LG HBS-S80 User guide
User Manual
LG FORCE™
Bluetooth® Wireless Stereo Headset
032
Rev 1.0 RU
English
Рyccкий
HBS-S80 www.lg.com
Қазақша
Українська
Contact ofce for compliance of this product :
LG Electronics European Shared Service Center B.V.
Krijgsman 1, 1186 DM Amstelveen, The Netherlands
User Manual
LG FORCE™
Bluetooth® Wireless Stereo Headset
All rights reserved. LG Electronics Inc., 2016
NOTE: For the best performance and to prevent any damage to, or misuse of the HBS-S80,
please read all of the information carefully prior to using the HBS-S80.
Any modications or changes to this manual due to typographical errors or inaccuracies of
stated information shall only be made by LG Electronics Inc.
HBS-S80 www.lg.com
ENGLISH
The LG FORCE (HBS-S80) is a lightweight wireless headset that uses Bluetooth technology.
This product can be used as an audio accessory for devices supporting either the A2DP or Hands-Free
Bluetooth Prole.
ENGLISH
Safety Cautions
! CAUTION
Do not disassemble, adjust or repair the product arbitrarily.
Do not place the product near excessive heat or ammable material.
Do not arbitrarily replace the battery as it may explode.
The product may be damaged if an incompatible charger is used.
Make sure that any infant or child does not swallow a magnet or a small component of the product.
Make sure that foreign objects do not enter the charger's connectors (charging port and power plug).
Failing to do so may result in re or electric shock.
For your safety, do not wear the product whilst it is being charged.
If you have a medical device implanted, contact your doctor before use.
Do not pull the earphone cable with excessive force.
For your safety, do not remove the battery that is incorporated in the product.
The lithium-ion polymer battery is a hazardous component which can cause injury.
Battery replacement by a non-qualied professional can cause damage to your device.
Do not replace the battery yourself. The battery can become damaged, which can cause overheat and
injury. The battery must be replaced by an authorised service provider. The battery should be recycled or
disposed separately from household waste.
! WARNING
Do not drop the product from a height.
Make sure that no alcohol or benzene comes into contact with the product.
Do not store the product in a wet or dusty place.
Do not place any heavy objects on the product.
Product is sweat and water-resistant (IPx5). It is not waterproof and should not be submerged in water.
NOTE
If the product is exposed to excessive sweat, clean the product.
Always keep the earbud of the earphone clean.
2
HD Speaker
Power O
2 sec
Power O
2 sec
If the communication network of the device to which you are connecting supports HD Voice Calling,
you can enjoy making voice calls and listening to music in high denition.
Qualcomm® aptX™ audio
LG HBS-S80 is powered by Qualcomm aptX audio. Qualcomm aptX audio is Bluetooth wireless
technology that provides clearer audio for listening to music and watching lms.
Qualcomm aptX audio is automatically enabled when a mobile phone or audio device supports it.
Product Components
ENGLISH
FORCE HBS-S80
(Medium ear gels installed)
TM
LG FORCE
Reference Guide User Manual
Micro USB
Charging Cable
Extra Ear Gels
(small & large)
Warranty Card WEEE Card (Europe Only)
NOTE: Actual product design may differ from images shown in manual.
CAUTION
!
Make sure that authentic LG Electronics components are used. Using a non-authentic component
may damage the product and thus void the warranty.
Pouch
3
Product Description
ENGLISH
Microphone (Rear)
Power Button
Volume Down
(Previous) Button
NOTE: When you control the volume (level 16), you will hear a control sound twice or as a long
sound from volume level 6 and higher.
Volume Up (Next) Button
MFB (Multi-Function Button)
Charging Port
Battery Charging and Alerts
Open the Charging Port cover and connect the charger to the Charging Port.
Indicator Lamp Red Purple Blue
Battery Status Charging 80% Completed
Press and hold the Volume Down Button for 2 seconds to check the battery level using voice
prompts and the Indicator Lamp.
