard.
When a mapped Axiom control is used, its parameter assignment and numerical or positional value will
appear on the LCD screen. After one second the screen will revert to the track name.
Axiom DirectLink for Logic Pro User Guide
7
Chapter 3: Axiom Controls with DirectLink
Pressing the Instrument button again will return Axiom to Mixer Mode. While in Instrument Mode, holding down the Shift button and pressing the Instrument button will open and close the active instrument
window.
Axiom Transport, Shift, Track select and Mute/Solo buttons are not affected by the Instrument button,
and retain their assignments in both Mixer and Instrument Mode.
3 Group F Button
The Group F button is illuminated by default, indicating that all nine Axiom faders and fader buttons
(F 1–1 8) are in DirectLink mode. When this button is presse d, it is no longer lit, and the f aders and buttons
are released from their DirectLink assignments, and mapped according to the active Patch.
Pressing the Group F button again returns all controls to their DirectLink assignments. The button also illuminates confirming the group is in DirectLink Mode.
4Faders
Mixer Mode (Default)
On Axiom 49 and 61, the first eight Faders (F1 – F8) control the track volume for the
currently selected bank of eight tracks. The active bank (for example 1 – 8) is highlighted along the left edge of the Logic Pro mixer, as shown in the illustration.
The right-most Fader (F9) and the single Fader on Axiom 25 will map to the Master
Fader of the Logic Pro project.
When an Axiom fader is moved, the current function or parameter assignment, and
its value will appear on the LCD screen.
Instrument Mode
The faders map to parameters on the virtual instrument within the target track.
When an Axiom fader is moved, the current function or parameter assignment, and
its value will appear on the LCD screen.
Moving an Axiom Fader while holding down the Shift button allows you to view or
“peek” at its current parameter assignment and value.
5 Fader Buttons
Mixer Mode (Default)
On Axiom 49 and 61, the first eight buttons (F10 – F17) map to the currently selected bank of eight tracks
in Logic Pro, and by default each button targets its corresponding track when pressed.
Pressing the right-most button (F18) switches buttons F10 – F17 to Mute mode. The LCD screen will display “Mute,” indicating the current mode of operation. Each button illuminates when pressed, and its corresponding track is muted.
Pressing button F18 again switches buttons F10 – F17 to Solo mode, and the LCD screen will display
“Solo.” Each button illuminates when pressed, and its corresponding track is soloed while all others are
muted.
Pressing F18 another time switches buttons F10 – F17 to Record Arm mode, and the LCD screen will display “Arm.” Each button illuminates when pressed, and its corresponding track is armed for recording.
Axiom DirectLink for Logic Pro User Guide
8
Chapter 3: Axiom Controls with DirectLink
Instrument Mode
Buttons F10 – F17 map to virtual instrument parameters within the target track.
When a mapped Axiom button is pressed, the current function or parameter assignment, and its value will
appear on the LCD screen.
Fader button F18 will be lit while DirectLink is in Instrument mode. Pressing this button “flips” the faders
and fader buttons back to Mixer mode, while the Encoders remain in Instrument mode. Pressing F18 a second time returns the faders and buttons to Instrument mode.
6 Group E Button
The Group E button is illuminated by default, indicating that all eight Axiom Encoder knobs (E1–E8) are
in DirectLink mode. When this button is pressed, it is no longer lit, and the knobs are released from their
DirectLink assignments, and mapped according to the current active preset Patch.
Pressing the Group E button again returns all controls to their DirectLink assignments. The button also illuminates confirming the group is in DirectLink Mode.
Pressing the Group E button does not release the Axiom Transport buttons from DirectLink.
7 Encoder Knobs
Mixer Mode
On Axiom 49 and 61, the Encoder knobs (E1 – E8) control the Pan knobs in the Logic Pro Mixer.
On Axiom 25 these knobs control the track volume for the currently selected bank of eight tracks.
The LCD screen will display the current track name and Pan value whenever a knob is moved.
