Quick Start Guide
Guide de démarrage rapide / Guía de inicio rápido
Read Me First....
Lisez-moi en premier.... /
Lea esto primero....
ENGLISH
FRANÇAIS
ESPAÑOL
AV Pre Tuner
AV7704
Please do not return this unit to the store.
If you need help…
Check our AVR setup tips online
Us.Marantz.com/SetupTips
Ca.Marantz.com/SetupTips
Call for Assistance
1-855-ONE-Marantz (USA)
1-855-663-6272
1-800-668-0652 (Canada)
Monday – Friday 10:00AM to 10:00PM E.S.T Saturday 12:00PM to 8:00PM E.S.T
Welcome
Thank you for choosing a Marantz Pre Tuner.
This guide provides step-by-step instructions for setting up your Pre Tuner.
Before You Begin
Required for Setup
|
|
|
or |
|
TV |
RCA cables |
XLR cables |
||
HDMI cable |
|
Power amplifier |
Speakers / |
|
|
|
|
|
Speaker cables |
|
|
Optional |
|
|
|
|
|
or |
|
LAN cable |
|
|
Wi-Fi router |
|
•When connecting this unit to a device that is compatible with the Deep Color, 4K and ARC functions, use a “High Speed HDMI cable with Ethernet” that displays the HDMI logo.
•These drawings are for illustrative purposes only and may not represent the actual product(s).
1
What’s In the Box
Quick Start Guide |
FM indoor antenna |
Safety Instructions |
AM loop antenna |
Notes on radio |
Sound calibration |
|
microphone |
Warranty (for USA / |
Sound calibration |
for CANADA) |
microphone stand |
Cable labels |
Remote control unit |
|
(RC037SR) |
Pre Tuner |
R03/AAA batteries |
Power cord |
External antennas |
|
for Bluetooth/ |
|
wireless connectivity |
•The included sound calibration microphone stand is convenient for use when performing Speaker Calibration. Using your own tripod or the supplied Sound calibration microphone stand enables settings to be automatically configured to the optimum listening environment, providing exceptionally high performance.
2
Important: External Antennas
The removable external antennas are required for both Bluetooth and Wireless network connectivity. Please make sure to connect the antennas before attempting to use the Bluetooth or Wi-Fi features of the AV7704.
nn Connecting the external antennas for
Bluetooth/Wireless connectivity
For each of the two antennas:
q Place the antenna evenly over the antenna terminal located at the upper left or right corner of the rear panel.
w Turn the antenna clockwise until it is fully connected. Do not over tighten.
e Rotate the antenna upwards for the best possible reception.
q w e
3