Battery Status High Medium Low
Indicator Lamp Flashes blue Flashes purple Fl ashes red
4
Earbuds (Left/Right)
Indicator Lamp
Putting on the Product
LG HBSS80
LG
1 Fit the top of the ear hooks on your ears, and insert the earbuds into your ears.
2 Fit the bottom of the ear hooks on your ears, and adjust the ear hooks so they do not move.
HBS-S80 Pairing and Connecting
If you start the process after putting in your earbuds, you can easily pair and
connect following the voice prompts.
If you hear that the battery is insufcient, recharge the battery before
proceeding with pairing.
If pairing is not completed within 3 minutes, the power automatically turns off.
If the power turns off automatically, press and hold the Power Button for
2 seconds to turn the power on.
Connecting Quickly
1 Press and hold the Power Button for 2 seconds to turn the power on.
2 The Indicator Lamp will turn blue and the HBS-S80 will switch to Search mode.
ENGLISH
5
3 From the mobile phone or device list, select LG HBSS80 to connect.
4 A voice message will indicate that the connection is complete.
5 Use the same process to pair the HBS-S80 with other devices.
ENGLISH
Connecting Manually
1 When the power is off, simultaneously press and hold the Power Button and the MFB for
2 seconds to turn the power on.
2 The blue Indicator Lamp turns on and the HBS-S80 switches to Search mode.
3 Select LG HBSS80 from the device list to connect.
Multiple Connections
The HBS-S80 can be simultaneously connected to a mobile phone and a PC.
The HBS-S80 can be connected to an additional device while it is already connected to a device.
1 When the power is off, simultaneously press and hold the Power Button and the MFB for
2 seconds to turn the power on.
2 The Indicator Lamp will turn blue, and the HBS-S80 will switch to Search mode.
3 From the mobile phone or device list, select LG HBSS80 to connect.
4 A voice message will indicate that the connection is complete. This device becomes the
“Main Connected Device”.
5 Try to connect to HBS-S80 using a previously connected device. This device becomes the
“Sub Connected Device”.
NOTE:
If simultaneously connected to two devices, the device that was connected most recently is
the “Main Connected Device”. The main functions work based on the “Main Connected Device”.
Automatic Reconnection
If you turn on the product, it automatically searches for and connects to the devices (“Main Connected
Device” and “Sub Connected Device”) to which it was previously connected. (If the product cannot nd
the device to which it was connected last time, the product switches to Search mode.)
If the product does not automatically connect to the device that you want, search the device list for
the product to which you want to connect and connect it manually.
6
Indicator Lamp
HBS-S80 Status Description
Power On The blue Indicator Lamp ashes four times.
Power Off The blue Indicator Lamp ashes four times.
Search Mode The blue Indicator Lamp is on.
Connected to a device The Indicator Lamp will ash blue once every 5 seconds.
Call Connected or
Playing Music
The Indicator Lamp will ash blue once every 5 seconds.
Mobile Calling Functions
Functions Description
Receiving a Call/
Hanging Up
Making a Call
Redial
Voice Dial Press and hold the MFB for 1 second.
Switching Calls
Receiving a Call While
on the Phone
Rejecting a Call Press and hold the MFB for 2 seconds.
Enabling/Disabling Mute
Press the MFB.
If you make a call using a mobile phone, the call is automatically connected
to the HBS-S80.
Press and hold the MFB for 2 seconds to redial the most recent number
that you called.
Press and hold the Volume Up Button for 2 seconds.
(Every time you press one of these buttons, the call switches to the mobile
phone or the HBS-S80.)
Press and hold the MFB for 1 second to receive another call while already
talking on the phone.
The rst call will be switched to call waiting. Press and hold the MFB for
1 second to return to the rst call.
Simultaneously press and hold the Volume Up Button and the Volume
Down Button for 1 second.
ENGLISH
7
CAUTION: Do not disable/enable mute while driving, as you need to use both hands.
NOTE: The Voice Dial and Redial functions work on the Main Connected Device or on the device
on which you made the last call. (The Voice Dial and Redial functions may work differently
depending on the mobile phone being used.)
ENGLISH
The Voice Dial and Redial functions are not available while music is being played.
Press the MFB to pause the music before using these functions.