Instrument Mode
The Encoder knobs map to parameters on the virtual instrument within the target track.
The LCD screen will display the current function or parameter assignment, as well as the current value
whenever a knob is moved.
Moving a control while holding down the Shift button allows you to view or “peek” at its current assignment and value.
Axiom DirectLink for Logic Pro User Guide
9
Chapter 3: Axiom Controls with DirectLink
8Transport Buttons
In both Mixer and Instrument Modes, these buttons map to their corresponding buttons in Logic Pro and
control the functions described below.
Rewind - Holding this button rewinds the Logic Pro transport until the button is
released. Momentarily pressing this button rewinds the transport one bar at a
time.
Fast Forward - Holding this button forwards the Logic Pro transport until the button is released. Momentarily pressing this button forwards the transport one bar at
a time.
Stop - This button stops playback or recording. Pressing this button twice skips to
the beginning of the song, or the beginning of a looped section when Logic is set
to play or record in Cycle mode (See “Loop Play” button below).
Play - This button starts playback or recording.
Record - This button controls the Record button in the Logic transport.
Loop Play - Pressing the Loop button switches the transport Cycle function on and
off. This function lets you either playback the song or record multiple takes between the Loop Start and End points specified in the Logic Pro transport.
9 Mute Button
In both Mixer and Instrument mode the Mute button performs the following functions:
• By default, pressing this button mutes the target track in a Logic Pro project.
• Pressing this button while holding down the Shift button controls the Solo button for the Logic Pro
track.
10 Track Buttons
In both Mixer and Instrument Mode these buttons select the target track or bank of 8 tracks within a Logic
Pro project.
• Track Selection - The left Track button (<) targets the previous track in the project. For example, if Track
2 is currently targeted, pressing this button will target Track 1. The right Track button (>) targets the next
track. For example, if Track 2 is currently targeted, pressing this button will target Track 3. The LCD
screen will display the track name. If the target is an instrument track with a virtual instrument, it is
armed for recording, and the instrument sound is heard when the keys are pressed. If Instrument Mode
is active the controls will map to the instrument within the target track.
These buttons can also be used to target tracks outside the currently active bank of 8 tracks. For example,
if track 8 is currently targeted and the > Track button is pressed, Track 9 will be targeted. Axiom Faders
and their corresponding buttons will now control Tracks 9 – 16.
Axiom DirectLink for Logic Pro User Guide
10
Chapter 3: Axiom Controls with DirectLink
• Bank Selection - When the Shift button is held down the left Track button (<) selects the previous bank
of 8 tracks. For example, if the bank of Tracks 9 – 16 is currently selected, pressing this button when Shift
is held down will select the bank of Tracks 1 – 8. The right Track button (> ) selects the next bank of 8
tracks. For example, if the bank of Tracks 9 – 16 is currently selected, pressing this button when Shift is
held down will select the bank of Tracks 17 – 24.
11 Zone Button
This button is used for accessing the individual Zone buttons (1, 2, 3, and 4).
Zones are used to split or layer the keyboard. When the Zone button is active, Shift, Track and Mute buttons will not function in DirectLink Mode. Pressing the Zone button returns these buttons to DirectLink.
For more information, refer to Chapter 7, “Keyboard Zones” of the Axiom User Guide.
12 Patch Buttons
These buttons are used for selecting virtual instrument sound patches when an active instrument window
is open or hidden.
Hiding an instrument window is not the same as closing it. Refer to the Logic User Manual for more information about hiding instrument or plug-in windows.
Axiom DirectLink for Logic Pro User Guide
11
Chapter 3: Axiom Controls with DirectLink
Chapter 4: Instrument Mode
Instrument Mode maps Axiom controls to numerous virtual instrument parameters within a targeted track in
Logic Pro. This chapter provides an overview of how to setup and use DirectLink to control an instrument
loaded into a track within a Logic Pro project.
