Marantz CD6002 User Manual

4.92 Mb

Model CD6002 User Guide

CD Player

CLASS 1 LASER PRODUCT

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

TEXT

ENGLISH

WARRANTY

For warranty information, contact your local Marantz distributor.

RETAIN YOUR PURCHASE RECEIPT

Your purchase receipt is your permanent record of a valuable purchase. It should be kept in a safe place to be referred to as necessary for insurance purposes or when corresponding with Marantz.

IMPORTANT

When seeking warranty service, it is the responsibility of the consumer to establish proof and date of purchase. Your purchase receipt or invoice is adequate for such proof.

FOR U.K. ONLY

This undertaking is in addition to a consumer's statutory rights and does not affect those rights in any way.

FRANÇAIS

GARANTIE

Pour des informations sur la garantie, contacter le distributeur local Marantz.

CONSERVER L'ATTESTATION D'ACHAT

L'attestation d'achat est la preuve permanente d'un achat de valeur. La conserver en lieu sur pour s'y reporter aux fi ns d'obtention d'une couverture d'assurance ou dans le cadre de correspondances avec Marantz.

IMPORTANT

Pour l'obtention d'un service couvert par la garantie, il incombe au client d'établir la preuve de l'achat et d'en corroborer la date. Le reçu ou la facture constituent des preuves suffisantes.

DEUTSCH

GARANTIE

Bei Garantiefragen wenden Sie sich bitte an Ihren Marantz-Händler.

HEBEN SIE IHRE QUITTING GUT AUF

Die Quittung dient Ihnen als bleibende Unterlage für Ihren wertvollen Einkauf Das Aufbewahren der Quittung ist wichtig, da die darin enthaltenen Angaben für Versicherungswecke oder bei Korrespondenz mit Marantz angeführt werden müssen.

WICHTIG!

BeiGarantiefragenmußderKundeeineKaufunterlage mit Kaufdatum vorlegen. Ihren Quittung oder Rechnung ist als Unterlage ausreichend.

NEDERLANDS

GARANTIE

Voor inlichtingen omtrent garantie dient u zich tot uw plaatselijke Marantz.

UW KWITANTIE, KASSABON E.D. BEWAREN

Uw kwitantie, kassabon e.d. vormen uw bewijs van aankoop van een waardevol artikel en dienen op een veilige plaats bewaard te worden voor evt, verwijzing bijv, in verbend met verzekering of bij correspondentie met Marantz.

BELANGRIJK

Bij een evt, beroep op de garantie is het de verantwoordelijkheid van de consument een gedateerd bewijs van aankoop te tonen.Uw kassabon of factuurzijn voldoende bewijs.

ESPAÑOL

GARANTIA

Para obtener información acerca de la garantia póngase en contacto con su distribuidor Marantz.

GUARDE SU RECIBO DE COMPRA

Su recibo de compra es su prueba permanente de haber adquirido un aparato de valor, Este recibo deberá guardarlo en un lugar seguro y utilizarlo como referencia cuando tenga que hacer uso del seguro o se ponga en contacto con Marantz.

IMPORTANTE

Cuando solicite el servicio otorgado por la garantia el usuario tiene la responsabilidad de demonstrar cuándo efectuó la compra. En este caso, su recibo de compra será la prueba apropiada.

ITALIANO

GARANZIA

L’apparecchio è coperto da una garanzia di buon funzionamento della durata di un anno, o del periodo previsto dalla legge, a partire dalla data di acquisto comprovata da un documento attestante il nominativo del Rivenditore e la data di vendita. La garanzia sarà prestata con la sostituzione o la riparazione gratuita delle parti difettose.

Non sono coperti da garanzia difetti derivanti da uso improprio, errata installazione, manutenzione effettuata da personale non autorizzato o, comunque, da circostanze che non possano riferirsi a difetti di funzionamento dell’apparecchio. Sono inoltre esclusi dalla garanzia gli interventi inerenti l’installazione e l’allacciamento agli impianti di alimentazione.

Gli apparecchi verranno riparati presso i nostri Centri di Assistenza Autorizzati. Le spese ed i rischi di trasporto sono a carico del cliente.

La casa costruttrice declina ogni responsabilità per danni diretti o indiretti provocati dalla inosservanza delle prescrizioni di installazione, uso e manutenzione dettagliate nel presente manuale o per guasti dovuti ad uso continuato a fini professionali.

SVENSKA

GARANTI

För information om garantin, kontakta Marantz lokalagent.

SPAR KVITTOT

Kvittot är ett inköpsbevis på en värdefull vara.Det skall förvaras säkert och hänvisas till vid försäkringsfall eller vidkorrespondens mod Marantz.