Playing Music
Functions Description
Play
Pause Press the MFB while your music is playing.
Previous Song Press and hold the Volume Down Button for 1 second.
Next Song Press and hold the Volume Up Button for 1 second.
Change Equaliser Mode
NOTE: To switch to a different music playback device when multiple devices are connected, stop
any music playing and play music from the device of your choice.
Press the MFB.
Music will play from the activated player of the connected device.
While your music is playing, press and hold the MFB for 2 seconds.
The Equaliser Mode will change in the following order:
Bass Boost (default) > Normal > Treble Boost.
Out of Range
If the device connected to the product is out of effective communication range (10 metres/33 feet),
the communication signal becomes weak and the communication is lost.
If the device comes back within effective communication range, the product automatically reconnects
to the device. If the device is not automatically reconnected, press the MFB on the product to connect
to it manually.
If a device not in use moves out of range when multiple devices are connected, a voice prompt will be
generated. In this case, the automatic reconnection function is not supported.
8
Summary of HBS-S80 Functions
Function HBS-S80 Status Action
Power On Power off Press and hold the Power Button for 2 seconds.
Power Off Power on Press and hold the Power Button for 3 seconds.
Volume Up
Volume Down
Switching Calls Talking Press and hold the Volume Up Button for 2 seconds.
Receiving a Call Ringing Briey press the MFB.
Ending a Call Talking Briey press the MFB.
Call Waiting Talking Press and hold the MFB for 1 second.
Last Number Redial Idle Press and hold the MFB for 2 seconds.
Voice Dialling
(must be supported on
mobile device)
Rejecting a Call Ringing Press and hold the MFB for 2 seconds.
Enabling/Disabling Mute Talking
Pairing Mode (manual) Power off
Battery Status Check Idle
Play Power on Briey press the MFB.
Pause Music on Briey press the MFB.
Next Song Music on Press and hold the Volume Up Button for 1 second.
Previous Song Music on
Equaliser Settings Music on Press and hold the MFB for 2 seconds.
Talking/
Music on
Talking/
Music on
Idle Press and hold the MFB for 1 second.
Briey press the Volume Up Button.
Briey press the Volume Down Button.
Simultaneously press and hold the Volume Up and
Volume Down Buttons for 1 second.
Simultaneously press and hold the MFB and the
Power Button for 2 seconds.
Press and hold the Volume Down Button for 2 seconds.
Press and hold the Volume Down Button for 1 second.
ENGLISH
9
Troubleshooting
Problems Solutions
ENGLISH
The power does not turn on Check the battery level and charge it.
Cannot make a call with the
HBS-S80
Cannot register the
HBS-S80 to the
mobile phone
The sound is low Control the sound level of the device connected to the HBS-S80.
If the mobile phone does not support headset and hands-free functions,
you cannot use the calling features.
Check the battery level and charge it.
Check whether the HBS-S80 is turned on.
Check whether the HBS-S80 is in Search mode.
-
While the power is off, Simultaneously press and hold the Power Button
and MFB for 2 seconds to turn the power on. The HBS-S80 will change
to Search mode.
Specications and Features
Item Comments
Bluetooth Specications
Battery Battery 3.7 V / 115 mAh, Lithium-ion polymer
Standby Time Up to 400 hours*
Talk Time Up to 6.5 hours*
Music Play Time Up to 6 hours*
Charging Time Less than 2.5 hours
Rated Input Voltage DC 4.75 V ~ 5.3 V, 400 mA
Operating Temperature -10 °C (+14 °F) ~ +50 °C (+122 °F)
Dimensions/Weight [39.2 mm (W) X 74.7 mm (L) X 30.45 mm (H)] X 2 / 27.5 g
Operating Frequency 2402 MHz to 2480 MHz
*Certain features may use more power and cause actual time to vary.
10
V 4.1 (Headset/Hands-Free/A2DP/AVRCP)
Declaration of Conrmation
FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
IMPORTANT NOTE :
To comply with the FCC RF exposure compliance requirements, no change to the antenna or the
device is permitted. Any change to the antenna or the device could result in the device exceeding the
RF exposure requirements and void user’s authority to operate the device.