Setting Up Instrument Mode
The following steps will guide you through setting up Instrument Mode. Please make sure Axiom is properly
connected to your computer.
To Set Up Instrument Mode:
1 If needed, create an Instrument Track in the Logic Pro project. Please refer to the Logic Pro User Manual for
more details.
2 Load a virtual instrument on to an instrument track.
3 Select the track using either the Fader buttons or the Track buttons.
4 Switch DirectLink to Instrument Mode by pressing the Instrument button (Inst). The button will illuminate,
confirming that Axiom is in Instrument mode
5 Hold down the Shift button and press the Instrument button down to open and close the Instrument win-
dow.
Using Instrument Mode
Axiom Instrument Maps
Axiom Instrument Maps have been created for each of the Logic virtual instruments, which define the default
mapping assignments for Axiom controls. The installer is available for download at www.m-audio.com/drivers and includes maps for all Logic instruments.
Once the maps have been installed, DirectLink will assign Axiom controls to parameters within an open Logic
instrument as described in Appendix A, “DirectLink Control Assignments.”
Please check the DirectLink web page periodically as maps for third party instruments will be released in
the future.
Changing DirectLink Control Assignments
There is cu rre ntly no way t o ch ange the parameter mappings for an Instrument in Logic itself. Logic does however have a powerful MIDI learn feature which enables you to define the parameter mappings for individual
plug-ins outside of DirectLink as described below.
Axiom DirectLink for Logic Pro User Guide
12
Chapter 4: Instrument Mode
The following instructions provide an overview of the process. Refer to the Logic Pro 9 User Manual, Logic Pro
Control Surfaces Support Guide and Logic Studio Instruments Guide for more information.
To reassign an Axiom control:
1 Disengage the control from DirectLink by pressing its corresponding Group button. Press the Group E but-
ton for an Encoder, or Group F button for a Fader or Fader button.
2 Press Command + K on your computer keyboard to open Controller Assignments window opens in Logic.
3 Click the Learn Mode button in the lower right of the window.
4 Move a control on the Instrument in Logic.
5 Move the Axiom control you are reassigning to issue the new mapping.
Your new Instrument mapping will be stored with The Axiom Control Surface in Logic. However, these mappings will be lost if you delete Axiom from Logic's Control Surface set-up dialog.
In the future, you will need to use the same Axiom preset that was active when reassigning the control so
that it always works as expected with that particular Logic instrument.
Controlling Virtual Instruments
Once an Instrument Track is targeted by Axiom and Instrument Mode is activated (See “Instrument Button
(Inst)” on page 7), the instrument name will appear on the LCD screen. If the Track buttons (See “Track Buttons” on page 10) were used for targeting a track, it is also armed for recording, and notes are heard when the
keys are pressed.
Logic Pro has an automated track name feature which names the track according to the current instrument
sound patch. This LCD screen on Axiom will display this name, and in this instance the LCD will display a
new track name when a new instrument sound patch is chosen.
It is possible to rename the track as described in the Logic Pro User guide.
Opening and Closing an Instrument Window
While DirectLink is in Instrument Mode, holding down the Shift button and pressing the Instrument button
will open and close the window for the active instrument.
Instrument Preset Selection
Sound patches within virtual instruments are selected using the Axiom Patch buttons, when the instrument
window is open or hidden.
Hiding an instrument window is not the same as closing it. Refer to the Logic User Manual for more information about hiding instrument or plug-in windows.
Adjusting Instrument Parameters
When a mapped Axiom control is moved its parameter assignment and numerical or positional value will appear on the LCD screen. After one second the screen will revert to the track name.
Axiom controls can be returned to Mixer Mode, at any time, by pressing the Instrument button.
Refer to Chapter 3, “Axiom Controls with DirectLink” for more information about Axiom control types
and their Instrument Mode functions.
Axiom DirectLink for Logic Pro User Guide
13
Chapter 4: Instrument Mode
Appendix A: DirectLink Control Assignments
The following tables list the default DirectLink control assignments for each Logic instrument once the Logic
Pro Instrument Maps have been installed.
