Page 1
01 - 2015
EN401MP
HEDGE TRIMMER ATTACHMENT
3
7
2
1
4
6
5
Page 2
34
35
30
36
29
33
28
37
27
31
26
21
25
32
24
20
23
19
18
22
17
16
13
11
12
1415
55
56
57
58
59
60
63
42
38
62
43
39
61
44
33
A03
76
72
74
41
45
73
54
53
52
51
50
49
48
46
47
81
2 EN401MP
69
64
68
70
71
65
78
66
67
A03
80
79
Page 3
3 MODEL EN401MP (20/03/2017)
Item No. Type Sub Part No. Description Qty Unit
1 893670-0 MAKITA LOGO LABEL 1 PC.
2 801F86-1 CAUTION LABEL 1 PC.
3 424434-7 CAP 24 1 PC.
4 142033-0 PIPE COMPLETE 1 PC.
4 INC. Item No. 2
5 961003-8 RETAINING RING S-7 1 PC.
6 326088-5 SHAFT A 1 PC.
7 814A82-0 DATE CODE LABEL 1 PC.
11 266817-3 H.S. BUTTON HEAD BOLT M6X85 1 PC.
12 232279-7 CONED DISC SPRING 6 1 PC.
13 941151-9 FLAT WASHER 6 1 PC.
14 266818-1 HEX. SOCKET HEX. BOLT M8X8 1 PC.
15 318969-7 JOINT 1 PC.
16 227604-5 SPIRAL BEVEL GEAR 9 1 PC.
17 211032-4 BALL BEARING 608ZZ 1 PC.
18 211032-4 BALL BEARING 608ZZ 1 PC.
19 962102-9 RETAINING RING R-22 1 PC.
20 310534-8 CAM A 1 PC.
21 310535-6 CAM B 1 PC.
22 922126-7 HEX. SOCKET HEAD BOLT M4X16 2 PC.
23 313254-3 HOLDER PLATE 1 PC.
24
961011-9
STOP RING E-4 2 PC.
25
346657-6 SLIDE PLATE 1 PC.
26 231297-2 COMPRESSION SPRING 9 1 PC.
27 962103-7 RETAINING RING R-24 1 PC.
28 961005-4 RETAINING RING S-9 1 PC.
29 210049-4 BALL BEARING 609ZZ 1 PC.
30 142000-5 SPINDLE COMPLETE 1 PC.
31 2 326812-6 ROD 5 2 PC.
32 233117-6 COMPRESSION SPRING 6 2 PC.
33 187575-7 SLIDE LEVER SET 1 SET
34 454249-8 COVER 1 PC.
35 265493-0 HEX. SOCKET HEAD BOLT M4X20 4 PC.
36 961011-9 STOP RING E-4 2 PC.
37 318970-2 PIPE HOLDER 1 PC.
38 922223-9 H.S.H.BOLT M5X16 WITH WR 1 PC.
39 922241-7 HEX. SOCKET HEAD BOLT M5X25 1 PC.
41 265995-6 TAPPING SCREW 4X18 2 PC.
42 1 454248-0 * GRIP 1 PC.
42 2 456369-4 * GRIP 1 PC.
43 2 911516-9 * PAN HEAD SCREW M4X12 2 PC.
44 252190-7 HEX.LOCK NUT M6-10 1 PC.
45 266818-1 HEX. SOCKET HEX. BOLT M8X8 1 PC.
46 267467-7 FLAT WASHER 36 1 PC.
47 922126-7 HEX. SOCKET HEAD BOLT M4X16 2 PC.
48 961006-2 RETAINING RING S-10 1 PC.
49 227605-3 SPIRAL BEVEL GEAR 22 1 PC.
50 310533-0 ANGULAR PLATE 1 PC.
51 211148-5 BALL BEARING 6001ZZ 1 PC.
52 211148-5 BALL BEARING 6001ZZ 1 PC.
53 227606-1 SPIRAL BEVEL GEAR 11 1 PC.
54 1 142018-6 * GEAR HOUSING COMPLETE 1 PC.
54 2 143500-8 * GEAR HOUSING COMPLETE 1 PC.
55 227607-9 SPIRAL BEVEL GEAR 12 1 PC.
56 211062-5 BALL BEARING 6000ZZ 1 PC.
57 211062-5 BALL BEARING 6000ZZ 1 PC.
58 962105-3 RETAINING RING R-26 1 PC.
59 227317-8 SPUR GEAR 24 1 PC.
60 961004-6 RETAINING RING S-8 1 PC.
61 346658-4 PLATE 1 PC.
62 346251-4 CONNECTING ROD 1 PC.
63 227248-1 SPUR GEAR 43 1 PC.
Page 4
4 MODEL EN401MP (20/03/2017)
Item No. Type Sub Part No. Description Qty Unit
64 346251-4 CONNECTING ROD 1 PC.
65 346256-4 HOLDER 1 PC.
66 922241-7 HEX. SOCKET HEAD BOLT M5X25 2 PC.
67 443159-4 SEAL 1 PC.
68 346658-4 PLATE 1 PC.
69 423458-0 GASKET 1 PC.
70 318968-9 UNDER COVER 1 PC.
71 922126-7 HEX. SOCKET HEAD BOLT M4X16 6 PC.
72 332058-4 GUIDE BAR 1 PC.
73 264089-4 HEX. LOCK NUT M6-10 4 PC.
74 346665-7 PLATE 1 PC.
76 313211-1 SLEEVE 5 2 PC.
78 346665-7 PLATE 1 PC.
79 266824-6 H.S. BUTTON HEAD BOLT M6X20 4 PC.
C01 874560-6 CARTON F/EN401MP 1 PC.
ACCESSORIES - See Catalogue or visit www. Makita.ca for m o re accesso ries information -
A01 452328-6 BLADE COVER 1 PC.
A02 782223-9 SOCKET WRENCH 1 PC.
A03 725187-4 SHEAR BLADE 2 PC.
A04 197768-8 SHEAR BLADE ASSEMBLY SET ME 1 PC.
A04 INC. 346629-1 END COVER 1 PC.
A04 INC.
266075-1 HEX. SOCKET HEAD BOLT M5X6 1 PC.
A04 INC. Item No.72-74, 76, 79, A03
Page 5
SERVICE CHANGES
1. Changes on Gear housing complete, Grip, M4x16 Hex socket head bolt
(TI#A9070)
Item No. Description Type 1 Type 2
42
GRIP 454248-0 456369-4
43
HEX. SOCKET HEAD BOLT M4X16 >>>
PAN HEAD SCREW M4X12
54 GEAR HOUSING COMPLETE
142018-6 143500-8
Above parts are completely interchangeable as a set.
No. 42 Type 1 Type 1
No.54 Type 1 Type 1
922128-3 911516-9
Service Changes -EN401MP (Updated:20/03/2017)