DECLARATION OF CONFORMITY :
Hereby, LG Electronics declares that this HBS-S80 is in compliance with the essential
requirements and other relevant provisions of Directive1999/5/EC. A copy of the
Declaration of Conformity can be found at http://www.lg.com/global/declaration
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
Qualcomm® aptXTM audio is a product of Qualcomm Technologies International, Ltd.
FCC ID: ZNFEHBSS80
ENGLISH
11
Additional Information
1. Radio frequency exposure
This Bluetooth Stereo Headset HBS-S80 is a radio transmitter and receiver. When in operation,
ENGLISH
it communicates with a Bluetooth equipped mobile device by receiving and transmitting radio
frequency (RF) electromagnetic elds (microwaves) in the frequency range 2.4 to 2.4835 GHz.
Your Bluetooth Headset is designed to operate in compliance with the RF exposure guidelines and
limits set by national authorities and international health agencies when used with any compatible
LG Electronics mobile phone.
2.
Bluetooth
Connection Precautions
The following environments affect the range and reception of Bluetooth signals:
- When walls, metal, human bodies or other obstacles exist between the Bluetooth device and the
connected device
- When equipment that uses 2.4 GHz frequency signals (Wireless LANs, wireless phones, micro
wave ovens etc.) is placed near the devices being used
3. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive atmosphere. It is rare,
but your electronic device could generate sparks. Sparks in such areas could cause an explosion or
re resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often,
but not always, clearly marked.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new battery or one that has not
been used for a long period of time could have reduced capacity the rst few times it is used. Do
not expose the battery to extreme temperatures, never above +50° or below -10°. For maximum
battery capacity, use the battery in room temperature. If the battery is used in low temperatures,
the battery capacity will be reduced. The battery can only be charged in temperatures between
+10° and +45°.
Removal of waste batteries and accumulators (Product with embedded battery ONLY)
- In case this product contains a battery incorporated within the product which cannot be readily
removed by end-users, LG recommends that only qualied professionals remove the battery,
either for replacement or for recycling at the end of this product’s working life. To prevent damage
to the product, and for their own safety, users should not attempt to remove the battery and
should contact LG Service Helpline, or other independent service providers for advice.
12
- Removal of the battery will involve dismantling of the product case, disconnection of the electrical
cables/contacts, and careful extraction of the battery cell using specialized tools. If you need the
instructions for qualied professionals on how to remove the battery safely, please visit
http://www.lge.com/global/sustainability/environment/take-back-recycling.
5. Recycling the battery in your
The battery in your Bluetooth Headset must be disposed of properly and should never be placed in
municipal waste.
Disposal of waste batteries/accumulators
1 This symbol may be combined with chemical symbols for mercury (Hg), cadmium
(Cd) or lead (Pb) if the battery contains more than 0.0005% of mercury, 0.002% of
cadmium or 0.004% of lead.
2 All batteries/accumulators should be disposed separately from the municipal waste
stream via designated collection facilities appointed by the government or the
local authorities.
3 The correct disposal of your old batteries/accumulators will help to prevent
potential negative consequences for the environment, animal and human health.
4 For more detailed information about disposal of your old batteries/accumulators,
please contact your city ofce, waste disposal service or the shop where you
purchased the product.
6. Conditions
- The warranty is valid only if the original receipt issued to the original purchaser by the dealer,
specifying the date of purchase and serial number, is presented with the product to be repaired or
replaced. LG Electronics reserves the right to refuse warranty service if this information has been
removed or changed after the original purchase of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced product shall be
warranted for the remaining time of the original warranty period or for ninety (90) days from
the date of repair, whichever is longer. Repair or replacement may involve the use of functionally
equivalent reconditioned units. Replaced parts or components will become the property of
LG Electronics.
- This Warranty does not cover any failure of the product due to normal wear and tear, or due
to misuse, including but not limited to use in other than the normal and customary manner, in
accordance with instructions for use and maintenance of the product. Nor does this warranty
cover any failure of the product due to accident, modication or adjustment, acts of God or
damage resulting from liquid.