EFM1
Encoder Knob Parameter
E1 Mod Harmonic
E2 Modulator Wave
E3 FM
E4 FM Fixed Frequency Toggle
E5 FM Depth
E6 Carrier Harmonic
E7 LFO Rate
E8 LFO Rate
Fader Parameter
F1 Volume Env Attack
F2 Volume Env Decay
F3 Volume Env Sustain
F4 Volume Env Decay
F4 Mod Env Attack
F6 Mod Env Decay
F7 Mod Env Sustain
F8 Mod Env Release
F9 Volume
Axiom DirectLink for Logic Pro User Guide
14
Appendix A: DirectLink Control Assignments
ES E
Fader Buttons Parameter
F10 n/a
F11 n/a
F12 n/a
F13 n/a
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Encoder Knob Parameter
E1 Filter Frequency
E2 Filter Resonance
E3 AR Int
E4 Velo Filter
E5 Waveform
E6 Vib/PWM
E7 Speed
E8 Velo Volume
Axiom DirectLink for Logic Pro User Guide
15
Appendix A: DirectLink Control Assignments
Fader Parameter
F1 Attack
F2 Release
F3 n/a
F4 n/a
F4 n/a
F6 n/a
F7 n/a
F8 n/a
F9 Volume
Fader Buttons Parameter
F10 Octave
F11 Chorus
F12 n/a
F13 n/a
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Axiom DirectLink for Logic Pro User Guide
16
Appendix A: DirectLink Control Assignments
ES M
Encoder Knob Parameter
E1 Filter Cutoff
E2 Filter Resonance
E3 Filter Decay
E4 Filter Intensity
E5 Mix
E6 Glide
E7 Volume Decay
E8 Overdrive
Fader Parameter
F1 n/a
F2 n/a
F3 n/a
F4 n/a
F4 n/a
F6 n/a
F7 n/a
F8 n/a
F9 Volume
Axiom DirectLink for Logic Pro User Guide
17
Appendix A: DirectLink Control Assignments
ES P
Fader Buttons Parameter
F10 Octave
F11 n/a
F12 n/a
F13 n/a
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Encoder Knob Parameter
E1 Filter Cutoff
E2 Filter Resonance
E3 Chorus
E4 Overdrive
E5 Vibrato/Wah
E6 Speed
E7 Velo Filter
E8 Velo Volume
Axiom DirectLink for Logic Pro User Guide
18
Appendix A: DirectLink Control Assignments
Fader Parameter
F1 Attack
F2 Decay
F3 Sustain
F4 Release
F4 Triangle
F6 Sawtooth
F7 Rectangle
F8 Noise
F9 Volume
Fader Buttons Parameter
F10 Octave
F11 VCA Mode
F12 n/a
F13 n/a
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Axiom DirectLink for Logic Pro User Guide
19
Appendix A: DirectLink Control Assignments
ES 1
Encoder Knob Parameter
E1 Filter Frequency
E2 Filter Resonance
E3 Filter Drive
E4 Filter Mode
E5 Waveform
E6 Sub Osc Waveform
E7 LFO Waveform
E8 LFO Rate
Fader Parameter
F1 Env Attack
F2 Env Decay
F3 Env Sustain
F4 Env Release
F4 Glide
F6 LFO Int 0
F7 Mod Env Int 0
F8 Mod Env Form
F9 Volume
Axiom DirectLink for Logic Pro User Guide
20
Appendix A: DirectLink Control Assignments
ES 2
Fader Buttons Parameter
F10 Octave
F11 Chorus
F12 VCA Mode
F13 n/a
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Encoder Knob Parameter
E1 MM Filter Cutoff
E2 MM Filter Resonance
E3 MM Filter Mode
E4 Drive
E5 LPF Cutoff