VIKTIGT

Fö att garantin skall gälla är det kundens sak att framställa bevis och datum om köpet. Kvitto eller faktura är tillräokligt bevis fö detta.

CE MARKING

English

The CD6002 is in conformity with the EMC directive and low-voltage directive.

Français

Le CD6002 est conforme à la directive EMC et à la directive sur les basses tensions.

Deutsch

Das Modell CD6002 entspricht den EMCRichtlinien und den Richtlinien für Niederspannungsgeräte.

Nederlands

De CD6002 voldoet aan de EMC eisen en de vereisten voor laag-voltage.

Español

El CD6002 está de acuerdo con las normas EMC y las relacionadas con baja tensión.

Italiano

Il CD6002 è conforme alle direttive CEE ed a quelle per i bassi voltaggi.

Svenska

CD6002 är tillverkad i enlighet med EMC direktiven och direktiven för lågvoltsutrusning.

English

WARNINGS

-Do not expose the equipment to rain or moisture.

-Do not remove the cover from the equipment.

-Do not insert anything into the equipment through the ventilation holes.

-Do not handle the mains cord with wet hands.

-Do not cover the ventilation with any items such as tablecloths, newspapers, curtains, etc.

-No naked flame sources, such as lighted candles, should be placed on the equipment.

-When disposing of used batteries, please comply with governmental regulations or environmental public instruction’s rules that apply in your country or area.

-Make a space of about 0.1 meter around the unit.

-No objects filled with liquids, such as vases, shall be placed on the equipment.

-When the switch is in the OFF position, the equipment is not completely switched off from MAINS.

-The equipment shall be installed near the power supply so that the power supply is easily accessible.

Français

AVERTISSEMENTS

-Ne pas exposer l’appareil à la pluie ni à l’humidité.

-Ne pas essayer de retirer le boîtier de l’appareil.

-Ne rien insérer dans l’appareil par les orifi ces de ventilation.

-Ne pas manipuler le cordon d’alimentation avec les mains mouillées.

-Ne pas recouvrir les ouïes de ventilation avec un objet quelconque comme une nappe, un journal, un rideau, etc.

-Ne placer aucune source de fl amme nue, comme une bougie allumée, sur l’appareil.

-Pour mettre au rebut les piles usées, respecter les lois gouvernementales ou les règlements offi ciels concernant l’environnement qui s’appliquent à votre pays ou région.

-Veiller à ce qu’aucun objet ne soit à moins de 0,1 mètre des côtés de l’appareil.

-Aucun objet rempli de liquide, un vase par exemple, ne doit être placé sur l’appareil.

-Lorsque l’interrupteur est sur la position OFF, l’appareil n’est pas complètement déconnecté du SECTEUR (MAINS).

-L’appareil sera installé près de la source d’alimentation, de sorte que cette dernière soit facilement accessible.

Deutsch

WARNHINWEISE

-Das Gerät nicht Regen oder Feuchtigkeit aussetzen.

-Die Abdeckung nicht vom Gerät abnehmen.

-Keine Gegenstände durch die Belüftungsschlitze stecken.

-Das Netzkabel nicht mit feuchten oder nassen Händen anfassen.

-Decken Sie die Lüftungsöffnungen nicht mit einem

Tischtuch, einer Zeitung, einem Vorhang usw. ab.

-Es dürfen keine Gegenstände mit offener Flamme, wie etwa brennende Kerzen, auf dem Gerät aufgestellt werden.

-Beachten Sie bei der Entsorgung der verbrauchten Batterien alle geltenden lokalen und überregionalen Regelungen.

-Auf allen Geräteseiten muß ein Zwischenraum von ungefähr 0,1 meter vorhanden sein.

-Auf das Gerät dürfen keine mit Flüssigkeiten gefüllte Behälter, wie etwa eine Vase, gestellt werden.

-Wenn der Schalter ausgeschaltet ist (OFF-Position), ist das Gerät nicht vollständig vom Stromnetz (MAINS) abgetrennt.

-Das Gerät sollte in der Nähe einer Netzsteckdose aufgestellt werden, damit es leicht an das Stromnetz angeschlossen werden kann.

Nederlands

WAARSCHUWINGEN

-Stel het apparaat niet bloot aan regen of vocht.

-Verwijder de afdekplaat van het apparaat niet.

-Duw niets door de ventilatieopeningen in het apparaat.

-Raak het netsnoer niet met natte handen aan.

-Bedek de ventilatieopeningen niet met enige voorwerpen, zoals tafelkleden, kranten, gordijnen, enz.