Bluetooth
Headset
ENGLISH
13
- This warranty does not cover product failures due to improper repair installations, modications
or service performed by a non-LG Electronics authorized person. Tampering with any of the seals
on the product will void the warranty.
ENGLISH
Limited Warranty
SUBJECT TO THE CONDITIONS OF THIS LIMITED WARRANTY, LG ELECTRONICS WARRANTS THIS
PRODUCT TO BE FREE FROM DEFECTS IN DESIGN, MATERIAL AND WORKMANSHIP AT THE TIME
OF ITS ORIGINAL PURCHASE BY A CONSUMER, AND FOR A SUBSEQUENT PERIOD OF ONE (1)
YEAR. SHOULD YOUR PRODUCT NEED WARRANTY SERVICE, PLEASE RETURN IT TO THE DEALER
FROM WHOM IT WAS PURCHASED OR CONTACT YOUR LOCAL LG ELECTRONICS CONTACT
CENTER TO GET FURTHER INFORMATION.
Important safety information
Avoiding hearing damage
Permanent hearing loss may occur if you use your Handsfree car kit at a high volume. Set the volume
to a safe level. You can adapt over time to a higher volume of sound that may sound normal but can
be damaging to your hearing.
If you experience ringing in your ears or mufed speech, stop listening and have your hearing
checked. The louder the volume, the less time is required before your hearing could be affected.
Hearing experts suggest that to protect your hearing:
• Limit the amount of time you use Headset at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Please refer to your handset user guide for more information on how to adjust listening levels on
your handset.
Using headsets safely
Use of Headset to listen to music while operating a vehicle is not recommended and is illegal in
some areas. Be careful and attentive while driving. Stop using this device if you nd it disruptive or
distracting while operating any type of vehicle or performing any other activity that requires your
full attention.
14
Manufacturer Info
LG ELECTRONICS INC
128, YEOUI-DAERO, YEONGDUNGPO-GU, SEOUL, KOREA
Production Plants
EM-Tech Viet Nam Co,. Ltd.
Yen Phong Industrials Zone Bac Ninh Province, Viet Nam.
Production Date
Production date indicated on the box
Additional information
(1) Storage
Do not install or store the appliance outdoors or in places exposed to direct weather conditions
(direct sunlight, wind, rain or temperatures below zero degrees)
(2) Transportation
The product is transported by any means of transport in accordance with the rules of transportation
of goods, operating in the this type of transportation.
• Transportation must be carried out under conditions excluding damage.
• Do not expose the product to impact loads during loading and unloading.
(3) Realization
• The sale of products is performed in accordance with the rules established by the current
legislation of the country in which it is realized.
(4) Recycling
• Old electrical products can contain hazardous substances so correct disposal of your old
appliance will help prevent potential negative consequences for the environment and human
health. Your old appliance may contain reusable parts that could be used to repair other
products, and other valuable materials that can be recycled to conserve limited resources.
• For more detailed information about disposal of your old appliance, please contact your city
ofce, waste disposal service or the shop where you purchased the product.
ENGLISH
15
Disposal of your old appliance
1 This crossed-out wheeled bin symbol indicates that waste electrical and electronic
ENGLISH
16
products (WEEE) should be disposed of separately from the municipal waste stream.
2 Old electrical products can contain hazardous substances so correct disposal
of your old appliance will help prevent potential negative consequences for the
environment and human health. Your old appliance may contain reusable parts that
could be used to repair other products, and other valuable materials that can be
recycled to conserve limited resources.
3 You can take your appliance either to the shop where you purchased the product,
or contact your local government waste ofce for details of your nearest authorised
WEEE collection point. For the most up to date information for your country please
see www.lg.com/global/recycling.
Руководство пользователя
LG FORCE™
Беспроводная стереогарнитура Bluetooth
Все права сохранены. LG Electronics Inc., 2016
ПРИМЕЧАНИЕ.
повреждений или неправильного использования HBS-S80 внимательно прочитайте
информацию по использованию HBS-S80.