E6 LPF Resonance
E7 LPF Mode
E8 LPF FM
Axiom DirectLink for Logic Pro User Guide
21
Appendix A: DirectLink Control Assignments
Fader Parameter
F1 Env3 Attack
F2 Env3 Decay
F3 Env3 Sustain
F4 Env3 Release
F4 ENV2 Attack
F6 ENV2 Decay
F7 ENV2 Sustain
F8 ENV2 Release
F9 Volume
Fader Buttons Parameter
F10 Keyboard Mode
F11 Unison
F12 FX Dist Type
F13 FX Mod Type
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Axiom DirectLink for Logic Pro User Guide
22
Appendix A: DirectLink Control Assignments
EVB3
Encoder Knob Parameter
E1 Vibrato
E2 Vibrato Rate
E3 Chorus Rate
E4 EQ Low
E5 EQ Mid
E6 EQ High
E7 EQ Level
E8 Reverb
Fader Parameter
F1 UM 16’
F2 UM 5 -1/3’
F3 UM 8’
F4 UM 4
F4 UM 2 -2/3’
F6 UM 2
F7 UM 1 -3/5’
F8 UM 1 -1/3
F9 UM 1’
Axiom DirectLink for Logic Pro User Guide
23
Appendix A: DirectLink Control Assignments
EVD6
Fader Buttons Parameter
F10 Cabinet
F11 Rotor Speed
F12 Reverb Mode
F13 Vibrato Upper
F14 Vibrato Lower
F15 Percussion
F16 Percussion Mode
F17 Percussion Harmonic
F18 n/a
Encoder Knob Parameter
E1 Comp Ratio
E2 Dist Tone
E3 Dist Gain
E4 Mod FX Rate
E5 Mod FX Intensity
E6 Mod FX Mode
E7 Wah Range
E8 Wah Envelope
Axiom DirectLink for Logic Pro User Guide
24
Appendix A: DirectLink Control Assignments
Fader Parameter
F1 String Decay
F2 String Release
F3 String Damping
F4 Tension Mod
F4 String Stiffness
F6 String Inharmonicity
F7 Pitch Fall
F8 Brilliance
F9 Volume
Fader Buttons Parameter
F10 Brilliant
F11 Treble
F12 Medium
F13 Soft
F14 Pickup Mode
F15 Pickup CD
F16 Pickup AB
F17 Model
F18 n/a
Axiom DirectLink for Logic Pro User Guide
25
Appendix A: DirectLink Control Assignments
EVOC 20
Encoder Knob Parameter
E1 Filter Cutoff
E2 Filter Resonance
E3 Low Frequency
E4 High Frequency
E5 Resonance
E6 Formant Stretch
E7 Formant Shift
E8 Analog
Fader Parameter
F1 ENV Attack
F2 ENV Release
F3 Attack
F4 Release
F4 LFO Rate
F6 LFO2 Rate
F7 Noise Color
F8 Noise Volume
F9 Volume
Axiom DirectLink for Logic Pro User Guide
26
Appendix A: DirectLink Control Assignments
EVP88
Fader Buttons Parameter
F10 LowBand Mode
F11 HighBand Mode
F12 Kybd Mode
F13 Unison
F14 LFO Waveform
F15 LFO2 Waveform
F16 Ensemble
F17 n/a
F18 n/a
Encoder Knob Parameter
E1 EQ Treble
E2 EQ Bass
E3 Drive Gain
E4 Drive Tone
E5 Phaser Rate
E6 Tremolo Rate
E7 Tremolo Intensity
E8 Chorus Intensity
Axiom DirectLink for Logic Pro User Guide
27
Appendix A: DirectLink Control Assignments
Fader Parameter
F1 Decay
F2 Release
F3 Bell Volume
F4 Damper Volume
F4 Stereo Intensity
F6 Lower Stretch
F7 Upper Stretch
F8 Warmth
F9 Volume
Fader Buttons Parameter
F10 n/a
F11 n/a
F12 n/a
F13 n/a