-Plaats geen brandende voorwerpen, zoals kaarsen, op het apparaat.

-Volg bij het weggooien van verbruikte batterijen de overheidswetgeving of milieuvoorschriften op die van kracht zijn in het land of de regio waarin u zich bevindt.

-Zorg dat er 0,1 meter vrije ruimte rond het toestel is.

-Plaats geen voorwerpen met een vloeistof erin, zoals een bloemenvaas, op het apparaat.

-Als de schakelaar op OFF staat, is het apparaat niet volledig losgekoppeld van de netspanning (MAINS).

-De apparatuur wordt in de buurt van het stopcontact geïnstalleerd, zodat dit altijd gemakkelijk toegankelijk is.

Español

ADVERTENCIAS

-No exponga el equipo a la lluvia ni a la humedad.

-No extraiga la tapa del equipo.

-No introduzca nada en el interior del equipo a través de los orifi cios de ventilación.

-No maneje el cable de alimentación con las manos mojadas.

-No cubra la ventilación con objetos como manteles, periódicos, cortinas, etc.

-No deben colocarse sobre el equipo elementos con fuego, por ejemplo velas encendidas.

-Cuando se eliminen baterías usadas, deben cumplirse las reglamentaciones oficiales o las normas de protección medioambiental aplicables en su país o en su zona.

-Deje un espacio de unos 0,1 metro alrededor de la unidad.

-No se deben colocar sobre el aparato recipientes que contengan líquidos, como por ejemplo jarrones.

-Cuando el interruptor está en la posición OFF, el equipo no está completamente desconectado de la alimentación MAINS.

-El equipo se instalará cerca de la fuente de alimentación de manera que resulte fácil acceder a ella.

Italiano

AVVERTENZE

-Non esporre l’apparecchio alla pioggia o all’umidità.

-Non rimuovere il coperchio dell’apparecchio.

-Non introdurre oggetti all’interno dell’apparecchio attraverso i fori di ventilazione.

-Non toccare il cavo di alimentazione con le mani bagnate.

-Non coprire le fessure di ventilazione con tovaglie, giornali, tende od oggetti analoghi.

-Non posare sull’apparecchio sorgenti di fi amme scoperte quali candele accese.

-Smaltire le pile usate in conformità alle norme governative o disposizioni ambientali vigenti nel proprio paese o zona.

-Lasciare 0,1 metro liberi tutto intorno l’unità.

-Non mettere sull’apparecchiatura alcun contenitore di liquido, come ad esempio dei vasi.

-Quando l’interruttore è nella posizione OFF, l’apparecchiatura non è completamente scollegata da MAINS.

-L’apparecchio va installato in prossimità della fonte di alimentazione, in modo che quest’ultima sia facilmente accessibile.

Svenska

VARNINGAR

-Utsätt inte utrustningen för regn eller fukt.

-Ta inte bort utrustningens hölje.

-För inte in föremål i utrustningen genom ventilationshålen.

-Hantera inte nätsladden med våta händer.

-Täck inte för ventilationsöppningarna med några föremål som till exempel bordsdukar, dagstidningar, gardiner e.d.

-Inga föremål med öppen låga, som till exempel tända stearinljus, bör placeras på utrustningen.

-Följ de lagar och miljöskyddsråd som gäller i det land eller område där du bor när du gör dig av med batterier.

-Se till att det fi nns omkring 0,1 meter fri plats runt omkring enheten.

-Inga objekt som är fyllda med någon vätska, till exempel blomstervaser, bör placeras på apparaten.

-Även om strömbrytaren står i det avstängda läget OFF, så är utrustningen inte helt bortkopplad från det elektriska nätet (MAINS).

-Utrustningen ska vara installerad nära strömuttaget så att strömförsörjningen är lätt att tillgå.

OPT_060125N1

INTRODUCTION

CONTENTS

Thank you for selecting the Marantz CD6002 CD Player for your A/V system.

This Compact Disc Player incorporates a number of features designed to enhance the listening of your favorite audio sources.

Please read these operating instructions carefully. We recommend that you read the entire user guide before you attempt to connect or operate the player.

After you have reviewed the contents of this manual,we suggest that you make all system connections before you attempt to operate the unit.

7 Checking the accessories

After opening the cover of the packing box, check that the following accessories are included.

• Remote controller

• Size “AAA” batteries x 2

• AC Power cord

• Audio connecting cord

• Remote control connecting cord

• User Guide

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. This product and the accessories packed together are the applicable product to the WEEE directive except batteries.

Please dispose of any materials in accordance with your local recycling regulations.

When discarding the unit, comply with your local rules or regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