Любые изменения и исправления типографских ошибок или неточной информации
в данном руководстве могут быть внесены только LG Electronics Inc.
HBS-S80 www.lg.com
Для наилучшего качества работы, а также предотвращения любых
®
РУССКИЙ
LG FORCE (HBS-S80) — это легкая беспроводная гарнитура, поддерживающая
технологию
Bluetooth
Данное изделие можно использовать в качестве аксессуара с устройствами,
поддерживающими профиль
.
Bluetooth
A2DP или HFP.
Особые указания по технике безопасности
! ВНИМАНИЕ
Не следует самостоятельно разбирать, изменять или ремонтировать устройство.
РУССКИЙ
Не следует размещать устройство вблизи источников тепла и легковоспламеняющихся
материалов.
Не следует самостоятельно выполнять замену аккумулятора, поскольку это может привести
к его взрыву.
Использование несовместимого зарядного устройства может привести к повреждению
изделия.
Следите за тем, чтобы маленькие дети не проглотили магниты и другие небольшие
детали изделия.
Не допускайте попадания посторонних предметов в разъемы зарядного устройства
(разъем для зарядки и на вилку питания). Несоблюдение этого требования может
привести к поражению электрическим током или возникновению пожара.
В целях обеспечения собственной безопасности не следует использовать изделие во
время его зарядки.
При наличии имплантированного медицинского прибора перед использованием
устройства следует проконсультироваться с врачом.
Не следует растягивать кабель наушников с чрезмерным усилием.
В целях обеспечения собственной безопасности не следует извлекать встроенный в
изделие аккумулятор.
Литий-ионный полимерный аккумулятор является опасным компонентом, неправильное
обращение с которым может привести к получению травм.
Замена аккумулятора неквалифицированным специалистом может привести к повреждению
устройства.
Не следует самостоятельно производить замену аккумулятора. Повреждение аккумулятора
может привести к его перегреву и получению травм. Замена аккумулятора должна
производиться авторизованным поставщиком услуг. Переработка или утилизация
аккумулятора должна осуществляться отдельно от бытовых отходов.
2
! ПРЕДУПРЕЖДЕНИЕ
Оберегайте изделие от падений с большой высоты.
Не допускайте попадания на изделие спирта или бензола.
Не храните изделие в сырых или пыльных местах.
Не ставьте на изделие тяжелые предметы.
Данное изделие защищено от воздействия пота и влаги (IPx5).
Оно не является водонепроницаемым, поэтому его не следует погружать в воду.
ПРИМЕЧАНИЕ
При попадании на изделие большого количества пота следует выполнить его очистку.
Следует регулярно выполнять очистку наушников.
Динамик HD
Вы можете совершать голосовые вызовы и слушать музыку в режиме аудио высокой
четкости, если сеть связи, используемая на устройстве, к которому подключена
гарнитура, поддерживает передачу голосовых данных в HD-качестве.
Qualcomm® aptX™ audio
В гарнитуре LG HBS-S80 используется технология обработки звука Qualcomm aptX.
Qualcomm aptX — это беспроводная технология
повышение качества звука во время прослушивания музыки и просмотра фильмов.
Функция обработки звука с помощью Qualcomm aptX активируется автоматически,
если мобильный телефон или аудиоустройство поддерживают эту технологию.
Bluetooth
, обеспечивающая
РУССКИЙ
3
Компоненты гарнитуры
Power O
2 sec
Power O
2 sec
FORCE HBS-S80
РУССКИЙ
(Установлены насадки
для наушников среднего
размера)
TM
LG FORCE
Справочное
руководство
ПРИМЕЧАНИЕ. Дизайн изделия может отличаться от изображений, приведенных в
ВНИМАНИЕ
!
Следует использовать только оригинальные компоненты LG Electronics.
Использование неоригинальных компонентов может привести к повреждению
изделия и аннулированию гарантии.
Зарядный кабель
Micro-USB
Руководство
пользователя
настоящем руководстве.
Дополнительные
насадки для
наушников
(маленькие и большие)
Гарантийный талон Карта WEEE
(только для Европы)
4
Чехол
Loading...