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Axiom DirectLink for Logic Pro User Guide
28
Appendix A: DirectLink Control Assignments
EXS24
Encoder Knob Parameter
E1 Filter Cutoff
E2 Filter Resonance
E3 Drive
E4 Filter Key Tracking
E5 Glide Time
E6 Pitcher
E7 Pitcher via Velocity
E8 Level via Velocity
Fader Parameter
F1 ENV1 Attack
F2 ENV1 Decay
F3 ENV1 Sustain
F4 ENV1 Release
F4 ENV2 Attack
F6 ENV2 Decay
F7 ENV2 Sustain
F8 ENV2 Release
F9 Volume
Axiom DirectLink for Logic Pro User Guide
29
Appendix A: DirectLink Control Assignments
Klopfgeist
Fader Buttons Parameter
F10 Filter Type
F11 Filter Fat
F12 Filter On/Off
F13 LFO1 Wave
F14 LFO2 Wave
F15 Unison
F16 Mono Mode
F17 n/a
F18 n/a
Encoder Knob Parameter
E1 Tonality
E2 Note Off Damp
E3 Tune
E4 Detune
E5 Mode
E6 n/a
E7 n/a
E8 Level Min Vel
Axiom DirectLink for Logic Pro User Guide
30
Appendix A: DirectLink Control Assignments
Fader Parameter
F1 n/a
F2 n/a
F3 n/a
F4 n/a
F4 n/a
F6 n/a
F7 n/a
F8 n/a
F9 Volume
Fader Buttons Parameter
F10 n/a
F11 n/a
F12 n/a
F13 n/a
F14 n/a
F15 n/a
F16 n/a
F17 n/a
F18 n/a
Axiom DirectLink for Logic Pro User Guide
31
Appendix A: DirectLink Control Assignments
Sculpture
Encoder Knob Parameter
E1 Filter Cutoff
E2 Filter Resonance
E3 String Resonance
E4 String Media Loss
E5 String Tension Modulation
E6 EQ Low
E7 EQ Mid
E8 EQ High
Fader Parameter
F1 Amp Env Attack Hard
F2 Amp Env Attack Soft
F3 Amp Env Decay
F4 Amp Env Sustain
F4 Amp Env Release
F6 Delay Wet Level
F7 Delay Feedback
F8 Delay Cross Feed
F9 Volume
Axiom DirectLink for Logic Pro User Guide
32
Appendix A: DirectLink Control Assignments
Ultra Beat
Fader Buttons Parameter
F10 Filter On/Off
F11 Filter Type
F12 EQ On/Off
F13 EQ Model
F14 Delay On/Off
F15 Delay Time Mode
F16 Kybd Mode
F17 Limiter Mode
F18 n/a
Encoder Knob Parameter
E1 Filter Cutoff
E2 Filter Resonance
E3 Crush Drive
E4 Crush Downsample
E5 Crush Clip Level
E6 Noise Cutoff
E7 Noise Resonance
E8 Noise Dirt
Axiom DirectLink for Logic Pro User Guide
33
Appendix A: DirectLink Control Assignments
Fader Parameter
F1 OSC1 Saturation
F2 OSC1 Asymmetr y
F3 OSC1 Slope
F4 OSC1 Pitch
F4 OSC1 Pitch via Vel
F6 OSC1 Level
F7 OSC1 LevelMod Amount
F8 n/a
F9 Volume
Fader Buttons Parameter
F10 OSC1 On/Off
F11 OSC1 Type
F12 Level Source
F13 Noise On/Off
F14 Noise Filter Type
F15 n/a
F16 Sequencer On/Off
F17 Start/Stop Sequencer
F18 n/a
Axiom DirectLink for Logic Pro User Guide
34
Appendix A: DirectLink Control Assignments
Avid
5795 Martin Road
Irwindale, CA 91706-6211 USA
Technical Support (USA)
Visit the Online Support Center at
www.avid.com/support
Product Information
For company and product information,
visit us on the web at www.avid.com
Loading...
